Oracle Sun X4-4 Server

REQUEST A PRICE QUOTE:

Brand:	Oracle / Sun Microsystems
Condition:	Refurbished and new (limited availability)
Availability:	Contact
Shipping Area:	Worldwide to most countries
Shipping Method:	Fedex (most orders), UPS, DHL, Freight Courier
Price:	Please use the quote form above for quick pricing
Payment:	Credit Card, Check, Net Terms (oac), Wire Transfer (required for international orders)
Guarantee:	All items are tested by Oracle trained technicians & backed by a 100% warranty
Questions?	Don’t hesitate to contact us with any questions regarding compatibility or other product info and requests. Our website represents only a fraction of our full inventory. Please reach out with your full requirements

Specs and Information:

Processor

Number

2 or 4 15-Core

Architecture

Type: Intel Xeon E7-8895 Processor Series

CPUs

Intel 2.80GHz 15-Core Xeon E7-8895 v2, 155W

Cache memory

256KB unified (data and instruction) Level 2 cache
Up to 37.5 MB shared last Level 3 cache.

Main Memory

Capacities

DIMM slots: 96 DIMM slots, 24 DIMMs per CPU
DIMM type: Registered low-voltage DDR3L-1600 DIMMs,
Registered low-voltage DDR3L-1600 Load Reduced DIMMs
DIMM size: 8GB, 16GB, 32GB (LR)
Maximum capacity: 3TB

Standard Integrated Interfaces

Network

Four 10 GbE on-board Ethernet copper ports

Network Management

One dedicated 10/100/1000Base-T Ethernet copper management port

Serial Management

One RS-232 RJ45 serial port

USB

Front: 2 USB 2.0 Ports
Rear: 2 USB 2.0 Ports
Internal: 1 USB 2.0 Port

PCI Express

11 PCI Express 3.0 Slots

9 slots are x8 PCI-E slots
2 slots are x16 PCI-E slots

Note: Slot 2 is designated for the storage controller HBA.

Video

One Rear and One Front HD15 VGA port

Graphics controller

VGA 2D graphics controller embedded.
Support remote console at a resolution up to 1600x1200x16bits@60Hz
(1024×678 when viewed remotely via ILOM RKVMS)

Internal Mass Storage

Disks

Six 2.5″ SAS-2/SATA-3 front-accessible, hot-swappable disk bays.

Drive Type	Density	Speed	Form Factor
SAS-2	600GB	10,000 RPM	2.5″
SAS-2	1.2TB	10,000 RPM	2.5″
SATA-3	400GB	Solid State	2.5″

Power Supplies

Dual redundant, hot swappable power supplies
2000W Capacity (From 200 Volts to 240 Volts)

Environment

Power Consumption

Online power calculator

AC power

100-127 VAC for 2 CPU’s
200-240 VAC for 2 or 4 CPU’s
50/60 Hz Nominal frequencies

Maximum Input Current

12A @ 100VAC / 12A @ 200VAC

Maximum Power Consumption

1467W

Maximum Heat Output

5005 BTU/hr

Temperature

Single, non-rack system:
Operating: 5° C to 35° C (41° F to 95° F)
Nonoperating: -40° C to 68° C (-40° F to 154°F)

Humidity

Single, non-rack system:
Operating: 10% to 90% relative humidity noncondensing
Nonoperating: up to 93% relative humidity noncondensing

Altitude

Single, non-rack system:
Operating: Up to 3048 m (10,000 ft.), maximum operating temperature is derated by 1° C for every 300 m (985 ft) above 900 m (2,952 ft).
Nonoperating: Up to 12,000 m (39,370 ft.)

Acoustic Noise Emissions

LwAd (1B= 10dB) at max ambient: 8.9 B (idle and operating room temperature)
LpAm bystander at max ambient: 75 dBA

Regulations
Meets or exceeds the following requirements:

Safety

IEC 60950, UL/CSA60950-1, EN60950-1, IEC60950-1 (CB scheme with all country differences), North America (NRTL), European Union (EU), International CB Scheme, 2006/95/EC (73/23/EEC) Low Voltage Directive

EMC

FCC CFR 47 Part 15B Class A, EN55022 Class A, CNS-13438 Class A (Taiwan), Title 47, Part 15, Subpart B Class A (United States), ICES-003 (A) NMB-3 (A) Class A (Canada), ETSI EN300386 (V1.6.1), VCCI: 2008 Class A (Japan), KN 22 RRL Public Notice 2009-9 (Dec 21, 2009)

Immunity

EN 55024 (Immunity), EN61000-3-2, EN61000-3-3

Certifications

Safety Marks: UL/cUL, UL DEMKO, CCC, CE, BSMI, GOST-R, S-Mark
Regulatory: CE, FCC, EAC, C-Tick, VCCI, BSMI, KCC, ICES-003(A), NMB-3(A), WEEE symbol, China RoHS symbol

Dimensions and Weight

Height

129.9 mm (5.1 in.)

Width

436.5 mm (17.2 in.)

Depth

732 mm (28.8 in.)

Weight

Maximum: 40 kg (88 lb.)

Rack Mounting

Sun Server X4-4 Racks
( Using the Tooless Slide Rail Rackmount Kit PN#371-4791 )

Racks are as follows:

Sun Rack 1242
Sun Rack 1042

Batteries
Option #	Manufacturing Part #	Description	Previous Part #
n/a	150-3993 [C]	3V Lithium Coin Cell Battery	n/a

CPU Module
Option #	Manufacturing Part #	Description	Previous Part #
7109365 [S]	1 x 2.8GHz 15-Core Intel Xeon E7-8895 CPU Module
	7070792 [F]	CPU Heatsink (Brickland)	n/a
	7080240	CPU Installation/Removal Tool	n/a
	7083528 [F]	2.8GHz 15-Core Intel Xeon E7-8895 v2, 155W	n/a
n/a	7065502	Two CPU Air Diverter	n/a

Cables
Option #	Manufacturing Part #	Description	Previous Part #
7102869	7039990 [C]	MPO to MPO High Bandwidth QSFP Optical Cable, 10M	n/a
7102870	7039999 [C]	MPO to MPO High Bandwidth QSFP Optical Cable, 20M	n/a
7102871	7040001 [C]	MPO to MPO High Bandwidth QSFP Optical Cable, 50M	n/a
X2121A-1M-N	530-4444 [C]	10Gbps QSFP to QSFP Cable, 1m	n/a
X2121A-2M	530-4567 [C]	10Gbps QSFP to QSFP Cable, 2m	n/a
X2121A-3M-N	530-4445 [C]	10Gbps QSFP to QSFP Cable, 3m	n/a
X2121A-5M-N	530-4446 [C]	10Gbps QSFP to QSFP Cable, 5m	n/a
X2130A-1M-N	530-4441 [C]	10Gbps SFP+ TwinX Cable, 1m	n/a
X2130A-3M-N	530-4442 [C]	10Gbps SFP+ TwinX Cable, 3m	n/a
X2130A-5M-N	530-4443 [C]	10Gbps SFP+ TwinX Cable, 5m	n/a
n/a	530-3100	RJ45F to DB9F Adapter	n/a
n/a	7085487 [F]	X4-4 Cable Kit	n/a
	530-4288	Fan Board to System Board Power Cable	n/a
	530-4289	System Board to PDB Cable	n/a
	530-4290	System Board to Disk Backplane Signal Cable	n/a
	530-4291	System Board to Disk Backplane Power Cable	n/a
	530-4349 [F]	LED Flex Circuit	n/a
	7044137	SFF-8087 to 90 SFF-8087 SAS Cable, 510mm	n/a
	7044138	SFF-8087 to 90 SFF-8087 DVD SAS Cable, 510mm/530mm	n/a
	530-4287	Fan Board to System Board Signal Cable	n/a
	530-4348	System Board to Rear I/O Board Signal Cable	n/a

Chassis
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7043043	X4-4 Base Assembly	n/a
	7066597	X4-4 Building Block Chassis	n/a
	350-1585	Top Cover Air Baffle	n/a
	7052037	Air Divider with Fault Remind Button	n/a
	7052517	X4-4 Nameplate	n/a
n/a	7074704	Chassis Subassembly	n/a
	341-5805	Rack Mount Ear	n/a
	341-6188	Power Supply Chassis Cable Cover	n/a
	350-1392	Front Bezel	n/a
	7068043	Power Distribution Board Cover	n/a
	7075160	Chassis	n/a
	350-1383	Top Cover	n/a
	150-4065	Interlock Switch Magnet	n/a
	530-4356	AC Input Line Filter with Cable	n/a

Communication
Option #	Manufacturing Part #	Description	Previous Part #
7104074	7092757 [C]	Dual 40Gb/Sec (4x) QDR InfiniBand Host Channel Adapter Module M3	n/a
n/a	7046442 [C]	Dual 40Gb/Sec (4x) QDR InfiniBand Host Channel Adapter Module M3	n/a

Disk Backplane
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7039459 [F]	6-Slot Disk Backplane	n/a

Disks
Option #	Manufacturing Part #	Description	Previous Part #
7105214	7064135 [C]	600GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks:	n/a
	7045228	Hitachi HUC109060CSS600 [H109060SESUN600G] (600GB – 10000 RPM – SAS Disk)	n/a
	7066795	Hitachi HUC109060CSS600 [H109060SESUN600G] (600GB – 10000 RPM – SAS Disk)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a
7107550	7077233 [C]	400GB Solid State SATA Drive Assembly	n/a
	7076379	Intel SSDSC2BA400G3S [ITVSC2BA3SUN400] (400GB – 2.5″ Solid State – SATA-3 Disk)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a
7106617 [S]	7045850 [C]	1.2TB – 10000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks:	n/a
	7045846	Hitachi HUC101212CSS600 [H101212SESUN1.2T] (1.2TB – 10000 RPM – SAS Disk)	n/a
	7082883	Hitachi HUC101212CSS600 [H101212SESUN1.2T] (1.2TB – 10000 RPM – SAS Disk)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a

Ethernet
Option #	Manufacturing Part #	Description	Previous Part #
7100477	7070195 [C]	Quad Port GbE PCI Express 2.0 Low Profile Adapter, UTP	n/a
7100488	7070006 [C]	Dual 10-Gigabit Base-T PCI Express Gen2	n/a
X1109A-Z	7051223 [C]	Dual 10-Gigabit PCI Express Ethernet SFP+ LP	n/a
X2124A	135-1204 [C]	10Gb/Sec QDR InfiniBand / 40Gb/Sec Ethernet QSFP Transceiver	n/a
X2129A-N	530-4449 [C]	10Gb/Sec Short Wave SFP+ Transceiver	n/a
X5562A-Z	135-1205 [C]	10Gb/Sec Long Wave SFP+ Transceiver	n/a

Fan
Option #	Manufacturing Part #	Description	Previous Part #
n/a	541-3539 [C]	92mm Fan Module	n/a
n/a	7057262 [F]	Fan Cage Assembly	n/a
	530-4349 [F]	LED Flex Circuit	n/a
	7057260	Fan Board with USB and VGA	n/a

Fibre Channel
Option #	Manufacturing Part #	Description	Previous Part #
7101674	7023303 [C]	Dual 16Gigabit/Sec Fibre Channel / 10Gbps FCoE Host Adapter, QLogic	n/a
7101676	7023325 [C]	Pair of 16Gbps Short Wave SFP+	n/a
7101676	7023324	16Gb/Sec Short Wave SFP+ Transceiver, QLogic	n/a
7101678	7023315 [C]	Pair of 10Gbps Short Wave SFP+	n/a
7101678	7023316	10Gb/Sec Short Wave SFP+ Transceiver, QLogic	n/a
7101680	7023066 [C]	Pair of 16Gbps Long Wave SFP+	n/a
7101680	7023064	16Gb/Sec Long Wave SFP+ Transceiver, QLogic	n/a
7101684	7023036 [F]	Dual 16Gigabit/Sec Fibre Channel / 10Gbps FCoE Host Adapter, Emulex	n/a
7101686	7023059 [C]	Pair of 16Gbps Short Wave SFP+	n/a
7101686	7023053	16Gb/Sec Short Wave SFP+ Transceiver, Emulex	n/a
7101688	7023057 [C]	Pair of 10Gbps Short Wave SFP+	n/a
7101688	7023046	10Gb/Sec Short Wave SFP+ Transceiver, Emulex	n/a
SG-XPCIE2FC-EM8-N	7053434 [C]	8Gigabit/Sec PCI Express Dual FC Host Adapter	n/a
SG-XPCIE2FC-QF8-N	371-4325 [C]	8Gigabit/Sec PCI Express Dual FC Host Adapter	n/a

Memory
Option #	Manufacturing Part #	Description	Previous Part #
7106840	7076173 [C]	16GB 1.35V DDR3L-1600 DIMM	n/a
7106841	7073781 [C]	32GB 1.35V DDR3L-1600 Load Reduced DIMM	n/a
7106839 [S]	7076172 [C]	8GB 1.35V DDR3L-1600 DIMM	n/a
n/a	330-4839	Memory Slot Filler	n/a
n/a	7038488 [C]	4GB USB 2.0 Flash Drive	n/a
n/a	7084609 [C]	Memory Riser Assembly	n/a
	7066592	Memory Riser Tray	n/a
	7084605	Memory Riser Board	n/a

Power
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7052431 [F]	Power Distribution Board / Power Supply Backplane	n/a
	371-4446	Bus Bar	n/a
	7052430	Power Distribution Board / Power Supply Backplane	n/a
n/a	7060596 [C]	Type A239E 2000 Watt AC Input Power Supply	n/a
n/a	7081064 [C]	Type A239A 2000 Watt AC Input Power Supply	7060596 [C]
n/a	7300803 [F]	Power Supply Backplane Assembly	7052431 [F]
	371-4446	Bus Bar	n/a
	7052430	Power Distribution Board / Power Supply Backplane	n/a
n/a	7317314 [F]	Power Supply Backplane Assembly	n/a
	371-4446	Bus Bar	n/a
	7052430	Power Distribution Board / Power Supply Backplane	n/a
	7317311	High Potential (Hipot) Test Passed Label	n/a

Rack
Option #	Manufacturing Part #	Description	Previous Part #
n/a	371-4791 [C]	Tool-less Slide Rail Rack Mount Kit	n/a
n/a	371-4812 [C]	Cable Management Arm	n/a

Removable Media
Option #	Manufacturing Part #	Description	Previous Part #
7109368 [S]	7300356 [C]	Tray-Load SATA DVD-Writer/CD-Writer	7082409 [C]
	7071296	8x Tray-Load SATA DVD-ROM Writer / 24x CD-ROM Writer	n/a
	7079028	DVD Bezel	n/a
	7094095	DVD Carrier	n/a
n/a	7070422 [C]	Slot-Load SATA DVD-Writer/CD-Writer	n/a
	341-5808	Bezel	n/a
	341-6389	Mounting Tray	n/a
	7045772	8x Slot-Load SATA DVD-Writer/24x CD-Writer	n/a
n/a	7082409 [C]	Tray-Load SATA DVD-Writer/CD-Writer	n/a
	7071296	8x Tray-Load SATA DVD-ROM Writer / 24x CD-ROM Writer	n/a
	7079028	DVD Bezel	n/a
	7079063	DVD Carrier	n/a
	7089203	DVD Liner	n/a
n/a	7302240 [C]	Tray-Load SATA DVD-Writer/CD-Writer	n/a
	7089963	8x Tray-Load DVD-ROM/24-x CD-ROM Writer (Gen5)	n/a
	7094095	DVD Carrier	n/a
n/a	7314403 [C]	Tray-Load DVD Assembly	n/a
	7079028	DVD Bezel	n/a
	7089203	DVD Liner	n/a
	7094095	DVD Carrier	n/a
	7309891	8x Tray-Load DVD-ROM/24x CD-ROM Writer (Gen6)	n/a

SCSI
Option #	Manufacturing Part #	Description	Previous Part #
7105387	8-Port 6Gbps SAS-2 PCI Express HBA
7105387	7047853 [C]	8-Port 6Gbps SAS-2 PCI Express HBA (LSI)	n/a
7107092	7069200 [C]	800GB PCI Express Flash Accelerator F80 SAS HBA	n/a
SG-SAS6-EXT-Z	7047853 [C]	8-Port 6Gbps SAS-2 PCI Express HBA (LSI)	n/a
SGX-SAS6-R-INT-Z	7047503 [C]	8-Port 6Gbps SAS-2 RAID PCI Express HBA, B4 ASIC	n/a
SGX-SAS6-R-INT-Z	7050794 [C]	6Gbps SAS-2 RAID PCI Battery Module, BBU08	n/a
SGX-SAS6-INT-Z [S]	7047852 [C]	8-Port 6Gbps SAS-2 PCI Express HBA (LSI)	n/a

System Board
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7066596 [F]	System Board Assembly	n/a
	7051520	Rear I/O Board	n/a
	7079088	System Board	n/a
	150-3993 [C]	3V Lithium Coin Cell Battery	n/a
	7079794	System Board Tray	n/a

System Service Processor
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7067268 [C]	Service Processor	n/a

Industry Leading Quality, Support and Integrity

Quality Inspection Checklist
Before it leaves our facility, every used and refurbished item is thoroughly inspected by our certified technicians and undergoes our exclusive Quality Inspection Checklist to ensure 100% satisfaction guarantee.

Greentec Systems is a leading provider
For server, networking and storage equipment. We have an extensive array of inventory of IBM Servers & Storage, Sun Servers & Storage, Cisco Networking (Switches, Routers, Security), and NetApp Storage (disk shelves, disk drives, Filers, NearStore, NetCache). If you don’t see the item or product you require please contact us.

Have this equipment to sell?
Depending on the age and condition of the equipment, there is a very good likelihood that we will be able to offer you cash or trade-in credit for other IT hardware. If the equipment is very old we can also assist you with properly decommissioning that gear in the most environmentally friendly way possible.

Questions?
For more information please contact 888.333.7388, or fill out the quote from above. We’d love to hear from you.
