Used Oracle Sun BLADE X8440 SERVER MODULE

Oracle Sun BLADE X8440 SERVER MODULE

REQUEST A PRICE QUOTE:

Capacity

Number

4 Opteron processors
128 GB memory
Two hot-plug / hot swap SAS or SATA hard disks

Processor

Number

4 CPUs per Blade

Architecture

Dual-core and Quad-core AMD Opteron 800 Series

2.3 GHz Quad-core 8356, 75W
2.2 GHz Quad-core 8354, 75W
1.9 GHz Quad-core 8347 HE, 55W
3.0 GHz Dual-core 8222, 95W

Cache Memory

1 MB L2 Cache

Memory

DIMM Specifications

1GB DDR2-667MHz/PC5300 ECC Registered 1-Rank/512 Mbit SDRAM.
2GB DDR2-667MHz/PC5300 ECC Registered 2-Rank/512 Mbit SDRAM.
4GB DDR2-667MHz/PC5300 ECC Registered 1-Rank/1 Gbit SDRAM.
2GB DDR2-667MHz/PC5300 ECC Registered 2-Rank/1 Gbit SDRAM.

Capacities per X8440 Server Module

8 DIMM slots per processor, for a maximum total of 32 slots. DIMMs are configured in 2 DIMM pairs.
Memory DIMMs must be installed in identical pairs (from the same manufacturer and in the same capacity) for 128-bit ECC and maximum performance.
1GB DIMMs minimum configuration of 8GB, maximum configuration of 32GB.
2GB DIMMs minimum configuration of 16GB, maximum configuration of 64GB.
4GB DIMMs minimum configuration of 32GB, maximum configuration of 128GB.

Optional Storage

Disk

Up to two optional, hot swappable, hot pluggable, SATA or SAS drives per blade.
May be configured as independent, striped (RAID 0) or mirrored (RAID 1).
Mixing disk types (i.e. one SAS disk and one SATA disk) on same X8440 Server Module is not supported.

Drive Type	Density	Speed	Form Factor
SAS	73 GB	10,000 RPM	2.5″
SAS	146 GB	10,000 RPM	2.5″
SATA	80 GB	5,400 RPM	2.5″

Solid State Drives

Up to two 32GB solid state drives

Solid State Drives

Up to two 32GB solid state drives

Management Environment
The Sun Blade Modular Systems have a tiered system management architecture that allows management at either the chassis level or the Server Module level.

Common System Management for both the Chassis and the Server Module

Integrated Lights Out Management (ILOM) 1.1 with RKVMS (Remote Keyboard Video Mouse) is pre-installed on the CMM (Chassis Monitoring Module) and the SP (Service Processor). ILOM will run on standby power. Note: Accessing ILOM through Mozilla will require Mozilla version 1.7.5 or greater.
Support for Sun N1 System Manager 1.3.1.
Compatibility for third-party SNMP system managers with requirements for SNMP (v1, v2C, v3) and IPMI (2.0).
System management is consistent with Sun Fire X4100 and Sun Fire X4200 servers.

Sun Blade Server Module Service Processor (SP)

Server Module management (ILOM) can be accessed directly via the dedicated DB-9 serial port located on the front of the Server Module or via the CMM.
Each Server Module includes an on-board (separately powered) SP that communicates with the four main processors and the rest of the Server Modules.
Server Module management is available even when Server Module is powered off but the Chassis is powered on.

Standard Integrated Interfaces

Network Management

The Server Module provides a DB-9 serial port. Reference the Management Environment section.

PCI Interfaces with the Sun Blade 8000 Modular System

In the Sun Blade 8000 Modular System, six PCI Express interfaces per Server Module are allocated to either:

Two I/O PCI Express ExpressModules (EMs)
or
Four Network Express Modules (NEMs)

The Server Module currently creates 40 lanes allocated as follows:

8 lanes/32Gbps allocated to each of the two EMs (16 lanes).
8 lane/32Gbps allocated to each of the upper two NEMs (16 lanes).
4 lane/16Gbps allocated to each of the lower two NEMs (8 lanes).

PCI Interfaces with the Sun Blade 8000 P Modular System

In the Sun Blade 8000 P Modular System, two PCIe x8 lanes to the upper NEMs are supported.

USB

Each optional X8440 Server Module provides two USB 2.0 ports.

Video

Each optional X8440 Server Module provides a VGA Video connection to the ATI Rage XL graphics chip.

Regulations

RoHS Compliance Level

RoHS:YL

\Batteries
Option #	Manufacturing Part #	Description
n/a	150-4277	3V Lithium coin battery, RoHS:Y

Blade
Option #	Manufacturing Part #	Description
X5199A-Z	594-4729	Sun Blade X8440 Server Module with 8GB Memory (4 × 2GB) and 2 CPUs (3.0 GHz, 95W, Dual Core Opteron 8222)
	371-2354	2GB DDR2-667 ECC Registered DIMM, 2-Rank/512 Mbit SDRAM, RoHS:Y
	371-2481	Hyper Transport (HT) Termination Adapter (5189A-Z), RoHS:Y
	371-2509	3.0 GHz CPU, Opteron 8222 Dual Core, F3 Stepping, 95W, RoHS:Y
	541-1950	0MB Sun Blade X8440 Server Module Assembly, RoHS:YL
	541-2755	Airflow Baffles (5189A-Z), RoHS:Y
X5200A-Z	594-4677	Sun Blade X8440 Server Module with 16GB Memory (8 × 2GB) and 4 CPUs (3.0 GHz, 95W, Dual Core Opteron 8222)
	371-2354	2GB DDR2-667 ECC Registered DIMM, 2-Rank/512 Mbit SDRAM, RoHS:Y
	371-2509	3.0 GHz CPU, Opteron 8222 Dual Core, F3 Stepping, 95W, RoHS:Y
	541-1950	0MB Sun Blade X8440 Server Module Assembly, RoHS:YL
X5215A-C	594-5806	Sun Blade X8440 Server Module with 32GB Memory (16 × 2GB 1-Rank DIMMs) and 4 CPUs (2.3 GHz, 75W, Quad Core Opteron 8356)
	371-4044	2.3 GHz CPU, Opteron 8356 Quad Core, B3 Stepping, 75W, RoHS:Y
	371-4137	2GB DDR2-667 ECC Registered DIMM, 1-Rank/1Gbit SDRAM, RoHS:Y
	541-1950	0MB Sun Blade X8440 Server Module Assembly, RoHS:YL
X5215A-Z	594-4730	Sun Blade X8440 Server Module with 32GB Memory (16 × 2GB) and 4 CPUs (2.3 GHz, 75W, Quad Core Opteron 8356)
	371-2354	2GB DDR2-667 ECC Registered DIMM, 2-Rank/512 Mbit SDRAM, RoHS:Y
	371-4044	2.3 GHz CPU, Opteron 8356 Quad Core, B3 Stepping, 75W, RoHS:Y
	541-1950	0MB Sun Blade X8440 Server Module Assembly, RoHS:YL
X5259A-C	594-5807	Sun Blade X8440 Server Module with 16GB Memory (8 × 2GB 1- Rank DIMMs) and 4 CPUs (2.2 GHz, 75W, Dual Core Opteron 8354)
	371-4043	2.2 GHz CPU, Opteron 8354 Quad Core, B3 Stepping, 75W, RoHS:Y
	371-4137	2GB DDR2-667 ECC Registered DIMM, 1-Rank/1Gbit SDRAM, RoHS:Y
	541-1950	0MB Sun Blade X8440 Server Module Assembly, RoHS:YL
X5259A-Z	594-4947	Sun Blade X8440 Server Module with 16GB Memory (8 × 2GB) and 4 CPUs (2.2 GHz, 75W, Dual Core Opteron 8354)
	371-2354	2GB DDR2-667 ECC Registered DIMM, 2-Rank/512 Mbit SDRAM, RoHS:Y
	371-4043	2.2 GHz CPU, Opteron 8354 Quad Core, B3 Stepping, 75W, RoHS:Y
	541-1950	0MB Sun Blade X8440 Server Module Assembly, RoHS:YL
X5276A-C	594-5808	Sun Blade X8440 Server Module with 16GB Memory (8 × 2GB 1-Rank DIMMs) and 4 CPUs (1.9 GHz, 55W, Quad Core Opteron 8347 HE)
	371-4046	1.9 GHz CPU, Opteron 8347HE Quad Core, B3 Stepping, 55W, RoHS:Y
	371-4137	2GB DDR2-667 ECC Registered DIMM, 1-Rank/1Gbit SDRAM, RoHS:Y
	541-1950	0MB Sun Blade X8440 Server Module Assembly, RoHS:YL
X5276A-Z	594-4732	Sun Blade X8440 Server Module with 16GB Memory (8 × 2GB) and 4 CPUs (1.9 GHz, 55W, Quad Core Opteron 8347 HE)
	371-2354	2GB DDR2-667 ECC Registered DIMM, 2-Rank/512 Mbit SDRAM, RoHS:Y
	371-4046	1.9 GHz CPU, Opteron 8347HE Quad Core, B3 Stepping, 55W, RoHS:Y
	541-1950	0MB Sun Blade X8440 Server Module Assembly, RoHS:YL
n/a	F541-1950	0MB Sun Blade X8440 Server Module Assembly, RoHS:YL
	150-4277	3V Lithium coin battery, RoHS:Y
	250-1802	Alcohol Wipe Cleaner
	310-0030	CPU Heatsink, RoHS:Y
	310-0049	G751 Thermal Grease Syringe, RoHS:Y
	541-1950	0MB Sun Blade X8440 Server Module Assembly, RoHS:YL

CPU Module
Option #	Manufacturing Part #	Description
X5219A-Z	2 × 2.3 GHz CPU, Opteron 8356 Quad Core, 75W, RoHS:YL
	310-0030	CPU Heatsink, RoHS:Y
	310-0065	Thermal Grease, Syringe, RoHS:Y
	371-4044	2.3 GHz CPU, Opteron 8356 Quad Core, B3 Stepping, 75W, RoHS:Y
X5285A-Z	2 × 2.2 GHz CPU, Opteron 8354 Quad Core, 75W, RoHS:YL
	250-1802	Alcohol Wipe Cleaner
	310-0030	CPU Heatsink, RoHS:Y
	310-0065	Thermal Grease, Syringe, RoHS:Y
	371-4043	2.2 GHz CPU, Opteron 8354 Quad Core, B3 Stepping, 75W, RoHS:Y
X5305A-Z	2 × 1.9 GHz CPU, Opteron 8347 HE Quad Core, 55W, RoHS:YL
	250-1802	Alcohol Wipe Cleaner
	310-0030	CPU Heatsink, RoHS:Y
	310-0065	Thermal Grease, Syringe, RoHS:Y
	371-4046	1.9 GHz CPU, Opteron 8347HE Quad Core, B3 Stepping, 55W, RoHS:Y
n/a	541-2755	Airflow Baffles (5189A-Z), RoHS:Y
n/a	F310-0030	CPU Heatsink Assembly, RoHS:Y
	310-0030	CPU Heatsink, RoHS:Y
	310-0049	G751 Thermal Grease Syringe, RoHS:Y
n/a	F371-2509	3.0 GHz CPU, Opteron 8222 Dual Core, F3 Stepping, 95W, RoHS:Y
	250-1802	Alcohol Wipe Cleaner
	310-0049	G751 Thermal Grease Syringe, RoHS:Y
	371-2509	3.0 GHz CPU, Opteron 8222 Dual Core, F3 Stepping, 95W, RoHS:Y
n/a	F371-4043	2.2 GHz CPU, Opteron 8354 Quad Core, 75W, RoHS:Y
n/a	371-4043	2.2 GHz CPU, Opteron 8354 Quad Core, B3 Stepping, 75W, RoHS:Y
n/a	F371-4044	2.3 GHz CPU, Opteron 8356 Quad Core, 75W CPU, RoHS:Y
	250-1802	Alcohol Wipe Cleaner
	310-0065	Thermal Grease, Syringe, RoHS:Y
	371-4044	2.3 GHz CPU, Opteron 8356 Quad Core, B3 Stepping, 75W, RoHS:Y
n/a	F371-4046	1.9 GHz CPU, Opteron 8347HE Quad Core, 55W CPU
	250-1802	Alcohol Wipe Cleaner
	310-0065	Thermal Grease, Syringe, RoHS:Y
	371-4046	1.9 GHz CPU, Opteron 8347HE Quad Core, B3 Stepping, 55W, RoHS:Y

Disks
Option #	Manufacturing Part #	Description
XRA-SS2CD-73G15K	540-7360	73GB – 15000 RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks, RoHS:Y
	390-0382	Seagate ST973451SS [ST973451SSUN72G] (73GB – 15000 RPM – SAS Disk), RoHS:Y
	541-0239	Nemo Bracket, RoHS:Y
XRB-SS2CD-146G10KZ	540-7151	146GB – 10000 RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks and brackets, RoHS:Y
	390-0324	Seagate ST9146802SS [ST914602SSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0375	Fujitsu MBB2147RC [MBB2147RCSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0377	Hitachi HUC101414CSS300 [H101414SCSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	541-0239	Nemo Bracket, RoHS:Y
	541-3004	Nemo Bracket with Insulator, RoHS:Y
XRB-SS2CD-73G10KZ	540-6611	73GB 10000 RPM SAS, Disk Assembly with 1 of the following disks and brackets, RoHS:Y
	390-0213	Seagate ST973401SS [ST973401SSUN72G] (73GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0285	Fujitsu MAY2073RC [MAY2073RCSUN72] (73GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0323	Seagate ST973402SS [ST973402SSUN72G] (73GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0374	Fujitsu MBB2073RC [MBB2073RCSUN72G] (73.4GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0376	Hitachi HUC101473CSS300 [H101473SCSUN72G] (73.4GB – 10000 RPM – SAS Disk), RoHS:Y
	541-0239	Nemo Bracket, RoHS:Y
	541-3004	Nemo Bracket with Insulator, RoHS:Y
XRB-ST3CD-200G5K	540-7554	200GB – 5400 RPM SATA Disk Assrmbly with 1 bracket and 1 of the following disks, RoHS:Y
	390-0407	Fujitsu MHY2200BS [MHY2200BSSUN200G] (200GB – 5400 RPM – SATA Disk), RoHS:Y
	541-3004	Nemo Bracket with Insulator, RoHS:Y
XRB-ST3CD-80G5KZ	541-1115	80GB – 5400 RPM SATA, Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
	390-0250	Fujitsu MHV2080BS [MHV5480SBSUN80G] (80GB – 5400 RPM – SATA Disk), RoHS:Y
	541-0239	Nemo Bracket, RoHS:Y

Batteries
Option #	Manufacturing Part #	Description
n/a	150-4277	3V Lithium coin battery, RoHS:Y

Blade
Option #	Manufacturing Part #	Description
X5199A-Z	594-4729	Sun Blade X8440 Server Module with 8GB Memory (4 × 2GB) and 2 CPUs (3.0 GHz, 95W, Dual Core Opteron 8222)
	371-2354	2GB DDR2-667 ECC Registered DIMM, 2-Rank/512 Mbit SDRAM, RoHS:Y
	371-2481	Hyper Transport (HT) Termination Adapter (5189A-Z), RoHS:Y
	371-2509	3.0 GHz CPU, Opteron 8222 Dual Core, F3 Stepping, 95W, RoHS:Y
	541-1950	0MB Sun Blade X8440 Server Module Assembly, RoHS:YL
	541-2755	Airflow Baffles (5189A-Z), RoHS:Y
X5200A-Z	594-4677	Sun Blade X8440 Server Module with 16GB Memory (8 × 2GB) and 4 CPUs (3.0 GHz, 95W, Dual Core Opteron 8222)
	371-2354	2GB DDR2-667 ECC Registered DIMM, 2-Rank/512 Mbit SDRAM, RoHS:Y
	371-2509	3.0 GHz CPU, Opteron 8222 Dual Core, F3 Stepping, 95W, RoHS:Y
	541-1950	0MB Sun Blade X8440 Server Module Assembly, RoHS:YL
X5215A-C	594-5806	Sun Blade X8440 Server Module with 32GB Memory (16 × 2GB 1-Rank DIMMs) and 4 CPUs (2.3 GHz, 75W, Quad Core Opteron 8356)
	371-4044	2.3 GHz CPU, Opteron 8356 Quad Core, B3 Stepping, 75W, RoHS:Y
	371-4137	2GB DDR2-667 ECC Registered DIMM, 1-Rank/1Gbit SDRAM, RoHS:Y
	541-1950	0MB Sun Blade X8440 Server Module Assembly, RoHS:YL
X5215A-Z	594-4730	Sun Blade X8440 Server Module with 32GB Memory (16 × 2GB) and 4 CPUs (2.3 GHz, 75W, Quad Core Opteron 8356)
	371-2354	2GB DDR2-667 ECC Registered DIMM, 2-Rank/512 Mbit SDRAM, RoHS:Y
	371-4044	2.3 GHz CPU, Opteron 8356 Quad Core, B3 Stepping, 75W, RoHS:Y
	541-1950	0MB Sun Blade X8440 Server Module Assembly, RoHS:YL
X5259A-C	594-5807	Sun Blade X8440 Server Module with 16GB Memory (8 × 2GB 1- Rank DIMMs) and 4 CPUs (2.2 GHz, 75W, Dual Core Opteron 8354)
	371-4043	2.2 GHz CPU, Opteron 8354 Quad Core, B3 Stepping, 75W, RoHS:Y
	371-4137	2GB DDR2-667 ECC Registered DIMM, 1-Rank/1Gbit SDRAM, RoHS:Y
	541-1950	0MB Sun Blade X8440 Server Module Assembly, RoHS:YL
X5259A-Z	594-4947	Sun Blade X8440 Server Module with 16GB Memory (8 × 2GB) and 4 CPUs (2.2 GHz, 75W, Dual Core Opteron 8354)
	371-2354	2GB DDR2-667 ECC Registered DIMM, 2-Rank/512 Mbit SDRAM, RoHS:Y
	371-4043	2.2 GHz CPU, Opteron 8354 Quad Core, B3 Stepping, 75W, RoHS:Y
	541-1950	0MB Sun Blade X8440 Server Module Assembly, RoHS:YL
X5276A-C	594-5808	Sun Blade X8440 Server Module with 16GB Memory (8 × 2GB 1-Rank DIMMs) and 4 CPUs (1.9 GHz, 55W, Quad Core Opteron 8347 HE)
	371-4046	1.9 GHz CPU, Opteron 8347HE Quad Core, B3 Stepping, 55W, RoHS:Y
	371-4137	2GB DDR2-667 ECC Registered DIMM, 1-Rank/1Gbit SDRAM, RoHS:Y
	541-1950	0MB Sun Blade X8440 Server Module Assembly, RoHS:YL
X5276A-Z	594-4732	Sun Blade X8440 Server Module with 16GB Memory (8 × 2GB) and 4 CPUs (1.9 GHz, 55W, Quad Core Opteron 8347 HE)
	371-2354	2GB DDR2-667 ECC Registered DIMM, 2-Rank/512 Mbit SDRAM, RoHS:Y
	371-4046	1.9 GHz CPU, Opteron 8347HE Quad Core, B3 Stepping, 55W, RoHS:Y
	541-1950	0MB Sun Blade X8440 Server Module Assembly, RoHS:YL
n/a	F541-1950	0MB Sun Blade X8440 Server Module Assembly, RoHS:YL
	150-4277	3V Lithium coin battery, RoHS:Y
	250-1802	Alcohol Wipe Cleaner
	310-0030	CPU Heatsink, RoHS:Y
	310-0049	G751 Thermal Grease Syringe, RoHS:Y
	541-1950	0MB Sun Blade X8440 Server Module Assembly, RoHS:YL

CPU Module
Option #	Manufacturing Part #	Description
X5219A-Z	2 × 2.3 GHz CPU, Opteron 8356 Quad Core, 75W, RoHS:YL
	310-0030	CPU Heatsink, RoHS:Y
	310-0065	Thermal Grease, Syringe, RoHS:Y
	371-4044	2.3 GHz CPU, Opteron 8356 Quad Core, B3 Stepping, 75W, RoHS:Y
X5285A-Z	2 × 2.2 GHz CPU, Opteron 8354 Quad Core, 75W, RoHS:YL
	250-1802	Alcohol Wipe Cleaner
	310-0030	CPU Heatsink, RoHS:Y
	310-0065	Thermal Grease, Syringe, RoHS:Y
	371-4043	2.2 GHz CPU, Opteron 8354 Quad Core, B3 Stepping, 75W, RoHS:Y
X5305A-Z	2 × 1.9 GHz CPU, Opteron 8347 HE Quad Core, 55W, RoHS:YL
	250-1802	Alcohol Wipe Cleaner
	310-0030	CPU Heatsink, RoHS:Y
	310-0065	Thermal Grease, Syringe, RoHS:Y
	371-4046	1.9 GHz CPU, Opteron 8347HE Quad Core, B3 Stepping, 55W, RoHS:Y
n/a	541-2755	Airflow Baffles (5189A-Z), RoHS:Y
n/a	F310-0030	CPU Heatsink Assembly, RoHS:Y
	310-0030	CPU Heatsink, RoHS:Y
	310-0049	G751 Thermal Grease Syringe, RoHS:Y
n/a	F371-2509	3.0 GHz CPU, Opteron 8222 Dual Core, F3 Stepping, 95W, RoHS:Y
	250-1802	Alcohol Wipe Cleaner
	310-0049	G751 Thermal Grease Syringe, RoHS:Y
	371-2509	3.0 GHz CPU, Opteron 8222 Dual Core, F3 Stepping, 95W, RoHS:Y
n/a	F371-4043	2.2 GHz CPU, Opteron 8354 Quad Core, 75W, RoHS:Y
n/a	371-4043	2.2 GHz CPU, Opteron 8354 Quad Core, B3 Stepping, 75W, RoHS:Y
n/a	F371-4044	2.3 GHz CPU, Opteron 8356 Quad Core, 75W CPU, RoHS:Y
	250-1802	Alcohol Wipe Cleaner
	310-0065	Thermal Grease, Syringe, RoHS:Y
	371-4044	2.3 GHz CPU, Opteron 8356 Quad Core, B3 Stepping, 75W, RoHS:Y
n/a	F371-4046	1.9 GHz CPU, Opteron 8347HE Quad Core, 55W CPU
	250-1802	Alcohol Wipe Cleaner
	310-0065	Thermal Grease, Syringe, RoHS:Y
	371-4046	1.9 GHz CPU, Opteron 8347HE Quad Core, B3 Stepping, 55W, RoHS:Y

Disks
Option #	Manufacturing Part #	Description
XRA-SS2CD-73G15K	540-7360	73GB – 15000 RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks, RoHS:Y
	390-0382	Seagate ST973451SS [ST973451SSUN72G] (73GB – 15000 RPM – SAS Disk), RoHS:Y
	541-0239	Nemo Bracket, RoHS:Y
XRB-SS2CD-146G10KZ	540-7151	146GB – 10000 RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks and brackets, RoHS:Y
	390-0324	Seagate ST9146802SS [ST914602SSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0375	Fujitsu MBB2147RC [MBB2147RCSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0377	Hitachi HUC101414CSS300 [H101414SCSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	541-0239	Nemo Bracket, RoHS:Y
	541-3004	Nemo Bracket with Insulator, RoHS:Y
XRB-SS2CD-73G10KZ	540-6611	73GB 10000 RPM SAS, Disk Assembly with 1 of the following disks and brackets, RoHS:Y
	390-0213	Seagate ST973401SS [ST973401SSUN72G] (73GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0285	Fujitsu MAY2073RC [MAY2073RCSUN72] (73GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0323	Seagate ST973402SS [ST973402SSUN72G] (73GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0374	Fujitsu MBB2073RC [MBB2073RCSUN72G] (73.4GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0376	Hitachi HUC101473CSS300 [H101473SCSUN72G] (73.4GB – 10000 RPM – SAS Disk), RoHS:Y
	541-0239	Nemo Bracket, RoHS:Y
	541-3004	Nemo Bracket with Insulator, RoHS:Y
XRB-ST3CD-200G5K	540-7554	200GB – 5400 RPM SATA Disk Assrmbly with 1 bracket and 1 of the following disks, RoHS:Y
	390-0407	Fujitsu MHY2200BS [MHY2200BSSUN200G] (200GB – 5400 RPM – SATA Disk), RoHS:Y
	541-3004	Nemo Bracket with Insulator, RoHS:Y
XRB-ST3CD-80G5KZ	541-1115	80GB – 5400 RPM SATA, Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
	390-0250	Fujitsu MHV2080BS [MHV5480SBSUN80G] (80GB – 5400 RPM – SATA Disk), RoHS:Y
	541-0239	Nemo Bracket, RoHS:Y

Memory
Option #	Manufacturing Part #	Description
X5093A-Z	2 GB (2 × 1GB) DDR1-667 ECC Registered DIMMs, RoHS:YL
X5093A-Z	371-2353	1GB DDR1-667 ECC Registered DIMM, 1-Rank/512 Mbit SDRAM, RoHS:Y
X5094A-C	4 GB (2 × 2GB) DDR2-667 ECC Registered DIMMs, RoHS:YL
X5094A-C	371-4137	2GB DDR2-667 ECC Registered DIMM, 1-Rank/1Gbit SDRAM, RoHS:Y
X5094A-Z	4 GB (2 × 2GB) DDR2-667 ECC Registered DIMMs, RoHS:YL
X5094A-Z	371-2354	2GB DDR2-667 ECC Registered DIMM, 2-Rank/512 Mbit SDRAM, RoHS:Y
X5095A-Z	8 GB (2 × 4GB) DDR2-667 ECC Registered DIMMs, RoHS:YL
X5095A-Z	371-2355	4GB DDR2-667 ECC Registered DIMM, 2-Rank/1 Gbit SDRAM, RoHS:Y
n/a	540-7226	2GB (2 × 1GB) Memory, RoHS:Y
n/a	371-2353	1GB DDR1-667 ECC Registered DIMM, 1-Rank/512 Mbit SDRAM, RoHS:Y
n/a	540-7227	4GB (2 × 2GB) Memory, RoHS:Y
n/a	371-2354	2GB DDR2-667 ECC Registered DIMM, 2-Rank/512 Mbit SDRAM, RoHS:Y
n/a	540-7228	8GB (2 × 4GB) Memory, RoHS:Y
n/a	371-2355	4GB DDR2-667 ECC Registered DIMM, 2-Rank/1 Gbit SDRAM, RoHS:Y
n/a	540-7840	4GB (2 × 2GB) Memory, RoHS:Y
n/a	371-4137	2GB DDR2-667 ECC Registered DIMM, 1-Rank/1Gbit SDRAM, RoHS:Y

Memory
Option #	Manufacturing Part #	Description
X5093A-Z	2 GB (2 × 1GB) DDR1-667 ECC Registered DIMMs, RoHS:YL
X5093A-Z	371-2353	1GB DDR1-667 ECC Registered DIMM, 1-Rank/512 Mbit SDRAM, RoHS:Y
X5094A-C	4 GB (2 × 2GB) DDR2-667 ECC Registered DIMMs, RoHS:YL
X5094A-C	371-4137	2GB DDR2-667 ECC Registered DIMM, 1-Rank/1Gbit SDRAM, RoHS:Y
X5094A-Z	4 GB (2 × 2GB) DDR2-667 ECC Registered DIMMs, RoHS:YL
X5094A-Z	371-2354	2GB DDR2-667 ECC Registered DIMM, 2-Rank/512 Mbit SDRAM, RoHS:Y
X5095A-Z	8 GB (2 × 4GB) DDR2-667 ECC Registered DIMMs, RoHS:YL
X5095A-Z	371-2355	4GB DDR2-667 ECC Registered DIMM, 2-Rank/1 Gbit SDRAM, RoHS:Y
n/a	540-7226	2GB (2 × 1GB) Memory, RoHS:Y
n/a	371-2353	1GB DDR1-667 ECC Registered DIMM, 1-Rank/512 Mbit SDRAM, RoHS:Y
n/a	540-7227	4GB (2 × 2GB) Memory, RoHS:Y
n/a	371-2354	2GB DDR2-667 ECC Registered DIMM, 2-Rank/512 Mbit SDRAM, RoHS:Y
n/a	540-7228	8GB (2 × 4GB) Memory, RoHS:Y
n/a	371-2355	4GB DDR2-667 ECC Registered DIMM, 2-Rank/1 Gbit SDRAM, RoHS:Y
n/a	540-7840	4GB (2 × 2GB) Memory, RoHS:Y
n/a	371-4137	2GB DDR2-667 ECC Registered DIMM, 1-Rank/1Gbit SDRAM, RoHS:Y

Batteries
Option #	Manufacturing Part #	Description
n/a	150-4277	3V Lithium coin battery, RoHS:Y

Blade
Option #	Manufacturing Part #	Description
X5199A-Z	594-4729	Sun Blade X8440 Server Module with 8GB Memory (4 × 2GB) and 2 CPUs (3.0 GHz, 95W, Dual Core Opteron 8222)
	371-2354	2GB DDR2-667 ECC Registered DIMM, 2-Rank/512 Mbit SDRAM, RoHS:Y
	371-2481	Hyper Transport (HT) Termination Adapter (5189A-Z), RoHS:Y
	371-2509	3.0 GHz CPU, Opteron 8222 Dual Core, F3 Stepping, 95W, RoHS:Y
	541-1950	0MB Sun Blade X8440 Server Module Assembly, RoHS:YL
	541-2755	Airflow Baffles (5189A-Z), RoHS:Y
X5200A-Z	594-4677	Sun Blade X8440 Server Module with 16GB Memory (8 × 2GB) and 4 CPUs (3.0 GHz, 95W, Dual Core Opteron 8222)
	371-2354	2GB DDR2-667 ECC Registered DIMM, 2-Rank/512 Mbit SDRAM, RoHS:Y
	371-2509	3.0 GHz CPU, Opteron 8222 Dual Core, F3 Stepping, 95W, RoHS:Y
	541-1950	0MB Sun Blade X8440 Server Module Assembly, RoHS:YL
X5215A-C	594-5806	Sun Blade X8440 Server Module with 32GB Memory (16 × 2GB 1-Rank DIMMs) and 4 CPUs (2.3 GHz, 75W, Quad Core Opteron 8356)
	371-4044	2.3 GHz CPU, Opteron 8356 Quad Core, B3 Stepping, 75W, RoHS:Y
	371-4137	2GB DDR2-667 ECC Registered DIMM, 1-Rank/1Gbit SDRAM, RoHS:Y
	541-1950	0MB Sun Blade X8440 Server Module Assembly, RoHS:YL
X5215A-Z	594-4730	Sun Blade X8440 Server Module with 32GB Memory (16 × 2GB) and 4 CPUs (2.3 GHz, 75W, Quad Core Opteron 8356)
	371-2354	2GB DDR2-667 ECC Registered DIMM, 2-Rank/512 Mbit SDRAM, RoHS:Y
	371-4044	2.3 GHz CPU, Opteron 8356 Quad Core, B3 Stepping, 75W, RoHS:Y
	541-1950	0MB Sun Blade X8440 Server Module Assembly, RoHS:YL
X5259A-C	594-5807	Sun Blade X8440 Server Module with 16GB Memory (8 × 2GB 1- Rank DIMMs) and 4 CPUs (2.2 GHz, 75W, Dual Core Opteron 8354)
	371-4043	2.2 GHz CPU, Opteron 8354 Quad Core, B3 Stepping, 75W, RoHS:Y
	371-4137	2GB DDR2-667 ECC Registered DIMM, 1-Rank/1Gbit SDRAM, RoHS:Y
	541-1950	0MB Sun Blade X8440 Server Module Assembly, RoHS:YL
X5259A-Z	594-4947	Sun Blade X8440 Server Module with 16GB Memory (8 × 2GB) and 4 CPUs (2.2 GHz, 75W, Dual Core Opteron 8354)
	371-2354	2GB DDR2-667 ECC Registered DIMM, 2-Rank/512 Mbit SDRAM, RoHS:Y
	371-4043	2.2 GHz CPU, Opteron 8354 Quad Core, B3 Stepping, 75W, RoHS:Y
	541-1950	0MB Sun Blade X8440 Server Module Assembly, RoHS:YL
X5276A-C	594-5808	Sun Blade X8440 Server Module with 16GB Memory (8 × 2GB 1-Rank DIMMs) and 4 CPUs (1.9 GHz, 55W, Quad Core Opteron 8347 HE)
	371-4046	1.9 GHz CPU, Opteron 8347HE Quad Core, B3 Stepping, 55W, RoHS:Y
	371-4137	2GB DDR2-667 ECC Registered DIMM, 1-Rank/1Gbit SDRAM, RoHS:Y
	541-1950	0MB Sun Blade X8440 Server Module Assembly, RoHS:YL
X5276A-Z	594-4732	Sun Blade X8440 Server Module with 16GB Memory (8 × 2GB) and 4 CPUs (1.9 GHz, 55W, Quad Core Opteron 8347 HE)
	371-2354	2GB DDR2-667 ECC Registered DIMM, 2-Rank/512 Mbit SDRAM, RoHS:Y
	371-4046	1.9 GHz CPU, Opteron 8347HE Quad Core, B3 Stepping, 55W, RoHS:Y
	541-1950	0MB Sun Blade X8440 Server Module Assembly, RoHS:YL
n/a	F541-1950	0MB Sun Blade X8440 Server Module Assembly, RoHS:YL
	150-4277	3V Lithium coin battery, RoHS:Y
	250-1802	Alcohol Wipe Cleaner
	310-0030	CPU Heatsink, RoHS:Y
	310-0049	G751 Thermal Grease Syringe, RoHS:Y
	541-1950	0MB Sun Blade X8440 Server Module Assembly, RoHS:YL

CPU Module
Option #	Manufacturing Part #	Description
X5219A-Z	2 × 2.3 GHz CPU, Opteron 8356 Quad Core, 75W, RoHS:YL
	310-0030	CPU Heatsink, RoHS:Y
	310-0065	Thermal Grease, Syringe, RoHS:Y
	371-4044	2.3 GHz CPU, Opteron 8356 Quad Core, B3 Stepping, 75W, RoHS:Y
X5285A-Z	2 × 2.2 GHz CPU, Opteron 8354 Quad Core, 75W, RoHS:YL
	250-1802	Alcohol Wipe Cleaner
	310-0030	CPU Heatsink, RoHS:Y
	310-0065	Thermal Grease, Syringe, RoHS:Y
	371-4043	2.2 GHz CPU, Opteron 8354 Quad Core, B3 Stepping, 75W, RoHS:Y
X5305A-Z	2 × 1.9 GHz CPU, Opteron 8347 HE Quad Core, 55W, RoHS:YL
	250-1802	Alcohol Wipe Cleaner
	310-0030	CPU Heatsink, RoHS:Y
	310-0065	Thermal Grease, Syringe, RoHS:Y
	371-4046	1.9 GHz CPU, Opteron 8347HE Quad Core, B3 Stepping, 55W, RoHS:Y
n/a	541-2755	Airflow Baffles (5189A-Z), RoHS:Y
n/a	F310-0030	CPU Heatsink Assembly, RoHS:Y
	310-0030	CPU Heatsink, RoHS:Y
	310-0049	G751 Thermal Grease Syringe, RoHS:Y
n/a	F371-2509	3.0 GHz CPU, Opteron 8222 Dual Core, F3 Stepping, 95W, RoHS:Y
	250-1802	Alcohol Wipe Cleaner
	310-0049	G751 Thermal Grease Syringe, RoHS:Y
	371-2509	3.0 GHz CPU, Opteron 8222 Dual Core, F3 Stepping, 95W, RoHS:Y
n/a	F371-4043	2.2 GHz CPU, Opteron 8354 Quad Core, 75W, RoHS:Y
n/a	371-4043	2.2 GHz CPU, Opteron 8354 Quad Core, B3 Stepping, 75W, RoHS:Y
n/a	F371-4044	2.3 GHz CPU, Opteron 8356 Quad Core, 75W CPU, RoHS:Y
	250-1802	Alcohol Wipe Cleaner
	310-0065	Thermal Grease, Syringe, RoHS:Y
	371-4044	2.3 GHz CPU, Opteron 8356 Quad Core, B3 Stepping, 75W, RoHS:Y
n/a	F371-4046	1.9 GHz CPU, Opteron 8347HE Quad Core, 55W CPU
	250-1802	Alcohol Wipe Cleaner
	310-0065	Thermal Grease, Syringe, RoHS:Y
	371-4046	1.9 GHz CPU, Opteron 8347HE Quad Core, B3 Stepping, 55W, RoHS:Y

Disks
Option #	Manufacturing Part #	Description
XRA-SS2CD-73G15K	540-7360	73GB – 15000 RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks, RoHS:Y
	390-0382	Seagate ST973451SS [ST973451SSUN72G] (73GB – 15000 RPM – SAS Disk), RoHS:Y
	541-0239	Nemo Bracket, RoHS:Y
XRB-SS2CD-146G10KZ	540-7151	146GB – 10000 RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks and brackets, RoHS:Y
	390-0324	Seagate ST9146802SS [ST914602SSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0375	Fujitsu MBB2147RC [MBB2147RCSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0377	Hitachi HUC101414CSS300 [H101414SCSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	541-0239	Nemo Bracket, RoHS:Y
	541-3004	Nemo Bracket with Insulator, RoHS:Y
XRB-SS2CD-73G10KZ	540-6611	73GB 10000 RPM SAS, Disk Assembly with 1 of the following disks and brackets, RoHS:Y
	390-0213	Seagate ST973401SS [ST973401SSUN72G] (73GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0285	Fujitsu MAY2073RC [MAY2073RCSUN72] (73GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0323	Seagate ST973402SS [ST973402SSUN72G] (73GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0374	Fujitsu MBB2073RC [MBB2073RCSUN72G] (73.4GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0376	Hitachi HUC101473CSS300 [H101473SCSUN72G] (73.4GB – 10000 RPM – SAS Disk), RoHS:Y
	541-0239	Nemo Bracket, RoHS:Y
	541-3004	Nemo Bracket with Insulator, RoHS:Y
XRB-ST3CD-200G5K	540-7554	200GB – 5400 RPM SATA Disk Assrmbly with 1 bracket and 1 of the following disks, RoHS:Y
	390-0407	Fujitsu MHY2200BS [MHY2200BSSUN200G] (200GB – 5400 RPM – SATA Disk), RoHS:Y
	541-3004	Nemo Bracket with Insulator, RoHS:Y
XRB-ST3CD-80G5KZ	541-1115	80GB – 5400 RPM SATA, Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
	390-0250	Fujitsu MHV2080BS [MHV5480SBSUN80G] (80GB – 5400 RPM – SATA Disk), RoHS:Y
	541-0239	Nemo Bracket, RoHS:Y

Memory
Option #	Manufacturing Part #	Description
X5093A-Z	2 GB (2 × 1GB) DDR1-667 ECC Registered DIMMs, RoHS:YL
X5093A-Z	371-2353	1GB DDR1-667 ECC Registered DIMM, 1-Rank/512 Mbit SDRAM, RoHS:Y
X5094A-C	4 GB (2 × 2GB) DDR2-667 ECC Registered DIMMs, RoHS:YL
X5094A-C	371-4137	2GB DDR2-667 ECC Registered DIMM, 1-Rank/1Gbit SDRAM, RoHS:Y
X5094A-Z	4 GB (2 × 2GB) DDR2-667 ECC Registered DIMMs, RoHS:YL
X5094A-Z	371-2354	2GB DDR2-667 ECC Registered DIMM, 2-Rank/512 Mbit SDRAM, RoHS:Y
X5095A-Z	8 GB (2 × 4GB) DDR2-667 ECC Registered DIMMs, RoHS:YL
X5095A-Z	371-2355	4GB DDR2-667 ECC Registered DIMM, 2-Rank/1 Gbit SDRAM, RoHS:Y
n/a	540-7226	2GB (2 × 1GB) Memory, RoHS:Y
n/a	371-2353	1GB DDR1-667 ECC Registered DIMM, 1-Rank/512 Mbit SDRAM, RoHS:Y
n/a	540-7227	4GB (2 × 2GB) Memory, RoHS:Y
n/a	371-2354	2GB DDR2-667 ECC Registered DIMM, 2-Rank/512 Mbit SDRAM, RoHS:Y
n/a	540-7228	8GB (2 × 4GB) Memory, RoHS:Y
n/a	371-2355	4GB DDR2-667 ECC Registered DIMM, 2-Rank/1 Gbit SDRAM, RoHS:Y
n/a	540-7840	4GB (2 × 2GB) Memory, RoHS:Y
n/a	371-4137	2GB DDR2-667 ECC Registered DIMM, 1-Rank/1Gbit SDRAM, RoHS:Y

Industry Leading Quality, Support and Integrity

Quality Inspection Checklist
Before it leaves our facility, every used and refurbished item is thoroughly inspected by our certified technicians and undergoes our exclusive Quality Inspection Checklist to ensure 100% satisfaction guarantee.

Greentec Systems is a leading provider
For server, networking and storage equipment. We have an extensive array of inventory of IBM Servers & Storage, Sun Servers & Storage, Cisco Networking (Switches, Routers, Security), and NetApp Storage (disk shelves, disk drives, Filers, NearStore, NetCache). If you don’t see the item or product you require please contact us.

Have this equipment to sell?
Depending on the age and condition of the equipment, there is a very good likelihood that we will be able to offer you cash or trade-in credit for other IT hardware. If the equipment is very old we can also assist you with properly decommissioning that gear in the most environmentally friendly way possible.

Questions?
For more information please contact 888.333.7388, or fill out the quote from above. We’d love to hear from you.
