| Processor |
| Number |
One |
| Architecture |
AMD-64 100 Series 1.8GHz (model 144), 2.2GHz (model 148), 2.6GHz (model 152) |
| Cache memory |
1MB Level 2 |
| Main Memory |
| Capacities |
 Four DIMM slots
ECC – 512MB, 1GB, 2GB
Non-ECC 256MB
Unbuffered DIMMs only
8 GB Maximum, installed in identically matched pairs |
| Standard Interfaces |
| Audio |
5 AC ’97 ports. One line-in, Two line-out, Two microphone-in |
| Video |
ATI Rage XL 8MB PCI graphics |
| Ethernet |
One Gigabit ethernet port |
| Expansion Slots |
One PCI-Express x16 slot (reserved for graphics)
Two PCI-Express x1 slots
Four PCI slots (3.3V/5V, 32-bit, 33MHz), 3 half length, one full length |
| Fire Wire |
Two IEEE 1394a ports |
| USB |
Six Serial Bus 2.0 ports, two in front, four in back |
| Internal Storage |
| Disks |
Up to 2x 80GB or 250GB SATA disk drives |
| DVD |
One DVD-ROM or DVD+R/RW |
| Graphics |
| Cards |
|
| Environment |
| AC Power |
100-120; 220-240 VAC, 47-63 Hz |
| Input Current |
4A @ 100 VAC |
| Power consumption |
Power Supply – 400 Watts |
| Heat output |
1365 BTU/hr |
| Temperature |
Operating: 5° C to 35° C (41° F to 95° F)
Nonoperating: -40° C to 65° C (-40° F to 158° F) |
| Humidity |
Operating: 20% to 93% relative humidity, non-condensing
Nonoperating: 93% relative humidity, non-condensing |
| Acoustic noise |
Operating: < 4.7 bels
Idling: < 4.3 bels |
Regulations
Meets or exceeds the following requirements: |
| Safety |
UL/CSA-60950-1, EN 60950-1, IEC 60950-1 CB |
| RFI/EMI |
EN 55022/CISPR22 Class B, FCC CFR47 Part 15 Class B, EN 61000-3-2, EN 61000-3-3 |
| Immunity |
EN 55024 |
| Regulatory Markings |
UL/cUL, TUV-GS, CE FCC, ICES-003, C-Tiek, VCCI, GOST-R, BSMI, CCC, S-Mark |
| Ergonomics |
EK1-1TB-2000 |
| Dimensions and Weights |
| Height |
43.36 cm (17.07 in) |
| Width |
19.96 cm (7.86 in) |
| Depth |
46.74 cm (18.4 in) |
| Weight |
15.4 kg (34 lbs) |
|
CPU Module |
| Option # |
Manufacturing
Part # |
Description |
| X3798A |
594-2617 |
2.4GHz Dual Core Opteron 180 Socket 939, RoHS:Y |
|
|
- CPU Fan/Heatsink/Shroud, RoHS:Y
|
|
|
- 2.4GHz Dual Core Opteron 180 Socket 939 (E6 Stepping), RoHS:Y
|
| 4188A-Z |
596-6317 |
3.0GHz Opteron 156 Socket 939 (E4 Stepping), RoHS:Y |
|
|
|
|
|
- 3.0GHz Opteron 156 Socket 939 (E4 Stepping), RoHS:Y
|
| X4187A-Z |
594-3518 |
2.6GHz Dual Core Opteron 185 Socket 939, RoHS:Y |
|
|
- CPU Fan/Heatsink/Shroud, RoHS:Y
|
|
|
- 2.6GHz Dual Core Opteron 185 Socket 939 (E6 Stepping), RoHS:Y
|
| n/a |
596-5116 |
1.8GHz Opteron 144 Socket 939, RoHS:Y |
|
|
|
|
|
- 1.8GHz Opteron 144 Socket 939 (E4 Stepping), RoHS:Y
|
| n/a |
596-5117 |
2.2GHz Opteron 148 Socket 939, RoHS:Y |
|
|
|
|
|
- 2.2GHz Opteron 148 Socket 939 (E4 Stepping), RoHS:Y
|
| n/a |
596-5118 |
2.6GHz Opteron 152 Socket 939, RoHS:Y |
|
|
|
|
|
- 2.6GHz Opteron 152 Socket 939 (E4 Stepping), RoHS:Y
|
| n/a |
596-5754 |
2.8GHz Opteron 154 Socket 939, RoHS:Y |
|
|
|
|
|
- 2.8GHz Opteron 154 Socket 939 (E4 Stepping), RoHS:Y
|
|
Disk Backplane |
| Option # |
Manufacturing
Part # |
Description |
| n/a |
370-7959 |
SATA Disk Backplane, ROHS:Y |
|
Disks |
| Option # |
Manufacturing
Part # |
Description |
| X8011A |
540-6485 |
250GB – 7200 RPM SATA, Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y |
|
|
- Seagate ST3250824AS [STN7225SASUN250G]
(250GB – 7200 RPM – SATA Disk), RoHS:Y
|
|
|
- Hitachi HDT722525DLA380 [HDS7225SBSUN250G]
(250GB – 7200 RPM – SATA Disk), RoHS:Y
|
|
|
- Hitachi HDT725025VLA380 [HDS7225SCSUN250G]
(250GB – 7200 RPM – SATA Disk), RoHS:Y
|
|
|
- Seagate ST3250820NS [ST32500NSSUN250G]
(250GB – 7200 RPM – SATA Disk), RoHS:Y
|
| 540-6521 |
250GB – 7200 RPM SATA. Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y |
|
|
- Seagate ST3250823AS
(250GB – 7200 RPM – SATA Disk), RoHS:Y
|
|
|
- Hitachi HDS722525VLSA80
(250GB – 7200 RPM – SATA Disk), RoHS:Y
|
|
|
|
| X8012A |
540-6520 |
80GB – 7200 RPM SATA, Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y |
|
|
- Seagate ST380013AS
(80GB – 7200 RPM – SATA Disk)
|
|
|
- Hitachi HDS728080PLA380
(80GB – 7200RPM – SATA Disk), RoHS:Y
|
|
|
|
|
Fan |
| Option # |
Manufacturing
Part # |
Description |
| n/a |
310-0036 |
CPU Fan/Heatsink, ROHS:Y |
| n/a |
370-7956 |
92mm Fan, RoHS:Y |
|
Graphics |
| Option # |
Manufacturing
Part # |
Description |
| X8009A |
370-7946 |
nVidia Quadro FX1400 |
| X8010A |
370-7945 |
nVidia Quadro NVS280 |
| X8015A |
530-3325 |
DVI-A(M) to HD15F Adapter, 49mm |
| X7264A |
370-7988 |
NVIDIA Quadro FX3450 3D Graphics Accelerator, RoHS:Y |
| X7298A |
371-0854 |
NVIDIA Quadro FX540 3D Graphics Accelerator, RoHS:Y |
| n/a |
530-3320 |
DMS-59 to Dual DVI-I Cable, 215mm |
|
I/O |
| Option # |
Manufacturing
Part # |
Description |
| n/a |
370-7957 |
Front I/O Board Assembly, RoHS:Y |
|
Input Device |
| Option # |
Manufacturing
Part # |
Description |
| n/a |
371-0754 |
M29 USB Optical mouse with scroll wheel |
|
Memory |
| Option # |
Manufacturing
Part # |
Description |
| X8006A |
2GB (2 × 1GB DDR400/PC3200 ECC DIMM) Option |
| 540-6465 |
2GB (2 × 1GB) Memory FRU, RoHS:Y |
|
|
- 1GB DDR400/PC3200 ECC Unbuffered DIMM, ROHS:Y
|
| X8007A |
1GB (2 × 512MB DDR400/PC3200 ECC DIMM) Option |
| 540-6464 |
1GB (2 × 512MB) Memory FRU, RoHS:Y |
|
|
- 512MB DDR400/PC3200 ECC Unbuffered DIMM, RoHS:Y
|
| X8008A |
512MB (2 × 256MB DDR400/PC3200 Non-ECC DIMM) Option |
| 540-6463 |
512MB (2 × 256MB) Memory FRU, RoHS:Y |
|
|
- 256MB DDR400/PC3200 Non-ECC Unbuffered DIMM, RoHS:Y
|
| X4211A-Z |
4GB (2 × 2GB DDR266/PC2100 ECC DIMM) Option, RoHS:YL |
| 540-7077 |
2GB Memory FRU, RoHS:Y |
|
|
- 2GB DDR266/PC2100 ECC Unbuffered DIMM, RoHS:Y
|
|
Power |
| Option # |
Manufacturing
Part # |
Description |
| n/a |
300-1794 |
400 Watt Power Supply |
|
Removable Media |
| Option # |
Manufacturing
Part # |
Description |
| n/a |
370-7950 |
DVD-ROM / CD-ROM |
| n/a |
540-7791 |
Dual DVD-RW FRU, RoHS:Y |
|
|
- 16x DVD-Writer / 40x CD-Writer, RoHS:Y
|
|
SCSI |
| Option # |
Manufacturing
Part # |
Description |
| X9265A |
370-6682 |
Dual Ultra-320 SCSI/RAID |
|
System Board |
| Option # |
Manufacturing
Part # |
Description |
| n/a |
375-3306 |
System Board |
