Oracle Sun X5-8 Server

REQUEST A PRICE QUOTE:

Brand:	Oracle / Sun Microsystems
Condition:	Refurbished and new (limited availability)
Availability:	Contact
Shipping Area:	Worldwide to most countries
Shipping Method:	Fedex (most orders), UPS, DHL, Freight Courier
Price:	Please use the quote form above for quick pricing
Payment:	Credit Card, Check, Net Terms (oac), Wire Transfer (required for international orders)
Guarantee:	All items are tested by Oracle trained technicians & backed by a 100% warranty
Questions?	Don’t hesitate to contact us with any questions regarding compatibility or other product info and requests. Our website represents only a fraction of our full inventory. Please reach out with your full requirements

Specs and Information:

Processor

Number

4 or 8 CMODs (Compute Modules), providing 4 or 8 CPU configurations

Architecture

Type: Intel Xeon E7-8895 Processor Series

CPUs

Intel 2.6GHz 18-Core Xeon E7-8895 v3, 175W

Main Memory

Capacities

DIMM Slots per CMOD: 24
Total DIMM Slots: 192
DIMM Size and Type: 16GB: DDR3L-1600 ECC registered or 32GB: DDR3L-1600 load-reduced ECC DIMMs (LRDIMM)
Minimum Populated DIMM Slots per CMOD : 4 DIMMs per CMOD
Minimum Memory Capacity: 256GB using 16GB DIMMs
Maximum Memory Capacity: 6TB using 32GB DIMMs
Memory capacity needs to be equal across all CMODs
Memory mixing is not allowed

Standard I/O

Network

Two 1 GbE network ports (RJ-45 connector)

Network Management

One 10/100/1000Base-T Ethernet Service Processor (SP) (RJ-45 connector) port

Serial Management

One RS-232 RJ45 serial console port

USB

Rear: 2 USB 2.0 Ports
Internal: 2 USB 2.0 Ports

Video

One VGA 1,280 x1,024×8 MB @ 60 Hz graphics controller port with DB-15 connector

I/O Expansion

2 PCI Express 3.0 Slots per CMOD for maximum of 16 Slots. Hot swappable via Dual PCIe Card Carrier (DPCC).

1 x8 PCI-E slot and 1 x16 PCI-E slot per DPCC
Four CMOD systems support PCIe slots 1 through 8
Eight CMOD systems support all 16 PCIe slots
PCIe slots 13, 14, 15, and 16 cannot contain bootable devices such as HBAs or network boot devices
No mixing of Emulex and Qlogic versions of the Sun Storage 16Gb Fibre Channel PCIe Universal HBA in the system

Internal Mass Storage

Disks

Eight rear-accessible and hot-swappable 2.5″ SAS-2 HDDs or eight 2.5″ SATA-3 SSDs for up to 9.6TB of internal storage.

Drive Type	Density	Speed	Form Factor
SAS-2	600GB	10,000 RPM	2.5″
SAS-2	1.2TB	10,000 RPM	2.5″
SATA-3	400GB	Solid State	2.5″

Power Supplies and Fans

Four dual redundant, hot swap power supplies and 8 Hot-swap Redundant Dual Fans.
Cooling is front to back.

Environment

Power Consumption

Online power calculator

AC power

Nominal input frequencies 50/60 Hz
Operating input voltage range 200-240 VAC
Rated input current 23A@200 to 230 VAC 12A max per cord
Maximum power consumption 3400W

Maximum Heat Output

11600 BTU/hr

Temperature

Operating: 5° C to 35° C (41° F to 95° F)
Nonoperating: -40° C to 70° C (-40° F to 158°F)

Humidity

Operating: 10% to 90% relative humidity, noncondensing
Nonoperating: Up to 93% relative humidity, noncondensing

Altitude

Single, non-rack system:
Operating: Up to 3000 m (9,840 ft.), maximum operating temperature is derated by 1° C for every 300 m (985 ft) above 900 m (2,952 ft), except in China where regulations may limit installations to a maximum altitude of 2,000 m
Nonoperating: 0 to 12,000 m (39,370 ft.)

Acoustic Noise Emissions

LwAd (1B= 10dB) – 7.7 B operating, 6.8 B idling

Regulations
Meets or exceeds the following requirements:

Safety

UL/CSA 60950-1, EN 60950-1, IEC 60950-1 (CB Scheme with all country differences)

EMC

Emissions: FCC CFR 47 Part 15, ICES-003, EN 55022, EN610000-3-2, EN61000-3-3
Immunity: EN55024

Emissions and Immunity

EN300 386

Certifications

Safety Marks

North America (NRTL), European Union (EU), International CB Scheme, HSE Exemption (India), BSMI (Taiwan), RCM (Australia), MSIP (Korea), VCCI (Japan)

European Union Directives

2006/95/EC Low Voltage Directive, 2004/108/EC EMC Directive, 2011/65/EU RoHS Directive, 2012/19/EU WEEE Directive

Dimensions and Weight

Height

219.25 mm (8.63 in.) 5U

Width

445 mm (17.5 in.)

Depth

834 mm (32.8 in.)

Weight

Maximum: 114 kg (250 lbs.)

Rack Mounting & Clearance

Oracle Server X4-8 Racks

Tooless Slide Rail Rackmount Kit
Sun Rack 1242
Front Minimum Clearance: 1,232 mm (48.5 in)
Rear Minimum Clearance: 914 mm (36 in)

Backplane/Centerplane
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7308647 [F]	Busbar/Midplane Assembly	n/a
	7064783	Busbar Subassembly	n/a
	7064025	Busbar	n/a
	7308648	8-Slot Midplane Subassembly	n/a
	7308643	8-Slot Midplane	n/a

Batteries
Option #	Manufacturing Part #	Description	Previous Part #
n/a	150-3993 [C]	3V Lithium Coin Cell Battery	n/a

CPU Module
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7070792 [F]	CPU Heatsink (Brickland)	n/a
n/a	7080240	CPU Installation/Removal Tool	n/a
n/a	7302593 [F]	18-Core 2.6GHz Intel E7-8895 v3, 175W	n/a
n/a	7304446 [F]	CPU/Memory Module Assembly	n/a
	7084467	CMOD Chassis	n/a
	7304445	CPU/Memory Assembly	n/a
	7303468	CPU/Memory Board	n/a

Cables
Option #	Manufacturing Part #	Description	Previous Part #
7102869	7039990 [C]	MPO to MPO High Bandwidth QSFP Optical Cable, 10M	n/a
7102870	7039999 [C]	MPO to MPO High Bandwidth QSFP Optical Cable, 20M	n/a
7102871	7040001 [C]	MPO to MPO High Bandwidth QSFP Optical Cable, 50M	n/a
X2121A-1M-N	530-4444 [C]	10Gbps QSFP to QSFP Cable, 1m	n/a
X2121A-2M	530-4567 [C]	10Gbps QSFP to QSFP Cable, 2m	n/a
X2121A-3M-N	530-4445 [C]	10Gbps QSFP to QSFP Cable, 3m	n/a
X2121A-5M-N	530-4446 [C]	10Gbps QSFP to QSFP Cable, 5m	n/a
X2125A-1M-N	530-4450 [C]	QSFP to 4× SFP+ Splitter Cable, 1m	n/a
X2125A-3M-N	530-4451 [C]	QSFP to 4× SFP+ Splitter Cable, 3m	n/a
X2125A-5M-N	530-4452 [C]	QSFP to 4× SFP+ Splitter Cable, 5m	n/a
X2127A-10M	530-4480 [C]	MPO to 4x LC Duplex Splitter Cable, 10m	n/a
X2127A-20M	530-4481 [C]	MPO to 4x LC Duplex Splitter Cable, 10m	n/a
X2127A-50M	530-4482 [C]	MPO to 4x LC Duplex Splitter Cable, 50m	n/a
n/a	530-3100	RJ45F to DB9F Adapter	n/a
n/a	7084503 [C]	Cable Kit	n/a
	7064165	AC LED to Midplane Cable	n/a
	7075257	AC LED Board	n/a
	7073884	AC OK LED Board	n/a
n/a	7096698 [F]	2x 36-Pin SFF-8643 to 72-Pin SFF-8643 SAS-3 Cable, 300mm	n/a

Chassis
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7098401	Chassis Assembly	n/a
	7054505	Chassis Subassembly	n/a
	7025969	20A AC Input Line Filter	n/a
	7060153	AC Ground Cable	n/a
	7063266	Chassis	n/a
	7075019	Power Supply Cable Assembly	n/a
	7059728	Power Supply Cable	n/a
	7076663	Bracket	n/a
	7075285	Top Cover	n/a
	7064165	AC LED to Midplane Cable	n/a
	7075257	AC LED Board	n/a
	7073884	AC OK LED Board	n/a
	7097073	X5-8 Nameplate	n/a

Communication
Option #	Manufacturing Part #	Description	Previous Part #
7104074	7092757 [C]	Dual 40Gb/Sec (4x) QDR InfiniBand Host Channel Adapter Module M3	n/a

Disks
Option #	Manufacturing Part #	Description	Previous Part #
7110933	7094132 [C]	400GB Solid State SAS Drive Assembly	n/a
	7093645	400GB SAS Solid State Drive [HSCAC2DA4SUN400G]	n/a
	541-2123	Marlin 2.5″ Bracket	n/a
7111103	7093015 [C]	600GB – 10000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks:	n/a
	7093013	Hitachi HUC101860CSS200 (600.0GB – 10000 RPM SAS Disk)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a
7111108	7093037 [C]	1.2TB – 10000 RPM SAS SFF Disk Assembly w 1 bracket and 1 of the following disks:	n/a
	7093035	Hitachi HUC101812CSS200 [H101812SFSUN1.2T] (1.2TB – 10000 RPM – SAS DISK)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a

Ethernet
Option #	Manufacturing Part #	Description	Previous Part #
7100477	7070195 [C]	Quad Port GbE PCI Express 2.0 Low Profile Adapter, UTP	n/a
7100488	7070006 [C]	Dual 10-Gigabit Base-T PCI Express Gen2	n/a
X1109A-Z	7051223 [C]	Dual 10-Gigabit PCI Express Ethernet SFP+ LP	n/a
X2124A	135-1204 [C]	10Gb/Sec QDR InfiniBand / 40Gb/Sec Ethernet QSFP Transceiver	n/a
X2129A-N	530-4449 [C]	10Gb/Sec Short Wave SFP+ Transceiver	n/a
X5562A-Z	135-1205 [C]	10Gb/Sec Long Wave SFP+ Transceiver	n/a

Fan
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7091709	Fan Frame	n/a
n/a	7091860 [C]	Fan Module, 80x76mm, 13000 RPM	n/a

Fibre Channel
Option #	Manufacturing Part #	Description	Previous Part #
7101674	7023303 [C]	Dual 16Gigabit/Sec Fibre Channel / 10Gbps FCoE Host Adapter, QLogic	n/a
7101676	7023325 [C]	Pair of 16Gbps Short Wave SFP+	n/a
7101676	7023324	16Gb/Sec Short Wave SFP+ Transceiver, QLogic	n/a
7101678	7023315 [C]	Pair of 10Gbps Short Wave SFP+	n/a
7101678	7023316	10Gb/Sec Short Wave SFP+ Transceiver, QLogic	n/a
7101680	7023066 [C]	Pair of 16Gbps Long Wave SFP+	n/a
7101680	7023064	16Gb/Sec Long Wave SFP+ Transceiver, QLogic	n/a
7101684	7023036 [C]	Dual 16Gigabit/Sec Fibre Channel / 10Gbps FCoE Host Adapter, Emulex	n/a
7101686	7023059 [C]	Pair of 16Gbps Short Wave SFP+	n/a
7101686	7023053	16Gb/Sec Short Wave SFP+ Transceiver, Emulex	n/a
7101688	7023057 [C]	Pair of 10Gbps Short Wave SFP+	n/a
7101688	7023046	10Gb/Sec Short Wave SFP+ Transceiver, Emulex	n/a

I/O
Option #	Manufacturing Part #	Description	Previous Part #
n/a	351-0009	PCI Express Filler Panel, Low Profile	n/a
n/a	7084488 [C]	Front Indicator Module (FIM)	n/a
	7057505	Front Circuit Board	n/a
	7074700	Ribbon Cable, 460mm	n/a
	7084756	FIM Chassis Assembly	n/a
	7098638	Rear Circuit Board	n/a
	7082596	Front Circuit Board, FIM1	n/a
n/a	7094766 [C]	Dual PCI Express Card Carriers (DPCC)	n/a
	7073880	Dual PCI Express Board	n/a
	7094765	DPCC Chassis	n/a

Memory
Option #	Manufacturing Part #	Description	Previous Part #
7111365	7095790 [C]	16GB DDR3L-1600 1.35V Registered DIMM	n/a
7111372	7095791 [C]	32GB DDR3L-1600 1.35V Load Reduced DIMM	n/a
n/a	7090170 [C]	8GB USB Stick	n/a

Power
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7081596 [C]	A261 3000 Watt AC Input Power Supply	n/a
n/a	7302922 [C]	A261 3000 Watt AC Input Power Supply	7081596 [C]

Rack
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7090552 [C]	Rackmount Kit	n/a
	7090551	Spacer Kit	n/a
	7090644	Rail Kit	n/a

SCSI
Option #	Manufacturing Part #	Description	Previous Part #
7110865	7307468 [F]	1.6TB Flash Accelerator F160 NVMe Card w/ LP Bracket (B1 Silicon)	n/a
n/a	7085211	Internal RAID HBA Assembly	n/a
	7070402	Double Sided Fastener, 1″x5″	n/a
	7085209 [F]	8-Port 12Gbps SAS3 Internal RAID HBA	n/a
	7086345 [F]	13.5V 6.4F Super Capacitor	n/a
	7086346 [F]	Super Capacitor Cable	n/a

System Board
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7096849 [C]	System Module Assembly (SMOD)	n/a
	7078321	4-Slot Disk Cage Assembly	n/a
	7064572	4-Slot Disk Cage	n/a
	7073882	4-Slot Disk Backplane	n/a
	7084581	SMOD Chassis Assembly	n/a
	7096851	System Module Controller Subassembly	n/a
	7057962	System Module PCI Express Riser	n/a
	7095092	System Module Controller	n/a
	150-3993 [C]	3V Lithium Coin Cell Battery	n/a
