Oracle Sun T5240 Server Pricing Specs Configurations – Complete Info

sun t5240 server Oracle Sun T5240 Server Pricing Specs Configurations – Complete Info Sun Servers SUN SPARC T5240 copy

REQUEST A PRICE QUOTE:

    Name*

    Phone

    Details*

    Sun T5240 Server Information

    • The Sun SPARC Enterprise T5240 server equipped with dual 1.4GHz UltraSPARC T2 Plus processors delivered a 16 cores/2 chips/128 threads world record SPECompM2001 result of 25,488 for systems with two or less processors.

    • The Sun SPARC Enterprise T5240 server, running Oracle Solaris and  Oracle Solaris Studio 12 software on two UltraSPARC T2 Plus processors, beats the 64 cores/32 chips/64 threads SPEC OMPM2001 result of Unisys ES7000/One server by 3.5% in 1/12 the space. Unisys used freely available gcc compilers and libraries on this 32-socket Intel Xeon-based system.

    • The Sun SPARC Enterprise T5240 server, running Oracle Solaris and Oracle Solaris Studio 12 software on two UltraSPARC T2 Plus processors, beats the SPEC OMPM2001 4 cores/2 chips/8 threads result of IBM p 520 POWER6-based system by 25% in half the space.

    • Compared to the previous generation of IBM systems, the Sun SPARC Enterprise T5240 server with two UltraSPARC T2 Plus processors, surpasses the 4 cores/2 chips/8 threads SPEC OMPM2001 result of IBM p5 550 system by 27% in half the space.

    Oracle Sun T5240 Processor
    Number Two UltraSPARC T2 Plus multicore processors
    Architecture SPARC V9 architecture, ECC protected
    CPUs 1.2GHz 4-Core (32 ×2 for a total of 64 concurrent threads)
    1.2GHz 6-Core (48 ×2 for a total of 96 concurrent threads)
    1.2GHz 8-Core (64 ×2 for a total of 128 concurrent threads)
    1.4GHz 8-Core (64 ×2 for a total of 128 concurrent threads)
    Cache memory 4MB Level 2
    Oracle Sun T5240 Memory / Ram
    Capacities Total DIMM slots: 16 on system board, 16 on memory mezzanine, 32 slots total
    DIMM type: FBDIMM
    DIMM size: 1GB, 2GB, 4GB or 8GB
    Maximum capacity: 256GB (32 × 8GB)
    Standard Integrated Interfaces for the Oracle Sun T5240
    Network 4 × 10/100/1000 Mbps autonegotiating ports
    Note: 10-Gb Ethernet ports are available by adding XAUI cards to the I/O expansion slots. For each XAUI card added, one onboard 1Gb ethernet port is disabled.
    Network Management One dedicated 10/100Base-T RJ-45 port Ethernet port
    Serial Management One dedicated RJ-45 port
    Remote Management Onboard system controller, running Integrated Lights Out Manager (ILOM) 2.0 with two command sets:
    • ILOM
    • ALOM CMT compatibility shell

    Both command sets are available through the RJ-45 serial and 10/100Mbps ethernet interfaces.
    Serial One DB-9 connector
    USB Front: 2 USB 2.0 Ports
    Rear: 2 USB 2.0 Ports
    PCI Expansion Slots
    • 6 low-profile PCI-Express slots.
    • Slots 0 and 1 support PCI-Express or proprietary 10Gbit Ethernet (XAUI) cards.
    Slot # Physical Electrical
    0 x8 x8
    1 x8 x8
    2 x16 x8
    3 x8 x8
    4 x8 x8
    5 x8 x8
    Internal Mass Storage for the Oracle Sun T5240
    Disks
    • All PTO standard configurations ship with 8 disk backplanes and cannot be changed later.
    • ATO configurations provide an 8 disk or 16 disk backplane option as a selectable item.
    • The maximum disk capacity depends on which backplane is selected, and cannot be changed later.
      • Up to 16 73GB (10K or 15K RPM), 146GB 10K RPM, and 300GB, 10K RPM SAS 2.5 inch form factor disk drives

    Notes:
    Integrated hard drive controller supports RAID 0 and RAID 1.
    Hard drive configurations of nine or more hard drives require an input voltage of 200 – 240VAC.
    Solid State Drives
    • Up to 8 32GB solid state drives
    DVD-ROM 1 slimline DVD-Writer/CD-Writer
    Power Supplies
    2 × 1100 Watt, hot-swappable, N+1 redundant power supply units (PSU)
    Environment
    Input Voltage 100 – 240 VAC, 50-60Hz
    200 – 240 VAC, 50-60Hz for configurations containing either 16-disk backplane or 1.4GHz CPUs
    Input Current 12.0 – 10.0 A @ 100-120 VAC (max)
    7.2 – 6.0 A @ 200-240 VAC (max)
    Note: The maximum operating input values are based on P / (V *0.95), where P=maximum input power, V=input voltage. You can use this equation to calculate the maximum operating input current for your specific input voltage.
    Input Power 1364 W (max)
    Heat Output 4653 BTU/hr (max)
    Temperature Operating: 5° C to 35° C (41° F to 95° F)
    Nonoperating:-40° C to 65° C (-40° F to 149° F)Note: Above 900m (3000 ft), decrease maximum temperature as altitude increase, 1° C/300m (1.6° F/1000ft)
    Humidity Operating: 10% to 90% relative humidity noncondensing, 27° C (80.6° F) maximum wet bulb
    Nonoperating: 93% relative humidity noncondensing, 35° C (95° F) maximum wet bulb
    Altitude Operating: up to 3000m (10000 ft.)
    Nonoperating: up to 12000m (40000 ft.)
    Vibration Operating: 0.15G (z-axis), 0.10G (x,y axes) 5-500Hz swept sine
    Nonoperating: 0.5G (z-axis), 0.25G (x,y axes) 5-500Hz swept sine
    Shock Operating: 3G, 11ms half-sine
    Nonoperating: 1-inch roll-off free fall, front-to-back rolling direction, 25mm threshold height at 0.75 m/s impact velocity
    Sound Power Level
    LwAd (1 B = 10dB)    		 Operating: 7.7 B
    Idling: 7.7 B
    Sound Pressure Level
    LpAm (bystander positions)    		 Operating: 66 dB
    Idling: 66 dB
    Regulations
    Meets or exceeds the following requirements:
    RoHS Compliance Level RoHS:Y
    Safety UL/CSA-60950-1, EN60950-1, IEC60950-1 CB Scheme with all country deviations, IEC825-1, 2, CFR21 part 1040, CNS14336, GB4943
    RFI/EMI EN55022 Class A 47 CFR 15B Class A ICES-003 Class A VCCI Class A AS/NZ 3548 Class A CNS 13438 Class A KSC 5858 Class A GB9254 Class A EN61000-3-2 GB17625.1 EN61000-3-3
    Immunity EN55024 IEC 61000-4-2 IEC 61000-4-3 IEC 61000-4-4 IEC 61000-4-5 IEC 61000-4-6 IEC 61000-4-8 IEC 61000-4-11
    Regulatory Markings CE, FCC, ICES-003, C-tick, VCCI, GOST-R, BSMI, MIC, UL/cUL, UL/LVD, UL/S-mark
    Dimensions and WeightOracle Sun T5240
    Height 88 mm (3.49 in.)
    Width 425 mm (16.75 in.)
    Depth 714 mm (28.1 in.)
    Weight 23.81 kg (52.5 lb.) *
    Batteries
    Option # Manufacturing
    Part #    		 Description
    n/a 371-2210 CR2032 3V Battery, RoHS:Y
    Cables
    Option # Manufacturing
    Part #    		 Description
    SEUX9SA2Z 560-2917 Cable Kit (2× Mini SAS Cables), RoHS:Y
    • 530-4077
    • 4x Mini SAS Cable, SFF-8087 to SFF-8087, 400mm, RoHS:Y
    X311L Localized Power Cord Kit – North America/Asia, RoHS:Y
    180-1097 IEC 320 C13 to NEMA 5-15P – 15A/125V 2.5M Black, RoHS:Y
    X312E Localized Power Code Kit – China, RoHS:Y
    180-1982 IEC 320 C13 to GB 2099/GB 1002 – 10A/250V 2.5M, RoHS:Y
    X312F Localized Power Cord Kit – Argentina, RoHS:Y
    180-1999 IEC 320 C13 to IRAM 2073 – 10A/250V 2.5M Black, RoHS:Y
    X312G Localized Power Cord Kit – Korea, RoHS:Y
    180-1662 IEC 320 C13 to KSC 8305 – 15A/250V 2.5M Black, RoHS:Y
    X312L Localized Power Cord Kit – Continental Europe, RoHS:Y
    180-1993 IEC 320 C13 to CEE 7/7 10A/250V 2.5M Black, RoHS:Y
    X314L Localized Power Cord Kit – Swiss, RoHS:Y
    180-1994 IEC 320 C13 to SEV 1011 – 10A/250V 2.5M Black, RoHS:Y
    X317L Localized Power Cord Kit – U.K., RoHS:Y
    180-1997 IEC 320 C13 to BS 1363 – 10A/250V 2.5M Black, RoHS:Y
    X320A Localized Power Cord Kit – North America/Asia, RoHS:Y
    180-2164 IEC 320 C13 to NEMA 6-15P – 10A/250V 2.0M Black, RoHS:Y
    X332T International Power Cord Kit, RoHS:Y
    180-2071 Blue 16A IEC 309 to IEC 320 C13 International 4.0M, RoHS:Y
    X333A-25-10-IL Localized Power Cord Kit Israel, RoHS:Y
    180-2130 IEC 320 C13 to SI-32, 10A/250V, 2.5M, Black, RoHS:Y
    X333A-25-15-JP Localized Power Cord Kit Japan, RoHS:Y
    180-2243 IEC 320 C13 to PSE 5-15P, 15A/125V, 2.5M, Black, RoHS:Y
    X333A-25-15-TW Localized Power Cord Kit – Taiwan, RoHS:Y
    180-2333 IEC 320 C13 to CNS 690 – 15A/125V 2.5M Black, RoHS:Y
    X333F-25-15-JP Localized Power Cord Kit Japan, RoHS:Y
    180-2244 IEC 320 C13 to PSE 6-15P, 15A/250V, 2.5M, Black, RoHS:Y
    X340L Power Kit for North America, L6-20 20A Twist Lock Plug, RoHS:Y
    180-2070 NEMA L6-20P to IEC 320 C13 – 4.0M, RoHS:Y
    X383L Localized Power Cord Kit – Danish, RoHS:Y
    180-1995 IEC 320 C13 to Asfnit 107 – 10A/250V 2.5M Black, RoHS:Y
    X384L Localized Power Cord Kit – Italian, RoHS:Y
    180-1996 IEC 320 C13 to CEI 23-16/VII – 10A/250V 2.5M Black, RoHS:Y
    X386L Localized Power Cord Kit – Australian, RoHS:Y
    180-1998 IEC 320 C13 to AS 3112 – 10A/250V 2.5M Black, RoHS:Y
    X9237-1-A Power Cord Jumper X-Option 1.0M, RoHS:Y
    180-2082 IEC 320 Sheet E to IEC 320 C13 Power Jumper Cord 13A 90° 1.0M, RoHS:Y
    X9238-1-A Power Cord Jumper X-Option 2.5M, RoHS:Y
    180-2085 IEC 320 Sheet E to IEC 320 C13 Power Jumper Cord 13A 90° 2.5M, RoHS:Y
    n/a 530-3100 RJ45F to DB9F Adapter, RoHS:Y
    n/a 541-3370 PDB to System Board Ribbon Cable w/ insulator, RoHS:Y
    • 343-0786
    • Kapton Tape, RoHS:Y
    • 530-3956
    • PDB to System Board Ribbon Cable, RoHS:Y
    Communication
    Option # Manufacturing
    Part #    		 Description
    X4237A 375-3606 Sun Dual Port 40Gb/sec 4x Infiniband QDR Host Channel Adapter PCI Express, RoHS:Y
    X6000A 375-3424 PCI Express Sun Crypto Accelerator 6000, RoHS:Y
    X1236A-Z 375-3382 Dual Port 10Gb/sec 4x PCI Express Infiniband Host Channel Adapter – Low Profile, RoHS:Y
    Disk Backplane
    Option # Manufacturing
    Part #    		 Description
    n/a 501-7730 8-Slot Disk Backplane, PATA DVD, RoHS:Y
    n/a 501-7760 16-Slot Disk Backplane, PATA DVD, RoHS:YL
    n/a 511-1256 8-Slot Disk Backplane, SATA DVD, RoHS:Y
    n/a 511-1257 16-Slot Disk Backplane, SATA DVD, RoHS:YL
    n/a 542-0355 Backplane Retainer Clip Kit
    • 330-5301
    • Grey 2U Backplane Retainer Clip
    Disks
    Option # Manufacturing
    Part #    		 Description
    SESX3C11Z 540-7355 146GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
    • 390-0324
    • Seagate ST9146802SS [ST914602SSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0375
    • Fujitsu MBB2147RC [MBB2147RCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0377
    • Hitachi HUC101414CSS300 [H101414SCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-2123
    • Marlin Bracket 2.5″, RoHS:Y
    540-7868 146GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
    • 390-0324
    • Seagate ST9146802SS [ST914602SSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0377
    • Hitachi HUC101414CSS300 [H101414SCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0448
    • Seagate ST9146803SS [ST914603SSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0450
    • Hitachi HUC103014CSS600 [H103014SCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-2123
    • Marlin Bracket 2.5″, RoHS:Y
    SESX3G11Z 540-7869 300GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
    • 390-0449
    • Seagate ST93000SSUNG [ST930003SSUN300G]
      (300GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0451
    • Hitachi HUC103030CSS600 [H103030SCSUN300G]
      (300GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-2123
    • Marlin Bracket 2.5″, RoHS:Y
    SESX3Y11Z 540-7841 32GB Solid State Drive Assembly, SATA Interface, RoHS:Y
    • 371-4196
    • 32GB Solid State Drive, SATA Interface, RoHS:Y
    • 541-2123
    • Marlin Bracket 2.5″, RoHS:Y
    SESX3A11Z 540-7354 73GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
    • 390-0285
    • Fujitsu MAY2073RC [MAY2073RCSUN72]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0323
    • Seagate ST973402SS [ST973402SSUN72G]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0374
    • Fujitsu MBB2073RC [MBB2073RCSUN72G]
      (73.4GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0376
    • Hitachi HUC101473CSS300 [H101473SCSUN72G]
      (73.4GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-2123
    • Marlin Bracket 2.5″, RoHS:Y
    SESX3A21Z 540-7361 73GB – 15000 RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks, RoHS:Y
    • 390-0382
    • Seagate ST973451SS [ST973451SSUN72G]
      (73GB – 15000 RPM – SAS Disk), RoHS:Y
    • 541-2123
    • Marlin Bracket 2.5″, RoHS:Y
    Ethernet
    Option # Manufacturing
    Part #    		 Description
    SESX7XA1Z 501-7489 10GbE XAUI Card, RoHS:Y
    SESX7XT1Z 375-3301 10Gb/sec XFP Optical Transceiver Short Range (SR), RoHS:YL
    SESX7XT2Z 375-3495 10Gb/sec XFP Optical Transceiver Long Range (LR), RoHS:Y
    SG-XPCIEFCOE2-Q-SR 375-3681 Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA – SR, RoHS:Y
    SG-XPCIEFCOE2-Q-TA 375-3682 Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA – Direct Attach, RoHS:Y
    X1027A-Z 501-7283 PCI Express Dual 10-Gigabit Ethernet Fiber, RoHS:Y
    X4447A-Z 511-1422 PCI Express Quad Gigabit Ethernet UTP, RoHS:Y
    • 371-2207
    • Bracket Low-Profile, RoHS:Y
    560-2884 Ship Kit for Gigabit Ethernet options
    • 371-2348
    • Bracket Standard, RoHS:Y
    X5558A 375-3301 10Gb/sec XFP Optical Transceiver Short Range (SR), RoHS:YL
    X5560A-Z 375-3495 10Gb/sec XFP Optical Transceiver Long Range (LR), RoHS:Y
    X7280A-2 371-0905 PCI Express Dual Gigabit Ethernet UTP, RoHS:Y
    X7281A-2 371-0904 PCI Express Dual Gigabit Ethernet MMF, RoHS:Y
    n/a 501-7606 PCI Express Quad Gigabit Ethernet UTP, RoHS:Y
    • 371-2207
    • Bracket Low-Profile, RoHS:Y
    • 371-2348
    • Bracket Standard, RoHS:Y
    Fan
    Option # Manufacturing
    Part #    		 Description
    n/a 541-2211 Fan Power Board, RoHS:Y
    • 330-4463
    • Top Bracket, RoHS:Y
    • 330-4464
    • Bottom Bracket, RoHS:Y
    • 501-7695
    • Fan Board, RoHS:Y
    n/a 541-2940 CPU Dual Fan Assembly w/ Metal Fingerguards, RoHS:Y
    • 310-0119
    • Delta Fan, 60×38mm, 2U, RoHS:Y
    n/a 541-3290 CPU Dual Fan Assembly w/ Metal Fingerguards, RoHS:Y
    Fibre Channel
    Option # Manufacturing
    Part #    		 Description
    SG-XPCIE1FC-EM4 375-3396 4Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
    SG-XPCIE1FC-EM8-Z 371-4295 8Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
    SG-XPCIE1FC-QF4 375-3355 4Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
    SG-XPCIE1FC-QF8-Z 371-4324 8Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
    SG-XPCIE2FC-EM4 375-3397 4Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
    SG-XPCIE2FC-EM8-Z 371-4306 8Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
    SG-XPCIE2FC-QF4 375-3356 4Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
    SG-XPCIE2FC-QF8-Z 371-4325 8Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
    Graphics
    Option # Manufacturing
    Part #    		 Description
    X3000A 375-3545 XVR-300 x8 Graphics Accelerator, RoHS:Y
    530-3474 DVI-A(M) to HD15F Adapter, 49mm, RoHS:Y
    530-3998 DMS-59 to Dual DVI-I Cable, 215mm, RoHS:Y
    X4240A 605-4668 XVR-300X16 Graphics Accelerator, RoHS:Y
    • 375-3458
    • XVR-300 Graphics Accelerator, RoHS:Y
    • 530-3474
    • DVI-A(M) to HD15F Adapter, 49mm, RoHS:Y
    • 530-3998
    • DMS-59 to Dual DVI-I Cable, 215mm, RoHS:Y
    I/O
    Option # Manufacturing
    Part #    		 Description
    n/a 541-2108 x16/x8 PCI Express Riser Card Assembly, RoHS:Y
    • 341-4139
    • PCI Filler Panel, RoHS:Y
    • 501-7715
    • x16/x8 PCI Express Riser Card, RoHS:Y
    • 541-2736
    • Riser Bracket, RoHS:Y
    n/a 541-2109 x8/x8 XAUI Riser Card Assembly, RoHS:Y
    • 341-4139
    • PCI Filler Panel, RoHS:Y
    • 501-7719
    • x8/x8 XAUI Riser Card, RoHS:Y
    • 541-2736
    • Riser Bracket, RoHS:Y
    IDPROM
    Socket Manufacturing
    Part #    		 Component Type Host ID
    n/a 525-2344 System Configuration PROM n/a
    Memory
    Option # Manufacturing
    Part #    		 Description
    SESX2B3Z 4GB Memory Expansion (2 × 2GB) X-Option, RoHS:Y
    511-1151 2GB DDR2-667/PC2-5300 1.5V DIMM, RoHS:Y
    SESX2C1Z 8GB Memory Expansion (2 × 4GB) X-Option, RoHS:Y
    501-7954 4GB DDR2-667/PC2-5300 1.8V FBDIMM, RoHS:Y
    SESX2C3Z 8GB Memory Expansion (2 × 4GB) X-Option, RoHS:Y
    511-1152 4GB DDR2-667/PC2-5300 1.5V DIMM, RoHS:Y
    SESX2D3Z 16GB Memory Expansion (2 × 8GB) X-Option, RoHS:Y
    511-1228 8GB DDR2-667/PC2-5300 1.5V DIMM, RoHS:Y
    SEUX2MM2Z 594-4996 Memory Mezzanine, RoHS:Y
    • 330-4839
    • Memory Slot Filler, RoHS:Y
    • 341-4167
    • Memory Mezzanine Shipping Bracket, RoHS:Y
    • 540-7792
    • Memory Mezzanine Assembly, RoHS:Y
    • 511-1231
    • Memory Riser, RoHS:Y
    • 541-2473
    • Side Support Bracket, RoHS:Y
    • 541-3064
    • Clear Plastic Memory Mezzanine Air Duct, RoHS:Y
    • 541-3065
    • Grey Plastic Memory Mezzanine Lower Air Duct, RoHS:Y
    SESX2A1Z 2GB Memory Expansion (2 × 1GB) X-Option, RoHS:Y
    501-7952 1GB DDR2-667/PC2-5300 1.8V FBDIMM, RoHS:Y
    SESX2A3Z 2GB Memory Expansion (2 × 1GB) X-Option, RoHS:Y
    511-1150 1 GB DDR2-667/PC2-5300 1.5V DIMM, RoHS:Y
    SESX2B1Z 4GB Memory Expansion (2 × 2GB) X-Option, RoHS:Y
    501-7953 2GB DDR2-667/PC2-5300 1.8V FBDIMM, RoHS:Y
    SEUX2MM1Z 594-5205 Memory Mezzanine, RoHS:Y
    • 330-4839
    • Memory Slot Filler, RoHS:Y
    • 341-4167
    • Memory Mezzanine Shipping Bracket, RoHS:Y
    • 541-2351
    • Memory Mezzanine Assembly, RoHS:Y
    • 501-7678
    • Memory Riser, RoHS:Y
    • 541-2473
    • Side Support Bracket, RoHS:Y
    • 541-3064
    • Clear Plastic Memory Mezzanine Air Duct, RoHS:Y
    • 541-3065
    • Grey Plastic Memory Mezzanine Lower Air Duct, RoHS:Y
    n/a 371-3651 Memory Slot Filler, EBS93011010, RoHS:Y
    Power
    Option # Manufacturing
    Part #    		 Description
    SEUX9PS51Z 300-2138 1100/1200 Watt AC Input Power Supply, Type A235, RoHS:Y
    n/a 300-2105 1200 Watt DC Input Power Supply, Type D204, RoHS:Y
    n/a 371-4650 Energy Storage Module (ESM), RoHS:Y
    n/a 541-2073 Power Distribution Board/Bus Bar Assembly, RoHS:Y
    • 341-3166
    • Bus Bar Left, RoHS:Y
    • 341-3167
    • Bus Bar Right, RoHS:Y
    • 501-7697
    • Horizontal Power Distribution Board, RoHS:Y
    • 371-2484
    • PDB Signal Cable, RoHS:Y
    • 501-7951
    • Vertical Power Distribution Board, RoHS:Y
    Rack
    Option # Manufacturing
    Part #    		 Description
    SESX9CA1Z 371-2742 Cable Management Arm, RoHS:Y
    SESX9RK1Z 371-2741 Screw-Mount Slide Rail Rackmount Kit, 730mm, RoHS:Y
    SESX9RK2Z 371-2740 Snap-In Slide Rail Rackmount Kit, 730mm, RoHS:Y
    Removable Media
    Option # Manufacturing
    Part #    		 Description
    SESX9DV2Z 541-3493 SATA DVD-Writer/CD-Writer – USB Board Assembly, RoHS:Y
    • 330-5056
    • DVD Interconnect Holder, RoHS:Y
    • 390-0442
    • 8x SATA DVD-Writer/24x CD-Writer, RoHS:Y
    • 390-0443
    • 8x SATA DVD-Writer/24x CD-Writer, RoHS:Y
    • 501-7698
    • USB Board, RoHS:Y
    • 541-3686
    • DVD Bezel, RoHS:Y
    SESX9DV1Z 541-2110 PATA DVD-Writer/CD-Writer – USB Board Assembly, RoHS:Y
    • 330-4418
    • DVD Interconnect Holder, RoHS:Y
    • 390-0337
    • 8x PATA DVD-Writer/24x CD-Writer, RoHS:Y
    • 501-7698
    • USB Board, RoHS:Y
    • 541-2111
    • DVD Bezel, RoHS:Y
    n/a 541-2732 USB Assembly, RoHS:Y
    • 330-4418
    • DVD Interconnect Holder, RoHS:Y
    • 341-4072
    • DVD Filler Panel, RoHS:Y
    • 501-7698
    • USB Board, RoHS:Y
    SCSI
    Option # Manufacturing
    Part #    		 Description
    SG-XPCIE2SCSIU320Z 375-3357 Dual-Channel Ultra320 LVD SCSI PCI Express Adapter, RoHS:Y
    SG-XPCIE8SAS-E-Z 375-3487 PCI Express 8-Port Host Adapter, RoHS:Y
    SGXPCIESAS-R-EXT-Z 371-3253 Lithium Ion Battery Module
    375-3537 8-Port SAS RAID External HBA, RoHS:Y
    SGXPCIESAS-R-INT-Z 371-3253 Lithium Ion Battery Module
    375-3536 8-Port SAS Adaptec RAID HBA, RoHS:Y
    XTA-FAS-S3IE96GB 541-3731 96GB PCI Express Flash Accelerator F20 SAS HBA, RoHS:Y
    • 371-4415
    • 24GB Solid State Flash Memory Module, RoHS:Y
    • 371-4650
    • Energy Storage Module (ESM), RoHS:Y
    • 511-1500
    • PCI Express Flash Board, RoHS:Y
    System Board
    Option # Manufacturing
    Part #    		 Description
    n/a 341-4139 PCI Filler Panel, RoHS:Y
    n/a 540-7908 8-Core 1.6GHz Motherboard Assembly, RoHS:Y
    • 330-4793
    • Memory Mezzanine Slot Filler, RoHS:Y
    • 511-1344
    • 8-Core 1.6GHz System Board, RoHS:Y
    • 371-2210
    • CR2032 3V Battery, RoHS:Y
    • 525-2344
    • System Configuration PROM, RoHS:Y
    • 541-2523
    • System Board Tray, RoHS:Y
    n/a 540-7934 8-Core 1.4GHz Motherboard Assembly, RoHS:Y
    • 330-4793
    • Memory Mezzanine Slot Filler, RoHS:Y
    • 511-1378
    • 8-Core 1.4GHz System Board, RoHS:Y
    • 371-2210
    • CR2032 3V Battery, RoHS:Y
    • 525-2344
    • System Configuration PROM, RoHS:Y
    • 541-2523
    • System Board Tray, RoHS:Y
    n/a 540-7938 4-Core 1.2GHz Motherboard Assembly, RoHS:Y
    • 330-4793
    • Memory Mezzanine Slot Filler, RoHS:Y
    • 511-1391
    • 4-Core 1.2GHz System Board, RoHS:Y
    • 371-2210
    • CR2032 3V Battery, RoHS:Y
    • 525-2344
    • System Configuration PROM, RoHS:Y
    • 541-2523
    • System Board Tray, RoHS:Y
    n/a 540-7939 6-Core 1.2GHz Motherboard Assembly, RoHS:Y
    • 330-4793
    • Memory Mezzanine Slot Filler, RoHS:Y
    • 511-1392
    • 6-Core 1.2GHz System Board, RoHS:Y
    • 371-2210
    • CR2032 3V Battery, RoHS:Y
    • 525-2344
    • System Configuration PROM, RoHS:Y
    • 541-2523
    • System Board Tray, RoHS:Y
    n/a 540-7940 8-Core 1.2GHz Motherboard Assembly, RoHS:Y
    • 330-4793
    • Memory Mezzanine Slot Filler, RoHS:Y
    • 511-1393
    • 8-Core 1.2GHz System Board, RoHS:Y
    • 371-2210
    • CR2032 3V Battery, RoHS:Y
    • 525-2344
    • System Configuration PROM, RoHS:Y
    • 541-2523
    • System Board Tray, RoHS:Y
    n/a 541-2528 6-Core 1.2GHz Motherboard Assembly, RoHS:Y
    • 330-4793
    • Memory Mezzanine Slot Filler, RoHS:Y
    • 501-7846
    • 6-Core 1.2GHz System Board, RoHS:Y
    • 371-2210
    • CR2032 3V Battery, RoHS:Y
    • 525-2344
    • System Configuration PROM, RoHS:Y
    • 541-2523
    • System Board Tray, RoHS:Y
    n/a 541-2529 8-Core 1.2GHz Motherboard Assembly, RoHS:Y
    • 330-4793
    • Memory Mezzanine Slot Filler, RoHS:Y
    • 501-7847
    • 8-Core 1.2GHz System Board, RoHS:Y
    • 371-2210
    • CR2032 3V Battery, RoHS:Y
    • 525-2344
    • System Configuration PROM, RoHS:Y
    • 541-2523
    • System Board Tray, RoHS:Y
    n/a 541-2530 8-Core 1.4GHz Motherboard Assembly, RoHS:Y
    • 330-4793
    • Memory Mezzanine Slot Filler, RoHS:Y
    • 501-7848
    • 8-Core 1.4GHz System Board, RoHS:Y
    • 371-2210
    • CR2032 3V Battery, RoHS:Y
    • 525-2344
    • System Configuration PROM, RoHS:Y
    • 541-2523
    • System Board Tray, RoHS:Y
    n/a 541-2931 4-Core 1.2GHz Motherboard Assembly, RoHS:Y
    • 330-4793
    • Memory Mezzanine Slot Filler, RoHS:Y
    • 511-1035
    • 4-Core 1.2GHz System Board, RoHS:Y
    • 371-2210
    • CR2032 3V Battery, RoHS:Y
    • 525-2344
    • System Configuration PROM, RoHS:Y
    • 541-2523
    • System Board Tray, RoHS:Y

    Industry Leading Quality, Support and Integrity

    Quality Inspection Checklist
    Before it leaves our facility, every used and refurbished item is thoroughly inspected by our certified technicians and undergoes our exclusive Quality Inspection Checklist to ensure 100% satisfaction guarantee.

    Greentec Systems is a leading provider
    For server, networking and storage equipment. We have an extensive array of inventory of IBM Servers & Storage, Sun Servers & Storage, Cisco Networking (Switches, Routers, Security), and NetApp Storage (disk shelves, disk drives, Filers, NearStore, NetCache). If you don’t see the item or product you require please contact us.

    Have this equipment to sell?
    Depending on the age and condition of the equipment, there is a very good likelihood that we will be able to offer you cash or trade-in credit for other IT hardware. If the equipment is very old we can also assist you with properly decommissioning that gear in the most environmentally friendly way possible.

    Questions?
    For more information please contact 888.333.7388, or fill out the quote from above. We’d love to hear from you.

    Request Quote
    Greentec Systems We geek out helping you with your IT infrastructure.
    Request a quote or product information
    Send
