Oracle Sun X4100 Server

Oracle Sun X4100 Server Oracle Sun X4100 Server Sun Servers SUN FIRE X4100 copy

REQUEST A PRICE QUOTE:

    Name*

    Phone

    Details*

    Processor
    Number 1 or 2 (Single or Dual-Core)
    Architecture Type: AMD Opteron Processor 200 Series
    Single Core: 248 (2.2GHz), 252 (2.6GHz), or 254 (2.8GHz)
    Dual Core: 275 (2.2GHz), 280 (2.4GHz), or 285 (2.6GHz)
    Cache memory 1 MB Level 2 cache per processor core
    Main Memory
    Capacities DIMM slots per processor: 4
    DIMM slots per System Board: 8 (using 2 processors)
    DIMM type: DDR1/400 ECC registered DIMMs (128 bit plus ECC databus)
    DIMM size: 512-MB, 1-GB, or 2-GB
    Maximum capacity: 16GB (when configured with 2-GB DIMMs and 2 processors)
    Standard Integrated Interfaces
    Network Four 10/100/1000Base-T Ethernet ports
    Network Management One dedicated 10/100Base-T Ethernet port
    Serial Management One dedicated TIA/EIA-232-F asynchronous RJ45 port
    SAS Four channel SAS interface, internal access only.
    ATI Rage XL Video Chip, VGA Video 15-pin Port
    USB Front: One USB 1.1 port
    Rear: Two USB 1.1 ports
    Expansion bus Two internal MD2 low profile PCI-X slots
    • one at 64-bit/100MHz (slot 0)
    • one at 64-bit/133MHz (slot 1)
    Internal Mass Storage
    Disks Up to four hot-swap Disks (36GB, 73GB or 146GB 10K RPM SAS HDD) without DVD-ROM
    DVD-ROM One EIDE ATAPI Slot Loading DVD-ROM (optional)
    Power Supplies
    Dual redundant, hot swappable power supplies
    (Maximum DC output = 550W)
    (Maximum AC input = 550W x 1.33 efficiency = 733W)
    Environment
    AC power 90-264 V AC (47-63 Hz)
    Temperature Single, non-rack system:
    Operating: 5° C to 35° C (41° F to 95° F)
    Nonoperating: -40° C to 65° C (-40° F to 149° F)
    Humidity Single, non-rack system:
    Operating: 10% to 90% relative humidity noncondensing, 27° C (80.6° F) max wet bulb
    Nonoperating: up to 93% relative humidity noncondensing, 38° C (100.4° F) max wet bulb
    Altitude Single, non-rack system:
    Operating: up to 3000 m (10,000 ft.), maximum ambient temperature is derated by 1° C per 500 m above 500 m
    Nonoperating: up to 12,000 m (40,000 ft.)
    Acoustic noise Single, non-rack system:
    Less than 83 dB sound power in ambient temperature of up to 24° C
    Vibration Single, non-rack system:
    .20 G, 5 to 500 Hz sine sweep
    Shock Single, non-rack system:
    5 G, 11 ms half-sine
    Regulations
    Meets or exceeds the following requirements:
    Safety IEC60950, UL/CSA60950, EN60950, CB Scheme with all country differences
    RFI/EMI FCC Class A, Part 15 47 CFR, EN55022, CISPR 22, EN300-386:v1.31, ICES-003
    Immunity EN55024, EN300-386:v1.31
    Certifications Safety: cULus Mark, TUV GS Mark, CE Mark, CCC, GOST R, S-Mark
    EMC: CE Mark (93/68/EEC), Emissions and Immunity Class A Emissions Levels: FCC, VCCI, BSMI, C-tick, MIC, CCC, GOST
    Dimensions and Weight
    Height 43.8 mm (1.72 in.)
    Width 455 mm (17.5 in.)
    Depth 640 mm (25.2 in.)
    Weight 18.6 kg (41.1 lb.) maximum with rack kit
    8.0 kg (17.0 lb.) maximum without rack kit
    CPU Module
    Option # Manufacturing
    Part #    		 Description
    X8045A-Z 240-4987 25mm Heatsink Shoulder Screw, RoHS:Y
    240-4988 10mm Heatsink Spring, RoHS:Y
    310-0014 CPU Heatsink Assembly, RoHS:Y
    310-0049 G751 Thermal Grease Syringe, RoHS:Y
    371-0935 2.6GHz Dual Core CPU, AMD Opteron 285SE, E6 Stepping, 120W
    X8031A 310-0014 CPU Heatsink Assembly, RoHS:Y
    310-0049 G751 Thermal Grease Syringe, RoHS:Y
    341-1026 10mm Heatsink Spring
    341-1028 25mm Heatsink Shoulder Screw
    370-7711 2.2GHz CPU, AMD Opteron 248, E4 Stepping, RoHS:Y
    X8031A-Z 240-4987 25mm Heatsink Shoulder Screw, RoHS:Y
    240-4988 10mm Heatsink Spring, RoHS:Y
    310-0014 CPU Heatsink Assembly, RoHS:Y
    310-0049 G751 Thermal Grease Syringe, RoHS:Y
    370-7711 2.2GHz CPU, AMD Opteron 248, E4 Stepping, RoHS:Y
    X8033A 310-0014 CPU Heatsink Assembly, RoHS:Y
    310-0049 G751 Thermal Grease Syringe, RoHS:Y
    341-1026 10mm Heatsink Spring
    341-1028 25mm Heatsink Shoulder Screw
    370-7937 2.6GHz CPU, AMD Opteron 252, E4 Stepping, RoHS:Y
    X8033A-Z 240-4987 25mm Heatsink Shoulder Screw, RoHS:Y
    240-4988 10mm Heatsink Spring, RoHS:Y
    310-0014 CPU Heatsink Assembly, RoHS:Y
    310-0049 G751 Thermal Grease Syringe, RoHS:Y
    370-7937 2.6GHz CPU, AMD Opteron 252, E4 Stepping, RoHS:Y
    X8034A 310-0014 CPU Heatsink Assembly, RoHS:Y
    310-0049 G751 Thermal Grease Syringe, RoHS:Y
    341-1026 10mm Heatsink Spring
    341-1028 25mm Heatsink Shoulder Screw
    370-7962 2.8GHz CPU, AMD Opteron 254, E4 Stepping, RoHS:Y
    X8034A-Z 240-4987 25mm Heatsink Shoulder Screw, RoHS:Y
    240-4988 10mm Heatsink Spring, RoHS:Y
    310-0014 CPU Heatsink Assembly, RoHS:Y
    310-0049 G751 Thermal Grease Syringe, RoHS:Y
    370-7962 2.8GHz CPU, AMD Opteron 254, E4 Stepping, RoHS:Y
    X8036A 310-0014 CPU Heatsink Assembly, RoHS:Y
    310-0049 G751 Thermal Grease Syringe, RoHS:Y
    341-1026 10mm Heatsink Spring
    341-1028 25mm Heatsink Shoulder Screw
    370-7799 2.0GHz Dual Core CPU, AMD Opteron 270, E6 Stepping, 95W
    X8037A 310-0014 CPU Heatsink Assembly, RoHS:Y
    310-0049 G751 Thermal Grease Syringe, RoHS:Y
    341-1026 10mm Heatsink Spring
    341-1028 25mm Heatsink Shoulder Screw
    370-7800 2.2GHz Dual Core CPU, AMD Opteron 275, E6 Stepping, 95W, RoHS:Y
    X8037A-Z 240-4987 25mm Heatsink Shoulder Screw, RoHS:Y
    240-4988 10mm Heatsink Spring, RoHS:Y
    310-0014 CPU Heatsink Assembly, RoHS:Y
    310-0049 G751 Thermal Grease Syringe, RoHS:Y
    370-7800 2.2GHz Dual Core CPU, AMD Opteron 275, E6 Stepping, 95W, RoHS:Y
    X8038A 310-0014 CPU Heatsink Assembly, RoHS:Y
    310-0049 G751 Thermal Grease Syringe, RoHS:Y
    341-1026 10mm Heatsink Spring
    341-1028 25mm Heatsink Shoulder Screw
    370-7938 2.4GHz Dual Core CPU, AMD Opteron 280SE, E6 Stepping, 120W
    X8044A 310-0014 CPU Heatsink Assembly, RoHS:Y
    310-0049 G751 Thermal Grease Syringe, RoHS:Y
    341-1026 10mm Heatsink Spring
    341-1028 25mm Heatsink Shoulder Screw
    371-0839 2.4GHz Dual Core CPU AMD Opteron 280, E6 Stepping, 95W, RoHS:Y
    X8044A-Z 240-4987 25mm Heatsink Shoulder Screw, RoHS:Y
    240-4988 10mm Heatsink Spring, RoHS:Y
    310-0014 CPU Heatsink Assembly, RoHS:Y
    310-0049 G751 Thermal Grease Syringe, RoHS:Y
    371-0839 2.4GHz Dual Core CPU AMD Opteron 280, E6 Stepping, 95W, RoHS:Y
    X8045A 310-0014 CPU Heatsink Assembly, RoHS:Y
    310-0049 G751 Thermal Grease Syringe, RoHS:Y
    341-1026 10mm Heatsink Spring
    341-1028 25mm Heatsink Shoulder Screw
    371-0935 2.6GHz Dual Core CPU, AMD Opteron 285SE, E6 Stepping, 120W
    Cables
    Option # Manufacturing
    Part #    		 Description
    X311L Localized Power Cord Kit – North America/Asia, RoHS:Y
    180-1097 IEC 320 C13 to NEMA 5-15P – 15A/125V 2.5M Black, RoHS:Y
    X312E Localized Power Code Kit – China, RoHS:Y
    180-1982 IEC 320 C13 to GB 2099/GB 1002 – 10A/250V 2.5M, RoHS:Y
    X312L Localized Power Cord Kit – Continental Europe, RoHS:Y
    180-1993 IEC 320 C13 to CEE 7/7 10A/250V 2.5M Black, RoHS:Y
    X314L Localized Power Cord Kit – Swiss, RoHS:Y
    180-1994 IEC 320 C13 to SEV 1011 – 10A/250V 2.5M Black, RoHS:Y
    X317L Localized Power Cord Kit – U.K., RoHS:Y
    180-1997 IEC 320 C13 to BS 1363 – 10A/250V 2.5M Black, RoHS:Y
    X384L Localized Power Cord Kit – Italian, RoHS:Y
    180-1996 IEC 320 C13 to CEI 23-16/VII – 10A/250V 2.5M Black, RoHS:Y
    X386L Localized Power Cord Kit – Australian, RoHS:Y
    180-1998 IEC 320 C13 to AS 3112 – 10A/250V 2.5M Black, RoHS:Y
    X9280A 530-3387 4X SFF8470 to 12X SFF8470 InfiniBand Cable, 2 Meter
    X9281A 530-3386 4X SFF8470 to 12X SFF8470 InfiniBand Cable, 5 Meter
    n/a 530-3100 RJ45F to DB9F Adapter, RoHS:Y
    n/a 530-3338 Front I/O Board to System Board Cable, RoHS:Y
    n/a 541-0648 Flex Circuit Assembly, RoHS:YL
    Communication
    Option # Manufacturing
    Part #    		 Description
    X1235A 375-3260 PCI-X Dual Port 4x InfiniBand Host Channel Adapter – Low Profile
    Disk Backplane
    Option # Manufacturing
    Part #    		 Description
    n/a 501-6919 2-Slot Disk Backplane, RoHS:YL
    n/a 501-6976 4-Slot Disk Backplane, RoHS:YL
    Disks
    Option # Manufacturing
    Part #    		 Description
    XRA-SS2CD-146G10KZ 540-7151 146GB – 10000 RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks and brackets, RoHS:Y
    • 390-0324
    • Seagate ST9146802SS [ST914602SSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0375
    • Fujitsu MBB2147RC [MBB2147RCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0377
    • Hitachi HUC101414CSS300 [H101414SCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-0239
    • Nemo Bracket, RoHS:Y
    • 541-3004
    • Nemo Bracket with Insulator, RoHS:Y
    XRA-SS2CD-36G10K 540-6358 36GB 10000 RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:YL
    • 390-0208
    • Seagate ST936701SS [ST936701LSUN36G]
      (36GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0210
    • Fujitsu MAV2036RC [MAV2036RCSUN36G]
      (36GB – 10000 RPM – SAS Disk), RoHS:YL
    • 390-0284
    • Fujitsu MAY2036RC [MAY2036RCSUN36]
      (36GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-0239
    • Nemo Bracket, RoHS:Y
    XRA-SS2CD-36G10KZ 540-6610 36GB 10000 RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks, RoHS:Y
    • 390-0208
    • Seagate ST936701SS [ST936701LSUN36G]
      (36GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0284
    • Fujitsu MAY2036RC [MAY2036RCSUN36]
      (36GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-0239
    • Nemo Bracket, RoHS:Y
    XRA-SS2CD-73G10K 541-0323 73GB 10000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks, RoHS:YL
    • 390-0211
    • Fujitsu MAV2073RC [MAV2073RCSUN72G]
      (73GB – 10000 RPM – SAS Disk), RoHS:YL
    • 390-0213
    • Seagate ST973401SS [ST973401SSUN72G]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0285
    • Fujitsu MAY2073RC [MAY2073RCSUN72]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-0239
    • Nemo Bracket, RoHS:Y
    XRA-SS2CD-73G10KZ 540-6611 73GB 10000 RPM SAS, Disk Assembly with 1 of the following disks and brackets, RoHS:Y
    • 390-0213
    • Seagate ST973401SS [ST973401SSUN72G]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0285
    • Fujitsu MAY2073RC [MAY2073RCSUN72]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0323
    • Seagate ST973402SS [ST973402SSUN72G]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0374
    • Fujitsu MBB2073RC [MBB2073RCSUN72G]
      (73.4GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0376
    • Hitachi HUC101473CSS300 [H101473SCSUN72G]
      (73.4GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-0239
    • Nemo Bracket, RoHS:Y
    • 541-3004
    • Nemo Bracket with Insulator, RoHS:Y
    n/a 540-7777 146GB 10000 RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks, RoHS:Y
    • 390-0324
    • Seagate ST9146802SS [ST914602SSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0375
    • Fujitsu MBB2147RC [MBB2147RCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0448
    • Seagate ST9146803SS [ST914603SSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-0239
    • Nemo Bracket, RoHS:Y
    • 541-3004
    • Nemo Bracket with Insulator, RoHS:Y
    Ethernet
    Option # Manufacturing
    Part #    		 Description
    X7285A 371-0911 Low Profile PCI-X Dual Gigabit Ethernet UTP, RoHS:Y
    X7286A 371-0912 Low Profile PCI-X Single Gigabit Ethernet MMF, RoHS:Y
    Fan
    Option # Manufacturing
    Part #    		 Description
    n/a 501-6917 Fan Connector Board (A64/A86), RoHS:Y
    n/a 541-0266 Fan Module (Single Fan), RoHS:Y
    Fibre Channel
    Option # Manufacturing
    Part #    		 Description
    SG-XPCI1FC-QF4 375-3354 4Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI2FC-QF4 375-3294 4Gb PCI-X Dual FC Host Adapter, RoHS:Y
    SG-XPCI1FC-EM2 375-3304 2Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI1FC-QL2 375-3383 2Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI1FC-QLC 375-3253 Entry-Level 2Gb PCI-X Single FC Host Adapter
    SG-XPCI1FC-QLC-Z 375-3364 Entry-Level 2Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI2FC-EM2 375-3305 2Gb PCI-X Dual FC Host Adapter, RoHS:Y
    SG-XPCI2FC-QF2 375-3108 2Gb PCI Dual FC Host Adapter
    • 240-4839
    • Low Profile Bracket, RoHS:Y
    SG-XPCI2FC-QF2-Z 375-3363 2Gb PCI Dual FC Host Adapter, RoHS:Y
    • 240-4839
    • Low Profile Bracket, RoHS:Y
    I/O
    Option # Manufacturing
    Part #    		 Description
    n/a 501-6914 1-Slot PCI Riser Board, RoHS:YL
    n/a 501-6918 Front I/O Board w/Cover Interlock Switch, RoHS:YL
    Memory
    Option # Manufacturing
    Part #    		 Description
    X8021A 1GB (2 × 512MB DDR400/PC3200 ECC DIMM) Option, RoHS:YL
    594-1676 1GB (2 × 512MB DDR400/PC3200 ECC DIMM), RoHS:YL
    • 371-0071
    • 512MB PC3200 DDR400 ECC registered DIMM, RoHS:YL
    X8021A-Z 1GB (2 × 512MB DDR400/PC3200 ECC DIMM) Option, RoHS:YL
    594-1676 1GB (2 × 512MB DDR400/PC3200 ECC DIMM), RoHS:YL
    • 371-0071
    • 512MB PC3200 DDR400 ECC registered DIMM, RoHS:YL
    X8022A 2GB (2 × 1GB DDR400/PC3200 ECC DIMM) Option
    594-1677 2GB (2 × 1GB DDR400/PC3200 ECC DIMM), RoHS:YL
    • 371-0072
    • 1GB PC3200 DDR400 ECC registered DIMM, RoHS:YL
    X8022A-Z 2GB (2 × 1GB DDR400/PC3200 ECC DIMM) Option, RoHS:YL
    594-1677 2GB (2 × 1GB DDR400/PC3200 ECC DIMM), RoHS:YL
    • 371-0072
    • 1GB PC3200 DDR400 ECC registered DIMM, RoHS:YL
    X8023A 4GB (2 × 2GB DDR400/PC3200 ECC DIMM) Option, RoHS:YL
    594-1678 4GB (2 × 2GB DDR400/PC3200 ECC DIMM), RoHS:YL
    • 371-0073
    • 2GB PC3200 DDR400 ECC registered DIMM, RoHS:YL
    X8023A-Z 4GB (2 × 2GB DDR400/PC3200 ECC DIMM) Option, RoHS:YL
    594-1678 4GB (2 × 2GB DDR400/PC3200 ECC DIMM), RoHS:YL
    • 371-0073
    • 2GB PC3200 DDR400 ECC registered DIMM, RoHS:YL
    X8024A-Z 8GB (2 × 4GB PC3200 DDR400 DIMM) Option, RoHS:YL
    594-4108 8GB (2 × 4GB DDR1-400/PC3200 ECC DIMM), RoHS:Y
    • 371-1460
    • 4GB PC3200 DDR1-400 ECC registered DIMM, RoHS:Y
    n/a F540-6453 2GB (2 × 1GB) Memory FRU, RoHS:YL
    • 371-0072
    • 1GB PC3200 DDR400 ECC registered DIMM, RoHS:YL
    n/a F540-6454 1GB (2 × 512MB) Memory FRU, RoHS:YL
    • 371-0071
    • 512MB PC3200 DDR400 ECC registered DIMM, RoHS:YL
    n/a F540-6497 4GB (2 × 2GB) Memory FRU, RoHS:YL
    • 371-0073
    • 2GB PC3200 DDR400 ECC registered DIMM, RoHS:YL
    n/a F540-6838 8GB (2 ?? 4GB) Memory FRU, RoHS:YL
    • 371-1460
    • 4GB PC3200 DDR1-400 ECC registered DIMM, RoHS:Y
    Miscellaneous
    Option # Manufacturing
    Part #    		 Description
    X949A-4 594-2682 Wago DC Connector Set (10 pack), RoHS:Y
    • 130-6352
    • Wago DC Connector, RoHS:Y
    • 230-4652
    • Wago DC Connector Strain Relief, RoHS:Y
    • 230-4653
    • Wago DC Connector Opening Lever, RoHS:Y
    n/a 501-6916 LED/Switch Board (A64/A86), RoHS:Y
    Power
    Option # Manufacturing
    Part #    		 Description
    X8026A 300-1757 550 Watt Power Supply
    X8026A-Z 300-1945 550 Watt, Type A203, AC Input Power Supply, RoHS:YL
    X8051A-Z 300-2006 DC -48VDC 550W Power Supply (Type D193), RoHS:YL
    n/a 501-6920 Power Distribution Board, RoHS:YL
    Removable Media
    Option # Manufacturing
    Part #    		 Description
    8030A 540-6368 Slimline ATAP/IDE DVD-ROM/CD-ROM Drive Assembly
    • 390-0218
    • 8x DVD-ROM/24x CD-ROM Drive
    SCSI
    Option # Manufacturing
    Part #    		 Description
    SG-XPCI8SAS-E-Z 375-3488 3Gb PCI-X SAS 8-Port Host Adapter, RoHS:Y
    SGXPCI1SCSILM320-Z 375-3366 PCI Single Ultra320 SCSI Adapter
    SG-XPCI1SCSI-LM320 375-3255 PCI/PCI-X Single Ultra320 SCSI Adapter
    System Board
    Option # Manufacturing
    Part #    		 Description
    n/a 501-7261 System Board
    • 150-3993
    • Panasonic BR2032 Battery, RoHS:Y
    n/a 501-7644 System Board, RoHS:YL
    • 150-3993
    • Panasonic BR2032 Battery, RoHS:Y
    System Service Processor
    Option # Manufacturing
    Part #    		 Description
    n/a 501-6979 Service Processor Board, RoHS:YL

    Industry Leading Quality, Support and Integrity

    Quality Inspection Checklist
    Before it leaves our facility, every used and refurbished item is thoroughly inspected by our certified technicians and undergoes our exclusive Quality Inspection Checklist to ensure 100% satisfaction guarantee.

    Greentec Systems is a leading provider
    For server, networking and storage equipment. We have an extensive array of inventory of IBM Servers & Storage, Sun Servers & Storage, Cisco Networking (Switches, Routers, Security), and NetApp Storage (disk shelves, disk drives, Filers, NearStore, NetCache). If you don’t see the item or product you require please contact us.

    Have this equipment to sell?
    Depending on the age and condition of the equipment, there is a very good likelihood that we will be able to offer you cash or trade-in credit for other IT hardware. If the equipment is very old we can also assist you with properly decommissioning that gear in the most environmentally friendly way possible.

    Questions?
    For more information please contact 888.333.7388, or fill out the quote from above. We’d love to hear from you.

    Request Quote
    Greentec Systems We geek out helping you with your IT infrastructure.
    Request a quote or product information
    Send
