Oracle Sun Netra 20 SERVER

REQUEST A PRICE QUOTE:

Racking
Rack mountable in 19-inch, 23-inch, 24-inch, and 600-mm racks. They are also rack-enabled for 2- and 4-post rack mounts.
Processor
Number	One or two
Architecture	UltraSPARC III at 750 MHz UltraSPARC III Cu at 900 MHz UltraSPARC III Cu at 1200 MHz
Cache memory	8 MB integrated second-level
Main Memory
Capacities	8 slots populated in two banks of four 128, 256, 512, or 1024 MB DIMMs
Standard Interfaces
Alarm	One alarm port (DB15)
Ethernet	One ethernet/fast ethernet (10BASE-T/100BASE-T) twisted-pair port (RJ-45)
FC-AL	One Fibre Channel Arbitrated Loop (FC-AL) high-speed serial data connector (HSSDC)
Parallel	One IEEE 1284-compliant parallel port (DB25)
PCI	Four internal PCI 2.1 compliant slots: One full-size PCI slot, 32- or 64-bit, 33- or 66-MHz, 3.3 VDC Two full-size PCI slots, 32- or 64-bit, 33-MHz, 5.0 VDC One short-size PCI slot (slot 3), 32- or 64-bit, 33-MHz, 5.0 VDC
SCSI	One 40-MB/sec, 68-pin, UltraSCSI (SCSI-3) port
Serial	Two RS-232/RS-423 asynchronous/synchronous serial ports (DB25) One RS-232/RS-423 asynchronous LOM/console port (RJ-45)
System Configuration Reader and Card	Rear-accessible for transfer of system configuration information, including hostid
USB	Four Universal Serial Bus (USB) Type A ports
Internal Mass Storage
Disks	Up to two 3.5-inches by 1-inch fibre channel 36 GB Up to two 3.5-inches by 1-inch fibre channel 73 GB
DVD-ROM	10X DVD-ROM Drive
Tape	20-40GB 4 mm DDS-4 DAT Tape Drive
Environment
AC input (AC200)	90 – 264 VAC, 47 – 63 Hz, 7.2 A (max @ 100 VAC)
DC input (DC200)	-48 to -60 VDC (dual isolated inputs) 12 A (max @ -48 VDC), 10 A (max @ -60 VDC)
Heat output	2250 BTU
Temperature	Operating: 5° C to 40° C (41° F to 104° F) Nonoperating: -40° C to 70° C (-40° F to 158° F)
Humidity	Operating: 20% to 80% relative humidity, noncondensing Nonoperating: 10% to 95% relative humidity, noncondensing
Altitude	Operating: 3000 m (10,000 ft.) Nonoperating: 12,000 m ( 40,000 ft.)
Acoustic noise	Operating: <60dBA Idling: <60dBA
Seismic	GR-63-CORE requirements for earthquake risk Zone 4
Number of cords	1
Regulations Meets or exceeds the following requirements:
Safety	UL 1950/CAS C22.2 No. 950, EN 60950 (73/23/EEC), IEC 950, CCIB for PSU, GOSTMark
Emissions	CFR Title 47 FCC Part 15, EN 55022 (89/336/EEC)
Immunity	EN 50082-1 (89/336/EEC)
Telco environment (DC Version)	Telcordia: GR-63-CORE, GR-1089-CORE, TR-NWT-00295, SR 3580 NEBS Level 3
Certification	Safety: cULus Mark, T?V GS Mark, CE Mark EMC: CE Mark, (93/68/EEC), FCC authorized Class A, VCCI, BSMI, CTICK
Dimensions and Weights
Height	6.97 inches (177 mm)
Width (without mounting ears)	17.13 inches (435 mm)
Depth (with front bezel)	19.53 inches (496 mm)
Weight	60 lb (27.30 kg)
Shipping Weight (product and packing)	62 lb (28 kg)

Batteries
Option #	Manufacturing Part #	Description
n/a	150-2850	3V Lithium Battery BR1632 / CR1632, RoHS:Y

Boot PROM
Socket	Manufacturing Part #	Patch
U2103	525-1807	111292
U2103	525-1899	111292

CPU Module
Option #	Manufacturing Part #	Description
X6988A	501-6248	750MHz UltraSPARC III Module (DC Model)
X6990A	501-5675	750MHz UltraSPARC III Module (AC Model)
X7009A	501-6747	900MHz UltraSPARC III Cu Module (501-6002 screened for processor flatness)
X7310A	501-6750	1200MHz UltraSPARC III Cu Module (501-6690 screened for processor flatness)
n/a	501-6002	900MHz UltraSPARC III Cu Module
n/a	501-6485	1200MHz UltraSPARC III Cu Module
n/a	501-6690	1200MHz UltraSPARC III Cu Module
n/a	501-6745	1200MHz UltraSPARC III Cu Module (501-6485 screened for processor flatness)
n/a	501-6805	1200MHz UltraSPARC III Cu Module

Cables
Option #	Manufacturing Part #	Description
n/a	530-3032	Power Cable
n/a	560-2631	Power Cable Kit
	530-3026	Removable Media Power Cable
	530-3027	System Board to PDB Switch Cable
	530-3028	System Board to PDB Sense Cable
	530-3029	FC-AL Backplane to PDB Power Cable
	530-3030	FC-AL Backplane to PDB I²C Cable
n/a	560-2632	Data Cable Kit
	530-3031	SCCR to System Board to PDB Cable
	530-3033	Alarm Module to PDB to LED Board Cable
	530-3065	Removable Media SCSI Cable with 50-Pin to 68-Pin Adapter

Card/Reader
Option #	Manufacturing Part #	Description
n/a	370-4435	System Configuration Card
n/a	370-5155	System Configuration Card, RoHS:Y
n/a	501-5965	System Configuration Card Reader

Communication
Option #	Manufacturing Part #	Description
X1133A	375-0130	Crypto Accelerator I
X1155A	370-2728	High Speed Serial Interface PCI (HSI/P) 2.0
X1157A	501-3028	SunATM-155/MFiber PCI 4.0
X1158A	501-3027	SunATM-155/UTP PCI 4.0
X2156A	375-0100	Serial Asynchronous Interface PCI (SAI/P) 3.0
X4011A	501-6039	Crypto Accelerator 4000 UTP (copper)
X4012A	501-6040	Crypto Accelerator 4000 MMF (fiber)
X4111A	501-6039	Crypto Accelerator 4000 UTP (copper)
X4112A	501-6040	Crypto Accelerator 4000 MMF (fiber)
X6762A	375-3089	Crypto Accelerator 1000
X7087A	501-6543	Alarm/LOMlite2 Module (1200MHz)
n/a	501-5893	Alarm/LOMlite2 Module (750MHz/900MHz)

Disks
Option #	Manufacturing Part #	Description
X6724A	540-4525	36.4GB – 10000 RPM FC-AL, Disk Assembly with 1 bracket, 1 of the following plates, and 1 of the following disks:
	340-6640	Plate
	340-7269	Plate, RoHS:Y
	390-0035	Seagate ST336704FC [ST336704FSUN36G] (36.4GB – 10000 RPM – FC-AL Disk)
	390-0070	Seagate ST336605FC [ST336605FSUN36G] (36.4GB – 10000 RPM – FC-AL Disk)
	390-0137	Seagate ST336607FC [ST336607FSUN36G] (36.4GB – 10000 RPM – FC-AL Disk)
	540-3024	1″ SPUD Bracket, RoHS:Y
X6805A	540-6604	73.4GB – 10000 RPM, Disk Assembly with 1 bracket, 1 of the following plates, and 1 of the following disks, RoHS:Y
	341-1986	Plate, RoHS:Y
	390-0256	Fujitsu MAW3073FC [MAW3073FCSUN73G] (73.4GB – 10000 RPM – FC-AL Disk), RoHS:Y
	390-0269	Hitachi HUS1073FA [HUS1073FASUN72G] (73.4GB – 10000 RPM – FC-AL Disk), RoHS:Y
	390-0279	Seagate ST373207FC [ST373207FSUN72G] (73.4GB – 10000 RPM – FC-AL Disk), RoHS:Y
	540-3024	1″ SPUD Bracket, RoHS:Y
X6819A	540-5698	36.4GB – 10000 RPM FC-AL, Disk Assembly (NEBS) with 1 bracket, 1 of the following plates, and 1 of the following disks:
	340-6640	Plate
	340-7269	Plate, RoHS:Y
	390-0035	Seagate ST336704FC [ST336704FSUN36G] (36.4GB – 10000 RPM – FC-AL Disk)
	390-0070	Seagate ST336605FC [ST336605FSUN36G] (36.4GB – 10000 RPM – FC-AL Disk)
	390-0137	Seagate ST336607FC [ST336607FSUN36G] (36.4GB – 10000 RPM – FC-AL Disk)
	390-0146	Hitachi DK32EJ-36FC [DK32EJ72FSUN72G] (36.4GB 10000 RPM – FC-AL Disk)
	540-3024	1″ SPUD Bracket, RoHS:Y
X6855A	540-5694	73.4GB – 10000 RPM FC-AL, Disk Assembly (NEBS) with 1 bracket, 1 of the following plates, and 1 of the following disks:
	340-6640	Plate
	340-7269	Plate, RoHS:Y
	390-0071	Seagate ST373405FC [ST373405FSUN72G] (73.4GB – 10000 RPM – FC-AL Disk)
	390-0121	Seagate ST373307FC [ST373307FSUN72G] (73.4GB – 10000 RPM – FC-AL Disk)
	390-0122	Fujitsu MAP3735FC [MAP3735F SUN72G] (73.4GB – 10000 RPM – FC-AL Disk)
	390-0123	Hitachi DK32EJ-72FC [DK32EJ72FSUN72G] (73.4GB – 10000 RPM – FC-AL Disk)
	540-3024	1″ SPUD Bracket, RoHS:Y
n/a	540-5408	73.4GB – 10000 RPM FC-AL, Disk Assembly with 1 bracket, 1 of the following plates, and 1 of the following disks:
	340-6640	Plate
	340-7269	Plate, RoHS:Y
	390-0071	Seagate ST373405FC [ST373405FSUN72G] (73.4GB – 10000 RPM – FC-AL Disk)
	390-0098	Fujitsu MAN3735FC [MAN3735F SUN72G] (73.4GB – 10000 RPM – FC-AL Disk)
	390-0121	Seagate ST373307FC [ST373307FSUN72G] (73.4GB – 10000 RPM – FC-AL Disk)
	390-0122	Fujitsu MAP3735FC [MAP3735F SUN72G] (73.4GB – 10000 RPM – FC-AL Disk)
	390-0123	Hitachi DK32EJ-72FC [DK32EJ72FSUN72G] (73.4GB – 10000 RPM – FC-AL Disk)
	390-0165	Seagate ST373207FC [ST373207FSUN72G] (73.4GB – 10000 RPM – FC-AL Disk)
	390-0166	Fujitsu MAT3073FC [MAT3073F SUN72G] (73.4GB – 10000 RPM – FC-AL Disk)
	390-0167	Hitachi HUS1073FA [HUS1073FASUN72G] (73.4GB – 10000 RPM – FC-AL Disk)
	540-3024	1″ SPUD Bracket, RoHS:Y

Ethernet
Option #	Manufacturing Part #	Description
X4445A	501-6738	Quad GigaSwift PCI-X Ethernet (QGE-X), RoHS:Y
X1033A	501-5019	Sun FastEthernet PCI Adapter (FE/P) 2.0
X1034A	501-5406	Quad FastEthernet PCI (QFE/P)
X1141A	501-4373	Gigabit Ethernet PCI (GBE/P) 2.0
X1150A	501-5902	Sun GigaSwift Ethernet UTP (Copper)
X1151A	501-5524	Sun GigaSwift Ethernet MMF (Fiber)
X3150A	501-5902	Sun GigaSwift Ethernet UTP (Copper)
X3151A	501-5524	Sun GigaSwift Ethernet MMF (Fiber)
X4150A	501-6719	GigaSwift Ethernet UTP (GCS)
X4151A	501-6762	GigaSwift Ethernet MMF (GFS)
X4444A	501-6522	Quad GigaSwift Ethernet UTP (QGE)

Fibre Channel
Option #	Manufacturing Part #	Description
SG-XPCI1FC-QF4	375-3354	4Gb PCI-X Single FC Host Adapter, RoHS:Y
SG-XPCI2FC-QF4	375-3294	4Gb PCI-X Dual FC Host Adapter, RoHS:Y
SG-XPCI1FC-EM2	375-3304	2Gb PCI-X Single FC Host Adapter, RoHS:Y
SG-XPCI1FC-QL2	375-3383	2Gb PCI-X Single FC Host Adapter, RoHS:Y
SG-XPCI2FC-EM2	375-3305	2Gb PCI-X Dual FC Host Adapter, RoHS:Y
SG-XPCI2FC-QF2-Z	375-3363	2Gb PCI Dual FC Host Adapter, RoHS:Y
SG-XPCI2FC-QF2-Z	240-4839	Low Profile Bracket, RoHS:Y
X6727A	375-3030	PCI Dual FC Host Adapter+, RoHS:YL
X6799A	375-3019	PCI Single FC Host Adapter
n/a	540-4794	2-Slot FC-AL Disk Backplane

Graphics
Option #	Manufacturing Part #	Description
X3685A	375-3069	XVR-500 Graphics Accelerator
X3780A	375-3153	XVR-600 Graphics Accelerator

Memory
Option #	Manufacturing Part #	Description
X7056A	4 GB (4 × 1GB SDRAM DIMMs)
X7056A	501-7386	1GB SDRAM DIMM, RoHS:YL
X7050A	512MB (4 × 128MB SDRAM DIMMs)
X7050A	501-4489	128MB SDRAM DIMM
X7051A	2 GB (4 × 512MB SDRAM DIMMs)
X7051A	501-7385	512MB SDRAM DIMM, RoHS:YL
X7052A	4 GB (4 × 1GB SDRAM DIMMs)
X7052A	501-5031	1GB SDRAM DIMM
X7053A	1 GB (4 × 256MB SDRAM DIMMs)
X7053A	501-5401	256MB SDRAM DIMM
X7061A	1 GB (4 × 256MB SDRAM DIMMs)
X7061A	501-6175	256MB SDRAM DIMM CR1/LC1
X7062A	2 GB (4 × 512MB SDRAM DIMMs)
X7062A	501-6174	512MB SDRAM DIMM CR1/LC1
n/a	501-5030	512MB SDRAM DIMM
n/a	501-6109	1GB SDRAM DIMM
n/a	540-5086	1GB SDRAM DIMM
F511-1030	Package of 25 × 512MB SDRAM DIMMs
501-7385	512MB SDRAM DIMM, RoHS:YL
F511-1031	Package of 25 × 1GB SDRAM DIMMs
501-7386	1GB SDRAM DIMM, RoHS:YL

Miscellaneous
Option #	Manufacturing Part #	Description
X949A	595-5302	Wago DC Connector Set, RoHS:Y
	130-4361	DC Connector, RoHS:Y
	230-1708	DC Connector Strain Relief
	230-1711	DC Connector Opening Lever

Power
Option #	Manufacturing Part #	Description
n/a	300-1496	AC Input Power Supply Type A161
n/a	300-1497	DC Input Power Supply Type D139
n/a	540-4795	Power Distribution Assembly
n/a	370-4317	Power Distribution Board

Rack
Option #	Manufacturing Part #	Description
X6845A	595-6721	Netra 20 Rack Mount Kit for Sun Rack 900
X6902A	595-4630	23″ Rack Mount Kit
X6903A	595-4631	24″ Rack Mount Kit
X6904A	595-4632	600 mm Rack Mount Kit
X7099A	595-5832	19″ Slide Adapter Kit

Removable Media
Option #	Manufacturing Part #	Description
X6168A	390-0025	10X DVD-ROM Drive
X6295A	390-0028	20-40GB 4 mm DDS-4 Tape Drive (Medium Grey Bezel)

SCSI
Option #	Manufacturing Part #	Description
SGXPCI2SCSILM320-Z	375-3365	PCI Dual Ultra320 SCSI Adapter, RoHS:YL
SG-XPCI2SCSI-LM320	375-3191	PCI/PCI-X Dual Ultra320 SCSI Adapter
X1032A	501-5656	Single-Ended Ultra/Wide SCSI/FastEthernet (SunSwift PCI)
X2222A	501-5727	Dual FastEthernet / Dual SCSI PCI Adapter
X4422A	501-6635	Dual GigabitEthernet / Dual SCSI PCI Adapter
X6540A	375-0005	Dual Single-Ended Ultra/Wide SCSI (PCI)
X6541A	375-0006	Dual Differential Ultra/Wide SCSI (UDWIS/P)(HVD)
X6542A	375-0078	SCSI RAID Controller (SRC/P)
X6758A	375-3057	PCI Dual Ultra3 SCSI Host Adapter (LVD)

Switch/Hub
Option #	Manufacturing Part #	Description
X6746A	Redundant FC 8-port Switch Option (two 8-port switches)
X6746A	540-4372	StorEdge Network FC Switch-8

System Board
Option #	Manufacturing Part #	Description
n/a	501-5938	0MB FRU (SCHIZO 2.2)
n/a	501-6230	0MB FRU (SCHIZO >=2.2)
n/a	501-6560	0MB FRU (SCHIZO 2.5)
