Oracle Sun Ultra 25 Workstation

Sun Ultra 25 Specifications and Pricing Quote

Greentec Systems is proud to offer the legacy Sun Ultra 25 Workstation combines the legendary quality and reliability of Sun SPARC/Solaris OS-based workstations with improved performance, capacity, and graphics, to meet the demands of today’s enterprise-class applications. Every Sun

The refurbished Sun Ultra 25 Workstation is powered by a 1.34-GHz UltraSPARC IIIi processor, with enhanced peripheral support and graphics options, and ships with the Solaris 10 OS preinstalled and a full suite of time-saving development tools that can be immediately deployed to start software development.

Visualization and graphics capabilities are delivered across a PCI-Express graphics bus— doubling the bandwidth of AGP 8x and enabling significant performance improvements over existing PCI-based graphics solutions. Sun’s new XVR-2500 3-D graphics accelerator, with over 80 million peak 3-D Gouraud-shaded X-buffered triangles per second, delivers a 3.3 x performance improvement over Sun’s previous generation XVR-1200.

The Sun Ultra 25 Workstation boosts capacity and storage options over previous generations, offering dual Gigabit Ethernet, five I/0 expansion slots—two PCI Express x16 slots, one PCI-Express x8 slot and two PCI-X 100-MHz full-length expansion slots—and support for up to four 250-GB internal SATA hard drives. With a maximum memory of up to eight GB and one TB of internal storage, the Sun Ultra 25 Workstation has the capacity to handle datasets of any size.

The Sun Ultra 25 Workstation—loaded with a complete set of award-winning software development tools, grid-enabled, and deliver- ing the legendary quality and reliability of Sun workstations—is a great step

Sun Ultra 25 Highlights

Ultimate upgrade platform for all SPARC®/SolarisTM OS-based workstation users
Single UltraSPARC® IIIi processor combines with the SolarisTM 10 Operating System to deliver binary compatibility from the desktop to the data center, as well as seam- less upgradability
Comes preinstalled with the Solaris 10 or 11 OS and a complete suite of permanently licensed Sun software development tools, including Sun JavaTM Studio, Sun StudioTM, and the JavaTM Enterprise System
New PCI-Express-based graphics solutions offer 3.3 x the performance of current graphics offerings
Dual PCI-Express x16 graphics slots, single PCI-Express x8 slot, and dual PCI-X 100-MHz slots deliver superior graphics and I/O performance
Grid-enabled with included N1TM Grid Engine software license

Oracle Sun Ultra 25 Processor
Number	One The processor communicates with the system I/O through the 167MHz Jbus interface.
Architecture	1.34GHz UltraSPARC IIIi:
Cache memory	1MB Level 2
Oracle Sun Ultra 25 Main Memory (RAM)
Capacities	Characteristics of the DDR-1 ECC-protected memory include: Maximum system memory – 8GB (using 2GB DIMMS) Maximum DIMMS – 4 (8GB max) Maximum DIMM slots – 4 Two physical banks of two DIMMs DIMM sizes offered – 512MB, 1GB, or 2GB DDR-1 registered ECC memory at 266 MHz Processor accesses memory across the 128-bit data bus. Must be installed in pairs.
Standard Interfaces
Audio	Four AC97 ports as follows: Two in front Two in rear
Ethernet	Two 10/100/1000 BaseT (Gigabit) ethernet ports (rear of workstation)
Expansion Slots	Five slots as follows: Two PCI-Express: both mechanical (x16) and electrically (x8) One PCI-Express mechanical (x8) and electrically (x4) Two PCI-X 100MHz/64 bit slots
Serial	Two ports (rear of workstation)
USB	Six ports as follows: Two USB 2.0 ports in front Four USB 2.0 ports in rear
Internal Storage
Disks	Allows a maximum of four internal 3.5″ SAS (146GB – 15000 RPM) or SATA (80GB or 250GB – 7200 RPM) disk drives. Drives are supported by an integrated PCI-X SAS/SATA disk controller.
Optical Disk Drives	Optical disk drive as follows: One 8x DVD-RW/24x CD-RW (Slot-loading) ATAPI – Interface Note: Systems that ship without an optical disk drive require an optical disk drive EMI filler panel in the unoccupied bay to cover the slot opening.
Graphics
Cards	Supported cards. Note: Solaris 10 currently does not support dual graphics cards, each driving a monitor.
Environment
AC Power	Voltage: 110-127/200-240 VAC Frequency: 50-60 Hz, 10/6 Amps
Input Current	6.4 amps @ 100 VAC, 3.2 amps @ 200 VAC
Power consumption	Power Supply – 1000 Watts (maximum)
Temperature	Operating: 2° C to 35° C (41° F to 95° F) at 3000 meters Nonoperating:-40° C to 68° C (-40° F to 158° F) at 12000 meters
Humidity	Operating: 7% to 93% relative humidity, non-condensing Nonoperating: 93% relative humidity, non-condensing
Acoustic noise	Operating:LWAd (1B=10db) 5.0 B LpAm (by standard position) 42 dBA Idling: LWAd (1B=10db) 4.5 B LpAm (by standard position) 38 dBA
Shock	Operating: 5 G’s, 11 msec, half-sine Nonoperating: 30 G’s, 11 msec, half-sine
Regulations
Meets or exceeds the following requirements:
RoHS Compliance Level	RoHS:Y
Safety	IEC60950 CB, UL/CSA-60950, EN60950
RFI/EMC	Class B, FCC CFR47, part 15 Class B; EN 6100-3-2, EN 61000-3-3
Immunity	EN55024 All applicable levels
Regulatory Markings	UL/cUL, TUV-GS, CE FCC, VCCI, ICES-003, CCC, C-tick, GOST-R, MIC, S-Mark, EEE, BSMI
Ergonomics	EK1-1TB-2000, RFI/EMC, EN 55022/CISPR22
Power Management	EPA MOU 3 (Supports PowerNow standard ACPI power states for Windows)
Oracle Sun Ultra 25 Dimensions and Weights
Height	445 mm (17.5 in)
Width	205 mm (8.1 in)
Depth	569 mm (22.4 in)
Weight	26.31 kg (58 lbs) fully configured depending on configuration

Cables
Option #	Manufacturing Part #	Description
X311L	Localized Power Cord Kit – North America/Asia, RoHS:Y
X311L	180-1097	IEC 320 C13 to NEMA 5-15P – 15A/125V 2.5M Black, RoHS:Y
X312E	Localized Power Code Kit – China, RoHS:Y
X312E	180-1982	IEC 320 C13 to GB 2099/GB 1002 – 10A/250V 2.5M, RoHS:Y
X312F	Localized Power Cord Kit – Argentina, RoHS:Y
X312F	180-1999	IEC 320 C13 to IRAM 2073 – 10A/250V 2.5M Black, RoHS:Y
X312G	Localized Power Cord Kit – Korea, RoHS:Y
X312G	180-1662	IEC 320 C13 to KSC 8305 – 15A/250V 2.5M Black, RoHS:Y
X312L	Localized Power Cord Kit – Continental Europe, RoHS:Y
X312L	180-1993	IEC 320 C13 to CEE 7/7 10A/250V 2.5M Black, RoHS:Y
X314L	Localized Power Cord Kit – Swiss, RoHS:Y
X314L	180-1994	IEC 320 C13 to SEV 1011 – 10A/250V 2.5M Black, RoHS:Y
X317L	Localized Power Cord Kit – U.K., RoHS:Y
X317L	180-1997	IEC 320 C13 to BS 1363 – 10A/250V 2.5M Black, RoHS:Y
X383L	Localized Power Cord Kit – Danish, RoHS:Y
X383L	180-1995	IEC 320 C13 to Asfnit 107 – 10A/250V 2.5M Black, RoHS:Y
X384L	Localized Power Cord Kit – Italian, RoHS:Y
X384L	180-1996	IEC 320 C13 to CEI 23-16/VII – 10A/250V 2.5M Black, RoHS:Y
X386L	Localized Power Cord Kit – Australian, RoHS:Y
X386L	180-1998	IEC 320 C13 to AS 3112 – 10A/250V 2.5M Black, RoHS:Y
n/a	530-2961	RJ45 Cat5 Ethernet Cable, RoHS:Y
n/a	n/a	Ultra 40 M2 Disk Backplane SATA Data Cable 422755900001 (155mm)

Communication
Option #	Manufacturing Part #	Description
X1355A-2	371-0982	2M, 80-Pin, 4-Port, DB37, RS449 Breakout Cable,RoHS:Y
X1355A-2	375-3296	Quad Port High Speed Serial Interface PCI-X (HSI/U), RoHS:Y
X2156A-2	375-3420	Serial Asynchronous Interface PCI (SAI/P) 3.0, RoHS:Y
X6000A	375-3424	PCI Express Sun Crypto Accelerator 6000, RoHS:Y

Disk Backplane
Option #	Manufacturing Part #	Description
n/a	F373-0020	Disk Backplane, RoHS:Y
	373-0020	Disk Backplane, RoHS:Y
	n/a	Ultra 40 Disk Backplane SATA Data Cable 422740700002 (230 mm)
	n/a	Ultra 40 M2 Disk Backplane SATA Data Cable 422755900001 (155mm)
	n/a	Ultra 25/45 Disk Backplane SAS/SATA Data Cable 422739300001 (75mm)

Disks
Option #	Manufacturing Part #	Description
XRA-SS1CE-146G15K	146GB – 15000 RPM SAS Disk Option, RoHS:Y
	540-7088	146GB – 15000RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:YL
	390-0334	Seagate ST3146855SS [ST314655SSUN146G] (146GB – 15000 RPM – SAS Disk), RoHS:Y
	390-0338	Seagate ST3146854SS [ST314654SSUN146G] (146GB – 15000 RPM – SAS Disk), RoHS:YL
	390-0371	Hitachi HUS153014VLS300 [HUS1514SBSUN146G] (146GB – 15000 RPM – SAS Disk), RoHS:YL
	540-6562	1″ SPUD Bracket, RoHS:Y
XRA-ST1CE-250G7K	250GB – 7200 RPM SATA Disk Option, RoHS:Y
	540-6485	250GB – 7200 RPM SATA, Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
	390-0354	Seagate ST3250820NS [ST32500NSSUN250G] (250GB – 7200 RPM – SATA Disk), RoHS:Y
	540-6562	1″ SPUD Bracket, RoHS:Y
	540-6666	250GB – 7200 RPM SATA, Disk Assembly with 1 bracket and 1 of the following disks, RoHS:Y
	390-0295	Hitachi HDT722525DLA380 [HDS7225SBSUN250G] (250GB – 7200 RPM – SATA Disk), RoHS:Y
	540-6562	1″ SPUD Bracket, RoHS:Y
XRC-ST1CE-160G7KZ	160GB – 7200 RPM SATA Disk Option, RoHS:Y
	540-7112	160GB – 7200 RPM SATA, Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
	390-0317	Hitachi HDT722516DLA380 [HDS7216SASUN160G] (160GB – 7200 RPM – SATA Disk), RoHS:Y
	390-0318	Seagate ST3160812AS [STA7216SASUN160G] (160GB – 7200 RPM – SATA Disk), RoHS:Y
	390-0351	Hitachi HDT721616PLA380 [HDS7216SBSUN160G] (160GB – 7200 RPM – SATA Disk), RoHS:Y
	540-6562	1″ SPUD Bracket, RoHS:Y
XRC-ST1CE-80G7KZ	540-7040	80GB – 7200 RPM SATA, Disk Assembly with 1 bracket and 1 of the following disks, RoHS:Y
	390-0303	Hitachi HDS728080PLA380 [HDS7280SASUN80G] (80GB – 7200 RPM – SATA Disk), RoHS:Y
	540-6562	1″ SPUD Bracket, RoHS:Y

Ethernet
Option #	Manufacturing Part #	Description
X1027A-Z	501-7283	PCI Express Dual 10-Gigabit Ethernet Fiber, RoHS:Y
X4150A-2	501-7415	GigaSwift Ethernet UTP (GCS), RoHS:Y
X4151A-2	501-7430	GigaSwift Ethernet MMF (GFS), RoHS:Y
X4445A	501-6738	Quad GigaSwift PCI-X Ethernet (QGE-X), RoHS:Y
X5544A-4	10Gb PCI-X Ethernet Adapter, no transceiver, RoHS:Y
	501-7413	10Gb PCI-X Ethernet Adapter, RoHS:Y
	370-7665	Bracket Standard 10Gb PCI-X Ethernet, RoHS:Y
	370-7792	Bracket Low-Profile 10Gb PCI-X Ethernet, RoHS:Y
X5558A	375-3301	10Gb/sec XFP Optical Transceiver Short Range (SR), RoHS:YL
X7280A-2	371-0905	PCI Express Dual Gigabit Ethernet UTP, RoHS:Y
X7281A-2	371-0904	PCI Express Dual Gigabit Ethernet MMF, RoHS:Y

Fan
Option #	Manufacturing Part #	Description
n/a	371-0703	3-Fan Tray, RoHS:Y
n/a	F373-0019	Fan Board, RoHS:Y
	373-0019	Fan Board, RoHS:Y
	n/a	Motherboard J20 to Fan Board Cable 422739300002

Fibre Channel
Option #	Manufacturing Part #	Description
SG-XPCIE1FC-QF4	375-3355	4Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
SG-XPCIE2FC-QF4	375-3356	4Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
SG-XPCI1FC-EM2	375-3304	2Gb PCI-X Single FC Host Adapter, RoHS:Y
SG-XPCI1FC-QL2	375-3383	2Gb PCI-X Single FC Host Adapter, RoHS:Y
SG-XPCI1FC-QLC-Z	375-3364	Entry-Level 2Gb PCI-X Single FC Host Adapter, RoHS:Y
SG-XPCI2FC-EM2	375-3305	2Gb PCI-X Dual FC Host Adapter, RoHS:Y
SG-XPCI2FC-QF2-Z	375-3363	2Gb PCI Dual FC Host Adapter, RoHS:Y
SG-XPCI2FC-QF2-Z	240-4839	Low Profile Bracket, RoHS:Y

Oracle Sun Ultra 25 Graphics
Option #	Manufacturing Part #	Description
X3000A	375-3545	XVR-300 x8 Graphics Accelerator, RoHS:Y
	530-3474	DVI-A(M) to HD15F Adapter, 49mm, RoHS:Y
	530-3998	DMS-59 to Dual DVI-I Cable, 215mm, RoHS:Y
X4240A	605-4668	XVR-300X16 Graphics Accelerator, RoHS:Y
	375-3458	XVR-300 Graphics Accelerator, RoHS:Y
	530-3474	DVI-A(M) to HD15F Adapter, 49mm, RoHS:Y
	530-3998	DMS-59 to Dual DVI-I Cable, 215mm, RoHS:Y
X7295A	375-3292	XVR-2500 Graphics Accelerator, RoHS:Y
X7296A	375-3290	XVR-100 Graphics Accelerator (64MB), RoHS:Y
n/a	375-3454	XVR-2500 Graphics Accelerator, RoHS:Y

I/O
Option #	Manufacturing Part #	Description
n/a	F373-0021	Front I/O Board I/O Assembly, RoHS:Y
	373-0021	Front I/O Board Assembly, RoHS:Y
	n/a	Motherboard J36 to I/O J3 USB Cable 422740700004
	n/a	Motherboard J3 to I/O J2 Audio/Power Cable 422739300005

IDPROM
Socket	Manufacturing Part #	Component Type	Host ID
n/a	525-2180	SEEPROM 2x MAC	83xxxxxx

Memory
Option #	Manufacturing Part #	Description
X8703A	540-6466	1GB (2 × 512MB) Memory FRU, RoHS:Y
X8703A	370-7972	512MB PC2700 DIMM, RoHS:Y
X8704A	540-6467	2GB (2 × 1GB) Memory FRU, RoHS:Y
X8704A	370-7973	1GB PC2700 DIMM, RoHS:Y
X8711A	540-6468	4GB (2 × 2GB) Memory FRU, RoHS:Y
X8711A	370-7974	2GB PC2700 DIMM, RoHS:Y

Miscellaneous
Option #	Manufacturing Part #	Description
X2136A	370-6200	Rear Guide Kit
X2136A	375-3203	SunPCi IIIpro 1.6GHz Co-Processor Card, 256MB memory

Power
Option #	Manufacturing Part #	Description
n/a	300-1800	1000W Power Supply, RoHS:Y

Removable Media
Option #	Manufacturing Part #	Description
X7277A	373-0018	DVD Paddleboard, RoHS:Y
X7277A	390-0403	8x PATA DVD-Writer / 24x CD-Writer, RoHS:Y
n/a	F371-1106	8x DVD-Writer/24x CD-Writer, RoHS:Y
	373-0018	DVD Paddleboard, RoHS:Y
	390-0403	8x PATA DVD-Writer / 24x CD-Writer, RoHS:Y
	n/a	Motherboard J11 to DVD Cable

SCSI
Option #	Manufacturing Part #	Description
SG-XPCIE2SCSIU320Z	375-3357	Dual-Channel Ultra320 LVD SCSI PCI Express Adapter, RoHS:Y
SGXPCI2SCSILM320-Z	375-3365	PCI Dual Ultra320 SCSI Adapter, RoHS:YL
X4422A-2	501-7490	Dual GigabitEthernet / Dual SCSI PCI Adapter, RoHS:Y
SG-XPCI2SCSI-LM320	375-3191	PCI/PCI-X Dual Ultra320 SCSI Adapter

Oracle Sun Ultra 25System Board
Option #	Manufacturing Part #	Description
n/a	375-3449	Motherboard 1 × 1.34GHz UltraSPARC IIIi, 0MB, RoHS:Y
n/a	371-0083	CPU Fan/Heatsink, RoHS:Y
n/a	375-3556	Motherboard 1 × 1.34GHz UltraSPARC IIIi, 0MB, RoHS:Y
	371-0083	CPU Fan/Heatsink, RoHS:Y
	375-3557	Motherboard w/ 1 CPU socket, RoHS:Y
