Oracle Sun SPARC T3-2 Server

REQUEST A PRICE QUOTE:

Brand:	Oracle / Sun Microsystems
Condition:	Refurbished and new (limited availability)
Availability:	Contact
Shipping Area:	Worldwide to most countries
Shipping Method:	Fedex (most orders), UPS, DHL, Freight Courier
Price:	Please use the quote form above for quick pricing
Payment:	Credit Card, Check, Net Terms (oac), Wire Transfer (required for international orders)
Guarantee:	All items are tested by Oracle trained technicians & backed by a 100% warranty
Questions?	Don’t hesitate to contact us with any questions regarding compatibility or other product info and requests. Our website represents only a fraction of our full inventory. Please reach out with your full requirements

Here is one of the newest two -socket, three rack unit (3U) server, Greentec Systems is pround to offer refurbished used Oracle Sun SPARC T3-2 is powered by the industry’s first 16 core SPARC T3 processor and is the first 256 thread general purpose server
It packs 16 cores and 128 simultaneous threads onto a single piece of silicon, together
with the key functions of an entire system on a single chip
The SPARC T3-2 features 6 hard disk drives, 32 DDR3 DIMM slots, and 10 PCIe Gen2 slots. When fully populated with 8GB DDR3 DIMMs, the system provides a total of 256 gb memory ram.

Sun T3-2 Specs and Information:

Processor

Number

Two SPARC T3 16-Core 1.65GHz processor

Architecture

SPARC V9 architecture

CPUs

1.65GHz 16-Core
128 threads per CPU, 256 threads max
Sixteen floating-point units
Dual multithreaded 10 GbE PCI integrated onto each chip
On-board cryptography with new Kasumi Bulk algorithm, SHA384, & SHA512 supporting 12 embedded security industry-standard ciphers: DES, 3DES, AES, RC4, SHA1, SHA256, SHA384, SHA512, MD5, RSA to 2048 key, ECC, CRC32

Cache memory

6MB integrated L2

Main Memory

Capacities

Total DIMM slots: 32 – 8 slots per memory riser, 2 memory risers per CPU
DIMM type: DDR3
DIMM size: 4GB or 8GB
Minimum Configuation: 64GB. (16 × 4GB). 16 slots is minimum slot configuration.
Maximum capacity: 256GB (32 × 8GB)

Standard Integrated Interfaces

Network

4 × 10/100/1000 Mbps autonegotiating ports

Network Management

One dedicated 10/100Base-T RJ-45 port Ethernet port

Serial Management

One dedicated RJ-45 port

Remote Management

Onboard service processor, running Integrated Lights Out Manager (ILOM) 3.0

Graphics

Two DB-15 VGA connectors (one front, one rear)

USB

Front: 2 USB 2.0 Ports
Rear: 2 USB 2.0 Ports
(also 1 internal USB port)

PCI Expansion Slots

10 low-profile PCI-Express 2.0 slots.
1 Network Module Card / XAUI slot

Slot #	Physical	Electrical
0	x8	x8
1	x8	x8
2	x8	x8
3	x16	x8
4	x8	x4
5	x8	x4
6	x16	x8
7	x8	x8
8	x8	x8
9	x8	x8

Internal Mass Storage

Disks

Up to six 2.5-inch SAS drives
300GB 2.5-inch SAS disk drives
RAID 0 and RAID 1 support

DVD-ROM

1 slimline SATA DVD +/-RW

Power Supplies

2 × 2060 Watt, hot-swappable, N+1 redundant power supply units (PSU)

Environment

Input Voltage

200 – 240 VAC, 50-60Hz

Input Current

12A @ 200 VAC

Heat Output

7,417 BTU/hr (Max)

Power Consumption

2175W (Max)

Temperature

Operating: 5° C to 35° C (41° F to 95° F)
Nonoperating: -40° C to 65° C (-40° F to 149° F)

Humidity

Operating: 10% to 90% relative humidity noncondensing, 27° C (80.6° F) maximum wet bulb
Nonoperating: Up to 93% relative humidity noncondensing, 38° C (100.4° F) maximum wet bulb

Altitude

Operating: up to 3000m (10000 ft.)
Nonoperating: up to 12000m (40000 ft.)Note: Up to 3048m (10000 ft), maximum ambient temperature is derated by 2° C for every 1km (3.6° F for every 3280ft)

Vibration

Operating: 0.15G (vertical), 0.10G (horizontal) 5-500Hz swept sine
Nonoperating: 0.5G (vertical), 0.25G horizontal) 5-500Hz swept sine

Shock

Operating: 3Gs, 11ms half-sine
Nonoperating: 1-inch roll-off free fall, front-to-back rolling direction, 25mm threshold height at 0.75 m/s impact velocity

Acoustic Noise

Operating/Idling: 7.7 B / 7.6 B (LwAd, 1B = 10dB)
Operating/Idling: 61.5 dB / 61.2 dB (LpAm, bystander positions)

Regulations
Meets or exceeds the following requirements:

Safety

UL/CSA-60950-1, EN60950-1, IEC60950-1 CB Scheme with all country deviations, IEC825-1, 2, CFR21 part 1040, CNS14336

RFI/EMI

EN55022 Class A 47 CFR 15B Class A ICES-003 Class A VCCI Class A AS/NZ 3548 Class A CNS 13438 Class A KSC 5858 Class A EN61000-3-2 EN61000-3-3

Immunity

EN55024 IEC 61000-4-2 IEC 61000-4-3 IEC 61000-4-4 IEC 61000-4-5 IEC 61000-4-6 IEC 61000-4-8 IEC 61000-4-11

Regulatory Markings

CE, FCC, ICES-003, C-tick, VCCI, GOST-R, BSMI, MIC, UL/cUL

Dimensions and Weight

Height

129.85 mm (5.11 in.)

Width

436.5 mm (17.18 in.)

Depth

732 mm (28.81 in.)

Weight

Min: 26.31 kg (58 lbs)
Max: 36.29 kg (80 lbs)

Clearance and Service Access

Front

910 mm (36 in.)

Rear

910 mm (36 in.)

Batteries
Option #	Manufacturing Part #	Description	Previous Part #
n/a	371-2210 [C]	3V Lithium Coin Cell Battery	n/a

Cables
Option #	Manufacturing Part #	Description	Previous Part #
7102869	7039990 [C]	MPO to MPO High Bandwidth QSFP Optical Cable, 10M	n/a
7102870	7039999 [C]	MPO to MPO High Bandwidth QSFP Optical Cable, 20M	n/a
7102871	7040001 [C]	MPO to MPO High Bandwidth QSFP Optical Cable, 50M	n/a
X2121A-1M-N	530-4444 [C]	10Gbps QSFP to QSFP Cable, 1m	n/a
X2121A-3M-N	530-4445 [C]	10Gbps QSFP to QSFP Cable, 3m	n/a
X2121A-5M-N	530-4446 [C]	10Gbps QSFP to QSFP Cable, 5m	n/a
X2125A-1M-N	530-4450 [C]	QSFP to 4× SFP+ Splitter Cable, 1m	n/a
X2125A-3M-N	530-4451 [C]	QSFP to 4× SFP+ Splitter Cable, 3m	n/a
X2125A-5M-N	530-4452 [C]	QSFP to 4× SFP+ Splitter Cable, 5m	n/a
X2127A-10M	530-4480 [C]	MPO to 4x LC Duplex Splitter Cable, 10m	n/a
X2127A-20M	530-4481 [C]	MPO to 4x LC Duplex Splitter Cable, 10m	n/a
X2127A-50M	530-4482 [C]	MPO to 4x LC Duplex Splitter Cable, 50m	n/a
X2130A-1M-N	530-4441 [C]	10Gbps SFP+ TwinX Cable, 1m	n/a
X2130A-3M-N	530-4442 [C]	10Gbps SFP+ TwinX Cable, 3m	n/a
X2130A-5M-N	530-4443 [C]	10Gbps SFP+ TwinX Cable, 5m	n/a
X2130A-10M-N [S]	530-4454 [C]	10Gbps SFP+ TwinX Cable, 10m	n/a
n/a	560-2963 [C]	Cable Kit	n/a
	530-3895	4x Mini SAS Cable, SFF-8087 to SFF-8087, 530mm	n/a
	530-4287	Fan Board to System Board Signal Cable	n/a
	530-4288	Fan Board to System Board Power Cable	n/a
	530-4289	System Board to PDB Cable	n/a
	530-4290	System Board to Disk Backplane Signal Cable	n/a
	530-4291	System Board to Disk Backplane Power Cable	n/a
n/a	7070388 [C]	Cable Kit	560-2963 [C]
	7024007 [C]	SAS Cable, SFF-8087 to SFF-8087, 215mm (x2)	n/a
	530-3895	4x Mini SAS Cable, SFF-8087 to SFF-8087, 530mm	n/a
	530-4287	Fan Board to System Board Signal Cable	n/a
	530-4288	Fan Board to System Board Power Cable	n/a
	530-4289	System Board to PDB Cable	n/a
	530-4290	System Board to Disk Backplane Signal Cable	n/a
	530-4291	System Board to Disk Backplane Power Cable	n/a

Communication
Option #	Manufacturing Part #	Description	Previous Part #
X4242A	375-3696 [C]	Dual 40Gbps InfiniBand 4x QDR PCI Express Low Profile Host Channel Adapter	n/a
X4242A	7092767 [C]	Dual 40Gbps InfiniBand 4x QDR PCI Express Low Profile Host Channel Adapter	n/a
X6000A-N [S]	375-3424 [C]	PCI Express Sun Crypto Accelerator 6000	n/a

Disk Backplane
Option #	Manufacturing Part #	Description	Previous Part #
n/a	511-1246 [F]	6-Slot Disk Backplane	n/a

Disks
Option #	Manufacturing Part #	Description	Previous Part #
SE6X3G11Z [S]	540-7869 [C]	300GB – 10000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks:	n/a
	390-0449	Seagate ST9300603SS [ST930003SSUN300G] (300GB – 10000 RPM – SAS Disk)	n/a
	390-0451	Hitachi HUC103030CSS600 [H103030SCSUN300G] (300GB – 10000 RPM – SAS Disk)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a
SE6X3G12Z [S]	542-0388 [C]	300GB – 10000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks:	n/a
	390-0487	Hitachi HUC106030CSS600 [H106030SDSUN300G] (300GB – 10000 RPM – SAS Disk)	n/a
	390-0490	Seagate ST9300605SS [ST930005SSUN300G](300GB 10000 RPM SAS Disk)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a
SE6X3K11Z [S]	542-0287 [C]	600GB – 10000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks;	n/a
	390-0488	Hitachi HUC106060CSS600 [H106060SDSUN600G] (600GB – 10000 RPM – SAS Disk)	n/a
	390-0491	Seagate ST9600205SS [ST960005SSUN600G](600GB 10000 RPM SAS Disk)	n/a
	7045228	Hitachi HUC109060CSS600 [H109060SESUN600G] (600GB – 10000 RPM – SAS Disk)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a
SE6X3Y11Z [S]	540-7841 [C]	32GB Solid State SATA Drive Assembly	n/a
SE6X3Y11Z [S]	541-2123	Marlin 2.5″ Bracket	n/a
SESX3G11Z-N [S]	540-7869 [C]	300GB – 10000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks:	n/a
	390-0449	Seagate ST9300603SS [ST930003SSUN300G] (300GB – 10000 RPM – SAS Disk)	n/a
	390-0451	Hitachi HUC103030CSS600 [H103030SCSUN300G] (300GB – 10000 RPM – SAS Disk)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a

Ethernet
Option #	Manufacturing Part #	Description	Previous Part #
7105381	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA – SR
7105381	7053422 [C]	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA – SR	375-3681 [C]
SE4X5XC1Z	511-1525 [C]	10 Gb Ethernet Network Module	n/a
X1109A-Z	7051223 [C]	Dual 10-Gigabit PCI Express Ethernet SFP+ LP	375-3617 [C]
X2124A-N	135-1204 [C]	10Gb/Sec QDR InfiniBand / 40Gb/Sec Ethernet QSFP Transceiver	n/a
X2129A-N	530-4449 [C]	10Gb/Sec Short Wave SFP+ Transceiver	n/a
SG-XPCIEFCOE2-Q-SR [S]	7053422 [C]	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA – SR	375-3681 [C]
SG-XPCIEFCOE2-Q-TA [S]	7053423 [C]	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA – Direct Attach	375-3682 [C]
X4447A-Z-N [S]	7055021 [C]	Quad Port GbE PCI Express, UTP	511-1422 [C]
X4447A-Z-N [S]	371-2207	Bracket Low-Profile	n/a
X7280A-2-N [S]	371-0905 [C]	PCI Express Dual Gigabit Ethernet UTP	n/a
X7281A-2-N [S]	7056733 [C]	PCI Express Dual Gigabit Ethernet MMF	371-0904 [C]
n/a	371-0904 [C]	PCI Express Dual Gigabit Ethernet MMF	n/a
n/a	375-3617 [C]	Dual 10-Gigabit Ethernet SFP+ LP	n/a
n/a	375-3681 [C]	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA – SR	n/a
n/a	375-3682 [C]	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA – Direct Attach	n/a
n/a	511-1422 [C]	Quad Port GbE PCI Express, UTP	n/a
n/a	371-2207	Bracket Low-Profile	n/a

Fan
Option #	Manufacturing Part #	Description	Previous Part #
n/a	541-3535 [F]	Fan Cage Assembly	n/a
	511-1243	Fan Board with USB and VGA	n/a
	530-4349 [F]	LED Flex Circuit	n/a
n/a	541-3539 [C]	92mm Fan Module	n/a

Fibre Channel
Option #	Manufacturing Part #	Description	Previous Part #
SG-XPCIE2FC-EM8-N	7053434 [C]	8Gigabit/Sec PCI Express Dual FC Host Adapter	371-4306 [C]
SG-XPCIE2FC-QF8-N	371-4325 [C]	8Gigabit/Sec PCI Express Dual FC Host Adapter	n/a
7105389 [S]	Gigabit/Sec PCI Express Dual FC Host Adapter for EU Countries
7105389 [S]	7053427 [C]	4Gigabit/Sec PCI Express Dual FC Host Adapter	n/a
7105390 [S]	4Gigabit/Sec PCI Express Single FC Host Adapter for EU Countries
7105390 [S]	7053428 [C]	4Gigabit/Sec PCI Express Single FC Host Adapter	n/a
SG-XPCIE1FC-EM4 [S]	375-3396 [C]	4Gigabit/Sec PCI Express Single FC Host Adapter	n/a
SG-XPCIE1FC-EM4 [S]	7053428 [C]	4Gigabit/Sec PCI Express Single FC Host Adapter	n/a
SG-XPCIE1FC-EM8-N [S]	371-4295 [C]	8Gigabit/Sec PCI Express Single FC Host Adapter	n/a
SG-XPCIE1FC-EM8-N [S]	7053433 [C]	8Gigabit/Sec PCI Express Single FC Host Adapter	n/a
SG-XPCIE1FC-QF4 [S]	375-3355 [C]	4Gigabit/Sec PCI Express Single FC Host Adapter	n/a
SG-XPCIE1FC-QF8-N [S]	371-4324 [C]	8Gigabit/Sec PCI Express Single FC Host Adapter	n/a
SG-XPCIE2FC-EM4 [S]	375-3397 [C]	4Gigabit/Sec PCI Express Dual FC Host Adapter	n/a
SG-XPCIE2FC-EM4 [S]	7053427 [C]	4Gigabit/Sec PCI Express Dual FC Host Adapter	n/a
SG-XPCIE2FC-QF4 [S]	375-3356 [C]	4Gigabit/Sec PCI Express Dual FC Host Adapter	n/a
n/a	371-4306 [C]	8Gigabit/Sec PCI Express Dual FC Host Adapter	n/a

Memory
Option #	Manufacturing Part #	Description	Previous Part #
SE6X2B11Z [S]	8GB Memory Expansion (2 × 4GB) X-Option
SE6X2B11Z [S]	371-4872 [C]	4GB DDR3-1333/PC3-10600 DIMM	n/a
SE6X2C11Z [S]	16GB Memory Expansion (2 × 8GB) X-Option
SE6X2C11Z [S]	371-4658 [C]	8GB DDR3-1333/PC3-10600 DIMM	n/a
n/a	330-5269	Memory Riser Filler	n/a
n/a	541-3819 [C]	Memory Riser Assembly	541-4418 [C]
	341-5773	Memory Riser Tray	n/a
	511-1241	Memory Riser Board	n/a
n/a	541-4418 [C]	Memory Riser Assembly	n/a
	341-5773	Memory Riser Tray	n/a
	511-1667	Memory Riser Board	n/a

Power
Option #	Manufacturing Part #	Description	Previous Part #
n/a	300-2344 [C]	Type A239C 1030/2060 Watt AC Input Power Supply	n/a
n/a	541-3541 [F]	Power Distribution Board / Power Supply Backplane	n/a
	371-4446	Bus Bar	n/a
	511-1242	Power Distribution Board	n/a
n/a	7022322 [F]	Power Distribution Board / Power Supply Backplane	541-3541 [F]
n/a	371-4446	Bus Bar	n/a
n/a	7048278 [C] [A]	Type A239C 1030/2060 Watt AC Input Power Supply	300-2344 [C]
n/a	7052431 [F] [A]	Power Distribution Board / Power Supply Backplane	7022322 [F]
n/a	371-4446	Bus Bar	n/a
n/a	7060596 [C] [A]	Type A239E 2000 Watt AC Input Power Supply	7048278 [C] [A]

Rack
Option #	Manufacturing Part #	Description	Previous Part #
SE4X5CA1Z [S]	371-4812 [C]	Cable Management Arm	n/a
n/a	371-4791 [C]	Tool-less Slide Rail Rack Mount Kit	n/a

Removable Media
Option #	Manufacturing Part #	Description	Previous Part #
SE4X5DV1Z [S]	541-4272 [C]	Slot-Load DVD Assembly	n/a
	341-5807	Mounting Tray	n/a
	341-6168	Bezel	n/a
	390-0443	8x Slot-Load SATA DVD-Writer/24x CD-Writer	n/a
n/a	7013722 [C]	Slot-Load SATA DVD-Writer/CD-Writer	n/a
	341-5808	Bezel	n/a
	341-6389	Mounting Tray	n/a
	390-0486	8x Slot-Load SATA DVD-Writer/24x CD-Writer	390-0443

SCSI
Option #	Manufacturing Part #	Description	Previous Part #
SGX-SAS6-R-INT-Z ²	7047503 [C]	8-Port 6Gbps SAS-2 RAID PCI Express HBA, B4 ASIC	375-3701 [C]
SGX-SAS6-R-INT-Z ²	7050794 [C]	6Gbps SAS-2 RAID PCI Battery Module, BBU08	371-4982 [C]
SG-XPCIE8SAS-E-Z ⁴ [S]	7050793 [C]	PCI Express 8-Port Host Adapter	375-3487 ³ [C]
SG-XPCIE8SAS-E-Z-N ⁶ [S]	7050793 [C]	PCI Express 8-Port Host Adapter	375-3487 ⁵ [C]
SGX-SAS6-EXT-Z [S]	7047853 [C]	8-Port 6Gbps SAS-2 PCI Express HBA (LSI)	375-3641 [C]
SGX-SAS6-INT-Z [S]	7047852 [C]	8-Port 6Gbps SAS-2 PCI Express HBA (LSI)	375-3640 [C]
SGXPCIE2SCSIU320-N [S]	7050790 [C]	Dual-Channel Ultra320 LVD SCSI PCI Express Adapter	375-3357 [C]
XTA-FAS-S3IE96GB-N [S]	541-3731	96GB PCI Express Flash Accelerator F20 SAS HBA	n/a
	371-4650 [C]	Energy Storage Module (ESM)	n/a
	511-1500 [C]	PCI Express Flash Board	n/a
	7061269 [C]	24GB Solid State Flash Memory Module, FW D21Y	371-4415 [C]
n/a	371-4415 [C]	24GB Solid State Flash Memory Module	n/a
n/a	371-4982 [C]	6Gbps SAS-2 RAID PCI Battery Module, BBU08	n/a
n/a	375-3357 [C]	Dual-Channel Ultra320 LVD SCSI PCI Express Adapter	n/a
n/a	375-3487 ¹ [C]	PCI Express 8-Port Host Adapter	n/a
n/a	375-3640 [C]	8-Port 6Gbps SAS-2 PCI Express HBA (LSI)	n/a
n/a	375-3641 [C]	8-Port 6Gbps SAS-2 PCI Express HBA (LSI)	n/a
n/a	375-3701 [C]	8-Port 6Gbps SAS-2 RAID PCI Express HBA, B4 ASIC	n/a

¹ Supported only for attaching Sun Storage 2530 arrays.
² Can only be used in Slot 0. Uses internal DVD cables. Use of this card will disable the use of an internal DVD drive.
³ Supported only for attaching Sun Storage 2530 arrays.
⁴ Supported only for attaching Sun Storage 2530 arrays.
⁵ Supported only for attaching Sun Storage 2530 arrays.
⁶ Supported only for attaching Sun Storage 2530 arrays.

System Board
Option #	Manufacturing Part #	Description	Previous Part #
n/a	541-4295 [F]	16-Core 1.65GHz System Board Assembly	n/a
	341-6194	Mounting Tray	n/a
	371-2210 [C]	3V Lithium Coin Cell Battery	n/a
	511-1245	Rear I/O Board	n/a
	511-1499	System Board	n/a
	525-2146 [F]	SSCC NVRAM	n/a
	530-3510	Interlock Switch Cable	n/a
	530-4348	System Board to Rear I/O Board Signal Cable	n/a
n/a	7310162 [F]	16-Core 1.65GHz System Board Assembly	n/a
	341-6194	Mounting Tray	n/a
	371-2210 [C]	3V Lithium Coin Cell Battery	n/a
	511-1245	Rear I/O Board	n/a
	7310154	System Board	n/a
	525-2146 [F]	SSCC NVRAM	n/a
	530-3510	Interlock Switch Cable	n/a
	530-4348	System Board to Rear I/O Board Signal Cable	n/a

System Service Processor
Option #	Manufacturing Part #	Description	Previous Part #
n/a	542-0303 [C]	Service Processor Assembly	n/a
	350-1614	Service Processor Cover	n/a
	511-1336	AST2200 Service Processor	n/a

Industry Leading Quality, Support and Integrity

Quality Inspection Checklist
Before it leaves our facility, every used and refurbished item is thoroughly inspected by our certified technicians and undergoes our exclusive Quality Inspection Checklist to ensure 100% satisfaction guarantee.

Greentec Systems is a leading provider
For server, networking and storage equipment. We have an extensive array of inventory of IBM Servers & Storage, Sun Servers & Storage, Cisco Networking (Switches, Routers, Security), and NetApp Storage (disk shelves, disk drives, Filers, NearStore, NetCache). If you don’t see the item or product you require please contact us.

Have this equipment to sell?
Depending on the age and condition of the equipment, there is a very good likelihood that we will be able to offer you cash or trade-in credit for other IT hardware. If the equipment is very old we can also assist you with properly decommissioning that gear in the most environmentally friendly way possible.

Questions?
For more information please contact 888.333.7388, or fill out the quote from above. We’d love to hear from you.
