Oracle Sun X4250 Server

REQUEST A PRICE QUOTE:

Processor

Number

1 or 2 Dual-Core or Quad-Core

Architecture

Type: Intel Dual-Core or Quad-Core Processors

CPUs

Dual-Core Intel Xeon X5260 (6MB L2, 3.33 GHz, 1333 MHz FSB, 80W)
Dual-Core Intel Xeon X5270 (6MB L2, 3.50 GHz, 1333 MHz FSB, 80W)
Quad-Core Intel Xeon L5420 (2x6MB L2, 2.5 GHz, 1066 MHz FSB, 50W)
Quad-Core Intel Xeon E5410 (2x6MB L2, 2.33 GHz, 1066 MHz FSB, 80W)
Quad-Core Intel Xeon E5440 (2x6MB L2, 2.83 GHz, 1333 MHz FSB, 80W)
Quad-Core Intel Xeon E5450 (2x6MB L2, 3.0 GHz, 1333 MHz FSB, 80W)
Quad-Core Intel Xeon X5460 (2x6MB L2, 3.16 GHz, 1333 MHz FSB, 120W)
Quad-Core Intel Xeon L5430 (2x6MB L2, 2.66 GHz, 1333 MHz FSB, 50W)
Quad-Core Intel Xeon X5470 (2x6MB L2, 3.33 GHZ, 1333 MHz FSB, 120W)

Cache memory

6MB Level 2 for Dual-Core
2x6MB Level 2 for Quad-Core

Main Memory

Capacities

Total DIMM slots: 16
DIMM type: PC2-5300 DDR2 667MHz Registered DIMMs (128 bit plus ECC databus)
DIMM size: 2-GB or 4-GB
Maximum capacity: 64GB (when configured with 4-GB DIMMs)
NOTE: DIMMs must be installed in pairs. Pairs of different densities may be mixed.

Standard Integrated Interfaces

Network

Four 10/100/1000 Base-T Ethernet Ports

Network Management

One dedicated 10/100Base-T Ethernet port

Serial Management

One dedicated TIA/EIA-232-F asynchronous RJ45 port

SAS

Eight channel SAS interfaces for internal or external drives with add-on SAS Host Bus Adapter.

USB

Front: Two USB 2.0 ports
Rear: Two USB 2.0 ports
Internal: One USB 2.0 port

PCI Expansion Slots

Six internal MD2 low profile 8-lane PCI Express slots (all with x8 mechanical connectors)

Internal Mass Storage

Disks

SAS: Up to sixteen internal 2.5″ SAS Disks with add-on SAS Host Bus Adapter

Drive Type	Density	Speed	Form Factor
SAS	73 GB	10,000 RPM	2.5″
SAS	73 GB	15,000 RPM	2.5″
SAS	146 GB	10,000 RPM	2.5″
SAS	300 GB	10,000 RPM	2.5″

DVD-ROM

One EIDE DVD+/-RW drive

Power Supplies

Dual redundant, hot swappable power supplies
(Power supply rating output = 1050W)
(UL Maximum AC input = 1050W x 1.33 efficiency = 1397W)
(12 Amps RMS at 100 VAC)

Environment

AC power

90-264 V AC (47-63 Hz)

Temperature

Single, non-rack system:
Operating: 5° C to 35° C (41° F to 95° F)
Nonoperating: -40° C to 70° C (-40° F to 158° F)

Humidity

Single, non-rack system:
Operating: 10% to 90% relative humidity noncondensing, 38° C (100.4° F) max wet bulb
Nonoperating: up to 93% relative humidity noncondensing

Altitude

Single, non-rack system:
Operating: up to 3048 m (10000 ft.), maximum ambient temperature is derated by 1° C per 300 m above 900 m
Nonoperating: 15kPa

Acoustic noise

Single, non-rack system:
LwAd (1B=10dB)
7.7 B at max ambient
LwAd bystander
65.8 dB at max ambient

Regulations
Meets or exceeds the following requirements:

RoHS Compliance Level

RoHS:YL

Safety

IEC60950, UL/CSA60950, EN60950, CB Scheme with all country differences

RFI/EMI

FCC CFR 47 Part 15 Class A, EN55022 Class A, EN 61000-3-2, EN61000-3-3, EN 300-386

Immunity

EN55024, EN300-386

Certifications

Safety: UL/cUL, UL DEMKO, CE, BSMI, CCC, GOST-R, S-Mark
EMC: CE, FCC, VCCI, ICES, C-Tick, MIC, CCC, GOST-R, BSMI Class A

Other

Complies with WEEE Directive (2002/96/EC) and RoHS Directive (2002/95/EC)

Dimensions and Weight

Height

88 mm (3.49 in.)

Width (not including ears)

426 mm (16.75 in.)

Width (including ears)

426 mm (16.75 in.)

Depth (not including PSU handle)

714 mm (28.125 in.)

Depth (including PSU handle)

733.65 mm (28.88 in.)

Weight

25.6 kg (56.3 lb.) maximum assuming PCI-Express card weighs 0.12 kg
(0.25 lb) each, and without the rack mounting slide rail kit installed.

Batteries
Option #	Manufacturing Part #	Description
n/a	371-2210	CR2032 3V Battery, RoHS:Y

CPU Module
Option #	Manufacturing Part #	Description
X6390A	3.33GHz Dual-Core Xeon X5260, RoHS:YL
	310-0153	Xeon Heatsink, RoHS:Y
	371-3948	3.33 GHz CPU, Xeon X5260, Dual Core, 80W, RoHS:Y
X6391A	2.33GHz Quad-Core Xeon E5410, RoHS:Y
	310-0153	Xeon Heatsink, RoHS:Y
	371-3950	2.33GHz CPU, Xeon E5410 Quad Core, 80W, RoHS:Y
X6392A	2.83GHz Quad-Core Xeon E5440, RoHS:Y
	310-0153	Xeon Heatsink, RoHS:Y
	371-3949	2.83GHz CPU, Xeon E5440 Quad Core, 80W, RoHS:Y
X6393A	3.16GHz Quad-Core Xeon X5460, RoHS:Y
	310-0153	Xeon Heatsink, RoHS:Y
	371-3952	3.16GHz CPU, Xeon X5460 Quad Core, 1333MHz FSB, 120W, RoHS:Y
X6394A	2.5GHz Quad-Core Xeon L5420, RoHS:Y
	310-0153	Xeon Heatsink, RoHS:Y
	371-3951	2.5GHz CPU, Xeon L5420 Quad Core, 1333MHz FSB, 50W, RoHS:Y
X6395A	3.00GHz Quad-Core Xeon E5450, RoHS:YL
	310-0153	Xeon Heatsink, RoHS:Y
	371-4146	3.00GHz CPU, Xeon E5450 Quad Core, 80W, RoHS:Y
X6396A	3.5GHz Dual-Core Xeon X5270, RoHS:YL
	310-0153	Xeon Heatsink, RoHS:Y
	371-4388	3.5GHz CPU, Xeon X5270 Dual Core, 80W, RoHS:Y
X6397A	2.66GHz Quad-Core Xeon L5430, RoHS:YL
	310-0153	Xeon Heatsink, RoHS:Y
	371-4389	2.66GHz CPU, Xeon L5430 Quad Core, 50W, RoHS:Y
X6398A	3.33GHz Quad-Core Xeon X5470, RoHS:YL
	310-0153	Xeon Heatsink, RoHS:Y
	371-4390	3.33GHz CPU, Xeon X5470 Quad Core, 120W, RoHS:Y
n/a	350-1271	Thermal Grease FRU w/ Alcohol Wipe
	250-1802	Alcohol Wipe Cleaner
	310-0065	Thermal Grease, Syringe, RoHS:Y

Cables
Option #	Manufacturing Part #	Description
n/a	530-4082	4x Mini SAS Cable Pair, RoHS:Y

Communication
Option #	Manufacturing Part #	Description
X6000A	375-3424	PCI Express Sun Crypto Accelerator 6000, RoHS:Y
X1236A-Z	375-3382	Dual Port 10Gb/sec 4x PCI Express Infiniband Host Channel Adapter – Low Profile, RoHS:Y
X4217A-Z	375-3549	Dual Port 20Gb/sec 4x PCI Express Infiniband Host Channel Adapter – Low Profile, RoHS:Y

Disk Backplane
Option #	Manufacturing Part #	Description
n/a	501-7760	16-Slot Disk Backplane, PATA DVD, RoHS:YL
n/a	511-1257	16-Slot Disk Backplane, SATA DVD, RoHS:YL
n/a	542-0355	Backplane Retainer Clip Kit
n/a	330-5301	Grey 2U Backplane Retainer Clip

Disks
Option #	Manufacturing Part #	Description
XRA-SS2CF-300G10K	540-7869	300GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
	390-0449	Seagate ST93000SSUNG [ST930003SSUN300G] (300GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0451	Hitachi HUC103030CSS600 [H103030SCSUN300G] (300GB – 10000 RPM – SAS Disk), RoHS:Y
	541-2123	Marlin Bracket 2.5″, RoHS:Y
XRA-ST2CF-32G2SSD	540-7841	32GB Solid State Drive Assembly, SATA Interface, RoHS:Y
	371-4196	32GB Solid State Drive, SATA Interface, RoHS:Y
	541-2123	Marlin Bracket 2.5″, RoHS:Y
XRB-SS2CF-146G10K	540-7868	146GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
	390-0324	Seagate ST9146802SS [ST914602SSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0377	Hitachi HUC101414CSS300 [H101414SCSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0448	Seagate ST9146803SS [ST914603SSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0450	Hitachi HUC103014CSS600 [H103014SCSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	541-2123	Marlin Bracket 2.5″, RoHS:Y
XRA-SS2CF-146G10K	540-7355	146GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
	390-0324	Seagate ST9146802SS [ST914602SSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0375	Fujitsu MBB2147RC [MBB2147RCSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0377	Hitachi HUC101414CSS300 [H101414SCSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	541-2123	Marlin Bracket 2.5″, RoHS:Y
XRA-SS2CF-73G10K	540-7354	73GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
	390-0285	Fujitsu MAY2073RC [MAY2073RCSUN72] (73GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0323	Seagate ST973402SS [ST973402SSUN72G] (73GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0374	Fujitsu MBB2073RC [MBB2073RCSUN72G] (73.4GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0376	Hitachi HUC101473CSS300 [H101473SCSUN72G] (73.4GB – 10000 RPM – SAS Disk), RoHS:Y
	541-2123	Marlin Bracket 2.5″, RoHS:Y
XRA-SS2CF-73G15K	540-7361	73GB – 15000 RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks, RoHS:Y
	390-0382	Seagate ST973451SS [ST973451SSUN72G] (73GB – 15000 RPM – SAS Disk), RoHS:Y
	541-2123	Marlin Bracket 2.5″, RoHS:Y

Ethernet
Option #	Manufacturing Part #	Description
SG-XPCIEFCOE2-Q-SR	375-3681	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA – SR, RoHS:Y
SG-XPCIEFCOE2-Q-TA	375-3682	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA – Direct Attach, RoHS:Y
X1027A-Z	501-7283	PCI Express Dual 10-Gigabit Ethernet Fiber, RoHS:Y
X1106A-Z	375-3585	Intel PRO/10GbE-SR x8 PCI Express Low Profile Bracket, RoHS:Y
X1107A-Z	375-3586	Intel PRO/10GbE-SR x8 PCI Express Low Profile Bracket, RoHS:Y
X4446A-Z	375-3481	PCI Express Quad Gigabit Ethernet UTP, RoHS:Y
X5558A	375-3301	10Gb/sec XFP Optical Transceiver Short Range (SR), RoHS:YL
X5560A-Z	375-3495	10Gb/sec XFP Optical Transceiver Long Range (LR), RoHS:Y
X7280A-2	371-0905	PCI Express Dual Gigabit Ethernet UTP, RoHS:Y
X7281A-2	371-0904	PCI Express Dual Gigabit Ethernet MMF, RoHS:Y

Fan
Option #	Manufacturing Part #	Description
n/a	541-2211	Fan Power Board, RoHS:Y
	330-4463	Top Bracket, RoHS:Y
	330-4464	Bottom Bracket, RoHS:Y
	501-7695	Fan Board, RoHS:Y
n/a	541-2940	CPU Dual Fan Assembly w/ Metal Fingerguards, RoHS:Y
n/a	310-0119	Delta Fan, 60×38mm, 2U, RoHS:Y
n/a	541-3290	CPU Dual Fan Assembly w/ Metal Fingerguards, RoHS:Y
n/a	310-0210	Fan, 60×38mm, 2U, RoHS:Y

Fibre Channel
Option #	Manufacturing Part #	Description
SG-XPCIE1FC-EM4	375-3396	4Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
SG-XPCIE1FC-QF4	375-3355	4Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
SG-XPCIE2FC-EM4	375-3397	4Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
SG-XPCIE2FC-EM8-Z	371-4306	8Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
SG-XPCIE2FC-QF4	375-3356	4Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y

I/O
Option #	Manufacturing Part #	Description
n/a	540-7692	x8 PCI Express Riser Pair, RoHS:Y
n/a	371-4112	x8 PCI Express Riser Pair, RoHS:Y

Memory
Option #	Manufacturing Part #	Description
X6381A	540-7347	4GB (2 × 2GB) Memory FRU, RoHS:Y
X6381A	371-3068	2GB Registered ECC DDR2-667/PC2-5300 DIMM, RoHS:Y
X6382A	540-7348	8GB (2 × 4GB) Memory FRU, RoHS:Y
X6382A	371-3069	4GB Registered ECC DDR2-667/PC2-5300 DIMM, RoHS:Y

Power
Option #	Manufacturing Part #	Description
X6328A	300-1897	1050 Watt Power Supply, Type A217, RoHS:Y
n/a	541-2073	Power Distribution Board/Bus Bar Assembly, RoHS:Y
	341-3166	Bus Bar Left, RoHS:Y
	341-3167	Bus Bar Right, RoHS:Y
	371-2484	PDB Signal Cable, RoHS:Y
	501-7697	Horizontal Power Distribution Board, RoHS:Y
	501-7951	Vertical Power Distribution Board, RoHS:Y

Rack
Option #	Manufacturing Part #	Description
X6324A	371-2742	Cable Management Arm, RoHS:Y
X6325A	371-2740	Snap-In Slide Rail Rackmount Kit, 730mm, RoHS:Y
X6326A	371-2741	Screw-Mount Slide Rail Rackmount Kit, 730mm, RoHS:Y

Removable Media
Option #	Manufacturing Part #	Description
X6323A	541-2110	PATA DVD-Writer/CD-Writer – USB Board Assembly, RoHS:Y
	330-4418	DVD Interconnect Holder, RoHS:Y
	390-0337	8x PATA DVD-Writer/24x CD-Writer, RoHS:Y
	501-7698	USB Board, RoHS:Y
	541-2111	DVD Bezel, RoHS:Y
X6386A	541-3493	SATA DVD-Writer/CD-Writer – USB Board Assembly, RoHS:Y
	330-5056	DVD Interconnect Holder, RoHS:Y
	390-0442	8x SATA DVD-Writer/24x CD-Writer, RoHS:Y
	390-0443	8x SATA DVD-Writer/24x CD-Writer, RoHS:Y
	501-7698	USB Board, RoHS:Y
	541-3686	DVD Bezel, RoHS:Y
n/a	541-2732	USB Assembly, RoHS:Y
	330-4418	DVD Interconnect Holder, RoHS:Y
	341-4072	DVD Filler Panel, RoHS:Y
	501-7698	USB Board, RoHS:Y

SCSI
Option #	Manufacturing Part #	Description
SG-XPCIE2SCSIU320Z	375-3357	Dual-Channel Ultra320 LVD SCSI PCI Express Adapter, RoHS:Y
SG-XPCIE8SAS-E-Z	375-3487	PCI Express 8-Port Host Adapter, RoHS:Y
SG-XPCIE8SAS-I-Z	371-3255	PCI Express 8-Port SAS Controller, RoHS:Y
SGXPCIESAS-R-EXT-Z	371-3253	Lithium Ion Battery Module
SGXPCIESAS-R-EXT-Z	375-3537	8-Port SAS RAID External HBA, RoHS:Y
SGXPCIESAS-R-INT-Z	371-3253	Lithium Ion Battery Module
SGXPCIESAS-R-INT-Z	375-3536	8-Port SAS Adaptec RAID HBA, RoHS:Y

System Board
Option #	Manufacturing Part #	Description
n/a	341-4139	PCI Filler Panel, RoHS:Y
n/a	540-7779	System Board Assembly/FRU, RoHS:Y
	375-3598	System Board, RoHS:Y
	371-2210	CR2032 3V Battery, RoHS:Y
	n/a	System Board Tray

Industry Leading Quality, Support and Integrity

Quality Inspection Checklist
Before it leaves our facility, every used and refurbished item is thoroughly inspected by our certified technicians and undergoes our exclusive Quality Inspection Checklist to ensure 100% satisfaction guarantee.

Greentec Systems is a leading provider
For server, networking and storage equipment. We have an extensive array of inventory of IBM Servers & Storage, Sun Servers & Storage, Cisco Networking (Switches, Routers, Security), and NetApp Storage (disk shelves, disk drives, Filers, NearStore, NetCache). If you don’t see the item or product you require please contact us.

Have this equipment to sell?
Depending on the age and condition of the equipment, there is a very good likelihood that we will be able to offer you cash or trade-in credit for other IT hardware. If the equipment is very old we can also assist you with properly decommissioning that gear in the most environmentally friendly way possible.

Questions?
For more information please contact 888.333.7388, or fill out the quote from above. We’d love to hear from you.
