Oracle Sun Storage F5100 Flash Server
REQUEST A PRICE QUOTE:
| Brand: | Oracle / Sun Microsystems |
| Condition: | Refurbished and new (limited availability) |
| Availability: | Contact |
| Shipping Area: | Worldwide to most countries |
| Shipping Method: | Fedex (most orders), UPS, DHL, Freight Courier |
| Price: | Please use the quote form above for quick pricing |
| Payment: | Credit Card, Check, Net Terms (oac), Wire Transfer (required for international orders) |
| Guarantee: | All items are tested by Oracle trained technicians & backed by a 100% warranty |
| Questions? | Don’t hesitate to contact us with any questions regarding compatibility or other product info and requests. Our website represents only a fraction of our full inventory. Please reach out with your full requirements |
Specs and Information:
| Flash Modules | |
| 20, 40, or 80 24GB Flash Modules (FMODs) | |
| Capacity | |
| Capacity |
20 FMODs: 480 GB 40 FMODs: 960 GB 80 FMODs: 1,920 GB |
| Domains | 4 |
| Interfaces | |
| Ports | 16 × 4-wide sas-1 (64 channels) |
| SAS Domains | 4 |
| Power | |
| Input Voltage | 100-120VAC or 200-240 VAC |
| Idle Power |
20 FMODs: 127 watts 40 FMODs: 157 watts 80 FMODs: 213 watts |
| Active Power |
20 FMODs: 127 watts 40 FMODs: 281 watts 80 FMODs: 386 watts |
| Peak Turn-on (10 minutes during ESM charge) |
20 FMODs: 385 watts 40 FMODs: 445 watts 80 FMODs: 505 watts |
| Environment | |
| Temperature |
Operating: 5° to 35° C (41° to 95° F) Non-Operating: -40° to 65° C (-40° to 149° F) |
| Relative Humidity |
Operating: 1% to 90%, 27° C (80.6 F) max Non-Operating: 10% to 93%, 35° C (95° F) max |
| Altitude |
Operating: 3000 meters Non-Operating: 12000 meters |
| Acoustic | 55.4dB |
| Dimensions & Weights | |
| Height | 44 mm (1.746 in) – 1 Rack Unit (RU) |
| Width | 425 mm (16.750 in) |
| Depth | 714 mm (28.125 in) |
| Weight | 15.9 kg (35 lbs) |
| Array Controller | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # | Description | Previous Part # | |
| n/a | 541-3143 [F] | Motherboard Assembly | n/a | |
|
| n/a | ||
|
| n/a | ||
|
| n/a | ||
| Backplane/Centerplane | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # | Description | Previous Part # | |
| n/a | 511-1140 [F] | Energy Storage Backplane (ESB) | n/a | |
| Cables | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # | Description | Previous Part # | |
| XTA-1.0M-SAS | 530-3882 [C] | 4X Mini SAS Cable, SFF-8088 to SFF-8088, 1M | n/a | |
| XTA-2.0M-SAS | 530-3883 [C] | 4X Mini SAS Cable, SFF-8088 to SFF-8088, 2M | n/a | |
| XTA-0.5M-SAS [S] | 530-3886 [C] | 4X Mini SAS Cable, SFF-8088 to SFF-8088, 0.5M | n/a | |
| XTA-3.0M-SAS [S] | 530-3884 [C] | 4X Mini SAS Cable, SFF-8088 to SFF-8088, 3M | n/a | |
| n/a | 180-1097 [C] | IEC 320 C13 to NEMA 5-15P – 15A/125V 2.5M Black | n/a | |
| n/a | 560-2928 [F] | Backplane to Motherboard Cable Kit | n/a | |
|
| n/a | ||
|
| n/a | ||
| Fan | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # | Description | Previous Part # | |
| n/a | 330-4683 | Fan Connector Cover | n/a | |
| n/a | 541-1984 [C] | Fan Module | n/a | |
|
| n/a | ||
|
| n/a | ||
| n/a | 541-2112 [F] | Fan Power Board | n/a | |
| Memory | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # | Description | Previous Part # | |
| XTA4ST3S-24GBFM [S] | 24GB Flash Module Expansion (4 × 24GB FMODs) X-Option | |||
| 7061954 [C] | 24GB Flash Module | 371-4846 [C] | ||
| n/a | 371-4091 [C] | 24GB Flash Module | n/a | |
| n/a | 371-4846 [C] | 24GB Flash Module | 371-4091 [C] | |
| Power | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # | Description | Previous Part # | |
| n/a | 300-2137 [C] | Type A236 720 Watt AC Input Power Supply | n/a | |
| n/a | 300-2233 [C] | Type A247 760 Watt AC Input Power Supply | n/a | |
| n/a | 501-7696 [F] | Power Distribution Board | n/a | |
| n/a | 511-1604 [F] | Power Distribution Board | n/a | |
| n/a | 541-3259 [C] | Energy Storage Module (ESM)/ Supercap Assembly | n/a | |
|
| n/a | ||
|
| n/a | ||
|
| n/a | ||
|
| n/a | ||
| Rack | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # | Description | Previous Part # | |
| n/a | 371-2741 [C] | 1U/2U Screw-Mount Slide Rail Rackmount Kit, 730mm | n/a | |
| SCSI | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # | Description | Previous Part # | |
| 7105387 | 8-Port 6Gbps SAS-2 PCI Express HBA | |||
| 7047853 | 8-Port 6Gbps SAS-2 PCI Express HBA (LSI) | 375-3641 | ||
| SG-XPCIE8SAS-E-Z [S] | 7050793 | PCI Express 8-Port Host Adapter | 375-3487 | |
| SG-XPCIE8SAS-EB-Z [S] | 375-3486 | Sun StorageTek SAS Host Bus Adapter PCI Express ExpressModule | n/a | |
| SGX-SAS6-EXT-Z [S] | 7047853 | 8-Port 6Gbps SAS-2 PCI Express HBA (LSI) | 375-3641 | |
| n/a | 375-3487 | PCI Express 8-Port Host Adapter | n/a | |
| n/a | 375-3641 | 8-Port 6Gbps SAS-2 PCI Express HBA (LSI) | n | |
