The Oracle Sun Fire X4170 M2

This amazing compact server utilizes the Intel Xeon Processor 5600 Series and has unparalleled performance balanced with compute, memory and I/O capabilities that are accelerated with two flash options, making it the most versatile building block for a number of IT applications. It is ideal for running middleware applications such as WebLogic, systems administration applications such as Oracle Enterprise Manager and Oracle Identity Manager, and software development applications such as Oracle Solaris Studio.

The two new flash options include Solid State Drives (SSDs), and Sun Flash Accelerator PCIe cards, which can deliver I/O performance improvements equivalent to four hundred 15k RPM HDDs. The server can also reduce power consumption by as much as eighty percent. In addition, storage connectivity bandwidth is doubled from the previous generation server with the upgrade to SAS-2 interfaces.

The combination of these features with high-efficiency power supplies and new algorithms for power capping make this server the best performing and most efficient of its kind. System management is simplified with Oracle Integrated Lights Out Manager (ILOM) that comes standard in every Sun Fire X4170 M2 server. ILOM centralizes system management locally or remotely to ease system configuration, software provisioning and updates, providing a consistent interface across the entire x86 product line.

Software Operating Systems ? Oracle Linux ? Oracle Solaris (Pre-installed) ? Red Hat Enterprise Linux ? SuSE Linux Enterprise Server ? Microsoft Windows Server

Sun Fire X4170 M2 Server Information Features
Feature	Description
Processor	Intel Xeon processor 5600 series Supports up to two processors with two Intel processor sockets
Memory	18 slots for DDR3 DIMMs: Up to 144 GB of 1333-MHz ECC registered DDR3 memory
Ethernet ports	Four ports, 10/100/1000 Mbps, auto-negotiating through two separate controllers
Internal storage drives	Up to six 2.5-inch SATA disk drives or solid-state drives (SSDs) with on-board SATA controller Or Up to eight 2.5-inch SAS, SATA or SSD drives with optional HW RAID controller. Note – When the on-board SATA controller is used, storage drives are not supported in the drive slots below the DVD drive.
Removable media	One slimline DVD-R/W drive, supporting CD-R/W, CD+R/W, DVD-R/W, DVD+R/W formats
USB ports	Five USB 2.0 ports: Two in front, two in rear, and one internal
Service ports	One RJ-45 serial management port (SER MGT) (default connection to access service processor) One 10/100-Mbps network management port (NET MGT) (to access service processor) One HD-15 VGA video port
Cooling	Four hot-swappable system fan modules
PCIe interfaces	Three riser boards, each having one standard low-profile PCIe slot PCIe slot 0: x16 electrical/x16 mechanical PCIe slots 1 and 2: x8 electrical/x8 mechanical
Power	AC power: 100-120/200-240 V AC, 12/6 A, 50-60 Hz Up to two hot-swappable 760W power supply units (PSUs) to provide N+N redundancy, with energy efficient design
Remote management	ILOM service processor providing: Command-line interface (CLI) over SSH Web-based browser interface (BUI) over HTTPS IPMI 2.0 SNMP (v1, v2c, and v3) Remote graphical access (remote KVM) over Ethernet Remote storage over Ethernet
Operating system	Supports: Oracle Solaris 10 10/09 and subsequent releases Oracle Enterprise Linux 5.4 (64-bit) Red Hat Enterprise Linux 5.4 (64-bit) SUSE Linux Enterprise Server (SLES) 10 SP3 (64-bit) SLES 11 (64-bit) Oracle Virtual Machine (OVM) Version 2.2.1 VMware ESX 4.0 Update 1 VMware ESXi 4.0 Update 1 Microsoft Windows Server 2008 SP2 (64-bit) Standard Edition/Enterprise Edition (64-bit)/Datacenter Edition (64-bit) Microsoft Windows Server 2008 R2 Standard Edition/Enterprise Edition/Datacenter Edition

Processor
Number	1 to 2 Quad-Core or 6-Core
Architecture	Type: Intel Xeon Quad-Core or 6-Core Processors
CPUs	Intel 2.40GHz Quad-Core Xeon L5620 (12MB L2, 80W) Intel 2.26GHz 6-Core Xeon L5640 (12MB L2, 60W) Intel 2.93GHz 6-Core Xeon E5670 (12MB L2, 95W)
Main Memory
Capacities	Total DIMM slots: 18 DIMM type: DDR3 1066MHz or 1333MHz Registered DIMMs DIMM size: 4-GB 1333MHz or 8-GB 1066MHz Maximum capacity: 144GB (when configured with 8-GB DIMMs)
Standard Integrated Interfaces
Network	Four 10/100/1000 Base-T Ethernet Ports
Network Management	One dedicated 10/100Base-T Ethernet port
Serial Management	One dedicated TIA/EIA-232-F asynchronous RJ45 port
SAS	Four channel SAS interface, internal access only
USB	Front: Two USB 2.0 ports Rear: Two USB 2.0 ports Internal: One USB 2.0 port (for a USB thumb drive)
PCI Expansion Slots	Three low profile PCI Express 2.0 slots (1 x16 electrical/mechanical, 2 x8 electrical/mechanical)
Internal Mass Storage
Disks	SAS: Up to eight 2.5″ SAS Disks or four solid-state drives (SSDs) with add-on SAS Host Bus Adapter (300GB – 10000 RPM SAS or 146GB – 10000 RPM SAS or 32GB SOLID STATE SATA) FMOD: Up to two 24GB flash memory modules (An optional energy storage module (ESM) is required).
DVD-ROM	One SATA DVD+/-RW drive
Power Supplies
Dual redundant, hot swappable power supplies (Power supply rating output = 760W) (UL Maximum AC input = 760W x 1.33 efficiency = 1010W) (9.0 Amps RMS at 100 VAC)
Environment
AC power	100-120 / 200-240 VAC (50-60 Hz)
Temperature	Single, non-rack system: Operating: 5° C to 35° C (41° F to 95° F) Nonoperating: -40° C to 70° C (-40° F to 158° F)
Humidity	Single, non-rack system: Operating: 10% to 90% relative humidity noncondensing, 27° C (80.6° F) max wet bulb Nonoperating: up to 93% relative humidity noncondensing, 38° C (100.4° F) max wet bulb
Altitude	Single, non-rack system: Operating: up to 3000 m (9,843 ft.), maximum ambient temperature is derated by 1° C per 300 m above 900 m Nonoperating: up to 12,000 m (40,000 ft.)
Regulations Meets or exceeds the following requirements:
RoHS Compliance Level	RoHS:YL
Safety	UL 60950-1 2nd Ed, EN60950-1:2006 2nd Ed, CB Scheme with all country differences
RFI/EMI	FCC CFR 47 Part 15 Subpart B Class A, EN55022:2006+A1:2007 Class A, EN 61000-3-2, EN61000-3-3, EN 300-386
Immunity	EN55024, EN300-386
Certifications	Safety: UL/cUL, UL DEMKO, CE, BSMI, CCC, GOST-R, S-Mark EMC: CE, FCC, VCCI, ICES, C-Tick, MIC, CCC, GOST-R, BSMI Class A
Dimensions and Weight
Height	43.43 mm (1.71 in.)
Width	425.5 mm (16.75 in.)
Depth	685.8 mm (27.0 in.)
Weight	16.36 kg (36 lb.) maximum assuming PCI-Express card weighs 0.12 kg (0.25 lb) each, and without the rack mounting slide rail kit installed.

CPU Module
Option #	Manufacturing Part #	Description
X5921A-1U	371-4889	2.93GHz Intel 6-Core Xeon X5670, 12MB, 95W, RoHS:Y
X5921A-1U	541-2545	Xeon Heatsink w/Grease, RoHS:Y
X5924A-1U	371-4885	2.4GHz Intel Quad-Core Xeon E5620, 12MB, 80W, RoHS:Y
X5924A-1U	541-2545	Xeon Heatsink w/Grease, RoHS:Y
X5925A-1U	371-4887	2.26GHz Intel 6-Core Xeon L5640, 12MB, 60W, RoHS:Y
X5925A-1U	541-2545	Xeon Heatsink w/Grease, RoHS:Y

Communication
Option #	Manufacturing Part #	Description
X4237A-N	375-3606	Sun Dual Port 40Gb/sec 4x Infiniband QDR Host Channel Adapter PCI Express, RoHS:Y

Disk Backplane
Option #	Manufacturing Part #	Description
n/a	511-1548	8-Slot Disk Backplane, SATA DVD, RoHS:Y

Disks
Option #	Manufacturing Part #	Description
XRA-SS2CF300G10K-N	540-7869	300GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
	390-0449	Seagate ST93000SSUNG [ST930003SSUN300G] (300GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0451	Hitachi HUC103030CSS600 [H103030SCSUN300G] (300GB – 10000 RPM – SAS Disk), RoHS:Y
	541-2123	Marlin Bracket 2.5″, RoHS:Y
XRA-ST2CF32G2SSD-N	540-7841	32GB Solid State Drive Assembly, SATA Interface, RoHS:Y
	371-4196	32GB Solid State Drive, SATA Interface, RoHS:Y
	541-2123	Marlin Bracket 2.5″, RoHS:Y
XRB-SS2CF146G10K-N	540-7868	146GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
	390-0324	Seagate ST9146802SS [ST914602SSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0377	Hitachi HUC101414CSS300 [H101414SCSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0448	Seagate ST9146803SS [ST914603SSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0450	Hitachi HUC103014CSS600 [H103014SCSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	541-2123	Marlin Bracket 2.5″, RoHS:Y
XRB-ST2CF-500G7K	542-0371	500GB – 7200 RPM SATA Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
	390-0468	Seagate ST9500530NS [ST95000NSSUN500G] (500GB – 7200 RPM – SATA Disk), RoHS:Y
	541-2123	Marlin Bracket 2.5″, RoHS:Y

Ethernet
Option #	Manufacturing Part #	Description
X1109A-Z	375-3617	Dual 10-Gigabit Ethernet SFP+ LP, RoHS:Y
X2129A-N	530-4449	10Gbps Short Wave Pluggable (SFP+) Transceiver, RoHS:Y
X2130A-10M-N	530-4454	Sun 10Gbps SFP+ TwinX Cable, 10m, RoHS:Y
X2130A-1M-N	530-4441	Sun 10Gbps SFP+ TwinX Cable, 1m, RoHS:Y
X2130A-3M-N	530-4442	Sun 10Gbps SFP+ TwinX Cable, 3m, RoHS:Y
X2130A-5M-N	530-4443	Sun 10Gbps SFP+ TwinX Cable, 5m, RoHS:Y
X4446A-Z-N	375-3481	PCI Express Quad Gigabit Ethernet UTP, RoHS:Y

Fan
Option #	Manufacturing Part #	Description
n/a	541-4274	Fan Board Assembly, RoHS:Y
	330-5274	Fan Deck, RoHS:Y
	511-1490	Fan Board, RoHS:Y
n/a	541-4276	Fan Module, RoHS:Y
n/a	371-4789	40x56mm, 15300 RPM Fan, RoHS:Y

Fibre Channel
Option #	Manufacturing Part #	Description
SG-XPCIE1FC-EM8-Z	371-4295	8Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
SG-XPCIE1FC-QF8-Z	371-4324	8Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
SG-XPCIE2FC-EM8-Z	371-4306	8Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
SG-XPCIE2FC-QF8-Z	371-4325	8Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y

I/O
Option #	Manufacturing Part #	Description
n/a	541-2883	1-Slot x8 PCI Express Riser Assembly, RoHS:Y
	501-7967	1-Slot x8 PCI Express Riser, RoHS:Y
	541-2924	Riser Mounting Bracket, RoHS:Y
n/a	541-2885	1-Slot x16 PCI Express Riser Assembly, RoHS:Y
	501-7965	1-Slot x16 PCI Express Riser, RoHS:Y
	541-2924	Riser Mounting Bracket, RoHS:Y

Memory
Option #	Manufacturing Part #	Description
X4851A	371-4899	8GB Registered DDR3-1066 DIMM, RoHS:Y
X4910A	371-4965	4GB Registered DDR3-1333 DIMM, RoHS:Y
X4911A	371-4966	8GB Registered DDR3-1333 DIMM, RoHS:Y
XRA-S-4G2-USB2	371-4743	4GB USB 2.0 Flash Drive, RoHS:Y
X4850A	371-4898	4GB Registered DDR3-1333 DIMM, RoHS:Y
XRA-ST3C-24G2FMD	371-4531	24GB SATA-based Sun Flash Module, RoHS:Y

Power
Option #	Manufacturing Part #	Description
X5932A	300-2233	Type A247 760 Watt Power Supply, RoHS:Y
n/a	511-1489	Power Distribution Board, RoHS:Y

Rack
Option #	Manufacturing Part #	Description
X6324A-N	371-2742	Cable Management Arm, RoHS:Y
X6325A-N	371-2740	Snap-In Slide Rail Rackmount Kit, 730mm, RoHS:Y
X6326A-N	371-2741	Screw-Mount Slide Rail Rackmount Kit, 730mm, RoHS:Y

Removable Media
Option #	Manufacturing Part #	Description
X8325A-N	541-3493	SATA DVD-Writer/CD-Writer – USB Board Assembly, RoHS:Y
	330-5056	DVD Interconnect Holder, RoHS:Y
	390-0442	8x SATA DVD-Writer/24x CD-Writer, RoHS:Y
	390-0443	8x SATA DVD-Writer/24x CD-Writer, RoHS:Y
	501-7698	USB Board, RoHS:Y
	541-3686	DVD Bezel, RoHS:Y

SCSI
Option #	Manufacturing Part #	Description
SGX-SAS6-INT-Z	375-3640	8-Port 6Gbps SAS-2 HBA, RoHS:Y
SGX-SAS6-R-INT-Z	371-4746	6Gigabit SAS RAID PCI Battery Module, BBU07, RoHS:Y
SGX-SAS6-R-INT-Z	375-3644	6Gigabit SAS RAID PCI Express HBA, B2 ASIC, RoHS:Y

System Board
Option #	Manufacturing Part #	Description
n/a	541-4081	System Board Assembly/FRU, RoHS:Y
	511-1213	System Board, RoHS:Y
	150-3993	Panasonic BR2032 Battery, RoHS:Y
	541-2543	System Board Tray, RoHS:Y
