Oracle Sun X4270 Server

REQUEST A PRICE QUOTE:

Processor

Number

1 or 2 Intel Quad-Core

Architecture

Type: Intel Xeon 5500 series Quad-Core Processors

CPUs

Intel Xeon X5570 2.93 GHz (8MB cache, 6.4 GY/s QPI, SMT, Turbo, 95W)
Intel Xeon X5560 2.80 GHz (8MB cache, 6.4 GY/s QPI, SMT, Turbo, 95W)
Intel Xeon E5540 2.53 GHz (8MB cache, 5.86 GY/s QPI, SMT, Turbo, 80W)
Intel Xeon L5520 2.26 GHz (8MB cache, 5.86 GY/s QPI, SMT, Turbo, 60W)
Intel Xeon E5520 2.26 GHz (8MB cache, 5.86 GY/s QPI, SMT, Turbo, 80W)

Cache memory

8MB Level 2

Main Memory

Capacities

Total DIMM slots: 18
DIMM type: DDR3 1066MHz or 1333MHz Registered DIMMs
DIMM size: 2-GB, 4-GB, 8-GB 1066MHz or 4-GB 1333MHz
Maximum capacity: 144GB (when configured with 8-GB DIMMs)

Standard Integrated Interfaces

Network

Four 10/100/1000 Base-T Ethernet Ports

Network Management

One dedicated 10/100Base-T Ethernet port

Serial Management

One dedicated TIA/EIA-232-F asynchronous RJ45 port

SAS

Four channel SAS interface, internal access only

USB

Front: Two USB 2.0 ports
Rear: Two USB 2.0 ports
Internal: One USB 2.0 port

PCI Expansion Slots

Six internal MD2 low profile 8-lane PCI Express slots (all with x8 mechanical connectors)

Internal Mass Storage

Disks

SAS: Up to sixteen internal 2.5″ SAS or SSD Disks with add-on SAS Host Bus Adapter

Drive Type	Density	Speed	Form Factor
SAS	73 GB	15,000 RPM	2.5″
SAS	300 GB	10,000 RPM	2.5″
SAS	146 GB	10,000 RPM	2.5″
Solid State Drive	32 GB	NA	2.5″

DVD-ROM

One SATA DVD+/-RW drive

Power Supplies

Dual redundant, hot swappable power supplies
(Power supply rating output = 1050W)
(UL Maximum AC input = 1050W x 1.33 efficiency = 1397W)
(8.2 Amps RMS at 100 VAC)

Environment

AC power

90-264 V AC (47-63 Hz)

Temperature

Single, non-rack system:
Operating: 5° C to 35° C (41° F to 95° F)
Nonoperating: -40° C to 70° C (-40° F to 158° F)

Humidity

Single, non-rack system:
Operating: 10% to 90% relative humidity noncondensing, 38° C (100.4° F) max wet bulb
Nonoperating: up to 93% relative humidity noncondensing

Altitude

Single, non-rack system:
Operating: up to 3048 m (10000 ft.), maximum ambient temperature is derated by 1° C per 300 m above 900 m
Nonoperating: 15kPa

Acoustic noise

Single, non-rack system:
LwAd (1B=10dB)
7.7 B at max ambient
LwAd bystander
65.8 dB at max ambient

Regulations
Meets or exceeds the following requirements:

RoHS Compliance Level

RoHS:YL

Safety

UL/cUL, CE, BSMI, GOST-R, S-Mark, CSA C22.2 No. 60950-03

RFI/EMI

FCC CFR 47 Part 15 Class A, EN55022 Class A, EN 61000-3-2, EN61000-3-3, EN 300-386

Immunity

EN55024, EN300-386

Certifications

Safety: UL/cUL, UL DEMKO, CE, BSMI, CCC, GOST-R, S-Mark
EMC: CE, FCC, VCCI, ICES, C-Tick, MIC, CCC, GOST-R, BSMI Class A

Other

Complies with WEEE Directive (2002/96/EC) and RoHS Directive (2002/95/EC)

Dimensions and Weight

Height

84.84 mm (3.34 in.)

Width

425.5 mm (16.75 in.)

Depth

685.8 mm (27 in.)

Weight

22.27 kg (49 lb.)

CPU Module
Option #	Manufacturing Part #	Description
X5861A-2U	371-4298	2.93GHz Intel Quad-Core Xeon X5570, 8MB, 95W
	541-3310	Xeon Heatsink w/Grease, RoHS:Y
	240-6751	Heatsink Spring, RoHS:Y
	310-0211	Pre-greased Heatsink
X5862A-2U	371-4299	2.80GHz Intel Quad-Core Xeon X5560, 8MB, 95W, RoHS:Y
	541-3310	Xeon Heatsink w/Grease, RoHS:Y
	240-6751	Heatsink Spring, RoHS:Y
	310-0211	Pre-greased Heatsink
X5863A-2U	371-4300	2.53GHz Intel Quad-Core Xeon E5540, 8MB, 80W, RoHS:Y
	541-3310	Xeon Heatsink w/Grease, RoHS:Y
	240-6751	Heatsink Spring, RoHS:Y
	310-0211	Pre-greased Heatsink
X5864A-2U	371-4302	2.26GHz Intel Quad-Core Xeon L5520, 8MB, 60W, RoHS:Y
	541-3310	Xeon Heatsink w/Grease, RoHS:Y
	240-6751	Heatsink Spring, RoHS:Y
	310-0211	Pre-greased Heatsink
X5865A-2U	371-4477	2.26GHz Intel Quad-Core Xeon E5520, 8MB, 80W, RoHS:Y
	541-3310	Xeon Heatsink w/Grease, RoHS:Y
	240-6751	Heatsink Spring, RoHS:Y
	310-0211	Pre-greased Heatsink

Cables
Option #	Manufacturing Part #	Description
X311L	Localized Power Cord Kit – North America/Asia, RoHS:Y
X311L	180-1097	IEC 320 C13 to NEMA 5-15P – 15A/125V 2.5M Black, RoHS:Y
X312E	Localized Power Code Kit – China, RoHS:Y
X312E	180-1982	IEC 320 C13 to GB 2099/GB 1002 – 10A/250V 2.5M, RoHS:Y
X312F	Localized Power Cord Kit – Argentina, RoHS:Y
X312F	180-1999	IEC 320 C13 to IRAM 2073 – 10A/250V 2.5M Black, RoHS:Y
X312G	Localized Power Cord Kit – Korea, RoHS:Y
X312G	180-1662	IEC 320 C13 to KSC 8305 – 15A/250V 2.5M Black, RoHS:Y
X312L	Localized Power Cord Kit – Continental Europe, RoHS:Y
X312L	180-1993	IEC 320 C13 to CEE 7/7 10A/250V 2.5M Black, RoHS:Y
X314L	Localized Power Cord Kit – Swiss, RoHS:Y
X314L	180-1994	IEC 320 C13 to SEV 1011 – 10A/250V 2.5M Black, RoHS:Y
X317L	Localized Power Cord Kit – U.K., RoHS:Y
X317L	180-1997	IEC 320 C13 to BS 1363 – 10A/250V 2.5M Black, RoHS:Y
X332A	Localized Power Cord Kit – Taiwan, RoHS:Y
X332A	180-2121	IEC 320 C13 to NEMA 5-15P – 10A/125V 2.5M Black, RoHS:Y
X383L	Localized Power Cord Kit – Danish, RoHS:Y
X383L	180-1995	IEC 320 C13 to Asfnit 107 – 10A/250V 2.5M Black, RoHS:Y
X384L	Localized Power Cord Kit – Italian, RoHS:Y
X384L	180-1996	IEC 320 C13 to CEI 23-16/VII – 10A/250V 2.5M Black, RoHS:Y
X386L	Localized Power Cord Kit – Australian, RoHS:Y
X386L	180-1998	IEC 320 C13 to AS 3112 – 10A/250V 2.5M Black, RoHS:Y

Communication
Option #	Manufacturing Part #	Description
X4237A	375-3606	Sun Dual Port 40Gb/sec 4x Infiniband QDR Host Channel Adapter PCI Express, RoHS:Y
X1236A-Z	375-3382	Dual Port 10Gb/sec 4x PCI Express Infiniband Host Channel Adapter – Low Profile, RoHS:Y
X4217A-Z	375-3549	Dual Port 20Gb/sec 4x PCI Express Infiniband Host Channel Adapter – Low Profile, RoHS:Y

Disk Backplane
Option #	Manufacturing Part #	Description
n/a	511-1257	16-Slot Disk Backplane, SATA DVD, RoHS:YL
n/a	542-0355	Backplane Retainer Clip Kit
n/a	330-5301	Grey 2U Backplane Retainer Clip

Disks
Option #	Manufacturing Part #	Description
XRA-SS2CF-146G10K2	542-0217	146GB – 10000 RPM SAS2 SFF Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
	390-0448	Seagate ST9146803SS [ST914603SSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0450	Hitachi HUC103014CSS600 [H103014SCSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	541-2123	Marlin Bracket 2.5″, RoHS:Y
XRA-SS2CF-300G10K	540-7869	300GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
	390-0449	Seagate ST93000SSUNG [ST930003SSUN300G] (300GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0451	Hitachi HUC103030CSS600 [H103030SCSUN300G] (300GB – 10000 RPM – SAS Disk), RoHS:Y
	541-2123	Marlin Bracket 2.5″, RoHS:Y
XRA-ST2CF-32G2SSD	540-7841	32GB Solid State Drive Assembly, SATA Interface, RoHS:Y
	371-4196	32GB Solid State Drive, SATA Interface, RoHS:Y
	541-2123	Marlin Bracket 2.5″, RoHS:Y
XRA-ST2CF-500G7K	542-0184	500GB – 7200 RPM SATA Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
	390-0468	Seagate ST9500530NS [ST95000NSSUN500G] (500GB – 7200 RPM – SATA Disk), RoHS:Y
	541-4199	Marlin Bracket 15mm, RoHS:Y
XRB-SS2CF-146G10K	540-7868	146GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
	390-0324	Seagate ST9146802SS [ST914602SSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0377	Hitachi HUC101414CSS300 [H101414SCSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0448	Seagate ST9146803SS [ST914603SSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0450	Hitachi HUC103014CSS600 [H103014SCSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	541-2123	Marlin Bracket 2.5″, RoHS:Y
XRA-SS2CF-146G10K	540-7355	146GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
	390-0324	Seagate ST9146802SS [ST914602SSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0375	Fujitsu MBB2147RC [MBB2147RCSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0377	Hitachi HUC101414CSS300 [H101414SCSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	541-2123	Marlin Bracket 2.5″, RoHS:Y
XRA-SS2CF-73G15K	540-7361	73GB – 15000 RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks, RoHS:Y
	390-0382	Seagate ST973451SS [ST973451SSUN72G] (73GB – 15000 RPM – SAS Disk), RoHS:Y
	541-2123	Marlin Bracket 2.5″, RoHS:Y

Ethernet
Option #	Manufacturing Part #	Description
SG-XPCIEFCOE2-Q-SR	375-3681	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA – SR, RoHS:Y
SG-XPCIEFCOE2-Q-TA	375-3682	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA – Direct Attach, RoHS:Y
X1106A-Z	375-3585	Intel PRO/10GbE-SR x8 PCI Express Low Profile Bracket, RoHS:Y
X1107A-Z	375-3586	Intel PRO/10GbE-SR x8 PCI Express Low Profile Bracket, RoHS:Y
X1109A-Z	375-3617	Dual 10-Gigabit Ethernet SFP+ LP, RoHS:Y
X4446A-Z	375-3481	PCI Express Quad Gigabit Ethernet UTP, RoHS:Y
X7280A-2	371-0905	PCI Express Dual Gigabit Ethernet UTP, RoHS:Y
X7281A-2	371-0904	PCI Express Dual Gigabit Ethernet MMF, RoHS:Y

Fan
Option #	Manufacturing Part #	Description
n/a	541-2211	Fan Power Board, RoHS:Y
	330-4463	Top Bracket, RoHS:Y
	330-4464	Bottom Bracket, RoHS:Y
	501-7695	Fan Board, RoHS:Y
n/a	541-3290	CPU Dual Fan Assembly w/ Metal Fingerguards, RoHS:Y
n/a	310-0210	Fan, 60×38mm, 2U, RoHS:Y

Fibre Channel
Option #	Manufacturing Part #	Description
SG-XPCIE1FC-EM4	375-3396	4Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
SG-XPCIE1FC-EM8-Z	371-4295	8Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
SG-XPCIE1FC-QF4	375-3355	4Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
SG-XPCIE1FC-QF8-Z	371-4324	8Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
SG-XPCIE2FC-EM4	375-3397	4Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
SG-XPCIE2FC-EM8-Z	371-4306	8Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
SG-XPCIE2FC-QF4	375-3356	4Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
SG-XPCIE2FC-QF8-Z	371-4325	8Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y

I/O
Option #	Manufacturing Part #	Description
n/a	541-2884	x8/x8 PCI Express Riser Assembly, RoHS:Y
	501-7964	x8/x8 PCI Express Riser, RoHS:Y
	541-2531	Bracket, RoHS:Y
n/a	541-3356	x8/x8 Switched PCI Express Riser Assembly, RoHS:Y
	511-1139	x8/x8 Switched PCI Express Riser, RoHS:Y
	541-2531	Bracket, RoHS:Y

Memory
Option #	Manufacturing Part #	Description
X4680A	375-3590	16GB Compact Flash, RoHS:Y
X5868A	371-4285	8GB Registered DDR3-1066 DIMM, RoHS:Y
X5866A	371-4282	2GB Registered DDR3-1066 DIMM, RoHS:Y
X5867A	371-4283	4GB Registered DDR3-1066 DIMM, RoHS:Y
X5869A	371-4287	2GB Registered DDR3-1333 DIMM, RoHS:Y
X5870A	371-4288	4GB Registered DDR3-1333 DIMM, RoHS:Y

Power
Option #	Manufacturing Part #	Description
X6328A	300-1897	1050 Watt Power Supply, Type A217, RoHS:Y
n/a	541-2073	Power Distribution Board/Bus Bar Assembly, RoHS:Y
	341-3166	Bus Bar Left, RoHS:Y
	341-3167	Bus Bar Right, RoHS:Y
	371-2484	PDB Signal Cable, RoHS:Y
	501-7697	Horizontal Power Distribution Board, RoHS:Y
	501-7951	Vertical Power Distribution Board, RoHS:Y

Rack
Option #	Manufacturing Part #	Description
X6324A	371-2742	Cable Management Arm, RoHS:Y
X6325A	371-2740	Snap-In Slide Rail Rackmount Kit, 730mm, RoHS:Y
X6326A	371-2741	Screw-Mount Slide Rail Rackmount Kit, 730mm, RoHS:Y

Removable Media
Option #	Manufacturing Part #	Description
X8325A	541-3493	SATA DVD-Writer/CD-Writer – USB Board Assembly, RoHS:Y
	330-5056	DVD Interconnect Holder, RoHS:Y
	390-0442	8x SATA DVD-Writer/24x CD-Writer, RoHS:Y
	390-0443	8x SATA DVD-Writer/24x CD-Writer, RoHS:Y
	501-7698	USB Board, RoHS:Y
	541-3686	DVD Bezel, RoHS:Y
n/a	541-2732	USB Assembly, RoHS:Y
	330-4418	DVD Interconnect Holder, RoHS:Y
	341-4072	DVD Filler Panel, RoHS:Y
	501-7698	USB Board, RoHS:Y

SCSI
Option #	Manufacturing Part #	Description
SG-XPCIE2SCSIU320Z	375-3357	Dual-Channel Ultra320 LVD SCSI PCI Express Adapter, RoHS:Y
SG-XPCIE8SAS-E-Z	375-3487	PCI Express 8-Port Host Adapter, RoHS:Y
SG-XPCIE8SAS-I-Z	371-3255	PCI Express 8-Port SAS Controller, RoHS:Y
SGXPCIESAS-R-EXT-Z	371-3253	Lithium Ion Battery Module
SGXPCIESAS-R-EXT-Z	375-3537	8-Port SAS RAID External HBA, RoHS:Y
SGXPCIESAS-R-INT-Z	371-3253	Lithium Ion Battery Module
SGXPCIESAS-R-INT-Z	375-3536	8-Port SAS Adaptec RAID HBA, RoHS:Y

System Board
Option #	Manufacturing Part #	Description
n/a	341-4139	PCI Filler Panel, RoHS:Y
n/a	541-2542	System Board Assembly, RoHS:Y
	501-7917	System Board, RoHS:Y
	150-3993	Panasonic BR2032 Battery, RoHS:Y
	541-2543	System Board Tray, RoHS:Y

Industry Leading Quality, Support and Integrity

Quality Inspection Checklist
Before it leaves our facility, every used and refurbished item is thoroughly inspected by our certified technicians and undergoes our exclusive Quality Inspection Checklist to ensure 100% satisfaction guarantee.

Greentec Systems is a leading provider
For server, networking and storage equipment. We have an extensive array of inventory of IBM Servers & Storage, Sun Servers & Storage, Cisco Networking (Switches, Routers, Security), and NetApp Storage (disk shelves, disk drives, Filers, NearStore, NetCache). If you don’t see the item or product you require please contact us.

Have this equipment to sell?
Depending on the age and condition of the equipment, there is a very good likelihood that we will be able to offer you cash or trade-in credit for other IT hardware. If the equipment is very old we can also assist you with properly decommissioning that gear in the most environmentally friendly way possible.

Questions?
For more information please contact 888.333.7388, or fill out the quote from above. We’d love to hear from you.
