Oracle Sun X4500, RoHS Server

Oracle Sun X4500, RoHS Server Oracle Sun X4500, RoHS Server Sun Servers SUN FIRE X4500 copy

REQUEST A PRICE QUOTE:

    Name*

    Phone

    Details*



    Processor
    Number 2
    Architecture Type: AMD Opteron, Model 285
    Dual Core: 2.6 GHz (95Watt)
    Type: AMD Opteron, Model 290
    Dual Core: 2.8 GHz (95Watt)
    Cache memory 1 MB L2 Cache
    Main Memory
    Capacities DIMM slots per CPU Socket: 4
    DIMM sizes: 2-GB
    DIMM type: DDR1/400 MHz ECC registered DIMMs
    Maximum capacity: 16 GB (when configured with 2-GB DIMMs and 2 CPU Modules)
    Standard Integrated Interfaces
    Network Four 10/100/1000Base-T Ethernet ports, RJ-45 connectors
    Network Management One dedicated 10/100Base-T Ethernet port, RJ-45 connector
    Serial Management One TIA/EIA-232-F asynchronous RJ-45 Serial Connector (on the Graphics Redirect and Service Processor (GRASP) Board)
    SATA Six 8-port SATA controllers, internal access only.
    Video ATI Rage XL Video Chip, VGA Video Port (on the Graphics Redirect and Service Processor (GRASP) Board)
    USB Front: Two USB 2.0 ports
    Rear: Two USB 2.0 ports
    Expansion bus 2 MD2 Low Profile (half-height/half-length), 64-Bit, 133MHz PCI-X Slots.
    Internal Mass Storage
    Disks Internal: forty-eight hot-swappable disk drives for a total of 48 TB of raw storage.
    SW RAID enabled by RAID-Z in Solaris ZFS.
    Drive Type Density Speed Form Factor
    SATA II 250 GB, 500 GB and 1 TB 7,200 RPM 3.5″
    Power Supplies
    Two dual redundant, hot-swappable power supplies.
    UL Maximum( AC Input) 1800W
    Power Supply Rating (DC output) 1500 W
    Typical Power Consumption 1000 W, with 200CFM, max measured is 1100W
    Environment
    AC power Source 200-240 V AC @ 10 Amps
    Temperature Operating: 5° C to 32° C (37° F to 91° F)
    Nonoperating: -40° C to 65° C (-40° F to 149° F)
    Humidity Operating: 10% to 90% relative humidity noncondensing, 27° C (80.6° F) max wet bulb
    Nonoperating: up to 93% relative humidity noncondensing, 38° C (100.4° F) max wet bulb
    Altitude Operating:Up to 3048 m, maximum ambient temperature is derated by 1 degree C per 300 m above 900 m.
    Nonoperating: Up to 4000 m.
    Acoustic noise
    (Measure and Environment)    		 Declared noise emissions in accordance with ISO 9296, A-weighted, operating and idling:
    Less than 83 dB sound power in ambient temperature of up to 24° C
    Regulations
    Meets or exceeds the following requirements:
    RoHS Compliance Level RoHS:YL
    Safety IEC60950, UL/CSA60950-1, EN60950, CB Scheme with all country differences
    RFI/EMI FCC Class A, Part 15 47 CFR, EN55022, CISPR 22, EN300-386:v1.3.2, ICES-003.
    Immunity EN55024,EN300-386:v1.3.2.
    Certifications Safety: cULus Mark, UL/Demko GS Mark, CE Mark, CCC, GOST R, S-Mark
    CE Mark (93/68/EEC), Emissions and Immunity Class A Emissions Levels: FCC, VCCI, C-Tick, MIC,
    CCC, GOST R, BSMI.
    Other: Labeled per WEEE (Waste Electrical and Electrical Equipment) Directive
    Dimensions and Weight
    Height 175 mm (6.75 in.) (4 Rack Units)
    Width 445 mm (17.0 in.) (19″ Rack Mountable)
    Depth 736 mm (29.0 in.)
    Weight



    CPU Module
    Option # Manufacturing
    Part #    		 Description
    n/a 371-4042 2.3 GHz CPU, Opteron 2356 Quad Core, B3 Stepping, 75W, RoHS:Y
    n/a 371-4681 2.6 GHz CPU, Opteron 2435 6-Core, D0 Stepping, 75W, RoHS:Y
    n/a F371-0856 2.6GHz Dual Core CPU, AMD Opteron 285 E6 Stepping (95Watt), RoHS:Y
    • 250-1802
    • Alcohol Wipe Cleaner
    • 310-0049
    • G751 Thermal Grease Syringe, RoHS:Y
    • 371-0856
    • 2.6GHz Dual Core CPU, AMD Opteron 285, E6 Stepping, 95W
    n/a F371-1779 2.8GHz Dual Core CPU, AMD Opteron 290 E6 Stepping, RoHS:YL
    • 250-1802
    • Alcohol Wipe Cleaner
    • 310-0049
    • G751 Thermal Grease Syringe, RoHS:Y
    • 371-1779
    • 2.8GHz Dual Core CPU, AMD Opteron 290, E6 Stepping, 95W, RoHS:YL
    Cables
    Option # Manufacturing
    Part #    		 Description
    X312E Localized Power Code Kit – China, RoHS:Y
    180-1982 IEC 320 C13 to GB 2099/GB 1002 – 10A/250V 2.5M, RoHS:Y
    X312L Localized Power Cord Kit – Continental Europe, RoHS:Y
    180-1993 IEC 320 C13 to CEE 7/7 10A/250V 2.5M Black, RoHS:Y
    X317L Localized Power Cord Kit – U.K., RoHS:Y
    180-1997 IEC 320 C13 to BS 1363 – 10A/250V 2.5M Black, RoHS:Y
    X320A Localized Power Cord Kit – North America/Asia, RoHS:Y
    180-2164 IEC 320 C13 to NEMA 6-15P – 10A/250V 2.0M Black, RoHS:Y
    X330A Power Cord 220V 15A US/Japan, RoHS:Y
    180-2075 Power Cord 220V 15A US/Japan, RoHS:Y
    X340L Power Kit for North America, L6-20 20A Twist Lock Plug, RoHS:Y
    180-2070 NEMA L6-20P to IEC 320 C13 – 4.0M, RoHS:Y
    X384L Localized Power Cord Kit – Italian, RoHS:Y
    180-1996 IEC 320 C13 to CEI 23-16/VII – 10A/250V 2.5M Black, RoHS:Y
    X386L Localized Power Cord Kit – Australian, RoHS:Y
    180-1998 IEC 320 C13 to AS 3112 – 10A/250V 2.5M Black, RoHS:Y
    n/a 180-1995 IEC 320 C13 to Asfnit 107 – 10A/250V 2.5M Black, RoHS:Y
    Communication
    Option # Manufacturing
    Part #    		 Description
    X1333A-4 375-3418 Infiniband PCI-X Card, RoHS:YL
    Disks
    Option # Manufacturing
    Part #    		 Description
    XRA-ST1CH-1T7K 540-7507 1TB – 7200RPM SATA, Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
    • 390-0381
    • Hitachi HUA721010KLA330 [HUA7210SASUN1.0T]
      (1TB – 7200 RPM – SATA Disk), RoHS:Y
    • 390-0479
    • Hitachi H7210CA30 [H7210CA30SUN1.0T] (1TB – 7200 RPM- SATA Disk), RoHS:Y
    • 541-0456
    • Disk Drive Mounting Bracket, RoHS:Y
    XRA-ST1CH-500G7KZ 541-3050 500GB – 7200RPM SATA, Disk Assembly with 1 of the following disks:, RoHS:Y
    • 390-0383
    • Hitachi HUA721050KLA330 [HUA7250SBSUN500G]
      (500GB – 7200 RPM – SATA Disk), RoHS:Y
    • 541-0456
    • Disk Drive Mounting Bracket, RoHS:Y
    XRA-ST1CH-250G7KZ 541-1468 250GB – 7200RPM SATA, Disk Assembly with 1 of the following disks:, RoHS:Y
    • 390-0246
    • Hitachi HDT722525DLA380 [HDS7225SBSUN250G]
      (250GB – 7200 RPM – SATA Disk), RoHS:Y
    • 390-0354
    • Seagate ST3250820NS [ST32500NSSUN250G]
      (250GB – 7200 RPM – SATA Disk), RoHS:Y
    • 541-0456
    • Disk Drive Mounting Bracket, RoHS:Y
    XRA-ST1CH-750G7KZ 540-7244 750GB – 7200RPM SATA, Disk Assembly with 1 of the following disks:, RoHS:Y
    • 390-0379
    • Hitachi HUA721075KLA330 [HUA7275SASUN750G]
      (750GB – 7200 RPM – SATA Disk), RoHS:Y
    • 541-0456
    • Disk Drive Mounting Bracket, RoHS:Y
    n/a 541-1467 500GB – 7200RPM SATA, Disk Assembly with 1 of the following disks:, RoHS:Y
    • 390-0247
    • Hitachi HDS725050KLA360 [HDS7250SASUN500G]
      (500GB – 7200 RPM – SATA Disk), RoHS:Y
    • 541-0456
    • Disk Drive Mounting Bracket, RoHS:Y
    Ethernet
    Option # Manufacturing
    Part #    		 Description
    X5544A-4 10Gb PCI-X Ethernet Adapter, no transceiver, RoHS:Y
    501-7413 10Gb PCI-X Ethernet Adapter, RoHS:Y
    • 370-7665
    • Bracket Standard 10Gb PCI-X Ethernet, RoHS:Y
    • 370-7792
    • Bracket Low-Profile 10Gb PCI-X Ethernet, RoHS:Y
    X5558A 375-3301 10Gb/sec XFP Optical Transceiver Short Range (SR), RoHS:YL
    X7285A 371-0911 Low Profile PCI-X Dual Gigabit Ethernet UTP, RoHS:Y
    X7286A 371-0912 Low Profile PCI-X Single Gigabit Ethernet MMF, RoHS:Y
    Fan
    Option # Manufacturing
    Part #    		 Description
    n/a 541-0458 Fan Module, RoHS:YL
    Fibre Channel
    Option # Manufacturing
    Part #    		 Description
    SG-XPCI1FC-EM4-Z 375-3398 4Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI1FC-QF4 375-3354 4Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI2FC-EM4-Z 375-3399 4Gb PCI-X Dual FC Host Adapter, RoHS:Y
    SG-XPCI2FC-QF4 375-3294 4Gb PCI-X Dual FC Host Adapter, RoHS:Y
    SG-XPCI1FC-EM2 375-3304 2Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI1FC-QL2 375-3383 2Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI1FC-QLC-Z 375-3364 Entry-Level 2Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI2FC-EM2 375-3305 2Gb PCI-X Dual FC Host Adapter, RoHS:Y
    SG-XPCI2FC-QF2-Z 375-3363 2Gb PCI Dual FC Host Adapter, RoHS:Y
    • 240-4839
    • Low Profile Bracket, RoHS:Y
    Memory
    Option # Manufacturing
    Part #    		 Description
    X4231A-Z F541-1903 4GB (2 × 2GB) Memory, RoHS:Y
    • 371-1964
    • 2 GB DDR400/PC3200 DIMM, RoHS:Y
    n/a 371-4180 2GB DDR667/PC2-5300 DIMM, RoHS:Y
    Power
    Option # Manufacturing
    Part #    		 Description
    X4502A-Z 300-1787 Power Supply Type A205, RoHS:YL
    n/a 501-7104 Power Distribution Board, RoHS:YL
    Rack
    Option # Manufacturing
    Part #    		 Description
    X4229A-Z 371-2887 Cable Management Arm, RoHS:Y
    X4541 350-1393 Slide Rail, RoHS:Y
    X4228A-Z 371-3493 Slide Rail, RoHS:Y
    n/a 371-2886 Slide Rail and Cable Management Arm Combo Kit, RoHS:Y
    SCSI
    Option # Manufacturing
    Part #    		 Description
    SG-XPCI8SAS-E-Z 375-3488 3Gb PCI-X SAS 8-Port Host Adapter, RoHS:Y
    SGXPCI1SCSILM320-Z 375-3366 PCI Single Ultra320 SCSI Adapter
    System Board
    Option # Manufacturing
    Part #    		 Description
    B24-BZ2-4540-CONT System Controller Upgrade Kit (X4500 to X4540), RoHS:Y
    541-4144 System Controller Assembly (32GB, 2 × 2.6GHz), RoHS:YL
    • 310-0141
    • Heatsink with Captive Screws and Springs, RoHS:Y
    • 371-4180
    • 2GB DDR667/PC2-5300 DIMM, RoHS:Y
    • 371-4681
    • 2.6 GHz CPU, Opteron 2435 6-Core, D0 Stepping, 75W, RoHS:Y
    • 541-3758
    • System Controller Assembly, RoHS:YL
    B24-FSZ2-4540-CONT System Controller Upgrade Kit (X4500 to X4540), RoHS:YL
    541-3431 Upgraded X4540 System Controller (32GB, 2× 2.36GHz), RoHS:YL
    • 310-0141
    • Heatsink with Captive Screws and Springs, RoHS:Y
    • 371-4042
    • 2.3 GHz CPU, Opteron 2356 Quad Core, B3 Stepping, 75W, RoHS:Y
    • 371-4180
    • 2GB DDR667/PC2-5300 DIMM, RoHS:Y
    • 541-3758
    • System Controller Assembly, RoHS:YL
    n/a 541-0776-09 System Controller Assembly (8 × 2GB) (2 × 2.6GHz), RoHS:YL
    • 541-0597
    • Graphics Redirect and Service Processor (GRASP) Assembly, RoHS:YL
    • 501-7160
    • Graphics Board, RoHS:YL
    • 501-7383
    • Service Processor, RoHS:YL
    • 541-0780
    • System Controller Assembly, RoHS:YL
    • 501-7102
    • I/O Board, RoHS:YL
    • 501-7273
    • CPU Board (2 × 2.6GHz), RoHS:YL
    • 150-3993
    • Panasonic BR2032 Battery, RoHS:Y
    • 240-4987
    • 25mm Heatsink Shoulder Screw, RoHS:Y
    • 240-4988
    • 10mm Heatsink Spring, RoHS:Y
    • 310-0072
    • Heatsink, RoHS:Y
    • 371-0856
    • 2.6GHz Dual Core CPU, AMD Opteron 285, E6 Stepping, 95W
    • 500-7101
    • CPU/Memory Board, RoHS:YL
    • 541-0476
    • Rear I/O Panel, RoHS:Y
    n/a 541-0776-10 System Controller Assembly (8 × 2GB) (2 × 2.8GHz), RoHS:YL
    • 240-4987
    • 25mm Heatsink Shoulder Screw, RoHS:Y
    • 240-4988
    • 10mm Heatsink Spring, RoHS:Y
    • 310-0072
    • Heatsink, RoHS:Y
    • 371-1779
    • 2.8GHz Dual Core CPU, AMD Opteron 290, E6 Stepping, 95W, RoHS:YL
    • 541-0597
    • Graphics Redirect and Service Processor (GRASP) Assembly, RoHS:YL
    • 501-7160
    • Graphics Board, RoHS:YL
    • 501-7383
    • Service Processor, RoHS:YL
    • 541-1915
    • System Controller Assembly, RoHS:YL
    • 501-7102
    • I/O Board, RoHS:YL
    • 501-7641
    • CPU Board, RoHS:YL
    • 150-3993
    • Panasonic BR2032 Battery, RoHS:Y
    • 500-7101
    • CPU/Memory Board, RoHS:YL
    System Service Processor
    Option # Manufacturing
    Part #    		 Description
    n/a 541-0597 Graphics Redirect and Service Processor (GRASP) Assembly, RoHS:YL
    • 501-7160
    • Graphics Board, RoHS:YL
    • 501-7383
    • Service Processor, RoHS:YL
    n/a 541-2963 Graphics Redirect and Service Processor (GRASP) Assembly, RoHS:YL
    • 501-7383
    • Service Processor, RoHS:YL
    • 511-1045
    • Graphics Board, RoHS:YL
