Oracle’s Sun SPARC T7 is an advanced systems for enterprise workloads, with unique capabilities for information security, database and Java acceleration. Breakthrough software in silicon technology in Oracle’s SPARC processor provides full speed encryption, plus detection and prevention of attacks to critical data in memory. It also enables real time analytics to be performed on OLTP databases by accelerating Oracle database in-memory queries in Oracle database 12c.

The T7-1 server is a single-processor system that enables organizations to respond to IT demands with security and performance, at a lower cost compared to alternatives. It is ideal for a wide range of enterprise-class workloads, including database, applications, Java, and middleware. This system is based on the SPARC M7 processor, the first to use a revolutionary technology from Oracle referred to as software in silicon.

Built-in virtualization capabilities in Oracle’s SPARC servers include both Oracle Solaris Zones and Oracle VM Server for SPARC. These allow enterprise workloads to be run within a virtual environment with near-zero performance impact. You can virtualize and consolidate many servers onto one, reducing the physical footprint of the data center as well as lowering the costs of operation, power, and cooling. Oracle Solaris Zones technology provides the capability to run legacy applications that require earlier versions of Oracle Solaris.

Other advanced capabilities of the SPARC T7-1 server are large memory capacity, higher bandwidth, and minimal latency, which are achieved through four enhanced memory controllers per socket, faster and reduced power DDR4 memory, and prefetch acceleration techniques. The I/O subsystem supports low-profile PCIe 3.0 adapters and industry-standard NVMe flash technology to provide high-capacity storage with minimal latency. Integrated controllers for networking, disks, and management reduce the cost of the system and provide greater expandability. Contact Greentec Systems for a discounted quote on the T7-1 server

Brand:	Oracle / Sun Microsystems
Condition:	Refurbished and new (limited availability)
Availability:	Contact
Shipping Area:	Worldwide to most countries
Shipping Method:	Fedex (most orders), UPS, DHL, Freight Courier
Price:	Please use the quote form above for quick pricing
Payment:	Credit Card, Check, Net Terms (oac), Wire Transfer (required for international orders)
Guarantee:	All items are tested by Oracle trained technicians & backed by a 100% warranty
Questions?	Don’t hesitate to contact us with any questions regarding compatibility or other product info and requests. Our website represents only a fraction of our full inventory. Please reach out with your full requirements

SPARC T7-1	2	1× SPARC M7	4.13 GHz	1 TB	Eight 2.5″ SAS-3

Oracle Sun SPARC T7 Server chart, t7-1 t7-2 oracle sun sparc t7-1 server Oracle Sun SPARC T7-1 Server Screen Shot 2017 07 10 at 8 — Oracle Sun SPARC T7 Server chart, t7-1 t7-2

Oracle T7-1 Server Benefits:

Full-speed encryption allows end-to-end data protection with near-zero performance impact
First-ever hardware-based protection helps prevent malicious memory attacks and helps protect the integrity of application data
Complete stack integration enables real-time analytics on OLTP databases by accelerating the performance of Oracle Database 12c In-Memory
World-record performance running Oracle Database, Java and enterprise applications allows you to complete more work in less time
Outperforms dual- and quad-processor alternatives

Manufacturer	Sun Oracle
Warray	Standard and optional Greentec Systems 24/7/365 onsite maintenance warranty
Preceeded By	SPARC T5-1
Rack Units	2U
Height	87.6
Width	445
Depth	737
Weight [Kg]	25.60
CPU Socket(s)	1
Compatible CPU(s)	SPARC M7 (V9)
Max CPU Clk Spd	4.13 GHz
CPU Cache	16KB/256KB/64MB
Max # Thread(s)	256
Max # Core(s)	32
Memory Slot(s)	16
Memory Capacity	512GB
Memory Expansion	Sixteen dual inline memory module (DIMM) slots per processor supporting half and fully populated memory configurations using 16 or 32 GB DDR4 DIMMs
Drive Bays	Up to eight 600 GB or 1200 GB 2.5 in SAS-3 drives
Supported OS	Oracle Solaris
USB Port(s)	Four external USB (two front USB 2.0 and two rear USB 3.0)
PCI Slot(s)	six low-profile PCIe 3.0 (four x8 and two x16 or x8 wired) slots
LAN Socket(s)	four 10 GbE (100 Mbps/1 Gbps/10 Gbps), full duplex only, auto-negotiating

Specs and Information:

Processor

Number

One SPARC M7 32-Core 4.133GHz processor

CPUs

4.133GHz 32-Core
256 threads per processor (up to 8 threads per core)
Eight accelerators per processor, each supporting four concurrent in-memory query operations with decompression.
Thirty-two on-chip Encryption Instruction Accelerators with direct non-privileged support for
15 industry-standard cryptographic algorithms: AES, Camellia, CRC32c, DES, 3DES, DH, DSA, ECC,
MD5, RSA, SHA-1, SHA-224, SHA-256, SHA-384, SHA-512 (one per core)

Cache memory

Level 1: 16 KB instruction and 16 KB data per core, Level 2: 256 KB L2 I$ per four cores, 256 KB L2 D$ per core pair,
Level 3: 64 MB L3$ on chip.

Main Memory

Capacities

Total DIMM slots: 16 dual inline memory module (DIMM) slots per processor.
DIMM type: DDR4-2133
DIMM size: 16GB or 32GB
Maximum capacity: 512GB (16 × 32GB)

Standard Integrated Interfaces

Network

4 × 10 GbE (100 Mbps/1 Gbps/10 Gbps), full duplex only, auto-negotiating

Network Management

One dedicated 10/100Base-T RJ-45 port Ethernet port

Serial Management

One dedicated RJ-45 port

Remote Management

Onboard system processor, running Integrated Lights Out Manager (ILOM)

Graphics

One DB-15 VGA connector

USB

Front: 2 USB 2.0 Ports
Rear: 2 USB 3.0 Ports

PCI Expansion Slots

6 low-profile PCI-Express 3.0 slots.

Slot #	Physical	Electrical
1	x8	x8
2	x8	x8 or unused if slot 3 x16
3	x16	x8 or x16
4	x16	x8 or x16
5	x8	x8 or unused if slot 4 x16
6	x8	x8

Internal Mass Storage

Disks

Up to eight 2.5-inch SAS-3 drives
600GB or 1.2TB 2.5-inch SAS-3 disk drives
Optional Internal Storage: 400GB Solid State Drives, maximum of eight (installed in standard drive bays)
Optional Internal Storage: 1.6TB NVMe Drives, maximum of four (installed in standard drive bays)
RAID 0, RAID 1, and RAID 1E/10 support

DVD-ROM

One Slimline 1/2 height SATA DVD +/-RW

Power Supplies

2 × 1000 Watt, hot-swappable, 1+1 redundant power supply units (PSU)

Environment

Power Consumption

Online power calculator

Input Voltage

100 – 120 VAC, 50-60Hz
200 – 240 VAC, 50-60Hz

Input Current

7.0 A @ 200 VAC (all inputs)
5.7 A @ 200 VAC (per cord)

Input Power

1370W @ 200 VAC (all inputs)

Heat Output

4456 BTU/hr, 4702 Kj/hr

Temperature

Operating: 5° C to 35° C (41° F to 95° F)
Nonoperating: -40° C to 65° C (-40° F to 149° F)Note: Above 900m (3000 ft), decrease in maximum temperature as altitude increase, 1° C/300m (1.8° F/984ft)

Humidity

Operating: 10% to 90% relative humidity noncondensing, 27° C (81° F) maximum wet bulb
Nonoperating: 93% relative humidity noncondensing, 38° C (100° F) maximum wet bulb

Altitude

Operating: 0m to 3000m (9,840 ft.)
Nonoperating: 0m to 12000m (39,370 ft.)

Vibration

Operating: 0.15 G (vertical), 0.10 G (horizontal), 5 ? 500 Hz, swept-sine
Nonoperating: 0.5 G (vertical), 0.25 G (horizontal), 5 ? 500 Hz, swept-sine

Acoustic Noise

Operating/Idling: 62.0 dBA (LwAd, 1B = 10dB)
Operating/Idling: 69.7 dBA (LpAm, bystander positions)

Regulations
Meets or exceeds the following requirements:

Safety

UL/CSA-60950-1, EN60950-1, IEC60950-1 CB Scheme with all country deviations

RFI/EMI

EN55022 Class A, 47 CFR 15B Class A, ICES-003 Class A, VCCI Class A, AS/NZ3548 Class A, CNS 13438 Class A, KSC 5858 Class A, EN61000-3-2, EN61000-3-3

Immunity

EN55024, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5,
IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11

Certifications

North American Safety (NRTL), European Union (EU), International CB Scheme, BIS (India),
BSMI (Taiwan), RCM (Australia), CCC (PRC), MSIP (Korea), VCCI (Japan)

European Union Directives

2006/95/EC (73/23/EEC) Low Voltage Directive, 2014/35/EU EMC Directive, 2014/30/EU, Waste Electrical and Electronic Equipment Directive (WEEE) 2012/19/EU Directive, 2002/95/EC Restriction of Hazardous Substances (RoHS) Directive 2011/65/EU

Dimensions and Weight

Height

87.6 mm (3.5 in.); 2U

Width

445.0 mm (17.5 in.)

Depth

737 mm (29 in.)

Weight

Appx 25.62 kg (56.4 lbs), without rackmount kit

Clearance and Service Access

Front

910 mm (36 in.)

Rear

910 mm (36 in.)

Batteries
Option #	Manufacturing Part #	Description	Previous Part #
n/a	371-2210 [C]	3V Lithium Coin Cell Battery	n/a

CPU Module
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7097099	32-Core 4.133GHz CPU Mezzanine	n/a
n/a	7310197	32-Core 4.133GHz CPU Mezzanine	n/a
n/a	7315604	32-Core 4.133GHz CPU Mezzanine	n/a

Cables
Option #	Manufacturing Part #	Description	Previous Part #
7102869	7039990 [C]	MPO to MPO High Bandwidth QSFP Optical Cable, 10M	n/a
7102870	7039999 [C]	MPO to MPO High Bandwidth QSFP Optical Cable, 20M	n/a
7102871	7040001 [C]	MPO to MPO High Bandwidth QSFP Optical Cable, 50M	n/a
7105199	7063849 [C]	InfiniBand Cable, QSFP, Optical, MPO to MPO, 5M	n/a
7105206	7063852 [C]	InfiniBand Cable, QSFP, Optical, MPO to MPO, 100M	n/a
X2121A-1M-N	530-4444 [C]	10Gbps QSFP to QSFP Cable, 1m	n/a
X2121A-3M-N	530-4445 [C]	10Gbps QSFP to QSFP Cable, 3m	n/a
X2121A-5M-N	530-4446 [C]	10Gbps QSFP to QSFP Cable, 5m	n/a
X2125A-1M-N	530-4450 [C]	QSFP to 4× SFP+ Splitter Cable, 1m	n/a
X2125A-3M-N	530-4451 [C]	QSFP to 4× SFP+ Splitter Cable, 3m	n/a
X2125A-5M-N	530-4452 [C]	QSFP to 4× SFP+ Splitter Cable, 5m	n/a
X2130A-3M-N	530-4442 [C]	10Gbps SFP+ TwinX Cable, 3m	n/a
X2130A-5M-N	530-4443 [C]	10Gbps SFP+ TwinX Cable, 5m	n/a
n/a	530-3100	RJ45F to DB9F Adapter	n/a
n/a	530-3623	Shielded RJ45 to RJ45 Cable, 4M	n/a
n/a	7089783 [C]	Two Cable Bundle, PCI Express, 2xHD8i to 2x68P	n/a
	n/a	MiniSAS HD 8i to 90° MiniSAS, 2 and 3 to A, 465mm	n/a
	n/a	MiniSAS HD 8i to 90° MiniSAS, 0 and 1 to B, 500mm	n/a
n/a	7095863	SAS Cable Guide, 90°	n/a
n/a	7096303	SAS Cable Guide, 45°	n/a
n/a	7316563 [F]	Cable Kit SKU	n/a
	7014226 [C]	Interlock Cable, 125mm	n/a
	7064125	8-Pin Dc Power Cable, 394mm	n/a
	7064127	26-Pin Ribbon Data Cable, 280mm	n/a
	7064128	DVD Data and Power Cable, 600mm/75mm	n/a
	7314510	Dual Mini SAS-3 HD8i Cable	n/a
	n/a	76-Pin SFF-8643 to SFF-8087 to 90° SFF-8087 807mm	n/a
	n/a	76-Pin SFF-8643 to SFF-8087 to SFF-8087 597mm	n/a

Chassis
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7073525	Chassis Assembly	n/a
	7061427	Midwall Subassembly	n/a
	7082078	Chassis Subassembly	n/a
	7303490	Rear Cover Assembly	n/a
	150-4065	Interlock Switch Magnet	n/a

Communication
Option #	Manufacturing Part #	Description	Previous Part #
7104074	7092757 [C]	Dual 40Gb/Sec (4x) QDR InfiniBand Host Channel Adapter Module M3	n/a
n/a	7046442 [C]	Dual 40Gb/Sec (4x) QDR InfiniBand Host Channel Adapter Module M3	n/a

Disk Backplane
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7061430	8-Slot 2.5″ Disk Cage Assembly	n/a
	7017231 [F]	Disk Backplane Right LED Indicator Module	n/a
	7023333	Right Indicator	n/a
	7064122	Left Indicator Ribbon Cable	n/a
	7064124	Right Indicator Ribbon Cable	n/a
	7077320	Fan Door Cover	n/a
	7077622	8-Slot Disk Cage	n/a
	7096185 [F]	Left Indicator Assembly	n/a
	7096184	Left Indicator w/o Button or Lightpipe	n/a
	7097205 [F]	8-Slot Backplane	n/a

Disks
Option #	Manufacturing Part #	Description	Previous Part #
7110927	7302552 [C]	1.6TB Solid State NVMe Drive Assembly	n/a
	7093848	1.6TB 2.5″ eMLC NVMe Solid State Drive	n/a
	541-2123	Marlin 2.5″ Bracket	n/a
7110933	7094132 [C]	400GB Solid State SAS Drive Assembly	n/a
	7093645	400GB SAS Solid State Drive [HSCAC2DA4SUN400G]	n/a
	541-2123	Marlin 2.5″ Bracket	n/a
7111103	7093015 [C]	600GB – 10000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks:	n/a
	7093013	Hitachi HUC101860CSS200 (600.0GB – 10000 RPM SAS Disk)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a
7111108	7093037 [C]	1.2TB – 10000 RPM SAS SFF Disk Assembly w 1 bracket and 1 of the following disks:	n/a
	7093035	Hitachi HUC101812CSS200 [H101812SFSUN1.2T] (1.2TB – 10000 RPM – SAS DISK)	n/a
	541-2123	Marlin 2.5″ Bracket	n/a

Ethernet
Option #	Manufacturing Part #	Description	Previous Part #
7100477	7070195 [C]	Quad Port GbE PCI Express 2.0 Low Profile Adapter, UTP	n/a
7100481	7070202 [C]	Dual Port GbE PCI Express 2.0 Low Profile Adapter, MMF	n/a
7100488	7070006 [C]	Dual 10-Gigabit Base-T PCI Express Gen2	n/a
X1109A-Z	7051223 [C]	Dual 10-Gigabit PCI Express Ethernet SFP+ LP	n/a
X2124A-N	135-1204 [C]	10Gb/Sec QDR InfiniBand / 40Gb/Sec Ethernet QSFP Transceiver	n/a
X2129A-N	530-4449 [C]	10Gb/Sec Short Wave SFP+ Transceiver	n/a
X5562A-Z	135-1205 [C]	10Gb/Sec Long Wave SFP+ Transceiver	n/a

Fan
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7045042 [C]	Dual Counter Rotating Fan Module	n/a
n/a	7045041	80×80mm Counter Rotating Fan	n/a
n/a	7084402 [C]	Clear Plastic Air Duct Assembly	n/a

Fibre Channel
Option #	Manufacturing Part #	Description	Previous Part #
7101674	7023303 [C]	Dual 16Gigabit/Sec Fibre Channel / 10Gbps FCoE Host Adapter, QLogic	n/a
7101676	7023325 [C]	Pair of 16Gbps Short Wave SFP+	n/a
7101676	7023324	16Gb/Sec Short Wave SFP+ Transceiver, QLogic	n/a
7101678	7023315 [C]	Pair of 10Gbps Short Wave SFP+	n/a
7101678	7023316	10Gb/Sec Short Wave SFP+ Transceiver, QLogic	n/a
7101684	7023036 [C]	Dual 16Gigabit/Sec Fibre Channel / 10Gbps FCoE Host Adapter, Emulex	n/a
7101686	7023059 [C]	Pair of 16Gbps Short Wave SFP+	n/a
7101686	7023053	16Gb/Sec Short Wave SFP+ Transceiver, Emulex	n/a
7101688	7023057 [C]	Pair of 10Gbps Short Wave SFP+	n/a
7101688	7023046	10Gb/Sec Short Wave SFP+ Transceiver, Emulex	n/a
SG-XPCIE2FC-EM8-N	7053434 [C]	8Gigabit/Sec PCI Express Dual FC Host Adapter	n/a

I/O
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7064634 [F]	8-Port PCI Express Switch	n/a
n/a	7096186	PCI Express Switch w/o Bracket or Heatsink	n/a

Memory
Option #	Manufacturing Part #	Description	Previous Part #
7107207	7082850 [C]	16GB Registered DDR4-2133 DIMM	n/a
7107209	7082851 [C]	32GB Load Reduced DDR4-2133 DIMM	n/a
n/a	7074618 [C]	2GB Embedded USB	n/a
n/a	7300948 [F]	Memory Module Assembly	n/a
	7084075	Mounting Tray	n/a
	7094733	Protective Connector Cover	n/a
	7300945	Memory Module	n/a

Power
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7044130 [C]	A258 1000 Watt AC Input Power Supply	n/a

Rack
Option #	Manufacturing Part #	Description	Previous Part #
n/a	350-1719 [C]	1U/2U Snap-In Slide Rail Rackmount Kit	n/a
n/a	7042273 [C]	1U/2U Cable Management Arm (Snap-in)	n/a

Removable Media
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7096965 [F]	Tray-Load DVD Assembly	n/a
	7082449	DVD Bezel	n/a
	7089963	8x Tray-Load DVD-ROM/24-x CD-ROM Writer (Gen5)	n/a
	7096434	Mounting Tray	n/a
	7318288	Bezel	n/a
n/a	7319315 [F]	Tray-Load DVD Assembly	n/a
	7096434	Mounting Tray	n/a
	7309891	8x Tray-Load DVD-ROM/24x CD-ROM Writer (Gen6)	n/a
	7318288	Bezel	n/a

SCSI
Option #	Manufacturing Part #	Description	Previous Part #
7110119	7085208 [C]	8-Port 12Gbps SAS PCI Express HBA	n/a
7110865	7307468 [C]	1.6TB Flash Accelerator F160 NVMe Card w/ LP Bracket (B1 Silicon)	n/a

System Board
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7014226 [C]	Interlock Cable, 125mm	n/a
n/a	7300942 [F]	System Board Assembly	n/a
	530-4348	System Board to Rear I/O Board Signal Cable	n/a
	7051520	Rear I/O Board	n/a
	7074618 [C]	2GB Embedded USB	n/a
	7094165	System Board Tray	n/a
	7097099	32-Core 4.133GHz CPU Mezzanine	n/a
	7300937	System Board	n/a
	371-2210 [C]	3V Lithium Coin Cell Battery	n/a
	525-2146 [C]	SSCC NVRAM	n/a
n/a	7310207 [F]	System Board Assembly	n/a
	7051520	Rear I/O Board	n/a
	7074618 [C]	2GB Embedded USB	n/a
	7094165	System Board Tray	n/a
	7300937	System Board	n/a
	371-2210 [C]	3V Lithium Coin Cell Battery	n/a
	525-2146 [C]	SSCC NVRAM	n/a
	7310197	32-Core 4.133GHz CPU Mezzanine	n/a
	530-4348	System Board to Rear I/O Board Signal Cable	n/a
n/a	7315713 [F]	System Board Assembly	n/a
	7051520	Rear I/O Board	n/a
	7074618 [C]	2GB Embedded USB	n/a
	7094165	System Board Tray	n/a
	7300937	System Board	n/a
	371-2210 [C]	3V Lithium Coin Cell Battery	n/a
	525-2146 [C]	SSCC NVRAM	n/a
	7315604	32-Core 4.133GHz CPU Mezzanine	n/a
	530-4348	System Board to Rear I/O Board Signal Cable	n/a

System Service Processor
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7306978 [F]	Service Processor Assembly	n/a
	350-1614	Service Processor Cover	n/a
	7306979	Service Processor	n/a
n/a	7319380 [F]	Service Processor Assembly	n/a
	350-1614	Service Processor Cover	n/a
	7319381	Service Processor	n/a

Industry Leading Quality, Support and Integrity

Quality Inspection Checklist
Before it leaves our facility, every used and refurbished item is thoroughly inspected by our certified technicians and undergoes our exclusive Quality Inspection Checklist to ensure 100% satisfaction guarantee.

Greentec Systems is a leading provider
For server, networking and storage equipment. We have an extensive array of inventory of IBM Servers & Storage, Sun Servers & Storage, Cisco Networking (Switches, Routers, Security), and NetApp Storage (disk shelves, disk drives, Filers, NearStore, NetCache). If you don’t see the item or product you require please contact us.

Have this equipment to sell?
Depending on the age and condition of the equipment, there is a very good likelihood that we will be able to offer you cash or trade-in credit for other IT hardware. If the equipment is very old we can also assist you with properly decommissioning that gear in the most environmentally friendly way possible.

Questions?
For more information please contact 888.333.7388, or fill out the quote from above. We’d love to hear from you.
