Oracle Sun Netra X4270 SERVER SPECS AND DIMENSIONS
REQUEST A PRICE QUOTE:
| Processor | |
| Number | Two Intel Quad-core |
| Architecture | Type: Quad-Core Intel Xeon L5518 (8MB L3, 5.86 GT/s QPI, 2.13 GHz, 1066 MHz FSB, 60W) |
| Cache memory | 32KB instruction and 32KB data L1 cache per core 256KB unified (data and instruction) L2 cache per core 8MB shared inclusive L3 cache per processor |
| Main Memory | |
| Capacities |
DIMM slots per CPU socket: 9 Total DIMM slots (when 2 CPU’s are installed): 18 DIMM type: PC3-10600 DDR3-1333 Registered DIMMs PC3-8500 DDR3-1066 Registered DIMMs DIMM size: 4GB, 8GB Maximum capacity: 144 GB (when configured with 8GB DIMMs) |
| Standard Integrated Interfaces | |
| Network | Four 10/100/1000Base-T Ethernet ports |
| Network Management | One 10/100Base-T Ethernet port |
| Serial Management | One TIA/EIA-232-F asynchronous RJ45 port |
| SAS | Four-channel SAS Interface (with SFF-8088 connector), internal access only |
| USB (2.0) | Rear: 2 |
| Video | One VGA Video port (HD-15) |
| Alarms | Four fail-safe DB-15 dry contact (critical, major, minor and user) |
| Expansion Bus | Two PCI-Express full-height, full length slots (x8 electrical, x16 mechanical) Four x8 PCI-Express MD2 low profile slots Note: PCI-Express MD2 slot 3 is reserved for the internal SAS host bus adapter |
| Internal Mass Storage | |
| Option 1 | DVD-R/W, up to two 300GB 2.5in 10K RPM SAS disks, maximum capacity 600GB |
| Option 2 | No DVD-R/W, Up to four 300GB 2.5in 10K RPM SAS disks, maximum capacity 1.2TB |
| DVD-ROM | One Slimline DVD/RW |
| Power Supplies | |
| Two 660W (1+1) hot-swappable DC Note: To ensure redundant operation of the power supplies, the two power inputs should be connected to separate power sources. |
|
| Nominal input voltages | -48VDC or -60VDC |
| Operating input voltage range | -48VDC or -75VDC |
| Max operating input current | 15.4 A at -48VDC (740 VA) |
| Maximum Operating Input Power | 740 W |
| Environment | |
| Temperature |
Operating: 5° C to 40° C (41° F to 104° F)/Short term: 5° C to 55° C (23° F to 131° F) Nonoperating: -40° C to 70° C (-40° F to 158° F) |
| Humidity |
Operating: 5% to 85% relative humidity noncondensing, max wet bulb. Short term: 5% to 90% relative humidity noncondensing, but not to exceed 0.024kg water/kg dry air (0.053 lbs. water 2.205 lb. dry air) Nonoperating: up to 93% relative humidity noncondensing, 40° C (104.4° F) max wet bulb |
| Altitude |
Operating: up to 3,000m (9,850 ft.) @40° C (104° F) Nonoperating: up to 12,000m (40,000 ft.) |
| Acoustic noise | Operating/Idling Acoustic Noise 7.2B (LwAd, 1B=10dB) |
|
Regulations Meets or exceeds the following requirements: |
|
| RoHS Compliance Level | RoHS:Y |
| Safety | UL/CSA-60950-1 2nd edition 2007-03-27, EN60950-1, IEC60950-1 CB Scheme with all country deviations, IEC825-1, 2, CFR21 part 1040, CNS`4336, GB4943 |
| Ergonomics | EK`-ITB-2000 |
| RFI/EMC | EN55022:2006+A1:2007/CISPR22:2005+A1+A2:2006 Class A, 47 CFR 15B Class A, ICES-003 Class A, VCCI Class A, AS/NZ 3548 Class A, CNS 13438 Class A, KSC 5858 Class A, GB9254 Class A,GB17625.1, EN61000-3-3, EN61000-3-3 |
| Immunity | EN55024, IEC 61000-4-2 Electrostatic discharge, IEC 61000-4-3 RF E-field immunity, IEC 61000-4-4 Electrical Fast Transient/Burst, IEC 61000-4-5 Surge, IEC 61000-4-6 RF-Conducted immunity, IEC 61000-4-8 Power frequency magnetic field immunity, IEC 61000-4-11 Voltage dips, short interruptions |
| Telecommunications | EN 300 386, IEC 60068, Telcordia NEBS Level 3 |
| Regulatory Markings | CE, FCC, ICES-003, C-tick, VCCI, GOST-R, BSMI, KCC, UL/cUL, UL/DEMOKO/GS, UL/S-mark, CCC |
| Seismic | GR-63-CORE requirements for earthquake zone 4 |
| Dimensions and Weight | |
| Height | 87.4 mm (3.44 in.) 2 RU |
| Width | 442 mm (17.4 in.) including bezel 425.5 mm (16.75 in.) chassis |
| Depth |
To connector plane: 500 mm (20 in.) Max overall: 525 mm (20.67 in.) |
| Weight | Approximate (without PCI cards) 18.7 kg (41.23 lb.) |
| Service Access Clearance |
Front: 91 cm (36 in.) Rear: 91 cm (36 in.) |
| Batteries | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| n/a | 371-2210 | CR2032 3V Battery, RoHS:Y | ||
| CPU Module | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| X5160 | 371-4488 | 2.13 GHz CPU, L5518 Intel Xeon Quad Core, RoHS:Y | ||
|
|
|||
|
|
|||
| 541-2545 | Xeon Heatsink w/Grease, RoHS:Y | |||
|
|
|||
|
|
|||
| Cables | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| n/a | 530-4439 | Cable Kit, RoHS:Y | ||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
| Communication | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| 6000A | 375-3424 | PCI Express Sun Crypto Accelerator 6000, RoHS:Y | ||
| Disk Backplane | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| n/a | 542-0255 | 2-Drive Cluster, SATA DVD, RoHS:Y | ||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
| n/a | 542-0270 | 4-Drive Cluster, RoHS:Y | ||
|
|
|||
|
|
|||
| Disks | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| RA-SS2ND-300G10K | 540-7867 | 300GB – 10000 RPM SAS, NEBS Compliant Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y | ||
|
|
|||
|
|
|||
| Ethernet | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| 1027A-Z | 501-7283 | PCI Express Dual 10-Gigabit Ethernet Fiber, RoHS:Y | ||
| 5558A-Z | 375-3301 | 10Gb/sec XFP Optical Transceiver Short Range (SR), RoHS:YL | ||
| 7280A-2 | 371-0905 | PCI Express Dual Gigabit Ethernet UTP, RoHS:Y | ||
| X1109A-Z | 375-3617 | Dual 10-Gigabit Ethernet SFP+ LP, RoHS:Y | ||
| X2129A-N | 530-4449 | 10Gbps Short Wave Pluggable (SFP+) Transceiver, RoHS:Y | ||
| X2130A-10M-N | 530-4454 | Sun 10Gbps SFP+ TwinX Cable, 10m, RoHS:Y | ||
| X2130A-1M-N | 530-4441 | Sun 10Gbps SFP+ TwinX Cable, 1m, RoHS:Y | ||
| X2130A-3M-N | 530-4442 | Sun 10Gbps SFP+ TwinX Cable, 3m, RoHS:Y | ||
| X2130A-5M-N | 530-4443 | Sun 10Gbps SFP+ TwinX Cable, 5m, RoHS:Y | ||
| X4446A-Z | 375-3481 | PCI Express Quad Gigabit Ethernet UTP, RoHS:Y | ||
| X4447A-Z | 511-1422 | PCI Express Quad Gigabit Ethernet UTP, RoHS:Y | ||
|
|
|||
| 560-2884 | Ship Kit for Gigabit Ethernet options | |||
| Fan | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| n/a | 371-2701 | PDB Fan (FT2), RoHS:Y | ||
| n/a | 371-4795 | System Fans Assembly (FT 0), RoHS:Y | ||
| n/a | 371-4796 | HDD Fan (FT 1), RoHS:Y | ||
| Fibre Channel | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| SG-XPCIE2FC-QF8-N | 371-4325 | 8Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y | ||
| SG-XPCIE2FC-QF8-Z | 371-4325 | 8Gigabit/Sec PCI Express Dual FC Host Adapter, RoHS:Y | ||
| I/O | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| n/a | 371-4751 | PCI Tray Assembly, RoHS:Y | ||
|
|
|||
|
|
|||
| n/a | 542-0269 | PCI Riser, RoHS:Y | ||
|
|
|||
|
|
|||
|
|
|||
| Memory | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| 5868A | 8GB (1 × 8GB DDR3-1066 DIMM) ATO Option, RoHS:Y | |||
| 371-4285 | 8GB Registered DDR3-1066 DIMM, RoHS:Y | |||
| X4850A | 371-4898 | 4GB Registered DDR3-1333 DIMM, RoHS:Y | ||
| Miscellaneous | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| X4234A-Z | 594-3954 | Air Filter 10-Pack, RoHS:Y | ||
|
|
|||
| X4353A-Z | 594-4536 | Air Filter for 4 Hard Disk Drive Chassis, RoHS:Y | ||
|
|
|||
| Power | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| n/a | 300-2186 | 660 Watt DC Input Power Supply, Type D218, RoHS:Y | ||
| n/a | 300-2299 | 760 Watt AC Input Power Supply, Delta A247A, RoHS:Y | ||
| n/a | 371-4750 | Power Distribution Board, RoHS:YL | ||
| Rack | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| X2089A | 350-1387 | 19″ 2-post Slide Rail Kit, RoHS:Y | ||
| X7901A-4 | 371-1478 | 19″ 2-post Rackmount Kit, RoHS:Y | ||
| X7902A-4 | 371-1481 | 23″ 2-post Rackmount Kit, RoHS:Y | ||
| X7904A-4 | 371-1479 | 600mm x 600mm Rackmount Kit, RoHS:Y | ||
| X8099A-4 | 371-1480 | 19″ 4-post Slide Mount Kit, RoHS:Y | ||
| Removable Media | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| 4358A-Z | 390-0443 | 8x SATA DVD-Writer/24x CD-Writer, RoHS:Y | ||
| SCSI | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| SG-PCIE2SCSIU320Z | 375-3357 | Dual-Channel Ultra320 LVD SCSI PCI Express Adapter, RoHS:Y | ||
| SG-PCIE8SAS-I-Z | 371-3255 | PCI Express 8-Port SAS Controller, RoHS:Y | ||
| SGX-SAS6-R-INT-Z | 371-4746 | 6Gigabit SAS RAID PCI Battery Module, BBU07, RoHS:Y | ||
| 375-3644 | 6Gigabit SAS RAID PCI Express HBA, B2 ASIC, RoHS:Y | |||
| System Board | ||||
|---|---|---|---|---|
| Option # | Manufacturing Part # |
Description | ||
| n/a | 542-0268 | 0MB System Board with Tray, RoHS:Y | ||
|
|
|||
|
|
|||
