Oracle Sun X4600, RoHS Server

Oracle Sun X4600, RoHS Server Oracle Sun X4600, RoHS Server Sun Servers SUN FIRE X4600 RoHS copy

REQUEST A PRICE QUOTE:

    Name*

    Phone

    Details*



    Processor
    Number Up to 8 (Single or Dual-Core)
    Architecture Type: AMD Opteron Processor 800 Series
    Single Core: 856 (3.0GHz)
    Dual Core: 885 (2.6GHz)
    Cache memory 1 MB Level 2
    Sun Fire X4600 M2 difference: See Model 2 (M2) CPU specifications.
    The M2 uses AMD Opteron 8000 series CPUs.
    BIOS revisions differ between the AMD Opteron 800 and 8000 series. BIOS downloads are available at: http://www.sun.com/servers/x64/x4600/downloads.jsp
    Main Memory
    Capacities DIMM slots per CPU Socket: 4
    DIMM sizes:1-GB, or 2-GB
    Maximum capacity: 64GB (when configured with 2-GB DIMMs and 8 CPU Modules)
    Sun Fire X4600 M2 difference: See Model 2 (M2) Memory specifications.
    The M2 uses DDR2-667 memory. DIMM slot locations differ between DDR1 and DDR2 DIMMs. Refer to Sun Fire X4600 and Sun Fire X4600 M2 service documentation for DIMM installation information.
    Standard Integrated Interfaces
    Network Four 10/100/1000Base-T Ethernet ports, RJ45 connectors
    Network Management One dedicated 10/100Base-T Ethernet port, RJ45 connector
    Serial Management RS-232 Serial Interface, RJ45 connector
    SAS Four channel SAS interface
    USB Front: Two USB 2.0 ports
    Rear: Two USB 2.0 ports
    Expansion bus 8 Low Profile PCI Expansion slots
    • 6 PCIe slots (4 x 8-lane PCI slots, 2 x 4-lane PCI slots)
    • 2 64-bit/100 MHz PCI-X slots
    Internal Mass Storage
    Disks Internal: Up to four 73GB or 146GB HDD Disks (Hot Pluggable 2.5″ SAS) RPM 10K
    Up to four 73GB HDD Disks (Hot Pluggable 2.5″ SAS) RPM 15K.
    DVD-ROM One EIDE DVD-ROM
    Power Supplies
    Four hot-swappable power supplies, redundant in 2+2 configuration; 120W processors only supported with 3+1 configuration (i.e. All power cords must be connected to same power source).
    Some earlier rev E based product were shipped with 3+1 power support. (Power source 100-240 VAC – 50/60 Hz input)
    (UL Maximum (DC output) = 850W)
    (Typical Power Consumption: 40 W/PSU)
    Environment
    AC power 90-264 V AC (47-63 Hz)
    Temperature Single, non-rack system:
    Operating: 5° C to 32° C (41° F to 90° F)
    Nonoperating: -40° C to 65° C (-40° F to 149° F)
    Humidity Single, non-rack system:
    Operating: 10% to 90% relative humidity noncondensing, 27° C (80.6° F) max wet bulb
    Nonoperating: up to 93% relative humidity noncondensing, 38° C (100.4° F) max wet bulb
    Altitude Single, non-rack system:
    Operating:32° C up to 900 meters and derating of 1°C for every 300 meters in altitude up to 3048 meters maximum
    Nonoperating: up to 12,000 m (40,000 ft.)
    Acoustic noise
    (Measure and Environment)    		 Declared noise emissions in accordance with ISO 9296, A-weighted, operating and idling:
    Less than 83 dB sound power in ambient temperature of up to 24° C
    LwAd (1B=10dB)
    at or below 25C
    at max ambient    		 8.1 B
    8.9 B
    LpAm bystander
    at or below 25C
    at max ambient    		 66 dB
    74 dB
    Regulations
    Meets or exceeds the following requirements:
    RoHS Compliance Level RoHS:YL
    Safety IEC60950, UL/CSA60950-1, EN60950, (CB Scheme with all country differences)
    RFI/EMI FCC Class A, Part 15 47 CFR, EN55022, CISPR 22, EN300-386:v1.3.2, ICES-003
    Immunity EN55024, EN300-386:v1.3.2
    Certifications Safety: cULus Mark, CE Mark, CCC, GOST R, S-Mark
    EMC: CE Mark (93/68/EEC), Emissions and Immunity Class A Emissions Levels: FCC, VCCI, BSMI, C-Tick, MIC, CCC (Applicable at GA), GOST R, BSMI
    Other: Labeled per WEEE (Waste Electrical and Electrical Equipment) Directive
    Dimensions and Weight
    Height 176 mm (6.9 in.)
    Width 445 mm (17.5 in.)
    Depth 629 mm (24.75 in.)
    Weight 40 kg (88 lb.) Maximum standalone server
    48 kg (106 lb.) Maximum with orderable rack-mount kit and cable management arm
    CPU Module
    Option # Manufacturing
    Part #    		 Description
    X8096A-Z 501-7051 CPU Filler Board Assembly, RoHS:YL
    X8103A-Z 541-1283 0MB 3.0GHz Opteron 856 CPU/Memory Module, RoHS:YL
    • 310-0028
    • Heatsink, RoHS:Y
    • 371-1759
    • 3.0GHz CPU, AMD Opteron 856, E4 Stepping, RoHS:Y
    • 501-7589
    • CPU/Memory Board, RoHS:YL
    • 541-0469
    • CPU Backplane assembly, RoHS:Y
    X8104A-Z 541-1770 0MB 2.4GHz Opteron 880 CPU/Memory Module, RoHS:YL
    • 310-0028
    • Heatsink, RoHS:Y
    • 371-0291
    • 2.4GHz Dual Core CPU, AMD Opteron 880, E6 Stepping, 95W, RoHS:Y
    • 501-7589
    • CPU/Memory Board, RoHS:YL
    • 541-0469
    • CPU Backplane assembly, RoHS:Y
    X8105A-Z 541-1771 0MB 2.6 GHz AMD Opteron 885 CPU Assembly, RoHS:YL
    • 310-0028
    • Heatsink, RoHS:Y
    • 371-1760
    • 2.6 GHz CPU, Opteron 885 E6 Stepping Dual Core, 95W, RoHS:Y
    • 501-7589
    • CPU/Memory Board, RoHS:YL
    • 541-0469
    • CPU Backplane assembly, RoHS:Y
    Cables
    Option # Manufacturing
    Part #    		 Description
    X311L Localized Power Cord Kit – North America/Asia, RoHS:Y
    180-1097 IEC 320 C13 to NEMA 5-15P – 15A/125V 2.5M Black, RoHS:Y
    X312E Localized Power Code Kit – China, RoHS:Y
    180-1982 IEC 320 C13 to GB 2099/GB 1002 – 10A/250V 2.5M, RoHS:Y
    X312F Localized Power Cord Kit – Argentina, RoHS:Y
    180-1999 IEC 320 C13 to IRAM 2073 – 10A/250V 2.5M Black, RoHS:Y
    X312G Localized Power Cord Kit – Korea, RoHS:Y
    180-1662 IEC 320 C13 to KSC 8305 – 15A/250V 2.5M Black, RoHS:Y
    X312L Localized Power Cord Kit – Continental Europe, RoHS:Y
    180-1993 IEC 320 C13 to CEE 7/7 10A/250V 2.5M Black, RoHS:Y
    X314L Localized Power Cord Kit – Swiss, RoHS:Y
    180-1994 IEC 320 C13 to SEV 1011 – 10A/250V 2.5M Black, RoHS:Y
    X317L Localized Power Cord Kit – U.K., RoHS:Y
    180-1997 IEC 320 C13 to BS 1363 – 10A/250V 2.5M Black, RoHS:Y
    X332A Localized Power Cord Kit – Taiwan, RoHS:Y
    180-2121 IEC 320 C13 to NEMA 5-15P – 10A/125V 2.5M Black, RoHS:Y
    X383L Localized Power Cord Kit – Danish, RoHS:Y
    180-1995 IEC 320 C13 to Asfnit 107 – 10A/250V 2.5M Black, RoHS:Y
    X384L Localized Power Cord Kit – Italian, RoHS:Y
    180-1996 IEC 320 C13 to CEI 23-16/VII – 10A/250V 2.5M Black, RoHS:Y
    X386L Localized Power Cord Kit – Australian, RoHS:Y
    180-1998 IEC 320 C13 to AS 3112 – 10A/250V 2.5M Black, RoHS:Y
    n/a 530-1819 Localized Power Cord Kit – Danish
    n/a 530-3100 RJ45F to DB9F Adapter, RoHS:Y
    Communication
    Option # Manufacturing
    Part #    		 Description
    X1236A-Z 375-3382 Dual Port 10Gb/sec 4x PCI Express Infiniband Host Channel Adapter – Low Profile, RoHS:Y
    X1333A-4 375-3418 Infiniband PCI-X Card, RoHS:YL
    Disk Backplane
    Option # Manufacturing
    Part #    		 Description
    n/a 501-7049 4-Slot Disk Backplane, RoHS:YL
    Disks
    Option # Manufacturing
    Part #    		 Description
    XRA-SS2CD-146G10KZ 540-7151 146GB – 10000 RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks and brackets, RoHS:Y
    • 390-0324
    • Seagate ST9146802SS [ST914602SSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0375
    • Fujitsu MBB2147RC [MBB2147RCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0377
    • Hitachi HUC101414CSS300 [H101414SCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-0239
    • Nemo Bracket, RoHS:Y
    • 541-3004
    • Nemo Bracket with Insulator, RoHS:Y
    XRA-SS2CD-73G10KZ 540-6611 73GB 10000 RPM SAS, Disk Assembly with 1 of the following disks and brackets, RoHS:Y
    • 390-0213
    • Seagate ST973401SS [ST973401SSUN72G]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0285
    • Fujitsu MAY2073RC [MAY2073RCSUN72]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0323
    • Seagate ST973402SS [ST973402SSUN72G]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0374
    • Fujitsu MBB2073RC [MBB2073RCSUN72G]
      (73.4GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0376
    • Hitachi HUC101473CSS300 [H101473SCSUN72G]
      (73.4GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-0239
    • Nemo Bracket, RoHS:Y
    • 541-3004
    • Nemo Bracket with Insulator, RoHS:Y
    XRA-SS2CD-73G15K 540-7360 73GB – 15000 RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks, RoHS:Y
    • 390-0382
    • Seagate ST973451SS [ST973451SSUN72G]
      (73GB – 15000 RPM – SAS Disk), RoHS:Y
    • 541-0239
    • Nemo Bracket, RoHS:Y
    Ethernet
    Option # Manufacturing
    Part #    		 Description
    X1027A-Z 501-7283 PCI Express Dual 10-Gigabit Ethernet Fiber, RoHS:Y
    X4446A-Z 375-3481 PCI Express Quad Gigabit Ethernet UTP, RoHS:Y
    X5544A-4 10Gb PCI-X Ethernet Adapter, no transceiver, RoHS:Y
    501-7413 10Gb PCI-X Ethernet Adapter, RoHS:Y
    • 370-7665
    • Bracket Standard 10Gb PCI-X Ethernet, RoHS:Y
    • 370-7792
    • Bracket Low-Profile 10Gb PCI-X Ethernet, RoHS:Y
    X5558A 375-3301 10Gb/sec XFP Optical Transceiver Short Range (SR), RoHS:YL
    X5560A-Z 375-3495 10Gb/sec XFP Optical Transceiver Long Range (LR), RoHS:Y
    X7280A-2 371-0905 PCI Express Dual Gigabit Ethernet UTP, RoHS:Y
    X7281A-2 371-0904 PCI Express Dual Gigabit Ethernet MMF, RoHS:Y
    X7285A 371-0911 Low Profile PCI-X Dual Gigabit Ethernet UTP, RoHS:Y
    X7286A 371-0912 Low Profile PCI-X Single Gigabit Ethernet MMF, RoHS:Y
    X5559A 375-3361 XFP Optical PCI-X Transceiver Single Mode Fibre, RoHS:YL
    Fan
    Option # Manufacturing
    Part #    		 Description
    n/a 371-0094 Fan Assembly, RoHS:Y
    Fibre Channel
    Option # Manufacturing
    Part #    		 Description
    SG-XPCI1FC-EM4-Z 375-3398 4Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI1FC-QF4 375-3354 4Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI2FC-EM4-Z 375-3399 4Gb PCI-X Dual FC Host Adapter, RoHS:Y
    SG-XPCI2FC-QF4 375-3294 4Gb PCI-X Dual FC Host Adapter, RoHS:Y
    SG-XPCIE1FC-EM4 375-3396 4Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
    SG-XPCIE1FC-EM8-Z 371-4295 8Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
    SG-XPCIE1FC-QF4 375-3355 4Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
    SG-XPCIE1FC-QF8-Z 371-4324 8Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
    SG-XPCIE2FC-EM4 375-3397 4Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
    SG-XPCIE2FC-EM8-Z 371-4306 8Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
    SG-XPCIE2FC-QF4 375-3356 4Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
    SG-XPCIE2FC-QF8-Z 371-4325 8Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
    SG-XPCI1FC-EM2 375-3304 2Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI1FC-QL2 375-3383 2Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI1FC-QLC-Z 375-3364 Entry-Level 2Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI2FC-EM2 375-3305 2Gb PCI-X Dual FC Host Adapter, RoHS:Y
    SG-XPCI2FC-QF2-Z 375-3363 2Gb PCI Dual FC Host Adapter, RoHS:Y
    • 240-4839
    • Low Profile Bracket, RoHS:Y
    Memory
    Option # Manufacturing
    Part #    		 Description
    X8120A-Z 594-2686 2 GB (2 × 1GB DDR1-400 Registered ECC DIMMs), RoHS:YL
    • 371-1096
    • 1 GB DDR1 Memory DIMM, RoHS:Y
    X8121A-Z 594-2687 4 GB (2 × 2GB DDR1-400 Registered ECC DIMMs), RoHS:YL
    • 371-1097
    • 2 GB DDR1 Memory DIMM, RoHS:Y
    n/a F541-1430 2 GB (2 × 1GB) DDR1 Memory DIMM, RoHS:Y
    • 371-1096
    • 1 GB DDR1 Memory DIMM, RoHS:Y
    n/a F541-1431 4 GB (2 × 2GB) DDR1 Memory DIMM, RoHS:Y
    • 371-1097
    • 2 GB DDR1 Memory DIMM, RoHS:Y
    Miscellaneous
    Option # Manufacturing
    Part #    		 Description
    n/a 501-7057 USB Board, RoHS:YL
    Power
    Option # Manufacturing
    Part #    		 Description
    X4094A-Z Power Supply (4 × 950W), RoHS:Y
    300-2013 950 Watt Power Supply (Type A222), RoHS:Y
    n/a 300-1971 850 Watt Power Supply (Type A204), RoHS:Y
    n/a 501-7052 Power Distribution Board, RoHS:YL
    Rack
    Option # Manufacturing
    Part #    		 Description
    X8094A-Z 371-0088 Cable Management Arm Assembly, RoHS:Y
    X8095A-Z 370-7785 Rail Kit Assembly, RoHS:Y
    Removable Media
    Option # Manufacturing
    Part #    		 Description
    n/a 390-0320 8x DVD-ROM / 24x CD-Writer Assembly, RoHS:YL
    SCSI
    Option # Manufacturing
    Part #    		 Description
    SG-XPCI8SAS-E-Z 375-3488 3Gb PCI-X SAS 8-Port Host Adapter, RoHS:Y
    SG-XPCIE2SCSIU320Z 375-3357 Dual-Channel Ultra320 LVD SCSI PCI Express Adapter, RoHS:Y
    SG-XPCIE8SAS-E-Z 375-3487 PCI Express 8-Port Host Adapter, RoHS:Y
    SG-XPCIESAS-E-Z 375-3488 3Gb PCI-X SAS 8-Port Host Adapter, RoHS:Y
    SGXPCI1SCSILM320-Z 375-3366 PCI Single Ultra320 SCSI Adapter
    SGXPCIESAS-R-EXT-Z 371-3253 Lithium Ion Battery Module
    375-3537 8-Port SAS RAID External HBA, RoHS:Y
    System Board
    Option # Manufacturing
    Part #    		 Description
    n/a 501-7588 Motherboard, RoHS:YL
    • 150-3993
    • Panasonic BR2032 Battery, RoHS:Y
    System Service Processor
    Option # Manufacturing
    Part #    		 Description
    n/a 501-7382 Graphics Redirect and Service Processor (GRASP) Board, RoHS:YL

    Industry Leading Quality, Support and Integrity

    Quality Inspection Checklist
    Before it leaves our facility, every used and refurbished item is thoroughly inspected by our certified technicians and undergoes our exclusive Quality Inspection Checklist to ensure 100% satisfaction guarantee.

    Greentec Systems is a leading provider
    For server, networking and storage equipment. We have an extensive array of inventory of IBM Servers & Storage, Sun Servers & Storage, Cisco Networking (Switches, Routers, Security), and NetApp Storage (disk shelves, disk drives, Filers, NearStore, NetCache). If you don’t see the item or product you require please contact us.

    Have this equipment to sell?
    Depending on the age and condition of the equipment, there is a very good likelihood that we will be able to offer you cash or trade-in credit for other IT hardware. If the equipment is very old we can also assist you with properly decommissioning that gear in the most environmentally friendly way possible.

    Questions?
    For more information please contact 888.333.7388, or fill out the quote from above. We’d love to hear from you.

    Request Quote
    Greentec Systems We geek out helping you with your IT infrastructure.
    Request a quote or product information
    Send
