Oracle Sun BLADE X6250 SERVER MODULE

Oracle Sun BLADE X6250 SERVER MODULE Oracle Sun BLADE X6250 SERVER MODULE SUN BLADE X6250 SERVER MODULE A93

REQUEST A PRICE QUOTE:

    Name*

    Phone

    Details*



    Processor
    Number Up to two.
    Architecture Type:Quad-core, Intel Xeon 5300 series processors.
    • Model/Speed: 5160, Dual Core, 3.00 GHz, 80W
    • Model/Speed: X5260, Dual Core, 3.33 GHz, 80W
    • Model/Speed: X5270, Dual Core, 3.5 GHz, 80W
    • Model/Speed: E5320, Quad Core, 1.86 GHz, 80W
    • Model/Speed: L5310, Quad Core, 1.6 GHz, 50W
    • Model/Speed: E5345, Quad Core, 2.33 GHz, 80W
    • Model/Speed: X5355, Quad Core, 2.66 GHz, 120W
    • Model/Speed: E5410, Quad Core, 2.33 GHz, 80W
    • Model/Speed: E5440, Quad Core, 2.83 GHz, 80W
    • Model/Speed: X5460, Quad Core, 3.16 GHz, 120W
    • Model/Speed: E5450, Quad Core, 3.0 GHz, 80W
    • Model/Speed: X5365, Quad Core, 3.0 GHz, 120W
    • Model/Speed: L5420, Quad Core, 2.5 GHz, 50W
    • Model/Speed: X5470, Quad Core, 3.33 GHz, 120W
    • Model/Speed: L5430, Quad Core, 2.66 GHz, 50W
    • Model/Speed: E5420, Quad Core, 2.5 GHz, 80W
    Cache Memory 4 MB, L2 Cache
    Main Memory
    Memory Type DDR2-667MHz / PC2-5300 ECC Registered DIMMs. Support for ChipKill with a minimum of 4 DIMMs.
    Capacities
    • Maximum memory: 64GB.
    • Total DIMM slots: 16.
    • All DIMM slots are accessible by both processors.
    • DIMM sizes: 1GB, 2GB and 4GB.
    • Memory must be populated in increments of 4 DIMMs per socket.
    Optional Storage
    Disk
    • Up to four optional, hot swappable, hot pluggable, SATA or SAS drives per blade.
    • Mixing disk types (i.e. one SAS disk and one SATA disk) on same X6250 Server Module is not supported.
    Drive Type Density Speed Form Factor RAID
    SAS 146 GB 10,000 RPM 2.5″ RAID 0/1/5/10
    SAS 73 GB 10,000 RPM 2.5″ RAID 0/1/5/10
    SAS 300 GB 10,000 RPM 2.5″ RAID 0/1/5/10
    SATA 80 GB 5,400 RPM 2.5″ **
    SATA 200 GB 5,400 RPM 2.5″ **
    SAS drives require the RAID Expansion Module board.
    ** RAID not currently supported for SATA.
    Solid State Drives
    • Up to 4 32GB solid state drives
    IDE Compact Flash 8GB Compact Flash Type II (supports Linux boot) is on the motherboard.
    Management Environment
    Sun Blade Server Module Service Processor (SP)
    • The SP is not a separate card. It is embedded on the motherboard.
    • The SP may be installed with Lights-Out Manager (LOM), IPMI 2.0-compatible software.
    • The factory pre-configured LOM transitioned from ELOM to ILOM in September 2008.
    • The SP card provides one 10/100 Management Ethernet Port to Midplane and the Chassis Monitoring Module (CMM).
    • LOM on the SP card can be accessed via the Dongle cable assembly’s DB9 connector to the Universal Connector Port (UCP) on the front of the Sun Blade X6250.
    • The Dongle cable assembly is provided with the Sun Blade 6000 chassis and also orderable. Option X4621A.
    • The SP card and LOM provide the following:
      • A Browser User Interface (HTTP/HTTPS).
      • DMTF/CLP based CLI and SSH.
      • Support for RADIUS, LDAP, and MS Active Directory.
      • IPMI 2.0 (Host access through KCS and remote).
      • Compatibility for third-party SNMP system managers with requirements for SNMP (v1, v2C, v3).
      • Remote KVMS/Java Console (redirected Keyboard Video Mouse and Storage through a JAVA Application).
      • Support for Sun N1 System Manager.
    Standard Integrated Interfaces
    Universal Connector Port (UCP) The Dongle Cable Assembly (Option X4621A) that ships with the Sun Blade 6000 chassis connects to the UCP and provides the following:
    • VGA HD15 port to AST2000 video controller with 128MB of shared SDRAM.
    • 2 USB 2.0 ports.
    • DB9 serial port (for connection to SP LOM).
    • RJ45 port. Not supported on the Sun Blade X6220 or X6250.
    • DB9F to RJ45F DCE Adapter.
    Network Management Two 10/100Base-T Ethernet connection via midplane to the CMM. Only one connection (NET 0) is used.
    Ethernet Two 10/100/1000Base-T Ethernet ports routed through midplane to 2 NEM slots.
    PCI Interfaces with the Sun Blade Modular System (chassis)
    • I/O is offered in two form factors:
      • PCI Express ExpressModules (EM)
        and
      • PCI Express Network Express Modules (NEM).
    • Each Sun Blade X6250 has four, PCI Express links allocated to:
      • Two EMs (X8)
        and
      • Two NEMs (X4).
    • Each NEM has one link assigned to each server module. All server modules share the NEM. For example, Blade 0 has access to NEM 0/slot 0, and NEM 1/slot 0. Blade 1 to NEM 0/slot 1 and NEM 1/slot 1, etc.
    • EM slots are not shared between server modules. Each EM slot is specific to one server module.
    Regulations
    RoHS Compliance Level RoHS:YL
    Dimensions and Weights
    Height 44.5mm (1.75 in).
    Width 327.15mm (12.88 in).
    Depth 496.82 (19.56 in).
    Weight (fully configured) 7.51 kg (16.56 lbs).
    Batteries
    Option # Manufacturing
    Part #    		 Description
    n/a 371-2210 CR2032 3V Battery, RoHS:Y
    Blade
    Option # Manufacturing
    Part #    		 Description
    X4361A 594-4530 Sun Blade X6250 Server Module with 2GB Memory (2 × 1GB) and 1 CPU (1.86GHz, Quad Core Xeon)
    • 310-0148
    • Heat Sink
    • 371-2649
    • 1.86 GHz CPU, Xeon E5320 Quad Core, 80W, RoHS:YL
    • 371-2658
    • RAID 5 Expansion Module (REM) Card Assembly, RoHS:YL
    • 371-2659
    • RAID Expansion Module (REM) Battery Back-up, RoHS:Y
    • 540-7251
    • 2 GB (2 × 1GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-2654
    • 1 GB PC2-5300 DDR2 DIMM, RoHS:Y
    • 540-7254
    • Blade Motherboard, RoHS:Y
    • 375-3501
    • Blade Motherboard, RoHS:Y
    • n/a
    • Disk Backplane, Data Cables and Disk Power Cable
    X4362A 594-4531 Sun Blade X6250 Server Module with 8GB Memory (4 × 2GB) and 2 CPUs (1.6GHz, Quad Core Xeon L5310)
    • 310-0148
    • Heat Sink
    • 371-2650
    • 1.60 GHz CPU, Xeon L5310 Quad Core, 50W, RoHS:YL
    • 371-2658
    • RAID 5 Expansion Module (REM) Card Assembly, RoHS:YL
    • 371-2659
    • RAID Expansion Module (REM) Battery Back-up, RoHS:Y
    • 540-7252
    • 4 GB (2 × 2GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-2655
    • 2 GB PC2-5300 DDR2 DIMM, RoHS:Y
    • 540-7254
    • Blade Motherboard, RoHS:Y
    • 375-3501
    • Blade Motherboard, RoHS:Y
    • n/a
    • Disk Backplane, Data Cables and Disk Power Cable
    X4363A 594-4532 Sun Blade X6250 Server Module with 32GB Memory (16 × 2GB) and 2 CPUs (2.33GHz, Quad Core Xeon 5345)
    • 310-0148
    • Heat Sink
    • 371-2652
    • 2.33 GHz CPU, Xeon E5345 Quad Core, 80W, RoHS:YL
    • 371-2658
    • RAID 5 Expansion Module (REM) Card Assembly, RoHS:YL
    • 371-2659
    • RAID Expansion Module (REM) Battery Back-up, RoHS:Y
    • 540-7252
    • 4 GB (2 × 2GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-2655
    • 2 GB PC2-5300 DDR2 DIMM, RoHS:Y
    • 540-7254
    • Blade Motherboard, RoHS:Y
    • 375-3501
    • Blade Motherboard, RoHS:Y
    • n/a
    • Disk Backplane, Data Cables and Disk Power Cable
    X4364A 594-4533 Sun Blade X6250 Server Module with 32GB Memory (8 × 4GB) and 2 CPUs (2.66GHz, Quad Core Xeon X5355)
    • 310-0148
    • Heat Sink
    • 371-2653
    • 2.66 GHz CPU, Xeon X5355 Quad Core, 120W, RoHS:YL
    • 371-2658
    • RAID 5 Expansion Module (REM) Card Assembly, RoHS:YL
    • 371-2659
    • RAID Expansion Module (REM) Battery Back-up, RoHS:Y
    • 540-7253
    • 8 GB (2 × 4GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-2656
    • 4 GB PC2-5300 DDR2 DIMM, RoHS:Y
    • 540-7254
    • Blade Motherboard, RoHS:Y
    • 375-3501
    • Blade Motherboard, RoHS:Y
    • n/a
    • Disk Backplane, Data Cables and Disk Power Cable
    X4365A 594-4816 Sun Blade X6250 Server Module with 8GB Memory (8 × 1GB) and 2 CPUs (3.0GHz, Dual Core, Xeon 5160)
    • 310-0148
    • Heat Sink
    • 371-2658
    • RAID 5 Expansion Module (REM) Card Assembly, RoHS:YL
    • 371-2659
    • RAID Expansion Module (REM) Battery Back-up, RoHS:Y
    • 371-3066
    • 3.0 GHz CPU, Xeon 5160 Dual Core, 80W, RoHS:YL
    • 540-7251
    • 2 GB (2 × 1GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-2654
    • 1 GB PC2-5300 DDR2 DIMM, RoHS:Y
    • 540-7254
    • Blade Motherboard, RoHS:Y
    • 375-3501
    • Blade Motherboard, RoHS:Y
    • n/a
    • Disk Backplane, Data Cables and Disk Power Cable
    X4367A 594-5282 Sun Blade X6250 Server Module with 4GB Memory (4 x 1GB) and 2 CPU’s (2.5GHz, Quad-Core Xeon L5420), RoHS:Y
    • 310-0148
    • Heat Sink
    • 371-2658
    • RAID 5 Expansion Module (REM) Card Assembly, RoHS:YL
    • 371-2659
    • RAID Expansion Module (REM) Battery Back-up, RoHS:Y
    • 371-3951
    • 2.5GHz CPU, Xeon L5420 Quad Core, 1333MHz FSB, 50W, RoHS:Y
    • 540-7251
    • 2 GB (2 × 1GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-2654
    • 1 GB PC2-5300 DDR2 DIMM, RoHS:Y
    • 540-7254
    • Blade Motherboard, RoHS:Y
    • 375-3501
    • Blade Motherboard, RoHS:Y
    • n/a
    • Disk Backplane, Data Cables and Disk Power Cable
    X4368A 594-5283 Sun Blade X6250 Server Module with 4GB Memory (4 x 1GB) and 2 CPUs (2.33GHz, Quad Core Xeon E5410)
    • 310-0148
    • Heat Sink
    • 371-2658
    • RAID 5 Expansion Module (REM) Card Assembly, RoHS:YL
    • 371-2659
    • RAID Expansion Module (REM) Battery Back-up, RoHS:Y
    • 371-3950
    • 2.33GHz CPU, Xeon E5410 Quad Core, 80W, RoHS:Y
    • 540-7251
    • 2 GB (2 × 1GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-2654
    • 1 GB PC2-5300 DDR2 DIMM, RoHS:Y
    • 540-7254
    • Blade Motherboard, RoHS:Y
    • 375-3501
    • Blade Motherboard, RoHS:Y
    • n/a
    • Disk Backplane, Data Cables and Disk Power Cable
    X4369A 594-5284 Sun Blade X6250 Server Moduel with 8GB Memory (4 x 2GB) and 2 CPUs (2.83 GHz, Quad Core Xeon E5440)
    • 310-0148
    • Heat Sink
    • 371-2658
    • RAID 5 Expansion Module (REM) Card Assembly, RoHS:YL
    • 371-2659
    • RAID Expansion Module (REM) Battery Back-up, RoHS:Y
    • 371-3949
    • 2.83GHz CPU, Xeon E5440 Quad Core, 80W, RoHS:Y
    • 540-7252
    • 4 GB (2 × 2GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-2655
    • 2 GB PC2-5300 DDR2 DIMM, RoHS:Y
    • 540-7254
    • Blade Motherboard, RoHS:Y
    • 375-3501
    • Blade Motherboard, RoHS:Y
    • n/a
    • Disk Backplane, Data Cables and Disk Power Cable
    X6250-24L2660-22 594-5672 Sun Blade X6250 Server Module with 4GB Memory (2 x 2GB), and 2 CPU’s (2.66GHz, Quad-Core Xeon L5430)
    • 310-0148
    • Heat Sink
    • 371-2658
    • RAID 5 Expansion Module (REM) Card Assembly, RoHS:YL
    • 371-2659
    • RAID Expansion Module (REM) Battery Back-up, RoHS:Y
    • 371-4389
    • 2.66GHz CPU, Xeon L5430 Quad Core, 50W, RoHS:Y
    • 540-7252
    • 4 GB (2 × 2GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-2655
    • 2 GB PC2-5300 DDR2 DIMM, RoHS:Y
    • 540-7254
    • Blade Motherboard, RoHS:Y
    • 375-3501
    • Blade Motherboard, RoHS:Y
    • n/a
    • Disk Backplane, Data Cables and Disk Power Cable
    X6250-24M2500-22 594-5673 Sun Blade X6250 Server Module with 2GB Memory (2 ?? 1GB) and 2 CPUs (2.50GHz, Quad Core Xeon E5420)
    • 310-0148
    • Heat Sink
    • 371-2658
    • RAID 5 Expansion Module (REM) Card Assembly, RoHS:YL
    • 371-2659
    • RAID Expansion Module (REM) Battery Back-up, RoHS:Y
    • 371-4405
    • 2.5GHz CPU, Xeon E5420 Quad Core, 80W, RoHS:Y
    • 540-7252
    • 4 GB (2 × 2GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-2655
    • 2 GB PC2-5300 DDR2 DIMM, RoHS:Y
    • 540-7254
    • Blade Motherboard, RoHS:Y
    • 375-3501
    • Blade Motherboard, RoHS:Y
    • n/a
    • Disk Backplane, Data Cables and Disk Power Cable
    X6250-24M3000-82 594-5537 Sun Blade X6250 Server Module with 16GB Memory (8 × 2GB) and 2 CPUs (3.00GHz, Quad Core Xeon E5450), 80W, RoHS:YL
    • 310-0148
    • Heat Sink
    • 371-2658
    • RAID 5 Expansion Module (REM) Card Assembly, RoHS:YL
    • 371-2659
    • RAID Expansion Module (REM) Battery Back-up, RoHS:Y
    • 371-4146
    • 3.00GHz CPU, Xeon E5450 Quad Core, 80W, RoHS:Y
    • 540-7252
    • 4 GB (2 × 2GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-2655
    • 2 GB PC2-5300 DDR2 DIMM, RoHS:Y
    • 540-7254
    • Blade Motherboard, RoHS:Y
    • 375-3501
    • Blade Motherboard, RoHS:Y
    • n/a
    • Disk Backplane, Data Cables and Disk Power Cable
    CPU Module
    Option # Manufacturing
    Part #    		 Description
    X4510A 310-0148 Heat Sink
    371-3066 3.0 GHz CPU, Xeon 5160 Dual Core, 80W, RoHS:YL
    X4511A 310-0148 Heat Sink
    371-2649 1.86 GHz CPU, Xeon E5320 Quad Core, 80W, RoHS:YL
    X4512A 310-0148 Heat Sink
    371-2650 1.60 GHz CPU, Xeon L5310 Quad Core, 50W, RoHS:YL
    X4513A 310-0148 Heat Sink
    371-2652 2.33 GHz CPU, Xeon E5345 Quad Core, 80W, RoHS:YL
    X4514A 310-0148 Heat Sink
    371-2653 2.66 GHz CPU, Xeon X5355 Quad Core, 120W, RoHS:YL
    X4515A 310-0148 Heat Sink
    371-3843 3.00 GHz CPU, Xeon X5365 Quad Core, 120W, RoHS:Y
    X4516A 310-0148 Heat Sink
    371-3948 3.33 GHz CPU, Xeon X5260, Dual Core, 80W, RoHS:Y
    X4517A 310-0148 Heat Sink
    371-3951 2.5GHz CPU, Xeon L5420 Quad Core, 1333MHz FSB, 50W, RoHS:Y
    X4518A 310-0148 Heat Sink
    371-3950 2.33GHz CPU, Xeon E5410 Quad Core, 80W, RoHS:Y
    X4519A 310-0148 Heat Sink
    371-3949 2.83GHz CPU, Xeon E5440 Quad Core, 80W, RoHS:Y
    X4520A 310-0148 Heat Sink
    371-3952 3.16GHz CPU, Xeon X5460 Quad Core, 1333MHz FSB, 120W, RoHS:Y
    X6250-X-12M3500 1 × 3.5 GHz CPU, Xeon X5270 Dual Core, 80W, RoHS:YL
    310-0148 Heat Sink
    371-4388 3.5GHz CPU, Xeon X5270 Dual Core, 80W, RoHS:Y
    X6250-X-14H3330 1 × 3.33 GHz CPU, Xeon X5470 Quad Core, 120W, RoHS:YL
    310-0148 Heat Sink
    371-4390 3.33GHz CPU, Xeon X5470 Quad Core, 120W, RoHS:Y
    X6250-X-14L2660 1 × 2.66 GHz CPU, Xeon L5430 Quad Core, 50W, RoHS:YL
    310-0148 Heat Sink
    371-4389 2.66GHz CPU, Xeon L5430 Quad Core, 50W, RoHS:Y
    X6250-X-14M2500 1 × 2.5 GHz CPU, Xeon E5420 Quad Core, 80W, RoHS:YL
    310-0148 Heat Sink
    371-4405 2.5GHz CPU, Xeon E5420 Quad Core, 80W, RoHS:Y
    X6250-X-14M3000 1 × 3.0 GHz CPU, Xeon E5450 Quad Core, 80W, RoHS:YL
    310-0148 Heat Sink
    371-4146 3.00GHz CPU, Xeon E5450 Quad Core, 80W, RoHS:Y
    Cables
    Option # Manufacturing
    Part #    		 Description
    X4622A Dongle II Cable Assembly for Universal Connector Port (UCP) with three connectors: 1 VGA HD15, 1 RJ45, 2×USB, and 1 DB9 to RJ45 Adapter, RoHS:YL
    530-3100 RJ45F to DB9F Adapter, RoHS:Y
    530-3936 USB/VGA/RJ45 Dongle Cable Adapter, RoHS:Y
    Disk Backplane
    Option # Manufacturing
    Part #    		 Description
    n/a n/a Disk Backplane, Data Cables and Disk Power Cable
    Disks
    Option # Manufacturing
    Part #    		 Description
    XRA-SS2CD-300G10K 540-7865 300GB – 10000 RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks, RoHS:Y
    • 390-0449
    • Seagate ST93000SSUNG [ST930003SSUN300G]
      (300GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-3004
    • Nemo Bracket with Insulator, RoHS:Y
    XRA-ST2CD-32G2SSD 540-7843 32GB Solid State Drive Assembly, SATA Interface, RoHS:Y
    • 371-4196
    • 32GB Solid State Drive, SATA Interface, RoHS:Y
    • 541-0239
    • Nemo Bracket, RoHS:Y
    XRB-SS2CD-146G10K 540-7864 146GB – 10000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks, RoHS:Y
    • 390-0377
    • Hitachi HUC101414CSS300 [H101414SCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0448
    • Seagate ST9146803SS [ST914603SSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0450
    • Hitachi HUC103014CSS600 [H103014SCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-3004
    • Nemo Bracket with Insulator, RoHS:Y
    XRA-SS2CD-73G15K 540-7360 73GB – 15000 RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks, RoHS:Y
    • 390-0382
    • Seagate ST973451SS [ST973451SSUN72G]
      (73GB – 15000 RPM – SAS Disk), RoHS:Y
    • 541-0239
    • Nemo Bracket, RoHS:Y
    XRB-SS2CD-146G10KZ 540-7151 146GB – 10000 RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks and brackets, RoHS:Y
    • 390-0324
    • Seagate ST9146802SS [ST914602SSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0375
    • Fujitsu MBB2147RC [MBB2147RCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0377
    • Hitachi HUC101414CSS300 [H101414SCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-0239
    • Nemo Bracket, RoHS:Y
    • 541-3004
    • Nemo Bracket with Insulator, RoHS:Y
    XRB-SS2CD-73G10KZ 540-6611 73GB 10000 RPM SAS, Disk Assembly with 1 of the following disks and brackets, RoHS:Y
    • 390-0213
    • Seagate ST973401SS [ST973401SSUN72G]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0285
    • Fujitsu MAY2073RC [MAY2073RCSUN72]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0323
    • Seagate ST973402SS [ST973402SSUN72G]
      (73GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0374
    • Fujitsu MBB2073RC [MBB2073RCSUN72G]
      (73.4GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0376
    • Hitachi HUC101473CSS300 [H101473SCSUN72G]
      (73.4GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-0239
    • Nemo Bracket, RoHS:Y
    • 541-3004
    • Nemo Bracket with Insulator, RoHS:Y
    XRB-ST3CD-200G5K 540-7554 200GB – 5400 RPM SATA Disk Assrmbly with 1 bracket and 1 of the following disks, RoHS:Y
    • 390-0407
    • Fujitsu MHY2200BS [MHY2200BSSUN200G]
      (200GB – 5400 RPM – SATA Disk), RoHS:Y
    • 541-3004
    • Nemo Bracket with Insulator, RoHS:Y
    XRB-ST3CD-80G5KZ 541-1115 80GB – 5400 RPM SATA, Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
    • 390-0250
    • Fujitsu MHV2080BS [MHV5480SBSUN80G]
      (80GB – 5400 RPM – SATA Disk), RoHS:Y
    • 541-0239
    • Nemo Bracket, RoHS:Y
    Ethernet
    Option # Manufacturing
    Part #    		 Description
    X1029A-Z 501-7961 Dual 10-Gigabit Ethernet Fabric Expansion Module (FEM), RoHS:Y
    X4681A 371-4304 Pass-Thru PCI Express Fabric Expansion Module (FEM), RoHS:Y
    Memory
    Option # Manufacturing
    Part #    		 Description
    X4680A 375-3590 16GB Compact Flash, RoHS:Y
    X4400A 540-7251 2 GB (2 × 1GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-2654
    • 1 GB PC2-5300 DDR2 DIMM, RoHS:Y
    X4401A 540-7252 4 GB (2 × 2GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-2655
    • 2 GB PC2-5300 DDR2 DIMM, RoHS:Y
    X4402A 540-7253 8 GB (2 × 4GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-2656
    • 4 GB PC2-5300 DDR2 DIMM, RoHS:Y
    X4625A 371-2905 8GB Compact Flash, RoHS:Y
    SCSI
    Option # Manufacturing
    Part #    		 Description
    X4620A 371-2658 RAID 5 Expansion Module (REM) Card Assembly, RoHS:YL
    371-2659 RAID Expansion Module (REM) Battery Back-up, RoHS:Y
    371-4078 Extension Cable, RoHS:Y
    530-4062 Battery Extension Cable, RoHS:Y

    Industry Leading Quality, Support and Integrity

    Quality Inspection Checklist
    Before it leaves our facility, every used and refurbished item is thoroughly inspected by our certified technicians and undergoes our exclusive Quality Inspection Checklist to ensure 100% satisfaction guarantee.

    Greentec Systems is a leading provider
    For server, networking and storage equipment. We have an extensive array of inventory of IBM Servers & Storage, Sun Servers & Storage, Cisco Networking (Switches, Routers, Security), and NetApp Storage (disk shelves, disk drives, Filers, NearStore, NetCache). If you don’t see the item or product you require please contact us.

    Have this equipment to sell?
    Depending on the age and condition of the equipment, there is a very good likelihood that we will be able to offer you cash or trade-in credit for other IT hardware. If the equipment is very old we can also assist you with properly decommissioning that gear in the most environmentally friendly way possible.

    Questions?
    For more information please contact 888.333.7388, or fill out the quote from above. We’d love to hear from you.

    Request Quote
    Greentec Systems We geek out helping you with your IT infrastructure.
    Request a quote or product information
    Send
