| Racking |
| Standard telco racks: 19 in. (standard), 23″, 24″, and 600mm (optional) |
| Processor |
| Number | One |
| Architecture | Architecture UltraSPARC IIe V9 Superscalar Processor Platform Version 9:
64-bit single processor, 500 MHz Integrated memory controller PC 100/133 |
| Cache memory | 16 KB data and 16 KB instruction on-chip Secondary: 256 on-chip |
| Main Memory |
| Capacities | 256- and 512-MB PC133 standard Registered DIMMs2 GB maximum |
| Standard Interfaces |
| Ethernet | Two ethernet/fast ethernet (10BASE-T/100BASE-T) shielded twisted-pair (STP) connector (RJ-45) |
| PCI | Single full length PCI slot compliant with PCI specification version 2.1; slot operates at 33-MHz, 32-bits |
| SCSI | One 80-MB/sec, 68-pin, Ultra2 SCSI (SE/LVD) port |
| Serial | Two RS-232C/RS-423 serial ports (RJ45); port A is used as a console and LOM port |
| System Configuration Reader and Card | Front-accessible for transfer of system configuration information, including hostid |
| USB | Two OHCI-compliant Universal Serial Bus (USB) Type A ports |
| Internal Mass Storage |
| Disks | Up to two 3.5×1-in. disks (18 GB); disk bays are front accessible and support hot-plug |
| CD-ROM | Optional 644 MB Slimline CD-ROM drive; 24X speed |
| Environment |
AC input
(Netra T1 AC200) | 90 – 264 VAC, 47 – 63 Hz, 2 A(max) |
DC input
(Netra T1 DC200) | -40 to -75 VDC, 4 A(max) |
| Input power |
Netra T1 AC200: 98 W
Netra T1 DC200: 62 W |
| Heat output | 550 BTU/hr, 335 BTU/hr (nominal) |
| Temperature |
Operating: 5° C to 40° C (41° F to 104° F)
Nonoperating: -40° C to 70° C (-40° F to 158° F) |
| Humidity |
Operating: 5% to 85% relative humidity, noncondensing
Nonoperating: 10% to 95% relative humidity, noncondensing |
| Altitude |
Operating: -300 m to 3000 m (-1000 to 10,000 ft.)
Nonoperating: -300 m to 12,000 m (-1000 to 40,000 ft.) |
| Acoustic noise |
Operating: < 65 dBA |
| Seismic | GR-63-CORE requirements for earthquake risk zone 4
ETSI ETS 300-19-2-3, A1 operating requirements |
| Number of cords | 1 |
Regulations
Meets or exceeds the following requirements: |
| Safety | UL 1950/CSA C22.2 No. 950, EN 60950 (73/23/EEC), IEC 950 |
| Emissions | CFR Title 47 FCC Part 15, EN 55022 (89/336/EEC) |
| Immunity | EN 50082-1 (89/336/EEC) |
| Telco environment | Telcordia: GR-63-CORE, GR-1089-CORE, TR-NWT-000295 (pending) Telcordia: SR 3580 NEBS Level 3 (pending) |
| Certification |
Safety: cULus Mark, TUV GS Mark, CE Mark
EMC: CE Mark (93/68/EEC), FCC authorized Class A |
| Dimensions and Weights |
| Height | 44.00 mm (1.73 in.) (1 RU) |
| Width (without mounting ears) | 437.2 mm (17.21 in.) |
| Depth (with front bezel) | 487.4 mm (19.2 in.) |
| Weight | 9 kg (20 lb.)
11.5 kg (25 lb.) shipping |
