Oracle Sun Storage 5210
REQUEST A PRICE QUOTE:
|
Disks
|
||
| Sun StorEdge 5210 NAS Appliance (Internal) | Up to six disks using one of the following:
|
|
| Sun StorEdge 5210 NAS Expansion Unit (External) | Up to twelve disks using one of the following:
|
|
|
Capacity
|
||
| Sun StorEdge 5210 NAS Appliance (Internal) | 876GB (6 × 146 = 876) | |
| Sun StorEdge 5210 NAS Expansion Unit (External) | 1.752TB (12 × 146 = 1.752) | |
| Mass Storage |
Maximum StorEdge 5210 NAS Appliance: 1 Maximum StorEdge 5210 NAS Expansion Units (EUs): 3 Maximum storage: 6.132TB (see notes 1 & 2) |
|
| Note 1: Maximum capacity depends on the number of external arrays you attach to the 5210 NAS Appliance. Note 2: A Sun StorEdge 5210 NAS Appliance (populated with 6 disks) and three Sun StorEdge 5210 Expansion Units (each EU populated with 12 disks, for a total of 36 disks) provides 6.132TB of storage (42 disks × 146 = 6.132TB). |
||
| Processor | ||
| Number | 1 | |
| Architecture | 3.06 GHz Intel Xeon processor | |
| Cache memory | 512-KB Level 2 cache | |
|
Memory
|
||
| Registered DDR-266 ECC SDRAM, system supports 4 × 1 GB DIMMs | ||
| Standard Interfaces | ||
| Network | Two 10/100/1000BaseT Ethernet ports Single-port optical (MMF) 10/100/1000 NIC (optional) |
|
| Serial | One RJ-45 serial port | |
| SCSI | One Ultra 320 SCSI multimode (SE/LVD) | |
| USB | Two USB 1.1 ports | |
| Expansion Bus | Two internal PCI-X 64-bit/100 MHz | |
| Power Supplies | ||
| Equipped with two 500W power supplies. Second is for redundancy. | ||
|
Environment
|
||
| AC Power | 100-240 V, 50/60Hz, 500W | |
| DC Output | 500W | |
| Heat Output |
StorEdge 5210 NAS:1448 BTU/hr StorEdge 5210 Expansion Unit: 1360 BTU/hr |
|
| Operating Temperature |
Operating: 10° C to 35° C (50° F to 95° F) (stand-alone server)1 10° C to 30° C (50° F to 86° F) (rack mounted at sea level)2 Nonoperating: -40° C to 65° C (-40° F to 149° F) |
|
| Humidity |
Operating: 10% to 90%, 27° C max wet bulb (noncondensing) Nonoperating: Up to 93% (noncondensing) |
|
| Altitude |
Operating: 10° C to 30° C (50° F to 86° F) (stand-alone server) 10° C to 25° C (50° F to 77° F) (rack mounted at sea level) Nonoperating: Up to 12000m |
|
|
1 – Subtract 1° C from the maximum temperature for every 500-meter increase in altitude. (Tested to 3000m at 24° C (75.2° F) 2 – Subtract 1° C from the maximum temperature for every 500-meter increase in altitude. (Tested to 3000m at 19° C (66.2° F) |
||
|
Dimensions and Weights
|
||
| Height |
StorEdge 5210 NAS: 8.7 cm (3.5 in) StorEdge 5210 Expansion Unit: 8.8 cm (3.5 in) |
|
| Width |
StorEdge 5210 NAS: 43.0 cm (16.93 in) StorEdge 5210 Expansion Unit: 44.7 cm (17.6 in) |
|
| Depth |
StorEdge 5210 NAS: 64.8 cm (25.51 in) StorEdge 5210 Expansion Unit: 53.3 cm (21.0 in) |
|
| Weight |
StorEdge 5210 NAS: 28.12 kg (62 lb) with 6 disks StorEdge 5210 Expansion Unit: 24.15 kg (53.25 lb) with 12 disks |
|
| Power Cord | SJT or SVT 18 SWG min, 3 conductor, w/250V, 10A plug/socket | |
| Socket | IEC 320, 250V, 10A | |
| Array Controller | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| n/a | 370-5396 | Ultra-160 JBOD I/O Module, 2U Expansion Unit | ||
| n/a | 370-7072 | Event Monitoring Unit (EMU) | ||
| Backplane/Centerplane | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| n/a | 370-5393 | JBOD, LVD Chassis & Midplane | ||
| CPU Module | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| n/a | 370-6045 | 3.06GHz Xeon CPU Assembly | ||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
| Cables | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| X1136A | 530-2982 | Ultra-3 SCSI cable, VHDCI/VHDCI, 0.8M | ||
| X3830B | 530-2984 | Ultra-3 SCSI cable, VHDCI/VHDCI, 4M | ||
| X3831B | 530-2985 | Ultra-3 SCSI cable, VHDCI/VHDCI, 10M | ||
| X1137A | 530-2983 | Ultra-3 SCSI cable, VHDCI/VHDCI, 1.2M | ||
| X1138A | 530-2538 | Ultra-3 SCSI cable, VHDCI/VHDCI, 2M | ||
| n/a | 370-5405 | Single Bus SCSI Jumper cable, 0.3M, 35-00000131-01 | ||
| n/a | 370-7132 | DB9 to RJ45 Cable, 200 mm | ||
| Disks | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| XRA-SC1CC-146G10K | 540-6227 | 146.8GB – 10000 RPM, Disk Assembly with 1 of the following disks: | ||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
| n/a | 540-5735 | 146.8GB – 10000 RPM, Disk Assembly with 1 of the following disks: | ||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
| n/a | 540-6129 | 146.8GB – 10000 RPM, Disk Assembly with 1 of the following disks: | ||
|
|
|||
|
|
|||
| n/a | n/a | Drive Mounting Bracket, 82-00000977 or 82-00000983 (Manufacturer Part Number) | ||
| Ethernet | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| XTA5000-NF1-1G | 375-3211 | Single Gigabit Ethernet | ||
| XTA5000-NF2-1G | 375-3250 | Intel PRO/1000MF Dual Gigabit Ethernet | ||
| Fan | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| n/a | 370-6036 | Memory Fan Assembly | ||
| n/a | 370-6050 | System Fan Assembly | ||
| Memory | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| n/a | 370-6040 | 1GB DDR Memory | ||
| Miscellaneous | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| n/a | 540-6127 | LCD Module Assembly | ||
| Power | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| n/a | 370-5398 | 420 Watt AC Power Supply / Fan Module | ||
| n/a | 370-6048 | 500W Power Supply (also used as Redundant Power Supply) |
||
| n/a | n/a | Dual AC Input/DC Power Distribution Unit | ||
| Rack | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| XTA-3000-2URK-19U | 370-6166 | SE3000 2U Family Universal Rackmount Kit | ||
| XTA-5200-2URK-19U | 595-6805 | Rail & Extension Kit | ||
|
|
|||
|
|
|||
|
|
|||
| SG-XARY030A | 595-4706 | 72 inch Sun StorEdge Expansion Cabinet | ||
| X5030A | 595-6805 | Rail & Extension Kit | ||
|
|
|||
|
|
|||
|
|
|||
| SCSI | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| XTA5210-SCR2-320 | 540-7078 | MegaRAID 320-2X Dual Ultra-320 SCSI Assembly | ||
|
|
|||
|
|
|||
|
|
|||
| n/a | 540-6250 | MegaRAID 320-2X Dual Ultra-320 SCSI | ||
|
|
|||
|
|
|||
|
|
|||
| n/a | 540-7140 | MegaRAID 320-2X Dual Ultra-320 SCSI Assembly | ||
|
|
|||
|
|
|||
