Oracle Sun Netra X3-2 / X4270 M3 Server

REQUEST A PRICE QUOTE:

Brand:	Oracle / Sun Microsystems
Condition:	Refurbished and new (limited availability)
Availability:	Contact
Shipping Area:	Worldwide to most countries
Shipping Method:	Fedex (most orders), UPS, DHL, Freight Courier
Price:	Please use the quote form above for quick pricing
Payment:	Credit Card, Check, Net Terms (oac), Wire Transfer (required for international orders)
Guarantee:	All items are tested by Oracle trained technicians & backed by a 100% warranty
Questions?	Don’t hesitate to contact us with any questions regarding compatibility or other product info and requests. Our website represents only a fraction of our full inventory. Please reach out with your full requirements

Specs and Information:

Processor
Number	Two Intel 6-core or Two Intel 8-core
Architecture	Type: 6-Core Intel Xeon E5-2620 (15MB Cache, 7.2 GT/s QPI, 2.0 GHz, 95W) 8-Core Intel Xeon E5-2658 (20MB Cache, 8 GT/s QPI, 2.1 GHz, 95W)
Cache memory	32KB instruction and 32KB data L1 cache per core 256KB unified (data and instruction) L2 cache per core 20MB shared inclusive L3 cache per processor
Main Memory
Capacities	DIMM slots per CPU socket: 8 Total DIMM slots (when 2 CPU’s are installed): 16 DIMM type: DDR3-1600 Registered DIMMs DIMM size: 8GB, 16GB Maximum capacity: 256 GB (when configured with 16GB DIMMs)
Standard Integrated Interfaces
Network	Four 100 Mb/s, 1000 Mb/sec, 10000 Mb/sec Ethernet ports
Network Management	One 10/100Base-T Ethernet port
Serial Management	One TIA/EIA-232-F asynchronous RJ45 port
SAS	Four-channel SAS Interface (with SFF-8088 connector), internal access only
USB (2.0)	Front: 2 Rear: 2 Internal: 2
Video	One VGA Video port (HD-15)
Alarms	Four fail-safe DB-15 dry contact (critical, major, minor and user)
Expansion Bus	Six PCIe 3.0 LP slots – six (6) x8-lane slots Note: Slot 1, the lower slot of Riser 1 is reserved for the Sun Storage 6 Gb SAS PCIe RAID HBA, Internal card. This is a configuration requirement.
Internal Mass Storage
Option 1	DVD-R/W, six 300GB or 600GB 2.5in 10K RPM SAS disks.
Option 2	No DVD-R/W, Up to eight 300GB or 600GB 2.5in 10K RPM SAS disks.
DVD-ROM	One 8x SATA DVD-Writer/24x CD-Writer
Power Supplies
Two 660W (1+1) hot-swappable DC or Two 760W hot-swappable AC Note: To ensure redundant operation of the power supplies, the two power inputs should be connected to separate power sources.
DC Power	-48V DC or -60V DC
AC Power	100-240V AC, 50-60 Hz
Environment
Power Consumption	Online power calculator
Temperature	Operating: 5° C to 45° C (41° F to 113° F)/Short term: 5° C to 55° C (23° F to 131° F) Nonoperating: -40° C to 70° C (-40° F to 158° F)
Humidity	Operating: 5% to 85% relative humidity noncondensing, max wet bulb. Short term: 5% to 90% relative humidity noncondensing, but not to exceed 0.024kg water/kg dry air (0.053 lbs. water 2.205 lb. dry air) Nonoperating: up to 93% relative humidity noncondensing, 40° C (104° F) max wet bulb
Altitude	Operating: Meets NEBS 4,000m (13,123 ft.) Nonoperating: up to 12,000m (39,370 ft.)
Acoustic noise	Operating/Idling Acoustic Noise less than 7.2B @ 25° C (LwAd, 1B=10dB)
Regulations Meets or exceeds the following requirements:
Safety	UL 60950-1, EN60950-1, IEC60950-1 (Evaluated to all CB countries), CSA C22.2 No. 60950-1-07, IEC825-1, 2, and CFR21 part 1040
NEBS	NEBS Level 3 certified by Telcordia
EMI	EN55022 Class A, CISPR22 Class A, 47 CFR 15B Class A, ICES-003 Class A, VCCI Class A, AS/NZ CISPR22 Class A, CNS 13438 Class A, EN300386 for Telecommunications Centers and for Other Than Telecommunications Centers
EMC (immunity)	EN55024, EN61000-3-2, EN61000-3-3, EN300386:2010 for Telecommunications Centers and for Other Than Telecommunications Centers.
Regulatory Markings	CE, FCC, ICES-003, C-tick, VCCI, GOST-R, BSMI, KCC, UL/cUL, S-mark, CCC
Seismic	GR-63-CORE requirements for earthquake zone 4
Other	Restriction of Hazardous Substances (RoHS) Directive and Waste Electrical and Electronics Equipment (WEEE) Directive
Dimensions and Weight
Height	87 mm (3.43 in.) 2 RU
Width	445 mm (17.52 in.) including mounting ears
Depth	maximum to PSU handles: 527.8 mm (20.78 in.) maximum of rear I/O: 501.4 mm (19.74 in.)
Weight	Approximate (without PCI cards) 18.5 kg (40.8 lb.)
Rack Mounting
Rack Units	2
Rack Kits Available	19-inch 2-post 19-inch 2-post (slide rail) 23-inch 2-post 600mm x 600mm and 19-inch 4-post slide adjustable¹
¹ The slide kit includes hardware that enables mounting to any of the following types of rack rails: 6 mm threaded holes #10-32 threaded holes #10 threaded holes These must be compliant racks which have mounting depths of 27-30 inches.

CPU Module
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7015351 [F]	2.1GHz Intel 8-Core Xeon E5-2658, 95W	n/a
n/a	7026486 [F]	CPU Heatsink	n/a
n/a	7043859 [F]	2.0GHz Intel 6-Core Xeon E5-2620, 95W	n/a

Cables
Option #	Manufacturing Part #	Description	Previous Part #
7102802	7042258 [F]	Disk Signal Cable – SAS Cable, Two 90° SFF-8087 to Two SFF-8087, Unshielded	n/a
X2130A-1M-N	530-4441 [C]	10Gbps SFP+ TwinX Cable, 1m	n/a
X2130A-3M-N	530-4442 [C]	10Gbps SFP+ TwinX Cable, 3m	n/a
X2130A-5M-N	530-4443 [C]	10Gbps SFP+ TwinX Cable, 5m	n/a
n/a	7042256 [F]	Cable Kit	n/a
	7026751	System Board to PDB Cable	n/a
	7026753	System Board to HDD Backplane Power Cable	n/a
	7026754	System Board to HDD Backplane DVD Cable	n/a
n/a	7076124 [C]	Disk Signal Cable – SAS Cable, Two 90° SFF-8087 to Two SFF-8087, Shielded	7042258 [F]

Disk Backplane
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7016784	6-Slot Disk Backplane Assembly	n/a
	7019790 [F]	6-Slot Disk Backplane	n/a
	7039237 [C]	6-Disk Backplane Air Filter Assembly	n/a
	7017275	6-Disk Backplane Air Filter	n/a
	7017276	6-Disk Backplane Air Filter Frame	n/a
n/a	7016785	8-Slot Disk Backplane Assembly	n/a
	7019791 [F]	8-Slot Disk Backplane	n/a
	7039238 [C]	8-Slot Backplane Air Filter Assembly	n/a
	7017277	8-Disk Backplane Air Filter	n/a
	7017278	8-Disk Backplane Air Filter Frame	n/a
n/a	7053745	6-Slot Disk Backplane Assembly	n/a
	7019790 [F]	6-Slot Disk Backplane	n/a
	7039237 [C]	6-Disk Backplane Air Filter Assembly	n/a
	7017275	6-Disk Backplane Air Filter	n/a
	7017276	6-Disk Backplane Air Filter Frame	n/a
n/a	7053748	8-Slot Disk Backplane Assembly	n/a
	7019791 [F]	8-Slot Disk Backplane	n/a
	7039238 [C]	8-Slot Backplane Air Filter Assembly	n/a
	7017277	8-Disk Backplane Air Filter	n/a
	7017278	8-Disk Backplane Air Filter Frame	n/a

Disks
Option #	Manufacturing Part #	Description	Previous Part #
7107550	7077233 [C]	400GB Solid State SATA Drive Assembly	n/a
	7076379	Intel SSDSC2BA400G3S [ITVSC2BA3SUN400] (400GB – 2.5″ Solid State – SATA-3 Disk)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a
XRA-SS2NF-300G10K2	542-0422 [C]	300GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks:	n/a
	390-0487	Hitachi HUC106030CSS600 [H106030SDSUN300G] (300GB – 10000 RPM – SAS Disk)	n/a
	390-0490	Seagate ST9300605SS [ST930005SSUN300G](300GB 10000 RPM SAS Disk)	n/a
	7045226	Hitachi HUC109030CSS600 [H109030SESUN300G] (300GB – 10000 RPM – SAS Disk)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a
XRA-SS2NF-600G10K2	542-0423 [C]	600GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks:	n/a
	390-0488	Hitachi HUC106060CSS600 [H106060SDSUN600G] (600GB – 10000 RPM – SAS Disk)	n/a
	390-0491	Seagate ST9600205SS [ST960005SSUN600G](600GB 10000 RPM SAS Disk)	n/a
	7045228	Hitachi HUC109060CSS600 [H109060SESUN600G] (600GB – 10000 RPM – SAS Disk)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a

Ethernet
Option #	Manufacturing Part #	Description	Previous Part #
7100477	7070195 [C]	Quad Port GbE PCI Express 2.0 Low Profile Adapter, UTP	7048474 [C]
7100481	7070202 [C]	Dual Port GbE PCI Express 2.0 Low Profile Adapter, MMF	7014747 [C]
7100488	7070006 [C]	Dual 10-Gigabit Base-T PCI Express Gen2	n/a
X1109A-Z	7051223 [C]	Dual 10-Gigabit PCI Express Ethernet SFP+ LP	375-3617 [C]
X2129A-N	530-4449 [C]	10Gb/Sec Short Wave SFP+ Transceiver	n/a
X5562A-Z	135-1205 [C]	10Gb/Sec Long Wave SFP+ Transceiver	n/a
n/a	375-3617 [C]	Dual 10-Gigabit Ethernet SFP+ LP	n/a
n/a	7014747 [C]	Dual Port GbE PCI Express 2.0 Low Profile Adapter, MMF	n/a
n/a	7048474 [C]	Quad Port GbE PCI Express 2.0 Low Profile Adapter, UTP	n/a

Fan
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7014218	Five Fan Assembly	n/a
	7019706 [C]	Single Fan Module	n/a
	n/a	Five Fan Tray	n/a

Fibre Channel
Option #	Manufacturing Part #	Description	Previous Part #
7101674	7023303 [C]	Dual 16Gigabit/Sec Fibre Channel / 10Gbps FCoE Host Adapter, QLogic	n/a
7101676	7023325 [C]	Pair of 16Gbps Short Wave SFP+	n/a
7101676	7023324	16Gb/Sec Short Wave SFP+ Transceiver, QLogic	n/a
7101684	7023036 [C]	Dual 16Gigabit/Sec Fibre Channel / 10Gbps FCoE Host Adapter, Emulex	n/a
7101686	7023059 [C]	Pair of 16Gbps Short Wave SFP+	n/a
7101686	7023053	16Gb/Sec Short Wave SFP+ Transceiver, Emulex	n/a
7101688	7023057 [C]	Pair of 10Gbps Short Wave SFP+	n/a
7101688	7023046	10Gb/Sec Short Wave SFP+ Transceiver, Emulex	n/a
SG-XPCIE2FC-EM8-N	7053434 [C]	8Gigabit/Sec PCI Express Dual FC Host Adapter	371-4306 [C]
SG-XPCIE2FC-QF8-N	371-4325 [C]	8Gigabit/Sec PCI Express Dual FC Host Adapter	n/a
n/a	371-4306 [C]	8Gigabit/Sec PCI Express Dual FC Host Adapter	n/a

I/O
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7017384	Riser-1 Assembly	n/a
	7017385 [C]	2-Slot PCI Express Riser Board	n/a
	7043906	Riser-1 Cage	n/a
n/a	7020312	Riser-2 Assembly	n/a
	7017385 [C]	2-Slot PCI Express Riser Board	n/a
	7043907	Riser-2 Cage	n/a
n/a	7020313	Riser-3 Assembly	n/a
	7017385 [C]	2-Slot PCI Express Riser Board	n/a
	7043908	Riser-3 Cage	n/a

Memory
Option #	Manufacturing Part #	Description	Previous Part #
7100792	7053841 [C]	32GB DDR3-1066/DDR3-1333 DIMM, 1.35V	n/a
7102800	7041588 [C]	16GB Registered DDR3-1600 DIMM, 1.35V	n/a
7102797 [S]	7041566 [C]	8GB Registered DDR3-1600 DIMM, 1.35V	n/a
n/a	7038488 [C]	4GB USB 2.0 Flash Drive	n/a

Miscellaneous
Option #	Manufacturing Part #	Description	Previous Part #
n/a	130-4361	DC Connector	n/a
n/a	230-1708	DC Connector Strain Relief	n/a
n/a	230-1711	DC Connector Opening Lever	n/a

Power
Option #	Manufacturing Part #	Description	Previous Part #
n/a	300-2186 [C]	Type D218 660 Watt DC Input Power Supply	n/a
n/a	300-2299 [C]	Type A247A 760 Watt AC Input Power Supply	n/a
n/a	7014220 [F]	Power Distribution Board	n/a
n/a	7048340 [C]	Type D218 660 Watt DC Input Power Supply	n/a
n/a	7065505 [C]	Type A247B 760 Watt AC Input Power Supply	n/a
n/a	7302524 [C]	Type D218 660 Watt DC Input Power Supply	n/a

Rack
Option #	Manufacturing Part #	Description	Previous Part #
X7901A-4-N	371-1478	19″ 2-post Rackmount Kit	n/a
X8099A-4-N	371-1480	19″ 4-post Slide Mount Kit	n/a
X2089A-N [S]	350-1387	19″ 2-post Slide Rail Kit	n/a
X7902A-4-N [S]	371-1481	23″ 2-post Rackmount Kit	n/a
X7904A-4-N [S]	371-1479	600mm x 600mm Rackmount Kit	n/a

Removable Media
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7014219 [F]	USB Assembly	n/a
	7026762	USB Cable	n/a
	n/a	USB Board	n/a
n/a	7045440 [C]	Slot-Load DVD Assembly	n/a
	390-0486	8x Slot-Load SATA DVD-Writer/24x CD-Writer	n/a
	7039783	DVD Bracket	n/a
	7045772	8x Slot-Load SATA DVD-Writer/24x CD-Writer	n/a
n/a	7080802 [C]	Tray Load DVD Assembly	n/a
	7071296	8x Tray-Load SATA DVD-ROM Writer / 24x CD-ROM Writer	n/a
	7081170	DVD Tray	n/a
	7089963	8x Tray-Load DVD-ROM/24-x CD-ROM Writer (Gen5)	n/a

SCSI
Option #	Manufacturing Part #	Description	Previous Part #
7105387	8-Port 6Gbps SAS-2 PCI Express HBA
7105387	7047853 [C]	8-Port 6Gbps SAS-2 PCI Express HBA (LSI)	375-3641 [C]
SGX-SAS6-R-INT-Z	7047503 [C]	8-Port 6Gbps SAS-2 RAID PCI Express HBA, B4 ASIC	375-3701 [C]
SGX-SAS6-R-INT-Z	7050794 [C]	6Gbps SAS-2 RAID PCI Battery Module, BBU08	371-4982 [C]
SGX-SAS6-EXT-Z [S]	7047853 [C]	8-Port 6Gbps SAS-2 PCI Express HBA (LSI)	375-3641 [C]
SGX-SAS6-INT-Z [S]	7047852 [C]	8-Port 6Gbps SAS-2 PCI Express HBA (LSI)	375-3640 [C]
n/a	371-4982 [C]	6Gbps SAS-2 RAID PCI Battery Module, BBU08	n/a
n/a	375-3640 [C]	8-Port 6Gbps SAS-2 PCI Express HBA (LSI)	n/a
n/a	375-3641 [C]	8-Port 6Gbps SAS-2 PCI Express HBA (LSI)	n/a
n/a	375-3701 [C]	8-Port 6Gbps SAS-2 RAID PCI Express HBA, B4 ASIC	n/a

System Board
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7016786 [F]	System Board Assembly	n/a
	7017372	System Board Tray	n/a
	7017375	System Board	n/a
n/a	7077974 [F]	System Board Assembly	7016786 [F]
	7017375	System Board	n/a
	7077975	System Board Tray	n/a
n/a	7090901 [F]	System Board Assembly	n/a
	7077975	System Board Tray	n/a
	7090903	System Board	n/a
