Oracle Sun V65x Server
REQUEST A PRICE QUOTE:
| Processor | |
| Number | 1 or 2 |
| Architecture | 2.8 GHz, 3.06 GHz, or 3.2 GHz Intel Xeon |
| Cache memory | 512-KB Level 2 cache |
| Main Memory | |
| Capacities | 512 MB/12 GB 6 DIMM sockets available. |
| Standard Interfaces | |
| Ethernet | Dual Integrated 10/100/1000- NIC |
| Graphics | VGA Video connector, ATI Rage XL (front and rear) |
| PCI | Six 64-bit/100-MHz PCI-X slots |
| SCSI | One Ultra320 68-pin, high-density VHDCI SCSI connector (SE/LVD). |
| Serial | One RS232 RJ45 connector (rear accessible) |
| USB | Three USB ports (one front, two rear) |
| Internal Mass Storage | |
| Disks | Up to six 36GB, 73GB, or 146GB (10K RPM) disks |
| Removable Media | One CD-ROM/floppy and optional DVD-ROM/floppy |
| Power Supplies | |
| Dual, redundant 500W power supplies. Only one power supply is required. | |
| Environment | |
| AC input | 100-240 V, 50/60 Hz, 500 W PFC supply, dual (redundant) fans |
| Input Power | 500 W (max) |
| Temperature |
Operating: +10° C to +35° C Nonoperating: -40° C to +70° C |
| Vibration |
Operating: 0.15 G z-axis; 0.10 G x- and y-axis, 5 to 500 Hz sine Nonoperating: 0.5 G z-axis; 0.25 G x- and y-axis, 5 to 500 Hz sine |
| Shock | Operating: 3 G, 11 ms, half-sine |
|
Regulations Meets or exceeds the following requirements: | |
| FCC Class A, CISPR 22A, VCCI-A, UL, CE, Austel, BSMI, GOST R, MIC, Nemko GS, Canada ICES-003 Class A | |
| Dimensions and Weights | |
| Height | 3.50 in. (87 mm) |
| Width – with mounting ears | 16.93 in. (430 mm) |
| Depth – with front bezel | 25.51 in. (648 mm) |
| Weight | Approximately 50 lb. (unpacked two-drive server) Approximately 55 lb. (packaged) |
| CPU Module | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # | Description | ||
| (X)5120A | 370-6044 | 2.8GHz Xeon CPU Assembly | ||
|
| |||
|
| |||
|
| |||
|
| |||
|
| |||
|
| |||
|
| |||
|
| |||
| (X)5121A | 370-6045 | 3.06GHz Xeon CPU Assembly | ||
|
| |||
|
| |||
|
| |||
|
| |||
|
| |||
|
| |||
|
| |||
|
| |||
| (X)5138A | 370-6458 | 3.2GHz Xeon CPU Assembly | ||
|
| |||
|
| |||
|
| |||
|
| |||
|
| |||
|
| |||
|
| |||
|
| |||
| Cables | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # | Description | ||
| X312L | Localized Power Cord Kit – Continental Europe, RoHS:Y | |||
| 180-1993 | IEC 320 C13 to CEE 7/7 10A/250V 2.5M Black, RoHS:Y | |||
| X314L | Localized Power Cord Kit – Swiss, RoHS:Y | |||
| 180-1994 | IEC 320 C13 to SEV 1011 – 10A/250V 2.5M Black, RoHS:Y | |||
| X317L | Localized Power Cord Kit – U.K., RoHS:Y | |||
| 180-1997 | IEC 320 C13 to BS 1363 – 10A/250V 2.5M Black, RoHS:Y | |||
| X5137A | 595-7129 | Serial & RJ45 Dongle Kit | ||
|
| |||
| n/a | 530-3230 | PS/2 Y-Cable | ||
| n/a | 540-5763 | 2U Cable Kit | ||
| Disks | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # | Description | ||
| (X)5126A | 540-5936 | 36.4GB – 10000 RPM, Disk Assembly with 1 of the following disks: | ||
|
| |||
|
| |||
| (X)5127A | 540-5937 | 73.4GB – 10000 RPM, Disk Assembly with 1 of the following disks: | ||
|
| |||
|
| |||
|
| |||
|
| |||
|
| |||
|
| |||
|
| |||
| XRA-SC1CC-146G10K | 540-6227 | 146.8GB – 10000 RPM, Disk Assembly with 1 of the following disks: | ||
|
| |||
|
| |||
|
| |||
|
| |||
|
| |||
|
| |||
| Fan | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # | Description | ||
| n/a | 370-6036 | Memory Fan Assembly | ||
| n/a | 370-6050 | System Fan Assembly | ||
| Fibre Channel | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # | Description | ||
| (X)5133A | 501-6640 | Fibre Channel PCI Adapter | ||
| SG-XPCI1FC-QF2 | 375-3102 | 2Gb PCI Single FC Host Adapter | ||
| SG-XPCI1FC-QL2 | 375-3383 | 2Gb PCI-X Single FC Host Adapter, RoHS:Y | ||
| SG-XPCI2FC-QF2 | 375-3108 | 2Gb PCI Dual FC Host Adapter | ||
|
| |||
| I/O | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # | Description | ||
| n/a | n/a | I/O (SCSI) Backplane Air Baffle | ||
| n/a | n/a | 3-Slot Half-Height PCI-X Riser | ||
| n/a | n/a | I/O (SCSI) Backplane IDE/Floppy Cable Clamp | ||
| n/a | n/a | I/O (SCSI) Backplane | ||
| n/a | n/a | 3-Slot Full-Height PCI-X Riser | ||
| Memory | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # | Description | ||
| (X)5122A | 370-6038 | 256MB DDR Memory | ||
| (X)5123A | 370-6039 | 512MB DDR Memory | ||
| (X)5124A | 370-6040 | 1GB DDR Memory | ||
| (X)5125A | 370-6141 | 2GB DDR Memory | ||
| Miscellaneous | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # | Description | ||
| 5135A | 330-3696 | Drive Sled (empty) | ||
| Power | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # | Description | ||
| X5134A | 370-6048 | 500W Power Supply (also used as Redundant Power Supply) | ||
| n/a | n/a | Dual AC Input/DC Power Distribution Unit | ||
| Rack | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # | Description | ||
| X5030A | 595-6805 | Rail & Extension Kit | ||
|
| |||
|
| |||
|
| |||
| Removable Media | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # | Description | ||
| (X)5130A | 370-6042 | Slimline 24X CD-ROM/Floppy | ||
| (X)5131A | 370-6043 | Slimline 8X DVD-ROM/Floppy | ||
| SCSI | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # | Description | ||
| SG-XPCI2SCSI-LM320 | 375-3191 | PCI/PCI-X Dual Ultra320 SCSI Adapter | ||
| X5132A | 595-6945 | Zero Channel RAID Controller | ||
|
| |||
| System Board | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # | Description | ||
| n/a | 501-6637 | Motherboard Assembly | ||
|
| |||
