IBM pSeries 9110-510 p510 server from Greentec Systems

IBM Model: 9110-510 Server, Series – p510

• • Greentec Systems Server Highlights
    Outstanding value for entry UNIX servers
    Powerful, symmetric multiprocessing (SMP) on demand server
    2U rack-mount configuration
    One 1-way or 2-way, state-of-the-art, 64-bit POWER5 processor
    1.5 GHz processor on the p5-510 Express
    1.65 GHz processor on the p5-510
    Performance and capacity needed by demanding on demand applications
    Up to 32 GB of memory
    Up to 587.2 GB of internal disk storage
    Four hot-swap disk bays and three PCI-X slots for feature expandability
    One slimline media bay for DVD-ROM or DVD-RAM
    Dynamic logical partitioning (LPAR)
  • Model Summary Matrix
    Model: 510
    Processor Type: POWER5
    Clock Rate: 1.5 GHz and 1.65 GHz
    System Memory: 512MB to 32GB
    Internal Storage: 36.4GB to 587.2GB
    Slots: 3
    Bays: 5
  • Physical Specifications
    Width: 483 mm (19.0 in)
    Depth: 686 mm (27.0 in)
    Height: 89 mm (3.5 in)
    Weight: Minimum configuration: 16.8 kg (37 lb)
    Weight: Maximum configuration: 23.2 kg (51 lb)

Feature Codes



0050 – IBM Express Seller Indicator

0265 – AIX Partition Specify

0266 – Linux Partition Specify

0705 – Intgr w Data Retention Soln — IBM TotalStorage Data Retention Solution

0983 – Assembled in USA

0986 – CCS Customer Service Specify (US)

1820 – PCI-X Dual-port 4x IB HCA

1835 – 3 meter 4x IB Cable

1836 – 8 meter 4x IB Cable

1839 – 1.5 meter 4x IB Cable

1955 – 36/72gb 4mm DAT HOT SWAP LVD TAPE DRIVE

2114 – PCI SCSI Adapter 16-Bit Differential External Y Cable

2118 – Converter Cable, VHDCI to P, Mini-68 pin to 68 pin, 0.3M

2425 – 2.5M 16-bit SCSI-2 System to System Cable

2456 – LC-SC Fibre Channel Converter Cable

2459 – LC-SC 62.5-Micron Fiber Converter Cable

2591 – External USB 1.44 MB Diskette Drive

2640 – IDE Slimline DVD-ROM Drive

2738 – 2 Port USB PCI Adapter

2849 – POWER GXT135P Graphics Accelerator with Digital Support

2861 – ARTIC960Hx 4-Port EIA-232 Cable

2863 – ARTIC960Hx 4-Port X.21 Cable

2864 – ARTIC960Hx 4-Port V.35 (DTE) Cable

2934 – Asynchronous Terminal/Printer Cable EIA-232

2936 – Asynchronous Cable EIA-232/V.24

2943 – 8-Port Asynchronous Adapter EIA-232/RS-422, PCI bus

2944 – 128-Port Asynchronous Controller, PCI bus

2947 – IBM ARTIC960Hx 4-Port Multiprotocol PCI Adapter

2951 – 2-Port Cable, V.24 / EIA-232

2952 – 2-Port Cable, V.35

2953 – 2-Port Cable, V.36 / EIA-449

2954 – 2-Port Cable, X.21

2962 – 2-Port Multiprotocol PCI Adapter

3124 – Serial to Serial Port Cable for Drawer/Drawer

3125 – Serial to Serial Port Cable for Rack/Rack

3274 – 73.4 GB 10,000 RPM Ultra3 SCSI Disk Drive Assembly

3275 – 146.8 GB 10,000 RPM Ultra3 SCSI Disk Drive Assembly

3277 – 36.4 GB 15,000 RPM Ultra3 SCSI Disk Drive Assembly

3278 – 73.4 GB 15,000 RPM Ultra3 SCSI Disk Drive Assembly

3279 – 146.8 GB 15,000 RPM Ultra320 SCSI Disk Drive Assembly

3578 – 300 GB 10,000 RPM Ultra320 SCSI Disk Drive Assembly

3636 – L200P Flat Panel Monitor

3637 – IBM T541H/L150p 15″ TFT Color Monitors, Business Black, Captured Cable

3638 – IBM C220p 21-inch Color Monitor, Business Black, and Cable

3639 – IBM ThinkVision L170p Flat Panel Monitor

3640 – IBM ThinkVision L171p Flat Panel Monitor

3641 – IBM T115 Flat Panel Monitor

3642 – ThinkVision L191p Flat Panel Monitor

3643 – IBM T120 Flat Panel Monitor

3644 – IBM T119 Flat Panel Monitor

3645 – IBM T117 Flat Panel Monitor

3752 – Service Package

3925 – Serial Port Converter Cable, 9-Pin to 25-Pin

3926 – Asynch Printer/Terminal Cable, 9-pin to 25-pin, 4M

3927 – Serial Port Null Modem Cable, 9-pin to 9-pin, 3.7M

3928 – Serial Port Null Modem Cable, 9-pin to 9-pin, 10M

4242 – 6 Foot Extender Cable for Displays (15 pin D-shell to 15 pin D-shell)

4256 – Extender Cable – USB Keyboards, 2M

4443 – 512MB (2x256MB) DIMMs, 208-pin, 266 MHz DDR SDRAM

4444 – 1024MB (4x256MB) DIMMs, 208-pin, 266 MHz DDR SDRAM

4445 – 4096MB (4x1024MB) DIMMs, 208-pin, 8NS DDR SDRAM

4447 – 2048MB (4x512MB) DIMMs, 208-pin, 8NS DDR SDRAM

4449 – 8192MB (4x2048MB) DIMMs, 208-pin, 8NS DDR SDRAM

4450 – 16GB (4x4096MB) DIMMs, 208-pin, 266 MHz DDR Stacked SDRAM

4650 – Rack Indicator- Not Factory Integrated

4651 – Rack Indicator, Rack #1

4652 – Rack Indicator, Rack #2

4653 – Rack Indicator, Rack #3

4654 – Rack Indicator, Rack #4

4655 – Rack Indicator, Rack #5

4656 – Rack Indicator, Rack #6

4657 – Rack Indicator, Rack #7

4658 – Rack Indicator, Rack #8

4659 – Rack Indicator, Rack #9

4660 – Rack Indicator, Rack #10

4661 – Rack Indicator, Rack #11

4662 – Rack Indicator, Rack #12

4663 – Rack Indicator, Rack #13

4664 – Rack Indicator, Rack #14

4665 – Rack Indicator, Rack #15

4666 – Rack Indicator, Rack #16

4691 – Rack Status Beacon Cable, Junction Box To Drawer Or StatusBeacon

4692 – Rack Status Beacon Cable, Junction Box Daisy Chain

4764 – PCI-X Cryptographic Coprocessor (FIPS 4)

4962 – 10/100 Mbps Ethernet PCI Adapter II

5001 – Customer Service Specify

5005 – Software Preinstall

5700 – IBM Gigabit Ethernet-SX PCI-X Adapter

5701 – IBM 10/100/1000 Base-TX Ethernet PCI-X Adapter

5703 – PCI-X Dual Channel Ultra320 SCSI RAID Adapter

5706 – IBM 2-Port 10/100/1000 Base-TX Ethernet PCI-X Adapter

5707 – IBM 2-Port Gigabit Ethernet-SX PCI-X Adapter

5712 – PCI-X Dual Channel Ultra320 SCSI Adapter

5713 – 1 Gigabit iSCSI TOE PCI-X on Copper Media Adapter

5714 – 1 Gigabit iSCSI TOE PCI-X on optical media Adapter

5716 – 2 Gigabit Fibre Channel PCI-X Adapter

5718 – 10 Gigabit Ethernet-SR PCI-X Adapter

5719 – IBM 10 Gigabit Ethernet-LR PCI-X Adapter

5721 – 10 Gb Ethernet-SR PCI-X 2.0 DDR Adapter

5722 – 10 Gb Ethernet-LR PCI-X 2.0 DDR Adapter

5723 – 2 Port Asynchronous EIA-232 PCI Adapter

5736 – PCI-X DDR Dual Channel Ultra320 SCSI Adapter

5737 – PCI-X DDR Dual Channel Ultra320 SCSI RAID Adapter

5740 – 4-Port 10/100/1000 Base-TX PCI-X Adapter

5751 – IBM 4.7 GB IDE Slimline DVD-RAM Drive

5758 – 4 Gb Single-Port Fibre Channel PCI-X 2.0 DDR Adapter

5759 – 4 Gb Dual-Port Fibre Channel PCI-X 2.0 DDR Adapter

5951 – Full Width Quiet Touch Keyboard — USB, US English, #103P

5952 – Full Width Quiet Touch Keyboard — USB, French, #189

5953 – Full Width Quiet Touch Keyboard — USB, Italian, #142

5954 – Full Width Quiet Touch Keyboard — USB, German/Austrian, #129

5955 – Full Width Quiet Touch Keyboard — USB, UK English, #166P

5956 – Full Width Quiet Touch Keyboard — USB, Spanish, #172

5957 – Full Width Quiet Touch Keyboard — USB, Japanese, #194

5958 – Full Width Quiet Touch Keyboard — USB, BrazilianPortuguese, #275

5959 – Full Width Quiet Touch Keyboard — USB, Hungarian, #208

5960 – Full Width Quiet Touch Keyboard — USB, Korean, #413

5961 – Full Width Quiet Touch Keyboard — USB, Chinese, #467

5962 – Full Width Quiet Touch Keyboard — USB, French Canadian, #445

5963 – Full Width Quiet Touch Keyboard — USB, Canadian French, #058

5964 – Full Width Quiet Touch Keyboard — USB, Belgian/French, #120

5965 – Full Width Quiet Touch Keyboard — USB, Swedish/Finnish, #153

5966 – Full Width Quiet Touch Keyboard — USB, Danish, #159

5967 – Full Width Quiet Touch Keyboard — USB, Bulgarian, #442

5968 – Full Width Quiet Touch Keyboard — USB, Swiss/French/German, #150

5969 – Full Width Quiet Touch Keyboard — USB, Norwegian,#155

5970 – Full Width Quiet Touch Keyboard — USB, Dutch, #143

5971 – Full Width Quiet Touch Keyboard — USB, Portuguese, #163

5972 – Full Width Quiet Touch Keyboard — USB, Greek, #319

5973 – Full Width Quiet Touch Keyboard — USB, Hebrew, #212

5974 – Full Width Quiet Touch Keyboard — USB, Polish, #214

5975 – Full Width Quiet Touch Keyboard — USB, Slovakian, #245

5976 – Full Width Quiet Touch Keyboard — USB, Czech, #243

5977 – Full Width Quiet Touch Keyboard — USB, Turkish, #179

5978 – Full Width Quiet Touch Keyboard — USB, LA Spanish, #171

5979 – Full Width Quiet Touch Keyboard — USB, Arabic, #253

5980 – Full Width Quiet Touch Keyboard — USB, Thai, #191

5981 – Full Width Quiet Touch Keyboard — USB, Russian, #443

5982 – Full Width Quiet Touch Keyboard — USB, Slovenian, #234

5983 – Full Width Quiet Touch Keyboard — USB, US EnglishInternational, #103P

6230 – Advanced SerialRAID Plus Adapter

6231 – 128 MByte DRAM Option Card

6235 – 32 MByte Fast-Write Cache Option Card

6239 – 2 Gigabit Fibre Channel PCI-X Adapter

6458 – Power Cable — Drawer to IBM PDU, 14-foot, 250V/10A

6460 – Power Cord (14-foot), Drawer to OEM PDU (125V, 15A), Plug Type #4

6469 – Power Cord (14-foot), Drawer to OEM PDU (250V, 15A), United States, Plug Type #5

6470 – Power Cord – United States/Canada

6471 – Power Cord – Brazil (125V, 15A)

6472 – Power Cord – Belgium, Finland, France, Indonesia, Korea (250V, 16A)

6473 – Power Cord – Denmark (250V, 10A)

6474 – Power Cord – United Kingdom (250V, 13A)

6475 – Power Cord – Israel (250V, 6-16A)

6476 – Power Cord – Switzerland (250V, 10A)

6477 – Power Cord – South Africa/Pakistan (250V, 16A)

6478 – Power Cord – Italy/Chile (250V, 10A and 16A)

6479 – Power Cord – Australia/New Zealand/Argentina (250V, 10A)

6487 – Power Cord – Thailand (250V, 15A)

6488 – Power Cord – Uruguay (250V, 10A)

6493 – Power Cord – China (250V,10A)

6494 – Power Cord – India (250V/10A)

6495 – Power Cord – Brazil (250V,10A)

6496 – Power Cord – Korea (250V, 10A)

6651 – Power Cord (9-foot), To Wall/OEM PDU, (125V, 15A), Plug Type #75

6659 – Power Cord (9-foot), To Wall/OEM PDU, (250V, 15A), Plug Type #76

6660 – Power Cord (14-foot), Drawer To OEM PDU (125V, 15A), Plug Type #59 (DENAN marking)

6669 – Power Cord (14-foot), Drawer to OEM PDU, (250V, 15A), Plug Type #57 (DENAN marking)

6670 – Power Cord (6-foot), To Wall (125V, 15A), Plug Type #59 (Denan marking)

6671 – Power Cord (9-foot), Drawer to IBM PDU, 250V/10A

6672 – Power Cord (5-foot), Drawer to IBM PDU, 250V/10A

6680 – Power Cord (9-foot) , To Wall/OEM PDU, (250V, 10A), Plug Type #6, Insulated

6687 – Power Cord (6-foot),To Wall, (250V, 15A), Plug Type #5 (Denan marking)

7305 – AAP Software Pre-Install Indicator

7801 – Ethernet Cable, 6M, Hardware Management Console to System Unit

7802 – Ethernet Cable, 15M, Hardware Management Console to System Unit

8131 – 128-Port Asynchronous Controller Cable, 4.5 Meter

8132 – 128-Port Asynchronous Controller Cable, 23cm (9-Inch)

8133 – RJ-45 to DB-25 Converter Cable

8136 – Rack Mountable Remote Asynchronous Node 16-Port EIA-232

8137 – Enhanced Remote Asynchronous Node 16-Port EIA-232

8800 – Quiet Touch Keyboard – USB, Business Black, US English, #103P

8827 – Quiet Touch Keyboard – USB, Business Black, Turkish, #179

8829 – Quiet Touch Keyboard – USB, Business Black, LA Spanish, #171

8830 – Quiet Touch Keyboard – USB, Business Black, Arabic, #238

8833 – Quiet Touch Keyboard – USB, Korean, #413

8834 – Quiet Touch Keyboard – USB, Business Black, Chinese/US, #467

8835 – Quiet Touch Keyboard – USB, Business Black, French Canadian, #445

8836 – Quiet Touch Keyboard – USB, Business Black, Thai, #191

8838 – Quiet Touch Keyboard – USB, Business Black, Russian, #443

8839 – Quiet Touch Keyboard – USB, Business Black, Yugoslavian/Latin, #105

8840 – Quiet Touch Keyboard – USB, Business Black, US English (EMEA), #103P

8841 – Mouse – Business Black with Keyboard Attachment Cable

9004 – Southern Hemisphere Designator for Monitors

9169 – Order Routing Indicator – System Plant

9300 – Language Group Specify – US English

                     1
