Oracle Sun Fire X4470 Server

REQUEST A PRICE QUOTE:

Brand:	Oracle / Sun Microsystems
Condition:	Refurbished and new (limited availability)
Availability:	Contact
Shipping Area:	Worldwide to most countries
Shipping Method:	Fedex (most orders), UPS, DHL, Freight Courier
Price:	Please use the quote form above for quick pricing
Payment:	Credit Card, Check, Net Terms (oac), Wire Transfer (required for international orders)
Guarantee:	All items are tested by Oracle trained technicians & backed by a 100% warranty
Questions?	Don’t hesitate to contact us with any questions regarding compatibility or other product info and requests. Our website represents only a fraction of our full inventory. Please reach out with your full requirements

Specs and Information:

Processor

Number

2 or 4 6-Core or 8-Core

Architecture

Type: Intel Xeon 7500 Processor Series

CPUs

Intel 1.86GHz 6-Core Xeon E7530, 105W
Intel 2.00GHz 8-Core Xeon X7550, 130W
Intel 2.26GHz 8-Core Xeon X7560, 130W

Cache memory

256KB unified (data and instruction) Level 2 cache
12MB, 18MB or 24MB shared inclusive Level 3 cache

Main Memory

Capacities

DIMM slots: 64 DIMM slots, 16 DIMMs per CPU
DIMM type: Registered DDR3-1066/PC3-10600 ECC DIMMs
Registered DDR3-1066/PC3-8500 ECC DIMMs
DIMM size: 2GB, 4GB, 8GB
Maximum capacity: 512GB

Standard Integrated Interfaces

Network

Four Integrated 10/100/1000 Base-T Gigabit Ethernet

Network Management

One 10/100 Base-T Ethernet management port

Serial Management

One TIA/EIA-232-F asynchronous RJ45 serial port

USB

Front: 2 USB 2.0 Ports
Rear: 2 USB 2.0 Ports
Internal: 1 USB 2.0 Port

PCI Express

10 PCI Express 2.0 Slots

2 slots (3 and 5) are either x8 or x16 electrical interface (x16 connector)
6 slots are x8 PCI-E slots
2 slots are x4 PCI-E slots

Note: Slots 3 and 5 operate as x16 interfaces only when an x16 capable card is
installed and the adjacent slot (4 or 6) is unpopulated.

Video

One Rear and One Front HD15 VGA port

Graphics controller

VGA 2D graphics controller embedded in Optional Service Processor
Support remote console at a resolution up to 1600x1200x16bits@60Hz
(1024×678 when viewed remotely via ILOM RKVMS)
Note: The rear VGA port supports VESA Device Data Channel for monitor identification.

Internal Mass Storage

Disks

Up to 6 hot-swappable disks

Drive Type	Density	Speed	Form Factor
SAS	146GB, 300GB	10,000 RPM	2.5″

Solid State Drive

Up to six 32GB SATA solid state drive

Power Supplies

Dual redundant, hot swappable power supplies
2000W Capacity (From 200 Volts to 240 Volts)

Environment

Power Consumption

Online power calculator

AC power

100-127 VAC for 2 CPU’s
200-240 VAC for 2 or 4 CPU’s
50/60 Hz Nominal frequencies

Maximum Input Current

12A @ 100VAC / 12A @ 200VAC

Maximum Power Consumption

1800W

Maximum Heat Output

6143 BTU/hr

Temperature

Single, non-rack system:
Operating: 5° C to 35° C (41° F to 95° F)
Operating with 6 Gb SAS PCIe RAID Host Bus Adapter (SGX-SAS6-R-INT-Z): 5° C to 32° C (-40° F to 89.6°F)Nonoperating: -40° C to 68° C (-40° F to 154°F)

Humidity

Single, non-rack system:
Operating: 10% to 90% relative humidity noncondensing
Nonoperating: up to 93% relative humidity noncondensing

Altitude

Single, non-rack system:
Operating: Up to 3048 m (10,000 ft.), maximum operating temperature is derated by 1° C for every 300 m (985 ft) above 900 m (2,952 ft).
Nonoperating: Up to 12,000 m (39,370 ft.)

Acoustic Noise Emissions

LwAd (1B= 10dB) at max ambient: 8.9 B (idle and operating room temperature)
LpAm bystander at max ambient: 75 dBA

Regulations
Meets or exceeds the following requirements:

Safety

IEC 60950, UL/CSA60950, EN60950, CB scheme with all country differences

RFI/EMI

FCC CFR 47 Part 15 Class A, EN55022 Class A, EN300-386, EN 61000-3-2, EN 61000-3-3

Immunity

EN 55024 ,EN 300 386

Certifications

Safety: UL/cUL, UL DEMKO, CCC, CE, BSMI, GOST-R, S-Mark
EMC: CE, FCC, VCCI, ICES, C-Tick, MIC, CCC, GOST-R, BSMI Class A
Other: Labeled per WEEE (Waste Electrical and Electronic Equipment) Directive (2002/96/EC) and RoHS Directive (2002/95/EC)

Dimensions and Weight

Height

129.85 mm (5.1 in.)

Width

436.5 mm (17.2 in.)

Depth

732 mm (28.8 in.)

Weight

Maximum: 38.5 kg (85 lb.)
Minimum: 29.5 kg (65 lb.)

Rack Mounting

Sun Fire X4470 Server Racks (using the X2365A kit)

Racks are as follows:

Sun Rack 1242
Sun Rack 1042

Batteries
Option #	Manufacturing Part #	Description	Previous Part #
n/a	150-3993 [C]	3V Lithium Coin Cell Battery	n/a

CPU Module
Option #	Manufacturing Part #	Description	Previous Part #
X2341A [S]	2 × 1.86 GHz 6-Core Xeon E7530 CPU Modules and one of the following CPU heat sinks:
	310-0228 [F]	CPU Heatsink	n/a
	371-4721 [F]	1.86 GHz 6-Core Xeon E7530 CPU Module	n/a
X2342A [S]	2 × 2.0 GHz 8-Core Xeon X7550 CPU Modules and 1 of the following CPU heat sinks:
	310-0228 [F]	CPU Heatsink	n/a
	371-4692 [F]	2.00GHz 8-Core Xeon X7550 CPU Module	n/a
X2343A [S]	2 × 2.26GHz 8-Core Xeon X7560 CPU Modules X-Option
	310-0228 [F]	CPU Heatsink	n/a
	371-4860 [F]	2.26GHz 8-Core Xeon X7560 CPU Module	n/a

Cables
Option #	Manufacturing Part #	Description	Previous Part #
X2130A-1M-N	530-4441 [C]	10Gbps SFP+ TwinX Cable, 1m	n/a
X2130A-3M-N	530-4442 [C]	10Gbps SFP+ TwinX Cable, 3m	n/a
X2130A-5M-N	530-4443 [C]	10Gbps SFP+ TwinX Cable, 5m	n/a
X2130A-10M-N [S]	530-4454 [C]	10Gbps SFP+ TwinX Cable, 10m	n/a

Chassis
Option #	Manufacturing Part #	Description	Previous Part #
n/a	341-5805	Rack Mount Ear	n/a

Communication
Option #	Manufacturing Part #	Description	Previous Part #
X4242A	375-3696 [C]	Dual 40Gbps InfiniBand 4x QDR PCI Express Low Profile Host Channel Adapter	n/a
X4242A	7092767 [C]	Dual 40Gbps InfiniBand 4x QDR PCI Express Low Profile Host Channel Adapter	n/a
X4237A-N [S]	375-3606 [C]	Sun Dual Port 40Gb/sec 4x Infiniband QDR Host Channel Adapter PCI Express	n/a

Disk Backplane
Option #	Manufacturing Part #	Description	Previous Part #
n/a	511-1246 [F]	6-Slot Disk Backplane	n/a

Disks
Option #	Manufacturing Part #	Description	Previous Part #
XRA-SS2CF-600G10K2	542-0287 [C]	600GB – 10000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks;	n/a
	390-0488	Hitachi HUC106060CSS600 [H106060SDSUN600G] (600GB – 10000 RPM – SAS Disk)	n/a
	7045228	Hitachi HUC109060CSS600 [H109060SESUN600G] (600GB – 10000 RPM – SAS Disk)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a
XRB-SS2CF-300G10K2	542-0388 [C]	300GB – 10000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks:	n/a
	390-0487	Hitachi HUC106030CSS600 [H106030SDSUN300G] (300GB – 10000 RPM – SAS Disk)	n/a
	390-0490	Seagate ST9300605SS [ST930005SSUN300G](300GB 10000 RPM SAS Disk)	n/a
	7045226	Hitachi HUC109030CSS600 [H109030SESUN300G] (300GB – 10000 RPM – SAS Disk)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a
XRA-SS2CF300G10K-N [S]	540-7869 [C]	300GB – 10000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks:	n/a
	390-0449	Seagate ST9300603SS [ST930003SSUN300G] (300GB – 10000 RPM – SAS Disk)	n/a
	390-0451	Hitachi HUC103030CSS600 [H103030SCSUN300G] (300GB – 10000 RPM – SAS Disk)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a
XRA-ST2CF32G2SSD-N [S]	540-7841 [C]	32GB Solid State SATA Drive Assembly	n/a
	371-4196	Intel SSDSA2SH032G1SB [Inquiry Unknown] (32GB – 2.5″ Solid State – SATA Disk)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a
XRB-SS2CF146G10K-N [S]	540-7868 [C]	146GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks:	n/a
	390-0324	Seagate ST9146802SS [ST914602SSUN146G] (146GB – 10000 RPM – SAS Disk)	n/a
	390-0377	Hitachi HUC101414CSS300 [H101414SCSUN146G] (146GB – 10000 RPM – SAS Disk)	n/a
	390-0448	Seagate ST9146803SS [ST914603SSUN146G] (146GB – 10000 RPM – SAS Disk)	n/a
	390-0450	Hitachi HUC103014CSS600 [H103014SCSUN146G] (146GB – 10000 RPM – SAS Disk)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a

Ethernet
Option #	Manufacturing Part #	Description	Previous Part #
X1109A-Z	7051223 [C]	Dual 10-Gigabit PCI Express Ethernet SFP+ LP	375-3617 [C]
X2129A-N	530-4449 [C]	10Gb/Sec Short Wave SFP+ Transceiver	n/a
X5562A-Z	135-1205 [C]	10Gb/Sec Long Wave SFP+ Transceiver	n/a
SG-XPCIEFCOE2-Q-SR [S]	7053422 [C]	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA – SR	375-3681 [C]
SG-XPCIEFCOE2-Q-TA [S]	7053423 [C]	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA – Direct Attach	375-3682 [C]
X4446A-Z-N [S]	7054739 [C]	PCI Express Quad Gigabit Ethernet UTP	375-3481 [C]
n/a	375-3481 [C]	PCI Express Quad Gigabit Ethernet UTP	n/a
n/a	375-3617 [C]	Dual 10-Gigabit Ethernet SFP+ LP	n/a
n/a	375-3681 [C]	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA – SR	n/a
n/a	375-3682 [C]	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA – Direct Attach	n/a

Fan
Option #	Manufacturing Part #	Description	Previous Part #
n/a	541-3535 [F]	Fan Cage Assembly	n/a
	511-1243	Fan Board with USB and VGA	n/a
	530-4349 [F]	LED Flex Circuit	n/a
n/a	541-3539 [C]	92mm Fan Module	n/a

Fibre Channel
Option #	Manufacturing Part #	Description	Previous Part #
SG-XPCIE2FC-EM8-N	7053434 [C]	8Gigabit/Sec PCI Express Dual FC Host Adapter	371-4306 [C]
SG-XPCIE2FC-QF8-N	371-4325 [C]	8Gigabit/Sec PCI Express Dual FC Host Adapter	n/a
SG-XPCIE1FC-EM8-N [S]	371-4295 [C]	8Gigabit/Sec PCI Express Single FC Host Adapter	n/a
SG-XPCIE1FC-EM8-N [S]	7053433 [C]	8Gigabit/Sec PCI Express Single FC Host Adapter	n/a
SG-XPCIE1FC-QF8-N [S]	371-4324 [C]	8Gigabit/Sec PCI Express Single FC Host Adapter	n/a
n/a	371-4306 [C]	8Gigabit/Sec PCI Express Dual FC Host Adapter	n/a

Memory
Option #	Manufacturing Part #	Description	Previous Part #
X2350A [S]	2 × Memory Riser X-Option
	541-3819 [C]	Memory Riser Assembly	n/a
	341-5773	Memory Riser Tray	n/a
	511-1241	Memory Riser Board	n/a
X2352A [S]	330-4839	Memory Slot Filler	n/a
X8503A [S]	4GB (2 × 2GB DDR3-1066) Memory Kit X-Option
	542-0244 [C]	2 × 2GB DDR3-1333 DIMMs	n/a
	371-4774	2GB DDR3-1333 DIMM	n/a
X8504A [S]	8GB (2 × 4GB DDR3-1066) Memory Kit X-Option
	542-0245 [C]	2 × 4GB DDR3-1333 DIMMs	n/a
	371-4972	4GB DDR3-1333 DIMM	371-4775
X8505A [S]	16GB (2 × 8GB DDR3-1066) Memory Kit X-Option
	542-0246 [C]	2 × 8GB DIMMs	n/a
	371-4776	8GB DDR3/3L-1066/1333 DIMM	n/a
n/a	330-5269	Memory Riser Filler	n/a

Miscellaneous
Option #	Manufacturing Part #	Description	Previous Part #
X2361A [S]	798-6250	Sun Fire X4470 Media and Documentation Kit	n/a

Power
Option #	Manufacturing Part #	Description	Previous Part #
n/a	300-2228 [C]	Type A239A 2000 Watt AC Input Power Supply	n/a
n/a	300-2344 [C]	Type A239C 1030/2060 Watt AC Input Power Supply	n/a
n/a	541-3541 [F]	Power Distribution Board / Power Supply Backplane	n/a
	371-4446	Bus Bar	n/a
	511-1242	Power Distribution Board	n/a
n/a	7022322 [F]	Power Distribution Board / Power Supply Backplane	541-3541 [F]
	371-4446	Bus Bar	n/a
	7022323	Power Distribution Board	n/a

Rack
Option #	Manufacturing Part #	Description	Previous Part #
X2364A	371-4812 [C]	Cable Management Arm	n/a
X2365A	371-4791 [C]	Tool-less Slide Rail Rack Mount Kit	n/a

Removable Media
Option #	Manufacturing Part #	Description	Previous Part #
X8370A [S]	541-4272 [C]	Slot-Load DVD Assembly	n/a
	341-5807	Mounting Tray	n/a
	341-6168	Bezel	n/a
	390-0443	8x Slot-Load SATA DVD-Writer/24x CD-Writer	n/a

SCSI
Option #	Manufacturing Part #	Description	Previous Part #
SGX-SAS6-R-INT-Z ¹	7047503 [C]	8-Port 6Gbps SAS-2 RAID PCI Express HBA, B4 ASIC	375-3701 [C]
SGX-SAS6-R-INT-Z ¹	7050794 [C]	6Gbps SAS-2 RAID PCI Battery Module, BBU08	371-4982 [C]
SGX-SAS6-EXT-Z [S]	7047853 [C]	8-Port 6Gbps SAS-2 PCI Express HBA (LSI)	375-3641 [C]
SGX-SAS6-INT-Z ² [S]	7047852 [C]	8-Port 6Gbps SAS-2 PCI Express HBA (LSI)	375-3640 [C]
XTA-FAS-S3IE96GB-N [S]	541-3731	96GB PCI Express Flash Accelerator F20 SAS HBA	n/a
	371-4650 [C]	Energy Storage Module (ESM)	n/a
	511-1500 [C]	PCI Express Flash Board	n/a
	7061269 [C]	24GB Solid State Flash Memory Module, FW D21Y	371-4415 [C]
n/a	371-4415 [C]	24GB Solid State Flash Memory Module	n/a
n/a	371-4746 [C]	6Gbps SAS-2 RAID PCI Battery Module, BBU07	n/a
n/a	371-4982 [C]	6Gbps SAS-2 RAID PCI Battery Module, BBU08	371-4746 [C]
n/a	375-3640 [C]	8-Port 6Gbps SAS-2 PCI Express HBA (LSI)	n/a
n/a	375-3641 [C]	8-Port 6Gbps SAS-2 PCI Express HBA (LSI)	n/a
n/a	375-3644 [C]	8-Port 6Gbps SAS-2 RAID PCI Express HBA, B2 ASIC	n/a
n/a	375-3701 [C]	8-Port 6Gbps SAS-2 RAID PCI Express HBA, B4 ASIC	375-3644 [C]

¹ Supported in slot 4; See product notes (821-0704) for more information.
² Supported in slot 2

System Board
Option #	Manufacturing Part #	Description	Previous Part #
n/a	541-3540 [F]	System Board Assembly	n/a
	150-3993 [C]	3V Lithium Coin Cell Battery	n/a
	341-5567	System Board Tray	n/a
	511-1240	System Board	n/a
	511-1245	Rear I/O Board	n/a
	530-3510	Interlock Switch Cable	n/a
	530-4348	System Board to Rear I/O Board Signal Cable	n/a

Industry Leading Quality, Support and Integrity

Quality Inspection Checklist
Before it leaves our facility, every used and refurbished item is thoroughly inspected by our certified technicians and undergoes our exclusive Quality Inspection Checklist to ensure 100% satisfaction guarantee.

Greentec Systems is a leading provider
For server, networking and storage equipment. We have an extensive array of inventory of IBM Servers & Storage, Sun Servers & Storage, Cisco Networking (Switches, Routers, Security), and NetApp Storage (disk shelves, disk drives, Filers, NearStore, NetCache). If you don’t see the item or product you require please contact us.

Have this equipment to sell?
Depending on the age and condition of the equipment, there is a very good likelihood that we will be able to offer you cash or trade-in credit for other IT hardware. If the equipment is very old we can also assist you with properly decommissioning that gear in the most environmentally friendly way possible.

Questions?
For more information please contact 888.333.7388, or fill out the quote from above. We’d love to hear from you.
