Oracle Sun Storage 3310

Oracle Sun Storage 3310 Oracle Sun Storage 3310 3310

REQUEST A PRICE QUOTE:

    Name*

    Phone

    Details*

    Disks


    36GB
    • Seagate ST336605LC, 36.4GB – 10000 RPM, 1 inch, Ultra 160 LVD Drive
    • Fujitsu MAJ3364MC, 36.4GB – 10000 RPM, 1 inch, Ultra 320 LVD Drive
    • Seagate ST336753LC, 36.4GB – 15000 RPM, 1 inch, Ultra 320 LVD Drive
    • Fujitsu MAS3367NC, 36.4GB – 15000 RPM, 1 inch, Ultra 320 LVD Drive
    73GB
    • Seagate ST373307LC, 73.4GB – 10000 RPM, 1 inch, Ultra 320 LVD Drive
    • Hitachi DK32EJ-72NC, 73.4GB – 10000 RPM, 1 inch, Ultra 320 LVD Drive
    • Fujitsu MAP3735NC, 73.4GB – 10000 RPM, 1 inch, Ultra 320 LVD Drive
    • Seagate ST373207LC, 73.4GB – 10000 RPM, 1 inch, Ultra 320 LVD Drive
    • Fujitsu MAT3073NC, 73.4GB – 10000 RPM, 1 inch, Ultra 320 LVD Drive
    • Seagate ST373453LC, 73.4GB – 15000 RPM, 1 inch, Ultra 320 LVD Drive
    • Fujitsu MAS3735NC, 73.4GB – 15000 RPM, 1 inch, Ultra 320 LVD Drive
    146GB
    • Seagate ST3146807LC, 146.8GB – 10000 RPM, 1 inch, Ultra 320 LVD Drive
    • Fujitsu MAP3147NC, 146.8GB – 10000 RPM, 1 inch, Ultra 320 LVD Drive
    • Hitachi DK32EJ-14NC, 146.8GB – 10000 RPM, 1 inch, Ultra 320 LVD Drive
    • Seagate ST3146707LC, 146.8GB – 10000 RPM, 1 inch, Ultra 320 LVD Drive
    • Fujitsu MAT3147NC, 146.8GB – 10000 RPM, 1 inch, Ultra 320 LVD Drive
    300GB
    • Seagate ST3300007LC, 300B – 10000 RPM, 1 inch, Ultra 320 LVD Drive
    • Fujitsu MAT3300NC, 300B – 10000 RPM, 1 inch, Ultra 320 LVD Drive
    Capacity


    Up to 12 Disk drives per array1
    36.4GB Disk drives 12 x 36.4 = 436.8GB
    73.4GB Disk drives 12 x 73.4 = 880.8GB
    146.8GB Disk drives 12 x 146.8 = 1.7616TB
    300GB Disk drives 12 x 300 = 3.6TB
    1Minimum number of disk drives per array is five (5), per JTF.
    Environment


    Power Requirement AC: 90 to 132 VAC or 180 to 264 VAC, 47 to 63 Hz
    DC: -36 to -75 VDC
    Input Voltage AC: 100 to 240 VAC, single phase
    DC: -48 or -60 VDC, 18A
    Current Per Input AC: 100 to 240 VAC, 50-60 Hz, 5.0-7.1A
    DC: -48 or -60 VDC, 18A
    Maximum Inrush Current 100 VAC: 50A peak
    240 VAC: 100A peak
    Power Supply Output Voltages +5VDC and +12VDC
    Heat Output 785 BTU/hr (fully populated)
    Altitude Operating: To 3000 Meters (9000 feet)
    Non-operating: To 12000 Meters (36000 feet)
    Temperature Operating: 5° C to 40° C (41° F to 104° F)
    Non-operating: -40° C to 65° C (-40° F to 149° F)
    Humidity Operating: 10% to 90% @ 38° C (100° F), noncondensing
    Non-operating: 0% to 90% @ 27° C (80.6° F), noncondensing
    Shock Operating: 5.0 g’s, 11ms, half-sine (x, y, and z axis)
    Non-operating: 15 g’s, 11ms, half sine (x, y and z axis)
    Vibration Standalone
    Operating:     0.20 g’s, 5?Hz to 500?Hz to 5?Hz, swept-sine (5 sweeps in x, y, and z axis)
    Non-operating:1.0 g’s, 5?Hz to 500?Hz to 5?Hz, swept-sine (5 sweeps in x, y, and z axis)Rack Mounted
    Operating:     0.15 g’s vertical and 0.1 g’s horizontal, 5?Hz to 500?Hz, swept-sine
    Non-operating: 0.5 g’s vertical and 0.25 g’s horizontal, 1.0 Octaves per minute, 5?Hz to 500?Hz, swept-sine
    Dimensions and Weights


    Height Desktop: 9.25 cm (3.64 in)
    Rackmount: 8.8 cm (3.45 in)
    Width Desktop: 48.26 cm (19 in)
    Rackmount: 44.45 cm (17.5 in, chassis)
    Depth Main Chassis with bezel: 48.36 cm (19.04 in)
    Chassis with Power/Fan Modules and bezel: 53.44 cm (21.04 in)
    Chassis with Power/Fan Modules, Handles and bezel: 55.98 cm (22.04 in)
    Weight No Disks: 14.45 kg (31.85 lb)
    12 Disks: 24.15 kg (53.25 lb)
    Array Controller
    Option # Manufacturing
    Part #    		 Description
    XTA-3310-CTRL-512M 370-5403 512MB RAID Controller Module
    n/a 370-5394 Event Monitoring Unit (EMU)
    n/a 370-5396 Ultra-160 JBOD I/O Module, 2U Expansion Unit
    n/a 370-5397 Ultra-160 RAID I/O Module, 2U RAID Unit
    n/a 370-5533 Battery
    Backplane/Centerplane
    Option # Manufacturing
    Part #    		 Description
    n/a 370-5393 JBOD, LVD Chassis & Midplane
    n/a 370-5524 RAID Chassis & Midplane Assembly
    Cables
    Option # Manufacturing
    Part #    		 Description
    X1136A 530-2982 Ultra-3 SCSI cable, VHDCI/VHDCI, 0.8M
    X311L Localized Power Cord Kit – North America/Asia, RoHS:Y
    180-1097 IEC 320 C13 to NEMA 5-15P – 15A/125V 2.5M Black, RoHS:Y
    X312L Localized Power Cord Kit – Continental Europe, RoHS:Y
    180-1993 IEC 320 C13 to CEE 7/7 10A/250V 2.5M Black, RoHS:Y
    X314L Localized Power Cord Kit – Swiss, RoHS:Y
    180-1994 IEC 320 C13 to SEV 1011 – 10A/250V 2.5M Black, RoHS:Y
    X317L Localized Power Cord Kit – U.K., RoHS:Y
    180-1997 IEC 320 C13 to BS 1363 – 10A/250V 2.5M Black, RoHS:Y
    X3830B 530-2984 Ultra-3 SCSI cable, VHDCI/VHDCI, 4M
    X3831B 530-2985 Ultra-3 SCSI cable, VHDCI/VHDCI, 10M
    X383L Localized Power Cord Kit – Danish, RoHS:Y
    180-1995 IEC 320 C13 to Asfnit 107 – 10A/250V 2.5M Black, RoHS:Y
    X384L Localized Power Cord Kit – Italian, RoHS:Y
    180-1996 IEC 320 C13 to CEI 23-16/VII – 10A/250V 2.5M Black, RoHS:Y
    X386L Localized Power Cord Kit – Australian, RoHS:Y
    180-1998 IEC 320 C13 to AS 3112 – 10A/250V 2.5M Black, RoHS:Y
    X1132A 530-2452 External SCSI Cable, HD68 to VHDCI, 0.8M
    X1135A 530-3323 Ultra-3 SCSI Cable, HD68/VHDCI, 1.2M
    X1137A 530-2983 Ultra-3 SCSI cable, VHDCI/VHDCI, 1.2M
    X1138A 530-2538 Ultra-3 SCSI cable, VHDCI/VHDCI, 2M
    X3830A 530-2454 External SCSI Cable (Drive to Host HBA), HD68 to VHDC, 4M
    X3831A 530-2455 External SCSI Cable (Drive to Host HBA), HD68 to VHDC, 10M
    X3832A 530-2453 External SCSI Cable, HD68 to VHDCI, 2M
    XTA-3310-SC-TERM 370-4917 VHDCI-68 LVD SCSI Terminator
    XTA-3320-SC-TERM 371-0826 VHDCI-68 LVD SCSI Terminator Board, RoHS:YL
    n/a 370-5405 Single Bus SCSI Jumper cable, 0.3M, 35-00000131-01
    n/a 370-5528 RAID to JBOD Expansion cable, 0.45M, 35-00000131-02
    n/a 370-6627 DB-9M to DB-9F Serial Cable, 1.8M
    n/a 370-6629 Ethernet Cable, 35-88730002
    n/a 370-6630 DC Input Power Cable
    n/a 530-1819 Localized Power Cord Kit – Danish
    Disks
    Option # Manufacturing
    Part #    		 Description
    XTA-SC1NC-146G10K 540-6450 146.8GB – 10000 RPM, Disk Assembly with one of the following disks, RoHS:Y
    • 390-0253
    • Fujitsu MAW3147NC [MAW3147NCSUN146G]
      (146GB – 10000 RPM – SCSI Disk), RoHS:Y
    • 390-0266
    • Hitachi HUS103014FL3800 [HUS10143ASUN146G]
      (146GB – 10000 RPM – SCSI Disk), RoHS:Y
    • 390-0276
    • Seagate ST3146707LC [ST314670LSUN146G]
      (146GB – 10000 RPM – SCSI Disk), RoHS:Y
    XTA-SC1NC-300G10K 540-6132 300.0GB – 10000 RPM, Disk Assembly with one of the following disks, RoHS:Y
    • 390-0254
    • Fujitsu MAW3300NC [MAW3300NCSUN300G]
      (300GB – 10000 RPM – SCSI Disk), RoHS:Y
    • 390-0277
    • Seagate ST3300007LC [ST330000LSUN300G]
      (300GB – 10000 RPM – SCSI Disk), RoHS:Y
    XTA-SC1NC-73G10K 540-6448 73.4GB – 10000 RPM, Disk Assembly with one of the following disks, RoHS:Y
    • 390-0252
    • Fujitsu MAW3073NC [MAW3073NCSUN73G]
      (73.4GB – 10000 RPM – SCSI Disk), RoHS:Y
    • 390-0265
    • Hitachi HUS103073FL3800 [HUS10733ASUN72]
      (73.4GB – 10000 RPM – SCSI Disk), RoHS:Y
    • 390-0275
    • Seagate ST373207LC [ST373207LSUN72G]
      (73.4GB – 10000 RPM – SCSI Disk), RoHS:Y
    XTA-3310-146GB-10K 540-5735 146.8GB – 10000 RPM, Disk Assembly with 1 of the following disks:
    • 390-0145
    • Seagate ST3146807LC [ST314680LSUN146G]
      (146.8GB – 10000 RPM – SCSI Disk)
    • 390-0154
    • Fujitsu MAP3147NC [MAP3147N SUN146G]
      (146.8GB – 10000 RPM – SCSI Disk)
    • 390-0155
    • Hitachi DK32EJ-14NC [DK32EJ14NSUN146G]
      (146.8GB – 10000 RPM – SCSI Disk)
    • 390-0177
    • Seagate ST3146707LC [STST314670LSUN146G]
      (146GB – 10000 RPM – SCSI Disk)
    • 390-0178
    • Fujitsu MAT3147NC [MAT3147N SUN146G]
      (146GB – 10000 RPM – SCSI Disk)
    • 390-0179
    • Hitachi HUS103014FL3800 [HUS10143ASUN146G]
      (146GB – 10000 RPM – SCSI Disk)
    • 390-0253
    • Fujitsu MAW3147NC [MAW3147NCSUN146G]
      (146GB – 10000 RPM – SCSI Disk), RoHS:Y
    • 390-0266
    • Hitachi HUS103014FL3800 [HUS10143ASUN146G]
      (146GB – 10000 RPM – SCSI Disk), RoHS:Y
    • 390-0276
    • Seagate ST3146707LC [ST314670LSUN146G]
      (146GB – 10000 RPM – SCSI Disk), RoHS:Y
    540-6450 146.8GB – 10000 RPM, Disk Assembly with one of the following disks, RoHS:Y
    • 390-0253
    • Fujitsu MAW3147NC [MAW3147NCSUN146G]
      (146GB – 10000 RPM – SCSI Disk), RoHS:Y
    • 390-0266
    • Hitachi HUS103014FL3800 [HUS10143ASUN146G]
      (146GB – 10000 RPM – SCSI Disk), RoHS:Y
    • 390-0276
    • Seagate ST3146707LC [ST314670LSUN146G]
      (146GB – 10000 RPM – SCSI Disk), RoHS:Y
    XTA-3310-36GB-10K 540-5522 36.4GB – 10000 RPM, Disk Assembly with 1 of the following disks:
    • 390-0069
    • Seagate ST336605LC [ST336605LSUN36G]
      (36.4GB – 10000 RPM – SCSI Disk)
    • 390-0109
    • Seagate ST336607LC [ST336607LSUN36G]
      (36.4GB – 10000 RPM – SCSI Disk)
    • 390-0111
    • Hitachi DK32EJ-36NC [DK32EJ36NFSUN36G]
      (36.4GB – 10000 RPM – SCSI Disk)
    • 390-0156
    • Fujitsu MAP3367NC [MAP3367N SUN36G]
      (36.4GB – 10000 RPM – SCSI Disk)
    XTA-3310-36GB-15K 540-6121 36.4GB – 15000 RPM, Disk Assembly with one of the following disks:
    • 390-0131
    • Seagate ST336753LC [ST336753LSUN36G]
      (36.4GB – 15000 RPM – SCSI Disk)
    • 390-0132
    • Fujitsu MAS3367NC [MAS3367N SUN36G]
      (36.4GB – 15000 RPM – SCSI Disk)
    • 390-0199
    • Seagate ST336754LC [ST336754LSUN36G]
      (36.4GB – 15000 RPM – SCSI Disk), RoHS:Y
    • 390-0200
    • Fujitsu MAU3036NC [MAU3036NCSUN36G]
      (36.4GB – 15000 RPM – SCSI Disk)
    • 390-0201
    • Hitachi HUS151436VL3800 [HUS15363ASUN36G]
      (36.4GB – 15000 RPM – SCSI Disk)
    • 390-0259
    • Fujitsu MAX3036NC [MAX3036NCSUN36G]
      (36.4GB – 15000 RPM – SCSI Disk)
    540-5562 36.4GB – 15000 RPM (Lucent), Disk Assembly with one of the following disks:
    • 390-0131
    • Seagate ST336753LC [ST336753LSUN36G]
      (36.4GB – 15000 RPM – SCSI Disk)
    XTA-3310-73GB-10K 540-5563 73.4GB – 10000 RPM, Disk Assembly with 1 of the following disks:
    • 390-0106
    • Seagate ST373307LC [ST373307LSUN72G]
      (73.4GB – 10000 RPM – SCSI Disk)
    • 390-0108
    • Hitachi DK32EJ-72NC [DK32EJ72NSUN72G]
      (73.4GB – 10000 RPM – SCSI Disk)
    • 390-0157
    • Fujitsu MAP3735NC [MAP3735N SUN72G]
      (73.4GB – 10000 RPM – SCSI Disk)
    • 390-0174
    • Seagate ST373207LC [ST373207LSUN72G]
      (73.4GB – 10000 RPM – SCSI Disk)
    • 390-0175
    • Fujitsu MAT3073NC [MAT3073N SUN72G]
      (73.4GB – 10000 RPM – SCSI Disk)
    • 390-0176
    • Hitachi HUS103073FL3800 [HUS10733ASUN72G]
      (73.4GB – 10000 RPM – SCSI Disk)
    • 390-0252
    • Fujitsu MAW3073NC [MAW3073NCSUN73G]
      (73.4GB – 10000 RPM – SCSI Disk), RoHS:Y
    • 390-0265
    • Hitachi HUS103073FL3800 [HUS10733ASUN72]
      (73.4GB – 10000 RPM – SCSI Disk), RoHS:Y
    • 390-0275
    • Seagate ST373207LC [ST373207LSUN72G]
      (73.4GB – 10000 RPM – SCSI Disk), RoHS:Y
    540-6448 73.4GB – 10000 RPM, Disk Assembly with one of the following disks, RoHS:Y
    • 390-0252
    • Fujitsu MAW3073NC [MAW3073NCSUN73G]
      (73.4GB – 10000 RPM – SCSI Disk), RoHS:Y
    • 390-0265
    • Hitachi HUS103073FL3800 [HUS10733ASUN72]
      (73.4GB – 10000 RPM – SCSI Disk), RoHS:Y
    • 390-0275
    • Seagate ST373207LC [ST373207LSUN72G]
      (73.4GB – 10000 RPM – SCSI Disk), RoHS:Y
    XTA-3310-73GB-15K 540-6097 73.4GB – 15000 RPM, Disk Assembly with one of the following disks:
    • 390-0143
    • Seagate ST373453LC [ST373453LSUN72G]
      (73.4GB – 15000 RPM – SCSI Disk)
    • 390-0153
    • Fujitsu MAS3735NC [MAS3735N SUN72G]
      (73.4GB – 15000 RPM – SCSI Disk)
    • 390-0202
    • Seagate ST373454LC [ST373454LSUN72G]
      (73.4GB – 15000 RPM – SCSI Disk), RoHS:Y
    • 390-0203
    • Fujitsu MAU3073NC [MAU3073NCSUN72G]
      (73.4GB – 15000 RPM – SCSI Disk)
    • 390-0204
    • Hitachi HUS151473VL3800 [HUS15733ASUN72G]
      (73.4GB – 15000 RPM – SCSI Disk), RoHS:Y
    • 390-0260
    • Fujitsu MAX3073NC [MAX3073NCSUN72G]
      (73.4GB – 15000 RPM – SCSI Disk), RoHS:Y
    • 390-0325
    • Seagate ST373455LC [ST373455LSUN72G]
      (73.4GB – 15000 RPM – SCSI Disk), RoHS:Y
    • 390-0360
    • Hitachi HUS153073VL3800 [HUS15733BSUN72G]
      (73.4GB – 15000 RPM – SCSI Disk), RoHS:YL
    540-6449 73.4GB – 15000 RPM, Disk Assembly with one of the following disks, RoHS:YL
    • 390-0202
    • Seagate ST373454LC [ST373454LSUN72G]
      (73.4GB – 15000 RPM – SCSI Disk), RoHS:Y
    • 390-0204
    • Hitachi HUS151473VL3800 [HUS15733ASUN72G]
      (73.4GB – 15000 RPM – SCSI Disk), RoHS:Y
    • 390-0260
    • Fujitsu MAX3073NC [MAX3073NCSUN72G]
      (73.4GB – 15000 RPM – SCSI Disk), RoHS:Y
    • 390-0325
    • Seagate ST373455LC [ST373455LSUN72G]
      (73.4GB – 15000 RPM – SCSI Disk), RoHS:Y
    • 390-0360
    • Hitachi HUS153073VL3800 [HUS15733BSUN72G]
      (73.4GB – 15000 RPM – SCSI Disk), RoHS:YL
    XTA-SC1NC-146G15K 540-6494 146.8GB – 15000 RPM, Disk Assembly with one of the following disks, RoHS:YL
    • 390-0205
    • Seagate ST3146854LC [ST314685LSUN146G]
      (146GB – 15000 RPM – SCSI Disk), RoHS:Y
    • 390-0207
    • Hitachi HUS151414VL3800 [HUS15143ASUN146G]
      (146GB – 15000 RPM – SCSI Disk), RoHS:Y
    • 390-0261
    • Fujitsu MAX3147NC [MAX3147NCSUN146G]
      (146GB – 15000 RPM – SCSI Disk), RoHS:Y
    • 390-0327
    • Seagate ST3146855LC [ST314655LSUN146G]
      (146GB – 15000 RPM – SCSI Disk), RoHS:Y
    • 390-0361
    • Hitachi HUS153014VL3800 [HUS15143BSUN146G]
      (146GB – 15000 RPM – SCSI Disk), RoHS:Y
    XTA-SC1NC-73G15K 540-6449 73.4GB – 15000 RPM, Disk Assembly with one of the following disks, RoHS:YL
    • 390-0202
    • Seagate ST373454LC [ST373454LSUN72G]
      (73.4GB – 15000 RPM – SCSI Disk), RoHS:Y
    • 390-0204
    • Hitachi HUS151473VL3800 [HUS15733ASUN72G]
      (73.4GB – 15000 RPM – SCSI Disk), RoHS:Y
    • 390-0260
    • Fujitsu MAX3073NC [MAX3073NCSUN72G]
      (73.4GB – 15000 RPM – SCSI Disk), RoHS:Y
    • 390-0325
    • Seagate ST373455LC [ST373455LSUN72G]
      (73.4GB – 15000 RPM – SCSI Disk), RoHS:Y
    • 390-0360
    • Hitachi HUS153073VL3800 [HUS15733BSUN72G]
      (73.4GB – 15000 RPM – SCSI Disk), RoHS:YL
    n/a 540-6056 73.4GB – 10000 RPM, Disk Assembly with 1 of the following disk drives:
    • 390-0106
    • Seagate ST373307LC [ST373307LSUN72G]
      (73.4GB – 10000 RPM – SCSI Disk)
    • 390-0108
    • Hitachi DK32EJ-72NC [DK32EJ72NSUN72G]
      (73.4GB – 10000 RPM – SCSI Disk)
    • 390-0157
    • Fujitsu MAP3735NC [MAP3735N SUN72G]
      (73.4GB – 10000 RPM – SCSI Disk)
    • 390-0174
    • Seagate ST373207LC [ST373207LSUN72G]
      (73.4GB – 10000 RPM – SCSI Disk)
    • 390-0175
    • Fujitsu MAT3073NC [MAT3073N SUN72G]
      (73.4GB – 10000 RPM – SCSI Disk)
    • 390-0176
    • Hitachi HUS103073FL3800 [HUS10733ASUN72G]
      (73.4GB – 10000 RPM – SCSI Disk)
    • 390-0252
    • Fujitsu MAW3073NC [MAW3073NCSUN73G]
      (73.4GB – 10000 RPM – SCSI Disk), RoHS:Y
    • 390-0265
    • Hitachi HUS103073FL3800 [HUS10733ASUN72]
      (73.4GB – 10000 RPM – SCSI Disk), RoHS:Y
    • 390-0275
    • Seagate ST373207LC [ST373207LSUN72G]
      (73.4GB – 10000 RPM – SCSI Disk), RoHS:Y
    n/a 540-6058 146.8GB – 10000 RPM, Disk Assembly with 1 of the following disks:
    • 390-0145
    • Seagate ST3146807LC [ST314680LSUN146G]
      (146.8GB – 10000 RPM – SCSI Disk)
    • 390-0154
    • Fujitsu MAP3147NC [MAP3147N SUN146G]
      (146.8GB – 10000 RPM – SCSI Disk)
    • 390-0155
    • Hitachi DK32EJ-14NC [DK32EJ14NSUN146G]
      (146.8GB – 10000 RPM – SCSI Disk)
    • 390-0177
    • Seagate ST3146707LC [STST314670LSUN146G]
      (146GB – 10000 RPM – SCSI Disk)
    • 390-0178
    • Fujitsu MAT3147NC [MAT3147N SUN146G]
      (146GB – 10000 RPM – SCSI Disk)
    • 390-0179
    • Hitachi HUS103014FL3800 [HUS10143ASUN146G]
      (146GB – 10000 RPM – SCSI Disk)
    • 390-0253
    • Fujitsu MAW3147NC [MAW3147NCSUN146G]
      (146GB – 10000 RPM – SCSI Disk), RoHS:Y
    • 390-0266
    • Hitachi HUS103014FL3800 [HUS10143ASUN146G]
      (146GB – 10000 RPM – SCSI Disk), RoHS:Y
    • 390-0276
    • Seagate ST3146707LC [ST314670LSUN146G]
      (146GB – 10000 RPM – SCSI Disk), RoHS:Y
    n/a 540-6366 300GB – 10000 RPM, Disk Assembly with one of the following disks:
    • 390-0184
    • Seagate ST3300007LC [ST330000LSUN300G]
      (300.0GB – 10000 RPM – SCSI Disk)
    • 390-0185
    • Fujitsu MAT3300NC [MAT3300N SUN300G]
      (300.0GB – 10000 RPM – SCSI Disk)
    • 390-0254
    • Fujitsu MAW3300NC [MAW3300NCSUN300G]
      (300GB – 10000 RPM – SCSI Disk), RoHS:Y
    • 390-0277
    • Seagate ST3300007LC [ST330000LSUN300G]
      (300GB – 10000 RPM – SCSI Disk), RoHS:Y
    n/a n/a Drive Mounting Bracket, 82-00000977 or 82-00000983 (Manufacturer Part Number)
    n/a 540-6057 73.4GB – 15000 RPM, Disk Assembly with 1 of the following disks:
    • 390-0143
    • Seagate ST373453LC [ST373453LSUN72G]
      (73.4GB – 15000 RPM – SCSI Disk)
    • 390-0153
    • Fujitsu MAS3735NC [MAS3735N SUN72G]
      (73.4GB – 15000 RPM – SCSI Disk)
    • 390-0202
    • Seagate ST373454LC [ST373454LSUN72G]
      (73.4GB – 15000 RPM – SCSI Disk), RoHS:Y
    • 390-0203
    • Fujitsu MAU3073NC [MAU3073NCSUN72G]
      (73.4GB – 15000 RPM – SCSI Disk)
    • 390-0204
    • Hitachi HUS151473VL3800 [HUS15733ASUN72G]
      (73.4GB – 15000 RPM – SCSI Disk), RoHS:Y
    • 390-0260
    • Fujitsu MAX3073NC [MAX3073NCSUN72G]
      (73.4GB – 15000 RPM – SCSI Disk), RoHS:Y
    • 390-0325
    • Seagate ST373455LC [ST373455LSUN72G]
      (73.4GB – 15000 RPM – SCSI Disk), RoHS:Y
    • 390-0360
    • Hitachi HUS153073VL3800 [HUS15733BSUN72G]
      (73.4GB – 15000 RPM – SCSI Disk), RoHS:YL
    Power
    Option # Manufacturing
    Part #    		 Description
    XTA-3000-2UAC-KIT 370-6776 AC Power Supply / Fan Module, 2U
    371-0108 420 Watt AC Input Power Supply, RoHS:YL
    XTA-3000-2UDC-KIT 370-6798 DC Power Supply / Fan Module, 2U
    371-0109 420 Watt DC Input Power Supply, RoHS:YL
    XTA-3310-DC-KIT 370-5527 DC Power Supply / Fan Module
    n/a 370-5398 420 Watt AC Power Supply / Fan Module
    Rack
    Option # Manufacturing
    Part #    		 Description
    XTA-3000-2U-R2T 370-7596 Sun StorEdge 3000 2U Rack Ready to Tabletop conversion kit
    XTA-3000-2URK-19C 370-5649 Telco Rackmount Kit, Center Mount, 2U, 19″ Wide
    XTA-3000-2URK-19F 370-5650 Telco Rackmount Kit, Flush/Front Mount, 2U, 19″ Wide
    XTA-3000-2URK-19U 370-6166 SE3000 2U Family Universal Rackmount Kit
    XTA-3310-DESK-KIT 370-6179 Sun StorEdge 3000 Family Tabletop Conversion Kit, includes outer skin with feet and screws
    XTA-3310-RK-19C 370-5649 Telco Rackmount Kit, Center Mount, 2U, 19″ Wide
    XTA-3310-RK-19F 370-5650 Telco Rackmount Kit, Flush/Front Mount, 2U, 19″ Wide
    XTA-3310-RK-19L 370-5648 Rackmount Kit, 2U, 19″ Wide, 28″-36″ Deep (use with StorEdge 72″ Expansion Cabinet)
    XTA-3310-RK-19S 370-5643 Rackmount Kit, 2U, 19″ Wide, 22″-28″ Deep (use with Sun Rack 900)
    SCSI
    Option # Manufacturing
    Part #    		 Description
    SG-XPCIE2SCSIU320Z 375-3357 Dual-Channel Ultra320 LVD SCSI PCI Express Adapter, RoHS:Y
    SGXPCI2SCSILM320-Z 375-3365 PCI Dual Ultra320 SCSI Adapter, RoHS:YL
    SG-XPCI2SCSI-LM320 375-3191 PCI/PCI-X Dual Ultra320 SCSI Adapter
    X1018A 501-2739 Single-Ended Fast/Wide SCSI/FastEthernet (SunSwift/S)
    X2222A 501-5727 Dual FastEthernet / Dual SCSI PCI Adapter
    X4422A 501-6635 Dual GigabitEthernet / Dual SCSI PCI Adapter
    X6758A 375-3057 PCI Dual Ultra3 SCSI Host Adapter (LVD)
    X9265A 370-6682 Dual Ultra-320 SCSI/RAID



    Industry Leading Quality, Support and Integrity

    Quality Inspection Checklist
    Before it leaves our facility, every used and refurbished item is thoroughly inspected by our certified technicians and undergoes our exclusive Quality Inspection Checklist to ensure 100% satisfaction guarantee.

    Greentec Systems is a leading provider
    For server, networking and storage equipment. We have an extensive array of inventory of IBM Servers & Storage, Sun Servers & Storage, Cisco Networking (Switches, Routers, Security), and NetApp Storage (disk shelves, disk drives, Filers, NearStore, NetCache). If you don’t see the item or product you require please contact us.

    Have this equipment to sell?
    Depending on the age and condition of the equipment, there is a very good likelihood that we will be able to offer you cash or trade-in credit for other IT hardware. If the equipment is very old we can also assist you with properly decommissioning that gear in the most environmentally friendly way possible.

    Questions?
    For more information please contact 888.333.7388, or fill out the quote from above. We’d love to hear from you.

    Request Quote
    Greentec Systems We geek out helping you with your IT infrastructure.
    Request a quote or product information
    Send
