    Oracle Sun V445 Server Specs & Configurations

    The Oracle SunFire v445 is a series of server computers introduced in the early 2000’s by Sun Microsystems (since 2010, part of Oracle Corporation). The Sun Fire branding coincided with the introduction of the UltraSPARC III processor, superseding the UltraSPARC II-based Sun Enterprise series. In 2003, Sun broadened the Sun Fire brand, introducing Sun Fire servers using the Intel Xeon processor. In 2004, these early Intel Xeon models were superseded by models powered by AMD Opteron processors. Also in 2004, Sun introduced Sun Fire servers powered by the UltraSPARC IV dual-core processor. In 2007, Sun again introduced Intel Xeon Sun Fire servers, while continuing to offer the AMD Opteron versions as well.

    SPARC-based Sun Fire systems were produced until 2010, while x86-64 based machines were marketed until mid-2012. In mid-2012, Oracle Corporation ceased to use the Sun Fire brand for new server models. See below for specs and use the above contact form to purchase or get a fast quote.

    oracle sun v445 server specs configurations price quote Oracle Sun V445 Server Specs Configurations Price Quote Sun Microsystems v4451 300x141

    Condition: Used / Certified Refurbished

    Processor
    Number two to four
    Architecture 1.593 GHz UltraSPARC IIIi
    Cache memory 1 MB Level 2
    Main Memory
    Capacities 4 DIMM slots per processor.
    Support for 512MB, 1 GB and 2 GB DIMMS.
    DDR1 PC2700 DIMMs.
    Minimum configuration: 4GB (two CPU/memory modules with four 512-MB DIMMs).
    Maximum configuration: 32GB (four CPU/memory modules fully populated with 2-GB DIMMs).
    Standard Interfaces
    Ethernet 4 RJ-45 on board 10/100/1000BASE-T Gigabit/Fast Ethernet ports
    PCI
    • 8 PCI slots (4 PCI-E slots/4 PCI-X slots)

    NOTE: One of the short PCI-X slots may be occupied by a disk drive controller.
    New standard configurations with an integrated controller installed into the disk backplane are available, thereby making the previously occupied short PCI-X slot available. All systems that initially shipped with the PCI-X based disk controller can be upgraded in the field by ordering the FRU part F501-7244 – PCIe SAS-SATA Controller Board. The use of this controller will require the redefinition of the boot path as it is PCIe based, not PCI-X. It is encouraged that Services be contacted for the installation.
    System Management One Serial Management RJ45 port.
    One Network Management 10Base-T Ethernet, RJ45 port.
    Support for: Sun Management Center, Sun SNMP Management Agent, Advanced Lights Out Management (ALOM), Sun Net Connect, and Sun Update Connection.
    Serial 2 Serial Ports
    • 1 DB-9 connector and 1 RJ45 connector
    • The RJ45 port is used for serial management.
    USB Four USB 2.0 compliant ports, two front and two rear.
    SCSI None
    Internal Mass Storage
    Disks
    • Up to 8 73GB or 146GB, 10,000rpm, 2.5″ SAS disk drives.
    • Hardware RAID 0 and 1.
    • Drives are front-accessible, hot-pluggable.
    DVD-ROM One internal combination CD/DVD-RW writer.
    Environment
    AC Power Consumption
    Typical Operating Range    		 327 – 557 W for operation @ 100 VAC to 240 VAC.
    Maximum AC Input per Power Supply 660 W.
    Maximum DC Output per Power Supply 550 W.
    AC Power Consumption Typical Operating Range: 327 – 557 W for operation @ 100 VAC to 240 VAC.
    Heat Dissipation Typical Operating Range: 1065-2689 BTU/hr. for operation @ 100 VAC to 240 VAC
    Maximum Heat: 3157 BTU/hr. for operation @ 100 VAC to 240 VAC.
    Temperature Operating: 5°C to 35°C (41°F to 95°) non-condensing.
    Nonoperating: -40°C to 35°C (-40°F to 95°) non-condensing.
    Minimum temperature of -20°C is required if NiMH batteries are used.
    Humidity
    (IEC 60068-2-3&56 )    		 Operating: 20% to 80% relative humidity, noncondensing, 27°C max wet bulb
    Nonoperating: Up to 93% relative humidity, noncondensing, 38°C max wet bulb
    Altitude
    (IEC 60068-2-13)    		 Operating:0 to 3,000m (0 to 10,000 ft.); Max. ambient temperature is derated by 1° C per 500 m. above 500 m.
    Nonoperating: 0-12,000 m (0 to 40,000 ft.)
    Acoustics
    ISO 9295/9296
    (ISO 7779:1988)    		 Operating: At full speed 75 dBA
    Nonoperating: N/A
    Declared acoustics is as declared in Bels, per ISO 9295/9296 because acoustics is the only test where there are no formal input-response scenarios that lead to pass-fail criteria.
    Vibration
    (IEC-60068-2-6&64)    		 Operating: 0.0001 g2/Hz, 5 to 150 Hz, -12db /octave slope 150 to 500 Hz.
    Nonoperating: 0.001 g2/Hz, 5 to 150 Hz, -12db /octave slope 150 to 500 Hz.
    Shock Operating: 3.0 g peak, 11 milliseconds half-sine pulse —IEC 60068-2-27.
    Nonoperating: 15.0 g peak, 11 milliseconds half-sine pulse; 1.0 roll-off front to back, 0.5 inch roll-off side to side.
    Handling Drops
    (IEC 60068-2-31)    		 60 mm, 1 drop per corner, 4 corners.
    Threshold Impact
    (ETE 1010-01)    		 0.85m/s, 3 impacts per caster, all 4 casters, 25 mm step-up.
    Regulations
    Meets or exceeds the following requirements:
    RoHS Compliance Level RoHS:YL
    Safety UL 60950, CB Scheme IEC 950, CSA C22.2 950 from UL
    TUV EN 60950
    UL CB scheme IEC 950 (CE mark)
    RFI/EMI 47 CFR 15B Class A
    EN55022 Class A
    VCCI Class B
    AS/NZ 3548
    CNS 13438
    KSC 5858
    ICES-003
    Immunity IEC 1000
    EN55024 per EMC Directive 89/336/EEC, including
    IEC 61000-4-2 Electrostatic discharge immunity test
    IEC 61000-4-3 Radiated, radio-frequency, electromagnetic field immunity test
    IEC 61000-4-4 Electrical fast transient/burst immunity test
    IEC 61000-4-5 Surge immunity test
    IEC 61000-4-6 Immunity to conducted disturbances, induced by radio frequency fields
    IEC 61000-4-8 Power frequency magnetic field immunity test
    IEC 61000-4-11 Voltage dips, short interruptions and voltage variations immunity tests
    Dimensions and Weights
    Height 4RU – Rack-based system: 17.45 cm (6.87 in.)
    Width 44.5 cm (17.48 in.)
    Depth 64.4 cm (25.4 in.)
    Weight Minimum 31 kg (70 lb.)
    Maximum 37.2 kg (82 lb.)
    Batteries
    Option # Manufacturing
    Part #    		 Description
    n/a 150-1204 3V Lithium battery, RoHS:Y
    Cables
    Option # Manufacturing
    Part #    		 Description
    X311L Localized Power Cord Kit – North America/Asia, RoHS:Y
    180-1097 IEC 320 C13 to NEMA 5-15P – 15A/125V 2.5M Black, RoHS:Y
    X312E Localized Power Code Kit – China, RoHS:Y
    180-1982 IEC 320 C13 to GB 2099/GB 1002 – 10A/250V 2.5M, RoHS:Y
    X312F Localized Power Cord Kit – Argentina, RoHS:Y
    180-1999 IEC 320 C13 to IRAM 2073 – 10A/250V 2.5M Black, RoHS:Y
    X312G Localized Power Cord Kit – Korea, RoHS:Y
    180-1662 IEC 320 C13 to KSC 8305 – 15A/250V 2.5M Black, RoHS:Y
    X312L Localized Power Cord Kit – Continental Europe, RoHS:Y
    180-1993 IEC 320 C13 to CEE 7/7 10A/250V 2.5M Black, RoHS:Y
    X314L Localized Power Cord Kit – Swiss, RoHS:Y
    180-1994 IEC 320 C13 to SEV 1011 – 10A/250V 2.5M Black, RoHS:Y
    X317L Localized Power Cord Kit – U.K., RoHS:Y
    180-1997 IEC 320 C13 to BS 1363 – 10A/250V 2.5M Black, RoHS:Y
    X320A Localized Power Cord Kit – North America/Asia, RoHS:Y
    180-2164 IEC 320 C13 to NEMA 6-15P – 10A/250V 2.0M Black, RoHS:Y
    X330A Power Cord 220V 15A US/Japan, RoHS:Y
    180-2075 Power Cord 220V 15A US/Japan, RoHS:Y
    X332A Localized Power Cord Kit – Taiwan, RoHS:Y
    180-2121 IEC 320 C13 to NEMA 5-15P – 10A/125V 2.5M Black, RoHS:Y
    X333A-25-10-IL Localized Power Cord Kit Israel, RoHS:Y
    180-2130 IEC 320 C13 to SI-32, 10A/250V, 2.5M, Black, RoHS:Y
    X333A-25-15-JP Localized Power Cord Kit Japan, RoHS:Y
    180-2243 IEC 320 C13 to PSE 5-15P, 15A/125V, 2.5M, Black, RoHS:Y
    X333F-25-15-JP Localized Power Cord Kit Japan, RoHS:Y
    180-2244 IEC 320 C13 to PSE 6-15P, 15A/250V, 2.5M, Black, RoHS:Y
    X383L Localized Power Cord Kit – Danish, RoHS:Y
    180-1995 IEC 320 C13 to Asfnit 107 – 10A/250V 2.5M Black, RoHS:Y
    X384L Localized Power Cord Kit – Italian, RoHS:Y
    180-1996 IEC 320 C13 to CEI 23-16/VII – 10A/250V 2.5M Black, RoHS:Y
    X386L Localized Power Cord Kit – Australian, RoHS:Y
    180-1998 IEC 320 C13 to AS 3112 – 10A/250V 2.5M Black, RoHS:Y
    X321L North America/Asia Power Cords 4-Pack, RoHS:Y
    180-2023 IEC 320 C13 to NEMA 6-15P – 10A/250V 4.0M Black, RoHS:Y
    X322L Continental Europe Power Cords 4-pack, RoHS:Y
    180-2024 IEC 320 C13 to CEE 7/7 10A/250V 4.0M Black, RoHS:Y
    X323L 180-2029 IEC 320 C13 to Asfnit 107 4.0M Black, RoHS:Y
    X324L 180-2027 IEC 320 C13 to SEV 1011 10A/250V 4.0M Black, RoHS:Y
    X325L 180-2028 IEC 320 C13 to CEI.23-16-VII 10A/250V 4.0M Black, RoHS:Y
    X326L 180-2025 IEC 320 C13 to AS 3112 10A/250V 4.0M Black, RoHS:Y
    X327L 180-2026 IEC 320 C13 to BS 1363 10A/250V 4.0M Black, RoHS:Y
    X328L China Power Cords 4-Pack, RoHS:Y
    180-1982 IEC 320 C13 to GB 2099/GB 1002 – 10A/250V 2.5M, RoHS:Y
    X335L 180-2030 IEC 320 C13 to IRAM 2073 10A/250V 4.0M Black, RoHS:Y
    X336L U.S. Power Cords 4-Pack, RoHS:Y
    180-2070 NEMA L6-20P to IEC 320 C13 – 4.0M, RoHS:Y
    X338L U.S. Watertight Power Cords 4-Pack, RoHS:Y
    180-2072 Blue 20A Watertight IEC 309 to IEC 320 C13, 4.0M, RoHS:Y
    X339L International Watertight Power Cords 4-Pack, RoHS:Y
    180-2073 Blue 16A Watertight IEC 309 to IEC 320 C13 4.0M, RoHS:Y
    n/a 530-3100 RJ45F to DB9F Adapter, RoHS:Y
    Communication
    Option # Manufacturing
    Part #    		 Description
    X1355A-2 371-0982 2M, 80-Pin, 4-Port, DB37, RS449 Breakout Cable,RoHS:Y
    375-3296 Quad Port High Speed Serial Interface PCI-X (HSI/U), RoHS:Y
    X2156A-2 375-3420 Serial Asynchronous Interface PCI (SAI/P) 3.0, RoHS:Y
    X6000A 375-3424 PCI Express Sun Crypto Accelerator 6000, RoHS:Y
    X1333A-4 375-3418 Infiniband PCI-X Card, RoHS:YL
    Disk Backplane
    Option # Manufacturing
    Part #    		 Description
    n/a 501-7243 8-Slot Disk Backplane, RoHS:YL
    Disks
    Option # Manufacturing
    Part #    		 Description
    XRA-SS2CD-146G10KZ 540-7151 146GB – 10000 RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks and brackets, RoHS:Y
    • 390-0324
    • Seagate ST9146802SS [ST914602SSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0375
    • Fujitsu MBB2147RC [MBB2147RCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0377
    • Hitachi HUC101414CSS300 [H101414SCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-0239
    • Nemo Bracket, RoHS:Y
    • 541-3004
    • Nemo Bracket with Insulator, RoHS:Y
    XRA-SS2CD-73G10KZ 540-6611 73GB 10000 RPM SAS, Disk Assembly with 1 of the following disks and brackets, RoHS:Y
    • 390-0213
    • Seagate ST973401SS [ST973401SSUN72G]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0285
    • Fujitsu MAY2073RC [MAY2073RCSUN72]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0323
    • Seagate ST973402SS [ST973402SSUN72G]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0374
    • Fujitsu MBB2073RC [MBB2073RCSUN72G]
      (73.4GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0376
    • Hitachi HUC101473CSS300 [H101473SCSUN72G]
      (73.4GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-0239
    • Nemo Bracket, RoHS:Y
    • 541-3004
    • Nemo Bracket with Insulator, RoHS:Y
    XRB-SS2CD-146G10KZ 540-7151 146GB – 10000 RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks and brackets, RoHS:Y
    • 390-0324
    • Seagate ST9146802SS [ST914602SSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0375
    • Fujitsu MBB2147RC [MBB2147RCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0377
    • Hitachi HUC101414CSS300 [H101414SCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-0239
    • Nemo Bracket, RoHS:Y
    • 541-3004
    • Nemo Bracket with Insulator, RoHS:Y
    XRB-SS2CD-73G10KZ 540-6611 73GB 10000 RPM SAS, Disk Assembly with 1 of the following disks and brackets, RoHS:Y
    • 390-0213
    • Seagate ST973401SS [ST973401SSUN72G]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0285
    • Fujitsu MAY2073RC [MAY2073RCSUN72]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0323
    • Seagate ST973402SS [ST973402SSUN72G]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0374
    • Fujitsu MBB2073RC [MBB2073RCSUN72G]
      (73.4GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0376
    • Hitachi HUC101473CSS300 [H101473SCSUN72G]
      (73.4GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-0239
    • Nemo Bracket, RoHS:Y
    • 541-3004
    • Nemo Bracket with Insulator, RoHS:Y
    n/a 541-0323 73GB 10000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks, RoHS:YL
    • 390-0211
    • Fujitsu MAV2073RC [MAV2073RCSUN72G]
      (73GB – 10000 RPM – SAS Disk), RoHS:YL
    • 390-0213
    • Seagate ST973401SS [ST973401SSUN72G]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0285
    • Fujitsu MAY2073RC [MAY2073RCSUN72]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-0239
    • Nemo Bracket, RoHS:Y
    Ethernet
    Option # Manufacturing
    Part #    		 Description
    X1027A-Z 501-7283 PCI Express Dual 10-Gigabit Ethernet Fiber, RoHS:Y
    X4150A-2 501-7415 GigaSwift Ethernet UTP (GCS), RoHS:Y
    X4151A-2 501-7430 GigaSwift Ethernet MMF (GFS), RoHS:Y
    X4447A-Z 511-1422 PCI Express Quad Gigabit Ethernet UTP, RoHS:Y
    • 371-2207
    • Bracket Low-Profile, RoHS:Y
    560-2884 Ship Kit for Gigabit Ethernet options
    • 371-2348
    • Bracket Standard, RoHS:Y
    X5558A 375-3301 10Gb/sec XFP Optical Transceiver Short Range (SR), RoHS:YL
    X5560A-Z 375-3495 10Gb/sec XFP Optical Transceiver Long Range (LR), RoHS:Y
    X7280A-2 371-0905 PCI Express Dual Gigabit Ethernet UTP, RoHS:Y
    X7281A-2 371-0904 PCI Express Dual Gigabit Ethernet MMF, RoHS:Y
    n/a 501-7606 PCI Express Quad Gigabit Ethernet UTP, RoHS:Y
    • 371-2207
    • Bracket Low-Profile, RoHS:Y
    • 371-2348
    • Bracket Standard, RoHS:Y
    Fan
    Option # Manufacturing
    Part #    		 Description
    n/a 541-0868 Fan Assembly, RoHS:YL
    • 371-0716
    • Fan, RoHS:Y
    Fibre Channel
    Option # Manufacturing
    Part #    		 Description
    SG-XPCI1FC-EM4-Z 375-3398 4Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI1FC-QF4 375-3354 4Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI2FC-EM4-Z 375-3399 4Gb PCI-X Dual FC Host Adapter, RoHS:Y
    SG-XPCI2FC-QF4 375-3294 4Gb PCI-X Dual FC Host Adapter, RoHS:Y
    SG-XPCIE1FC-EM4 375-3396 4Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
    SG-XPCIE1FC-EM8-Z 371-4295 8Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
    SG-XPCIE1FC-QF4 375-3355 4Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
    SG-XPCIE1FC-QF8-Z 371-4324 8Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
    SG-XPCIE2FC-EM4 375-3397 4Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
    SG-XPCIE2FC-EM8-Z 371-4306 8Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
    SG-XPCIE2FC-QF4 375-3356 4Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
    SG-XPCIE2FC-QF8-Z 371-4325 8Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
    SG-XPCI1FC-EM2 375-3304 2Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI1FC-QL2 375-3383 2Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI2FC-EM2 375-3305 2Gb PCI-X Dual FC Host Adapter, RoHS:Y
    SG-XPCI2FC-QF2-Z 375-3363 2Gb PCI Dual FC Host Adapter, RoHS:Y
    • 240-4839
    • Low Profile Bracket, RoHS:Y
    Graphics
    Option # Manufacturing
    Part #    		 Description
    X3000A 375-3545 XVR-300 x8 Graphics Accelerator, RoHS:Y
    530-3474 DVI-A(M) to HD15F Adapter, 49mm, RoHS:Y
    530-3998 DMS-59 to Dual DVI-I Cable, 215mm, RoHS:Y
    X4240A 605-4668 XVR-300X16 Graphics Accelerator, RoHS:Y
    • 375-3458
    • XVR-300 Graphics Accelerator, RoHS:Y
    • 530-3474
    • DVI-A(M) to HD15F Adapter, 49mm, RoHS:Y
    • 530-3998
    • DMS-59 to Dual DVI-I Cable, 215mm, RoHS:Y
    X7295A 375-3292 XVR-2500 Graphics Accelerator, RoHS:Y
    X7296A 375-3290 XVR-100 Graphics Accelerator (64MB), RoHS:Y
    n/a 375-3454 XVR-2500 Graphics Accelerator, RoHS:Y
    I/O
    Option # Manufacturing
    Part #    		 Description
    n/a 501-7242 Front I/O Board Assembly, RoHS:YL
    Memory
    Option # Manufacturing
    Part #    		 Description
    X8703A 540-6466 1GB (2 × 512MB) Memory FRU, RoHS:Y
    • 370-7972
    • 512MB PC2700 DIMM, RoHS:Y
    X8704A 540-6467 2GB (2 × 1GB) Memory FRU, RoHS:Y
    • 370-7973
    • 1GB PC2700 DIMM, RoHS:Y
    X8711A 540-6468 4GB (2 × 2GB) Memory FRU, RoHS:Y
    • 370-7974
    • 2GB PC2700 DIMM, RoHS:Y
    Power
    Option # Manufacturing
    Part #    		 Description
    n/a 300-1848 550 Watt, Type A214 Power Supply, RoHS:YL
    n/a 300-1852 AC Input Power Supply (Type A214), RoHS:YL
    n/a 375-3302 Power Distribution Board Assembly, RoHS:Y
    Rack
    Option # Manufacturing
    Part #    		 Description
    X7437A-Z 541-2023 2-post Rackmount Kit, RoHS:YL
    n/a 371-2686 Rack Rail and Cable Management Arm, RoHS:Y
    Removable Media
    Option # Manufacturing
    Part #    		 Description
    n/a F541-1025 Internal DVD-Writer/CD-Writer, RoHS:YL
    • 341-1645
    • Mounting Bracket, RoHS:Y
    • 541-1025
    • Internal DVD-Writer/CD-Writer, RoHS:YL
    • 390-0282
    • DVD-Writer/CD-Writer, RoHS:Y
    • 390-0337
    • 8x PATA DVD-Writer/24x CD-Writer, RoHS:Y
    • 390-0380
    • DVD-Writer/CD-Writer, RoHS:Y
    • 390-0403
    • 8x PATA DVD-Writer / 24x CD-Writer, RoHS:Y
    SCSI
    Option # Manufacturing
    Part #    		 Description
    SG-XPCI8SAS-E-Z 375-3488 3Gb PCI-X SAS 8-Port Host Adapter, RoHS:Y
    SG-XPCIE2SCSIU320Z 375-3357 Dual-Channel Ultra320 LVD SCSI PCI Express Adapter, RoHS:Y
    SG-XPCIE8SAS-E-Z 375-3487 PCI Express 8-Port Host Adapter, RoHS:Y
    SGXPCI1SCSILM320-Z 375-3366 PCI Single Ultra320 SCSI Adapter
    SGXPCI2SCSILM320-Z 375-3365 PCI Dual Ultra320 SCSI Adapter, RoHS:YL
    SGXPCIESAS-R-EXT-Z 371-3253 Lithium Ion Battery Module
    375-3537 8-Port SAS RAID External HBA, RoHS:Y
    X4422A-2 501-7490 Dual GigabitEthernet / Dual SCSI PCI Adapter, RoHS:Y
    n/a 371-1490 PCI-X SAS HBA, Model SAS3090X, RoHS:Y
    System Board
    Option # Manufacturing
    Part #    		 Description
    X7451A-Z 501-7368 1.593GHz CPU/Memory Module Assembly with 2GB Memory (4x 512MB DIMMs), RoHS:YL
    • 370-7972
    • 512MB PC2700 DIMM, RoHS:Y
    • 501-7461
    • 1.593GHz CPU Board Assembly, RoHS:YL
    • 370-7684
    • UltraSPARC IIIi Heatsink, RoHS:Y
    • 501-7342
    • 0MB System Board, w/o UltraSPARC IIIi, RoHS:Y
    X7452A-Z 501-7287 1.593GHz CPU/Memory Module Assembly with 4GB Memory (4x 1GB DIMMs), RoHS:YL
    • 370-7973
    • 1GB PC2700 DIMM, RoHS:Y
    • 501-7461
    • 1.593GHz CPU Board Assembly, RoHS:YL
    • 370-7684
    • UltraSPARC IIIi Heatsink, RoHS:Y
    • 501-7342
    • 0MB System Board, w/o UltraSPARC IIIi, RoHS:Y
    X7453A-Z 501-7369 1.593GHz CPU/Memory Module Assembly with 8GB Memory (4x 2GB DIMMs), RoHS:YL
    • 370-7974
    • 2GB PC2700 DIMM, RoHS:Y
    • 501-7461
    • 1.593GHz CPU Board Assembly, RoHS:YL
    • 370-7684
    • UltraSPARC IIIi Heatsink, RoHS:Y
    • 501-7342
    • 0MB System Board, w/o UltraSPARC IIIi, RoHS:Y
    n/a 525-2146 SSCC NVRAM, RoHS:Y
    n/a F540-6556 Motherboard Assembly, RoHS:YL
    • 540-6556
    • Motherboard Assembly, RoHS:YL
    • 341-1161
    • Bus Bar, RoHS:Y
    • 501-7066
    • Motherboard, RoHS:YL
    • 541-1040
    • Motherboard Tray Assembly, RoHS:YL
    System Service Processor
    Option # Manufacturing
    Part #    		 Description
    n/a 501-7288 Service Processor, RoHS:YL

    Industry Leading Quality, Support and Integrity

    Quality Inspection Checklist
    Before it leaves our facility, every used and refurbished item is thoroughly inspected by our certified technicians and undergoes our exclusive Quality Inspection Checklist to ensure 100% satisfaction guarantee.

    Greentec Systems is a leading provider
    For server, networking and storage equipment. We have an extensive array of inventory of IBM Servers & Storage, Sun Servers & Storage, Cisco Networking (Switches, Routers, Security), and NetApp Storage (disk shelves, disk drives, Filers, NearStore, NetCache). If you don’t see the item or product you require please contact us.

    Have this equipment to sell?
    Depending on the age and condition of the equipment, there is a very good likelihood that we will be able to offer you cash or trade-in credit for other IT hardware. If the equipment is very old we can also assist you with properly decommissioning that gear in the most environmentally friendly way possible.

    Questions?
    For more information please contact 888.333.7388, or fill out the quote from above. We’d love to hear from you.

    Request Quote
    Greentec Systems We geek out helping you with your IT infrastructure.
    Request a quote or product information
    Send
