Oracle Sun Netra T2000 SERVER

Oracle Sun Netra T2000 SERVER Oracle Sun Netra T2000 SERVER SUN NETRA T2000 SERVER

REQUEST A PRICE QUOTE:

    Name*

    Phone

    Details*

    Processor
    Number 1
    Architecture 1.0/1.2-GHz UltraSPARC T1 Chip Multithreaded (CMT)
    1.2 GHz is 8 core
    1.0 GHz are 4 or 6-core
    CoolThreads Server
    ECO-Responsible Server
    Cache memory 3 MB unified level 2 cache with ECC
    Main Memory
    Capacities DIMM slots per memory controller: 4
    DIMM type: DDR2 ECC registered DIMMs
    DIMM size: 512-MB, 1-GB, 2-GB, or 4-GB
    Maximum capacity: 64GB (when configured with 4-GB DIMMs)
    Note: DIMMS must be installed in sets of 8 (with one pair on each controller). Two basic memory configurations are supported: 2-DIMMs or 4-DIMMs per controller, with a maximum memory configuration of 16 DIMMs. All DIMMs must have identical capacity.
    Standard Integrated Interfaces
    Network Four 10/100/1000 Base-T Ethernet autonegotiating ports
    Network Management One dedicated 10/100Base-T Ethernet port
    Remote Management SC Serial Management port and Net Management port
    USB Rear:Two USB 1.1 ports
    PCI Interfaces One PCI-Express (PCI-E) low-profile X8 (slot 0)
    Three PCI-X full-height 64-bit, 133 MHz card slots. (slots 0 , 1, 2), 2x full length, 1x half height
    Internal Storage
    Disks SFF 2.5-inch form factor, SAS, 10K RPM, 73GB or 146GB, hot-pluggable drives.
    Two disk drive chassis supports up to two drives with support for RAID (0+1).
    Four disk drive chassis supports two, three or four disk RAID 0.
    Removable Media 1 (optional) slimline DVD-R/CD-RW drive
    Power Supplies
    Two hot-swappable, high efficiency 550W (1+1 redundant) power supplies.
    Operating input voltage range AC specification:100 to 240 VAC, 50-60 Hz
    DC specification: -48VDC or -60VDC (nominal)
    Maximum operating input current AC specification:5.4 A at 100 to 120 VAC or 2.6 A at 200 to 240 VAC
    DC specification: 10.4A at -48VDC or 8.3A at -60VDC
    Maximum heat dissipation AC:1,840 BTU/hr
    DC:1,710 BTU/hr
    Nominal Power 300 W
    Space, Watts and Performance (SWaP)
    Space (RU) 2
    Watts 300
    Performance (application tier benchmark) 5300
    Performance/watt 17.667
    SWaP 8.8
    Environment
    Temperature Operating: 5° C to 40° C (41° F to 104° F)
    Non-operating: -40° C to 70° C (-40° F to 158° F)
    Humidity Operating: 5% to 85% relative humidity, noncondensing, 27° C (80.6° F) wet bulb
    Non-operating: up to 93% relative humidity, noncondensing 38° C (100.4 ° F) wet bulb
    Altitude Operating: up to 3000 m (9,850 ft.) @40° C
    Non-operating: up to 12,000 m (40,000 ft.)
    Acoustic noise – LwAd (1 B = 10 dB) Operating: 7.0 B
    Idling: 7.0 B
    Vibration (verify) Operating: 0.2 Gs, Swept sine 5-500-5Hz, 1 octave/min, all axes, IEC 60068-2-13
    Non-operating: 1.0 Gs, Swept sine 5-500-5Hz, 1 octave/min, all axes, IEC 60068-2-13
    Shock(verify) Operating: 5.0 Gs peak 11 msec, half-sine pulse, IEC 60068-2-27
    Non-operating: 30.0 Gs peak 11 msec, half-sine pulse, IEC 60068-2-27
    Cooling 3 hot-swappable and redundant system fans.
    1 hot-swappable blower unit.
    Regulations
    Meets or exceeds the following requirements:
    RoHS Compliance Level RoHS:YL
    Safety UL/CSA-60950-1, EN60950-1, IEC60950-1 CB Scheme with all country deviations, IEC 825-1,2, CFR21 part 1040, CNS 14336, GB4943
    Ergonomics EK1-1TB-2000
    RFI/EMI EN55022 Class A, 47 CFR 15B Class A, ICES-003 Class A, VCCI Class A, AS/NC 3548 Class A, CNS 13438 Class A, KSC 5858 Class A, GB9254 Class A, EN61000-3-2, GB17625.1, EN61000-3-3
    Immunity EN55024, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-1111
    Telecommunications EN300-386, DC only: Telcordia SR 3580 NEBs Level 3
    Regulatory Markings (pending) CE, FCC, ICES-003, C-tick, VCCI, GOST-R, BSMI, MIC, UL/cUL, UL/DEMKO/GS, UL/S-mark, CCC
    Seismic GR-63-CORE requirements for earthquake zone 4
    ETSI EN 300 019-2-1,2,3 Class 1.2, 2.3, 3.1E
    Dimensions and Weight
    Height (2 rack units) 89 mm (3.5 in.)
    Width 424 mm (16.7 in.)
    Depth 508 mm (20 in max.)
    483 mm (19 in. to connector plane)
    Weight, approximate (without PCI cards and rack mounts) 16 kg (35 lb.)
    Batteries
    Option # Manufacturing
    Part #    		 Description
    n/a 150-1204 3V Lithium battery, RoHS:Y
    Cables
    Option # Manufacturing
    Part #    		 Description
    X311L Localized Power Cord Kit – North America/Asia, RoHS:Y
    180-1097 IEC 320 C13 to NEMA 5-15P – 15A/125V 2.5M Black, RoHS:Y
    X312E Localized Power Code Kit – China, RoHS:Y
    180-1982 IEC 320 C13 to GB 2099/GB 1002 – 10A/250V 2.5M, RoHS:Y
    X312F Localized Power Cord Kit – Argentina, RoHS:Y
    180-1999 IEC 320 C13 to IRAM 2073 – 10A/250V 2.5M Black, RoHS:Y
    X312G Localized Power Cord Kit – Korea, RoHS:Y
    180-1662 IEC 320 C13 to KSC 8305 – 15A/250V 2.5M Black, RoHS:Y
    X312L Localized Power Cord Kit – Continental Europe, RoHS:Y
    180-1993 IEC 320 C13 to CEE 7/7 10A/250V 2.5M Black, RoHS:Y
    X314L Localized Power Cord Kit – Swiss, RoHS:Y
    180-1994 IEC 320 C13 to SEV 1011 – 10A/250V 2.5M Black, RoHS:Y
    X317L Localized Power Cord Kit – U.K., RoHS:Y
    180-1997 IEC 320 C13 to BS 1363 – 10A/250V 2.5M Black, RoHS:Y
    X383L Localized Power Cord Kit – Danish, RoHS:Y
    180-1995 IEC 320 C13 to Asfnit 107 – 10A/250V 2.5M Black, RoHS:Y
    X384L Localized Power Cord Kit – Italian, RoHS:Y
    180-1996 IEC 320 C13 to CEI 23-16/VII – 10A/250V 2.5M Black, RoHS:Y
    X386L Localized Power Cord Kit – Australian, RoHS:Y
    180-1998 IEC 320 C13 to AS 3112 – 10A/250V 2.5M Black, RoHS:Y
    n/a 530-3100 RJ45F to DB9F Adapter, RoHS:Y
    n/a 530-3361 CPU/Memory to I/O Board Cable, RoHS:Y
    Communication
    Option # Manufacturing
    Part #    		 Description
    X1355A-2 371-0982 2M, 80-Pin, 4-Port, DB37, RS449 Breakout Cable,RoHS:Y
    375-3296 Quad Port High Speed Serial Interface PCI-X (HSI/U), RoHS:Y
    X1333A-4 375-3418 Infiniband PCI-X Card, RoHS:YL
    n/a 371-1957 Alarm Board Assembly, RoHS:YL
    • 371-1101
    • Alarm Board, RoHS:YL
    • n/a
    • Bracket 340747400014
    • n/a
    • Alarm Board to Motherboard Cable 422747400001
    • n/a
    • Alarm Board to DB-15 Cable 422747400013
    n/a 371-2877 Telco Alarm Board, RoHS:YL
    Disks
    Option # Manufacturing
    Part #    		 Description
    XRA-SS2ND-300G10K 540-7867 300GB – 10000 RPM SAS, NEBS Compliant Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
    • 390-0449
    • Seagate ST93000SSUNG [ST930003SSUN300G]
      (300GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-3004
    • Nemo Bracket with Insulator, RoHS:Y
    XRA-SS2ND-146G10KZ 540-7152 146GB – 10000 RPM SAS, NEBS Compliant Disk Assembly with 1 of the following disks and brackets, RoHS:Y
    • 390-0324
    • Seagate ST9146802SS [ST914602SSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0377
    • Hitachi HUC101414CSS300 [H101414SCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-0239
    • Nemo Bracket, RoHS:Y
    • 541-3004
    • Nemo Bracket with Insulator, RoHS:Y
    XRA-SS2ND-73G10K 540-6643 73GB – 10000 RPM, NEBS, SAS, 2.5″, Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
    • 390-0213
    • Seagate ST973401SS [ST973401SSUN72G]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0285
    • Fujitsu MAY2073RC [MAY2073RCSUN72]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0323
    • Seagate ST973402SS [ST973402SSUN72G]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0376
    • Hitachi HUC101473CSS300 [H101473SCSUN72G]
      (73.4GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-0239
    • Nemo Bracket, RoHS:Y
    • 541-3004
    • Nemo Bracket with Insulator, RoHS:Y
    XRB-SS2ND-146G10K 540-7866 146GB – 10000 RPM SAS, NEBS Compliant Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
    • 390-0377
    • Hitachi HUC101414CSS300 [H101414SCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0448
    • Seagate ST9146803SS [ST914603SSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-3004
    • Nemo Bracket with Insulator, RoHS:Y
    Ethernet
    Option # Manufacturing
    Part #    		 Description
    X4151A-2 501-7430 GigaSwift Ethernet MMF (GFS), RoHS:Y
    X4445A 501-6738 Quad GigaSwift PCI-X Ethernet (QGE-X), RoHS:Y
    X4447A-Z 511-1422 PCI Express Quad Gigabit Ethernet UTP, RoHS:Y
    • 371-2207
    • Bracket Low-Profile, RoHS:Y
    560-2884 Ship Kit for Gigabit Ethernet options
    • 371-2348
    • Bracket Standard, RoHS:Y
    X7280A-2 371-0905 PCI Express Dual Gigabit Ethernet UTP, RoHS:Y
    X7281A-2 371-0904 PCI Express Dual Gigabit Ethernet MMF, RoHS:Y
    n/a 501-7606 PCI Express Quad Gigabit Ethernet UTP, RoHS:Y
    • 371-2207
    • Bracket Low-Profile, RoHS:Y
    • 371-2348
    • Bracket Standard, RoHS:Y
    Fan
    Option # Manufacturing
    Part #    		 Description
    n/a 371-1954 Fan Tray Assembly, RoHS:Y
    n/a 371-1955 HDD Fan Tray Assembly, RoHS:Y
    n/a 371-2736 System Fans Assembly, RoHS:Y
    Fibre Channel
    Option # Manufacturing
    Part #    		 Description
    SG-XPCI2FC-EM4-Z 375-3399 4Gb PCI-X Dual FC Host Adapter, RoHS:Y
    SG-XPCI2FC-QF4 375-3294 4Gb PCI-X Dual FC Host Adapter, RoHS:Y
    SG-XPCI2FC-EM2 375-3305 2Gb PCI-X Dual FC Host Adapter, RoHS:Y
    SG-XPCI2FC-QF2-Z 375-3363 2Gb PCI Dual FC Host Adapter, RoHS:Y
    • 240-4839
    • Low Profile Bracket, RoHS:Y
    Graphics
    Option # Manufacturing
    Part #    		 Description
    X3000A 375-3545 XVR-300 x8 Graphics Accelerator, RoHS:Y
    530-3474 DVI-A(M) to HD15F Adapter, 49mm, RoHS:Y
    530-3998 DMS-59 to Dual DVI-I Cable, 215mm, RoHS:Y
    X3777 375-3433 XVR-200 Graphics Accelerator, RoHS:Y
    I/O
    Option # Manufacturing
    Part #    		 Description
    n/a F371-2368 PCI Assembly, RoHS:YL
    • 371-1099
    • PCI Board, RoHS:YL
    • 371-2368
    • PCI Tray, RoHS:YL
    n/a n/a Tray 541274740005
    Memory
    Option # Manufacturing
    Part #    		 Description
    X7800A 1GB (2 × 512MB DDR2) Memory Expansion Kit, RoHS:Y
    370-6207 512MB DDR2 DIMM, 533 MHz, RoHS:Y
    X7801A 2GB (2 × 1GB DDR2) Memory Expansion Kit, RoHS:Y
    370-6208 1GB DDR2 DIMM, 533 MHz, RoHS:Y
    X7802A 4GB (2 × 2GB DDR2) Memory Expansion Kit, RoHS:Y
    370-6209 2GB DDR2 DIMM, 533 MHz, RoHS:Y
    X7803A 8GB (2 × 4GB DDR2) Memory Expansion Kit
    370-6210 4GB DDR2 DIMM, RoHS:Y
    Miscellaneous
    Option # Manufacturing
    Part #    		 Description
    X4234A-Z 594-3954 Air Filter 10-Pack, RoHS:Y
    • 371-1961
    • Air Filter, RoHS:Y
    X4353A-Z 594-4536 Air Filter for 4 Hard Disk Drive Chassis, RoHS:Y
    • 371-2555
    • Air Filter for 4 Hard Disk Drive Chassis, RoHS:Y
    X949A-4 594-2682 Wago DC Connector Set (10 pack), RoHS:Y
    • 130-6352
    • Wago DC Connector, RoHS:Y
    • 230-4652
    • Wago DC Connector Strain Relief, RoHS:Y
    • 230-4653
    • Wago DC Connector Opening Lever, RoHS:Y
    Power
    Option # Manufacturing
    Part #    		 Description
    n/a 300-1852 AC Input Power Supply (Type A214), RoHS:YL
    n/a 300-2006 DC -48VDC 550W Power Supply (Type D193), RoHS:YL
    n/a 371-1098 Power Distribution Board, RoHS:YL
    • n/a
    • PDB J3 to Disk Drive Interface J6 Cable 422747400007
    Rack
    Option # Manufacturing
    Part #    		 Description
    X2089A 350-1387 19″ 2-post Slide Rail Kit, RoHS:Y
    X7901A-4 371-1478 19″ 2-post Rackmount Kit, RoHS:Y
    X7902A-4 371-1481 23″ 2-post Rackmount Kit, RoHS:Y
    X7904A-4 371-1479 600mm x 600mm Rackmount Kit, RoHS:Y
    X8099A-4 371-1480 19″ 4-post Slide Mount Kit, RoHS:Y
    Removable Media
    Option # Manufacturing
    Part #    		 Description
    X4356A-Z DVD-Writer/CD-Writer, RoHS:YL
    371-2261 DVD-ROM / CD-ROM Drive Bezel, RoHS:Y
    540-7563 DVD-Writer/CD-Writer, PATA, RoHS:Y
    • 390-0337
    • 8x PATA DVD-Writer/24x CD-Writer, RoHS:Y
    • 390-0403
    • 8x PATA DVD-Writer / 24x CD-Writer, RoHS:Y
    X4352A-Z 8× Slimline DVD-RW Drive Assembly, RoHS:YL
    390-0337 8x PATA DVD-Writer/24x CD-Writer, RoHS:Y
    n/a 390-0251 Slimline 8X DVD-ROM / 24X CD-Writer,RoHS:Y
    SCSI
    Option # Manufacturing
    Part #    		 Description
    SG-XPCIE2SCSIU320Z 375-3357 Dual-Channel Ultra320 LVD SCSI PCI Express Adapter, RoHS:Y
    SGXPCI2SCSILM320-Z 375-3365 PCI Dual Ultra320 SCSI Adapter, RoHS:YL
    SG-XPCI2SCSI-LM320 375-3191 PCI/PCI-X Dual Ultra320 SCSI Adapter
    System Board
    Option # Manufacturing
    Part #    		 Description
    n/a 525-2146 SSCC NVRAM, RoHS:Y
    n/a 541-1438 0MB 6-Core 1.0GHz System Board, RoHS:YL
    • 541-1437-01
    • System Board Assembly w/o UltraSPARC T1, RoHS:YL
    • 501-7501
    • CPU/Memory Board, RoHS:YL
    • 501-7502-01
    • I/O Board, RoHS:YL
    • 530-3361
    • CPU/Memory to I/O Board Cable, RoHS:Y
    n/a 541-1453 0MB 8-Core 1.2GHz System Board, RoHS:YL
    • 541-1437-01
    • System Board Assembly w/o UltraSPARC T1, RoHS:YL
    • 501-7501
    • CPU/Memory Board, RoHS:YL
    • 501-7502-01
    • I/O Board, RoHS:YL
    • 530-3361
    • CPU/Memory to I/O Board Cable, RoHS:Y
    n/a 541-1455 0MB 4-Core 1.0GHz System Board, RoHS:YL
    • 541-1437-01
    • System Board Assembly w/o UltraSPARC T1, RoHS:YL
    • 501-7501
    • CPU/Memory Board, RoHS:YL
    • 501-7502-01
    • I/O Board, RoHS:YL
    • 530-3361
    • CPU/Memory to I/O Board Cable, RoHS:Y
    n/a 541-2405 0MB 6-Core 1.0GHz System Board, RoHS:YL
    • 541-1437-02
    • System Board Assembly w/o UltraSPARC T1, RoHS:YL
    • 501-7501
    • CPU/Memory Board, RoHS:YL
    • 501-7502-02
    • I/O Board, RoHS:YL
    • 530-3361
    • CPU/Memory to I/O Board Cable, RoHS:Y
    n/a 541-2407 0MB 8-Core 1.2GHz System Board, RoHS:YL
    • 541-1437-02
    • System Board Assembly w/o UltraSPARC T1, RoHS:YL
    • 501-7501
    • CPU/Memory Board, RoHS:YL
    • 501-7502-02
    • I/O Board, RoHS:YL
    • 530-3361
    • CPU/Memory to I/O Board Cable, RoHS:Y
    n/a 541-2409 0MB 4-Core 1.0GHz System Board, RoHS:YL
    • 541-1437-02
    • System Board Assembly w/o UltraSPARC T1, RoHS:YL
    • 501-7501
    • CPU/Memory Board, RoHS:YL
    • 501-7502-02
    • I/O Board, RoHS:YL
    • 530-3361
    • CPU/Memory to I/O Board Cable, RoHS:Y
    System Service Processor
    Option # Manufacturing
    Part #    		 Description
    n/a 371-1962 Service Processor Assembly, RoHS:YL
    • 371-1100
    • Service Processor Riser, RoHS:YL
    • 371-1965
    • Service Processor, RoHS:YL
    • 150-1204
    • 3V Lithium battery, RoHS:Y
    • 525-2146
    • SSCC NVRAM, RoHS:Y
    • n/a
    • Bracket 340747400006

    Industry Leading Quality, Support and Integrity

    Quality Inspection Checklist
    Before it leaves our facility, every used and refurbished item is thoroughly inspected by our certified technicians and undergoes our exclusive Quality Inspection Checklist to ensure 100% satisfaction guarantee.

    Greentec Systems is a leading provider
    For server, networking and storage equipment. We have an extensive array of inventory of IBM Servers & Storage, Sun Servers & Storage, Cisco Networking (Switches, Routers, Security), and NetApp Storage (disk shelves, disk drives, Filers, NearStore, NetCache). If you don’t see the item or product you require please contact us.

    Have this equipment to sell?
    Depending on the age and condition of the equipment, there is a very good likelihood that we will be able to offer you cash or trade-in credit for other IT hardware. If the equipment is very old we can also assist you with properly decommissioning that gear in the most environmentally friendly way possible.

    Questions?
    For more information please contact 888.333.7388, or fill out the quote from above. We’d love to hear from you.

    Request Quote
    Greentec Systems We geek out helping you with your IT infrastructure.
    Request a quote or product information
    Send
