    Oracle Sun Netra SPARC T4-1 server is the first SPARC T4 processor based system with throughput offering 2x the I/O bandwidth and 5x improvement in single threaded performance over the previous generation Netra SPARC server, all in a compact 20 inch deep 2 RU chassis. Designed to meet the most demanding telecommunication Web, media services, OSS/BSS, and BRM workloads, the Netra SPARC T4-1 is the ideal platform for consolidation and virtualization of the data center.

    The Netra SPARC T4-1 server Product Overview is powered by the SPARC T4 processor (8-core and 4-core) featuring integrated on-chip cryptographic support, providing wire speed encryption capabilities. This server offers 16 DIMM slots, which can support a total of 256GB of memory, four hot-pluggable 2.5 inch drives or SSD plus DVD, integrated 10GbE networking, and builtin PCI Express Generation 2 expansion. Oracle Solaris and virtualization software such as the Oracle Solaris Zones and Oracle VM Server for SPARC technology make the Netra SPARC T4-1 a cost effective platform for large-scale telecommunication data center consolidation. The Netra SPARC T4-1 provides a network infrastructure solution with carrier-grade reliability leveraging the chassis from previous generation, hot swappable components such as high efficiency AC or DC power supplies and disk drives. The Netra SPARC T4-1 comes integrated at no additional cost with Integrated Lights Out Manager (ILOM) service processor that offers industry-standard protocols for standalone system management as well as integration with many industry leading management systems.

    Brand: Oracle / Sun Microsystems
    Condition: Refurbished and new (limited availability)
    Availability: Contact
    Shipping Area: Worldwide to most countries
    Shipping Method: Fedex (most orders), UPS, DHL, Freight Courier
    Price: Please use the quote form above for quick pricing
    Payment: Credit Card, Check, Net Terms (oac), Wire Transfer (required for international orders)
    Guarantee: All items are tested by Oracle trained technicians & backed by a 100% warranty
    Questions? Don’t hesitate to contact us with any questions regarding compatibility or other product info and requests. Our website represents only a fraction of our full inventory. Please reach out with your full requirements



    Specs and Information Oracle Sun Netra SPARC T4-1 server:



    Processor
    Number One 4-Core SPARC T4 2.85GHz
    or
    One 8-Core SPARC T4 2.85GHz
    Architecture SPARC V9 architecture, ECC protected
    CPUs
    • 2.85GHz 4-core or 8-core SPARC T4
    • 4-core 32 threads
    • 8-core 64 threads
    • up to 8 floating-point units
    • On-chip encryption instruction accelerators with direct non-privileged support for 16 industry standard cryptographic algorithms plus random number generation in each of the 8-cores: AES, Camellia, CRC32c, DES, 3DES, DH, DSA, ECC, Kasumi, MD5, RSA, SHA-1, SHA-224, SHA-256, SHA-384, SHA-512
    Cache memory
    • Level 1: 16KB instruction cache and 16K data cache per core
    • Level 2: 128KB cache per core
    • Level 3: Shared 4MB cache
    Main Memory
    Capacities
    • Total DIMM slots: 16 on system board
    • DIMM type: DDR3
    • DIMM size: 4GB, 8GB, and 16GB
    • Maximum capacity: 256GB (16 × 16GB)
    Standard Integrated Interfaces
    Network 4 × 10/100/1000 Mbps auto negotiating ports
    Up to 2 optional 10 GbE XAUI connections
    Network Management One dedicated 10/100Base-T RJ-45 port Ethernet port
    Serial Management One dedicated RJ-45 port
    Remote Management Onboard system processor, running Integrated Lights Out Manager (ILOM)
    Graphics One HD-15 VGA connector
    USB Front: 2 USB 2.0 Ports
    Rear: 2 USB 2.0 Ports
    PCI Expansion Slots
    • Five PCIe Gen2 x8 slots (including support of two full height half length PCIe cards slots and three low profile cards slots or two XAUI)
    • Slots 0 and 1 support PCI-Express or XAUI cards.
    Slot # Physical Electrical
    0 x8 x8
    1 x8 x8
    2 x8 x8
    3 x16 x8
    4 x16 x8
    Internal Mass Storage
    Disks
    • Up to four 2.5-inch SAS-2 disk drives
    • 300GB, 400GB or 600GB 2.5-inch SAS disk drives
    • RAID 0 and RAID 1 support
    DVD-ROM 1 slimline SATA DVD Drive
    Power Supplies
    2 × 1200 Watt (Type A249A AC or Type D204A DC), hot-swappable, N+1 redundant power supply units (PSU)
    Environment
    Power Consumption Online power calculator
    Input Voltage (AC) 100 – 240 VAC, 50-60Hz
    (DC) -48 VDC or -60 VDC
    Temperature Operating: 5° C to 45° C (41° F to 113° F)
    Short Term Operating: -5° C to 55° C (23° F to 131° F)
    Nonoperating: -40° C to 70° C (-40° F to 158° F)
    Humidity Operating: 5% to 85% relative humidity noncondensing
    Short Term Operating: 5% to 90% relative humidity noncondensing, but not to exceed 0.024 kg water/kg dry air (0.053 lb. water/2.205 lbs. dry air)
    Nonoperating: 93% relative humidity noncondensing, 40° C, 104° F) maximum wet bulb
    Altitude Operating: Meeets NEBS 4000m (13,123 ft) requirement
    Nonoperating: up to 12000m (39,370 ft.)
    Seismic GR-63-CORE requirements for Earthquake Zone 4
    Acoustic Noise Operating/Idling: 7.2 B (LwAd, 1B = 10dB)
    NEBS NEBS Level3 certified by Telecordia
    Regulations
    Meets or exceeds the following requirements:
    Safety UL/CSA C22.2 60950-1, 2nd Edition EN 60950-1, 2nd Edition, IEC 60950-1 :2005 2nd Edition CB Scheme with all national differences, IEC 825-1,2 and CFR21 part 1040
    RFI/EMI EN55022:2006+A1:2007/CISPR22:2005+A1:2005+A2:2006 EN300 386 V1.4.1 Class A, FCC CFR 47 Part 15 Class A
    Immunity EN55024/CISPR 24, EN 61000-3-2, EN 61000-3-3
    Regulatory Markings CE, FCC, ICES-003, C-tick, VCCI, GOST-R, BSMI, MIC, UL/cUL, S-mark, CCC
    Other Restriction of Hazardous Substances (RoHS) labeled, per WEEE (Waste Electrical and Electronics Equipment) Directive (2002/95/EC)
    Telecommunications EN 300 386
    Dimensions and Weight
    Height 87.1 mm (3.43 in.)
    Width 445 mm (17.52 in.) including bezel
    Depth 526 mm (20.71 in.) max to PSU handles
    Depth 501 mm (19.72 in.) max to rear I/O
    Weight 18.6kg (41 lbs) – fully configured without PCI cards installed
    Batteries
    Option # Manufacturing
    Part #    		 Description Previous
    Part #
    n/a 371-2210 [C] 3V Lithium Coin Cell Battery n/a
    Cables
    Option # Manufacturing
    Part #    		 Description Previous
    Part #
    X2130A-1M-N 530-4441 [C] 10Gbps SFP+ TwinX Cable, 1m n/a
    X2130A-3M-N 530-4442 [C] 10Gbps SFP+ TwinX Cable, 3m n/a
    X2130A-5M-N 530-4443 [C] 10Gbps SFP+ TwinX Cable, 5m n/a
    X333V-20-15-C14-N 7040692 [C] IEC 320 C13 to IEC 320 Sheet E – 10A/250V 2.0M 180-2442 [C]
    X333V-30-15-C14-N 7040693 [C] IEC 320 C13 to IEC 320 Sheet E, 10A, 3M 180-2443 [C]
    X8224A-N 1 SAS Cable Kit
    530-4088 [C] 4× Mini SAS Cable, 90° SFF-8087 to 90° SFF-8087 n/a
    X9237-1-A-N 180-2082 [C] IEC 320 Sheet E to IEC 320 C13 Power Jumper Cord 13A 90° 1.0M n/a
    X9238-1-A-N 180-2085 [C] IEC 320 Sheet E to IEC 320 C13 Power Jumper Cord 13A 90° 2.5M n/a
    n/a 180-2442 [C] IEC 320 C13 to IEC 320 Sheet E – 15A/250V 2.0M n/a
    n/a 180-2443 [C] IEC 320 C13 to IEC 320 Sheet E – 15A/250V 3.0M n/a
    n/a 530-3100 RJ45F to DB9F Adapter n/a
    1 Used with SGX-SAS6-R-INT-Z
    NOTE: Disk Backplane, System Board, Fan Board, PCI Mezzanine and PDB cables ship with Signal Interface Board part number 371-4939 or 7070187.
    Communication
    Option # Manufacturing
    Part #    		 Description Previous
    Part #
    X6000A-N [S] 375-3424 [C] PCI Express Sun Crypto Accelerator 6000 n/a
    Disk Backplane
    Option # Manufacturing
    Part #    		 Description Previous
    Part #
    n/a 371-4941 [C] 4-Slot Disk Backplane n/a
    • n/a
    • 90 ° SFF-8087 to 90 ° SFF-8087 Cable R0350-C0001-01
    		 n/a
    n/a 7070220 [C] 4-Slot Disk Backplane 371-4941 [C]
    • 7069525
    • 90 ° SFF-8087 to 90 ° SFF-8087 Cable R0350-C0001-01
    		 n/a
    Disks
    Option # Manufacturing
    Part #    		 Description Previous
    Part #
    7107550 7077233 [C] 400GB Solid State SATA Drive Assembly n/a
    • 7076379
    • Intel SSDSC2BA400G3S [ITVSC2BA3SUN400] (400GB – 2.5″ Solid State – SATA-3 Disk)
    		 n/a
    • 541-2123
    • Marlin 2.5″ Bracket
    		 n/a
    7111108 7093037 [C] 1.2TB – 10000 RPM SAS SFF Disk Assembly w 1 bracket and 1 of the following disks: n/a
    • 7093035
    • Hitachi HUC101812CSS200 [H101812SFSUN1.2T] (1.2TB – 10000 RPM – SAS DISK)
    		 n/a
    • 541-2123
    • Marlin 2.5″ Bracket
    		 n/a
    XRA-SS2NF-300G10K2 542-0422 [C] 300GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks: n/a
    • 390-0487
    • Hitachi HUC106030CSS600 [H106030SDSUN300G] (300GB – 10000 RPM – SAS Disk)
    		 n/a
    • 390-0490
    • Seagate ST9300605SS [ST930005SSUN300G](300GB 10000 RPM SAS Disk)
    		 n/a
    • 7045226
    • Hitachi HUC109030CSS600 [H109030SESUN300G] (300GB – 10000 RPM – SAS Disk)
    		 n/a
    • 541-2123
    • Marlin 2.5″ Bracket
    		 n/a
    XRA-SS2NF-600G10K2 542-0423 [C] 600GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks: n/a
    • 390-0488
    • Hitachi HUC106060CSS600 [H106060SDSUN600G] (600GB – 10000 RPM – SAS Disk)
    		 n/a
    • 390-0491
    • Seagate ST9600205SS [ST960005SSUN600G](600GB 10000 RPM SAS Disk)
    		 n/a
    • 7045228
    • Hitachi HUC109060CSS600 [H109060SESUN600G] (600GB – 10000 RPM – SAS Disk)
    		 n/a
    • 541-2123
    • Marlin 2.5″ Bracket
    		 n/a
    Ethernet
    Option # Manufacturing
    Part #    		 Description Previous
    Part #
    7100477 7070195 [C] Quad Port GbE PCI Express 2.0 Low Profile Adapter, UTP 7048474 [C]
    7100481 7070202 [C] Dual Port GbE PCI Express 2.0 Low Profile Adapter, MMF 7014747 [C]
    7100488 7070006 [C] Dual 10-Gigabit Base-T PCI Express Gen2 7014776 [C]
    SE3X7XA1Z 501-7489 2 [C] 10GbE XAUI Card n/a
    SE3X7XT1Z 375-3301 [C] 10Gb/sec XFP Optical Transceiver Multi Mode Short Range (SR) n/a
    7058828 [C] 10Gb/sec XFP Optical Transceiver Multi Mode Short Range (SR) 375-3301 [C]
    SE3X7XT2Z 375-3495 [C] 10Gb/Sec XFP Optical Transceiver Single Mode Long Range (LR) n/a
    X1109A-Z 7051223 [C] Dual 10-Gigabit PCI Express Ethernet SFP+ LP 375-3617 [C]
    X2129A-N 530-4449 [C] 10Gb/Sec Short Wave SFP+ Transceiver n/a
    X5562A-Z 135-1205 [C] 10Gb/Sec Long Wave SFP+ Transceiver n/a
    X4447A-Z-N [S] 7055021 [C] Quad Port GbE PCI Express, UTP 511-1422 [C]
    • 371-2207
    • Bracket Low-Profile
    		 n/a
    X7280A-2-N [S] 371-0905 [C] PCI Express Dual Gigabit Ethernet UTP n/a
    X7281A-2-N [S] 7056733 [C] PCI Express Dual Gigabit Ethernet MMF 371-0904 [C]
    n/a 371-0904 [C] PCI Express Dual Gigabit Ethernet MMF n/a
    n/a 375-3617 [C] Dual 10-Gigabit Ethernet SFP+ LP n/a
    n/a 511-1422 [C] Quad Port GbE PCI Express, UTP n/a
    • 371-2207
    • Bracket Low-Profile
    		 n/a
    n/a 7014741 [C] Quad Port GbE PCI Express 2.0 Low Profile Adapter, UTP n/a
    n/a 7014747 [C] Dual Port GbE PCI Express 2.0 Low Profile Adapter, MMF n/a
    n/a 7014776 [C] Dual 10-Gigabit Base-T PCI Express Gen2 n/a
    n/a 7048474 [C] Quad Port GbE PCI Express 2.0 Low Profile Adapter, UTP 7014741 [C]
    2 Requires one XFP Transceiver
    Fan
    Option # Manufacturing
    Part #    		 Description Previous
    Part #
    n/a 351-0011 [C] Dual System Fan FM0-FM4 n/a
    n/a 351-0012 [C] Disk Drive Fan FM5 n/a
    Fibre Channel
    Option # Manufacturing
    Part #    		 Description Previous
    Part #
    7101674 7023303 [C] Dual 16Gigabit/Sec Fibre Channel / 10Gbps FCoE Host Adapter, QLogic n/a
    7101676 7023325 [C] Pair of 16Gbps Short Wave SFP+ n/a
    • 7023324
    • 16Gb/Sec Short Wave SFP+ Transceiver, QLogic
    		 n/a
    7101678 7023315 [C] Pair of 10Gbps Short Wave SFP+ n/a
    • 7023316
    • 10Gb/Sec Short Wave SFP+ Transceiver, QLogic
    		 n/a
    7101684 7023036 [C] Dual 16Gigabit/Sec Fibre Channel / 10Gbps FCoE Host Adapter, Emulex n/a
    7101686 7023059 [C] Pair of 16Gbps Short Wave SFP+ n/a
    • 7023053
    • 16Gb/Sec Short Wave SFP+ Transceiver, Emulex
    		 n/a
    7101688 7023057 [C] Pair of 10Gbps Short Wave SFP+ n/a
    • 7023046
    • 10Gb/Sec Short Wave SFP+ Transceiver, Emulex
    		 n/a
    SG-XPCIE2FC-EM8-N 7053434 [C] 8Gigabit/Sec PCI Express Dual FC Host Adapter 371-4306 [C]
    SG-XPCIE2FC-QF8-N 371-4325 [C] 8Gigabit/Sec PCI Express Dual FC Host Adapter n/a
    n/a 371-4306 [C] 8Gigabit/Sec PCI Express Dual FC Host Adapter n/a
    I/O
    Option # Manufacturing
    Part #    		 Description Previous
    Part #
    n/a 371-4942 [C] PCI Express Mezzanine n/a
    n/a 542-0382 [C] PCI Express Riser Kit n/a
    • 371-4944
    • PCI Express Riser 0
    		 n/a
    • 371-4945
    • PCI Express Riser 1
    		 n/a
    • 371-4946
    • PCI Express Riser 2
    		 n/a
    n/a 542-0391 [C] Slot-Load DVD Tray Assembly (without DVD) n/a
    • 371-4940
    • Fan Control Board
    		 n/a
    • 371-4943
    • LED Board
    		 n/a
    • n/a
    • Fan Control Board to DVD Cable R0350-C0004-01
    		 n/a
    • n/a
    • DVD Tray Kit R0350-F0005-01
    		 n/a
    n/a 7052375 [C] PCI Express Mezzanine 371-4942 [C]
    n/a 7052388 [C] PCI Express Riser Kit [SKU] n/a
    • 7052372
    • PCI Express Riser 0
    		 n/a
    • 7052373
    • PCI Express Riser 1
    		 n/a
    • 7052390
    • PCI Express Riser 2
    		 n/a
    n/a 7068370 [C] Slot-Load DVD Tray Assembly (without DVD) n/a
    • 371-4940
    • Fan Control Board
    		 n/a
    • 7070222
    • LED Board
    		 n/a
      • 7069526
      • Fan Control Board to DVD Cable R0350-C0004-01
    		 n/a
      • 7069529
      • DVD Tray Kit R0350-F0005-01
    		 n/a
    n/a 7082729 [C] Tray-Load DVD Tray (without DVD) n/a
    • 371-4940
    • Fan Control Board
    		 n/a
    • 7070222
    • LED Board
    		 n/a
      • 7069526
      • Fan Control Board to DVD Cable R0350-C0004-01
    		 n/a
      • 7069529
      • DVD Tray Kit R0350-F0005-01
    		 n/a
    Memory
    Option # Manufacturing
    Part #    		 Description Previous
    Part #
    7104931 16GB Memory Expansion (1 × 16GB) Option
    7051724 3 [C] 16GB DDR3L-1600/PC3L-12800 DIMM n/a
    7101696 [S] 8GB Memory Expansion (2 × 4GB) Option
    7014642 [C] 4GB DDR3L-1333/PC3L-10600 DIMM n/a
    7102494 [S] 16GB Memory Expansion (2 × 8GB) Option
    7041271 [C] 8GB DDR3L-1333/PC3L-10600 DIMM n/a
    7102495 [S] 32GB Memory Expansion (2 × 16GB) Option
    7041272 [C] 16GB DDR3L-1333/PC3L-8500 DIMM n/a
    7105237 [S] 8GB Memory Expansion (1 × 8GB) Option
    7041271 [C] 8GB DDR3L-1333/PC3L-10600 DIMM n/a
    3 Cannot be mixed with 7041272.
    Miscellaneous
    Option # Manufacturing
    Part #    		 Description Previous
    Part #
    n/a 351-0014 [C] Air Filter n/a
    n/a 560-2958 Netra SPARC T3-1/T4-1 Ship Kit n/a
    • 530-2889
    • RJ45 to DB25 Serial Port Adapter
    		 n/a
    • 530-3100
    • RJ45F to DB9F Adapter
    		 n/a
    • 530-4001
    • RJ45M to RJ45F Extender, 30mm
    		 n/a
    • 7070225 [C]
    • Air Filter
    		 351-0014 [C]
    Power
    Option # Manufacturing
    Part #    		 Description Previous
    Part #
    n/a 300-2304 [C] Type A249A 1100/1200 Watt AC Input Power Supply n/a
    n/a 300-2305 [C] Type D204A 1200 Watt DC Input Power Supply n/a
    n/a 371-4938 [F] Power Distribution Board n/a
    n/a 371-4939 [C] Signal Interface Board n/a
    • n/a
    • Signal Interface Board to 4-Slot Disk Backplane Cable R0350-C0003-01
    		 n/a
    • n/a
    • Signal Interface Board to PCI Express Mezzanine Cable R0350-C0009-01
    		 n/a
    • n/a
    • Signal Interface Board to Fan Control Board Cable R0350-C0008-01
    		 n/a
    • n/a
    • Signal Interface Board to System Board Cable R0350-C0006-01
    		 n/a
    • n/a
    • Signal Interface Board to System Board Cable R0350-C0007-01
    		 n/a
    • n/a
    • Signal Interface Board to Fan Control Board Cable R0350-C0009-01
    		 n/a
    • n/a
    • Signal Interface Board to Power Distribution Board Cable R0350-C0010-01
    		 n/a
    n/a 565-1962 [C] Wago DC Connector Set n/a
    • 130-6940
    • Wago DC Connector
    		 n/a
    • 230-4851
    • Wago DC Connector Clamp Tool
    		 n/a
    n/a 7048339 [C] Type D204A 1200 Watt DC Input Power Supply 300-2305 [C]
    n/a 7057652 [F] Power Distribution Board 371-4938 [F]
    n/a 7070187 [C] Signal Interface Board 371-4939 [C]
    • 7069532
    • Signal Board to Disk Backplane Cable R0350-C0003-01
    		 n/a
    • 7069533
    • Signal Board to System Board Cable R0350-C0006-01
    		 n/a
    • 7069534
    • Signal Board to System Board Cable R0350-C0007-01
    		 n/a
    • 7069539
    • Signal Board to Fan Board Cable R0350-C0008-01
    		 n/a
    • 7069540
    • Signal Board to Fan Control Board Cable R0350-C0009-01
    		 n/a
    • 7069540
    • Signal Board to PCI Mezzanine Cable R0350-C0009-01
    		 n/a
    • 7069541
    • Signal Board to PDB Cable R0350-C0010-01
    		 n/a
    n/a 7081590 [C] Type A249A 1100/1200 Watt AC Input Power Supply 300-2304 [C]
    n/a 7087767 [C] Type D204A 1200 Watt DC Input Power Supply n/a
    Rack
    Option # Manufacturing
    Part #    		 Description Previous
    Part #
    X7901A-4-N 371-1478 19″ 2-post Rackmount Kit n/a
    X8099A-4-N 371-1480 19″ 4-post Slide Mount Kit n/a
    X2089A-N [S] 350-1387 19″ 2-post Slide Rail Kit n/a
    X7902A-4-N [S] 371-1481 23″ 2-post Rackmount Kit n/a
    X7904A-4-N [S] 371-1479 600mm x 600mm Rackmount Kit n/a
    Removable Media
    Option # Manufacturing
    Part #    		 Description Previous
    Part #
    n/a 390-0486 [C] 8x Slot-Load SATA DVD-Writer/24x CD-Writer n/a
    n/a 7045772 [C] 8x Slot-Load SATA DVD-Writer/24x CD-Writer n/a
    n/a 7071296 4 [C] 8x Tray-Load SATA DVD-ROM Writer / 24x CD-ROM Writer n/a
    n/a 7089963 5 [C] 8x Tray-Load DVD-ROM/24-x CD-ROM Writer (Gen5) n/a
    4 The Tray-Load DVD was added to the system in July 2014. The Tray-Load DVD is not compatible with Chassis 351-0008, 7046318, or 7070185. The Tray-Load DVD is not compatible with DVD Tray 542-0391 or 7068370.
    5 The Tray-Load DVD was added to the system in July 2014. The Tray-Load DVD is not compatible with Chassis 351-0008, 7046318, or 7070185. The Tray-Load DVD is not compatible with DVD Tray 542-0391 or 7068370.
    SCSI
    Option # Manufacturing
    Part #    		 Description Previous
    Part #
    7105387 8-Port 6Gbps SAS-2 PCI Express HBA
    7047853 [C] 8-Port 6Gbps SAS-2 PCI Express HBA (LSI) 375-3641 [C]
    SGX-SAS6-R-INT-Z 6 7 7047503 [C] 8-Port 6Gbps SAS-2 RAID PCI Express HBA, B4 ASIC 375-3701 [C]
    7050794 [C] 6Gbps SAS-2 RAID PCI Battery Module, BBU08 371-4982 [C]
    7105384 [S] Dual-Channel Ultra320 LVD SCSI PCI Express Adapter for EU Countries
    7050790 [C] Dual-Channel Ultra320 LVD SCSI PCI Express Adapter 375-3357 [C]
    SGX-SAS6-EXT-Z [S] 7047853 [C] 8-Port 6Gbps SAS-2 PCI Express HBA (LSI) 375-3641 [C]
    SGXPCIE2SCSIU320-N [S] 7050790 [C] Dual-Channel Ultra320 LVD SCSI PCI Express Adapter 375-3357 [C]
    n/a 371-4982 [C] 6Gbps SAS-2 RAID PCI Battery Module, BBU08 n/a
    n/a 375-3357 [C] Dual-Channel Ultra320 LVD SCSI PCI Express Adapter n/a
    n/a 375-3641 [C] 8-Port 6Gbps SAS-2 PCI Express HBA (LSI) n/a
    n/a 375-3701 [C] 8-Port 6Gbps SAS-2 RAID PCI Express HBA, B4 ASIC n/a
    6 Use SAS Cable Kit X8224A-N with this card.
    7 Install this card in Slot 0 only
    System Board
    Option # Manufacturing
    Part #    		 Description Previous
    Part #
    n/a 7022520 [F] 8-Core 2.85GHz System Board Assembly n/a
    • 310-0276
    • Heatsink
    		 n/a
    • 371-2210 [C]
    • 3V Lithium Coin Cell Battery
    		 n/a
    • 7015696
    • System Board
    		 n/a
      • 525-2146 [F]
      • SSCC NVRAM
    		 n/a
    n/a 7042220 [F] 4-Core 2.85GHz System Board Assembly n/a
    • 310-0276
    • Heatsink
    		 n/a
    • 371-2210 [C]
    • 3V Lithium Coin Cell Battery
    		 n/a
    • 7015696
    • System Board
    		 n/a
      • 525-2146 [F]
      • SSCC NVRAM
    		 n/a
    n/a 7051509 [F] 8-Core 2.85GHz System Board Assembly 7022520 [F]
    • 310-0276
    • Heatsink
    		 n/a
    • 371-2210 [C]
    • 3V Lithium Coin Cell Battery
    		 n/a
    • 7047135
    • System Board
    		 n/a
      • 525-2146 [F]
      • SSCC NVRAM
    		 n/a
    n/a 7051608 [F] 4-Core 2.85GHz System Board Assembly 7042220 [F]
    • 310-0276
    • Heatsink
    		 n/a
    • 371-2210 [C]
    • 3V Lithium Coin Cell Battery
    		 n/a
    • 7047135
    • System Board
    		 n/a
      • 525-2146 [F]
      • SSCC NVRAM
    		 n/a
    n/a 7077942 8 [F] 8-Core 2.85GHz System Board Assembly 7051509 [F]
    • 310-0276
    • Heatsink
    		 n/a
    • 371-2210 [C]
    • 3V Lithium Coin Cell Battery
    		 n/a
    • 7063382
    • System Board
    		 n/a
      • 525-2146 [F]
      • SSCC NVRAM
    		 n/a
    n/a 7077944 9 [F] 4-Core 2.85GHz System Board Assembly 7051608 [F]
    • 310-0276
    • Heatsink
    		 n/a
    • 371-2210 [C]
    • 3V Lithium Coin Cell Battery
    		 n/a
    • 7063382
    • System Board
    		 n/a
      • 525-2146 [F]
      • SSCC NVRAM
    		 n/a
    n/a 7302446 [F] 2.85GHz 8-Core System Board Assy n/a
    • 7047135
    • System Board
    		 n/a
      • 525-2146 [F]
      • SSCC NVRAM
    		 n/a
    n/a 7302447 [F] 2.85GHz 4-Core System Board Assembly n/a
    • 7047135
    • System Board
    		 n/a
      • 525-2146 [F]
      • SSCC NVRAM
    		 n/a
    8 System Board 7077942 requires minimum system firmware 8.4.2.d due to component changes at U6002, U6202, U13501, and U13601.
    9 System Board 7077944 requires minimum system firmware 8.4.2.d due to component changes at U6002, U6202, U13501, and U13601.
    System Service Processor
    Option # Manufacturing
    Part #    		 Description Previous
    Part #
    n/a 7022521 [C] Service Processor n/a
    • 511-1336
    • AST2200 Service Processor
    		 n/a
    n/a 7054793 [C] Service Processor 7022521 [C]
    • 7053714
    • AST2200 Service Processor
    		 n/a
    n/a 7070221 [C] Service Processor n/a
    • 7053714
    • AST2200 Service Processor
    		 n/a

    Industry Leading Quality, Support and Integrity

    Quality Inspection Checklist
    Before it leaves our facility, every used and refurbished item is thoroughly inspected by our certified technicians and undergoes our exclusive Quality Inspection Checklist to ensure 100% satisfaction guarantee.

    Greentec Systems is a leading provider
    For server, networking and storage equipment. We have an extensive array of inventory of IBM Servers & Storage, Sun Servers & Storage, Cisco Networking (Switches, Routers, Security), and NetApp Storage (disk shelves, disk drives, Filers, NearStore, NetCache). If you don’t see the item or product you require please contact us.

    Have this equipment to sell?
    Depending on the age and condition of the equipment, there is a very good likelihood that we will be able to offer you cash or trade-in credit for other IT hardware. If the equipment is very old we can also assist you with properly decommissioning that gear in the most environmentally friendly way possible.

    Questions?
    For more information please contact 888.333.7388, or fill out the quote from above. We’d love to hear from you.

    Request Quote
    Greentec Systems We geek out helping you with your IT infrastructure.
    Request a quote or product information
    Send
