Oracle Sun BLADE X6240 SERVER MODULE

Oracle Sun BLADE X6240 SERVER MODULE Oracle Sun BLADE X6240 SERVER MODULE SUN BLADE X6240 SERVER MODULE X6240

REQUEST A PRICE QUOTE:

    Name*

    Phone

    Details*



    Processor
    Number Two.
    Architecture Type:Opteron
    • Model/Speed/Watts/Cache: 2347HE, Quad Core, 1.9 GHz, 55W, 2M L3 Cache
    • Model/Speed/Watts/Cache: 2352, Quad Core, 2.1 GHz, 75W, 2M L3 Cache
    • Model/Speed/Watts/Cache: 2356, Quad Core, 2.30 GHz, 75W, 2M L3 Cache
    • Model/Speed/Watts/Cache: 2360SE, Quad Core, 2.5 GHz, 105W, 2M L3 Cache
    • Model/Speed/Watts/Cache: 2376, Quad Core, 2.3 GHz, 55W, 6M L3 Cache
    • Model/Speed/Watts/Cache: 2380, Quad Core, 2.5 GHz, 75W, 6M L3 Cache
    • Model/Speed/Watts/Cache: 2384, Quad Core, 2.7 GHz, 75W, 6M L3 Cache
    • Model/Speed/Watts/Cache: 2389, Quad Core, 2.9 GHz, 75W, 6M L3 Cache
    • Model/Speed/Watts/Cache: 2427, 6-Core, 2.2 GHz, 75W, 6M L3 Cache
    • Model/Speed/Watts/Cache: 2431, 6-Core, 2.4 GHz, 75W, 6M L3 Cache
    • Model/Speed/Watts/Cache: 2435, 6-Core, 2.6 GHz, 75W, 6M L3 Cache
    Main Memory
    Memory Type DDR2-667MHz / PC2-5300 ECC Registered DIMMs.
    Capacities
    • Maximum memory: 128GB.
    • Total DIMM slots: 16.
    • DIMM sizes: 2GB, 4GB and 8GB.
    Optional Storage
    Disk
    • Up to four optional, hot swappable, hot pluggable, SATA or SAS drives per blade.
    • Mixing disk types (i.e. one SAS disk and one SATA disk) on same X6240 Server Module is not supported.
    Drive Type Density Speed Form Factor RAID
    SAS 146 GB 10,000 RPM 2.5″ *
    SAS 73 GB 15,000 RPM 2.5″ *
    SAS 300 GB 10,000 RPM 2.5″ **
    SATA 200 GB 5,400 RPM 2.5″ **
    * SAS requires the RAID Expansion Module (REM) card.
    ** RAID on the SATA drives requires the REM.
    Solid State Drives
    • Up to four 32GB solid state drives
    IDE Compact Flash 8GB Compact Flash Type II (supports Linux boot) is on the motherboard.
    Management Environment
    Sun Blade Server Module Service Processor (SP)
    • The SP is not a separate card. It is embedded on the motherboard.
    • The SP provides Integrated Lights-Out Manager (ILOM).
    • Connection to ILOM can be made by:
      • Connecting a terminal or terminal emulator to the UCP via the dongle cable’s RJ-45 connector.
      • Connecting to the ethernet port via the dongle cable’s ethernet port or corresponding Network Express Module (NEM) port to provide either CLI or web interface.
      • Connecting a terminal or terminal emulator to the Chassis’ serial port.
    Standard Integrated Interfaces
    Universal Connector Port (UCP) The 3-wire Dongle Cable Assembly connects to the UCP and provides the following:
    • VGA HD15 port to AST2000 video controller.
      • 2 USB 2.0 ports.
      • 1 TIA/EIA-232-F DB-9 serial port.
    • The 4-wire Dongle Cable Assembly connects to the UCP and provides the following:
      • VGA HD15 port to AST2000 video controller.
      • 2 USB 2.0 ports.
      • 1 TIA/EIA-232-F DB-9 serial port. A DB-9 to RJ-45 adapter is provided with the 4-wire dongle.
      • One 10/100 Ethernet port.
    PCI Interfaces with the Sun Blade Modular System (chassis)
    • I/O is offered in two form factors:
      • PCI Express ExpressModules (EM)
        and
      • PCI Express Network Express Modules (NEM).
    • Each Sun Blade X6240 has four, PCI Express links allocated to:
      • Two EMs (X8)
        and
      • Two NEMs (X4).
    • Each NEM has one link assigned to each server module. All server modules share the NEM. For example, Blade 0 has access to NEM 0/slot 0, and NEM 1/slot 0. Blade 1 to NEM 0/slot 1 and NEM 1/slot 1, etc.
    • EM slots are not shared between server modules. Each EM slot is specific to one server module.
    Regulations
    RoHS Compliance Level RoHS:YL
    Dimensions and Weights
    Height 44.45mm (1.75 in).
    Width 327.15mm (12.88 in).
    Depth 496.82 (19.56 in).
    Weight (Empty) 6.01 kg (13.25 lbs).
    Weight (Fully Configured) 7.24 kg (15.95 lbs).
    Batteries
    Option # Manufacturing
    Part #    		 Description
    n/a 371-2210 CR2032 3V Battery, RoHS:Y
    Blade
    Option # Manufacturing
    Part #    		 Description
    X6240-24L1900-42 594-5567 Sun Blade X6240 Server Module with 8GB Memory (4 × 2GB) and 2 CPUs (1.9 GHz, Quad Core, Opteron 2347 HE, 55W)
    • 310-0091
    • Heat Sink, RoHS:Y
    • 371-3651
    • Memory Slot Filler, EBS93011010, RoHS:Y
    • 371-4095
    • 1.9 GHz CPU, Opteron 2347HE Quad Core, B3 Stepping, 55W, RoHS:Y
    • 540-7669
    • 4 GB (2 × 2GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-4062
    • 2 GB PC2-5300 DDR2 DIMM, RoHS:Y
    • 540-7906
    • Blade Motherboard Assembly
    • 375-3558
    • Blade Motherboard, RoHS:Y
    • n/a
    • Disk Backplane, RoHS:Y
    • 541-2629
    • Disk Drive Filler Panel, RoHS:Y
    X6240-24M2100-42 594-5618 Sun Blade X6240 Server Module with 8GB Memory (4 × 2GB) and 2 CPUs (2.1 GHz, Quad Core, Opteron 2352, 75W)
    • 310-0091
    • Heat Sink, RoHS:Y
    • 371-3651
    • Memory Slot Filler, EBS93011010, RoHS:Y
    • 371-4097
    • 2.1 GHz CPU Opteron 2352 Quad Core, B3 Stepping, 75W, RoHS:Y
    • 540-7669
    • 4 GB (2 × 2GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-4062
    • 2 GB PC2-5300 DDR2 DIMM, RoHS:Y
    • 540-7906
    • Blade Motherboard Assembly
    • 375-3558
    • Blade Motherboard, RoHS:Y
    • n/a
    • Disk Backplane, RoHS:Y
    • 541-2629
    • Disk Drive Filler Panel, RoHS:Y
    X6240-24M2300-82 594-5382 Sun Blade X6240 Server Module with 16GB Memory (8 × 2GB) and 2 CPUs (2.3 GHz, Quad Core, Opteron 2356, 75W)
    • 310-0091
    • Heat Sink, RoHS:Y
    • 371-3651
    • Memory Slot Filler, EBS93011010, RoHS:Y
    • 371-4042
    • 2.3 GHz CPU, Opteron 2356 Quad Core, B3 Stepping, 75W, RoHS:Y
    • 540-7669
    • 4 GB (2 × 2GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-4062
    • 2 GB PC2-5300 DDR2 DIMM, RoHS:Y
    • 540-7906
    • Blade Motherboard Assembly
    • 375-3558
    • Blade Motherboard, RoHS:Y
    • n/a
    • Disk Backplane, RoHS:Y
    • 541-2629
    • Disk Drive Filler Panel, RoHS:Y
    X6240-24M2501-42 594-5964 Sun Blade X6240 Server Module with 8GB Memory (4 × 2GB) and 2 CPU’s (2.5GHz, Opteron Quad-Core 2380, 75W)
    • 310-0091
    • Heat Sink, RoHS:Y
    • 371-3651
    • Memory Slot Filler, EBS93011010, RoHS:Y
    • 371-4432
    • 2.5 GHz CPU, Opteron 2380 Quad Core, C2 Stepping, 75W, RoHS:Y
    • 540-7669
    • 4 GB (2 × 2GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-4062
    • 2 GB PC2-5300 DDR2 DIMM, RoHS:Y
    • 540-7906
    • Blade Motherboard Assembly
    • 375-3558
    • Blade Motherboard, RoHS:Y
    • n/a
    • Disk Backplane, RoHS:Y
    • 541-2629
    • Disk Drive Filler Panel, RoHS:Y
    X6240-24M2701-82 594-5965 Sun Blade X6240 Server Module with 16GB Memory (8 × 2GB) and 2 CPU’s (2.7 GHz, Opteron Quad Core 2384, 75W)
    • 310-0091
    • Heat Sink, RoHS:Y
    • 371-3651
    • Memory Slot Filler, EBS93011010, RoHS:Y
    • 371-4438
    • 2.7 GHz CPU, Opteron 2384 Quad Core, C2 Stepping, 75W, RoHS:Y
    • 540-7669
    • 4 GB (2 × 2GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-4062
    • 2 GB PC2-5300 DDR2 DIMM, RoHS:Y
    • 540-7906
    • Blade Motherboard Assembly
    • 375-3558
    • Blade Motherboard, RoHS:Y
    • n/a
    • Disk Backplane, RoHS:Y
    • 541-2629
    • Disk Drive Filler Panel, RoHS:Y
    n/a 540-7676 Blade Motherboard Assembly
    • 375-3558
    • Blade Motherboard, RoHS:Y
    • n/a
    • Disk Backplane, RoHS:Y
    n/a 542-0141 Blade Motherboard Assembly, RoHS:Y
    • 375-3624
    • Blade Motherboard, RoHS:Y
    • n/a
    • Disk Backplane, RoHS:Y
    CPU Module
    Option # Manufacturing
    Part #    		 Description
    X6240-X-14H2500 Sun Blade X6240 Server Module Upgrade Kit with 1 CPU (2.5 GHz, 6-Core, Opteron 2360, 105W), RoHS:YL
    310-0091 Heat Sink, RoHS:Y
    371-4101 2.5 GHz CPU, Opteron 2360SE Quad Core, B3 Stepping, 105W, RoHS:Y
    X6240-X-14L1900 Sun Blade X6240 Server Module Upgrade Kit with 1 1.9 GHz CPU, Opteron 2347 HE Quad Core, 55W, RoHS:YL
    310-0091 Heat Sink, RoHS:Y
    371-4095 1.9 GHz CPU, Opteron 2347HE Quad Core, B3 Stepping, 55W, RoHS:Y
    X6240-X-14L2301 Sun Blade X6240 Server Module Upgrade Kit with 1 × 2.3 GHz CPU, Opteron 2376HE Quad Core, 55W, RoHS:YL
    310-0091 Heat Sink, RoHS:Y
    371-4502 2.3 GHz CPU, Opteron 2376 HE Quad Core, C2 Stepping, 55W, RoHS:Y
    X6240-X-14M2100 Sun Blade X6240 Server Module Upgrade Kit with 1 CPU (2.1 GHz, 6-Core, Opteron 2352, 75W), RoHS:YL
    310-0091 Heat Sink, RoHS:Y
    371-4097 2.1 GHz CPU Opteron 2352 Quad Core, B3 Stepping, 75W, RoHS:Y
    X6240-X-14M2300 Sun Blade X6240 Server Module Upgrade Kit with 1 × 2.3 GHz CPU, Opteron 2356 Quad Core, 75W, RoHS:YL
    310-0091 Heat Sink, RoHS:Y
    371-4042 2.3 GHz CPU, Opteron 2356 Quad Core, B3 Stepping, 75W, RoHS:Y
    X6240-X-14M2501 Sun Blade X6240 Server Module Upgrade Kit with 1 × 2.5 GHz CPU, Opteron 2380 Quad Core, 75W, RoHS:YL
    310-0091 Heat Sink, RoHS:Y
    371-4432 2.5 GHz CPU, Opteron 2380 Quad Core, C2 Stepping, 75W, RoHS:Y
    X6240-X-14M2701 Sun Blade X6240 Server Module Upgrade Kit with 1 × 2.7 GHz CPU, Opteron 2384 Quad Core, 75W, RoHS:YL
    310-0091 Heat Sink, RoHS:Y
    371-4438 2.7 GHz CPU, Opteron 2384 Quad Core, C2 Stepping, 75W, RoHS:Y
    X6240-X-14M2902 Sun Blade X6240 Server Module Upgrade Kit with 1 × 2.9 GHz CPU, Opteron 2389 Quad Core, 75W, RoHS:YL
    310-0091 Heat Sink, RoHS:Y
    371-4641 2.9 GHz CPU, Opteron 2389 Quad Core, C2 Stepping, 75W, RoHS:Y
    X6240-X-16H2803 Sun Blade X6240 Server Module Upgrade Kit with 1 × 2.3 GHz CPU, Opteron 2376HE Quad Core, 55W, RoHS:YL
    310-0091 Heat Sink, RoHS:Y
    371-4682 2.8GHz CPU, Opteron 2439 SE, 6-Core, D0 Stepping, 105W, RoHS:Y
    X6240-X-16M2203 Sun Blade X6240 Server Module Upgrade Kit with 1 CPU (2.2 GHz, 6-Core, Opteron 2427, 75W), RoHS:YL
    310-0091 Heat Sink, RoHS:Y
    371-4679 2.2 GHz CPU, Opteron 2427 6-Core, D0 Stepping, 75W, RoHS:Y
    X6240-X-16M2403 Sun Blade X6240 Server Module Upgrade Kit with 1 CPU (2.4 GHz, 6-Core, Opteron 2431, 75W), RoHS:YL
    310-0091 Heat Sink, RoHS:Y
    371-4680 2.4 GHz CPU, Opteron 2431 6-Core, D0 Stepping, 75W, RoHS:Y
    X6240-X-16M2603 Sun Blade X6240 Server Module Upgrade Kit with 1 CPU (2.6 GHz, 6-Core, Opteron 2435, 75W), RoHS:YL
    310-0091 Heat Sink, RoHS:Y
    371-4681 2.6 GHz CPU, Opteron 2435 6-Core, D0 Stepping, 75W, RoHS:Y
    n/a 250-1802 Alcohol Wipe Cleaner
    n/a 310-0065 Thermal Grease, Syringe, RoHS:Y
    Cables
    Option # Manufacturing
    Part #    		 Description
    X4622A Dongle II Cable Assembly for Universal Connector Port (UCP) with three connectors: 1 VGA HD15, 1 RJ45, 2×USB, and 1 DB9 to RJ45 Adapter, RoHS:YL
    530-3100 RJ45F to DB9F Adapter, RoHS:Y
    530-3936 USB/VGA/RJ45 Dongle Cable Adapter, RoHS:Y
    X4621A Dongle Cable Assembly for Universal Connector Port (UCP) with four connectors: 1 VGA HD15, 1 RJ45, 2USB, 1 DB9 Serial and 1 DB9 to RJ45 Adapter, RoHS:YL
    530-3813 DB9F to RJ45F, DCE Adapter, RoHS:Y
    530-3934 USB/VGA/DB-9/RJ45 Dongle Cable Adapter, RoHS:Y
    Communication
    Option # Manufacturing
    Part #    		 Description
    X4239A 511-1210 Dual Port 4x DDR PCI Express Gen 2 Fabric Expansion Module, RoHS:Y
    Disk Backplane
    Option # Manufacturing
    Part #    		 Description
    n/a n/a Disk Backplane
    Disks
    Option # Manufacturing
    Part #    		 Description
    XRA-SS2CF-300G10K 540-7869 300GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
    • 390-0449
    • Seagate ST93000SSUNG [ST930003SSUN300G]
      (300GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0451
    • Hitachi HUC103030CSS600 [H103030SCSUN300G]
      (300GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-2123
    • Marlin Bracket 2.5″, RoHS:Y
    XRA-ST2CF-32G2SSD 540-7841 32GB Solid State Drive Assembly, SATA Interface, RoHS:Y
    • 371-4196
    • 32GB Solid State Drive, SATA Interface, RoHS:Y
    • 541-2123
    • Marlin Bracket 2.5″, RoHS:Y
    XRB-SS2CD-146G10K 540-7864 146GB – 10000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks, RoHS:Y
    • 390-0377
    • Hitachi HUC101414CSS300 [H101414SCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0448
    • Seagate ST9146803SS [ST914603SSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0450
    • Hitachi HUC103014CSS600 [H103014SCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-3004
    • Nemo Bracket with Insulator, RoHS:Y
    XRB-SS2CF-146G10K 540-7868 146GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
    • 390-0324
    • Seagate ST9146802SS [ST914602SSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0377
    • Hitachi HUC101414CSS300 [H101414SCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0448
    • Seagate ST9146803SS [ST914603SSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0450
    • Hitachi HUC103014CSS600 [H103014SCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-2123
    • Marlin Bracket 2.5″, RoHS:Y
    XRA-SS2CF-146G10K 540-7355 146GB – 10000 RPM SAS SFF Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
    • 390-0324
    • Seagate ST9146802SS [ST914602SSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0375
    • Fujitsu MBB2147RC [MBB2147RCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 390-0377
    • Hitachi HUC101414CSS300 [H101414SCSUN146G]
      (146GB – 10000 RPM – SAS Disk), RoHS:Y
    • 541-2123
    • Marlin Bracket 2.5″, RoHS:Y
    XRA-SS2CF-73G15K 540-7361 73GB – 15000 RPM SAS, Disk Assembly with 1 bracket and 1 of the following disks, RoHS:Y
    • 390-0382
    • Seagate ST973451SS [ST973451SSUN72G]
      (73GB – 15000 RPM – SAS Disk), RoHS:Y
    • 541-2123
    • Marlin Bracket 2.5″, RoHS:Y
    XRA-ST2CF-200G5K 540-7555 200GB – 5400 RPL SATA Disk Assembly with 1 bracket and 1 of the following disks:, RoHS:Y
    • 390-0407
    • Fujitsu MHY2200BS [MHY2200BSSUN200G]
      (200GB – 5400 RPM – SATA Disk), RoHS:Y
    • 541-2123
    • Marlin Bracket 2.5″, RoHS:Y
    Ethernet
    Option # Manufacturing
    Part #    		 Description
    X4263A 373-0315 Dual 10-Gigabit Pass-Thru Fabric Expansion Module (FEM), RoHS:Y
    Memory
    Option # Manufacturing
    Part #    		 Description
    X4680A 375-3590 16GB Compact Flash, RoHS:Y
    X4249A 16 GB (2 × 8GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:YL
    371-4567 8GB PC2-5300 DDR2-667 DIMM, RoHS:Y
    X4261A 540-7669 4 GB (2 × 2GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-4062
    • 2 GB PC2-5300 DDR2 DIMM, RoHS:Y
    X4262A 540-7670 8 GB (2 × 4GB PC2-5300 DDR2 DIMMs) Assembly, RoHS:Y
    • 371-4063
    • 4 GB PC2-5300 DDR2 DIMM, RoHS:Y
    n/a 371-3651 Memory Slot Filler, EBS93011010, RoHS:Y
    n/a F541-3816 16 GB (2 & 8GB PC2-5300 DDR2 DIMMs), RoHS:Y
    • 371-4567
    • 8GB PC2-5300 DDR2-667 DIMM, RoHS:Y
    SCSI
    Option # Manufacturing
    Part #    		 Description
    X4607A 511-1098 RAID 0/1 Expansion Module, RoHS:Y
    X4620A 371-2658 RAID 5 Expansion Module (REM) Card Assembly, RoHS:YL
    371-2659 RAID Expansion Module (REM) Battery Back-up, RoHS:Y
    371-4078 Extension Cable, RoHS:Y
    530-4062 Battery Extension Cable, RoHS:Y

    Industry Leading Quality, Support and Integrity

    Quality Inspection Checklist
    Before it leaves our facility, every used and refurbished item is thoroughly inspected by our certified technicians and undergoes our exclusive Quality Inspection Checklist to ensure 100% satisfaction guarantee.

    Greentec Systems is a leading provider
    For server, networking and storage equipment. We have an extensive array of inventory of IBM Servers & Storage, Sun Servers & Storage, Cisco Networking (Switches, Routers, Security), and NetApp Storage (disk shelves, disk drives, Filers, NearStore, NetCache). If you don’t see the item or product you require please contact us.

    Have this equipment to sell?
    Depending on the age and condition of the equipment, there is a very good likelihood that we will be able to offer you cash or trade-in credit for other IT hardware. If the equipment is very old we can also assist you with properly decommissioning that gear in the most environmentally friendly way possible.

    Questions?
    For more information please contact 888.333.7388, or fill out the quote from above. We’d love to hear from you.

    Request Quote
    Greentec Systems We geek out helping you with your IT infrastructure.
    Request a quote or product information
    Send
