Sun Netra 240 Specs Dimensions and Parts List – Greentec Systems
Racking
|
| Fits into a standard 19-inch wide rack. Rack kit included 19-inch 4 post. Additional rack kits available 19-inch 2 post, 23-inch 2 post, 600mm x 600mm, and 19-inch 4 post slide adjustable up to 800 mm |
| Processor |
| Number |
One to two |
| Architecture |
1.503GHz UltraSPARC IIIi, 64 bit, 4-way Superscalar SPARC V9 |
| Cache memory |
64 KB data, 32KB instruction and 1 MB integrated L2 |
| Main Memory |
| Capacities |
- 4 DIMM slots per processor, registered DDR-1 SDRAM (PC2100) 128 bit + ECC databus
- System configuration from 1GB to 8GB
|
| Standard Interfaces |
| Alarms |
Four fail-safe, dry contact alarms (critical, major, minor and user) with external reset input via DB15 pin connector |
| Ethernet |
- Four 10/100/1000 BaseT Ethernet
- One 10 BaseT Ethernet (Network Management)
|
| PCI |
Three internal PCI 2.2 compliant expansion slots:
- One 64 bit 33/66 MHz 3.3V full-length
- Two 64 bit 33 MHz 5V half-length
|
| SCSI |
One Ultra160 SCSI multimode (SE/LVD) |
| Serial |
- One TIA/EIA-232-F asynchronous (DB9) Port
- One TIA/EIA-232-F (RJ45) Port (Serial Management)
|
| System Configuration Reader and Card |
Front accessible for transfer of system configuration information, including host ID, MAC address, NVRAM |
| USB |
Two OHCI-1.0 Compliant Interfaces, supporting dual speeds of 12 and 1.5 Mbits/sec each |
| Internal Mass Storage |
| Disks |
Up to two hot-swap Ultra-320 SCSI 73GB or 146GB 15Krpm disks |
| DVD-ROM |
- Optional slim-line ATAPI DVD-ROM
- Optional slim-line DVD-RW
|
| Environment |
Power Supplies
(AC Version) |
1+1 with independent power cordsMax. input power: 550 W
Max. output power: 400 W
Max. power consumption: 353 W
Input current: 6.1A (at 90 VAC) |
Power Supplies
(DC Version) |
1+1 with independent power cordsMax. input power: 571 W
Max. output power: 400 W
Max. power consumption: 394 W
Input current: 15A@40V (Max) |
| AC power |
90-264 V AC (47-63 Hz) |
| DC Power |
-40V to -75V DC (range), single or dual power sources
-48V or -60V DC (nominal) |
| Heat output |
1,389 BTU/hr max |
| Temperature |
Operating: (AC) 0° C to 40° C (32° F to 104° F)
Operating: (DC) -5°C to 45°C (23°F to 113°F); short term -5°C to 55°C (23°F to 131°F)
Nonoperating: -40°C to 70°C (-40°F to 158°F) |
| Humidity |
Operating: (AC) 90% relative humidity, noncondensing, 40° C max wet bulb
Operating: (DC) 5% to 93% relative humidity, noncondensing
Nonoperating: up to 93% relative humidity, noncondensing |
| Altitude |
Operating: Up to 3000m
Nonoperating: Up to 12000m |
| Acoustic noise |
Declared Noise emissions in accordance with ISO 9296:
Operating: 7.0 B [LWAd(1B=10dB)]
Idling: 7.0 B [LWAd(1B=10dB)] |
| ETSI |
EN 300-019-2-1,2,3, Table 3.1 & Table 3.1E |
| Seismic |
GR-63-CORE requirements for earthquake zone 4 |
Regulations
Meets or exceeds the following requirements:
|
| RoHS Compliance Level |
RoHS:YL |
| Safety |
IEC60950, UL/CSA60950, EN60950 |
| RFI/EMI |
FCC Class A, part 15 47 CFR, EN55022, CISPR 22, EN 300-386:2001 V1.3.1, ICES-003 |
| Certification |
Safety: cULus Mark, TUV GS Mark, CE Mark, CCC, GOST R
EMC: CE Mark (93/68/EEC), FCC authorized Class A, VCCI, BSMI, C-Tick, MIC Telecommunication: Telcordia GR-63 CORE, GR-1089-CORE, SR 3580 NEBS Level3 |
| Dimensions and Weights |
| Height |
87.4 mm (3.44-inch) – 2RU |
| Width |
425mm (16.73-inch) not including bezel
442mm (17.4-inch) including bezel |
| Depth |
483mm (19-inch) to rear connectors
483mm (19-inch) to rear connectors |
| Weight |
16.3kg (36 lbs); 18.6kg (41 lbs) fully configured with rackmount kit |
