Oracle Sun Storage 7120

Oracle Sun Storage 7120 Oracle Sun Storage 7120 7120

REQUEST A PRICE QUOTE:

    Name*

    Phone

    Details*

    Processor
    Number 1 to 2 Intel Quad-Core
    Architecture Type: Intel Xeon Quad-Core Processor
    CPUs Intel Xeon 2.40 GHz Quad-Core E5620 (12MB L3, 80W)
    Main Memory
    Capacities Total DIMM slots: 18
    DIMM type: DDR3 1333MHz Registered DIMMs
    DIMM size: 4-GB 1333MHz
    Maximum capacity: 72GB (when fully populated with 4-GB DIMMs)
    Standard Integrated Interfaces
    Network Four 10/100/1000 Base-T Ethernet Ports
    Network Management One dedicated 10/100Base-T Ethernet port
    Serial Management One dedicated TIA/EIA-232-F asynchronous RJ45 port
    USB Front: Two USB 2.0 ports
    Rear: Two USB 2.0 ports
    Internal: One USB 2.0 port
    PCI Expansion Slots Four internal MD2 low profile 8-lane PCI Express slots (all with x8 mechanical connectors)
    Internal Mass Storage
    Disks SAS: Configurations of Up to 12 internal 3.5″ SAS HDDs with add-on SAS Host Bus Adapter
    SATA:Up to 2 internal 2.5″ SATA HDDs using the rear 2-Slot HDD assembly
    Drive Type Density Speed Form Factor
    SAS 1 TB 7,200 RPM 3.5″
    SAS 2 TB 7,200 RPM 3.5″
    SATA 500 GB 7,200 RPM 2.5″
    Power Supplies
    Dual redundant, hot swappable power supplies
    (Power supply rating output = 1200W)
    (UL Maximum AC input = 1200W x 1.33 efficiency = 1596W)
    (13.0 Amps Max current AC RMS)
    Environment
    AC power 100-120/200-240 V AC, (50-60 Hz)
    Temperature Single, non-rack system:
    Operating: 5° C to 35° C (41° F to 95° F)
    Nonoperating: -40° C to 70° C (-40° F to 158° F)
    Humidity Single, non-rack system:
    Operating: 10% to 90% relative humidity noncondensing, 38° C (100.4° F) max wet bulb
    Nonoperating: up to 93% relative humidity noncondensing
    Altitude Single, non-rack system:
    Operating: Up to 3048 m (10000 ft.), maximum ambient temperature is derated by 1° C per 300 m above 900 m
    Nonoperating: Up to 12,000 m (40,000 ft.)
    Regulations
    Meets or exceeds the following requirements:
    RoHS Compliance Level RoHS:YL
    Safety UL/cUL, CE, BSMI, GOST-R, S-Mark, CSA C22.2 No. 60950-03
    RFI/EMI FCC CFR 47 Part 15 Class A, EN55022 Class A, EN 61000-3-2, EN61000-3-3, EN 300-386
    Immunity EN55024, EN300-386
    Certifications Safety: UL/cUL, UL DEMKO, CE, BSMI, CCC, GOST-R, S-Mark
    EMC: CE, FCC, VCCI, ICES, C-Tick, MIC, CCC, GOST-R, BSMI Class A
    Other Complies with WEEE Directive (2002/96/EC) and RoHS Directive (2002/95/EC)
    Dimensions and Weight
    Height 87.12 mm (3.43 in.)
    Width 425.45 mm (16.75 in.)
    Depth 762.0 mm (30 in.)
    Weight 29.54 kg (65 lb.)
    Array Controller
    Option # Manufacturing
    Part #    		 Description
    n/a 542-0194 6Gbps SAS-2 Interface Module (SIM), RoHS:Y
    CPU Module
    Option # Manufacturing
    Part #    		 Description
    n/a 371-4885 2.4GHz Intel Quad-Core Xeon E5620, 12MB, 80W, RoHS:Y
    n/a 541-3310 Xeon Heatsink w/Grease, RoHS:Y
    • 240-6751
    • Heatsink Spring, RoHS:Y
    • 310-0211
    • Pre-greased Heatsink
    Cables
    Option # Manufacturing
    Part #    		 Description
    n/a 530-3883 4X Mini SAS Cable, SFF-8088 to SFF-8088, 2M, RoHS:Y
    n/a 560-2952 X4270 M2 Cable Kit, RoHS:Y
    • 530-4245
    • 10-Pin Backplane Power Cable, RoHS:Y
    • 530-4458
    • 24-Slot Backplane Power Cable, RoHS:Y
    • 530-4459
    • 12/24-Slot Backplane Signal Cable, RoHS:Y
    • 530-4471
    • Fan Signal Cable, RoHS:Y
    • 530-4488
    • Fan Power Cable, RoHS:Y
    Communication
    Option # Manufacturing
    Part #    		 Description
    n/a 375-3606 Sun Dual Port 40Gb/sec 4x Infiniband QDR Host Channel Adapter PCI Express, RoHS:Y
    Disk Backplane
    Option # Manufacturing
    Part #    		 Description
    n/a 541-4235 Rear Disk Module Assembly, RoHS:Y
    • 501-7843
    • 2-Slot Disk Backplane, RoHS:Y
    • 530-3888
    • Hard Disk Drive Power Cable, RoHS:Y
    • 530-4406
    • Dual Disk Drive Data Cable, RoHS:Y
    • 541-4186
    • Rear Disk Bracket Assembly, RoHS:Y
    n/a 541-4363 12-Slot 3.5″ Disk Backplane Assembly, RoHS:
    • 341-5083
    • Mounting Bracket, RoHS:Y
    • 511-1593
    • 12-Slot 3.5″ Disk Backplane, RoHS:Y
    Disks
    Option # Manufacturing
    Part #    		 Description
    n/a 350-1574 Disk Shelf SSD Filler Panel
    n/a 540-7824 1.0TB – 7200 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
    • 390-0438
    • Seagate ST31000640SS [ST31000SSSUN1.0T] (1TB – 7200 RPM – SAS Disk), RoHS:Y
    • 350-1386
    • 3.5″ Disk Drive Bracket, RoHS:Y
    n/a 541-4242 Disk Shelf HDD Filler Panel, RoHS:Y
    n/a 542-0247 2TB – 7200 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
    • 390-0476
    • Seagate ST32000444SS [ST32000SSSUN2.0T] (2TB – 7200 RPM – SAS Disk)
    • 350-1386
    • 3.5″ Disk Drive Bracket, RoHS:Y
    n/a 542-0274 2TB – 7200 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks:
    • 390-0476
    • Seagate ST32000444SS [ST32000SSSUN2.0T] (2TB – 7200 RPM – SAS Disk)
    • 350-1508
    • Stingray Mounting Bracket
    n/a 542-0340 1TB – 7200 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks:
    • 390-0475
    • Seagate ST31000424SS [ST31001SSSUN1.0T] (1TB – 7200 RPM – SAS Disk), RoHS:Y
    • 350-1508
    • Stingray Mounting Bracket
    n/a 542-0371 500GB – 7200 RPM SATA Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
    • 390-0468
    • Seagate ST9500530NS [ST95000NSSUN500G]
      (500GB – 7200 RPM – SATA Disk), RoHS:Y
    • 541-2123
    • Marlin Bracket 2.5″, RoHS:Y
    Ethernet
    Option # Manufacturing
    Part #    		 Description
    n/a 375-3481 PCI Express Quad Gigabit Ethernet UTP, RoHS:Y
    n/a 375-3617 Dual 10-Gigabit Ethernet SFP+ LP, RoHS:Y
    n/a 530-4449 10Gbps Short Wave Pluggable (SFP+) Transceiver, RoHS:Y
    Fan
    Option # Manufacturing
    Part #    		 Description
    n/a 541-4124 Fan Board Assembly, RoHS:Y
    • 330-5243
    • Fan Board Cover, RoHS:Y
    • 511-1434
    • Fan Board, RoHS:Y
    n/a 541-4222 Fan Assembly, RoHS:Y
    • 371-4613
    • 60×28mm 10400/9500 RPM Dual Fan, RoHS:Y
    Fibre Channel
    Option # Manufacturing
    Part #    		 Description
    n/a 371-4325 8Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y
    I/O
    Option # Manufacturing
    Part #    		 Description
    n/a 541-2884 x8/x8 PCI Express Riser Assembly, RoHS:Y
    • 501-7964
    • x8/x8 PCI Express Riser, RoHS:Y
    • 541-2531
    • Bracket, RoHS:Y
    n/a 541-3356 x8/x8 Switched PCI Express Riser Assembly, RoHS:Y
    • 511-1139
    • x8/x8 Switched PCI Express Riser, RoHS:Y
    • 541-2531
    • Bracket, RoHS:Y
    Memory
    Option # Manufacturing
    Part #    		 Description
    n/a 371-4743 4GB USB 2.0 Flash Drive, RoHS:Y
    n/a 371-4965 4GB Registered DDR3-1333 DIMM, 1.35V, RoHS:Y
    Power
    Option # Manufacturing
    Part #    		 Description
    n/a 300-2235 1200W Power Supply, Type A249, RoHS:Y
    n/a 300-2276 764W AC Input Power Supply and Fan Assembly, RoHS:Y
    n/a 371-4650 Energy Storage Module (ESM), RoHS:Y
    n/a 541-4223 Power Distribution Assembly, RoHS:Y
    • 341-3166
    • Bus Bar Left, RoHS:Y
    • 341-3167
    • Bus Bar Right, RoHS:Y
    • 511-1437
    • Horizontal Power Distribution Board, RoHS:Y
    • 511-1513
    • Vertical Power Distribution Board, RoHS:Y
    • 371-2484
    • PDB Signal Cable, RoHS:Y
    Rack
    Option # Manufacturing
    Part #    		 Description
    DS2X-4URK-19U 350-1531 Rackmount Kit, RoHS:Y
    • n/a
    • Left Mounting Rail
    • n/a
    • Right Mounting Rail
    n/a 350-1265 Snap-In Slide Rail Rackmount Kit
    n/a 350-1287 Cable Management Arm, RoHS:Y
    n/a 350-1502 Bolt-In Slide Rail Kit, RoHS:Y
    SCSI
    Option # Manufacturing
    Part #    		 Description
    n/a 375-3609 8-Port 6Gbps SAS-2 RAID HBA, RoHS:Y
    n/a 375-3665 8-Port 6Gbps SAS-2 RAID HBA, RoHS:Y
    n/a 541-3731 96GB PCI Express Flash Accelerator F20 SAS HBA, RoHS:Y
    • 371-4415
    • 24GB Solid State Flash Memory Module, RoHS:Y
    • 371-4650
    • Energy Storage Module (ESM), RoHS:Y
    • 511-1500
    • PCI Express Flash Board, RoHS:Y
    System Board
    Option # Manufacturing
    Part #    		 Description
    n/a 541-4081 System Board Assembly/FRU, RoHS:Y
    • 511-1213
    • System Board, RoHS:Y
    • 150-3993
    • Panasonic BR2032 Battery, RoHS:Y
    • 541-2543
    • System Board Tray, RoHS:Y
