Used Oracle Sun V100 Server

Oracle Sun V100 Server

REQUEST A PRICE QUOTE:

Processor
Number	One
Architecture	500 MHz UltraSPARC IIe 550MHz or 650MHz UltraSPARC IIi
Cache	16 KB data and 16 KB instruction on-chip; Secondary: 512 on-chip
Main Memory
Capacities	128-, 256-, or 512-MB PC133 Registered ECC DIMMs 2 GB maximum
Standard Interfaces
Ethernet	Two ethernet/fast ethernet (10BASE-T/100BASE-T) shielded twisted-pair (STP) connector (RJ-45)
Serial	Two RS-232C/RS-423 serial ports (RJ45); port A is used for LOM
System Configuration Reader and Card	Rear-accessible for transfer of system configuration information, including hostid
USB	Two standard Universal Serial Bus (USB) Type A ports
Internal Mass Storage
Disk	Up to two 3.5-in.x 1-in.7200 rpm IDE disks (40 GB)
CD-ROM	644-MB SuperSlim CD-ROM,24X speed (standard)
Environment
AC input	90 – 264 VAC, 47 – 63 Hz, 1.3 A(max)
Input power	81 W(max)
Heat output	148 BTU/hr (nominal) to 280 BTU/hr (max)
Temperature	Operating: 5° C to 40° C (41° F to 104° F) Nonoperating: -40° C to 70° C (-40° F to 158° F)
Humidity	Operating: 5% to 85% relative humidity, noncondensing Nonoperating: 10% to 95% relative humidity, noncondensing
Altitude	Operating: -300 m to 3000 m (-1000 to 10,000 ft.) Nonoperating: -300 m to 12,000 m (-1000 to 40,000 ft.)
Acoustic noise	Operating: 6.3 bels Idling: 6.0 bels
Number of cords	1
Regulations Meets or exceeds the following requirements:
Safety	UL 1950/CSA C22.2 No.950,EN 60950 (73/23/EEC), IEC 950,CCIB for PSU,GOSTMark
RFI/EMI	CFR Title 47 FCC Part 15,EN 55022 (89/336/EEC)
Immunity	EN55024 (89/336/EEC)
Certification	Safety: cULus Mark,TUV GS Mark,CE Mark EMC: CE Mark (93/68/EEC),FCC authorized Class A,VCCI, BSMI,CTICK
Dimensions and Weights
Height	4.36 cm (1.72 in.)
Width	44.5 cm (17.55 in.)
Depth	48.26 cm (19 in.)
Weight	6kg (13.2 lb.) approximate 10 kg (22 lb.) approximate shipping

Boot PROM
Socket	Manufacturing Part #	Patch
n/a	n/a	111952

Cables
Option #	Manufacturing Part #	Description
n/a	530-3100	RJ45F to DB9F Adapter, RoHS:Y

Card/Reader
Option #	Manufacturing Part #	Description
n/a	370-4285	System Configuration Card

Disks
Option #	Manufacturing Part #	Description
X7096A	40.0GB – 7200 RPM disk option, with brackets and 1 of the following disks:
	370-4419	Seagate ST340824A (40.0GB – 7200 RPM – IDE Disk)
	370-4419	IBM IC35L040AVER07 (41.1GB – 7200 RPM – IDE Disk)
	370-4419	Seagate ST340016A (40.0GB – 7200 RPM – IDE Disk)
	370-4419	Western Digital WD400BB (40.0GB – 7200 RPM – IDE Disk)
	370-4419	Seagate ST340014A (40.0GB – 7200 RPM – IDE Disk)
	370-6205	Disk bracket
	370-6206	Disk Bracket Handle
X7097A	540-6215	80.0GB – 7200 RPM, Disk Assembly with brackets, and 1 of the following disks:
	370-6164	Hitachi HDS722580VLAT20 (80.0GB – 7200 RPM – IDE Disk)
	370-6164	Seagate ST380011A (80.0GB – 7200 RPM – IDE Disk)
	370-6205	Disk bracket
	370-6206	Disk Bracket Handle
n/a	370-6626	Seagate ST340014A (40.0GB – 7200 RPM – IDE Disk)
n/a	370-7631	IBM IC35L040AVER07 (41.1GB – 7200 RPM – IDE Disk)

Memory
Option #	Manufacturing Part #	Description
X7090A	370-4289	128MB REG/BUFF DIMM
X7091A	370-4237	256 MB SDRAM DIMM
X7092A	370-4281	512MB SDRAM DIMM

Power
Option #	Manufacturing Part #	Description
n/a	370-4363	80W AC Input Power Supply

Rack
Option #	Manufacturing Part #	Description
X7085A	595-5802	19-inch Rack Mount Kit

Removable Media
Option #	Manufacturing Part #	Description
n/a	370-4278	24X Slimline CD-ROM Drive
n/a	371-0980	24X Slimline CD-ROM Drive, RoHS:Y

System Board
Option #	Manufacturing Part #	Description
n/a	375-3090	Sun Fire V100 Motherboard (500MHz)
n/a	375-3110	Sun Fire V100 Motherboard (550MHz)
n/a	375-3115	Sun Fire V100 Motherboard (650MHz)

Whole System FRU
Option #	Manufacturing Part #	Description
N19-UPE1-9S-102EX1	600-7883	Sun Fire V100 FRU 500MHz CPU, 1GB RAM, 2× 40GB Disk, 24X CD-ROM
N19-UPE1-9S-128EX1	600-7881	Sun Fire V100 FRU 500MHz CPU, 128MB RAM, 1× 40GB Disk, 24X CD-ROM
N19-UPE1-9S-202EX1	600-7884	Sun Fire V100 FRU 500MHz CPU, 2GB RAM, 2× 40GB Disk, 24X CD-ROM
N19-UPE1-9S-512EX1	600-7882	Sun Fire V100 FRU 500MHz CPU, 512MB RAM, 1× 40GB Disk, 24X CD-ROM
N19-UTE1-9S-102EX1	600-7997	Sun Fire V100 FRU 650MHz CPU, 1GB RAM, 2× 40GB Disk, 24X CD-ROM
N19-UTE1-9S-202EX1	600-7998	Sun Fire V100 FRU 650MHz CPU, 2GB RAM, 2× 40GB Disk, 24X CD-ROM
N19-UTE1-A1-102XB1	602-2708	Sun Fire V100 FRU 650MHz CPU, 1GB RAM, 2× 80GB Disk, CD-ROM
N19-UUE1-9S-102EX1	602-2412	Sun Fire V100 FRU 550MHz CPU, 1GB RAM, 1× 40GB Disk, 24X CD-ROM
N19-UUE1-9S-256EX1	600-7995	Sun Fire V100 FRU 550MHz CPU, 256MB RAM, 1× 40GB Disk, 24X CD-ROM
N19-UUE1-9S-512EX1	600-7996	Sun Fire V100 FRU 550MHz CPU, 512MB RAM, 1× 40GB Disk, 24X CD-ROM
N19-UUE1-A1-102XA1	602-2707	Sun Fire V100 FRU 550MHz CPU, 1GB RAM, 1× 80GB Disk, 24X CD-ROM
N19-UUE1-A1-256XA1	602-2706	Sun Fire V100 FRU 550MHz CPU, 256MB RAM, 1× 80GB Disk, 24X CD-ROM
