Oracle Sun X2100 Server

Oracle Sun X2100 Server Oracle Sun X2100 Server Sun Servers SUN FIRE X2100 copy

REQUEST A PRICE QUOTE:

    Name*

    Phone

    Details*



    Processor
    Number1 (Single or Dual-Core)
    Architecture Type: AMD Opteron Socket 939 Processor
    Single Core: 146 (2.0GHz), 148 (2.2GHz), or 152 (2.6GHz)
    Dual Core: 175 (2.2GHz)
    Cache memory1 MB Level 2 cache per processor core
    Main Memory
    Capacities DIMM slots: 4
    DIMM type: unbuffered DDR1/400 ECC DIMMs (128 bit plus ECC databus)
    DIMM size: 512-MB, 1-GB or 2-GB
    Maximum capacity: 8GB
    Standard Integrated Interfaces
    NetworkTwo 10/100/1000Base-T Ethernet ports (nge0=LAN1 and bge0=LAN2)
    Network ManagementLights Out Management (LOM) via optional Service Processor
    Serial ManagementOne Serial TIA/EIA-232-F asynchronous HD-9 port
    SATAFour channel SATA interface, internal access only.
    USB Front: Two USB 2.0 ports
    Rear: Four USB 2.0 ports
    Expansion busOne internal 64-bit PCI-Express riser slot (8-lane, low-profile, short length)
    Graphics controllerATI Rage XL graphics controller with 8MB memory
    Internal Mass Storage
    DisksUp to two hot-pluggable 3.5″ Disks (80GB or 250GB 7200 RPM SATA HDD)
    DVD-ROMOne EIDE ATAPI Slot Loading DVD-ROM (optional)
    Power Supplies
    Single, hot pluggable power supply
    (Maximum DC output = 300W)
    (Maximum AC output = 300W x 1.33 efficiency)
    Environment
    AC power90-264 V AC (47-63 Hz)
    TemperatureSingle, non-rack system:
    Operating: 5° C to 35° C (41° F to 95° F)
    Nonoperating: -40° C to 65° C (-40° F to 149° F)
    HumiditySingle, non-rack system:
    Operating: 10% to 90% relative humidity noncondensing, 27° C (80.6° F) max wet bulb
    Nonoperating: up to 93% relative humidity noncondensing, 38° C (100.4° F) max wet bulb
    AltitudeSingle, non-rack system:
    Operating: up to 3000 m (10,000 ft.), maximum ambient temperature is derated by 1° C per 500 m above 500 m
    Nonoperating: up to 12,000 m (40,000 ft.)
    Acoustic noiseSingle, non-rack system:
    Less than 76 dB sound power in ambient temperature of up to 24° C
    Regulations
    Meets or exceeds the following requirements:
    SafetyIEC60950, UL/CSA60950-1, EN60950, CB Scheme with all country differences
    RFI/EMIFCC Class A, Part 15 47 CFR, EN55022, CISPR 22, EN300-386:v1.31, ICES-003
    ImmunityEN55024, EN300-386:v1.3.2
    Certifications Safety: cULus Mark, TUV GS Mark, CE Mark, CCC, GOST R, S-Mark
    EMC: CE Mark (93/68/EEC), Emissions and Immunity Class A Emissions Levels: FCC, VCCI, BSMI, C-Tick, MIC, CCC, GOST
    Other: Labeled per WEEE (Waste Electrical and Electronic Equipment) Directive 2002/95/EC
    Dimensions and Weight
    Height43 mm (1.69 in.)
    Width425.5 mm (16.75 in.)
    Depth550 mm (21.68 in.)
    Weight (with packaging)18 kg (39.7 lb.) maximum with slide rail kit
    CPU Module
    Option #Manufacturing
    Part #    		Description
    8073A310-0056CPU Heatsink
    370-79412.6GHz Opteron 152 Socket 939 (E4 Stepping), RoHS:Y
    8071A310-0056CPU Heatsink
    371-07342.0GHz Opteron 146 Socket 939 (E4 Stepping)
    8071A-Z310-0098CPU Heatsink, RoHS:Y
    8072A310-0056CPU Heatsink
    370-79402.2GHz Opteron 148 Socket 939 (E4 Stepping), RoHS:Y
    8072A-Z310-0098CPU Heatsink, RoHS:Y
    370-79402.2GHz Opteron 148 Socket 939 (E4 Stepping), RoHS:Y
    8074A310-0056CPU Heatsink
    371-08832.8GHz Opteron 154 Socket 939 (E4 Stepping), RoHS:Y
    8074A-Z310-0098CPU Heatsink, RoHS:Y
    371-08832.8GHz Opteron 154 Socket 939 (E4 Stepping), RoHS:Y
    8075A-Z310-0098CPU Heatsink, RoHS:Y
    371-08843.0GHz Opteron 156 Socket 939 (E4 Stepping), RoHS:Y
    8076A-Z310-0098CPU Heatsink, RoHS:Y
    371-08862.6GHz Dual Core Opteron 185 Socket 939 (E6 Stepping), RoHS:Y
    8084A310-0056CPU Heatsink
    371-08852.4GHz Dual Core Opteron 180 Socket 939 (E6 Stepping), RoHS:Y
    8084A-Z310-0098CPU Heatsink, RoHS:Y
    371-08852.4GHz Dual Core Opteron 180 Socket 939 (E6 Stepping), RoHS:Y
    8085A310-0056CPU Heatsink
    371-07352.2GHz Dual Core Opteron 175 Socket 939 (E6 Stepping)
    n/a310-0065X23-7783D Thermal Grease Syringe, RoHS:Y
    Cables
    Option #Manufacturing
    Part #    		Description
    X311LLocalized Power Cord Kit – North America/Asia, RoHS:Y
    180-1097IEC 320 C13 to NEMA 5-15P – 15A/125V 2.5M Black, RoHS:Y
    X312ELocalized Power Code Kit – China, RoHS:Y
    180-1982IEC 320 C13 to GB 2099/GB 1002 – 10A/250V 2.5M, RoHS:Y
    X312LLocalized Power Cord Kit – Continental Europe, RoHS:Y
    180-1993IEC 320 C13 to CEE 7/7 10A/250V 2.5M Black, RoHS:Y
    X314LLocalized Power Cord Kit – Swiss, RoHS:Y
    180-1994IEC 320 C13 to SEV 1011 – 10A/250V 2.5M Black, RoHS:Y
    X317LLocalized Power Cord Kit – U.K., RoHS:Y
    180-1997IEC 320 C13 to BS 1363 – 10A/250V 2.5M Black, RoHS:Y
    X332ALocalized Power Cord Kit – Taiwan, RoHS:Y
    180-2121IEC 320 C13 to NEMA 5-15P – 10A/125V 2.5M Black, RoHS:Y
    X384LLocalized Power Cord Kit – Italian, RoHS:Y
    180-1996IEC 320 C13 to CEI 23-16/VII – 10A/250V 2.5M Black, RoHS:Y
    X386LLocalized Power Cord Kit – Australian, RoHS:Y
    180-1998IEC 320 C13 to AS 3112 – 10A/250V 2.5M Black, RoHS:Y
    n/a180-1995IEC 320 C13 to Asfnit 107 – 10A/250V 2.5M Black, RoHS:Y
    Communication
    Option #Manufacturing
    Part #    		Description
    X6000A375-3424PCI Express Sun Crypto Accelerator 6000, RoHS:Y
    Disk Backplane
    Option #Manufacturing
    Part #    		Description
    n/a371-07332-Slot SATA Disk Backplane
    n/a371-16052-Slot SATA Disk Backplane, RoHS:Y
    Disks
    Option #Manufacturing
    Part #    		Description
    X8078A540-6596250GB – 7200 RPM SATA, Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
    • 370-7948
    • Seagate ST3250823AS
      (250GB – 7200 RPM – SATA Disk), RoHS:Y
    • 371-0114
    • Hitachi HDS722525VLSA80
      (250GB – 7200 RPM – SATA Disk), RoHS:Y
    • 540-6562
    • 1″ SPUD Bracket, RoHS:Y
    X8079A540-659580GB – 7200 RPM SATA, Disk Assembly with 1 bracket and 1 of the following disks, RoHS:Y:
    • 370-7947
    • Seagate ST380013AS
      (80GB – 7200 RPM – SATA Disk)
    • 371-0113
    • Hitachi HDS728080PLA380
      (80GB – 7200RPM – SATA Disk), RoHS:Y
    • 540-6562
    • 1″ SPUD Bracket, RoHS:Y
    Ethernet
    Option #Manufacturing
    Part #    		Description
    X7280A-2371-0905PCI Express Dual Gigabit Ethernet UTP, RoHS:Y
    X7281A-2371-0904PCI Express Dual Gigabit Ethernet MMF, RoHS:Y
    Fan
    Option #Manufacturing
    Part #    		Description
    n/a371-0737Single Fan Assembly
    n/a371-0770Dual Fan Assembly
    Fibre Channel
    Option #Manufacturing
    Part #    		Description
    SG-XPCIE1FC-EM4375-33964Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
    SG-XPCIE1FC-QF4375-33554Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
    SG-XPCIE2FC-EM4375-33974Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
    SG-XPCIE2FC-QF4375-33564Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
    I/O
    Option #Manufacturing
    Part #    		Description
    n/a371-0732PCI Express Riser with Bracket
    n/a371-0738Front I/O Board
    Memory
    Option #Manufacturing
    Part #    		Description
    X4211A-Z4GB (2 × 2GB DDR266/PC2100 ECC DIMM) Option, RoHS:YL
    540-70772GB Memory FRU, RoHS:Y
    • 371-2102
    • 2GB DDR266/PC2100 ECC Unbuffered DIMM, RoHS:Y
    X8006A2GB (2 × 1GB DDR400/PC3200 ECC DIMM) Option
    540-64652GB (2 × 1GB) Memory FRU, RoHS:Y
    • 370-7944
    • 1GB DDR400/PC3200 ECC Unbuffered DIMM, ROHS:Y
    X8007A1GB (2 × 512MB DDR400/PC3200 ECC DIMM) Option
    540-64641GB (2 × 512MB) Memory FRU, RoHS:Y
    • 370-7943
    • 512MB DDR400/PC3200 ECC Unbuffered DIMM, RoHS:Y
    Power
    Option #Manufacturing
    Part #    		Description
    n/a300-1835300 Watt Power Supply, ROHS:Y
    Removable Media
    Option #Manufacturing
    Part #    		Description
    X8082A371-07368x DVD-ROM/24x CD-ROM Drive
    SCSI
    Option #Manufacturing
    Part #    		Description
    SG-XPCIE2SCSIU320Z375-3357Dual-Channel Ultra320 LVD SCSI PCI Express Adapter, RoHS:Y
    SG-XPCIE8SAS-E-Z375-3487PCI Express 8-Port Host Adapter, RoHS:Y
    System Board
    Option #Manufacturing
    Part #    		Description
    n/a375-3342System Board
    System Service Processor
    Option #Manufacturing
    Part #    		Description
    X8081A371-0743Service Processor
