    Oracle Sun 6180 Server Storage Array Information & Specs

    Brand:Oracle / Sun Microsystems
    Condition:Refurbished and new (limited availability)
    Availability:Contact
    Shipping Area:Worldwide to most countries
    Shipping Method:Fedex (most orders), UPS, DHL, Freight Courier
    Price:Please use the quote form above for quick pricing
    Payment:Credit Card, Check, Net Terms (oac), Wire Transfer (required for international orders)
    Guarantee:All items are tested by Oracle trained technicians & backed by a 100% warranty
    Questions?Don’t hesitate to contact us with any questions regarding compatibility or other product info and requests. Our website represents only a fraction of our full inventory. Please reach out with your full requirements

    Oracle Sun 6180 Specs and Information.

    Reliable Performance Sun 6180!

    Some of the world’s leading companies rely on Sun modular storage to protect their data! the Sun Storage 6180 Array is no exception. The Sun Storage 6180 Array is architected to provide the highest reliability and availability, offering redundant components; automated I/O path failover; and extensive online configuration, reconfiguration, and maintenance capabilities to ensure your data is available 24/7. The Sun Storage 6180 Array also ensures stored data is always protected. DACstore technology stores configuration metadata on each drive, RAID-6 technology guards against concurrent drive failures and errors, and persistent cache backups ensure any data in cache is captured and safe in the event of a power outage. All these features combine to create a system you can trust with your data.

    Continuous Investment Protection

    The Sun Storage 6180 Array delivers flexibility, scalability, and investment protection with online data-in-place upgrades across the entire Sun modular storage line. The Sun Storage 6180 Array allows customers to scale up and across all the way to the flagship Sun Storage 6780 Array with data intact! without wasting time and money with over-the-SAN migration support for previous generations of SAN

    Sun 6180 KEY FEATURES • Data encryption services deliver government-grade, cost-effective data protection throughout the lifecycle of the drive. • Next Generation 8 Gb/s FC interfaces provide backward and forward investment protection and deliver higher performance at a lower cost • 600GB 15K FC & 2TB 7.2K SATA drives provide more capacity than current FC and SATA drives

    6180 KEY BENEFITS • Up to 112 intermixed drives provide the ability to combine FC and SATA disk drives to enable a tiered storage environment. • Redundant, hot-swappable components maintain data availability by allowing components to be replaced without stopping I/O. • Persistent cache backup ensures any data in cache is captured permanently in the event of a power outage. • Custom XOR engine for RAID parity calculations enables exceptional disk-based performance that’s ideally suited for RAID-5 and RAID-6 configurations. • Data protection software enables remote replication, snapshot, and volume copy. • .NEBS Level 3 certified

    Sun 6180 parts and system pricing



    6180 Disks
    146GB 15K, FC
    300GB 15K, FC
    450GB 15K, FC
    500GB 7.2K, SATA
    600GB 15K, FC
    1TB 7.2K, SATA
    2TB 7.2K, SATA
    Characteristics for this array include:
    • Dual RAID controllers
      • 4GB of battery-backed cache
      • Four or Eight 8 Gb/s FC host connections per controller
    • Five to sixteen hard disk drives per tray
    • Supports RAID 0, 1, 3, 5, 6 (p + q) and 10
    • Rack mountable
    • Small 3 RU chassis
    Capacity
    Up to 16 Disk drives per array
    146.8GB Disk drives16 x 146.8 = 2.3488TB
    300GB Disk drives16 x 300 = 4.8TB
    450GB Disk drives16 x 450 = 7.2TB
    500GB Disk drives16 x 500 = 8.0TB
    1TB Disk drives16 x 1 = 16.0TB
    Total capacity depends on the following:
    • Number of expansion trays added to a controller tray
    • Up to three CSM200 expansion trays can be added to a controller tray (with 4GB cache and 4 Host Ports)
    • Up to six CSM200 expansion trays can be added to a controller tray (with 4GB cache and 8 Host Ports)
    • A controller tray and six expansion trays provide 112 disk drives (7 trays x 16 disk drives)
    • Example of available storage:
      • 300GB FC disk drives – total raw capacity = 33.6TB (112 x 300GB)
      • Sixteen 300GB FC drives in controller tray and ninety-six 500GB SATA drives in expansion trays – total raw capacity = 52.8TB (16 x 300GB + 96 x 500GB)

    Note 1: Total raw capacity decreases depending on RAID level and number of spares used within each array configuration.

    Note 2: The array configuration supports up to 15 global hot spare drives; each spare can be used for any disk in the array configuration.

    Environment
    AC input
    • 4.4 A Max Operating @ 100 VAC (90 – 136 VAC Range), 50/60 Hz
    • 1.9 A Max Operating @ 240 VAX (198 – 264 VAC Range), 50/60 Hz
    DC input17 A Max Operating (-36 to -72 V DC Range)
    Power and coolingDual hot-swappable redundant 620W power supplies and fan modules
    (power and fan modules are enclosed in one unit)
    Heat output1380 BTU/hr *
    Temperature
    • Operating:
      10° C to 40° C (50° F to 104° F) (without battery)
      10° C to 35° C (50° F to 95° F) (with battery)
    • Non-Operating (Storage):
      -10° C to 50° C (-14° F to 120° F) (without battery)
      -10° C to 45° C (-14° F to 113° F) (with battery – 3 month max.)
    • Non-Operating (Transit):
      -40° C to 60° C (-40° F to 140° F) (without battery)
      -40° C to 60° C (-40° F to 140° F) (with battery – 1 week max.)
    Humidity
    • Operating:
      20% to 80%, noncondensing
    • Nonoperating (Storage):
      10% to 90%, Max Dew Point 26° C (79° F), 10% per hour Gradient
    • Nonoperating (Transit):
      5% to 95%, Max Dew Point 26° C (79° F), 10% per hour Gradient
    Altitude
    • Operating: 30.5 m (100 ft) below sea level to 3000 m (9840 ft)
    • Nonoperating: 30.5 m (100 ft) below sea level to 12000 m (40000 ft)
    Vibration0.20 G, 5 to 500 Hz sinusoidal
    Shock
    • Operating:
      10 G, 3.75 ms half triangular
    • Nonoperating:
      30 G, 11 ms half sinewave in the side / side and up / down directions
      5 G, 11 ms half sinewave in the front / back direction
    * – Based on a configuration of two power supplies, two expansion trays, and 16 drives
    Regulations
    Meets or exceeds the following requirements:
    ImmunityCISPR 24 (EN55024), IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-11
    Safety and EmissionsIEC 60950, EN 60950, UL/CSA 60950, FCC Part 15 (47CFR15B), CISPR 22 (EN55022 – RF Radiated and Conducted Emissions), IEC 61000-3-2, IEC 61000-3-3
    Dimensions and Weights
    Height12.95 cm (5.1 in)
    Width48.28 cm (19 in)
    Depth57.15 cm (22.5 in)
    Weight43 kg (95 lbs) Max.
    Clearance and Service Access
    Front76.2 cm (30 in)
    Rear60.96 cm (24 in)
    Airflow for cooling is from front to rear.
    Array Controller
    Option #Manufacturing
    Part #    		DescriptionPrevious
    Part #
    n/a371-4676 [C]6180 Battery Backup Unitn/a
    n/a375-3336 [F]FC Expansion I/O Modulen/a
    n/a375-3630 [F]RAID Fibre Channel Controller, 2GB memory, 2 host portsn/a
    n/a375-3631 [F]RAID Fibre Channel Controller, 2GB memory, 4 host portsn/a
    Backplane/Centerplane
    Option #Manufacturing
    Part #    		DescriptionPrevious
    Part #
    n/a540-6545 [F]Drive Cage Midplanen/a
    Cables
    Option #Manufacturing
    Part #    		DescriptionPrevious
    Part #
    X9732A-Z537-1081 [F]Fibre Channel Optical Cable LC/LC, 2.0Mn/a
    X9733A-Z537-1082 [F]Fibre Channel Optical Cable LC/LC, 5Mn/a
    X9734A-Z537-1083 [F]Fibre Channel Optical Cable LC/LC, 15Mn/a
    X9736A-Z537-1084 [F]Fibre Channel Optical Cable LC/LC, 25Mn/a
    X9722A-Z [S]537-1088 [F]Fibre Channel Optical Cable LC/SC, 2Mn/a
    X9723A-Z [S]537-1089 [F]Fibre Channel Optical Cable LC/SC, 5Mn/a
    X9724A-Z [S]537-1090 [F]Fibre Channel Optical Cable LC/SC, 15Mn/a
    X9730A-Z [S]537-1080 [F]Fibre Channel Optical Cable LC/LC, 0.8Mn/a
    X9737A-Z [S]537-1092 [F]Fibre Channel Optical Cable LC/SC, 50Mn/a
    X9738A-Z [S]537-1085 [F]Fibre Channel Optical Cable LC/LC, 50Mn/a
    X9740A-Z [S]537-1093 [F]Fibre Channel Optical Cable LC/LC, 100Mn/a
    n/a530-3100RJ45F to DB9F Adaptern/a
    n/a530-3544 [F]PS2 6-pin DIN to RJ-45 Cable (2M)n/a
    n/a530-3569 [F]CSM200 Cable (2m, HSSDC2)n/a
    n/a530-3794 [F]Shielded RJ45 to RJ45 Cable, 6Mn/a
    n/a530-3880 [F]RJ45 to RJ45 Shielded Ethernet Cable, CAT5, 6M530-3794 [F]
    Disks
    Option #Manufacturing
    Part #    		DescriptionPrevious
    Part #
    XTC-ST1CF-500G7KZ540-6635 [C]500GB – 7200 RPM SATA, Disk Assembly with one of the following disks:n/a
    • 390-0247
    • Hitachi HDS725050KLA360 [HDS7250SASUN500G]
      (500GB – 7200 RPM – SATA Disk)
    		n/a
    • 390-0355
    • Seagate ST3500630NS [ST35000NSSUN500G]
      (500GB – 7200 RPM – SATA Disk)
    		n/a
    • 390-0383
    • Hitachi HUA721050KLA330 [HUA7250SBSUN500G]
      (500GB – 7200 RPM – SATA Disk)
    		n/a
    • 541-1406
    • Drive Mounting Bracket (SATA HDD Carrier)
    		n/a
    XTC-FC1CF-146G15KZ [S]540-6550 [C]146GB – 15000 RPM FC-AL, Disk Assembly with one of the following disks:n/a
    • 390-0299
    • Seagate ST3146954FC [ST314695FSUN146G]
      (146GB – 15000 RPM – FC-AL Disk)
    		n/a
    • 390-0313
    • Fujitsu MAX3147FD [MAX3147FDSUN146G]
      (146GB – 15000 RPM – FC-AL Disk)
    		n/a
    • 390-0328
    • Seagate ST3146855FC [ST314655FSUN146G]
      (146GB – 15000 RPM – FC-AL Disk)
    		n/a
    • 390-0419
    • Seagate ST3146356FC [ST314656FSUN146G]
      (146GB – 15000 RPM – FC-AL Disk)
    		n/a
    • 541-0882
    • Drive Mounting Bracket (HDD Carrier)
    		n/a
    XTC-FC1CF-300G15KZ [S]540-7156 [C]300GB – 15000 RPM FC-AL Disk Assembly with one of the following disks:n/a
    • 390-0330
    • Seagate ST3300655FC [ST330055FSUN300G]
      (300GB – 15000 RPM – FC-AL Disk)
    		n/a
    • 390-0420
    • Seagate ST3300656FC [ST330056FSUN300G]
      (300GB – 15000 RPM – FC-AL Disk)
    		n/a
    • 390-0462
    • Seagate ST3300657FC [ST330057FSUN300G]
      (300GB – 15000 RPM – FC-AL Disk)
    		n/a
    • 390-0482
    • Hitachi HUS156030VLF400 [HUS1530FCSUN300G]
      (300GB – 15000 RPM – FC-AL Disk)
    		n/a
    • 7010283
    • Seagate ST3300655FC [ST330055FSUN300G]
      (300GB – 15000 RPM – FC-AL Disk)
    		n/a
    • 541-0882
    • Drive Mounting Bracket (HDD Carrier)
    		n/a
    XTC-FC1CF-450G15K [S]540-7674 [C]450GB – 15000 RPM FC-AL, Disk Assembly with one of the following disks:n/a
    • 390-0421
    • Seagate ST3450856FC [ST345056FSUN450G]
      (450GB – 15000 RPM – FC-AL Disk)
    		n/a
    • 541-0882
    • Drive Mounting Bracket (HDD Carrier)
    		n/a
    XTC-FC1CF-600G15K [S]542-0163 [C]600GB – 15000 RPM FC-AL, Disk Assembly with one of the following disks and brackets:n/a
    • 390-0477
    • Seagate ST3600957FC [ST360957FSUN600G]
      (600GB – 15000 RPM FC-AL)
    		n/a
    • 390-0484
    • Hitachi HUS156060VLF401 [HUS1561FCSUN600G]
      (600GB – 15000 RPM FC-AL)
    		n/a
    • 541-0882
    • Drive Mounting Bracket (HDD Carrier)
    		n/a
    XTC-FC1CF-73GSSD [S]542-0321 [C]73GB Solid-State Drive FRUn/a
    • 542-0325
    • 73GB Solid-State Drive Tray
    		n/a
    • 371-4915
    • Stec F16IFE3B-73UC [Inquiry Unknown] (73GB – 3.5″ Solid State – FC-AL Disk)
    		n/a
    XTC-ST1CF-1TB7KZ [S]540-7590 [C]1TB – 7200 RPM SATA, Disk Assembly with one of the following disks:n/a
    • 390-0381
    • Hitachi HUA721010KLA330 [HUA7210SASUN1.0T]
      (1TB – 7200 RPM – SATA Disk)
    		n/a
    • 390-0414
    • Seagate ST31000340NS [ST31000NSSUN1.0T]
      (1TB – 7200 RPM – SATA Disk)
    		n/a
    • 390-0473
    • Seagate ST31000524NS [ST31001NSSUN1.0T]
      (1TB – 7200 RPM – SATA Disk)
    		n/a
    • 7045979
    • Seagate ST1000NM0011 [ST1000NM0011](1TB – 7200 RPM – SATA Disk)
    		n/a
    • 541-1406
    • Drive Mounting Bracket (SATA HDD Carrier)
    		n/a
    XTC-ST1CF-2TB7K [S]542-0164 [C]2TB – 7200 RPM, Disk Assembly with 1 bracket and 1 disk:n/a
    • 390-0467
    • Hitachi H7220AA30 [H7220AA30SUN2.0T]
      (2TB – 7200 RPM – SATA Disk)
    		n/a
    • 390-0474
    • Seagate ST32000644NS [ST32000NSSUN2.0T]
      (2TB – 7200 RPM – SATA Disk)
    		n/a
    • 7045982
    • Seagate ST2000NM0011 [ST2000NM0011] (2TB – 7200 RPM – SATA Disk)
    		n/a
    • 541-1406
    • Drive Mounting Bracket (SATA HDD Carrier)
    		n/a
    n/a541-1407Empty Disk Drive Slot Fillern/a
    n/a541-3899Disk Drive Filler Paneln/a
    Fibre Channel
    Option #Manufacturing
    Part #    		DescriptionPrevious
    Part #
    SG-XPCIE1FC-EM8-Z371-42958Gigabit/Sec PCI Express Single FC Host Adaptern/a
    70534338Gigabit/Sec PCI Express Single FC Host Adaptern/a
    SG-XPCIE1FC-QF8-Z371-43248Gigabit/Sec PCI Express Single FC Host Adaptern/a
    SG-XPCIE2FC-EM8-Z70534348Gigabit/Sec PCI Express Dual FC Host Adapter371-4306
    SG-XPCIE2FC-QF8-Z371-43258Gigabit/Sec PCI Express Dual FC Host Adaptern/a
    SG-XPCI1FC-EM2 [S]375-33042Gb PCI-X Single FC Host Adaptern/a
    SG-XPCI1FC-EM4-Z [S]375-33984Gb PCI-X Single FC Host Adaptern/a
    SG-XPCI1FC-QF4 [S]375-33544Gb PCI-X Single FC Host Adaptern/a
    SG-XPCI1FC-QL2 [S]375-33832Gb PCI-X Single FC Host Adaptern/a
    SG-XPCI2FC-EM2 [S]375-33052Gb PCI-X Dual FC Host Adaptern/a
    SG-XPCI2FC-EM4-Z [S]70585284Gb PCI-X Dual FC Host Adapter375-3399
    SG-XPCI2FC-QF2-Z [S]375-33632Gb PCI/PCI-X Dual FC Host Adaptern/a
    SG-XPCI2FC-QF4 [S]70608904Gb PCI-X Dual FC Host Adapter375-3294
    SG-XPCIE1FC-EM4 [S]375-33964Gigabit/Sec PCI Express Single FC Host Adaptern/a
    70534284Gigabit/Sec PCI Express Single FC Host Adaptern/a
    SG-XPCIE1FC-QF4 [S]375-33554Gigabit/Sec PCI Express Single FC Host Adaptern/a
    SG-XPCIE2FC-EM4 [S]375-33974Gigabit/Sec PCI Express Dual FC Host Adaptern/a
    70534274Gigabit/Sec PCI Express Dual FC Host Adaptern/a
    SG-XPCIE2FC-QF4 [S]375-33564Gigabit/Sec PCI Express Dual FC Host Adaptern/a
    SG-XPCIE2FCGBE-E-Z [S]371-40184Gb/sec PCI Express Dual FC / Dual Gigabit Ethernet ExpressModule Host Adapter, Emulexn/a
    SG-XPCIE2FCGBE-Q-Z [S]371-40174Gb/sec PCI Express Dual FC / Dual Gigabit Ethernet ExpressModule Host Adapter, QLogicn/a
    n/a371-1799 [F]4Gb/Sec Short Wave SFP Transceivern/a
    n/a371-43068Gigabit/Sec PCI Express Dual FC Host Adaptern/a
    n/a371-4582 [F]8Gb/Sec Short Wave SFP Transceivern/a
    n/a375-32944Gb PCI-X Dual FC Host Adaptern/a
    n/a375-33994Gb PCI-X Dual FC Host Adaptern/a
    n/a7048866 [F]4Gb/Sec Short Wave SFP Transceiver371-1799 [F]
    Sun 6180 Power Supply (Use form above for pricing)
    Option #Manufacturing
    Part #    		DescriptionPrevious
    Part #
    n/a180-2194 [F]DC Power Cablen/a
    n/a300-2012 [F]620 Watt DC Input Power Supply (CSM200)n/a
    n/a300-2055 [F]620 Watt AC Input Power Supply (CSM200)300-1826 [F]
    n/a300-2319 [F]620 Watt AC Input Power Supply (CSM200)300-2055 [F]
    Rack
    Option #Manufacturing
    Part #    		DescriptionPrevious
    Part #
    XTA6000-RK2-RAIL [S]594-5885Rack Rail Kit for Sun Rack IIn/a
    • 540-7796
    • Mounting Rail Kit
    		n/a
      • 341-4881
      • Mounting Rail
    		n/a
    XTA6X80CTRL-RK2-RL [S]542-0150Fixed Rail Mounting Kitn/a
    • 341-4882
    • Mounting Rail
    		n/a
    • 341-4883
    • Mounting Rail
    		n/a
    XTCCSM2-RK-19UZ [S]540-65983U Rack Rail Kit for Standard 19-inch System Cabinets

    Industry Leading Quality, Support and Integrity

    Quality Inspection Checklist
    Before it leaves our facility, every used and refurbished item is thoroughly inspected by our certified technicians and undergoes our exclusive Quality Inspection Checklist to ensure 100% satisfaction guarantee.

    Greentec Systems is a leading provider
    For server, networking and storage equipment. We have an extensive array of inventory of IBM Servers & Storage, Sun Servers & Storage, Cisco Networking (Switches, Routers, Security), and NetApp Storage (disk shelves, disk drives, Filers, NearStore, NetCache). If you don’t see the item or product you require please contact us.

    Have this equipment to sell?
    Depending on the age and condition of the equipment, there is a very good likelihood that we will be able to offer you cash or trade-in credit for other IT hardware. If the equipment is very old we can also assist you with properly decommissioning that gear in the most environmentally friendly way possible.

    Questions?
    For more information please contact 888.333.7388, or fill out the quote from above. We’d love to hear from you.

    Request Quote
    Greentec Systems We geek out helping you with your IT infrastructure.
    Request a quote or product information
    Send
