| Racking |
| Fits into 19-in, 23-in., 24-in., and 600mm racks (includes mounting kit for 19-in. racks) |
| Standard Interfaces |
| SCSI | Two single-ended ports, 68-pin SCSI connector
Can be daisy chained via port (2 max in a chain) |
| Internal Mass Storage |
| Disk | Up to three NEBS compliant, 18.2- or 36.4-GB hot pluggable, Ultra SCSI hard drives |
| Environment |
| AC input | 100 – 240 VAC, 47 – 63 Hz, <2.0 A |
| DC input | -48 to -60 VDC, <4.0 A |
| Input power | 150 W |
| Heat Output | 512 BTU/hr |
| Temperature 1 |
Operating: 0° C to 40° C (32° F to 104° F)
Operating (short term): -5° C to 55° C (23° F to 131° F)
Non-operating: -25° C to 65° C (-13° F to 149° F) |
| Humidity 1 |
Operating: 5% to 90% relative humidity, noncondensing
Operating (short term): 5% to 90% relative humidity, noncondensing
Non-operating: 5% to 95% relative humidity, noncondensing |
| Altitude |
Operating: 0 m to 3000 m (0 ft. to 10,000 ft.)
Nonoperating: 0 m to 12,000 m (0 ft. to 40,000 ft.) |
| Acoustic noise |
Operating: 6.0 Bels
Idling: 6.0 Bels |
| Seismic | Meets GR-63-CORE requirements for earthquake risk zone 4 |
| Number of cords | 1 |
1 – Short term is defined as 96 consecutive hours of operating.
If you plan to operate the controller module at altitudes between 1000m and 3000m (3280 ft. and 9850 ft.), you must lower the environmental temperature 3.3° C (1.7° F) for every 1000m (3280 ft.) above sea level. |
Regulations
Meets or exceeds the following requirements: |
| Safety | UL 1950, CSA C22.2-No. 950, EN 60950 (73/23/EEC), IEC 950 |
| Emissions | CFR Title 47 FCC Part 15, EN 55022 (89/336/EEC) |
| Immunity | EMC Directive (89/336/EEC), EN50082-1 |
| Telco environment | Telcordia GR-63-CORE, NEBS GR-1089-CORE, TR-NWT-000295 |
| Certification |
Telcordia: SR 3580 NEBS Level 3 certified
Safety: cULus Mark, TUV GS Mark, CE Mark
EMC: CE Mark (93/68/EEC), FCC authorized Class A |
| Dimensions and Weights |
| Height | 4.4 cm (1.73 in.) |
| Width | 43.6 cm (17.2 in.) |
| Depth | 47.2 cm (18.6 in.) |
| Weight | (without drives) 5.9 kg (13 lb.)
(with 3 drives) 8.16 kg (18 lb.) |
| Shipping Weight | 9.5 kg (20 lb.) |
|
Cables |
|---|
| Option # | Manufacturing
Part # | Description |
|---|
| X1134A | 530-2383 | External SCSI Cable, HD68 to HD68, 0.8M |
| X1139A | 530-2384 | External SCSI Cable, HD68 to HD68, 2M |
| X6917A | 530-2905 | External SCSI Right 90° Cable HD68 to VHDCI68, .5M |
| X959A | 530-2846 | External SCSI Right 90° Cable HD68 to VHDCI68, 2M |
|
Disks |
|---|
| Option # | Manufacturing
Part # | Description |
|---|
| X5239A | 540-4401 | 18.2GB – 10000 RPM, Disk Assembly with 1 bracket, 1 of the following plates, and 1 of the following disks: |
| |
| |
| |
| |
| - Seagate ST318203LC [ST318203LSUN18G]
(18.2GB – 10000 RPM – SCSI Disk)
|
| - Fujitsu MAJ3182MC [MAJ3182M SUN18G]
(18.2GB – 10000 RPM – SCSI Disk)
|
| - IBM DDYS-T18350 [DDYST1835SUN18G]
(18.2GB – 10000 RPM – SCSI Disk)
|
| - Seagate ST318305LC [ST318305LSUN18G]
(18.2GB – 10000 RPM – SCSI Disk)
|
| |
| X5244A | 540-4689 | 36.4GB – 10000 RPM, Disk Assembly with 1 bracket, 1 of the following plates, and 1 of the following disks: |
| |
| |
| |
| |
| - Seagate ST336704LC [ST336704LSUN36G]
(36.4GB – 10000 RPM – SCSI Disk)
|
| - Fujitsu MAJ3364MC [MAJ3364M SUN36G]
(36.4GB – 10000 RPM – SCSI Disk)
|
| - IBM DDYS-T36950 [DDYST3695SUN36G]
(36.4GB – 10000 RPM – SCSI Disk)
|
| - Seagate ST336605LC [ST336605LSUN36G]
(36.4GB – 10000 RPM – SCSI Disk)
|
| - Seagate ST336607LC [ST336607LSUN36G]
(36.4GB – 10000 RPM – SCSI Disk)
|
| - Fujitsu MAP3367NC [MAP3367N SUN36G]
(36.4GB – 10000 RPM – SCSI Disk)
|
| |
|
Miscellaneous |
|---|
| Option # | Manufacturing
Part # | Description |
|---|
| X6918A | 540-4377 | Replacement Front Bezel |
| |
| |
| |
| |
| X949A | 595-5302 | Wago DC Connector Set, RoHS:Y |
| |
| - DC Connector Strain Relief
|
| - DC Connector Opening Lever
|
| n/a | 370-3911 | Fan Assembly |
|
Power |
|---|
| Option # | Manufacturing
Part # | Description |
|---|
| n/a | 300-1432 | 130W AC Input Power Supply (pre-release) |
| n/a | 300-1447 | 130W DC Input Power Supply |
| n/a | 300-1448 | 130W AC Input Power Supply |
|
Rack |
|---|
| Option # | Manufacturing
Part # | Description |
|---|
| X6919A | 595-6231 | 19-inch Rack Mount Kit |
| X6920A | 595-6231 | 19-inch Rack Mount Kit |
| X6966A | 595-5322 | 23-inch Rack Mount Kit |
| X6967A | 595-5323 | 24-inch Rack Mount Kit |
| X6968A | 595-5324 | 600 mm Rack Mount Kit |
|
SCSI |
|---|
| Option # | Manufacturing
Part # | Description |
|---|
| X1032A | 501-5656 | Single-Ended Ultra/Wide SCSI/FastEthernet (SunSwift PCI) |
| X6540A | 375-0005 | Dual Single-Ended Ultra/Wide SCSI (PCI) |
|
System Board |
|---|
| Option # | Manufacturing
Part # | Description |
|---|
| n/a | 501-5450 | Netra st D130 Motherboard |
|
Whole System FRU |
|---|
| Option # | Manufacturing
Part # | Description |
|---|
| n/a | 540-4175 | Netra st D130 – DC Power without Disk |
| n/a | 540-4176 | Netra st D130 – AC Power without Disk |
