Oracle Sun Storage 3511

REQUEST A PRICE QUOTE:

Disks
250 GB	Hitachi 250GB – 7200 RPM, SATA Disk Drive
400 GB	Hitachi 400GB – 7200 RPM, SATA Disk Drive
500 GB	Hitachi 500GB – 7200 RPM, SATA Disk Drive
Note 1: All RAID configurations ship pre-configured with RAID level zero (RAID 0). Note 2: Supported RAID levels include 0, 1, 1+0, 3, 5, 3+0, and 5+0.
Capacity
Up to 12 Disk drives per array
250GB Disk drives	12 x 250 = 3TB
400GB Disk drives	12 x 400 = 4.8TB
500GB Disk drives	12 x 500 = 6.0TB
Environment
Power Requirement	AC: 90 to 264 VAC, single phase (47 to 63Hz) DC: -36 to -75 VDC
Input Voltage	AC: 100 to 240 VAC, single phase DC: -48 to -60 VDC, 18A
Current Per Input	AC: Values include: 90 VAC (3.51A) to 264 VAC (1.25A), 50 Hz 90 VAC (3.56A) to 264 VAC (1.31A), 60 Hz DC: -48 to -60 VDC, 18A
Maximum Inrush Current	115 VAC: 50A peak 230 VAC: 100A peak
Power Supply Output Voltages	+5VDC and +12VDC
Heat Output	1105 BTU/hr (fully populated array)
Altitude	Operating: -30 m to 3,048 m(-100 to 10000 feet) Non-operating: -30 m to 12192 m(-100 to 40000 feet)
Temperature	Operating: 5° C to 40° C (41° F to 104° F) Non-operating: -40° C to 65° C (-40° F to 149° F)
Humidity	Operating: 10% to 90% relative to 27° C max. wet bulb, noncondensing Non-operating:) 0% to 90% relative to 38° C max. wet bulb, noncondensing
Shock	Operating: 5.0 G, 11-ms, half-sine Non-operating: 15.0 G, 11-ms, half-sine
Vibration	Operating: 0.2 G, 5-500 Hz, swept-sine Non-operating: 1.0 G, 5-500 Hz, swept-sine
Dimensions and Weights
Height	Desktop: 9.25 cm (3.64 in) Rackmount: 8.89 cm (3.5 in)
Width	Desktop: 48.26 cm (19 in) Rackmount: 44.7 cm – body only (17.6 in)
Depth	Main Chassis: 45.72 cm (18.0 in) Chassis with Fan Modules: 50.80 cm (20.0 in) Chassis with Fan Modules and Handles: 53.34 cm (21.5 in)
Weight	Fully Loaded 26.8 kg (59.1 lbs) Packaged Weight (fully loaded): 31.9 kg (70.5 lbs)

Array Controller
Option #	Manufacturing Part #	Description
XTA-3511-CTRL-1G	370-6773	RAID I/O Module, 1GB Memory and Battery Backup (370-6799)
n/a	370-6774	Expansion I/O Module (JBOD)
n/a	370-6799	Battery Module

Backplane/Centerplane
Option #	Manufacturing Part #	Description
n/a	370-6775	2U Chassis + Midplane

Cables
Option #	Manufacturing Part #	Description
X311L	Localized Power Cord Kit – North America/Asia, RoHS:Y
X311L	180-1097	IEC 320 C13 to NEMA 5-15P – 15A/125V 2.5M Black, RoHS:Y
X312L	Localized Power Cord Kit – Continental Europe, RoHS:Y
X312L	180-1993	IEC 320 C13 to CEE 7/7 10A/250V 2.5M Black, RoHS:Y
X314L	Localized Power Cord Kit – Swiss, RoHS:Y
X314L	180-1994	IEC 320 C13 to SEV 1011 – 10A/250V 2.5M Black, RoHS:Y
X317L	Localized Power Cord Kit – U.K., RoHS:Y
X317L	180-1997	IEC 320 C13 to BS 1363 – 10A/250V 2.5M Black, RoHS:Y
X383L	Localized Power Cord Kit – Danish, RoHS:Y
X383L	180-1995	IEC 320 C13 to Asfnit 107 – 10A/250V 2.5M Black, RoHS:Y
X384L	Localized Power Cord Kit – Italian, RoHS:Y
X384L	180-1996	IEC 320 C13 to CEI 23-16/VII – 10A/250V 2.5M Black, RoHS:Y
X386L	Localized Power Cord Kit – Australian, RoHS:Y
X386L	180-1998	IEC 320 C13 to AS 3112 – 10A/250V 2.5M Black, RoHS:Y
X9721A	537-1036	Fibre Channel Optical Cable LC/SC, 0.4M
X9740A	537-1062	Fibre Channel Optical Cable LC/LC, 100M
X9722A	537-1035	Fibre Channel Optical Cable LC/SC, 2M
X9723A	537-1033	Fibre Channel Optical Cable LC/SC, 5M
X9724A	537-1034	Fibre Channel Optical Cable LC/SC, 15M
X9730A	537-1057	Fibre Channel Optical Cable LC/LC, 0.8M
X9732A	537-1041	Fibre Channel Optical Cable LC/LC, 2M, 2.0M
X9733A	537-1042	Fibre Channel Optical Cable LC/LC, 5M
X9734A	537-1043	Fibre Channel Optical Cable LC/LC, 15M
X9735A	537-1053	Fibre Channel Optical Cable LC/SC, 25M
X9736A	537-1051	Fibre Channel Optical Cable LC/LC, 25M
X9737A	537-1055	Fibre Channel Optical Cable LC/SC, 50M
X9738A	537-1052	Fibre Channel Optical Cable LC/LC, 50M
X9739A	537-1063	Fibre Channel Optical Cable SC/SC, 100M
n/a	130-4723	Fibre Channel Cable Coupler SC/SC
n/a	370-5540	Fibre Channel Expansion Cable, 0.5M
n/a	370-6627	DB-9M to DB-9F Serial Cable, 1.8M
n/a	370-6629	Ethernet Cable, 35-88730002
n/a	530-1819	Localized Power Cord Kit – Danish

Disks
Option #	Manufacturing Part #	Description
XTA-ST1NC-400G7K	540-6364	400GB – 7200 RPM SATA, Disk Assembly with one of the following disks:
XTA-ST1NC-400G7K	390-0214	Hitachi HDS724040KLSA80 [HDS7240SBSUN400G] (400GB – 7200 RPM – SATA Disk)
XTA-ST1NC-250G7K	540-6180	250GB – 7200 RPM SATA, Disk Assembly with one of the following disks:
	390-0164	Hitachi HDS722525VLSA80 [HDS7225SASUN250G] (250GB – 7200 RPM – SATA Disk)
	390-0246	Hitachi HDT722525DLA380 [HDS7225SBSUN250G] (250GB – 7200 RPM – SATA Disk), RoHS:Y
	390-0352	Hitachi HDT725025VLA380 [HDS7225SCSUN250G] (250GB – 7200 RPM – SATA Disk), RoHS:Y
XTA-ST1NC-500G7K	540-6365	500GB – 7200 RPM SATA, Disk Assembly with one of the following disks, RoHS:Y
XTA-ST1NC-500G7K	390-0247	Hitachi HDS725050KLA360 [HDS7250SASUN500G] (500GB – 7200 RPM – SATA Disk), RoHS:Y
n/a	n/a	Drive Mounting Bracket, 82-00001200 (Manufacturer Part Number)

Fibre Channel
Option #	Manufacturing Part #	Description
SG-XPCI1FC-QF4	375-3354	4Gb PCI-X Single FC Host Adapter, RoHS:Y
SG-XPCI2FC-QF4	375-3294	4Gb PCI-X Dual FC Host Adapter, RoHS:Y
SG-XPCIE1FC-EM4	375-3396	4Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
SG-XPCIE1FC-QF4	375-3355	4Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
SG-XPCIE2FC-EM4	375-3397	4Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
SG-XPCIE2FC-QF4	375-3356	4Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
SG-XPCIE2FCGBE-E-Z	371-4018	4Gb/sec PCI Express Dual FC / Dual Gigabit Ethernet ExpressModule Host Adapter, Emulex, RoHS:Y
SG-XPCIE2FCGBE-Q-Z	371-4017	4Gb/sec PCI Express Dual FC / Dual Gigabit Ethernet ExpressModule Host Adapter, QLogic, RoHS:Y
X6748A	375-0118	Compact PCI (cPCI) Dual Channel FC
(X)5133A	501-6640	Fibre Channel PCI Adapter
SFP-SW-4GB	371-0294	4Gbps Short Wave SFP, RoHS:Y
SFP-SW-4GB-4PK	371-0294	4Gbps Short Wave SFP, RoHS:Y
SG-XPCI1FC-EM2	375-3304	2Gb PCI-X Single FC Host Adapter, RoHS:Y
SG-XPCI1FC-JF2	375-3156	JNI 2Gb PCI Single FC Host Adapter
SG-XPCI1FC-QF2	375-3102	2Gb PCI Single FC Host Adapter
SG-XPCI1FC-QL2	375-3383	2Gb PCI-X Single FC Host Adapter, RoHS:Y
SG-XPCI1FC-QLC	375-3253	Entry-Level 2Gb PCI-X Single FC Host Adapter
SG-XPCI1FC-QLC-Z	375-3364	Entry-Level 2Gb PCI-X Single FC Host Adapter, RoHS:Y
SG-XPCI2FC-EM2	375-3305	2Gb PCI-X Dual FC Host Adapter, RoHS:Y
SG-XPCI2FC-JF2	375-3157	JNI 2Gb PCI Dual FC Host Adapter
SG-XPCI2FC-QF2	375-3108	2Gb PCI Dual FC Host Adapter
SG-XPCI2FC-QF2	240-4839	Low Profile Bracket, RoHS:Y
SG-XPCI2FC-QF2-Z	375-3363	2Gb PCI Dual FC Host Adapter, RoHS:Y
SG-XPCI2FC-QF2-Z	240-4839	Low Profile Bracket, RoHS:Y
X6727A	375-3030	PCI Dual FC Host Adapter+, RoHS:YL
X6757A	375-3048	SBus Dual FC Network Adapter
X6799A	375-3019	PCI Single FC Host Adapter
X9279A	370-6697	2Gb/Sec Single FC PCI-X Host Adapter
n/a	370-5211	2Gbps Short Wave SFP
n/a	371-0099	2Gbps Short Wave SFP

Power
Option #	Manufacturing Part #	Description
XTA-3000-2UAC-KIT	370-6776	AC Power Supply / Fan Module, 2U
XTA-3000-2UAC-KIT	371-0108	420 Watt AC Input Power Supply, RoHS:YL
XTA-3000-2UDC-KIT	370-6798	DC Power Supply / Fan Module, 2U
XTA-3000-2UDC-KIT	371-0109	420 Watt DC Input Power Supply, RoHS:YL

Rack
Option #	Manufacturing Part #	Description
XTA-3000-2U-R2T	370-7596	Sun StorEdge 3000 2U Rack Ready to Tabletop conversion kit
XTA-3000-2URK-19C	370-5649	Telco Rackmount Kit, Center Mount, 2U, 19″ Wide
XTA-3000-2URK-19F	370-5650	Telco Rackmount Kit, Flush/Front Mount, 2U, 19″ Wide
XTA-3000-2URK-19U	370-6166	SE3000 2U Family Universal Rackmount Kit
XTA-3000-2URK-19CZ	371-0828	Telco Rackmount Kit, Center Mount, 2U, 19″ Wide, RoHS:YL
XTA-3000-2URK-19FZ	371-0829	Telco Rackmount Kit, Flush/Front Mount, 2U, 19″ Wide, RoHS:YL
XTA-3000-2URK-19UZ	371-0827	SE3000 2U Family Universal Rackmount Kit, RoHS:YL

Switch/Hub
Option #	Manufacturing Part #	Description
SG-XSW64-BASE	370-5790	64 Port Base Unit 2Gb FC Switch (32 ports included with base unit)
SG-XSWBRO24K-MOD	Brocade 24000 Director 16-port FC Switching Blade
SG-XSWBRO24K-MOD	370-6820	16-Port Switch Module
SG-XSWM6140-64P	370-6131	McData Intrepid 6140 140-port Switch with 64 Ports active
SG-XSWM6140-RK64I	370-6133	McData Intrepid 6140 140-port Switch with 64 ports active in a McData Fabricenter Rack (International power)
SG-XSWM6140-RK64P	370-6132	McData Intrepid 6140 140-port Switch with 64 ports active in a McData Fabricenter Rack (US power).
SG-XSWMD4500-8P	370-6085	McData Sphereon 4500 24-port Switch with 8 ports activated
SG-XSWMD4500-UPG	n/a	McData Sphereon 4500 8 port activation license key, activates 8 additional ports
SG-XSWQLG5200-20P	370-7694	QLogic 5200 Switch (20 ports active)
SG-XSWQLG5200-8P	370-7664	QLogic 5200 Switch (8 ports active)
SG-XSW16-2GB	540-5404	Sun StorEdge Network 2GB FC Switch-16
SG-XSW16-32P	540-4751	Sun StorEdge Network FC Switch-16
SG-XSW64-BLADE-8P	370-5847	8 Port 2Gb FC Blade (Add up to 4 to SG-XSW64-BASE to achieve 64 ports)
SG-XSW8-2GB	540-5554	Sun StorEdge Network 2GB FC Switch-8
SG-XSWBRO12000-32P	370-5748	Brocade Silkworm 12000 Switch with 32 Ports
SG-XSWBRO12000-64P	370-4749	Brocade Silkworm 12000 Switch with 64 Ports
SG-XSWBRO24K-32P	370-6820	16-Port Switch Module
SG-XSWBRO24K-32P	370-7046	Brocade 24000 Director 32-Port Switch
SG-XSWBRO3200	370-5769	Brocade Silkworm 3200 8-Port FC Switch
SG-XSWBRO3250	370-6824	Brocade 3252 Value Line 8-Port FC Switch
SG-XSWBRO3250	370-7047	Brocade 3250 8-Port FC Switch
SG-XSWBRO3250VL2	370-6824	Brocade 3252 Value Line 8-Port FC Switch
SG-XSWBRO3800	370-4949	Brocade Silkworm 3800 16-Port FC Switch
SG-XSWBRO3850	370-6826	Brocade 3852 Value Line 16-Port FC Switch
SG-XSWBRO3850	370-7048	Brocade 3850 16-Port FC Switch
SG-XSWBRO3850VL2	370-6826	Brocade 3852 Value Line 16-Port FC Switch
SG-XSWBRO3900	370-6078	Brocade Silkworm 3900 32-Port FC Switch
SG-XSWBRO4100-16P	370-7756	Brocade Silkworm 4100 FC Switch (16 Ports)
SG-XSWBRO4100-32P	370-7770	Brocade Silkworm 4100 FC Switch (32 Ports)
SG-XSWMD4300-12P	370-6169	McData Sphereon 4300 12-port Switch
SG-XSWMD6064-32P	370-5732	McData 6064 Director Switch w/32 ports
n/a	540-4372	StorEdge Network FC Switch-8
