Oracle Sun BLADE X8420 SERVER MODULE

Oracle Sun BLADE X8420 SERVER MODULE Oracle Sun BLADE X8420 SERVER MODULE SUN BLADE X8420 SERVER MODULE

REQUEST A PRICE QUOTE:

    Name*

    Phone

    Details*

    Capacity
    Number
    • 4 dual-core Opteron processors
    • 64 GB memory
    • Two hot-plug / hot swap SAS or SATA hard disks
    Processor
    Number4 dual-core CPUs per Blade
    ArchitectureDual-core AMD Opteron 800 Series
    • 2.4 GHz 8216
    • 2.6 GHz 8218
    • 2.6 GHz 8218HE, 68W low power
    • 2.8 GHz 8220
    Cache Memory1 MB L2 Cache
    Memory
    Memory TypeDDR2, 667MHz PC2-5300 ECC Registered DIMMs
    Capacities per X8420 Server Module4 DIMM slots per processor, for a maximum total of 16 slots. DIMMs are configured in 2 DIMM pairs.
    Memory DIMMs must be installed in identical pairs (from the same manufacturer and in the same capacity) for 128-bit ECC and maximum performance.
    1GB DIMMs minimum configuration of 8GB, maximum configuration of 16GB.
    2GB DIMMs minimum configuration of 16GB, maximum configuration of 32GB.
    4GB DIMMs minimum configuration of 32GB, maximum configuration of 64GB.
    Optional Storage
    DiskUp to two optional, hot swappable, hot pluggable, SATA or SAS drives per blade.
    May be configured as independent, striped (RAID 0) or mirrored (RAID 1).
    Mixing disk types (i.e. one SAS disk and one SATA disk) on same X8420 Server Module is not supported.
    Drive TypeDensitySpeedForm Factor
    SAS73 GB10,000 RPM2.5″
    SAS146 GB10,000 RPM2.5″
    SATA80 GB5,400 RPM2.5″
    Management Environment
    The Sun Blade Modular Systems have a tiered system management architecture that allows management at either the chassis level or the Server Module level.
    Common System Management for both the Chassis and the Server Module
    • Integrated Lights Out Management (ILOM) 1.1 with RKVMS (Remote Keyboard Video Mouse) is pre-installed on the CMM (Chassis Monitoring Module) and the SP (Service Processor). ILOM will run on standby power. Note: Accessing ILOM through Mozilla will require Mozilla version 1.7.5 or greater.
    • Support for Sun N1 System Manager 1.3.1.
    • Compatibility for third-party SNMP system managers with requirements for SNMP (v1, v2C, v3) and IPMI (2.0).
    • System management is consistent with Sun Fire X4100 and Sun Fire X4200 servers.
    Sun Blade Server Module Service Processor (SP)
    • Server Module management (ILOM) can be accessed directly via the dedicated DB-9 serial port located on the front of the Server Module or via the CMM.
    • Each Server Module includes an on-board (separately powered) SP that communicates with the four main processors and the rest of the Server Modules.
    • Server Module management is available even when Server Module is powered off but the Chassis is powered on.
    Standard Integrated Interfaces
    Network ManagementThe Server Module provides a DB-9 serial port. Reference the Management Environment section.
    PCI Interfaces with the Sun Blade 8000 Modular SystemIn the Sun Blade 8000 Modular System, six PCI Express interfaces per Server Module are allocated to either:
    • Two I/O PCI Express ExpressModules (EMs)
      or
    • Four Network Express Modules (NEMs)

    The Server Module currently creates 40 lanes allocated as follows:

    • 8 lanes/32Gbps allocated to each of the two EMs (16 lanes).
    • 8 lane/32Gbps allocated to each of the upper two NEMs (16 lanes).
    • 4 lane/16Gbps allocated to each of the lower two NEMs (8 lanes).
    PCI Interfaces with the Sun Blade 8000 P Modular SystemIn the Sun Blade 8000 P Modular System, two PCIe x8 lanes to the upper NEMs are supported.
    USBEach optional X8420 Server Module provides two USB 2.0 ports.
    VideoEach optional X8420 Server Module provides a VGA Video connection to the ATI Rage XL graphics chip.
    Regulations
    RoHS Compliance LevelRoHS:YL
    Batteries
    Option #Manufacturing
    Part #    		Description
    n/a150-43153V Lithium battery, RoHS:Y
    Blade
    Option #Manufacturing
    Part #    		Description
    X5064A-Z602-3715Sun Blade X8420 Server Module with 8GB Memory (8 × 1GB) and 4 CPUs (2.4 GHz, Dual Core Opteron 8216), RoHS:YL
    • 150-4315
    • 3V Lithium battery, RoHS:Y
    • 310-0030
    • CPU Heatsink, RoHS:Y
    • 371-2353
    • 1GB DDR1-667 ECC Registered DIMM, 1-Rank/512 Mbit SDRAM, RoHS:Y
    • 371-2479
    • 2.4 GHz CPU, Opteron 8216 Dual Core, F3 Stepping, 95W, RoHS:Y
    • 541-1394
    • 0MB Sun Blade X8420 Server Module, RoHS:YL
    • 501-7450
    • 0MB Sun Blade X8420 Board, RoHS:YL
    X5065A-Z602-3716Sun Blade X8420 Server Module with 16GB Memory (8 × 2GB) and 4 CPUs (2.6 GHz, Dual Core Opteron 8218), RoHS:YL
    • 150-4315
    • 3V Lithium battery, RoHS:Y
    • 310-0030
    • CPU Heatsink, RoHS:Y
    • 371-1832
    • 2.6 GHz CPU, Opteron 8218 Dual Core, F2 Stepping, 95W, RoHS:Y
    • 371-2354
    • 2GB DDR2-667 ECC Registered DIMM, 2-Rank/512 Mbit SDRAM, RoHS:Y
    • 541-1394
    • 0MB Sun Blade X8420 Server Module, RoHS:YL
    • 501-7450
    • 0MB Sun Blade X8420 Board, RoHS:YL
    X5066A-Z602-3300Sun Blade X8420 Server Module with 32GB Memory (8 × 4GB) and 4 CPUs (2.8 GHz, Dual Core Opteron 8220), RoHS:YL
    • 150-4315
    • 3V Lithium battery, RoHS:Y
    • 310-0030
    • CPU Heatsink, RoHS:Y
    • 371-2355
    • 4GB DDR2-667 ECC Registered DIMM, 2-Rank/1 Gbit SDRAM, RoHS:Y
    • 371-2480
    • 2.8 GHz CPU, Opteron 8220 Dual Core, F3 Stepping, 95W, RoHS:Y
    • 541-1394
    • 0MB Sun Blade X8420 Server Module, RoHS:YL
    • 501-7450
    • 0MB Sun Blade X8420 Board, RoHS:YL
    X5067A-Z594-4618Sun Blade X8420 Server Module, 68W (low power) with 16GB Memory (8 × 2GB) and 4 CPUs (2.6 GHz, Dual Core Opteron 8218HE), RoHS:YL
    • 150-4315
    • 3V Lithium battery, RoHS:Y
    • 310-0030
    • CPU Heatsink, RoHS:Y
    • 371-2354
    • 2GB DDR2-667 ECC Registered DIMM, 2-Rank/512 Mbit SDRAM, RoHS:Y
    • 371-2507
    • 2.6 GHz CPU, Opteron 8218HE Dual Core, F3 Stepping, 68W, RoHS:Y
    • 541-1394
    • 0MB Sun Blade X8420 Server Module, RoHS:YL
    • 501-7450
    • 0MB Sun Blade X8420 Board, RoHS:YL
    CPU Module
    Option #Manufacturing
    Part #    		Description
    n/a310-0030CPU Heatsink, RoHS:Y
    n/a371-18322.6 GHz CPU, Opteron 8218 Dual Core, F2 Stepping, 95W, RoHS:Y
    n/a371-24792.4 GHz CPU, Opteron 8216 Dual Core, F3 Stepping, 95W, RoHS:Y
    n/a371-24802.8 GHz CPU, Opteron 8220 Dual Core, F3 Stepping, 95W, RoHS:Y
    n/a371-25072.6 GHz CPU, Opteron 8218HE Dual Core, F3 Stepping, 68W, RoHS:Y
    Disks
    Option #Manufacturing
    Part #    		Description
    XRB-SS2CD-146G10KZ540-7151146GB – 10000 RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks and brackets, RoHS:Y
    • 390-0324
    • Seagate ST9146802SS [ST914602SSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0375
    • Fujitsu MBB2147RC [MBB2147RCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0377
    • Hitachi HUC101414CSS300 [H101414SCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-0239
    • Nemo Bracket, RoHS:Y
    • 541-3004
    • Nemo Bracket with Insulator, RoHS:Y
    XRB-SS2CD-73G10KZ540-661173GB 10000 RPM SAS, Disk Assembly with 1 of the following disks and brackets, RoHS:Y
    • 390-0213
    • Seagate ST973401SS [ST973401SSUN72G]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0285
    • Fujitsu MAY2073RC [MAY2073RCSUN72]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0323
    • Seagate ST973402SS [ST973402SSUN72G]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0374
    • Fujitsu MBB2073RC [MBB2073RCSUN72G]
      (73.4GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0376
    • Hitachi HUC101473CSS300 [H101473SCSUN72G]
      (73.4GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-0239
    • Nemo Bracket, RoHS:Y
    • 541-3004
    • Nemo Bracket with Insulator, RoHS:Y
    XRB-ST3CD-200G5K540-7554200GB – 5400 RPM SATA Disk Assrmbly with 1 bracket and 1 of the following disks, RoHS:Y
    • 390-0407
    • Fujitsu MHY2200BS [MHY2200BSSUN200G]
      (200GB – 5400 RPM – SATA Disk), RoHS:Y
    • 541-3004
    • Nemo Bracket with Insulator, RoHS:Y
    XRB-ST3CD-80G5KZ541-111580GB – 5400 RPM SATA, Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
    • 390-0250
    • Fujitsu MHV2080BS [MHV5480SBSUN80G]
      (80GB – 5400 RPM – SATA Disk), RoHS:Y
    • 541-0239
    • Nemo Bracket, RoHS:Y
    Memory
    Option #Manufacturing
    Part #    		Description
    X5093A-Z2 GB (2 × 1GB) DDR1-667 ECC Registered DIMMs, RoHS:YL
    371-23531GB DDR1-667 ECC Registered DIMM, 1-Rank/512 Mbit SDRAM, RoHS:Y
    X5094A-Z4 GB (2 × 2GB) DDR2-667 ECC Registered DIMMs, RoHS:YL
    371-23542GB DDR2-667 ECC Registered DIMM, 2-Rank/512 Mbit SDRAM, RoHS:Y
    X5095A-Z8 GB (2 × 4GB) DDR2-667 ECC Registered DIMMs, RoHS:YL
    371-23554GB DDR2-667 ECC Registered DIMM, 2-Rank/1 Gbit SDRAM, RoHS:Y
    n/a540-72262GB (2 × 1GB) Memory, RoHS:Y
    • 371-2353
    • 1GB DDR1-667 ECC Registered DIMM, 1-Rank/512 Mbit SDRAM, RoHS:Y
    n/a540-72274GB (2 × 2GB) Memory, RoHS:Y
    • 371-2354
    • 2GB DDR2-667 ECC Registered DIMM, 2-Rank/512 Mbit SDRAM, RoHS:Y
    n/a540-72288GB (2 × 4GB) Memory, RoHS:Y
    • 371-2355
    • 4GB DDR2-667 ECC Registered DIMM, 2-Rank/1 Gbit SDRAM, RoHS:Y
