HP ProLiant DL360 Gen8 G8 2 x SIX-CORE XEON, 384Gb
RAM, RAID
General
| Type | Server |
| Recommended Use | Small business, corporate business |
| Product Form Factor | Rack-mountable – 1U |
| Server Scalability | 2-way |
| Front Accessible Bays Qty | 1 |
| Hot-Swap Bays Qty | 8 |
| Localisation | Europe |
Processor / Chipset
| CPU | Intel Xeon E5-2630 / 2.3 GHz |
| Number of Cores | 6-core |
| 64-bit Computing | Yes |
| CPU Qty | 2 |
| Max CPU Qty | 2 |
| CPU Upgradability | Upgradable |
| Chipset Type | Intel C600 |
Cache Memory
| Installed Size | L3 Cache – 15 MB |
| Cache Per Processor | 15 MB |
RAM
| Installed Size | 384GB RAM |
| Technology | DDR3 SDRAM |
| Memory Speed | 1333 MHz |
| Memory Specification Compliance | PC3-10600 |
| Form Factor | DIMM 240-pin |
| Features | Registered, quad channel memory architecture, HP SmartMemory |
| |
| RAM Supported | PC3-12800 – 384 GB – registered ? PC3-10600 – 768 GB – ? PC3-10600 – 128 GB – unbuffered – Advanced ECC |
Hard Drive
Storage Controller
| Type | 1 x RAID – plug-in card – PCI Express 3.0 x8 |
| Controller Interface Type | SATA-600 / SAS 2.0 |
| Storage Controller Name | Smart Array P420i |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 10, RAID 50 |
| Buffer Size | 1 GB |
Card Reader
| Type | Card reader |
| Supported Flash Memory Cards | SD Memory Card |
Monitor
Graphics Controller
| Type | Integrated |
| Graphics Processor | Matrox G200 |
| Video Interfaces | VGA |
Input Device
Networking
| Type | Integrated |
| Ethernet Ports | 4 x Gigabit Ethernet |
| Ethernet Controller | HP 331FLR |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Protocol | IPMI 2.0, SMASH CLP |
| Remote Management Controller | Integrated Lights-Out 4 |
| Features | Wake on LAN (WoL), PXE support |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3ad (LACP) |
Expansion / Connectivity
| Bays | 1 (total) / 1 (free) x external 5.25″ x 1/2H ? 8 (total) / 8 (free) x hot-swap 2.5″ SFF |
| Slots | 24 (total) / 20 (free) x DIMM 240-pin ? 2 (total) / 1 (free) x CPU ? 1 (total) / 1 (free) x PCIe 3.0 x16 – half-length, full-height ? 1 (total) / 1 (free) x PCIe 3.0 x8 – low-profile |
| Interfaces | 1 x serial ? 1 x VGA ? 4 x LAN (Gigabit Ethernet) ? 1 x HP iLO ? 6 x USB 2.0 ( 2 front, 4 rear ) |
Miscellaneous
| Features | Administrator password, power-on password, keyboard password, serial port I/O control, quick lock, 92% efficiency power supply |
| Compliant Standards | ACPI 2.0b, FCC Class A certified, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, EN55024, CISPR 22, FCC CFR47 Part 15, IEC 60950-1, EN 60950-1, BSMI CNS 13438 |
Power
| Device Type | Power supply – hot-plug |
| Power Redundancy | Optional |
| Power Redundancy Scheme | 1+1 (with optional power supply) |
| Installed Qty | 1 |
| Max Supported Qty | 2 |
| Voltage Required | AC 120/230 V ( 50/60 Hz ) |
| Power Provided | 460 Watt |
| 80 PLUS Certification | 80 PLUS Platinum |
Operating System / Software
| OS Certified | SuSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux, Oracle Solaris |
