Oracle Sun BLADE X6450 SERVER MODULE

Oracle Sun BLADE X6450 SERVER MODULE Oracle Sun BLADE X6450 SERVER MODULE SUN BLADE X6450 SERVER MODULE FULL

REQUEST A PRICE QUOTE:

    Name*

    Phone

    Details*

    Processor
    Number Up to four.
    Architecture Type:Intel Xeon processors.
    • Model/Speed: E7220, 2-Core, 2.93 GHz, 80W
    • Model/Speed: L7345, 4-Core, 1.86 GHz, 50W
    • Model/Speed: L7445, 4-Core, 2.13 GHz, 50W
    • Model/Speed: E7320, 4-Core, 2.13 GHz, 80W
    • Model/Speed: E7340, 4-Core, 2.40 GHz, 80W
    • Model/Speed: E7440, 4-Core, 2.40 GHz, 90W
    • Model/Speed: L7455, 6-Core, 2.13 GHz, 65W
    • Model/Speed: E7450, 6-Core, 2.40 GHz, 90W
    Cache Memory L2 Cache
    Main Memory
    Memory Type PC2-5300 DDR2 Fully Buffered DIMMs (FBDIMMs).
    Capacities
    • Maximum memory: 192GB.
    • Total DIMM slots: 24.
    • DIMM sizes: 1GB, 2GB, 4GB and 8GB.
    • Install DIMMs in pairs of two beginning with A0/B0.
    IDE Compact Flash 8GB Compact Flash Type II (supports Linux boot) is on the motherboard.
    Optional Storage
    Solid State Drives
    • 1 32GB solid state drive.
    Management Environment
    Sun Blade Server Module Service Processor (SP)
    • The SP is not a separate card. It is embedded on the motherboard.
    • The SP is installed with Lights-Out Manager (LOM), IPMI 2.0-compatible software.
    • Embedded Lights-Out Manager (ELOM) and Integrated Lights-Out Manager (ILOM) are supported.
    • The factory pre-configured LOM transitioned to ILOM in September 2008.
    • The SP card provides one 10/100 Management Ethernet Port to Midplane and the Chassis Monitoring Module (CMM). The DB9-to-RJ45 serial adapter cable provides DB9 serial access to the server module through an RJ45 connection.
    • LOM on the SP card can be accessed via the Dongle cable’s DB9 connector to the Universal Connector Port (UCP) RJ45 connector on the front of the Sun Blade X6450.
    • The Dongle cable assembly is provided with the Sun Blade 6000 chassis and also orderable. Option X4621A.
    • The SP card and LOM provide the following:
      • A Browser User Interface (HTTP/HTTPS).
      • DMTF/CLP based CLI and SSH.
      • Support for RADIUS, LDAP, and MS Active Directory.
      • IPMI 2.0 (Host access through KCS and remote).
      • Compatibility for third-party SNMP system managers with requirements for SNMP (v1, v2C, v3).
      • Remote KVMS/Java Console (redirected Keyboard Video Mouse and Storage through a JAVA Application).
      • Support for Sun N1 System Manager.
    Standard Integrated Interfaces
    Universal Connector Port (UCP) The Dongle Cable Assembly (Option X4621A) that ships with the Sun Blade 6000 chassis connects to the UCP and provides the following:
    • VGA HD15 port to AST2000 video controller with 128MB of shared SDRAM.
    • 2 USB 2.0 ports.
    • DB9 serial port (for connection to SP LOM).
    • RJ45 port.
    • DB9F to RJ45F DCE Adapter.


    Network Management Two 10/100Base-T Ethernet connection via midplane to the CMM. Only one connection (NET 0) is used.
    Ethernet Two 10/100/1000Base-T Ethernet ports routed through midplane to 2 NEM slots.
    PCI Interfaces with the Sun Blade Modular System (chassis)
    • I/O is offered in two form factors:
      • PCI Express ExpressModules (EM)
        and
      • PCI Express Network Express Modules (NEM).
    • Each Sun Blade X6450 has four, PCI Express links allocated to:
      • Two EMs (X8)
        and
      • Two NEMs (X4).
    • Each NEM has one link assigned to each server module. All server modules share the NEM. For example, Blade 0 has access to NEM 0/slot 0, and NEM 1/slot 0. Blade 1 to NEM 0/slot 1 and NEM 1/slot 1, etc.
    • EM slots are not shared between server modules. Each EM slot is specific to one server module.
    Regulations
    RoHS Compliance Level RoHS:YL
    Blade
    Option # Manufacturing
    Part #    		 Description
    X6450-AB 599-3548 Sun Blade X6450 Server Module Base Assembly (no CPUs, no heatsinks, no memory), RoHS:Y
    • 540-7821
    • Blade Motherboard, RoHS:Y
    • 375-3601
    • System Board, RoHS:Y
    X6450-42M2930-82 594-5397 Sun Blade X6450 Server Module with 16GB Memory (8 x 2GB) and 4 CPU’s (2.93GHz, Dual-Core Xeon E7220)
    • 310-0187
    • CPU Heatsink, RoHS:Y
    • 371-3455
    • 2.93 GHz CPU, Xeon E7220, Dual Core, 80W, RoHS:Y
    • 375-3590
    • 16GB Compact Flash, RoHS:Y
    • 540-7252
    • 4 GB (2 × 2GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-2655
    • 2 GB PC2-5300 DDR2 DIMM, RoHS:Y
    • 540-7595
    • Blade Motherboard, RoHS:Y
    • 375-3564
    • System Board, RoHS:Y
    X6450-44L1860-82 594-5398 Sun Blade X6450 Server Module with 16GB Memory (8 x 2GB) and 4 CPU’s (1.86GHz, Quad-Core Xeon L7345)
    • 310-0187
    • CPU Heatsink, RoHS:Y
    • 371-3456
    • 1.86 GHz CPU, Xeon L7345 Quad Core, 50W, RoHS:Y
    • 375-3590
    • 16GB Compact Flash, RoHS:Y
    • 540-7252
    • 4 GB (2 × 2GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-2655
    • 2 GB PC2-5300 DDR2 DIMM, RoHS:Y
    • 540-7595
    • Blade Motherboard, RoHS:Y
    • 375-3564
    • System Board, RoHS:Y
    X6450-44L2131-82 594-5766 Sun Blade X6450 Server Module with 16GB Memory (8 x 2GB) and 4 CPU’s (2.13GHz, 4-Core Xeon L7445), RoHS:YL
    • 310-0187
    • CPU Heatsink, RoHS:Y
    • 371-4364
    • 2.13 GHz CPU, Xeon L7445 Quad Core, 50W, RoHS:Y
    • 375-3590
    • 16GB Compact Flash, RoHS:Y
    • 540-7252
    • 4 GB (2 × 2GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-2655
    • 2 GB PC2-5300 DDR2 DIMM, RoHS:Y
    • 540-7821
    • Blade Motherboard, RoHS:Y
    • 375-3601
    • System Board, RoHS:Y
    X6450-44M2130-82 594-5399 Sun Blade X6450 Server Module with 16GB Memory (8 x 2GB) and 4 CPU’s (2.13GHz, Quad-Core Xeon E7320)
    • 310-0187
    • CPU Heatsink, RoHS:Y
    • 371-3457
    • 2.13 GHz CPU, Xeon E7320 Quad Core, 80W, RoHS:Y
    • 375-3590
    • 16GB Compact Flash, RoHS:Y
    • 540-7252
    • 4 GB (2 × 2GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-2655
    • 2 GB PC2-5300 DDR2 DIMM, RoHS:Y
    • 540-7595
    • Blade Motherboard, RoHS:Y
    • 375-3564
    • System Board, RoHS:Y
    X6450-44M2400-B2 594-5400 Sun Blade X6450 Server Module with 32GB Memory (16 x 2GB) and 4 CPU’s (2.40GHz, Quad-Core Xeon E7340)
    • 310-0187
    • CPU Heatsink, RoHS:Y
    • 371-3458
    • 2.40 GHz CPU, Xeon E7340 Quad Core, 80W, RoHS:Y
    • 375-3590
    • 16GB Compact Flash, RoHS:Y
    • 540-7252
    • 4 GB (2 × 2GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-2655
    • 2 GB PC2-5300 DDR2 DIMM, RoHS:Y
    • 540-7595
    • Blade Motherboard, RoHS:Y
    • 375-3564
    • System Board, RoHS:Y
    X6450-44M2401-82 594-5768 Sun Blade X6450 Server Module with 16GB Memory (8 x 2GB) and 4 CPU’s (2.40GHz, 4-Core Xeon E7440), RoHS:YL
    • 310-0187
    • CPU Heatsink, RoHS:Y
    • 371-4363
    • 2.40 GHz CPU, Xeon E7440 Quad Core, 90W, RoHS:Y
    • 375-3590
    • 16GB Compact Flash, RoHS:Y
    • 540-7252
    • 4 GB (2 × 2GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-2655
    • 2 GB PC2-5300 DDR2 DIMM, RoHS:Y
    • 540-7821
    • Blade Motherboard, RoHS:Y
    • 375-3601
    • System Board, RoHS:Y
    X6450-46L2131-82 594-5767 Sun Blade X6450 Server Module with 16GB Memory (8 x 2GB) and 4 CPU’s (2.13GHz, 6-Core Xeon L7455), RoHS:YL
    • 310-0187
    • CPU Heatsink, RoHS:Y
    • 371-4366
    • 2.13 GHz CPU, Xeon L7455 6-Core, 65W, RoHS:Y
    • 375-3590
    • 16GB Compact Flash, RoHS:Y
    • 540-7252
    • 4 GB (2 × 2GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-2655
    • 2 GB PC2-5300 DDR2 DIMM, RoHS:Y
    • 540-7821
    • Blade Motherboard, RoHS:Y
    • 375-3601
    • System Board, RoHS:Y
    X6450-46M2401-B2 594-5769 Sun Blade X6450 Server Module with 32GB Memory (16 x 2GB) and 4 CPU’s (2.40GHz, 6-Core Xeon E7450), RoHS:YL
    • 310-0187
    • CPU Heatsink, RoHS:Y
    • 371-4365
    • 2.40 GHz CPU, Xeon E7450 6-Core, 90W, RoHS:Y
    • 375-3590
    • 16GB Compact Flash, RoHS:Y
    • 540-7252
    • 4 GB (2 × 2GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-2655
    • 2 GB PC2-5300 DDR2 DIMM, RoHS:Y
    • 540-7821
    • Blade Motherboard, RoHS:Y
    • 375-3601
    • System Board, RoHS:Y
    X6450-AA 599-3506 Sun Blade X6450 Server Module Base Assembly (no CPUs, no heatsinks, no memory), RoHS:Y
    • 540-7595
    • Blade Motherboard, RoHS:Y
    • 375-3564
    • System Board, RoHS:Y
    CPU Module
    Option # Manufacturing
    Part #    		 Description
    X6450-X-22M2930 2 × 2.93 GHz CPU, Xeon E7220 Dual Core, 80W, RoHS:YL
    310-0187 CPU Heatsink, RoHS:Y
    371-3455 2.93 GHz CPU, Xeon E7220, Dual Core, 80W, RoHS:Y
    X6450-X-24L1860 2 × 1.86 GHz CPU, Xeon L7345 Quad Core, 50W, RoHS:YL
    310-0187 CPU Heatsink, RoHS:Y
    371-3456 1.86 GHz CPU, Xeon L7345 Quad Core, 50W, RoHS:Y
    X6450-X-24L2131 2 × 2.13 GHz CPU, Xeon L7445 Quad Core, 50W, RoHS:YL
    310-0187 CPU Heatsink, RoHS:Y
    371-4364 2.13 GHz CPU, Xeon L7445 Quad Core, 50W, RoHS:Y
    X6450-X-24M2130 2 × 2.13 GHz CPU, Xeon E7320 Quad Core, 80W, RoHS:YL
    310-0187 CPU Heatsink, RoHS:Y
    371-3457 2.13 GHz CPU, Xeon E7320 Quad Core, 80W, RoHS:Y
    X6450-X-24M2400 2 × 2.40 GHz CPU, Xeon E7340 Quad Core, 80W, RoHS:YL
    310-0187 CPU Heatsink, RoHS:Y
    371-3458 2.40 GHz CPU, Xeon E7340 Quad Core, 80W, RoHS:Y
    X6450-X-24M2401 2 × 2.40 GHz CPU, Xeon E7440 Quad Core, 90W, RoHS:YL
    310-0187 CPU Heatsink, RoHS:Y
    371-4363 2.40 GHz CPU, Xeon E7440 Quad Core, 90W, RoHS:Y
    X6450-X-26L2131 2 × 2.13 GHz CPU, Xeon L7455 6-Core, 65W, RoHS:YL
    310-0187 CPU Heatsink, RoHS:Y
    371-4366 2.13 GHz CPU, Xeon L7455 6-Core, 65W, RoHS:Y
    X6450-X-26M2401 2 × 2.40 GHz CPU, Xeon E7450 6-Core, 90W, RoHS:YL
    310-0187 CPU Heatsink, RoHS:Y
    371-4365 2.40 GHz CPU, Xeon E7450 6-Core, 90W, RoHS:Y
    n/a 250-1802 Alcohol Wipe Cleaner
    n/a 310-0065 Thermal Grease, Syringe, RoHS:Y
    Cables
    Option # Manufacturing
    Part #    		 Description
    X4622A Dongle II Cable Assembly for Universal Connector Port (UCP) with three connectors: 1 VGA HD15, 1 RJ45, 2×USB, and 1 DB9 to RJ45 Adapter, RoHS:YL
    530-3100 RJ45F to DB9F Adapter, RoHS:Y
    530-3936 USB/VGA/RJ45 Dongle Cable Adapter, RoHS:Y
    Disks
    Option # Manufacturing
    Part #    		 Description
    XRA-ST2CB-32G2SSD 350-1278 Bracket, RoHS:Y
    530-4293 Data/Power Cable, 130mm, RoHS:Y
    540-7834 32GB Solid State Drive Assembly, SATA Interface, RoHS:Y
    • 371-4196
    • 32GB Solid State Drive, SATA Interface, RoHS:Y
    Ethernet
    Option # Manufacturing
    Part #    		 Description
    X1029A-Z 501-7961 Dual 10-Gigabit Ethernet Fabric Expansion Module (FEM), RoHS:Y
    X4681A 371-4304 Pass-Thru PCI Express Fabric Expansion Module (FEM), RoHS:Y
    Memory
    Option # Manufacturing
    Part #    		 Description
    X4680A 375-3590 16GB Compact Flash, RoHS:Y
    X4401A 540-7252 4 GB (2 × 2GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-2655
    • 2 GB PC2-5300 DDR2 DIMM, RoHS:Y
    X4402A 540-7253 8 GB (2 × 4GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-2656
    • 4 GB PC2-5300 DDR2 DIMM, RoHS:Y
    X5490A 375-3639 32GB Compact Flash, RoHS:Y
    X8286A 540-7852 16 GB (2 × 8GB PC2-5300 DDR2 1.5V DIMMs) Assembly, RoHS:Y
    • 371-4525
    • 8 GB PC2-5300 DDR2 1.5V DIMM, RoHS:Y
    SCSI
    Option # Manufacturing
    Part #    		 Description
    X4607A 511-1098 RAID 0/1 Expansion Module, RoHS:Y
    X4620A 371-2658 RAID 5 Expansion Module (REM) Card Assembly, RoHS:YL
    371-2659 RAID Expansion Module (REM) Battery Back-up, RoHS:Y
    371-4078 Extension Cable, RoHS:Y
    530-4062 Battery Extension Cable, RoHS:Y
