Greentec Systems is proud to offer Oracle’s refurbished SPARC T7 servers that are the world’s most advanced systems for enterprise workloads, with unique capabilities for information security, database and Java acceleration. Breakthrough Software in Silicon technology in Oracle’s new SPARC processor provides full speed encryption, plus detection and prevention of attacks to critical data in memory. It also enables real time analytics to be performed on OLTP databases by accelerating Oracle Database In-Memory queries in Oracle Database 12c. The combination of the world’s highest performance with breakthrough Software in Silicon features is the foundation to building the best and most secure mission critical clouds.

Oracle Sun SPARC T7-2 Server Overview

Oracle’s SPARC T7-2 server is a two-processor system that enables organizations to respond to IT demands with extreme security and performance, at a lower cost compared to alternatives. It is ideal for a wide range of enterprise class workloads, including database, applications, Java, and middleware, especially in a cloud environment. This system is based on the SPARC M7 processor, the first to use a revolutionary technology from Oracle referred to as Software in Silicon.
Software in Silicon technology is a breakthrough in microprocessor and server design, enabling databases and applications to run faster and with unprecedented security and reliability. The Silicon Secured Memory feature of Oracle’s SPARC M7 processor provides the capability of detecting and preventing invalid operations to application data, through hardware monitoring of software access to memory. This can stop malware from exploiting software vulnerabilities, such as buffer overflows. The hardware approach of Silicon Secured Memory is much faster than traditional software-based detection tools, meaning that security checks can be done in production without significant impact to performance. In addition, each processor core contains the fastest cryptographic acceleration in the industry, allowing IT organizations to deliver end-to- end data encryption and secure transactions with near-zero performance impact. In summary: you can easily activate data protection and encryption security, by default, without additional hardware investment.
In-memory Query Acceleration is another unique Software in Silicon feature in SPARC M7-based servers. It is implemented through accelerators specifically designed into the chip’s silicon to handle SQL primitives, such as those used by Oracle Database In- Memory in Oracle Database 12c. The accelerators operate on data at full memory speeds, taking advantage of the very high memory bandwidth of the processor.

KEY BENEFITS

Unique protection of application data from memory attacks or exploits of software vulnerabilities
End-to-end encryption of data with near-zero performance impact
Easy compliance management of application environments throughout their lifecycles, ensuring security of cloud infrastructure
Extreme acceleration of Oracle Database In-Memory queries, especially for compressed databases
Ability to run analytics on OLTP databases, enabling real-time insight on transactional data
Optimized for Java applications, middleware software, database, and enterprise applications
- Near-zero overhead virtualization for deploying more than 100 virtual machines per processor, lowering the cost per virtual machine
- Advanced design enables this dual- processor system to outperform competitive four-processor systems, lowering IT costKEY FEATURES
- Based on the advanced SPARC M7 processor, with first-ever Software in Silicon technology for security, performance, and efficiency
- 2 times faster performance per processor compared to current competitive processors, or previous- generation SPARC processors1
- Scalability within the same family of servers from 1 to 16 sockets with complete compatibility for applications and management
- Runs the Oracle Solaris 11 operating system for secure and compliant application deployment through single-step patching and immutable zones
- Agile and open cloud management with OpenStack, and powerful application-driven software-defined networking
- Built-in, no-cost virtualization technology with Oracle Solaris Zones and Oracle VM Server for SPARC
- Guaranteed binary compatibility and support for legacy applications that run under Oracle Solaris 10, 9, and 8
- Up to 6.4 TB of accelerated storage utilizing industry-standard NVMe technology in order to satisfy the most demanding I/O requirements
- Designed for the highest levels of reliability, availability, and serviceability (RAS) in a compact, energy-efficient footprin
Near-zero overhead virtualization for deploying more than 100 virtual machines per processor, lowering the cost per virtual machine
Advanced design enables this dual- processor system to outperform competitive four-processor systems, lowering IT costT7-2 KEY FEATURES
Based on the advanced SPARC M7 processor, with first-ever Software in Silicon technology for security, performance, and efficiency
2 times faster performance per processor compared to current competitive processors, or previous- generation SPARC processors1
Scalability within the same family of servers from 1 to 16 sockets with complete compatibility for applications and management
Runs the Oracle Solaris 11 operating system for secure and compliant application deployment through single-step patching and immutable zones
Agile and open cloud management with OpenStack, and powerful application-driven software-defined networking
Built-in, no-cost virtualization technology with Oracle Solaris Zones and Oracle VM Server for SPARC
Guaranteed binary compatibility and support for legacy applications that run under Oracle Solaris 10, 9, and 8
Up to 6.4 TB of accelerated storage utilizing industry-standard NVMe technology in order to satisfy the most demanding I/O requirements
Designed for the highest levels of reliability, availability, and serviceability (RAS) in a compact, energy-efficient footprint
Download SPARC T7-2 Server Documentation PDF’s Here

Brand:	Oracle / Sun Microsystems
Condition:	Refurbished and new (limited availability)
Availability:	Contact
Shipping Area:	Worldwide to most countries
Shipping Method:	Fedex (most orders), UPS, DHL, Freight Courier
Price:	Please use the quote form above for quick pricing
Payment:	Credit Card, Check, Net Terms (oac), Wire Transfer (required for international orders)
Guarantee:	All items are tested by Oracle trained technicians & backed by a 100% warranty
Questions?	Don’t hesitate to contact us with any questions regarding compatibility or other product info and requests. Our website represents only a fraction of our full inventory. Please reach out with your full requirements

Oracle Sun SPARC T7-2 Server Specs and Information:

Oracle Sun SPARC T7-2 Server Processor

Number

Two SPARC M7 32-Core 4.133GHz processors

CPUs

Up to 256 threads per processor (up to 8 threads per core)
Eight accelerators per processor, each supporting four concurrent in-memory query operations with decompression
Thirty-two on-chip encrytion instruction accelerators with direct nonpriviledged support for 15 industry-standard cryptographic algorithms: AES, Camellia, CRC32c, DES, 3DES, DH, DSA, ECC, MD5, RSA, SHA-1, SHA-224, SHA-256, SHA-384, SHA-512 (one per core)
Thirty-two floating-point units per processor (one per core)
One random number generator (one per processor)

Cache memory

Level 1: 16KB instruction and 16 KB data per core, Level 2: 256 KB L2 I$ per four cores, 256 KB L2 D$ per core pair, Level 3: 64 MB L3$ on chip

Sun SPARC T7-2 Server Main Memory

Capacities

Total DIMM slots: 32 – 4 slots per memory riser, 4 memory risers per CPU, 8 total memory risers
DIMM type: DDR4-2133
DIMM size: 16GB or 32GB
Maximum capacity: 1TB (32 × 32GB)

Standard Integrated Interfaces

Network

4 × 10 GbE Ethernet ports (100 Mbps/1 Gbps/10 Gbps), full duplex only, auto-negotiating

Network Management

One dedicated 10/100Base-T RJ-45 port Ethernet port

Serial Management

One dedicated RJ-45 port

Remote Management

Onboard service processor, running Integrated Lights Out Manager (ILOM)

Graphics

Two DB-15 VGA ports (one front, one rear)

USB

Front: 2 USB 2.0 Ports
Rear: 2 USB 3.0 Ports
Internal: 1 USB 3.0 Port

PCI Expansion Slots

8 low-profile PCI-Express 3.0 slots.

Slot #	Physical	Electrical
1	x16	x16
2	x16	x16
3	x8	x8
4	x8	x8
5	x8	x8
6	x8	x8
7	x16	x16
8	x16	x16

Oracle Sun SPARC T7-2 Server Internal Mass Storage

Disks

Up to six 2.5-inch SAS-3 drives
600GB or 1.2TB 2.5-inch SAS-3 disk drives
Optional internal storage may be installed within the standard drive bays:
400GB Solid State Drives (max 6) or 1.6 TB NVMe Solid State Drives (max 4)
RAID 0, RAID 1, and RAID 1E support

DVD-ROM

One Slimline SATA DVD +/-RW

Oracle Sun SPARC T7-2 Server Power Supplies

2 × 2000 Watt, hot-swappable, 1+1 redundant power supply units (PSU)

Environment

Input Voltage

200 – 240 VAC, 50-60Hz

Input Current

13.65A @ 200 VAC (max)

Input Power

2730W @ 200 VAC (max)

Maximum Heat Dissipation

9,317 BTU/hr, 9830 KJ/hr

Power Consumption

Online power calculator

Temperature

Operating: 5° C to 35° C (41° F to 95° F)
Nonoperating: -40° C to 65° C (-40° F to 149° F)

Humidity

Operating: 10% to 90% relative humidity noncondensing, 27° C (81° F) maximum wet bulb
Nonoperating: Up to 93% relative humidity noncondensing, 38° C (100° F) maximum wet bulb

Altitude

Operating: 0m to 3,000m (0 ft. to 9,840 ft), maximum ambient temperature is derated by 1° C for every 300m above 900m (1.8° F for every 1000ft)
Nonoperating: 0m to 12,000m ( 0 ft. to 39,370 ft.)

Acoustic Noise

Operating/Idling: 67.8 dBA / 80.4 dBA (LwAd, 1B = 10dB)
Operating/Idling: 7.7 B / 8.9 B (LpAm, bystander positions)

Regulations
Meets or exceeds the following requirements:

Safety

UL/CSA 60950-1, EN 60950-1 CB Scheme with all country deviations

EMI/EMC

FCC 47 CFR 15, ICES-003, EN 55022, EN61000-3-2, EN61000-3-3

Immunity

EN 55024

Certifications

North American Safety (NRTL), European Union (EU), International CB Scheme, BIS (India), BSMI (Taiwan), RCM (Australia), MSIP (Korea), VCCI (Japan)

European Union Directives

Restriction of Hazardous Substances (RoHS) Directive 2011/65/EU, Low Voltage Directive 2014/35/EU, EMC Directive 2014/30/EU, and

Oracle T7-2 Server Dimensions and Weight

Height

129.8 mm (5.11 in.), 3U

Width

436.5 mm (17.185 in.)

Depth

752.5 mm (29.63 in.)

Weight

Max: 37.2 kg (82 lbs) max, without rackmount kit

Clearance and Service Access

Front

914.4 mm (36 in.)

Rear

914.4 mm (36 in.)

Batteries
Option #	Manufacturing Part #	Description	Previous Part #
n/a	371-2210 [C]	3V Lithium Coin Cell Battery	n/a

Oracle Sun SPARC T7-2 Server CPU Module
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7097099	32-Core 4.133GHz CPU Mezzanine	n/a
n/a	7310197	32-Core 4.133GHz CPU Mezzanine	n/a
n/a	7315604	32-Core 4.133GHz CPU Mezzanine	n/a

Cables
Option #	Manufacturing Part #	Description	Previous Part #
7102870	7039999 [C]	MPO to MPO High Bandwidth QSFP Optical Cable, 20M	n/a
7102871	7040001 [C]	MPO to MPO High Bandwidth QSFP Optical Cable, 50M	n/a
7105206	7063852 [C]	InfiniBand Cable, QSFP, Optical, MPO to MPO, 100M	n/a
7110923	7098473 [F]	38-Pin Mini SAS-3 Cable, SFF-8643 to SFF-8643, 460mm	n/a
X2121A-1M-N	530-4444 [C]	10Gbps QSFP to QSFP Cable, 1m	n/a
X2121A-3M-N	530-4445 [C]	10Gbps QSFP to QSFP Cable, 3m	n/a
X2121A-5M-N	530-4446 [C]	10Gbps QSFP to QSFP Cable, 5m	n/a
X2125A-1M-N	530-4450 [C]	QSFP to 4× SFP+ Splitter Cable, 1m	n/a
X2125A-3M-N	530-4451 [C]	QSFP to 4× SFP+ Splitter Cable, 3m	n/a
X2125A-5M-N	530-4452 [C]	QSFP to 4× SFP+ Splitter Cable, 5m	n/a
X2130A-3M-N	530-4442 [C]	10Gbps SFP+ TwinX Cable, 3m	n/a
X2130A-5M-N	530-4443 [C]	10Gbps SFP+ TwinX Cable, 5m	n/a
X9238-1-A-N	180-2085 [C]	IEC 320 Sheet E to IEC 320 C13 Power Jumper Cord 13A 90° 2.5M	n/a
n/a	530-3100	RJ45F to DB9F Adapter	n/a
n/a	7314624 [F]	Cable Kit SKU	n/a
	530-4288	Fan Board to System Board Power Cable	n/a
	530-4289	System Board to PDB Cable	n/a
	7091364	System Board to Disk Backplane Signal Cable	n/a
	7314511	36-Pin Mini SAS-3 Cable, SFF-8643 to SFF-8643, 175mm	n/a
	530-4287	Fan Board to System Board Signal Cable	n/a
	530-4291	System Board to Disk Backplane Power Cable	n/a

Oracle Sun SPARC T7-2 Server Chassis
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7074704	Chassis Subassembly	n/a
	341-5805	Rack Mount Ear	n/a
	530-4356	AC Input Line Filter with Cable	n/a
	7047502	Chassis Shipping Bracket	n/a
	7068043	Power Distribution Board Cover	n/a
	7089112	Front Bezel	n/a
	7091225	G3 Chassis	n/a
	7092810	Top Cover	n/a
	150-4065	Interlock Switch Magnet	n/a
	7096096 [F]	6-Slot NVMe Backplane	n/a
	341-6188	Power Supply Chassis Cable Cover	n/a
n/a	7303163	G3N Chassis Subassembly	n/a
	341-5805	Rack Mount Ear	n/a
	541-3539 [C]	92mm Fan Module	n/a
	7068043	Power Distribution Board Cover	n/a
	7089112	Front Bezel	n/a
	7091225	G3 Chassis	n/a
	7092810	Top Cover	n/a
	150-4065	Interlock Switch Magnet	n/a
	7303476 [F]	Power Distribution Assembly	n/a
	371-4446	Bus Bar	n/a
	7307832	Power Distribution Board / Power Supply Backplane	n/a
	341-6188	Power Supply Chassis Cable Cover	n/a
	530-4356	AC Input Line Filter with Cable	n/a
	7096096 [F]	6-Slot NVMe Backplane	n/a
	7303158 [F]	Fan Cage Assembly	n/a
	530-4349	LED Flex Circuit	n/a
	7303154	Fan Board with USB and VGA	n/a

Communication
Option #	Manufacturing Part #	Description	Previous Part #
7104074	7092757 [C]	Dual 40Gb/Sec (4x) QDR InfiniBand Host Channel Adapter Module M3	n/a
n/a	7046442 [C]	Dual 40Gb/Sec (4x) QDR InfiniBand Host Channel Adapter Module M3	n/a

Disk Backplane
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7096096 [F]	6-Slot NVMe Backplane	n/a

Disks
Option #	Manufacturing Part #	Description	Previous Part #
7110927	7302552 [C]	1.6TB Solid State NVMe Drive Assembly	n/a
	7093848	1.6TB 2.5″ eMLC NVMe Solid State Drive	n/a
	541-2123	Marlin 2.5″ Bracket	n/a
7110933	7094132 [C]	400GB Solid State SAS Drive Assembly	n/a
	7093645	400GB SAS Solid State Drive [HSCAC2DA4SUN400G]	n/a
	541-2123	Marlin 2.5″ Bracket	n/a
7111103	7093015 [C]	600GB – 10000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks:	n/a
	7093013	Hitachi HUC101860CSS200 (600.0GB – 10000 RPM SAS Disk)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a
7111108	7093037 [C]	1.2TB – 10000 RPM SAS SFF Disk Assembly w 1 bracket and 1 of the following disks:	n/a
	7093035	Hitachi HUC101812CSS200 [H101812SFSUN1.2T] (1.2TB – 10000 RPM – SAS DISK)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a

T7-2 Server Ethernet
Option #	Manufacturing Part #	Description	Previous Part #
7100477	7070195 [C]	Quad Port GbE PCI Express 2.0 Low Profile Adapter, UTP	n/a
7100481	7070202 [C]	Dual Port GbE PCI Express 2.0 Low Profile Adapter, MMF	n/a
7100488	7070006 [C]	Dual 10-Gigabit Base-T PCI Express Gen2	n/a
X1109A-Z	7051223 [C]	Dual 10-Gigabit PCI Express Ethernet SFP+ LP	n/a
X2124A-N	135-1204 [C]	10Gb/Sec QDR InfiniBand / 40Gb/Sec Ethernet QSFP Transceiver	n/a
X2129A-N	530-4449 [C]	10Gb/Sec Short Wave SFP+ Transceiver	n/a
X5562A-Z	135-1205 [C]	10Gb/Sec Long Wave SFP+ Transceiver	n/a

Fan
Option #	Manufacturing Part #	Description	Previous Part #
n/a	541-3539 [C]	92mm Fan Module	n/a
n/a	7093647	Grey Plastic Air Divider w/ Fault Remind Button	n/a
n/a	7095079 [F]	Fan Cage Assembly	n/a
	530-4349	LED Flex Circuit	n/a
	7094477	Fan Board with USB and VGA	n/a
n/a	7303158 [F]	Fan Cage Assembly	n/a
	530-4349	LED Flex Circuit	n/a
	7303154	Fan Board with USB and VGA	n/a

Fibre Channel
Option #	Manufacturing Part #	Description	Previous Part #
7101674	7023303 [C]	Dual 16Gigabit/Sec Fibre Channel / 10Gbps FCoE Host Adapter, QLogic	n/a
7101676	7023325 [C]	Pair of 16Gbps Short Wave SFP+	n/a
7101676	7023324	16Gb/Sec Short Wave SFP+ Transceiver, QLogic	n/a
7101678	7023315 [C]	Pair of 10Gbps Short Wave SFP+	n/a
7101678	7023316	10Gb/Sec Short Wave SFP+ Transceiver, QLogic	n/a
7101684	7023036 [C]	Dual 16Gigabit/Sec Fibre Channel / 10Gbps FCoE Host Adapter, Emulex	n/a
7101686	7023059 [C]	Pair of 16Gbps Short Wave SFP+	n/a
7101686	7023053	16Gb/Sec Short Wave SFP+ Transceiver, Emulex	n/a
SG-XPCIE2FC-EM8-N	7053434 [C]	8Gigabit/Sec PCI Express Dual FC Host Adapter	n/a
SG-XPCIE2FC-QF8-N	371-4325 [C]	8Gigabit/Sec PCI Express Dual FC Host Adapter	n/a

I/O
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7064634 [F]	8-Port PCI Express Switch	n/a
n/a	7096186	PCI Express Switch w/o Bracket or Heatsink	n/a

Oracle Sun SPARC T7-2 Server Memory
Option #	Manufacturing Part #	Description	Previous Part #
7107207	7082850 [C]	16GB Registered DDR4-2133 DIMM	n/a
7107209	7082851 [C]	32GB Load Reduced DDR4-2133 DIMM	n/a
n/a	7074618 [C]	2GB Embedded USB	n/a
n/a	7092877	USB T10 Torx Thumbscrew, M3 0.5 x 6mm	n/a
n/a	7319165 [F]	Memory Riser Assembly	n/a
	7097166	Memory Riser	n/a
	7303166	Memory Riser Carrier	n/a

Power
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7049297 [C]	A263 2000W AC Input Power Supply	n/a
n/a	7300803 [F]	Power Supply Backplane Assembly	n/a
	371-4446	Bus Bar	n/a
	7052430	Power Distribution Board / Power Supply Backplane	n/a
n/a	7303476 [F]	Power Distribution Assembly	n/a
	371-4446	Bus Bar	n/a
	7307832	Power Distribution Board / Power Supply Backplane	n/a
n/a	7317314 [F]	Power Supply Backplane Assembly	n/a
	371-4446	Bus Bar	n/a
	7052430	Power Distribution Board / Power Supply Backplane	n/a

T7-2 Server Rack
Option #	Manufacturing Part #	Description	Previous Part #
XSR-JUMP-1MC13-N	7015399 [C]	10A/250V 90° IEC 320 Sheet E to IEC 320 C13 Cord, 1M	n/a
XSR-JUMP-2MC13-N	7015400 [C]	10A/250V 90° IEC 320 Sheet E to IEC 320 C13 Cord, 2M	n/a
n/a	371-4791 [C]	Tool-less Slide Rail Rack Mount Kit	n/a
n/a	371-4812 [C]	Cable Management Arm	n/a

Removable Media
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7302240 [C]	Tray-Load SATA DVD-Writer/CD-Writer	n/a
	7089963	8x Tray-Load DVD-ROM/24-x CD-ROM Writer (Gen5)	n/a
	7094095	DVD Carrier	n/a
	7318289	DVD Bezel	n/a
	7318304	Bezel Liner	n/a
n/a	7314403 [C]	Tray-Load DVD Assembly	n/a
	7079028	DVD Bezel	n/a
	7089203	DVD Liner	n/a
	7094095	DVD Carrier	n/a
	7309891	8x Tray-Load DVD-ROM/24x CD-ROM Writer (Gen6)	n/a

SCSI
Option #	Manufacturing Part #	Description	Previous Part #
7110119	7085208 [C]	8-Port 12Gbps SAS PCI Express HBA	n/a
7110865	7307468 [C]	1.6TB Flash Accelerator F160 NVMe Card w/ LP Bracket (B1 Silicon)	n/a

System Board
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7315607 [F]	System Board Assembly	n/a
	7051520	Rear I/O Board	n/a
	530-4348	System Board to Rear I/O Board Signal Cable	n/a
	7098011	System Board Tray	n/a
	7315604	32-Core 4.133GHz CPU Mezzanine	n/a
	7318239	System Board	n/a
	371-2210 [C]	3V Lithium Coin Cell Battery	n/a
	525-2146 [C]	SSCC NVRAM	n/a
	530-3510	Interlock Switch Cable	n/a
n/a	7318240 [F]	System Board Assembly	n/a
	7097099	32-Core 4.133GHz CPU Mezzanine	n/a
	530-4348	System Board to Rear I/O Board Signal Cable	n/a
	7051520	Rear I/O Board	n/a
	7098011	System Board Tray	n/a
	7318239	System Board	n/a
	371-2210 [C]	3V Lithium Coin Cell Battery	n/a
	525-2146 [C]	SSCC NVRAM	n/a
	530-3510	Interlock Switch Cable	n/a
n/a	7318270 [F]	System Board Assembly	n/a
	530-4348	System Board to Rear I/O Board Signal Cable	n/a
	7051520	Rear I/O Board	n/a
	7098011	System Board Tray	n/a
	7310197	32-Core 4.133GHz CPU Mezzanine	n/a
	7318239	System Board	n/a
	371-2210 [C]	3V Lithium Coin Cell Battery	n/a
	525-2146 [C]	SSCC NVRAM	n/a
	530-3510	Interlock Switch Cable	n/a

System Service Processor
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7306978 [F]	Service Processor Assembly	n/a
	350-1614	Service Processor Cover	n/a
	7306979	Service Processor	n/a
n/a	7319380 [F]	Service Processor Assembly	n/a
	350-1614	Service Processor Cover	n/a
	7319381	Service Processor	n/a

Industry Leading Quality, Support and Integrity

Quality Inspection Checklist
Before it leaves our facility, every used and refurbished item is thoroughly inspected by our certified technicians and undergoes our exclusive Quality Inspection Checklist to ensure 100% satisfaction guarantee.

Greentec Systems is a leading provider
For server, networking and storage equipment. We have an extensive array of inventory of IBM Servers & Storage, Sun Servers & Storage, Cisco Networking (Switches, Routers, Security), and NetApp Storage (disk shelves, disk drives, Filers, NearStore, NetCache). If you don’t see the item or product you require please contact us.

Have this equipment to sell?
Depending on the age and condition of the equipment, there is a very good likelihood that we will be able to offer you cash or trade-in credit for other IT hardware. If the equipment is very old we can also assist you with properly decommissioning that gear in the most environmentally friendly way possible.

Questions?
For more information please contact 888.333.7388, or fill out the quote from above. We’d love to hear from you.
