Used Oracle Sun Storage 5320 NAS Server

Oracle Sun Storage 5320 NAS

REQUEST A PRICE QUOTE:


Disks
Unit	Disk Configuration
Sun StorageTek 5320 NAS Appliance (Internal)	No disks installed within this unit.
Sun StorageTek 5320 RAID Expansion Unit (External)	Up to fourteen disk drives as follows: 146GB FC 300GB FC 400GB SATA
Sun StorageTek 5320 Expansion Unit (External)	Up to fourteen disk drives as follows: 146GB FC 300GB FC 400GB SATA
Capacity

Unit	Total Storage Capacity Per Unit
Sun StorageTek 5320 NAS Appliance (Internal)	No disks installed within this unit.
Sun StorageTek 5320 RAID Expansion Unit (External)	2.044TB (14 × 146GB) 4.200TB (14 × 300GB) 5.600TB (14 × 400GB)
Sun StorageTek 5320 Expansion Unit (External)	2.044TB (14 × 146GB) 4.200TB (14 × 300GB) 5.600TB (14 × 400GB)
Mass Storage	Maximum StorageTek 5320 RAID Expansion Units per Server: 2 Maximum StorageTek 5320 Expansion Units: 28
Note 1: Maximum capacity depends on the number of external arrays you attach to the 5320 NAS Appliance. Note 2: A Sun StorageTek 5320 NAS Appliance, with a Sun StorageTek 5320 RAID Expansion Unit, and a Sun StorageTek 5320 Expansion Unit can provide up to: 4.088TB of storage using the 146GB disks (28 disk drives × 146GB) 8.400TB of storage using the 300GB disks (28 disk drives × 300GB) 11.200TB of storage using the 400GB disks (28 disk drives × 400GB)
Processor
Number	1
Architecture	2.6GHz CPU, AMD Opteron 252 E4 Stepping
Cache memory	1-MB Level 2 cache
Memory
Characteristics include: Four (4) DIMM slots Registered DDR1/400 RAM Memory System supports 4 × 1 GB DIMMs
Standard Interfaces
Network	Four 10/100/1000Base-T Ethernet ports
SAS	Four channel SAS interface, internal access only
USB	The following ports are provided: Front: Two USB 1.1 port Rear: Two USB 1.1 ports (bottom for UPS connection; top for factory use only)
Expansion Bus	Five internal MD2 Low Profile 64-bit PCI-X slots as follows: One at 64-bit/100MHz (slot 0) One at 64-bit/133MHz (slot 1) Three at 64-bit/66MHz (slots 2-4)
Power Supplies
Sun StorageTek 5320 NAS Appliance (server)	Equipped with two 550W power supplies Note: Second power supply is for redundancy.
Sun StorageTek 5320 RAID Expansion Unit	Equipped with two 400W power supplies Note: Second power supply is for redundancy.
Sun StorageTek 5320 Expansion Unit	Equipped with two 400W power supplies Note: Second power supply is for redundancy.
Environment
Heat Output	StorageTek 5320 NAS Appliance: n/a StorageTek 5320 NAS RAID Expansion Unit: 1332 BTU/hr StorageTek 5320 NAS Expansion Unit: 1332 BTU/hr
*StorageTek 5320 NAS Appliance*
AC Power	100-240 V, 50/60Hz, 550W
Operating Temperature/Humidity (single, non-rack system)	10° C to 35° C (41° F to 95° F), 10% to 90% relative humidity, noncondensing, 27° C max wet bulb
Nonoperating Temperature/Humidity (single, non-rack system)	-40° C to 65° C (-40° F to 149° F), up to 93% relative humidity, noncondensing, 38° C max wet bulb
Operating Altitude (single, nonrack system)	Up to 3048m (10,000 feet), maximum ambient temperature is derated by 1 degree C per 300m (984.3 feet) above 900m (2952.8 feet)
Nonoperating Altitude (single, nonrack system)	Up to 12000m (39370.1 feet)
*StorageTek 5320 NAS Expansion Unit (RAID & I/O unit)*
AC Power	100-240 V, 50/60Hz, 400W
Operating Temperature/Humidity	5° to 40° C (41° to 104° F), 10% to 90% noncondensing
Nonoperating Temperature/Humidity	-10° to 50° C (-14° to 120° F), 10% – 90%, Max Dew Point is 26° C (79? F), 10% per hour Gradient
Operating Altitude	30.5m (100 feet) below sea level to 3,000 meters (9,840 feet)
Nonoperating Altitude	30.5m (100 feet) below sea level to 12,000 meters (40,000 feet)
Dimensions and Weights
Height	StorageTek 5320 NAS Appliance: 87.6 mm (3.45 in) StorageTek 5320 RAID Expansion Unit: 132 mm (5.21 in) StorageTek 5320 Expansion Unit: 132 mm (5.21 in)
Width	StorageTek 5320 NAS Appliance: 445 mm (17.52 in) StorageTek 5320 RAID Expansion Unit: 447 mm (17.6 in) StorageTek 5320 Expansion Unit: 447 mm (17.6 in)
Depth	StorageTek 5320 NAS Appliance: 640 mm (25.2 in) StorageTek 5320 RAID Expansion Unit: 561 mm (22.1 in) StorageTek 5320 Expansion Unit: 561 mm (22.1 in)
Weight	StorageTek 5320 NAS Appliance: 23.7 kg (52.1 lb) StorageTek 5320 RAID Expansion Unit: 43 kg (95 lb) with 14 disks StorageTek 5320 Expansion Unit: 41 kg (91 lb) with 14 disks
Power Cord	Power cord appropriate for installation requirements to be ordered as an x-option

Array Controller
Option #	Manufacturing Part #	Description
n/a	370-6931	Battery
n/a	375-3218	StorEdge CSM100, FC-AL Expansion I/O Module
n/a	375-3219	StorEdge CSM100, SATA Expansion I/O Module
n/a	375-3233	RAID Controller

Backplane/Centerplane
Option #	Manufacturing Part #	Description
n/a	370-7296	Chassis with Midplane Assembly

CPU Module
Option #	Manufacturing Part #	Description
n/a	596-5209	2.6GHz CPU, AMD Opteron 252 E4 Stepping, RoHS:Y
	310-0014	CPU Heatsink Assembly, RoHS:Y
	370-7937	2.6GHz CPU, AMD Opteron 252, E4 Stepping, RoHS:Y

Cables
Option #	Manufacturing Part #	Description
X311L	Localized Power Cord Kit – North America/Asia, RoHS:Y
X311L	180-1097	IEC 320 C13 to NEMA 5-15P – 15A/125V 2.5M Black, RoHS:Y
X320A	Localized Power Cord Kit – North America/Asia, RoHS:Y
X320A	180-2164	IEC 320 C13 to NEMA 6-15P – 10A/250V 2.0M Black, RoHS:Y
X9732A	537-1041	Fibre Channel Optical Cable LC/LC, 2M, 2.0M
X9734A	537-1043	Fibre Channel Optical Cable LC/LC, 15M
X9736A	537-1051	Fibre Channel Optical Cable LC/LC, 25M
X9738A	537-1052	Fibre Channel Optical Cable LC/LC, 50M
n/a	370-7292	2Gbps Short Wave SFP
n/a	530-1351	IEC 320 C13 to NEMA 6-15 – 10A/250V 2.0M Black, RoHS:Y
n/a	530-3327	Expansion Tray I/O Cable, 2M
n/a	530-3522	UPS Adapter Cable, USB to DB9, RoHS:Y
n/a	537-1020	Fibre Optical Cable SC/SC, 5M
n/a	537-1036	Fibre Channel Optical Cable LC/SC, 0.4M
n/a	537-1081	Fibre Channel Optical Cable LC/LC, 2M, 2.0M, RoHS:Y

Disks
Option #	Manufacturing Part #	Description
n/a	540-6242	146GB – 10000 RPM FC-AL, Disk Assembly with one of the following disks:
	390-0118	Seagate ST3146807FC [ST314680FSUN146G] (146GB – 10000 RPM – FC-AL Disk)
	390-0171	Seagate ST3146707FC [ST314670FSUN146G] (146GB – 10000 RPM – FC-AL Disk)
	390-0172	Fujitsu MAT3147FC [MAT3147F SUN146G] (146GB – 10000 RPM – FC-AL Disk)
	390-0173	Hitachi HUS1014FA [HUS1014FASUN146G] (146GB – 10000 RPM – FC-AL Disk)
	390-0257	Fujitsu MAW3147FC [MAW3147FCSUN146G] (146GB – 10000 RPM – FC-AL Disk), RoHS:Y
	390-0270	Hitachi HUS1014FA [HUS1014FASUN146G] (146GB – 10000 RPM – FC-AL Disk), RoHS:Y
	390-0280	Seagate ST3146707FC [ST314670FSUN146G] (146GB – 10000 RPM – FC-AL Disk), RoHS:Y
n/a	540-6243	300GB – 10000 RPM FC-AL, Disk Assembly with one of the following disks:
	390-0181	Seagate ST3300007FC [ST330000FSUN300G] (300GB – 10000 RPM – FC-AL Disk)
	390-0182	Fujitsu MAT3300FC [MAT3300F SUN300G] (300GB – 10000 RPM – FC-AL Disk)
	390-0258	Fujitsu MAW3300FC [MAW3300FCSUN300G] (300GB – 10000 RPM – FC-AL Disk), RoHS:Y
	390-0281	Seagate ST3300007FC [ST330000FSUN300G] (300GB – 10000 RPM – FC-AL Disk), RoHS:Y
n/a	540-6244	400GB – 7200 RPM SATA, Disk Assembly with one of the following disks:
n/a	390-0214	Hitachi HDS724040KLSA80 [HDS7240SBSUN400G] (400GB – 7200 RPM – SATA Disk)
n/a	540-6550	146GB – 15000 RPM FC-AL, Disk Assembly with one of the following disks:, RoHS:Y
	390-0299	Seagate ST3146954FC [ST314695FSUN146G] (146GB – 15000 RPM – FC-AL Disk), RoHS:Y
	390-0313	Fujitsu MAX3147FD [MAX3147FDSUN146G] (146GB – 15000 RPM – FC-AL Disk), RoHS:Y
	390-0328	Seagate ST3146855FC [ST314655FSUN146G] (146GB – 15000 RPM – FC-AL Disk), RoHS:Y
	390-0419	Seagate ST3146356FC [ST314656FSUN146G] (146GB – 15000 RPM – FC-AL Disk), RoHS:Y
	541-0882	Drive Mounting Bracket (HDD Carrier), RoHS:Y
n/a	540-7156	300GB – 15000 RPM FC-AL Disk Assembly with one of the following disks:, RoHS:Y
	390-0330	Seagate ST3300655FC [ST330055FSUN300G] (300GB – 15000 RPM – FC-AL Disk), RoHS:Y
	390-0420	Seagate ST3300656FC [ST330056FSUN300G] (300GB – 15000 RPM – FC-AL Disk), RoHS:Y
	390-0462	Seagate ST3300657FC [ST330057FSUN300G] (300GB – 15000 RPM – FC-AL Disk), RoHS:Y
	390-0482	Hitachi HUS156030VLF400 [HUS1530FCSUN300G] (300GB – 15000 RPM – FC-AL Disk), RoHS:Y
	541-0882	Drive Mounting Bracket (HDD Carrier), RoHS:Y
n/a	540-7245	750GB – 7200 RPM SATA Disk Assembly with one of the following disks, RoHS:Y
	390-0356	Seagate ST3750640NS [ST37500NSSUN750G] (750GB – 7200 RPM – SATA Disk), RoHS:Y
	390-0379	Hitachi HUA721075KLA330 [HUA7275SASUN750G] (750GB – 7200 RPM – SATA Disk), RoHS:Y
	541-1406	Drive Mounting Bracket (SATA HDD Carrier), RoHS:Y

Ethernet
Option #	Manufacturing Part #	Description
XTA5000-NC2-1G-Z	371-2289	PCI-X Dual Gigabit Ethernet, RoHS:YL
XTA5000-NF2-1G-Z	594-3422	Dual-port Gigabit MMF NIC, RoHS:Y
	375-3250	Intel PRO/1000MF Dual Gigabit Ethernet
	537-1081	Fibre Channel Optical Cable LC/LC, 2M, 2.0M, RoHS:Y
n/a	370-6687	PCI-X Dual Gigabit Ethernet, RoHS:YL

Fan
Option #	Manufacturing Part #	Description
n/a	370-6932	Array Fan Tray
n/a	501-6917	Server Fan Board (A65/A87), RoHS:Y
n/a	541-0269	Fan Module (Single Fan), RoHS:Y
n/a	541-0645	Rear Fan Tray, RoHS:Y

Fibre Channel
Option #	Manufacturing Part #	Description
XTA5000-HF2-2G-Z	375-3421	2Gb/sec 2-port FC HBA, RoHS:Y

Memory
Option #	Manufacturing Part #	Description
n/a	375-3422	256MB Compact Flash (Unprogrammed)
n/a	540-6854	Programmed Compact Flash (256MB) Card, RoHS:Y
n/a	371-1968	256MB Compact Flash (Unprogrammed), RoHS:Y
n/a	541-1111	Compact Flash Module, RoHS:Y

Miscellaneous
Option #	Manufacturing Part #	Description
n/a	380-1382	LCD Module Assembly, RoHS:Y

Power
Option #	Manufacturing Part #	Description
n/a	300-1708	400 Watt Power Supply
n/a	300-1757	550 Watt Power Supply
n/a	501-6920	Power Distribution Board, RoHS:YL

Rack
Option #	Manufacturing Part #	Description
XTACSM1-RK-3RU-19U	540-6273	Sun StorEdge CSM100 3U Rail Kit
	341-0443	Rail, Left Front, CSM DEL-NGR
	341-0444	Rail, Left Rear, CSM DEL-NGR
	341-0445	Rail, Right Front, CSM DEL-NGR
	341-0446	Rail, Right Rear, CSM DEL-NGR
n/a	370-7668	Cable Management Arm, RoHS:Y
n/a	370-7669	Slide Rail Kit, RoHS:Y
