Used Oracle Sun T5140 Server

Oracle Sun T5140 Server

REQUEST A PRICE QUOTE:

Processor

Number

Two UltraSPARC T2 Plus multicore processors

Architecture

SPARC V9 architecture, ECC protected

CPUs

1.2GHz 4-Core (32 ×2 for a total of 64 concurrent threads)
1.2GHz 6-Core (48 ×2 for a total of 96 concurrent threads)
1.2GHz 8-Core (64 ×2 for a total of 128 concurrent threads)
1.4GHz 8-Core (64 ×2 for a total of 128 concurrent threads)

Cache memory

4MB Level 2

Main Memory

Capacities

Total DIMM slots: 16
DIMM type: FBDIMM
DIMM size: 1GB, 2GB, 4GB or 8GB
Maximum capacity: 128GB (16 × 8GB)

Standard Integrated Interfaces

Network

4 × 10/100/1000 Mbps autonegotiating ports
Note: 10-Gb Ethernet ports are available by adding XAUI cards to the I/O expansion slots. For each XAUI card added, one onboard 1Gb ethernet port is disabled.

Network Management

One dedicated 10/100Base-T RJ-45 port Ethernet port

Serial Management

One dedicated RJ-45 port

Remote Management

Onboard system controller, running Integrated Lights Out Manager (ILOM) 2.0 with two command sets:

ILOM
ALOM CMT compatibility shell

Both command sets are available through the RJ-45 serial and 10/100Mbps ethernet interfaces.

Serial

One DB-9 connector

USB

Front: 2 USB 2.0 Ports
Rear: 2 USB 2.0 Ports

PCI Expansion Slots

3 low-profile PCI-Express slots.
Slots 0 and 1 support PCI-Express or proprietary 10Gbit Ethernet (XAUI) cards.

Slot #	Physical	Electrical
0	x8	x8
1	x8	x8
2	x16	x8

Internal Mass Storage

Disks

All PTO standard configurations ship with 4 disk backplanes and cannot be changed later.
ATO configurations provide a 4 disk or 8 disk backplane option as a selectable item.
The maximum disk capacity depends on which backplane is selected, and cannot be changed later. <.li>
- Up to 8 73GB (10K or 15K RPM), 146GB 10K RPM, and 300GB, 10K RPM SAS 2.5 inch form factor disk drives

Notes:
Integrated hard drive controller supports RAID 0 and RAID 1.

Solid State Drives

Up to 4 32GB solid state drives

DVD-ROM

1 slimline DVD-Writer/CD-Writer

Power Supplies

2 × 720 Watt, hot-swappable, N+1 redundant power supply units (PSU)

Environment

Input Voltage

100 – 240 VAC, 50-60Hz

Input Current

8.3 – 7.2 A @ 100-120 VAC (max)
4.3 – 3.6 A @ 200-240 VAC (max)
Note: The maximum operating input values are based on P / (V *0.95), where P=maximum input power, V=input voltage. You can use this equation to calculate the maximum operating input current for your specific input voltage.

Input Power

822 W (max)

Heat Output

2,804 BTU/hr (max)

Temperature

Operating: 5° C to 35° C (41° F to 95° F)
Nonoperating:-40° C to 65° C (-40° F to 149° F)Note: Above 900m (3000 ft), decrease maximum temperature as altitude increase, 1° C/300m (1.6° F/1000ft)

Humidity

Operating: 10% to 90% relative humidity noncondensing, 27° C (80.6° F) maximum wet bulb
Nonoperating: 93% relative humidity noncondensing, 35° C (95° F) maximum wet bulb

Altitude

Operating: up to 3000m (10000 ft.)
Nonoperating: up to 12000m (40000 ft.)

Vibration

Operating: 0.15G (z-axis), 0.10G (x,y axes) 5-500Hz swept sine
Nonoperating: 0.5G (z-axis), 0.25G (x,y axes) 5-500Hz swept sine

Shock

Operating: 3G, 11ms half-sine
Nonoperating: 1-inch roll-off free fall, front-to-back rolling direction, 25mm threshold height at 0.75 m/s impact velocity

Sound Power Level
LwAd (1 B = 10dB)

Operating: 7.3 B
Idling: 7.3 B

Sound Pressure Level
LpAm (bystander positions)

Operating: 62 dB
Idling: 62 dB

Regulations
Meets or exceeds the following requirements:

RoHS Compliance Level

RoHS:Y

Safety

UL/CSA-60950-1, EN60950-1, IEC60950-1 CB Scheme with all country deviations, IEC825-1,2 CFR21 part 1040, CNS14336, GB4943

RFI/EMI

EN55022 Class A, 47 CFR 15B Class A, ICES-003 Class A, VCCI Class A, AS/NZ3548 Class A CNS 13438 Class A KSC 5858 Class A, GB9254 Class A, EN61000-3-2, GB17625.1, EN61000-3-3

Immunity

EN55024 IEC 61000-4-2 IEC 61000-4-3 IEC 61000-4-4 IEC 61000-4-5 IEC 61000-4-6 IEC 61000-4-8 IEC 61000-4-11

Regulatory Markings

CE, FCC, ICES-003, C-tick, VCCI, GOST-R, BSMI, markings MIC, UL/cUL, UL/LVD, UL/S-mark, CCC

Dimensions and Weight

Height

44 mm (1.746 in.)

Width

425.5 mm (16.75 in.)

Depth

714.4 mm (28.1 in.)

Weight

16.78 kg (36.9 lb.)

Batteries
Option #	Manufacturing Part #	Description
n/a	371-2210	CR2032 3V Battery, RoHS:Y

Cables
Option #	Manufacturing Part #	Description
SETX9SA1Z	560-2916	Mini SAS Cable Kit, RoHS:Y
	530-3891	4x Mini SAS Cable, SFF-8087 to SFF-8087, 450mm, RoHS:Y
	530-3893	4x Mini SATA Cable, SFF-8087 to SFF-8087, 600mm, RoHS:Y
	530-4077	4x Mini SAS Cable, SFF-8087 to SFF-8087, 400mm, RoHS:Y
X311L	Localized Power Cord Kit – North America/Asia, RoHS:Y
X311L	180-1097	IEC 320 C13 to NEMA 5-15P – 15A/125V 2.5M Black, RoHS:Y
X312E	Localized Power Code Kit – China, RoHS:Y
X312E	180-1982	IEC 320 C13 to GB 2099/GB 1002 – 10A/250V 2.5M, RoHS:Y
X312F	Localized Power Cord Kit – Argentina, RoHS:Y
X312F	180-1999	IEC 320 C13 to IRAM 2073 – 10A/250V 2.5M Black, RoHS:Y
X312G	Localized Power Cord Kit – Korea, RoHS:Y
X312G	180-1662	IEC 320 C13 to KSC 8305 – 15A/250V 2.5M Black, RoHS:Y
X312L	Localized Power Cord Kit – Continental Europe, RoHS:Y
X312L	180-1993	IEC 320 C13 to CEE 7/7 10A/250V 2.5M Black, RoHS:Y
X314L	Localized Power Cord Kit – Swiss, RoHS:Y
X314L	180-1994	IEC 320 C13 to SEV 1011 – 10A/250V 2.5M Black, RoHS:Y
X317L	Localized Power Cord Kit – U.K., RoHS:Y
X317L	180-1997	IEC 320 C13 to BS 1363 – 10A/250V 2.5M Black, RoHS:Y
X332A	Localized Power Cord Kit – Taiwan, RoHS:Y
X332A	180-2121	IEC 320 C13 to NEMA 5-15P – 10A/125V 2.5M Black, RoHS:Y
X332T	International Power Cord Kit, RoHS:Y
X332T	180-2071	Blue 16A IEC 309 to IEC 320 C13 International 4.0M, RoHS:Y
X333A-25-10-IL	Localized Power Cord Kit Israel, RoHS:Y
X333A-25-10-IL	180-2130	IEC 320 C13 to SI-32, 10A/250V, 2.5M, Black, RoHS:Y
X333A-25-15-JP	Localized Power Cord Kit Japan, RoHS:Y
X333A-25-15-JP	180-2243	IEC 320 C13 to PSE 5-15P, 15A/125V, 2.5M, Black, RoHS:Y
X333F-25-15-JP	Localized Power Cord Kit Japan, RoHS:Y
X333F-25-15-JP	180-2244	IEC 320 C13 to PSE 6-15P, 15A/250V, 2.5M, Black, RoHS:Y
X340L	Power Kit for North America, L6-20 20A Twist Lock Plug, RoHS:Y
X340L	180-2070	NEMA L6-20P to IEC 320 C13 – 4.0M, RoHS:Y
X383L	Localized Power Cord Kit – Danish, RoHS:Y
X383L	180-1995	IEC 320 C13 to Asfnit 107 – 10A/250V 2.5M Black, RoHS:Y
X384L	Localized Power Cord Kit – Italian, RoHS:Y
X384L	180-1996	IEC 320 C13 to CEI 23-16/VII – 10A/250V 2.5M Black, RoHS:Y
X386L	Localized Power Cord Kit – Australian, RoHS:Y
X386L	180-1998	IEC 320 C13 to AS 3112 – 10A/250V 2.5M Black, RoHS:Y
X9237-1-A	Power Cord Jumper X-Option 1.0M, RoHS:Y
X9237-1-A	180-2082	IEC 320 Sheet E to IEC 320 C13 Power Jumper Cord 13A 90° 1.0M, RoHS:Y
X9238-1-A	Power Cord Jumper X-Option 2.5M, RoHS:Y
X9238-1-A	180-2085	IEC 320 Sheet E to IEC 320 C13 Power Jumper Cord 13A 90° 2.5M, RoHS:Y
n/a	530-3100	RJ45F to DB9F Adapter, RoHS:Y
n/a	541-3370	PDB to System Board Ribbon Cable w/ insulator, RoHS:Y
	343-0786	Kapton Tape, RoHS:Y
	530-3956	PDB to System Board Ribbon Cable, RoHS:Y

Communication
Option #	Manufacturing Part #	Description
X4237A	375-3606	Sun Dual Port 40Gb/sec 4x Infiniband QDR Host Channel Adapter PCI Express, RoHS:Y
X6000A	375-3424	PCI Express Sun Crypto Accelerator 6000, RoHS:Y
X1236A-Z	375-3382	Dual Port 10Gb/sec 4x PCI Express Infiniband Host Channel Adapter – Low Profile, RoHS:Y

Disk Backplane
Option #	Manufacturing Part #	Description
n/a	501-7699	4-Slot Disk Backplane, PATA DVD, RoHS:Y
n/a	501-7797	8-Slot Disk Backplane, PATA DVD, RoHS:Y
n/a	511-1282	4-Slot Disk Backplane, SATA DVD, RoHS:Y
n/a	511-1283	8-Slot Disk Backplane, SATA DVD, RoHS:Y
n/a	542-0355	Backplane Retainer Clip Kit
n/a	330-5316	Black 1U Backplane Retainer Clip

Disks
Option #	Manufacturing Part #	Description
SESX3C11Z	540-7355	146GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
	390-0324	Seagate ST9146802SS [ST914602SSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0375	Fujitsu MBB2147RC [MBB2147RCSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0377	Hitachi HUC101414CSS300 [H101414SCSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	541-2123	Marlin Bracket 2.5″, RoHS:Y
	540-7868	146GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
	390-0324	Seagate ST9146802SS [ST914602SSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0377	Hitachi HUC101414CSS300 [H101414SCSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0448	Seagate ST9146803SS [ST914603SSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0450	Hitachi HUC103014CSS600 [H103014SCSUN146G] (146GB – 10000 RPM – SAS Disk), RoHS:Y
	541-2123	Marlin Bracket 2.5″, RoHS:Y
SESX3G11Z	540-7869	300GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
	390-0449	Seagate ST93000SSUNG [ST930003SSUN300G] (300GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0451	Hitachi HUC103030CSS600 [H103030SCSUN300G] (300GB – 10000 RPM – SAS Disk), RoHS:Y
	541-2123	Marlin Bracket 2.5″, RoHS:Y
SESX3Y11Z	540-7841	32GB Solid State Drive Assembly, SATA Interface, RoHS:Y
	371-4196	32GB Solid State Drive, SATA Interface, RoHS:Y
	541-2123	Marlin Bracket 2.5″, RoHS:Y
SESX3A11Z	540-7354	73GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
	390-0285	Fujitsu MAY2073RC [MAY2073RCSUN72] (73GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0323	Seagate ST973402SS [ST973402SSUN72G] (73GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0374	Fujitsu MBB2073RC [MBB2073RCSUN72G] (73.4GB – 10000 RPM – SAS Disk), RoHS:Y
	390-0376	Hitachi HUC101473CSS300 [H101473SCSUN72G] (73.4GB – 10000 RPM – SAS Disk), RoHS:Y
	541-2123	Marlin Bracket 2.5″, RoHS:Y
SESX3A21Z	540-7361	73GB – 15000 RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks, RoHS:Y
	390-0382	Seagate ST973451SS [ST973451SSUN72G] (73GB – 15000 RPM – SAS Disk), RoHS:Y
	541-2123	Marlin Bracket 2.5″, RoHS:Y

Ethernet
Option #	Manufacturing Part #	Description
SESX7XA1Z	501-7489	10GbE XAUI Card, RoHS:Y
SESX7XT1Z	375-3301	10Gb/sec XFP Optical Transceiver Short Range (SR), RoHS:YL
SESX7XT2Z	375-3495	10Gb/sec XFP Optical Transceiver Long Range (LR), RoHS:Y
SG-XPCIEFCOE2-Q-SR	375-3681	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA – SR, RoHS:Y
SG-XPCIEFCOE2-Q-TA	375-3682	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA – Direct Attach, RoHS:Y
X1027A-Z	501-7283	PCI Express Dual 10-Gigabit Ethernet Fiber, RoHS:Y
X4447A-Z	511-1422	PCI Express Quad Gigabit Ethernet UTP, RoHS:Y
	371-2207	Bracket Low-Profile, RoHS:Y
	560-2884	Ship Kit for Gigabit Ethernet options
	371-2348	Bracket Standard, RoHS:Y
X5558A	375-3301	10Gb/sec XFP Optical Transceiver Short Range (SR), RoHS:YL
X5560A-Z	375-3495	10Gb/sec XFP Optical Transceiver Long Range (LR), RoHS:Y
X7280A-2	371-0905	PCI Express Dual Gigabit Ethernet UTP, RoHS:Y
X7281A-2	371-0904	PCI Express Dual Gigabit Ethernet MMF, RoHS:Y
n/a	501-7606	PCI Express Quad Gigabit Ethernet UTP, RoHS:Y
	371-2207	Bracket Low-Profile, RoHS:Y
	371-2348	Bracket Standard, RoHS:Y

Fan
Option #	Manufacturing Part #	Description
n/a	330-4683	Fan Connector Cover, RoHS:Y
n/a	541-2112	Fan Power Board, RoHS:Y
	330-4442	Top Bracket, RoHS:Y
	330-4443	Bottom Bracket, RoHS:Y
	501-7694	Fan Board, RoHS:Y
n/a	541-2802	Fan Module, RoHS:Y

Fibre Channel
Option #	Manufacturing Part #	Description
SG-XPCIE1FC-EM4	375-3396	4Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
SG-XPCIE1FC-EM8-Z	371-4295	8Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
SG-XPCIE1FC-QF4	375-3355	4Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
SG-XPCIE1FC-QF8-Z	371-4324	8Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
SG-XPCIE2FC-EM4	375-3397	4Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
SG-XPCIE2FC-EM8-Z	371-4306	8Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
SG-XPCIE2FC-QF4	375-3356	4Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
SG-XPCIE2FC-QF8-Z	371-4325	8Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y

Graphics
Option #	Manufacturing Part #	Description
X3000A	375-3545	XVR-300 x8 Graphics Accelerator, RoHS:Y
	530-3474	DVI-A(M) to HD15F Adapter, 49mm, RoHS:Y
	530-3998	DMS-59 to Dual DVI-I Cable, 215mm, RoHS:Y
X4240A	605-4668	XVR-300X16 Graphics Accelerator, RoHS:Y
	375-3458	XVR-300 Graphics Accelerator, RoHS:Y
	530-3474	DVI-A(M) to HD15F Adapter, 49mm, RoHS:Y
	530-3998	DMS-59 to Dual DVI-I Cable, 215mm, RoHS:Y

I/O
Option #	Manufacturing Part #	Description
n/a	541-2127	x16 PCI Express Riser Card Assembly, RoHS:Y
	501-7717	PCI Express Riser Card, RoHS:Y
	541-2737	Riser Bracket, RoHS:Y
n/a	541-2128	x8 PCI Express/XAUI Riser Card Assembly, RoHS:Y
	501-7721	XAUI Riser Card, RoHS:Y
	541-2737	Riser Bracket, RoHS:Y

IDPROM
Socket	Manufacturing Part #	Component Type	Host ID
n/a	525-2344	System Configuration PROM	n/a

Memory
Option #	Manufacturing Part #	Description
SESX2B3Z	4GB Memory Expansion (2 × 2GB) X-Option, RoHS:Y
SESX2B3Z	511-1151	2GB DDR2-667/PC2-5300 1.5V DIMM, RoHS:Y
SESX2C1Z	8GB Memory Expansion (2 × 4GB) X-Option, RoHS:Y
SESX2C1Z	501-7954	4GB DDR2-667/PC2-5300 1.8V FBDIMM, RoHS:Y
SESX2C3Z	8GB Memory Expansion (2 × 4GB) X-Option, RoHS:Y
SESX2C3Z	511-1152	4GB DDR2-667/PC2-5300 1.5V DIMM, RoHS:Y
SESX2D3Z	16GB Memory Expansion (2 × 8GB) X-Option, RoHS:Y
SESX2D3Z	511-1228	8GB DDR2-667/PC2-5300 1.5V DIMM, RoHS:Y
SESX2A1Z	2GB Memory Expansion (2 × 1GB) X-Option, RoHS:Y
SESX2A1Z	501-7952	1GB DDR2-667/PC2-5300 1.8V FBDIMM, RoHS:Y
SESX2A3Z	2GB Memory Expansion (2 × 1GB) X-Option, RoHS:Y
SESX2A3Z	511-1150	1 GB DDR2-667/PC2-5300 1.5V DIMM, RoHS:Y
SESX2B1Z	4GB Memory Expansion (2 × 2GB) X-Option, RoHS:Y
SESX2B1Z	501-7953	2GB DDR2-667/PC2-5300 1.8V FBDIMM, RoHS:Y

Power
Option #	Manufacturing Part #	Description
SETX9PS41Z	300-2137	720 Watt Power Supply, RoHS:Y
SETX9PS81Z	300-2143	760 Watt Power Supply, RoHS:Y
n/a	300-2186	660 Watt DC Input Power Supply, Type D218, RoHS:Y
n/a	371-4650	Energy Storage Module (ESM), RoHS:Y
n/a	501-7696	Power Distribution Board, RoHS:Y

Rack
Option #	Manufacturing Part #	Description
SESX9CA1Z	371-2742	Cable Management Arm, RoHS:Y
SESX9RK1Z	371-2741	Screw-Mount Slide Rail Rackmount Kit, 730mm, RoHS:Y
SESX9RK2Z	371-2740	Snap-In Slide Rail Rackmount Kit, 730mm, RoHS:Y

Removable Media
Option #	Manufacturing Part #	Description
SESX9DV2Z	541-3493	SATA DVD-Writer/CD-Writer – USB Board Assembly, RoHS:Y
	330-5056	DVD Interconnect Holder, RoHS:Y
	390-0442	8x SATA DVD-Writer/24x CD-Writer, RoHS:Y
	390-0443	8x SATA DVD-Writer/24x CD-Writer, RoHS:Y
	501-7698	USB Board, RoHS:Y
	541-3686	DVD Bezel, RoHS:Y
SESX9DV1Z	541-2110	PATA DVD-Writer/CD-Writer – USB Board Assembly, RoHS:Y
	330-4418	DVD Interconnect Holder, RoHS:Y
	390-0337	8x PATA DVD-Writer/24x CD-Writer, RoHS:Y
	501-7698	USB Board, RoHS:Y
	541-2111	DVD Bezel, RoHS:Y
n/a	541-2732	USB Assembly, RoHS:Y
	330-4418	DVD Interconnect Holder, RoHS:Y
	341-4072	DVD Filler Panel, RoHS:Y
	501-7698	USB Board, RoHS:Y

SCSI
Option #	Manufacturing Part #	Description
SG-XPCIE2SCSIU320Z	375-3357	Dual-Channel Ultra320 LVD SCSI PCI Express Adapter, RoHS:Y
SG-XPCIE8SAS-E-Z	375-3487	PCI Express 8-Port Host Adapter, RoHS:Y
SGXPCIESAS-R-EXT-Z	371-3253	Lithium Ion Battery Module
SGXPCIESAS-R-EXT-Z	375-3537	8-Port SAS RAID External HBA, RoHS:Y
SGXPCIESAS-R-INT-Z	371-3253	Lithium Ion Battery Module
SGXPCIESAS-R-INT-Z	375-3536	8-Port SAS Adaptec RAID HBA, RoHS:Y
XTA-FAS-S3IE96GB	541-3731	96GB PCI Express Flash Accelerator F20 SAS HBA, RoHS:Y
	371-4415	24GB Solid State Flash Memory Module, RoHS:Y
	371-4650	Energy Storage Module (ESM), RoHS:Y
	511-1500	PCI Express Flash Board, RoHS:Y

System Board
Option #	Manufacturing Part #	Description
n/a	540-7934	8-Core 1.4GHz Motherboard Assembly, RoHS:Y
	330-4793	Memory Mezzanine Slot Filler, RoHS:Y
	511-1378	8-Core 1.4GHz System Board, RoHS:Y
	371-2210	CR2032 3V Battery, RoHS:Y
	525-2344	System Configuration PROM, RoHS:Y
	541-2523	System Board Tray, RoHS:Y
n/a	540-7938	4-Core 1.2GHz Motherboard Assembly, RoHS:Y
	330-4793	Memory Mezzanine Slot Filler, RoHS:Y
	511-1391	4-Core 1.2GHz System Board, RoHS:Y
	371-2210	CR2032 3V Battery, RoHS:Y
	525-2344	System Configuration PROM, RoHS:Y
	541-2523	System Board Tray, RoHS:Y
n/a	540-7939	6-Core 1.2GHz Motherboard Assembly, RoHS:Y
	330-4793	Memory Mezzanine Slot Filler, RoHS:Y
	511-1392	6-Core 1.2GHz System Board, RoHS:Y
	371-2210	CR2032 3V Battery, RoHS:Y
	525-2344	System Configuration PROM, RoHS:Y
	541-2523	System Board Tray, RoHS:Y
n/a	540-7940	8-Core 1.2GHz Motherboard Assembly, RoHS:Y
	330-4793	Memory Mezzanine Slot Filler, RoHS:Y
	511-1393	8-Core 1.2GHz System Board, RoHS:Y
	371-2210	CR2032 3V Battery, RoHS:Y
	525-2344	System Configuration PROM, RoHS:Y
	541-2523	System Board Tray, RoHS:Y
n/a	541-2528	6-Core 1.2GHz Motherboard Assembly, RoHS:Y
	330-4793	Memory Mezzanine Slot Filler, RoHS:Y
	501-7846	6-Core 1.2GHz System Board, RoHS:Y
	371-2210	CR2032 3V Battery, RoHS:Y
	525-2344	System Configuration PROM, RoHS:Y
	541-2523	System Board Tray, RoHS:Y
n/a	541-2529	8-Core 1.2GHz Motherboard Assembly, RoHS:Y
	330-4793	Memory Mezzanine Slot Filler, RoHS:Y
	501-7847	8-Core 1.2GHz System Board, RoHS:Y
	371-2210	CR2032 3V Battery, RoHS:Y
	525-2344	System Configuration PROM, RoHS:Y
	541-2523	System Board Tray, RoHS:Y
n/a	541-2530	8-Core 1.4GHz Motherboard Assembly, RoHS:Y
	330-4793	Memory Mezzanine Slot Filler, RoHS:Y
	501-7848	8-Core 1.4GHz System Board, RoHS:Y
	371-2210	CR2032 3V Battery, RoHS:Y
	525-2344	System Configuration PROM, RoHS:Y
	541-2523	System Board Tray, RoHS:Y
n/a	541-2931	4-Core 1.2GHz Motherboard Assembly, RoHS:Y
	330-4793	Memory Mezzanine Slot Filler, RoHS:Y
	511-1035	4-Core 1.2GHz System Board, RoHS:Y
	371-2210	CR2032 3V Battery, RoHS:Y
	525-2344	System Configuration PROM, RoHS:Y
	541-2523	System Board Tray, RoHS:Y

Industry Leading Quality, Support and Integrity

Quality Inspection Checklist
Before it leaves our facility, every used and refurbished item is thoroughly inspected by our certified technicians and undergoes our exclusive Quality Inspection Checklist to ensure 100% satisfaction guarantee.

Greentec Systems is a leading provider
For server, networking and storage equipment. We have an extensive array of inventory of IBM Servers & Storage, Sun Servers & Storage, Cisco Networking (Switches, Routers, Security), and NetApp Storage (disk shelves, disk drives, Filers, NearStore, NetCache). If you don’t see the item or product you require please contact us.

Have this equipment to sell?
Depending on the age and condition of the equipment, there is a very good likelihood that we will be able to offer you cash or trade-in credit for other IT hardware. If the equipment is very old we can also assist you with properly decommissioning that gear in the most environmentally friendly way possible.

Questions?
For more information please contact 888.333.7388, or fill out the quote from above. We’d love to hear from you.
