Used Oracle Sun Netra 120 SERVER

Oracle Sun Netra 120 SERVER

REQUEST A PRICE QUOTE:

Processor
Number	One
Architecture	Sun Fire V120: UltraSPARC[tm] IIi superscalar processor: 64-bit single processor, 550- or 650- MHz Netra 120: UltraSPARC” IIi superscalar processor: 64-bit single processor, 650- MHz
Cache memory	16-KB data and 16-KB instruction on chipSecondary: 512-KB internal
Main Memory
Capacities	Four 256-MB, 512-MB, or 1-GB PC133 DIMMs4-GB memory max per system
Standard Interfaces
Ethernet	Two ethernet/fast ethernet (10BASE-T/100BASE-T) shielded twisted-pair (STP) connector (RJ-45)
PCI	Single full length PCI slot compliant with PCI specification version 2.1; slot operates at 33-MHz, 32 bits
SCSI	One 40-MB/sec, 68-pin, UltraSCSI (SCSI-3) synchronous port
Serial	Two RS-232C/RS-423 serial ports (RJ45); port A is used for LOM
System Configuration Reader and Card	Front-accessible for transfer of system configuration information, including hostid
USB	Two OHCI-compliant Universal Serial Bus (USB) Type A ports
Internal Mass Storage
Disks	Up to two 3.5-in. × 1-in.disks (18GB, 36GB, or 73GB SCSI), front accessible, support for hot plug
CD-ROM/DVD-ROM	Optional 644-MB SuperSlim CD-ROM, 24X speedOptional slimline,8X speed for DVD-ROM and 40X speed for CD-ROM
Environment
AC input (Sun Fire V120)	90 – 264 VAC, 47 – 63 Hz, 2 A(max)
DC input (Netra 120)	-40 to -75 VDC, 4 A(max)
Input power	Sun Fire V120: 98 W (nominal) Netra 120: 58 W (nominal)
Heat output	Sun Fire V120: Maximum 550 BTU/hr, Nominal 335 BTU/hr Netra 120: Nominal 198 BTU/hr
Temperature	Operating: 5° C to 40° C (41° F to 104° F) Nonoperating: -40° C to 70° C (-40° F to 158° F)
Humidity	Operating: 5% to 85% relative humidity, noncondensing Nonoperating: 10% to 95% relative humidity, noncondensing
Altitude	Operating: -300 m to 3000 m (-1000 to 10,000 ft.) Nonoperating: -300 m to 12,000 m (-1000 to 40,000 ft.)
Acoustic noise	Operating: < 65 dBA
Number of cords	1
Regulations Meets or exceeds the following requirements:
Safety	UL 1950/CSA C22.2 No.950, EN 60950 (73/23/EEC), IEC 950,CCIB for PSU, GOSTMark, GR-1089-CORE
Emissions	CFR Title 47 FCC Part 15, EN 55022 (89/336/EEC), GR-1089-CORE
Immunity	EN55024 (89/336/EEC), EN50082-1, GR-1089-CORE
Certification	Safety: cULus Mark, TUV GS Mark, CE Mark EMC: CE Mark (93/68/EEC), FCC authorized Class A, VCCI, BSMI,CTICK
Seismic	GR-63-CORE requirements for earthquake risk zone 4 ETSI ETS 300-19-2-3, A1 operating requirements
Dimensions and Weights
Height	4.4 cm (1.73 in.) (1 RU)
Width	43.7 cm (17.21 in.)
Depth	47.8 (18.8 in.)
Weight	10 kg (22 lb.)

Boot PROM
Socket	Manufacturing Part #	Patch
U27	258-7887	111991

Card/Reader
Option #	Manufacturing Part #	Description
n/a	370-4285	System Configuration Card
n/a	370-4290 Buy	LED/System Configuration Card Reader

Communication
Option #	Manufacturing Part #	Description
X1133A	375-0130	Crypto Accelerator I
X1155A	370-2728	High Speed Serial Interface PCI (HSI/P) 2.0
X1157A	501-3028	SunATM-155/MFiber PCI 4.0
X1158A	501-3027	SunATM-155/UTP PCI 4.0
X2156A	375-0100	Serial Asynchronous Interface PCI (SAI/P) 3.0
X4011A	501-6039	Crypto Accelerator 4000 UTP (copper)
X4012A	501-6040 Buy	Crypto Accelerator 4000 MMF (fiber)
X4111A	501-6039	Crypto Accelerator 4000 UTP (copper)
X4112A	501-6040 Buy	Crypto Accelerator 4000 MMF (fiber)
X6762A	375-3089	Crypto Accelerator 1000

Disks
Option #	Manufacturing Part #	Description
X5239A	540-4401	18.2GB – 10000 RPM, Disk Assembly with 1 bracket, 1 of the following plates, and 1 of the following disks:
	340-4288	Plate
	340-5928	Plate
	340-6640	Plate
	340-7269	Plate, RoHS:Y
	390-0002	Seagate ST318203LC [ST318203LSUN18G] (18.2GB – 10000 RPM – SCSI Disk)
	390-0043	Fujitsu MAJ3182MC [MAJ3182M SUN18G] (18.2GB – 10000 RPM – SCSI Disk)
	390-0048	IBM DDYS-T18350 [DDYST1835SUN18G] (18.2GB – 10000 RPM – SCSI Disk)
	390-0085	Seagate ST318305LC [ST318305LSUN18G] (18.2GB – 10000 RPM – SCSI Disk)
	540-3024	1″ SPUD Bracket, RoHS:Y
X5244A	540-4689	36.4GB – 10000 RPM, Disk Assembly with 1 bracket, 1 of the following plates, and 1 of the following disks:
	340-4288	Plate
	340-5928	Plate
	340-6640	Plate
	340-7269	Plate, RoHS:Y
	390-0050	Seagate ST336704LC [ST336704LSUN36G] (36.4GB – 10000 RPM – SCSI Disk)
	390-0051	Fujitsu MAJ3364MC [MAJ3364M SUN36G] (36.4GB – 10000 RPM – SCSI Disk)
	390-0052	IBM DDYS-T36950 [DDYST3695SUN36G] (36.4GB – 10000 RPM – SCSI Disk)
	390-0069	Seagate ST336605LC [ST336605LSUN36G] (36.4GB – 10000 RPM – SCSI Disk)
	390-0109 Buy	Seagate ST336607LC [ST336607LSUN36G] (36.4GB – 10000 RPM – SCSI Disk)
	390-0156	Fujitsu MAP3367NC [MAP3367N SUN36G] (36.4GB – 10000 RPM – SCSI Disk)
	540-3024	1″ SPUD Bracket, RoHS:Y
X5245A	540-5771	73.4GB – 10000 RPM, Disk Assembly with 1 bracket, 1 of the following plates and 1 of the following disks:
	340-5928	Plate
	340-7269	Plate, RoHS:Y
	390-0106	Seagate ST373307LC [ST373307LSUN72G] (73.4GB – 10000 RPM – SCSI Disk)
	390-0157	Fujitsu MAP3735NC [MAP3735N SUN72G] (73.4GB – 10000 RPM – SCSI Disk)
	390-0174	Seagate ST373207LC [ST373207LSUN72G] (73.4GB – 10000 RPM – SCSI Disk)
	390-0175	Fujitsu MAT3073NC [MAT3073N SUN72G] (73.4GB – 10000 RPM – SCSI Disk)
	390-0176	Hitachi HUS103073FL3800 [HUS10733ASUN72G] (73.4GB – 10000 RPM – SCSI Disk)
	390-0252	Fujitsu MAW3073NC [MAW3073NCSUN73G] (73.4GB – 10000 RPM – SCSI Disk), RoHS:Y
	390-0265	Hitachi HUS103073FL3800 [HUS10733ASUN72] (73.4GB – 10000 RPM – SCSI Disk), RoHS:Y
	390-0275	Seagate ST373207LC [ST373207LSUN72G] (73.4GB – 10000 RPM – SCSI Disk), RoHS:Y
	540-3024	1″ SPUD Bracket, RoHS:Y
n/a	540-4520 Buy	36.4GB – 10000 RPM, Disk Assembly with 1 bracket, 1 of the following plates, and 1 of the following disks:
	340-4288	Plate
	340-5928	Plate
	340-6640	Plate
	340-7269	Plate, RoHS:Y
	390-0050	Seagate ST336704LC [ST336704LSUN36G] (36.4GB – 10000 RPM – SCSI Disk)
	390-0051	Fujitsu MAJ3364MC [MAJ3364M SUN36G] (36.4GB – 10000 RPM – SCSI Disk)
	390-0052	IBM DDYS-T36950 [DDYST3695SUN36G] (36.4GB – 10000 RPM – SCSI Disk)
	390-0065	Fujitsu MAN3367MC [MAN3367M SUN36G] (36.4GB – 10000 RPM – SCSI Disk)
	390-0069	Seagate ST336605LC [ST336605LSUN36G] (36.4GB – 10000 RPM – SCSI Disk)
	390-0109 Buy	Seagate ST336607LC [ST336607LSUN36G] (36.4GB – 10000 RPM – SCSI Disk)
	390-0110	Fujitsu MAP3367NC [MAP3367N SUN36G] (36.4GB – 10000 RPM – SCSI Disk)
	390-0111	Hitachi DK32EJ-36NC [DK32EJ36NFSUN36G] (36.4GB – 10000 RPM – SCSI Disk)
	540-3024	1″ SPUD Bracket, RoHS:Y

Ethernet
Option #	Manufacturing Part #	Description
X4445A Buy	501-6738	Quad GigaSwift PCI-X Ethernet (QGE-X), RoHS:Y
X1033A	501-5019	Sun FastEthernet PCI Adapter (FE/P) 2.0
X1034A	501-5406	Quad FastEthernet PCI (QFE/P)
X1141A	501-4373	Gigabit Ethernet PCI (GBE/P) 2.0
X1150A	501-5902 Buy	Sun GigaSwift Ethernet UTP (Copper)
X1151A	501-5524 Buy	Sun GigaSwift Ethernet MMF (Fiber)
X2069A	501-5426	Gigabit Ethernet FC-AL/P
X3150A	501-5902 Buy	Sun GigaSwift Ethernet UTP (Copper)
X3151A	501-5524 Buy	Sun GigaSwift Ethernet MMF (Fiber)
X4150A	501-6719	GigaSwift Ethernet UTP (GCS)
X4151A	501-6762	GigaSwift Ethernet MMF (GFS)
X4444A	501-6522	Quad GigaSwift Ethernet UTP (QGE)

Fibre Channel
Option #	Manufacturing Part #	Description
SG-XPCI1FC-JF2	375-3156	JNI 2Gb PCI Single FC Host Adapter
SG-XPCI1FC-QF2	375-3102	2Gb PCI Single FC Host Adapter
SG-XPCI1FC-QL2	375-3383	2Gb PCI-X Single FC Host Adapter, RoHS:Y
SG-XPCI2FC-JF2	375-3157	JNI 2Gb PCI Dual FC Host Adapter
SG-XPCI2FC-QF2	375-3108	2Gb PCI Dual FC Host Adapter
SG-XPCI2FC-QF2	240-4839	Low Profile Bracket, RoHS:Y
X6727A	375-3030	PCI Dual FC Host Adapter+, RoHS:YL
X6729A	375-0040	Single Loop PCI FC-AL Host Adapter (FC100/P)
X6799A	375-3019 Buy	PCI Single FC Host Adapter

Graphics
Option #	Manufacturing Part #	Description
X3768A	370-4362	PGX64 8/24-Bit Color Frame Buffer

IDPROM
Socket	Manufacturing Part #	Component Type	Host ID
U25	100-6889	48T59 NVRAM	Unprogrammed

Memory
Option #	Manufacturing Part #	Description
X7091A	370-4237	256 MB SDRAM DIMM
X7092A	370-4281	512MB SDRAM DIMM
X7093A	370-4874	1 GB SDRAM DIMM

Miscellaneous
Option #	Manufacturing Part #	Description
X949A	595-5302	Wago DC Connector Set, RoHS:Y
	130-4361	DC Connector, RoHS:Y
	230-1708	DC Connector Strain Relief
	230-1711	DC Connector Opening Lever

Power
Option #	Manufacturing Part #	Description
n/a	300-1489 Buy	Delta DC Input Power Supply Type D137

Rack
Option #	Manufacturing Part #	Description
X6967A	595-5323	24-inch Rack Mount Kit
X7085A	595-5802	19-inch Rack Mount Kit

Removable Media
Option #	Manufacturing Part #	Description
X7088A	370-4278 Buy	24X Slimline CD-ROM Drive
X7288A	540-5014 Buy	Internal Slimline 8X DVD-ROM
n/a	371-0980 Buy	24X Slimline CD-ROM Drive, RoHS:Y

SCSI
Option #	Manufacturing Part #	Description
SGXPCI2SCSILM320-Z Buy	375-3365	PCI Dual Ultra320 SCSI Adapter, RoHS:YL
SG-XPCI2SCSI-LM320	375-3191	PCI/PCI-X Dual Ultra320 SCSI Adapter
X1032A	501-5656	Single-Ended Ultra/Wide SCSI/FastEthernet (SunSwift PCI)
X2222A	501-5727	Dual FastEthernet / Dual SCSI PCI Adapter
X4422A	501-6635	Dual GigabitEthernet / Dual SCSI PCI Adapter
X6540A	375-0005	Dual Single-Ended Ultra/Wide SCSI (PCI)
X6541A	375-0006 Buy	Dual Differential Ultra/Wide SCSI (UDWIS/P)(HVD)
X6758A	375-3057 Buy	PCI Dual Ultra3 SCSI Host Adapter (LVD)

System Board
Option #	Manufacturing Part #	Description
n/a	375-3065	650MHz UltraSPARC IIi
n/a	375-3199 Buy	650 MHz UltraSPARC IIi
