Oracle Sun 8000 Modular System Server

Oracle Sun 8000 Modular System Server Oracle Sun 8000 Modular System Server 8000

REQUEST A PRICE QUOTE:

    Name*

    Phone

    Details*

    Capacity
    Number
    • Up to 20 optional PCI ExpressModules.
    • Up to 4 optional PCI Express Network Express Modules (NEM).
    • Up to 10 hot-pluggable Sun Blade Server Modules.
    • 6, 3000-Watt, grid redundant power supplies; up to 735W budgeted per blade; 9000W total system power.
    • 3 fan modules to cool the PCI Express ExpressModules.
    • Up to 2 redundant Chassis Monitoring Modules with failover capability.
    • 9 high-performance fans to cool the blades.
    • 160 Gbps of I/O throughput via PCIe lanes to the midplane
    Management Environment
    The Sun Blade 8000 Modular System has a tiered system management architecture that allows management at either the chassis level or the Server Module level.
    Common System Management for both the Chassis and the Server Module
    • Integrated Lights Out Management (ILOM) 1.1 with RKVMS (Remote Keyboard Video Mouse) is pre-installed on the CMM and the SP. ILOM will run on standby power. Note: Accessing ILOM through Mozilla will require Mozilla version 1.7.5 or greater.
    • Support for Sun N1 System Manager 1.3.1.
    • Compatibility for third-party SNMP system managers with requirements for SNMP (v1, v2C, v3) and IPMI (2.0).
    • System management is consistent with Sun Fire X4100 and Sun Fire X4200 servers.
    Sun Blade 8000 Chassis Monitoring Module (CMM)
    • For redundancy, a second CMM is optional.
    • 1 RJ-45 dedicated management network 100BaseT port for Secure Shell CLI to ILOM, web GUI access to ILOM, IPMI 2.0, and SNMP v1, v2C, and V3.
    • A DB-9 serial port to access ILOM CLI.
    • 1 RJ-45 AUX port is currently not functional.
    • The CMM’s network ports are independent and do not interfere with network data traffic on, for example, a Network Express Module (NEM) communication option.
    • Connections to CMM’s Serial Management (DB-9 SERIAL MGT) port:
      • Laptop USB to SERIAL MGT port via serial null modem or cross over cable.
      • Network to Dongle DB9F to RJ45F, DCE Adapter (part number 530-3813 ships with chassis) to SERIAL MGT port.
    • Managing through the CMM does allow Server Module level management.
    Power Supplies
    Number Six, hot-plug / hot-swap, high-efficiency(~87%) power supplies are provided in a 3+3 redundant configuration.
    Output 3000 W per power supply
    Standard Integrated Interfaces
    Network The Sun Blade 8000, without an optional EM or NEM, does not offer network or I/O connectivity.
    Network Management The CMM provides one RJ-45 100BaseT port and a DB-9 Serial Management port, the Server Module provides a DB-9 serial port. Reference the Management Environmentsection.
    PCI Interfaces The Sun Blade 8000 Modular System I/O is architected using PCI Express technology with total I/O output of 1,920 Gbps when fully populated with 10 Server Modules. The Sun Blade 8000 chassis can support:
    • Up to two optional I/O PCI Express ExpressModules (EMs)
      and
    • Up to four Network Express Modules (NEMs)
    USB Each optional Server Module provides two USB 2.0 ports.
    Video Each optional Server Module provides a VGA Video connection to the ATI Rage XL graphics chip.
    Environment
    AC input
      • Voltage: 200-240 VAC
      • Frequency: 50-60 Hz
      • Current: 16A per AC input
      • Number of AC Inputs: 6
      • Maximum in-rush current: 40A
      • Power Factor: 0.98
    • Power Calculator
    Input power AC input connection:
    • AMER- L6-20P to IEC 320 C19; 2.5m; Sun PN 180-2005-01
    • EPAC- IEC 309 to IEC 320 320 C19; 2.5m; Sun PN 180-2004-01
    • Preinstalled in rack with power distribution unit – IEC 320 C20 to IEC 320 C19
    Heat output Thermal Design:
    • Total system volumetric airflow (front to rear): 1500 (Cubic Feet per Minute)
    • Airflow direction: Front to back
    • Total heat dissipation / HVAC load: 30,735 BTU/hr (assuming 9,000W)
    • Average temperature rise through chassis: 15° C (59° F)
    Temperature Operating: 5°C to 35°C (41° F to 95° F)
    Nonoperating: -40°C to 65°C (-40° F to 149° F)
    Relative Humidity Operating: 10% to 90% RH, non-condensing, 27° C max wet bulb
    Nonoperating: 5% to 93% RH, non-condensing, 38° C max wet bulb
    Altitude 0 to 7,500 feet (2,286m)
    Regulations
    Meets or exceeds the following requirements:
    RoHS Compliance Level RoHS:YL
    Product Safety
    • UL approved to UL 60950 and C22.2 No. 60950
    • TUV approved to EN60950-1 and CB Report IEC 950 3rd Edition; including all amendments and full worldwide deviations
    • GOST Certification
    • Korean MIC Certification
    • China CCC Mark for power supply only (system is exempt since it is rated greater than 1300W)
    • CE Declaration of Conformance to the Electronic Compatibility Directive and Low Voltage Directive with accompanying “Technical Data File”
    • Approval to Argentinian standards
    Laser Product and Optical I/O
    • FCC Regulation to Code of Federal regulations 21 CFR 1040-Lasers
    • TUV approval to IEC 60825-1 Safety of Laser Products
    • Canadian Radiation Emitting Devices Act REDR C1370
    Emissions and Immunities:
    Electromagnetic Interference
    • 47 CFR 15B (Code of Federal Regulations, Part 15, Subpart B) Class A
    • EN55022:1998 Class A per EMC directive 89/336/EEC (CE Mark)
    • VCCI Class A
    • Industry Canada ICES-003
    • AS/NZ 3548 (Australia/New Zealand)
    • CNS 13438 (Taiwan)
    Immunity
    • EN55024:1998 per EMC Directive 89/336/EEC
    • IEC 61000-4-2 Electrostatic discharge immunity test
    • IEC 61000-4-3 Radiated, radio-frequency, electromagnetic field immunity test
    • IEC 61000-4-4 Electrical fast transient/burst immunity test
    • IEC 61000-4-5 Surge immunity test
    • IEC 61000-4-6 Immunity to conducted disturbances, induced by radio-frequency fields
    • IEC 61000-4-8 Power frequency magnetic field immunity test
    • IEC 61000-4-11 Voltage dips, short interruptions, and voltage variations immunity tests
    Line Distortion EN 61000-3-2 per EMC Directive 89/336/EEC
    Voltage Fluctuations and Flicker EN 61000-3-3 per EMC Directive 89/336/EEC
    Dimensions and Weights
    Chassis Height 838.49mm (33.01 in) – 19 RU minus clearance
    Chassis Width 444.5mm (17.50 in)
    Chassis Depth Includes chassis metal and front bezel:722mm (28.43 in)
    In rack, distance from front vertical mounting rail to rear of chassis:    700mm (27.56 in)
    Weight Fully configured system 243.13kg (536lbs)
    Empty Chassis:    11.34kg (94lbs)
    Blade
    Option # Manufacturing
    Part #    		 Description
    Cables
    Option # Manufacturing
    Part #    		 Description
    X5044A-Z 6 AC Input Power Cords, 20A, Americas Domestic, NEMA L6-20P to IEC320-C19, 4m, RoHS:Y
    180-2005 Buy AC Input Power Cord, 20A, Americas Domestic, NEMA L6-20P to IEC320-C19, 4m, RoHS:Y
    X5045A-Z 4 AC Input Power Cords, 16A, International, IEC309 to IEC320-C19, 4m, RoHS:Y
    180-2004 AC Input Power Cord, 16A, International, IEC309 to IEC320-C19, 4m, RoHS:Y
    X5915A Buy 2 AC Power Cords and Adapters, 30A, NEMA L6-20R to L6-30P, 4M, RoHS:Y
    375-3493 Cable Assembly, Americas, NEMA L6-20R to L6-30P, 4M, RoHS:Y
    X5042A-Z Sun Rack 1000-42 Cable Management Basket, RoHS:Y
    371-1915 Sun Blade 8400 Cable Management Basket, RoHS:Y
    X5043A-Z 530-3813 DB9F to RJ45F, DCE Adapter, RoHS:Y
    X5046A-Z 6 Power Cords, 20A, (IEC 320-C19 to IEC 320, 1.5 M), RoHS:Y
    180-2095 Power Cord, 20A, (IEC 320-C19 to IEC 320, 1.5 M), RoHS:Y
    X5047A-Z 6 Power Cords, 20A, (IEC 320-C19 to IEC 320, 2.0 M), RoHS:Y
    180-2096 Power Cord, 20A, (IEC 320-C19 to IEC 320, 2.0 M), RoHS:Y
    Communication
    Option # Manufacturing
    Part #    		 Description
    X1288A-Z 375-3439 Dual Port 20Gb/sec 4x InfiniBand Host Channel Adapter PCI Express ExpressModule, RoHS:YL
    X1289A-Z 541-1376 Sun 10-Port 4x DDR InfiniBand Network Express (NEM) Module Assembly, RoHS:YL
    X4216A-Z 375-3548 Buy Dual Port 20Gb/sec 4x InfiniBand Host Channel Adapter PCI Express ExpressModule, RoHS:Y
    Ethernet
    Option # Manufacturing
    Part #    		 Description
    X1028A-Z Buy 541-2400 x8 PCI Express Dual 10-Gigabit Ethernet ExpressModule, RoHS:Y
    X1108A-Z Buy 375-3591 x8 PCI Express Dual 10-Gigabit SFP+ Ethernet ExpressModule, RoHS:Y
    X7283A-Z Buy 541-1206 x4 PCI Express Dual Gigabit Ethernet MMF ExpressModule, RoHS:Y
    X7284A-Z Buy 375-3498 x4 PCI Express Quad Gigabit Ethernet UTP ExpressModule
    X7287A-Z Buy 541-2487 x8 PCI Express Quad Gigabit Ethernet UTP ExpressModule, RoHS:Y
    X5040A-Z 541-0389 20-port Gigabit Ethernet Network Express Module (NEM), RoHS:YL
    X7282A-Z 541-0924 x4 PCI Express Dual Gigabit Ethernet UTP ExpressModule, RoHS:Y
    Fan
    Option # Manufacturing
    Part #    		 Description
    n/a 541-0385 Rear Fan Module (RFM), RoHS:Y
    n/a 541-0496 Front Fan Module (FFM), RoHS:Y
    n/a 541-0784 Front Fan Tray Assembly, RoHS:YL
    • 370-7767
    • Front Indicator Module (FIM), RoHS:YL
    • 501-7122
    • Front Fan Card, RoHS:YL
    • 530-3389
    • Front Indicator Cable, RoHS:Y
    • 541-0374
    • Front Fan Tray, RoHS:Y
    n/a 541-0824 Rear Fan Cage Assembly, RoHS:YL
    • 501-7123
    • Rear Fan Board/Module with three RFMs, RoHS:YL
    • 541-0383
    • Rear Fan Cage, RoHS:Y
    Fibre Channel
    Option # Manufacturing
    Part #    		 Description
    SG-XPCIE2FC-EB4-ZBuy 375-3386 4Gb/sec PCI Express Dual Fibre Channel ExpressModule Host Adapter, Emulex, RoHS:Y
    SG-XPCIE2FC-QB4-ZBuy 375-3384 4Gb/sec PCI Express Dual Fibre Channel ExpressModule Host Adapter, QLogic, RoHS:Y
    SG-XPCIE2FCGBE-E-Z Buy 371-4018 4Gb/sec PCI Express Dual FC / Dual Gigabit Ethernet ExpressModule Host Adapter, Emulex, RoHS:Y
    SG-XPCIE2FCGBE-Q-Z Buy 371-4017 4Gb/sec PCI Express Dual FC / Dual Gigabit Ethernet ExpressModule Host Adapter, QLogic, RoHS:Y
    SG-XPCIE20FC-NEM-Z 375-3385 Sun StorageTek 4Gb 20-Port FC NEM Host Bus Adapter, RoHS:YL
    I/O
    Option # Manufacturing
    Part #    		 Description
    n/a 541-0821 I/O Chassis Assembly, RoHS:YL
    • 541-0823
    • Centerplane Assembly, RoHS:YL
    • 541-0373
    • Bus Bar Assembly, RoHS:Y
    • 341-0777
    • Bus Bar, RoHS:Y
    • 501-6971
    • Centerplane, RoHS:YL
    • 530-3393
    • Power Cable, RoHS:Y
    • 371-0308
    • IEC320 C20 Line Filter, RoHS:Y
    • 530-3390
    • Rear Indicator Cable, RoHS:Y
    • 530-3488
    • AC Line Filter to 530-3393 Power Cable, RoHS:Y
    • 541-0419
    • Rear Interface Assembly, RoHS:Y
    • 370-7768
    • Rear Interface Module (RIM), RoHS:YL
    Power
    Option # Manufacturing
    Part #    		 Description
    n/a 300-1774 3048 Watt Power Supply, RoHS:YL
    SCSI
    Option # Manufacturing
    Part #    		 Description
    SG-XPCIE8SAS-EB-ZBuy 375-3486 Sun StorageTek SAS Host Bus Adapter PCI Express ExpressModule, RoHS:Y
