    Oracle Sun Ultra 24 Workstation, Greentec Systems

    Ultra 24 Specifications, Configurations & Pricing Quotes



    [themify_button bgcolor=”green” size=”xlarge” nofollow=”no” link=”https://docs.oracle.com/cd/E19127-01/ultra24.ws/820-2480-12/820-2480-12.pdf”]PDF: Sun Ultra 24 Workstation Service Manual[/themify_button]

    Sun Ultra 24 Processor
    Number One
    Architecture Intel Core[TM]2 Duo Processors, Intel Core[TM]2 Quad Processors, and Intel Core[TM]2 Quad Extreme Processor
    CPUs Intel Core2 Duo 2.0GHz, 2.66GHz, 3.0GHz
    Intel Core2 Quad 2.4GHz, 2.66GHz
    Intel Core2 Quad Extreme 3.0GHz
    Cache memory 2MB to 8MB Level 2 per processor
    Note: (Intel Core2 Duo E4400 processor has 2MB of Level 2)
    Sun Ultra 24 Workstation Main Memory
    Capacities oracle sun workstation ultra 24 Oracle Sun Workstation Ultra 24 Specs Pricing Configurations bulletFour DIMM slots
    oracle sun workstation ultra 24 Oracle Sun Workstation Ultra 24 Specs Pricing Configurations bulletECC – 512MB, 1GB, 2GB
    oracle sun workstation ultra 24 Oracle Sun Workstation Ultra 24 Specs Pricing Configurations bulletUnbuffered DIMMs only – DDR2-667
    oracle sun workstation ultra 24 Oracle Sun Workstation Ultra 24 Specs Pricing Configurations bulletDIMM slots are numbered from DIMM 0 to DIMM 3. Populate DIMM slots starting farthest from the CPU in the following order: (slot 3 – black), (slot 1 – black), (slot 2 – blue), and (slot 0 – blue)
    Sun Ultra 24 Standard Interfaces
    Audio
    • Line-in/Line-out jacks on the rear of the chassis
    • Microphone-in jack on the front and rear of the chassis
    • Headphone-out jack on the front of the chassis
    Video Supports PCIe based graphics accelerator cards
    Ethernet Single Gigabit Ethernet 10/100/1000BASE-T integrated on motherboard providing (1) RJ45 connector on the rear of the chassis.
    Expansion Slots
    • Two PCI Express x16 Gen-2 slots, full height
    • One PCI Express x8 slot (x4 electrical), full height
    • One PCI Express x1 slot, full height
    • Two PCI 5V 33 MHz 32-bit slots, full height/full length
    Fire Wire Two IEEE 1394 connectors on the front of the chassis
    USB Six USB 2.0 connectors (two on the front and four on the rear of the chassis)
    Sun Ultra 24 Internal Storage
    Disks Up to four SATA Disk Drives (4TB maximum) – 250GB, 750GB or 1TB (7,200 RPM)
    Up to four SAS Disk drives via PCIe HBA (1.8TB maximum) – 146GB, 300GB or 450GB (15,000 RPM)
    DVD One 16x DVD Writer/48x CD-ROM Writer or One 16x DVD-ROM/48x CD-ROM Drive
    Sun Ultra 24Power Supplies
    Single 530 Watt Power Supply
    Graphics
    Cards
    • Supported cards.
    Sun Ultra 24 Environment, weight specs dimensions
    AC Power 100-120, 220-240 VAC; 47-63 Hz
    Input Voltage Range Range 1: 90 Vrms (minimum), 115 Vrms (nominal), 132 Vrms (maximum)
    Range 2: 180 Vrms (minimum), 230 Vrms (nominal), 264 Vrms (maximum)
    Input Frequency Range Range 1: 57 Hz (minimum), 60 Hz (nominal), 63 Hz (maximum)
    Range 2: 47 Hz (minimum), 50 Hz (nominal), 53 Hz (maximum)
    Input Current Maximum Input Current:
    Range 1:     10A
    Range 2: 5A
    Maximum Inrush Current:
    Range 1: 50A – peak
    Range 2:100A – peak
    Temperature Operating: 5° C to 35° C (41° F to 95° F) – derate -1° C (-1.8 F) for every 300 m (985 ft) in altitude
    Nonoperating: -40° C to 65° C (-40° F to 149° F)
    Humidity Operating: 7% to 93% relative humidity, non-condensing, 38° C (100.4° F) max wet bulb
    Nonoperating: 93% relative humidity, non-condensing, 43° C (109.4° F) max wet bulb
    Shock 4.5G, 11msec. half-sine
    Vibration Operating: 0.25G in all axis, 5-500 Hz sine
    Nonoperating: 1.2G in all axis, 5-500 Hz sine
    Altitude Operating: Maximum 3000 m (9843 ft)
    Nonoperating: Maximum 12000 m (39370 ft)
    Regulations
    Meets or exceeds the following requirements:
    Safety UL/CSA-60950, EN 60950, IEC 60950 CB
    RFI/EMI EN 55022/CISPR22 Class B, FCC CFR47 Part 15 Class B; EN 6100-3-2, EN 61000-3-3
    Immunity EN 55024
    Regulatory Markings UL/cUL, TUV-GS, CE FCC, ICES-003, C-Tiek, VCCI, GOST-R, BSMI CCC, S-Mark
    Ergonomics EK1-1TB-2000
    RoHS Compliance Level RoHS:Y
    Dimensions and Weights
    Height 43.5 cm (17.1 in)
    Width 20 cm (7.9 in)
    Depth 47 cm (18.5 in)
    Weight 15.4 kg (34 lbs)
    Batteries
    Option # Manufacturing
    Part #    		 Description
    n/a 371-2210 CR2032 3V Battery, RoHS:Y
    Sun Ultra 24 CPU Module
    Option # Manufacturing
    Part #    		 Description
    4107A-Z 371-4034 2.8GHz/12M/1333MHz Intel Core2 Quad Q9550, RoHS:Y
    4109A-Z 371-4037 3.0GHz/6M/1333MHz Intel Core2 Duo E8400, RoHS:Y
    4118A-Z 371-3618 2.4GHz/8M/1066MHz Intel Core2 Quad Q6600
    4126A-Z 371-3621 2.66GHz/8M/1066MHz Intel Core2 Quad Q6700
    4137A-Z 371-4115 2.2GHz/2M/800MHz Intel Core2 Duo E4500, RoHS:Y
    4139A 371-4317 2.53GHz/3M/1066MHz Intel Core2 Duo E7200, RoHS:Y
    5154A 371-4400 3.0GHZ/12MB/1333MHz Intel Core2 Quad Q9650, RoHS:Y
    5155A 371-4398 3.3GHz/6MB/1333MHz Intel Core2 Duo E8600, RoHS:Y
    5156A 371-4399 2.33GHz/4MB/1333MHz Intel Core2 Quad Q8200, RoHS:Y
    4108A-Z 371-4035 2.5GHz/6M/1333MHz Intel Core2 Quad Q9300, RoHS:Y
    4117A-Z 371-3617 3.0GHz/8M/1333MHz Intel Core2 Extreme Quad QX6850
    4119A-Z 371-3619 3.0GHz/4M/1333MHz Intel Core2 Duo E6850
    4122A-Z 371-3622 2.66GHz/4M/1333MHz Intel Core2 Duo E6750
    4124A-Z 371-4036 3.16GHz/6M/1333MHz Intel Core2 Duo E8500, RoHS:Y
    4125A-Z 371-3620 2.0GHz/2M/800MHz Intel Core2 Duo E4400
    Cables
    Option # Manufacturing
    Part #    		 Description
    X311L Localized Power Cord Kit – North America/Asia, RoHS:Y
    180-1097 IEC 320 C13 to NEMA 5-15P – 15A/125V 2.5M Black, RoHS:Y
    X312E Localized Power Code Kit – China, RoHS:Y
    180-1982 IEC 320 C13 to GB 2099/GB 1002 – 10A/250V 2.5M, RoHS:Y
    X312F Localized Power Cord Kit – Argentina, RoHS:Y
    180-1999 IEC 320 C13 to IRAM 2073 – 10A/250V 2.5M Black, RoHS:Y
    X312G Localized Power Cord Kit – Korea, RoHS:Y
    180-1662 IEC 320 C13 to KSC 8305 – 15A/250V 2.5M Black, RoHS:Y
    X312L Localized Power Cord Kit – Continental Europe, RoHS:Y
    180-1993 IEC 320 C13 to CEE 7/7 10A/250V 2.5M Black, RoHS:Y
    X314L Localized Power Cord Kit – Swiss, RoHS:Y
    180-1994 IEC 320 C13 to SEV 1011 – 10A/250V 2.5M Black, RoHS:Y
    X317L Localized Power Cord Kit – U.K., RoHS:Y
    180-1997 IEC 320 C13 to BS 1363 – 10A/250V 2.5M Black, RoHS:Y
    X383L Localized Power Cord Kit – Danish, RoHS:Y
    180-1995 IEC 320 C13 to Asfnit 107 – 10A/250V 2.5M Black, RoHS:Y
    X384L Localized Power Cord Kit – Italian, RoHS:Y
    180-1996 IEC 320 C13 to CEI 23-16/VII – 10A/250V 2.5M Black, RoHS:Y
    X386L Localized Power Cord Kit – Australian, RoHS:Y
    180-1998 IEC 320 C13 to AS 3112 – 10A/250V 2.5M Black, RoHS:Y
    Sun Ultra 24 Disk Backplane
    Option # Manufacturing
    Part #    		 Description
    n/a 371-3630 4-Slot Disk Backplane
    Disks
    Option # Manufacturing
    Part #    		 Description
    XRB-SS1CE-146G15KZ 540-7088 146GB – 15000RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:YL
    • 390-0334
    • Seagate ST3146855SS [ST314655SSUN146G]
      (146GB – 15000 RPM – SAS Disk), RoHS:Y
    • 390-0338
    • Seagate ST3146854SS [ST314654SSUN146G]
      (146GB – 15000 RPM – SAS Disk), RoHS:YL
    • 390-0371
    • Hitachi HUS153014VLS300 [HUS1514SBSUN146G]
      (146GB – 15000 RPM – SAS Disk), RoHS:YL
    • 540-6562
    • 1″ SPUD Bracket, RoHS:Y
    XRB-SS1CE-300G15K 540-7155 300GB – 15K RPM SAS, Disk Assembly with 1 bracket, and 1 of the following disks, RoHS:YL
    • 390-0335
    • Seagate ST3300655SS [ST330055SSUN300G]
      (300GB – 15K RPM – SAS Disk), RoHS:Y
    • 390-0372
    • Hitachi HUS153030VLS300 [HUS1530SBSUN300G]
      (300GB – 15000 RPM – SAS Disk), RoHS:Y
    • 540-6562
    • 1″ SPUD Bracket, RoHS:Y
    XRB-SS1CE-450G15K 540-7780 450GB – 15000 RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
    • 390-0424
    • Seagate ST3450856SS [ST345056SSUN450G]
      (450GB – 15000 RPM – SAS Disk), RoHS:Y
    • 540-6562
    • 1″ SPUD Bracket, RoHS:Y
    XRB-ST1CE-1T7K 540-7506 1TB – 7200RPM SATA, Disk Assembly with 1 of the following disks:, RoHS:Y
    • 390-0381
    • Hitachi HUA721010KLA330 [HUA7210SASUN1.0T]
      (1TB – 7200 RPM – SATA Disk), RoHS:Y
    • 540-6562
    • 1″ SPUD Bracket, RoHS:Y
    XRB-ST1CE-750G7K 540-7238 750GB – 7200 RPM SATA Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
    • 390-0356
    • Seagate ST3750640NS [ST37500NSSUN750G]
      (750GB – 7200 RPM – SATA Disk), RoHS:Y
    • 390-0379
    • Hitachi HUA721075KLA330 [HUA7275SASUN750G]
      (750GB – 7200 RPM – SATA Disk), RoHS:Y
    • 540-6562
    • 1″ SPUD Bracket, RoHS:Y
    XRC-ST1CE-250G7K 540-7511 250GB – 7200RPM SATA, Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:YL
    • 390-0354
    • Seagate ST3250820NS [ST32500NSSUN250G]
      (250GB – 7200 RPM – SATA Disk), RoHS:Y
    • 390-0411
    • Seagate ST3250310NS [ST32502NSSUN250G]
      (250GB – 7200 RPM – SATA Disk), RoHS:Y
    • 540-6562
    • 1″ SPUD Bracket, RoHS:Y
    Ethernet
    Option # Manufacturing
    Part #    		 Description
    X4446A-Z 375-3481 PCI Express Quad Gigabit Ethernet UTP, RoHS:Y
    X7280A-2 371-0905 PCI Express Dual Gigabit Ethernet UTP, RoHS:Y
    X7281A-2 371-0904 PCI Express Dual Gigabit Ethernet MMF, RoHS:Y
    X4218A 371-2133 PCI Express Intel Pro 1000 PT 1-Port Copper Network Interface Card (NIC) X-Option, RoHS:Y
    Fan
    Option # Manufacturing
    Part #    		 Description
    n/a 310-0163 CPU Fan/Heatsink
    n/a 371-2108 Fan, RoHS:Y
    Graphics
    Option # Manufacturing
    Part #    		 Description
    X8015A-Z 530-3474 DVI-A(M) to HD15F Adapter, 49mm, RoHS:Y
    X4083A-Z 371-2963 NVIDIA Quadro FX4600 High-end 3D Graphics Accelerator, RoHS:Y
    X4084A-Z 371-2964 NVIDIA Quadro FX5600 Ultra High-end 3D Graphics Accelerator, RoHS:Y
    X4100A-Z 371-3990 NVIDIA Quadro FX370 Graphics Accelerator
    X4128A-Z 371-3624 NVIDIA Quadro FX3700 Graphics Accelerator, RoHS:Y
    X4129A-Z 371-3625 NVIDIA Quadro FX1700 Graphics Accelerator
    X4130A-Z 371-3626 NVIDIA Quadro FX570 Graphics Accelerator
    X4131A-Z 371-3627 NVIDIA Quadro NVS290 Graphics Accelerator w/ 59-Pin Cable
    I/O
    Option # Manufacturing
    Part #    		 Description
    n/a 371-2131 I/O Assembly, RoHS:Y
    Memory
    Option # Manufacturing
    Part #    		 Description
    X5277A-Z 540-7058 1GB (2 × 512MB) Memory FRU, RoHS:Y
    • 371-1998
    • 512MB Unregistered ECC DDR2-667/PC5300 DIMM, RoHS:Y
    X5278A-A 540-7778 2GB (2 × 1GB) Memory FRU, RoHS:Y
    • 371-4144
    • 1GB Unregistered ECC DDR2-667/PC2-5300 DIMM, RoHS:Y
    X5278A-Z 540-7059 2GB (2 × 1GB) Memory FRU, RoHS:Y
    • 371-1999
    • 1GB Unregistered ECC DDR2-667/PC5300 DIMM, RoHS:Y
    X5279A-Z 540-7060 4GB (2 × 2GB) Memory FRU, RoHS:Y
    • 371-2000
    • 2GB Unregistered ECC DDR2-667 DIMM, RoHS:Y
    Power
    Option # Manufacturing
    Part #    		 Description
    n/a 300-2132 530W Power Supply
    Removable Media
    Option # Manufacturing
    Part #    		 Description
    X4133A-Z 540-7509 DVD-Writer / CD-Writer Assembly, RoHS:Y
    • 390-0389
    • 16x DVD-Writer / 48x CD-Writer, RoHS:Y
    • 390-0440
    • 16x DVD-Writer / 40x CD-Writer, RoHS:Y
    • 390-0466
    • 16x DVD-Writer / 48x CD-Writer, RoHS:Y
    X4134A-Z 540-7510 DVD-ROM / CD-ROM Assembly, RoHS:Y
    • 390-0390
    • 16x DVD-ROM / 48x CD-ROM, RoHS:Y
    SCSI
    Option # Manufacturing
    Part #    		 Description
    SG-XPCIE4SAS-Z 371-2094 4 Port SAS PCI Express Internal HBA, RoHS:Y
    SG-XPCIE4SAS3-Z 371-3991 4 Port SAS PCI Express Internal HBA, RoHS:Y
    System Board
    Option # Manufacturing
    Part #    		 Description
    n/a 375-3540 Motherboard Assembly, RoHS:Y
    • 371-2210
    • CR2032 3V Battery, RoHS:Y
