Oracle Sun T2000, RoHS:YL Server

Oracle Sun T2000, RoHS:YL Server Oracle Sun T2000, RoHS:YL Server Sun Servers SUN SPARC ENTERPRISE T2000

REQUEST A PRICE QUOTE:

    Name*

    Phone

    Details*



    Processor
    Number 1
    Architecture 1.0/1.2/1.4-GHz UltraSPARC T1 Chip Multithreaded (CMT)
    1.4 GHz is 8 core
    1.2 GHz is 8 core
    1.0 GHz are 4 or 8-core
    CoolThreads Server
    ECO-Responsible Server
    Cache memory 3 MB unified level 2 cache with ECC
    Main Memory
    Capacities DIMM slots per memory controller: 4
    DIMM type: DDR2 ECC registered DIMMs
    DIMM size: 512-MB, 1-GB, 2-GB, or 4-GB
    Maximum capacity: 64GB (when configured with 4-GB DIMMs)
    Note: DIMMS must be installed in sets of 8. Two basic memory configurations are supported: 8-DIMM or 16-DIMM. All DIMMs must have identical capacity. An 8 DIMM configuration fully populates Rank 0 slots.
    Standard Integrated Interfaces
    Network Four 10/100/1000 Base-T Ethernet autonegotiating ports
    Network Management One dedicated 10/100Base-T Ethernet port
    Remote Management SC Serial Management port and Net Management port
    USB Front:Two USB 1.1 ports
    Rear:Two USB 1.1 ports
    PCI Interfaces Three PCI-Express low-profile, 2.5GHz lanes card slots with up to X8 data lanes.
    Two PCI-X low-profile, 64-bit, 133 MHz card slots.
    Note: Earlier models of the Sun Fire T2000 (non RoHS) used one PCI-X slot (slot 0) for the SAS disk controller.
    Internal Storage
    Disks Up to four 73GB or 146GB HDD Disks (Hot Pluggable, SFF, SAS, 10K RPM).
    Removable Media 1 slimline DVD-R/CD-RW drive
    Power Supplies
    Two hot-swappable, redundant, high efficiency 450W power supplies. Note: Earlier models of the Sun Fire T2000 (non RoHS) used 550W power supplies.
    The Sun SPARC Enterprise T2000, RoHS:YL server has two hot-swappable, redundant, high efficiency 450W power supplies. These are the electrical limits and ranges for the Sun SPARC Enterprise T2000 server utilizing 450 W power supplies:
    Operating input voltage range 100 to 240 VAC, 50-60 Hz
    Maximum operating input current 4.5 A at 100 to 120 VAC
    2.25 A at 200 to 240 VAC
    Maximum operating input power 400 W
    Maximum heat dissipation 1,535 BTU/hr
    Nominal Power 275 W
    A power calculator exists for the Sun SPARC Enterprise T2000 server, enabling customers to calculate the power of the components in their systems, providing them with an estimated overall total for different configurations. See: http://www.sun.com/servers/coolthreads/t2000/calc/index.jsp
    Space, Watts and Performance (SWaP)
    Space (RU) 2
    Watts 300
    Performance (application tier benchmark) 5300
    Performance/watt 17.667
    SWaP 8.8
    Environment
    Temperature Operating (Sea Level to 3000 ft(900m)): 5° C to 35° C (41° F to 95° F)
    Non-operating: -40° C to 60° C (-40° F to 140° F)
    Operating (Above 3000 ft(900m)):Decrease maximum temperature as altitude increases, 1.6°F/1000 ft (1°C/300m)
    Non-operating: -40° C to 60° C (-40° F to 140° F)
    Humidity Operating: 20% to 80% relative humidity noncondensing, 27° C (80.6° F) web bulb, IEC 60068-2-3&56
    Non-operating: 98% relative humidity 38° C (100.4 ° F) noncondensing,IEC 60068-2-3&56
    Altitude Operating: up to 3000 m (10,000 ft.), IEC 60068-2-13
    Non-operating: up to 12,000 m (40,000 ft.), IEC 60068-2-13
    Acoustic noise – LPAm (bystander positions) Operating: 62 dB
    Idling: 62 dB
    Acoustic noise – LwAd (1 B = 10 dB) Operating: 7.7 B
    Idling: 7.7 B
    Vibration Operating: 0.2 Gs, Swept sine 5-500-5Hz, 1 octave/min, all axes, IEC 60068-2-13
    Non-operating: 1.0 Gs, Swept sine 5-500-5Hz, 1 octave/min, all axes, IEC 60068-2-13
    Shock Operating: 5.0 Gs peak 11 msec, half-sine pulse, IEC 60068-2-27
    Non-operating: 30.0 Gs peak 11 msec, half-sine pulse, IEC 60068-2-27
    Cooling 3 hot-swappable and redundant system fans.
    1 hot-swappable blower unit.
    Regulations
    Meets or exceeds the following requirements:
    RoHS Compliance Level RoHS:YL
    Safety UL/CSA-60950-1, EN60950-1, IEC60950-1 CB Scheme with all country deviations, IEC 825-1,2, CFR21 part 1040, CNS 14336, GB4943
    Ergonomics EK1-1TB-2000
    RFI/EMI EN55022 Class A, 47 CFR 15B Class A, ICES-003 Class A, VCCI Class A, AS/NC 3548 Class A, CNS 13438 Class A, KSC 5858 Class A, GB9254 Class A, EN61000-3-2, GB17625.1, EN61000-3-3
    Immunity EN55024, IEC 61000-2, IEC 61000-3, IEC 61000-4, IEC 61000-5, IEC 61000-6, IEC 61000-8, IEC 61000-11
    Telecommunications EN300-386
    Regulatory Markings (pending) CE, FCC, ICES-003, C-tick, VCCI, GOST-R, BSMI, MIC, UL/cUL, UL/DEMKO/GS, UL/S-mark, CCC
    Dimensions and Weight
    Height (2 rack units) 89 mm (3.5 in.)
    Width 440 mm (17.3 in.)
    Depth 617 mm (24.3 in.)
    Weight, approximate (without PCI cards and rack mounts) 17 kg (37 lb.)
    Batteries
    Option # Manufacturing
    Part #    		 Description
    n/a 150-1204 3V Lithium battery, RoHS:Y
    Cables
    Option # Manufacturing
    Part #    		 Description
    X311L Localized Power Cord Kit – North America/Asia, RoHS:Y
    180-1097 IEC 320 C13 to NEMA 5-15P – 15A/125V 2.5M Black, RoHS:Y
    X312E Localized Power Code Kit – China, RoHS:Y
    180-1982 IEC 320 C13 to GB 2099/GB 1002 – 10A/250V 2.5M, RoHS:Y
    X312F Localized Power Cord Kit – Argentina, RoHS:Y
    180-1999 IEC 320 C13 to IRAM 2073 – 10A/250V 2.5M Black, RoHS:Y
    X312G Localized Power Cord Kit – Korea, RoHS:Y
    180-1662 IEC 320 C13 to KSC 8305 – 15A/250V 2.5M Black, RoHS:Y
    X312L Localized Power Cord Kit – Continental Europe, RoHS:Y
    180-1993 IEC 320 C13 to CEE 7/7 10A/250V 2.5M Black, RoHS:Y
    X314L Localized Power Cord Kit – Swiss, RoHS:Y
    180-1994 IEC 320 C13 to SEV 1011 – 10A/250V 2.5M Black, RoHS:Y
    X317L Localized Power Cord Kit – U.K., RoHS:Y
    180-1997 IEC 320 C13 to BS 1363 – 10A/250V 2.5M Black, RoHS:Y
    X320A Localized Power Cord Kit – North America/Asia, RoHS:Y
    180-2164 IEC 320 C13 to NEMA 6-15P – 10A/250V 2.0M Black, RoHS:Y
    X332T International Power Cord Kit, RoHS:Y
    180-2071 Blue 16A IEC 309 to IEC 320 C13 International 4.0M, RoHS:Y
    X333A-25-10-IL Localized Power Cord Kit Israel, RoHS:Y
    180-2130 IEC 320 C13 to SI-32, 10A/250V, 2.5M, Black, RoHS:Y
    X333A-25-15-JP Localized Power Cord Kit Japan, RoHS:Y
    180-2243 IEC 320 C13 to PSE 5-15P, 15A/125V, 2.5M, Black, RoHS:Y
    X333F-25-15-JP Localized Power Cord Kit Japan, RoHS:Y
    180-2244 IEC 320 C13 to PSE 6-15P, 15A/250V, 2.5M, Black, RoHS:Y
    X340L Power Kit for North America, L6-20 20A Twist Lock Plug, RoHS:Y
    180-2070 NEMA L6-20P to IEC 320 C13 – 4.0M, RoHS:Y
    X383L Localized Power Cord Kit – Danish, RoHS:Y
    180-1995 IEC 320 C13 to Asfnit 107 – 10A/250V 2.5M Black, RoHS:Y
    X384L Localized Power Cord Kit – Italian, RoHS:Y
    180-1996 IEC 320 C13 to CEI 23-16/VII – 10A/250V 2.5M Black, RoHS:Y
    X386L Localized Power Cord Kit – Australian, RoHS:Y
    180-1998 IEC 320 C13 to AS 3112 – 10A/250V 2.5M Black, RoHS:Y
    X321L North America/Asia Power Cords 4-Pack, RoHS:Y
    180-2023 IEC 320 C13 to NEMA 6-15P – 10A/250V 4.0M Black, RoHS:Y
    n/a 530-3361 CPU/Memory to I/O Board Cable, RoHS:Y
    n/a 530-3365 DVD Cable, RoHS:Y
    Communication
    Option # Manufacturing
    Part #    		 Description
    X6000A 375-3424 PCI Express Sun Crypto Accelerator 6000, RoHS:Y
    X1235A 375-3260 PCI-X Dual Port 4x InfiniBand Host Channel Adapter – Low Profile
    X1236A-Z 375-3382 Dual Port 10Gb/sec 4x PCI Express Infiniband Host Channel Adapter – Low Profile, RoHS:Y
    X1333A-4 375-3418 Infiniband PCI-X Card, RoHS:YL
    Disk Backplane
    Option # Manufacturing
    Part #    		 Description
    n/a 501-7755 4-Slot Disk Backplane, RoHS:YL
    Disks
    Option # Manufacturing
    Part #    		 Description
    SEPX3A11Z 540-7307 73GB 10000 RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks, RoHS:Y
    • 390-0213
    • Seagate ST973401SS [ST973401SSUN72G]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0323
    • Seagate ST973402SS [ST973402SSUN72G]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0374
    • Fujitsu MBB2073RC [MBB2073RCSUN72G]
      (73.4GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-0239
    • Nemo Bracket, RoHS:Y
    SEPX3C11Z 540-7777 146GB 10000 RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks, RoHS:Y
    • 390-0324
    • Seagate ST9146802SS [ST914602SSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0375
    • Fujitsu MBB2147RC [MBB2147RCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0448
    • Seagate ST9146803SS [ST914603SSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-0239
    • Nemo Bracket, RoHS:Y
    • 541-3004
    • Nemo Bracket with Insulator, RoHS:Y
    XRA-SS2CD-146G10KZ 540-7151 146GB – 10000 RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks and brackets, RoHS:Y
    • 390-0324
    • Seagate ST9146802SS [ST914602SSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0375
    • Fujitsu MBB2147RC [MBB2147RCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0377
    • Hitachi HUC101414CSS300 [H101414SCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-0239
    • Nemo Bracket, RoHS:Y
    • 541-3004
    • Nemo Bracket with Insulator, RoHS:Y
    XRA-SS2CD-73G10KZ 540-6611 73GB 10000 RPM SAS, Disk Assembly with 1 of the following disks and brackets, RoHS:Y
    • 390-0213
    • Seagate ST973401SS [ST973401SSUN72G]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0285
    • Fujitsu MAY2073RC [MAY2073RCSUN72]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0323
    • Seagate ST973402SS [ST973402SSUN72G]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0374
    • Fujitsu MBB2073RC [MBB2073RCSUN72G]
      (73.4GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0376
    • Hitachi HUC101473CSS300 [H101473SCSUN72G]
      (73.4GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-0239
    • Nemo Bracket, RoHS:Y
    • 541-3004
    • Nemo Bracket with Insulator, RoHS:Y
    Ethernet
    Option # Manufacturing
    Part #    		 Description
    X1027A-Z 501-7283 PCI Express Dual 10-Gigabit Ethernet Fiber, RoHS:Y
    X4150A-2 501-7415 GigaSwift Ethernet UTP (GCS), RoHS:Y
    X4151A-2 501-7430 GigaSwift Ethernet MMF (GFS), RoHS:Y
    X4447A-Z 511-1422 PCI Express Quad Gigabit Ethernet UTP, RoHS:Y
    • 371-2207
    • Bracket Low-Profile, RoHS:Y
    560-2884 Ship Kit for Gigabit Ethernet options
    • 371-2348
    • Bracket Standard, RoHS:Y
    X5544A-4 10Gb PCI-X Ethernet Adapter, no transceiver, RoHS:Y
    501-7413 10Gb PCI-X Ethernet Adapter, RoHS:Y
    • 370-7665
    • Bracket Standard 10Gb PCI-X Ethernet, RoHS:Y
    • 370-7792
    • Bracket Low-Profile 10Gb PCI-X Ethernet, RoHS:Y
    X7280A-2 371-0905 PCI Express Dual Gigabit Ethernet UTP, RoHS:Y
    X7281A-2 371-0904 PCI Express Dual Gigabit Ethernet MMF, RoHS:Y
    X4150A 501-6719 GigaSwift Ethernet UTP (GCS)
    X4151A 501-6762 GigaSwift Ethernet MMF (GFS)
    X5544A 10Gb PCI-X Ethernet Adapter, no transceiver
    370-7792 Bracket Low-Profile 10Gb PCI-X Ethernet, RoHS:Y
    501-7036 10Gb/sec PCI-X Ethernet Adapter
    • 370-7665
    • Bracket Standard 10Gb PCI-X Ethernet, RoHS:Y
    n/a 501-7606 PCI Express Quad Gigabit Ethernet UTP, RoHS:Y
    • 371-2207
    • Bracket Low-Profile, RoHS:Y
    • 371-2348
    • Bracket Standard, RoHS:Y
    Fan
    Option # Manufacturing
    Part #    		 Description
    n/a 541-0275 CPU fan, RoHS:YL
    n/a 541-0645 Rear Fan Tray, RoHS:Y
    Fibre Channel
    Option # Manufacturing
    Part #    		 Description
    SG-XPCI1FC-EM4-Z 375-3398 4Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI1FC-QF4 375-3354 4Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI2FC-EM4-Z 375-3399 4Gb PCI-X Dual FC Host Adapter, RoHS:Y
    SG-XPCI2FC-QF4 375-3294 4Gb PCI-X Dual FC Host Adapter, RoHS:Y
    SG-XPCIE1FC-EM4 375-3396 4Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
    SG-XPCIE1FC-EM8-Z 371-4295 8Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
    SG-XPCIE1FC-QF4 375-3355 4Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
    SG-XPCIE1FC-QF8-Z 371-4324 8Gigabit/Sec PCI Express Single FC Host Adapter, RoHS:Y
    SG-XPCIE2FC-EM4 375-3397 4Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
    SG-XPCIE2FC-EM8-Z 371-4306 8Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
    SG-XPCIE2FC-QF4 375-3356 4Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
    SG-XPCIE2FC-QF8-Z 371-4325 8Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
    SG-XPCI1FC-EM2 375-3304 2Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI1FC-QL2 375-3383 2Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI2FC-EM2 375-3305 2Gb PCI-X Dual FC Host Adapter, RoHS:Y
    SG-XPCI2FC-QF2-Z 375-3363 2Gb PCI Dual FC Host Adapter, RoHS:Y
    • 240-4839
    • Low Profile Bracket, RoHS:Y
    Graphics
    Option # Manufacturing
    Part #    		 Description
    X3000A 375-3545 XVR-300 x8 Graphics Accelerator, RoHS:Y
    530-3474 DVI-A(M) to HD15F Adapter, 49mm, RoHS:Y
    530-3998 DMS-59 to Dual DVI-I Cable, 215mm, RoHS:Y
    X3777 375-3433 XVR-200 Graphics Accelerator, RoHS:Y
    I/O
    Option # Manufacturing
    Part #    		 Description
    n/a 501-6978 Front I/O Board w/Cover Interlock Switch, RoHS:YL
    Memory
    Option # Manufacturing
    Part #    		 Description
    SEKX2A1Z 1GB (2 x 512MB DDR2) Memory Expansion Kit, RoHS:Y
    370-6207 512MB DDR2 DIMM, 533 MHz, RoHS:Y
    SEKX2B1Z 2GB (2 x 1Gb DDR2) Memory Expansion Kit, RoHS:Y
    370-6208 1GB DDR2 DIMM, 533 MHz, RoHS:Y
    SEKX2C1Z 4GB (2 x 2GB DDR2) Memory Expansion Kit, RoHS:Y
    370-6209 2GB DDR2 DIMM, 533 MHz, RoHS:Y
    SEKX2D1Z 8GB (2 x 4GB DDR2) Memory Expansion Kit, RoHS:Y
    370-6210 4GB DDR2 DIMM, RoHS:Y
    X7800A 1GB (2 × 512MB DDR2) Memory Expansion Kit, RoHS:Y
    370-6207 512MB DDR2 DIMM, 533 MHz, RoHS:Y
    X7801A 2GB (2 × 1GB DDR2) Memory Expansion Kit, RoHS:Y
    370-6208 1GB DDR2 DIMM, 533 MHz, RoHS:Y
    X7802A 4GB (2 × 2GB DDR2) Memory Expansion Kit, RoHS:Y
    370-6209 2GB DDR2 DIMM, 533 MHz, RoHS:Y
    X7803A 8GB (2 × 4GB DDR2) Memory Expansion Kit
    370-6210 4GB DDR2 DIMM, RoHS:Y
    Miscellaneous
    Option # Manufacturing
    Part #    		 Description
    n/a 501-6916 LED/Switch Board (A65/A87), RoHS:Y
    Power
    Option # Manufacturing
    Part #    		 Description
    n/a 501-7021 Power Distribution Board, RoHS:YL
    n/a F300-1735 450 Watt Power Supply, RoHS:Y
    • 300-1735
    • 450 Watt Power Supply, Power One, RoHS:YL
    • 300-1817
    • 450 Watt Power Supply, Tyco, RoHS:YL
    • 300-2110
    • 450 Watt Power Supply, Astec, RoHS:YL
    Rack
    Option # Manufacturing
    Part #    		 Description
    n/a 370-7668 Cable Management Arm, RoHS:Y
    n/a 370-7669 Slide Rail Kit, RoHS:Y
    Removable Media
    Option # Manufacturing
    Part #    		 Description
    n/a 390-0251 Slimline 8X DVD-ROM / 24X CD-Writer,RoHS:Y
    n/a 541-1474 DVD Cable Assembly, RoHS:YL
    • 530-3365
    • DVD Cable, RoHS:Y
    • 375-3104
    • Paddleboard, RoHS:YL
    SCSI
    Option # Manufacturing
    Part #    		 Description
    SG-XPCI8SAS-E-Z 375-3488 3Gb PCI-X SAS 8-Port Host Adapter, RoHS:Y
    SG-XPCIE2SCSIU320Z 375-3357 Dual-Channel Ultra320 LVD SCSI PCI Express Adapter, RoHS:Y
    SGXPCI1SCSILM320-Z 375-3366 PCI Single Ultra320 SCSI Adapter
    SGXPCIESAS-R-EXT-Z 371-3253 Lithium Ion Battery Module
    375-3537 8-Port SAS RAID External HBA, RoHS:Y
    SG-XPCI1SCSI-LM320 375-3255 PCI/PCI-X Single Ultra320 SCSI Adapter
    System Board
    Option # Manufacturing
    Part #    		 Description
    n/a 541-2142 0MB 8-Core 1.0GHz System Board, RoHS:YL
    • 541-2448
    • System Board Assembly w/o UltraSPARC T1, RoHS:YL
    • 501-7501
    • CPU/Memory Board, RoHS:YL
    • 501-7823
    • I/O Board, RoHS:YL
    • 530-3361
    • CPU/Memory to I/O Board Cable, RoHS:Y
    n/a 541-2192 0MB 8-Core 1.2GHz System Board, RoHS:YL
    • 541-2448
    • System Board Assembly w/o UltraSPARC T1, RoHS:YL
    • 501-7501
    • CPU/Memory Board, RoHS:YL
    • 501-7823
    • I/O Board, RoHS:YL
    • 530-3361
    • CPU/Memory to I/O Board Cable, RoHS:Y
    n/a 541-2226 0MB 4-Core 1.0GHz System Board, RoHS:YL
    • 541-2448
    • System Board Assembly w/o UltraSPARC T1, RoHS:YL
    • 501-7501
    • CPU/Memory Board, RoHS:YL
    • 501-7823
    • I/O Board, RoHS:YL
    • 530-3361
    • CPU/Memory to I/O Board Cable, RoHS:Y
    n/a 541-2449 0MB 8-Core 1.4GHz System Board, RoHS:YL
    • 541-2448
    • System Board Assembly w/o UltraSPARC T1, RoHS:YL
    • 501-7501
    • CPU/Memory Board, RoHS:YL
    • 501-7823
    • I/O Board, RoHS:YL
    • 530-3361
    • CPU/Memory to I/O Board Cable, RoHS:Y
    System Service Processor
    Option # Manufacturing
    Part #    		 Description
    n/a 501-7849 Service Processor, RoHS:YL
    • 150-1204
    • 3V Lithium battery, RoHS:Y

    Industry Leading Quality, Support and Integrity

    Quality Inspection Checklist
    Before it leaves our facility, every used and refurbished item is thoroughly inspected by our certified technicians and undergoes our exclusive Quality Inspection Checklist to ensure 100% satisfaction guarantee.

    Greentec Systems is a leading provider
    For server, networking and storage equipment. We have an extensive array of inventory of IBM Servers & Storage, Sun Servers & Storage, Cisco Networking (Switches, Routers, Security), and NetApp Storage (disk shelves, disk drives, Filers, NearStore, NetCache). If you don’t see the item or product you require please contact us.

    Have this equipment to sell?
    Depending on the age and condition of the equipment, there is a very good likelihood that we will be able to offer you cash or trade-in credit for other IT hardware. If the equipment is very old we can also assist you with properly decommissioning that gear in the most environmentally friendly way possible.

    Questions?
    For more information please contact 888.333.7388, or fill out the quote from above. We’d love to hear from you.

    Request Quote
    Greentec Systems We geek out helping you with your IT infrastructure.
    Request a quote or product information
    Send
