Oracle Sun ZFS Storage 7120 Server

Oracle Sun ZFS Storage 7120 Server Oracle Sun ZFS Storage 7120 Server 7120 front callout

REQUEST A PRICE QUOTE:

    Name*

    Phone

    Details*


    Brand: Oracle / Sun Microsystems
    Condition: Refurbished and new (limited availability)
    Availability: Contact
    Shipping Area: Worldwide to most countries
    Shipping Method: Fedex (most orders), UPS, DHL, Freight Courier
    Price: Please use the quote form above for quick pricing
    Payment: Credit Card, Check, Net Terms (oac), Wire Transfer (required for international orders)
    Guarantee: All items are tested by Oracle trained technicians & backed by a 100% warranty
    Questions? Don’t hesitate to contact us with any questions regarding compatibility or other product info and requests. Our website represents only a fraction of our full inventory. Please reach out with your full requirements



    Specs and Information:



    Processor
    Number 1 Intel Quad-Core
    Architecture Type: Intel Xeon Quad-Core Processor
    CPUs Intel Xeon 2.40 GHz Quad-Core E5620 (12MB L3, 80W)
    Main Memory
    Capacities Total DIMM slots: 6 (3 DIMM slots per CPU)
    Note: Additional DIMM slots are available but not populated in the 7120 standard configuations.
    DIMM type: DDR3 1333MHz Registered DIMMs
    DIMM size: 4GB 1333MHz
    Maximum capacity: 24GB (when 6 slots are populated with 4GB DIMMs) or 48GB (when 6 slots are populated with 8GB DIMMs)
    Standard Integrated Interfaces
    Network Four 10/100/1000 Base-T Ethernet Ports
    Network Management One dedicated 10/100Base-T Ethernet port
    Serial Management One dedicated TIA/EIA-232-F asynchronous RJ45 port
    USB Front: Two USB 2.0 ports
    Rear: Two USB 2.0 ports
    Internal: One USB 2.0 port
    PCI Expansion Slots Four internal MD2 low profile 8-lane PCI Express slots (all with x8 mechanical connectors)
    Internal Mass Storage
    Disks Up to 12 hot-swappable disks in the Sun Fire X4270 M2, 2 hot-swappable disks in the Sun Fire X4270 M2 Rear Disk Module & 24 hot-swappable disks in the Sun Disk Shelf 24×3.5″ SAS-2, Oracle Storage DE2-24C and Oracle Storage DE2-24P
    Part Number Part Description Form Factor Supported In
    Disks – ZFS Storage 7120 (X4270 M2 Server Head – Coral bracket)
    7011095[C] 73GB Solid State SAS Disk Assembly 3.5″ ZFS Storage 7120 (X4270 M2 Server Head)
    7047869[C] 73GB Solid State SAS-2 Disk Assembly 3.5″ ZFS Storage 7120 (X4270 M2 Server Head)
    7051739[C] 73GB Solid State SAS-2 Disk Assembly 3.5″ ZFS Storage 7120 (X4270 M2 Server Head)
    7024415[C] 300GB – 15000 RPM SATA Disk Assembly 3.5″ ZFS Storage 7120 (X4270 M2 Server Head)
    542-0166 [C] 600GB -15000 RPM Disk Drive Assembly 3.5″ ZFS Storage 7120 (X4270 M2 Server Head)
    542-0428 [C] 600GB – 15000 Disk Drive Assembly 3.5″ ZFS Storage 7120 (X4270 M2 Server Head)
    542-0392 [C] 1TB – 7200 Disk Drive Assembly 3.5″ ZFS Storage 7120 (X4270 M2 Server Head)
    540-7824 [C] 1TB – 7200 Disk Drive Assembly 3.5″ ZFS Storage 7120 (X4270 M2 Server Head)
    542-0247 [C] 2TB – 7200 Disk Drive Assembly 3.5″ ZFS Storage 7120 (X4270 M2 Server Head)
    7040582[C] 2TB – 7200 Disk Drive Assembly 3.5″ ZFS Storage 7120 (X4270 M2 Server Head)
    7010036[C] 3TB – 7200 Disk Drive Assembly 3.5″ ZFS Storage 7120 (X4270 M2 Server Head)
    Disks – ZFS Storage 7120 (X4270 M2 Server Head (Rear Disk Module) – Marlin bracket)
    542-0371 [C] 500GB – 7200 RPM SATA Disk Assembly 2.5″ ZFS Storage 7120 (X4270 M2 Server Head)
    7042768[C] 500GB – 10000 RPM SATA Disk Assembly 2.5″ ZFS Storage 7120 (X4270 M2 Server Head)
    Disks – Disk Shelf 24×3.5′ SAS-2 (Chassis PN#540-7980 – Stingray bracket)
    542-0191 [C] 300GB – 15000 RPM SAS Disk Drive Assembly 3.5″ Disk Shelf 24×3.5′ SAS-2 (Chassis PN#540-7980)
    542-0179 [C] 600GB – 15000 RPM SAS Disk Drive Assembly 3.5″ Disk Shelf 24×3.5′ SAS-2 (Chassis PN#540-7980)
    542-0340 [C] 1TB – 7200 RPM SAS Disk Drive Assembly 3.5″ Disk Shelf 24×3.5′ SAS-2 (Chassis PN#540-7980)
    542-0274 [C] 2TB – 7200 RPM SAS Disk Drive Assembly 3.5″ Disk Shelf 24×3.5′ SAS-2 (Chassis PN#540-7980)
    Disks – Disk Shelf 24×3.5′ SAS-2 (Chassis PN#7041264 – Stingray bracket)
    7047155[C] 300GB – 15000 RPM SAS Disk Drive Assembly 3.5″ Disk Shelf 24×3.5′ SAS-2 (Chassis PN#7041264)
    542-0179 [C] 600GB – 15000 RPM SAS Disk Drive Assembly 3.5″ Disk Shelf 24×3.5′ SAS-2 (Chassis PN#7041264)
    7047035[C] 600GB – 15000 RPM SAS Disk Drive Assembly 3.5″ Disk Shelf 24×3.5′ SAS-2 (Chassis PN#7041264)
    7042964[C] 2TB – 7200 RPM SAS Disk Drive Assembly 3.5″ Disk Shelf 24×3.5′ SAS-2 (Chassis PN#7041264)
    7010135[C] 3TB – 7200 RPM SAS Disk Drive Assembly 3.5″ Disk Shelf 24×3.5′ SAS-2 (Chassis PN#7041264)
    Disks – Storage DE2-24P – Evo bracket
    7094126[C] 200GB – Solid State SAS Disk Assembly 2.5″ DE2-24P
    7044283[C] 300GB – 10000 RPM SAS Disk Drive Assembly 2.5″ DE2-24P
    7044376[C] 900GB – 10000 RPM SAS Disk Drive Assembly 2.5″ DE2-24P
    Disks – Storage DE2-24C – Heron bracket
    7094120[C] 200GB – Solid State SAS Disk Assembly 3.5″ DE2-24C
    7044391[C] 3TB – 7200 RPM SAS Disk Drive Assembly 3.5″ DE2-24C
    7066831[C] 4TB – 7200 RPM SAS Disk Drive Assembly 3.5″ DE2-24C
    7301592[C] 8TB – 7200 RPM SAS Disk Drive Assembly 3.5″ DE2-24C
    Power Supplies
    Dual redundant, hot swappable power supplies
    (Power supply rating output = 1200W)
    (UL Maximum AC input = 1200W x 1.33 efficiency = 1596W)
    (13.0 Amps Max current AC RMS)
    Environment
    Power Consumption Online power calculator
    AC power 100-120/200-240 V AC, (50-60 Hz)
    Temperature Single, non-rack system:
    Operating: 5° C to 35° C (41° F to 95° F)
    Nonoperating: -40° C to 70° C (-40° F to 158° F)
    Humidity Single, non-rack system:
    Operating: 10% to 90% relative humidity noncondensing, 38° C (100.4° F) max wet bulb
    Nonoperating: up to 93% relative humidity noncondensing
    Altitude Single, non-rack system:
    Operating: Up to 3048 m (10000 ft.), maximum ambient temperature is derated by 1° C per 300 m above 900 m
    Nonoperating: Up to 12,000 m (40,000 ft.)
    Regulations
    Meets or exceeds the following requirements:
    Safety UL/cUL, CE, BSMI, GOST-R, S-Mark, CSA C22.2 No. 60950-03
    RFI/EMI FCC CFR 47 Part 15 Class A, EN55022 Class A, EN 61000-3-2, EN61000-3-3, EN 300-386
    Immunity EN55024, EN300-386
    Certifications Safety: UL/cUL, UL DEMKO, CE, BSMI, CCC, GOST-R, S-Mark
    EMC: CE, FCC, VCCI, ICES, C-Tick, MIC, CCC, GOST-R, BSMI Class A
    Other Complies with WEEE Directive (2002/96/EC) and RoHS Directive (2002/95/EC)
    Dimensions and Weight
    Height 87.12 mm (3.43 in.)
    Width 425.45 mm (16.75 in.)
    Depth 762.0 mm (30 in.)
    Weight 29.54 kg (65 lb.)
    Rack Mounting
    Sun ZFS Storage 7120 Racks Racks are as follows:
    • Sun Rack II 1042 (Redwood)
    • Sun Rack II 1242 (Redwood)
    Array Controller
    Option # Manufacturing
    Part #
    Description Previous
    Part #
    n/a 7043628 [C] 6Gbps SAS-2 I/O Controller Module n/a
    n/a 7045305 [C] 6Gbps SAS-2 Interface Module (SIM FW 3527) 7014946 [C] [S]
    n/a 7053644 [C] 6Gbps SAS-2 Interface Module (SIM FW 3529) 7045305 [C]
    n/a 542-0194 [C] [S] 6Gbps SAS-2 Interface Module (SIM FW 3520 or 3524) n/a
    n/a 7014946 [C] [S] 6Gbps SAS-2 Interface Module (SIM FW 3524 or 3527) 542-0194 [C] [S]
    NOTE: 6Gbps SAS-2 Interface Module (SIM) PN#7043628 is used in the Oracle Storage DE2-24C and DE2-24P as part of the Sun ZFS Storage 7120.
    NOTE: 6Gbps SAS-2 Interface Module (SIM) PN#542-0194, PN#7014946, PN#7045305 and PN#7053643 are used in the OPTIONAL Sun Disk Shelf 24×3.5″ SAS-2 as part of the Sun ZFS Storage 7120.
    Batteries
    Option # Manufacturing
    Part #
    Description Previous
    Part #
    n/a 150-3993 [C] 3V Lithium Coin Cell Battery n/a
    CPU Module
    Option # Manufacturing
    Part #
    Description Previous
    Part #
    n/a 371-4885 [F] 2.4GHz Intel Quad-Core Xeon E5620, 12MB, 80W n/a
    n/a 541-3310 [F] Xeon Heatsink w/Grease n/a
    • 240-6751
    • Spring Screw
    n/a
    • 310-0211
    • Pre-greased Heatsink
    n/a
    Cables
    Option # Manufacturing
    Part #
    Description Previous
    Part #
    XTA-2.0M-SAS-N 530-3883 [C] 4X Mini SAS Cable, SFF-8088 to SFF-8088, 2M n/a
    n/a 530-3888 Hard Disk Drive Power Cable n/a
    n/a 560-2952 [F] Cable Kit n/a
    • 530-4245
    • 12-Slot Backplane Power Cable
    n/a
    • 530-4458
    • 24-Slot Backplane Power Cable
    n/a
    • 530-4459
    • 12/24-Slot Backplane Signal Cable
    n/a
    • 530-4471
    • Fan Signal Cable
    n/a
    • 530-4488
    • Fan Power Cable
    n/a
    NOTE: PN#530-3883 is used to connect the Sun ZFS Storage 7120 to the Disk Shelf 24×3.5″ SAS-2.
    Communication
    Option # Manufacturing
    Part #
    Description Previous
    Part #
    X4242A 375-3696 [C] Dual 40Gbps InfiniBand 4x QDR PCI Express Low Profile Host Channel Adapter n/a
    7092767 [C] Dual 40Gbps InfiniBand 4x QDR PCI Express Low Profile Host Channel Adapter n/a
    X4237A-N [S] 375-3606 [C] Sun Dual Port 40Gb/sec 4x Infiniband QDR Host Channel Adapter PCI Express n/a
    n/a 542-0298 [C] Cluster Heartbeat Assembly n/a
    • 511-1496
    • Cluster Heartbeat Card
    n/a
    • 541-4350
    • EMI Gasket
    n/a
    n/a 7056175 [C] Cluster Heartbeat Assembly 542-0298 [C]
    • 511-1496
    • Cluster Heartbeat Card
    n/a
    • 541-4350
    • EMI Gasket
    n/a
    n/a 7089470 [C] Cluster Heartbeat Assembly 7056175 [C]
    • 541-4350
    • EMI Gasket
    n/a
    • 7087050
    • Cluster Heartbeat Card
    n/a
    Disk Backplane
    Option # Manufacturing
    Part #
    Description Previous
    Part #
    n/a 541-4235 Rear Disk Module Assembly n/a
    • 501-7843 [F]
    • 2-Slot 2.5″ Disk Backplane
    n/a
    • 541-4186
    • Rear Disk Bracket Assembly
    n/a
    n/a 541-4363 [F] 12-Slot 3.5″ Disk Backplane Assembly n/a
    • 341-5083
    • Mounting Bracket
    n/a
    • 511-1593
    • 12-Slot 3.5″ Disk Backplane
    n/a
    n/a 7049238 [F] 12-Slot 3.5″ Disk Backplane Assembly 541-4363 [F]
    • 341-5083
    • Mounting Bracket
    n/a
    • 7049234
    • 12-Slot 3.5″ Disk Backplane
    n/a
    n/a 7057207 Rear Disk Module Assembly 541-4235
    • 541-4186
    • Rear Disk Bracket Assembly
    n/a
    • 7049231 [F]
    • 2-Slot 2.5″ Disk Backplane
    501-7843 [F]
    Disks
    Option # Manufacturing
    Part #
    Description Previous
    Part #
    7111897 7301592 [C] 8TB 7200 RPM SAS-3 Disk Drive Assembly n/a
    • 7301585
    • Hitachi HUH728080AL5200 [H7280A520SUN8.0T] (8TB – 7200 RPM – SAS-3 Disk
    n/a
    • 7044392
    • 3.5″ Heron Disk Mounting Bracket
    n/a
    • 7096032
    • 3.5″ Heron Disk Mounting Bracket
    n/a
    7106629 [S] 7066831 [C] 4TB 7200 RPM SAS Disk Drive Assembly n/a
    • 7065489
    • Hitachi HUS724040ALS640 [H7240AS60SUN4.0T] (4TB – 7200 RPM – SAS Disk)
    n/a
    • 7044392
    • 3.5″ Heron Disk Mounting Bracket
    n/a
    • 7096032
    • 3.5″ Heron Disk Mounting Bracket
    n/a
    n/a 350-1574 Disk Shelf SSD Filler Panel n/a
    n/a 540-7824 [C] 1.0TB – 7200 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks: n/a
    • 390-0438
    • Seagate ST31000640SS [ST31000SSSUN1.0T] (1TB – 7200 RPM – SAS Disk)
    n/a
    • 350-1386
    • Coral 3.5″ Disk Drive Bracket
    n/a
    n/a 541-4242 Disk Shelf HDD Filler Panel n/a
    n/a 542-0166 [C] 600GB – 15000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks: n/a
    • 390-0463
    • Seagate ST3600057SS [ST360057SSUN600G]
      (600GB – 15000 RPM – SAS Disk)
    n/a
    • 350-1386
    • Coral 3.5″ Disk Drive Bracket
    n/a
    n/a 542-0179 [C] 600GB – 15000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks: n/a
    • 390-0463
    • Seagate ST3600057SS [ST360057SSUN600G]
      (600GB – 15000 RPM – SAS Disk)
    n/a
    • 350-1508
    • Stingray 3.5″ Mounting Bracket
    n/a
    n/a 542-0191 [C] 300GB – 15000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks: n/a
    • 390-0461
    • Seagate ST3300657SS [ST330057SSUN300G]
      (300GB – 15000 RPM – SAS Disk)
    n/a
    • 350-1508
    • Stingray 3.5″ Mounting Bracket
    n/a
    n/a 542-0247 [C] 2TB – 7200 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks: n/a
    • 390-0476
    • Seagate ST32000444SS [ST32000SSSUN2.0T] (2TB – 7200 RPM – SAS Disk)
    n/a
    • 350-1386
    • Coral 3.5″ Disk Drive Bracket
    n/a
    n/a 542-0274 [C] 2TB – 7200 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks: n/a
    • 390-0476
    • Seagate ST32000444SS [ST32000SSSUN2.0T] (2TB – 7200 RPM – SAS Disk)
    n/a
    • 7045281
    • Toshiba MK2001TRKB [MK2001RKBSUN2.0T] (2TB – 7200 RPM – SAS Disk)
    n/a
    • 350-1508
    • Stingray 3.5″ Mounting Bracket
    n/a
    n/a 542-0340 [C] 1TB – 7200 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks: n/a
    • 390-0475
    • Seagate ST31000424SS [ST31001SSSUN1.0T] (1TB – 7200 RPM – SAS Disk)
    n/a
    • 7045280
    • Toshiba MK1001TRKB [MK1001RKBSUN1.0T] (1TB – 7200 RPM – SAS Disk)
    n/a
    • 350-1508
    • Stingray 3.5″ Mounting Bracket
    n/a
    n/a 542-0371 [C] 500GB – 7200 RPM SATA Disk Assembly with 1 bracket and 1 of the following disks: n/a
    • 390-0468
    • Seagate ST9500530NS [ST95000NSSUN500G]
      (500GB – 7200 RPM – SATA Disk)
    n/a
    • 390-0492
    • Seagate ST9500620NS [ST95001NSSUN500G] (500GB – 7200 RPM – SATA Disk)
    n/a
    • 541-2123
    • Marlin 2.5″ Bracket
    n/a
    n/a 542-0392 [C] 1TB – 7200 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks: n/a
    • 390-0475
    • Seagate ST31000424SS [ST31001SSSUN1.0T] (1TB – 7200 RPM – SAS Disk)
    n/a
    • 350-1386
    • Coral 3.5″ Disk Drive Bracket
    n/a
    n/a 542-0428 [C] 600GB – 15000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks: n/a
    • 390-0463
    • Seagate ST3600057SS [ST360057SSUN600G]
      (600GB – 15000 RPM – SAS Disk)
    n/a
    • 390-0483
    • Hitachi HUS156060VLS600 [HUS1560SCSUN600G]
      (600GB – 15000 RPM – SAS Disk)
    n/a
    • 350-1386
    • Coral 3.5″ Disk Drive Bracket
    n/a
    n/a 7010036 [C] 3TB – 7200 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks: n/a
    • 7010033
    • Seagate ST33000650SS [ST33000SSSUN3.0T] (3TB – 7200 RPM – SAS Disk)
    n/a
    • 7021037
    • Hitachi HUS723030ALS640 [H7230AS60SUN3.0T] (3TB – 7200 RPM – SAS Disk)
    n/a
    • 350-1386
    • Coral 3.5″ Disk Drive Bracket
    n/a
    n/a 7010135 [C] 3TB – 7200 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks: n/a
    • 7010033
    • Seagate ST33000650SS [ST33000SSSUN3.0T] (3TB – 7200 RPM – SAS Disk)
    n/a
    • 7021037
    • Hitachi HUS723030ALS640 [H7230AS60SUN3.0T] (3TB – 7200 RPM – SAS Disk)
    n/a
    • 350-1508
    • Stingray 3.5″ Mounting Bracket
    n/a
    n/a 7011095 [C] 73GB Solid State Drive SAS Assembly (Logzilla) n/a
    • 371-5049
    • Stec Z16IZF2D-73UC [Inquiry Unknown] (73GB – 3.5″ Solid State – SAS-2 Disk)
    n/a
    • 350-1386
    • Coral 3.5″ Disk Drive Bracket
    n/a
    n/a 7024415 [C] 300GB – 15000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks: n/a
    • 390-0461
    • Seagate ST3300657SS [ST330057SSUN300G]
      (300GB – 15000 RPM – SAS Disk)
    n/a
    • 390-0481
    • Hitachi HUS156030VLS600 [HUS1530SCSUN300G]
      (300GB – 15000 RPM – SAS Disk)
    n/a
    • 350-1386
    • Coral 3.5″ Disk Drive Bracket
    n/a
    n/a 7040582 [C] 2TB – 7200 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks: n/a
    • 7025852
    • Hitachi HUS723020ALS640 [H7220AS60SUN2.0T] (2TB – 7200 RPM – SAS Disk)
    n/a
    • 350-1386
    • Coral 3.5″ Disk Drive Bracket
    n/a
    n/a 7042768 3 [C] 500GB – 10000 RPM SATA Disk Assembly with 1 bracket and 1 of the following disks: n/a
    • 7042764
    • Western Digital WD5000BLHX [WD500BLHXSUN500G] (500GB – 10000 RPM – SATA Disk)
    n/a
    • 541-2123
    • Marlin 2.5″ Bracket
    n/a
    n/a 7042964 [C] 2TB – 7200 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks: n/a
    • 7025852
    • Hitachi HUS723020ALS640 [H7220AS60SUN2.0T] (2TB – 7200 RPM – SAS Disk)
    n/a
    • 350-1508
    • Stingray 3.5″ Mounting Bracket
    n/a
    n/a 7044283 [C] 300GB 10000 RPM SAS Disk Drive Assembly n/a
    • 7045226
    • Hitachi HUC109030CSS600 [H109030SESUN300G] (300GB – 10000 RPM – SAS Disk)
    n/a
    • 7044311
    • 2.5″ Evo Disk Mounting Bracket
    n/a
    n/a 7044376 [C] 900GB 10000 RPM SAS Disk Drive Assembly n/a
    • 7045230
    • Hitachi HUC109090CSS900 [H109090SESUN900G] (900GB 10000 RPM SAS Disk Drive)
    n/a
    • 7044311
    • 2.5″ Evo Disk Mounting Bracket
    n/a
    n/a 7044391 [C] 3TB 7200 RPM SAS Disk Drive Assembly n/a
    • 7048503
    • Hitachi HUS723030ALS640 [H7230AS60SUN3.0T] (3TB 7200 RPM SAS Disk Drive)
    n/a
    • 7044392
    • 3.5″ Heron Disk Mounting Bracket
    n/a
    • 7096032
    • 3.5″ Heron Disk Mounting Bracket
    n/a
    n/a 7047035 [C] 600GB – 15000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks: n/a
    • 390-0463
    • Seagate ST3600057SS [ST360057SSUN600G]
      (600GB – 15000 RPM – SAS Disk)
    n/a
    • 390-0483
    • Hitachi HUS156060VLS600 [HUS1560SCSUN600G]
      (600GB – 15000 RPM – SAS Disk)
    n/a
    • 350-1508
    • Stingray 3.5″ Mounting Bracket
    n/a
    n/a 7047155 [C] 300GB – 15000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks: n/a
    • 390-0461
    • Seagate ST3300657SS [ST330057SSUN300G]
      (300GB – 15000 RPM – SAS Disk)
    n/a
    • 390-0481
    • Hitachi HUS156030VLS600 [HUS1530SCSUN300G]
      (300GB – 15000 RPM – SAS Disk)
    n/a
    • 350-1508
    • Stingray 3.5″ Mounting Bracket
    n/a
    n/a 7047869 [C] 73GB SAS-2 Solid State Drive Assembly (Logzilla) 7011095 [C]
    • 7047682
    • Stec Z16IZF3D-73UC [Inquiry Unknown] (73GB – 3.5″ Solid State – SAS-2 Disk)
    n/a
    • 350-1386
    • Coral 3.5″ Disk Drive Bracket
    n/a
    n/a 7051739 4 [C] 73GB SAS-2 Solid State Drive Assembly n/a
    • 7045627
    • Stec Z16IZF2E-73UCU [Inquiry Unknown] (73GB – 2.5″ Solid State – SAS-2 Disk)
    n/a
    • 7042920
    • 2.5″ Adapter
    n/a
    • 7042923
    • Left Bracket
    n/a
    • 7050989
    • 3.5″ Drive Bracket
    n/a
    n/a 7094120 5 [C] 200GB SAS Solid State Drive Assembly n/a
    • 7093646
    • HGST HUSMM1640ASS200 [HSCAC2DA6SUN200G] (200GB – 2.5″ Solid State – SAS Disk)
    n/a
    • 7044392
    • 3.5″ Heron Disk Mounting Bracket
    n/a
    • 7096032
    • 3.5″ Heron Disk Mounting Bracket
    n/a
    n/a 7094126 6 [C] 200GB SAS Solid State Drive Assembly n/a
    • 7093646
    • HGST HUSMM1640ASS200 [HSCAC2DA6SUN200G] (200GB – 2.5″ Solid State – SAS Disk)
    n/a
    • 7044311
    • 2.5″ Evo Disk Mounting Bracket
    n/a
    n/a 7309941 [C] [A] 200GB SAS-3 Solid State Drive Assembly with 1 bracket and 1 of the following disks: n/a
    • 7093646
    • HGST HUSMM1640ASS200 [HSCAC2DA6SUN200G] (200GB – 2.5″ Solid State – SAS Disk)
    n/a
    • 7042920
    • 2.5″ Adapter
    n/a
    • 7042923
    • Left Bracket
    n/a
    • 7050989
    • 3.5″ Drive Bracket
    n/a
    3 The Western Digital 500GB 10000 RPM drive replaced the Seagate 500GB 7200 RPM drive due to shortages caused by flooding in Thailand in 2011. The bezel is labeled SATA 500GB 7200 RPM 3Gbps.
    4 73GB SAS-2 Solid State Drive Assembly PN#7051739 requires a minimum AK firmware version of 2011.1.4.
    5 200GB SAS Solid State Drive Assembly PN#7094120 requires a minimum firmware version of 2013.1.2.9
    6 200GB SAS Solid State Drive Assembly PN#7094126 requires a minimum firmware version of 2013.1.2.9
    NOTE: See this table of supported disks per sub-system within the 7120 for more accurate part replacement selection.
    Ethernet
    Option # Manufacturing
    Part #
    Description Previous
    Part #
    X1109A-Z 7051223 [C] Dual 10-Gigabit PCI Express Ethernet SFP+ LP 375-3617 [C]
    X2129A-N 530-4449 [C] 10Gb/Sec Short Wave SFP+ Transceiver n/a
    X5562A-Z 135-1205 [C] 10Gb/Sec Long Wave SFP+ Transceiver n/a
    X4446A-Z-N [S] 7054739 [C] PCI Express Quad Gigabit Ethernet UTP 375-3481 [C]
    n/a 375-3481 [C] PCI Express Quad Gigabit Ethernet UTP n/a
    n/a 375-3617 [C] Dual 10-Gigabit Ethernet SFP+ LP n/a
    Fan
    Option # Manufacturing
    Part #
    Description Previous
    Part #
    n/a 541-4124 [F] Fan Board Assembly n/a
    • 330-5243
    • Fan Board Cover
    n/a
    • 511-1434
    • Fan Board
    n/a
    n/a 541-4222 [F] Fan Assembly n/a
    • 371-4613
    • 60×28mm 10400/9500 RPM Dual Fan
    n/a
    Fibre Channel
    Option # Manufacturing
    Part #
    Description Previous
    Part #
    SG-XPCIE2FC-QF8-N 371-4325 [C] 8Gigabit/Sec PCI Express Dual FC Host Adapter n/a
    I/O
    Option # Manufacturing
    Part #
    Description Previous
    Part #
    n/a 541-2884 [C] x8/x8 PCI Express Riser Assembly n/a
    • 501-7964
    • x8/x8 PCI Express Riser
    n/a
    • 541-2531
    • Bracket
    n/a
    n/a 541-3356 [F] x8/x8 Switched PCI Express Riser Assembly n/a
    • 511-1139
    • x8/x8 Switched PCI Express Riser
    n/a
    • 541-2531
    • Bracket
    n/a
    n/a 541-4306 [F] Connector Board Assembly n/a
    • 511-1517
    • Connector Board
    n/a
    • 341-6222
    • Mounting Bracket
    n/a
    • 530-3510
    • Interlock Switch Cable
    n/a
    n/a 7049269 [C] x8/x8 PCI Express Riser Assembly 541-2884 [C]
    • 541-2531
    • Bracket
    n/a
    • 7049268
    • x8/x8 PCI Express Riser
    501-7964
    n/a 7049272 [F] x8/x8 Switched PCI Express Riser Assembly 541-3356 [F]
    • 541-2531
    • Bracket
    n/a
    • 7049271
    • x8/x8 Switched PCI Express Riser
    n/a
    Memory
    Option # Manufacturing
    Part #
    Description Previous
    Part #
    X4911A 371-4966 [C] 8GB Registered DDR3L-1333/DDR3L-1600 DIMM, 1.35V n/a
    n/a 371-4743 [F] 4GB USB 2.0 Flash Drive n/a
    n/a 371-4898 [C] 4GB Registered DDR3-1333 DIMM, 1.5V n/a
    n/a 371-4965 [C] 4GB Registered DDR3-1333 DIMM, 1.35V n/a
    n/a 371-5002 [F] 4GB USB 2.0 Flash Drive n/a
    Power
    Option # Manufacturing
    Part #
    Description Previous
    Part #
    n/a 300-2235 [C] Type A249 1100/1200 Watt AC Input Power Supply n/a
    n/a 300-2276 [C] 764 Watt AC Input Power/Cooling Module n/a
    n/a 300-2304 [C] Type A249A 1100/1200 Watt AC Input Power Supply 300-2235 [C]
    n/a 541-4223 [F] Power Distribution Assembly n/a
    • 341-3166
    • Bus Bar Left
    n/a
    • 341-3167
    • Bus Bar Right
    n/a
    • 511-1437
    • Horizontal Power Distribution Board
    n/a
    • 511-1513
    • Vertical Power Distribution Board
    n/a
    • 371-2484
    • PDB Signal Cable
    n/a
    n/a 7043627 [C] 580 Watt AC Input Power Supply n/a
    n/a 7049253 [F] Power Distribution Assembly 541-4223 [F]
    • 341-3166
    • Bus Bar Left
    n/a
    • 341-3167
    • Bus Bar Right
    n/a
    • 7049252
    • Vertical Power Distribution Board
    n/a
    • 7051687
    • Horizontal Power Distribution Board
    511-1437
    • 371-2484
    • PDB Signal Cable
    n/a
    NOTE: 764W AC Input Power Supply and Fan Assembly PN#300-2276 is used in the OPTIONAL Sun Disk Shelf 24×3.5″ SAS-2 as part of the Sun ZFS Storage 7120.
    NOTE: 580W AC Input Power Supply PN#7043627 is used in the Oracle Storage DE2-24C and DE2-24P as part of the Sun ZFS Storage 7120.
    Rack
    Option # Manufacturing
    Part #
    Description Previous
    Part #
    DS2X-4URK-19U [S] 350-1531 Rackmount Kit n/a
    • n/a
    • Left Mounting Rail
    n/a
    • n/a
    • Right Mounting Rail
    n/a
    X5888A-N [S] 350-1287 [C] 1U/2U Cable Management Arm n/a
    n/a 350-1265 [C] 1U/2U Snap-In Slide Rail Rackmount Kit n/a
    n/a 350-1502 [C] 1U/2U Bolt-In Slide Rail Kit n/a
    n/a 350-1718 [C] 1U/2U Bolt-On Slide Rail Rackmount Kit n/a
    n/a 7044619 [C] Mounting Rail Kit n/a
    n/a 7063682 [C] Mounting Rail Kit n/a
    NOTE: Rackmount Kit DS2X-4URK-19U/350-1531 is used for rack mounting the OPTIONAL Sun Disk Shelf 24×3.5″ SAS-2 as part of the Sun ZFS Storage 7120.
    SCSI
    Option # Manufacturing
    Part #
    Description Previous
    Part #
    7105394 8-Port 6Gbps SAS-2 RAID HBA X-Option
    7056272 [C] 8-Port 6Gbps SAS-2 RAID HBA 375-3609 [C]
    SG-XPCIESAS-GEN2-Z [S] 7056272 [C] 8-Port 6Gbps SAS-2 RAID HBA 375-3609 [C]
    n/a 371-4415 24GB Solid State Flash Memory Module n/a
    n/a 375-3609 [C] 8-Port 6Gbps SAS-2 RAID HBA n/a
    n/a 375-3665 [C] 8-Port 6Gbps SAS-2 RAID HBA n/a
    n/a 7056275 [C] 8-Port 6Gbps SAS-2 RAID HBA 375-3665 [C]
    n/a 7075796 [F] 96GB PCI Express Flash Accelerator F20 SAS HBA n/a
    • 371-4650 [F]
    • Energy Storage Module (ESM)
    n/a
    • 511-1500
    • PCI Express Flash Board
    n/a
    • 7061269
    • 24GB Solid State Flash Memory Module, FW D21Y
    371-4415
    n/a 541-3731 [F] [S] 96GB PCI Express Flash Accelerator F20 SAS HBA n/a
    • 371-4650 [F]
    • Energy Storage Module (ESM)
    n/a
    • 511-1500
    • PCI Express Flash Board
    n/a
    • 7061269
    • 24GB Solid State Flash Memory Module, FW D21Y
    371-4415
    System Board
    Option # Manufacturing
    Part #
    Description Previous
    Part #
    n/a 541-4081 [F] System Board Assembly/FRU n/a
    • 511-1213
    • System Board
    n/a
      • 150-3993 [C]
      • 3V Lithium Coin Cell Battery
    n/a
    • 541-2543
    • System Board Tray
    n/a
    n/a 7049265 [F] System Board Assembly/FRU 541-4081 [F]
    • 7049264
    • System Board
    n/a
      • 150-3993 [C]
      • 3V Lithium Coin Cell Battery
    n/a

    Industry Leading Quality, Support and Integrity

    Quality Inspection Checklist
    Before it leaves our facility, every used and refurbished item is thoroughly inspected by our certified technicians and undergoes our exclusive Quality Inspection Checklist to ensure 100% satisfaction guarantee.

    Greentec Systems is a leading provider
    For server, networking and storage equipment. We have an extensive array of inventory of IBM Servers & Storage, Sun Servers & Storage, Cisco Networking (Switches, Routers, Security), and NetApp Storage (disk shelves, disk drives, Filers, NearStore, NetCache). If you don’t see the item or product you require please contact us.

    Have this equipment to sell?
    Depending on the age and condition of the equipment, there is a very good likelihood that we will be able to offer you cash or trade-in credit for other IT hardware. If the equipment is very old we can also assist you with properly decommissioning that gear in the most environmentally friendly way possible.

    Questions?
    For more information please contact 888.333.7388, or fill out the quote from above. We’d love to hear from you.

    Request Quote
    Greentec Systems We geek out helping you with your IT infrastructure.
    Request a quote or product information
    Send
