Oracle Sun Storage 2510

Oracle Sun Storage 2510 Oracle Sun Storage 2510 2510

REQUEST A PRICE QUOTE:

    Name*

    Phone

    Details*



    Disks
    Disk Configuration
    Sun StorageTek 2510Up to twelve disk drives as follows:
    • 73GB 15000 RPM, 3 Gb/sec SAS
    • 146GB 15000 RPM, 3 Gb/sec SAS
    • 300GB 15000 RPM, 3 Gb/sec SAS
    • 400GB 10000 RPM, 3Gb/sec SAS
    • 450GB 15000 RPM, 3Gb/sec SAS
    • 500GB 7200 RPM, 3Gb/sec SATA-II
    • 750GB 7200 RPM, 3Gb/sec SATA-II
    • 1TB 7200 RPM, 3Gb/sec SATA-II
    Capacity
    Supported drives/system per tray capacity:raw, unformatted
    73GB Disk drives12 × 73GB = 876GB
    146Gb Disk drives12 × 146GB = 1.75TB
    300GB Disk drives12 × 300GB = 3.6TB
    400GB Disk drives12 × 400GB = 4.8TB
    450GB Disk drives12 × 450GB = 5.4TB
    500GB Disk drives12 × 500GB = 6TB
    750GB Disk drives12 × 750GB = 9TB
    1TB Disk drives12 × 1TB = 12TB
    Note 1: Dynamic capacity expansion of 5 to 36 drives – 365GB to 36TB.
    Note 2: Up to two expansion trays are supported.
    Note 3: Drive depopulation scales from 5 to 12 disk drives per tray.
    Interfaces
    Host interfaces/link speedsUp to four 4 iSCSI 1Gb/s ports per array, up to 1GB cache per controller
    Environment
    Heat Output460 watts (1,571 BTU/hr.)
    AC Power3.96 A Max Opertaing @ 115 VAC (90 – 136 VAC Range), 47/63 Hz
    2.06 A Max Operating @ 240 VAC (180 – 264 VAC Range), 47/63 Hz
    Temperature Operating: 10° C to 40° C (50° F to 104° F), without battery; 10° C to 35° C (50° F to 95° F), with battery
    Non-Operating: -10° C to 50° C (-14° F to 122° F), without battery; -10° C to 45° C (-14° F to 113° F), with battery
    Relative Humidity Operating: 20% to 80% relative humidity, noncondensing
    Non-Operating: 10% to 90% relative humidity, noncondensing, max dew point is 26° C (79° F), 10 percent per hour gradient.
    Altitude Operating: 68.3 kPa (3,200 m), 40° C, four-hour dwell
    Non-Operating: 18.8 kPa (12,200 m), 0° C, four-hour dwell
    Shock Operating: 5.5g’s, 11 ms, half-sine, 10 shocks per direction, all 6 directions
    Non-Operating: 20 G, 8.0 msec square wave in each direction along x,y and z axis. 33 Gs, 11msec, half-sine, three shocks per direction, all six directions
    Vibration Operating: All three axes: 0.25 g’s, 5 to 500 Hz, swept-sine, 5 sweep cycles, 1 octave per minute
    Non-Operating: All three axes:1.2 Gs, five to 500 Hz, swept-sine, 5 sweep cycles, 1 octave per minute
    Dimensions and Weights
    Height86.1 mm (3.39 in)
    Width448.6 mm (17.66 in)
    Depth540 mm (21.26 in)
    Weight (maximum)27.01 kg (59.55 lb) with 12 dis
    Array Controller
    Option #Manufacturing
    Part #    		Description
    XTA-2500-1GBMEM371-45921GB Memory DIMM for STK 25xx Controller Cache Upgrade
    XTA-2501-IOM375-3502SAS Expansion Tray I/O Module (IOM), RoHS:Y
    XTA-2510-CTRL-1GB540-7736StorageTek 2510 iSCSI 1GB Controller Assembly, RoHS:Y
    • 371-2482
    • Battery, RoHS:Y
    • 375-3594
    • iSCSI 1GB Controller w/o battery, RoHS:Y
    XTA-2510-CTRL-512M540-7306StorageTek 2510 iSCSI 512MB Controller Assembly, RoHS:Y
    • 371-2482
    • Battery, RoHS:Y
    • 375-3518
    • iSCSI 512MB Controller w/o battery, RoHS:Y
    Backplane/Centerplane
    Option #Manufacturing
    Part #    		Description
    n/a540-7198Chassis/Midplane Assembly, RoHS:Y
    • 375-3505
    • Midplane, RoHS:Y
    • 540-7261
    • Chassis Assembly, RoHS:Y
    • 540-7262
    • Rear Cage Assembly, RoHS:Y
    Cables
    Option #Manufacturing
    Part #    		Description
    XTA-0.5M-SAS530-38864X Mini SAS Cable, SFF-8088 to SFF-8088, 0.5M, RoHS:YL
    XTA-1.0M-SAS530-38824X Mini SAS Cable, SFF-8088 to SFF-8088, 1M, RoHS:YL
    XTA-2.0M-SAS530-38834X Mini SAS Cable, SFF-8088 to SFF-8088, 2M, RoHS:Y
    XTA-6.0M-SAS530-38874X Mini SAS Cable, 6M, RoHS:YL
    XTA-3.0M-SAS530-38844X Mini SAS Cable, 3M, RoHS:YL
    XTA25X0-0.5M-SAS-Z530-38864X Mini SAS Cable, SFF-8088 to SFF-8088, 0.5M, RoHS:YL
    XTA25X0-1.0M-SAS-Z530-38824X Mini SAS Cable, SFF-8088 to SFF-8088, 1M, RoHS:YL
    XTA25X0-2.0M-SAS-Z530-38834X Mini SAS Cable, SFF-8088 to SFF-8088, 2M, RoHS:Y
    XTA25X0-3.0M-SAS-Z530-38844X Mini SAS Cable, 3M, RoHS:YL
    XTA25X0-6.0M-SAS-Z530-38874X Mini SAS Cable, 6M, RoHS:YL
    n/a530-3100RJ45F to DB9F Adapter, RoHS:Y
    n/a530-3544PS2 6-pin DIN to RJ-45 Cable (2M), RoHS:Y
    n/a530-3880RJ45 to RJ45 Shielded Ethernet Cable, CAT5, 6M, RoHS:Y
    Disks
    Option #Manufacturing
    Part #    		Description
    XTA-SS1NG-300G15K540-7219300GB – 15000 RPM, Disk Assembly with 1 bracket and 1 disk:, RoHS:YL
    • 390-0335
    • Seagate ST3300655SS [ST330055SSUN300G]
      (300GB – 15K RPM – SAS Disk), RoHS:Y
    • 390-0372
    • Hitachi HUS153030VLS300 [HUS1530SBSUN300G]
      (300GB – 15000 RPM – SAS Disk), RoHS:Y
    • 390-0423
    • Seagate ST3300656SS [ST330056SSUN300G]
      (300GB – 15000 RPM – SAS Disk), RoHS:Y
    • 390-0461
    • Seagate ST3300657SS [ST330057SSUN300G]
      (300GB – 15000 RPM – SAS Disk), RoHS:Y
    • 390-0481
    • Hitachi HUS156030VLS600 [HUS1530SCSUN300G]
      (300GB – 15000 RPM – SAS Disk), RoHS:Y
    • 540-7216
    • Bracket, RoHS:Y
    XTA-SS1NG-600GB15K542-0143600GB – 15000 RPM, Disk Assembly with 1 bracket and 1 disk:, RoHS:Y
    • 390-0463
    • Seagate ST3600057SS [ST360057SSUN300G]
      (600GB – 15000 RPM – SAS Disk), RoHS:Y
    • 390-0483
    • Hitachi HUS156060VLS600 [HUS1560SCSUN600G]
      (600GB – 15000 RPM – SAS Disk), RoHS:Y
    • 540-7216
    • Bracket, RoHS:Y
    XTA-ST1NG-1T7K540-76241TB – 7200 RPM, Disk Assembly with 1 bracket and 1 disk:, RoHS:Y
    • 390-0381
    • Hitachi HUA721010KLA330 [HUA7210SASUN1.0T]
      (1TB – 7200 RPM – SATA Disk), RoHS:Y
    • 390-0414
    • Seagate ST31000340NS [ST31000NSSUN1.0T]
      (1TB – 7200 RPM – SATA Disk), RoHS:Y
    • 390-0473
    • Seagate ST31000524NS [ST31001NSSUN1.0T]
      (1TB – 7200 RPM – SATA Disk), RoHS:Y
    • 540-7216
    • Bracket, RoHS:Y
    XTA-ST1NG-2T7K542-01832TB – 7200 RPM, Disk Assembly with 1 bracket and 1 disk:, RoHS:Y
    • 390-0467
    • Hitachi H7220AA30 [H7220AA30SUN2.0T]
      (2TB – 7200 RPM – SATA Disk), RoHS:Y
    • 390-0474
    • Seagate ST32000644NS [ST32000NSSUN2.0T]
      (2TB – 7200 RPM – SATA Disk), RoHS:Y
    • 540-7216
    • Bracket, RoHS:Y
    XTA-SS1NG-146G15K540-7197146GB – 15000 RPM, Disk Assembly with 1 bracket and 1 disk:, RoHS:Y
    • 390-0334
    • Seagate ST3146855SS [ST314655SSUN146G]
      (146GB – 15000 RPM – SAS Disk), RoHS:Y
    • 390-0371
    • Hitachi HUS153014VLS300 [HUS1514SBSUN146G]
      (146GB – 15000 RPM – SAS Disk), RoHS:YL
    • 390-0422
    • Seagate ST3146356SS [ST314656SSUN146G]
      (146GB – 15000 RPM – SAS Disk), RoHS:Y
    • 540-7216
    • Bracket, RoHS:Y
    XTA-SS1NG-400G10K540-7380400GB – 10000 RPM, Disk Assembly with 1 bracket and 1 disk:, RoHS:Y
    • 390-0397
    • Seagate ST3400755SS [ST340008SSUN0.4T]
      (400GB – 10000 RPM – SAS Disk), RoHS:Y
    • 540-7216
    • Bracket, RoHS:Y
    XTA-SS1NG-450GB15K540-7675450GB – 15000 RPM, Disk Assembly with 1 bracket and 1 disk:, RoHS:Y
    • 390-0424
    • Seagate ST3450856SS [ST345056SSUN450G]
      (450GB – 15000 RPM – SAS Disk), RoHS:Y
    • 540-7216
    • Bracket, RoHS:Y
    XTA-SS1NG-73G15K540-719673GB – 15000 RPM, Disk Assembly with 1 bracket and 1 disk:, RoHS:YL
    • 390-0333
    • Seagate ST373455SS [ST373455SSUN72G]
      (73.4GB – 15000 RPM – SAS Disk), RoHS:Y
    • 390-0370
    • Hitachi HUS153073VLS300 [HUS1573SBSUN72G]
      (73GB – 15000 RPM – SAS Disk), RoHS:YL
    • 540-7216
    • Bracket, RoHS:Y
    XTA-ST1NG-500G7K540-7195500GB – 7200 RPM, Disk Assembly with 1 bracket and 1 disk:, RoHS:Y
    • 390-0247
    • Hitachi HDS725050KLA360 [HDS7250SASUN500G]
      (500GB – 7200 RPM – SATA Disk), RoHS:Y
    • 390-0355
    • Seagate ST3500630NS [ST35000NSSUN500G]
      (500GB – 7200 RPM – SATA Disk), RoHS:Y
    • 390-0383
    • Hitachi HUA721050KLA330 [HUA7250SBSUN500G]
      (500GB – 7200 RPM – SATA Disk), RoHS:Y
    • 540-7216
    • Bracket, RoHS:Y
    XTA-ST1NG-750G7K540-7561750GB – 7200 RPM Disk Assembly with 1 bracket and 1 disk:, RoHS:Y
    • 390-0356
    • Seagate ST3750640NS [ST37500NSSUN750G]
      (750GB – 7200 RPM – SATA Disk), RoHS:Y
    • 390-0379
    • Hitachi HUA721075KLA330 [HUA7275SASUN750G]
      (750GB – 7200 RPM – SATA Disk), RoHS:Y
    • 540-7216
    • Bracket, RoHS:Y
    Power
    Option #Manufacturing
    Part #    		Description
    XTA-2500-2UAC-KIT540-7295AC Input Power Supply Assembly, RoHS:Y
    • 300-2051
    • 515 Watt AC Input Power Supply, RoHS:Y
    • 371-2737
    • Plastic Latch, RoHS:Y
    XTA-2500-2UDC-KIT540-7302DC Input Power Supply Assembly, RoHS:Y
    • 300-2073
    • 515 Watt DC Input Power Supply, RoHS:Y
    • 371-2737
    • Plastic Latch, RoHS:Y
    XTA-25X0-CTRL-BATT371-2482Battery, RoHS:Y
    n/a180-2194DC Power Cable, RoHS:Y
    Rack
    Option #Manufacturing
    Part #    		Description
    XTA-2500-2URK-19U594-4405StorageTek 2500 2U Universal Rack Mount Kit
