Oracle Sun E6800 Server

Oracle Sun E6800 Server Oracle Sun E6800 Server Sun Servers SUN FIRE 6800 copy

REQUEST A PRICE QUOTE:

    Name*

    Phone

    Details*



    Processor
    Number Two to 24
    Architecture UltraSPARC[tm] III: 750MHz
    UltraSPARC III Cu (copper based): 900MHz, 1050MHz or 1200MHz
    UltraSPARC IV: 1050MHz, 1200MHz or 1350MHz
    UltraSPARC IV+: 1.5GHz or 1.8GHz
    Cache per processor UltraSPARC III and III CU:
    Primary (L1): 32 KB instruction, and 64 KB data cache
    Secondary (L2): 8 MB, ECC protected
    UltraSPARC IV:
    Primary (L1): 64 KB 4-way data, 32 KB 4-way instruction, 2 KB Write, 2 KB Prefetch
    Secondary (L2): 16 MB external (exclusive access to 8 MB per pipeline), On-chip controller and address tags
    UltraSPARC IV+:
    Primary (L2): 2 MB on-chip
    Secondary (L3): 32 MB off-chip
    CPU interface Packet-switch crossbar connecting up to 6 CPU/Memory boards, and up to 4 I/O assemblies
    System Interconnect Fireplane, 9.6 GB/sec (at 150 MHz)
    System Boards
    Number of boards Maximum of 6 CPU/Memory boards and 4 I/O assemblies
    CPU/Memory board Two CPU’s with 32 GB (max) Memory or four CPU’s with 64 GB (max) memory
    PCI I/O Assembly Eight PCI slots supporting:
    6 full or short cards
    Oracle Sun E6800 Server Oracle Sun E6800 Server indent bullet4 at 33 MHz, 5V (slots 2, 4, 5, 6)
    Oracle Sun E6800 Server Oracle Sun E6800 Server indent bullet2 at 33/66 MHz, 3.3V (slots 3, 7)
    2 short boards
    Oracle Sun E6800 Server Oracle Sun E6800 Server indent bullet33 MHz, 5V (slots 0 and 1)
    CompactPCI I/O Assembly Four CompactPCI slots supporting 4-3U cPCI cards
    Oracle Sun E6800 Server Oracle Sun E6800 Server indent bullet2 at 33/66 MHz, 3.3V (slot 0 and 1)
    Oracle Sun E6800 Server Oracle Sun E6800 Server indent bullet2 at 33 MHz, 5V (slots 2 and 3)
    PCI-X I/O Assembly Eight 64-bit PCI-X slots
    Oracle Sun E6800 Server Oracle Sun E6800 Server indent bullet6 at 100 MHz
    Oracle Sun E6800 Server Oracle Sun E6800 Server indent bullet2 at 33 MHz
    Main Memory
    64 GB memory (max) per 4 CPU’s or 32 GB memory (max) per 2 CPU’s on a CPU/Memory boardMaximum system memory capacity of 384 GB (6 × 64 GB)1GB DIMMs are not supported on 750MHz CPU/Memory boards.Note: The UltraSPARC III processor contains an integrated memory controller which is responsible for memory management of local memory and for running diagnostics on the CPU/Memory board. Therefore, memory capacity is directly related to the number of CPU’s.
    Standard Interfaces
    System Controller Responsible for the overall control of the system. Each System Controller includes one RS-232/423 (DB25) serial interface and one 10/100BASE-T ethernet/fast ethernet (RJ45) interface. Dual system controllers are standard on the Sun Fire 6800.
    Internal Mass Storage
    Sun StorEdge[tm] D240 Media Tray A 2U-high, rack-mounted unit into which two UltraWide SCSI3 disk drive, and one DVD drive and one DDS4 tape drive can be fitted. The DVD and DDS4 devices can be replaced by extra disk drives if required. Up to 3 – D240 trays can be installed into the Sun Fire 6800 cabinet.
    Power Supplies
    The Sun Fire 3800-6800 server family can be configured with N”4″ redundant DC bulk power supplies, which are hot swappable. The DC bulk power supplies provide power for all of the Sun Fire 3800-6800 systems’ internal requirements, on a load-shared 48VDC power bus. The base package comes with 6 power supplies.
    Environment
    AC power 200 – 240 VAC, 47 – 63 Hz, 34 A with 2 RTS
    Input power 6,460 W
    Heat output 22,030 BTU/hr
    Temperature Optimal: 21° C to 23° C (70° F to 73.5° F)
    Operating: 5° C to 35° C (41° F to 95° F) – derate 2° C for every 1 km up to 3 km
    Nonoperating: -20° C to 60° C (-4° F to 140° F)
    Humidity Optimal: 45% to 50% relative humidity
    Operating: 20% to 80% relative humidity, noncondensing
    Nonoperating: 5% to 93% relative humidity, noncondensing
    Acoustic noise 69 dB(A)
    Vibration Operating: 0.15 G, 5 to 500Hz, swept sine
    Nonoperating: 0.6 G, 5 to 500Hz, swept sine, vertical
    0.3 G, 5 to 500Hz, swept sine, horizontal
    Shock Operating: 3 G, 11 ms, half sine
    Number of cords1 2 or 4 (dual power grid feature)
    1 One power cord for each RTS installed. Minimum required is two and maximum is four.
    Regulations
    Meets or exceeds the following requirements:
    Safety UL 1950, CSA C22.2 950, TUB EN60950, CB Scheme (Worldwide Deviation)
    RFI/EMI FCC Class A, ICES 003 Class A, DOC Class A, EN55022 Class A, VCCI Class A, BSMI Class A, EN61000-3-2 & EN61000-3-3
    Immunity EN55024, EN50082-1
    Dimensions and Weights
    Height 75.00 in, 190.5 cm
    Width 24.00 in, 61.0 cm
    Depth 53.00 in, 134.6 cm
    Weight, main cabinet 1000 lbs, 454 kg
    Power Cord 180 in (15 ft), 457.2 cm (4.6 m)
    Backplane/Centerplane
    Option # Manufacturing
    Part #    		 Description
    n/a 501-4405 6 Slot System Centerplane (Factory Installed)
    n/a 501-5005 Power Distribution Centerplane
    n/a 501-5006 Fan Distribution Centerplane
    n/a 501-5879 6 Slot System Centerplane (FRU)
    Blade
    Option # Manufacturing
    Part #    		 Description
    XUSBRDT-5240-128Z 594-5253 Sun Fire USBRDT 5240 Uniboard with 128 GB Memory (32 x 4GB), 2 CPUs (1.2GHz, 8-core UltraSPARC T2+), and 2 Drives, RoHS:Y
    XUSBRDT-5240-64Z 594-5252 Sun Fire USBRDT 5240 Uniboard with 64 GB Memory (32 x 4GB), 2 CPUs (1.2GHz, 8-core UltraSPARC T2+), and 2 Drives, RoHS:Y
    Boot PROM
    Socket Manufacturing
    Part #    		 Patch
    U2107 n/a 114525 (5.18.x)
    Cables
    Option # Manufacturing
    Part #    		 Description
    X3800A AC Input Power Cable Option (North American, Asian), RoHS:Y
    180-1943 AC Input Power Cable, Harting Han 6HsB to NEMA L6-30P (North American, Asian), RoHS:Y
    X3808A Watertight Power Cord (INTL), Blue 32A Watertight IEC 309 to Han 6HsB, RoHS:Y
    180-2063 Power Cord, Blue 32A Watertight IEC 309 to Han 6HsB (INTL), RoHS:Y
    X3848A AC Input Power Cable, Harting Han 6HsB to IEC309 (International), RoHS:Y
    180-1944 AC Input Power Cable, Harting Han 6HsB to IEC309 (INTL), RoHS:Y
    X3806A Watertight Power Cord (US), Blue 30A Watertight IEC 309 to Han 6HsB, RoHS:Y
    180-2058 Power Cord, Blue 30A Watertight IEC 309 to Han 6HsB (US), RoHS:Y
    n/a 180-1945 Power Cord IEC320 to AMP Mate-N-Lok, 2M, RoHS:Y
    n/a 180-1946 AC Power Cable .61 Meter
    n/a 180-1947 AC Power Cable 1.5 Meter
    n/a 180-1948 Power Cord IEC320 to AMP Mate-N-Lok, 3M, RoHS:Y
    Communication
    Option # Manufacturing
    Part #    		 Description
    X1071A 370-3878 HIPPI/P 1.1 High Performance Interface Board
    X1074A 370-3868 SCI Adapter (SCI/P)
    X1155A 370-2728 High Speed Serial Interface PCI (HSI/P) 2.0
    X1157A 501-3028 SunATM-155/MFiber PCI 4.0
    X1158A 501-3027 SunATM-155/UTP PCI 4.0
    X1159A 501-3029 SunATM-622/MFiber PCI 4.0
    X1266A 501-5483 Compact PCI (cPCI) SunATM 155 MMF NIC
    X1268A 501-5564 Compact PCI (cPCI) SunATM 622 MMF NIC
    X2156A 375-0100 Serial Asynchronous Interface PCI (SAI/P) 3.0
    X3895A 370-3922 Cluster 4 port SCI switch, Dolphin Model D515
    X3901A 530-2869 Cluster SCI Cable, 2M
    X3903A 530-2871 Cluster SCI Cable, 7.5M
    X3904A 530-2872 Cluster SCI Cable, 10M
    X4011A 501-6039 Crypto Accelerator 4000 UTP (copper)
    X4012A 501-6040 Crypto Accelerator 4000 MMF (fiber)
    X6762A 375-3089 Crypto Accelerator 1000
    Ethernet
    Option # Manufacturing
    Part #    		 Description
    X4445A 501-6738 Quad GigaSwift PCI-X Ethernet (QGE-X), RoHS:Y
    X7285A 371-0911 Low Profile PCI-X Dual Gigabit Ethernet UTP, RoHS:Y
    X7286A 371-0912 Low Profile PCI-X Single Gigabit Ethernet MMF, RoHS:Y
    X1033A 501-5019 Sun FastEthernet PCI Adapter (FE/P) 2.0
    X1034A 501-5406 Quad FastEthernet PCI (QFE/P)
    X1141A 501-4373 Gigabit Ethernet PCI (GBE/P) 2.0
    X1150A 501-5902 Sun GigaSwift Ethernet UTP (Copper)
    X1151A 501-5524 Sun GigaSwift Ethernet MMF (Fiber)
    X1234A 501-5502 Compact PCI (cPCI) QuadFastEthernet (QFE)
    X1261A 501-5523 Compact PCI (cPCI) Gigabit Ethernet
    X3150A 501-5902 Sun GigaSwift Ethernet UTP (Copper)
    X3151A 501-5524 Sun GigaSwift Ethernet MMF (Fiber)
    X4150A 501-6719 GigaSwift Ethernet UTP (GCS)
    X4151A 501-6762 GigaSwift Ethernet MMF (GFS)
    X4444A 501-6522 Quad GigaSwift Ethernet UTP (QGE)
    Fan
    Option # Manufacturing
    Part #    		 Description
    X4320A 540-3662 Fan Tray System Rack
    X4322A 540-3632 Fan Tray CPU Area (FT1 & FT3)
    n/a 540-3631 Fan Tray I/O Area (FT0 & FT2)
    Fibre Channel
    Option # Manufacturing
    Part #    		 Description
    SG-XPCI1FC-EM4-Z 375-3398 4Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI1FC-QF4 375-3354 4Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI2FC-EM4-Z 375-3399 4Gb PCI-X Dual FC Host Adapter, RoHS:Y
    SG-XPCI2FC-QF4 375-3294 4Gb PCI-X Dual FC Host Adapter, RoHS:Y
    X6748A 375-0118 Compact PCI (cPCI) Dual Channel FC
    SG-XPCI1FC-EM2 375-3304 2Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI1FC-JF2 375-3156 JNI 2Gb PCI Single FC Host Adapter
    SG-XPCI1FC-QF2 375-3102 2Gb PCI Single FC Host Adapter
    SG-XPCI1FC-QL2 375-3383 2Gb PCI-X Single FC Host Adapter, RoHS:Y
    SG-XPCI2FC-EM2 375-3305 2Gb PCI-X Dual FC Host Adapter, RoHS:Y
    SG-XPCI2FC-JF2 375-3157 JNI 2Gb PCI Dual FC Host Adapter
    SG-XPCI2FC-QF2 375-3108 2Gb PCI Dual FC Host Adapter
    • 240-4839
    • Low Profile Bracket, RoHS:Y
    SG-XPCI2FC-QF2-Z 375-3363 2Gb PCI Dual FC Host Adapter, RoHS:Y
    • 240-4839
    • Low Profile Bracket, RoHS:Y
    X6727A 375-3030 PCI Dual FC Host Adapter+, RoHS:YL
    X6767A 375-3102 2Gb PCI Single FC Host Adapter
    X6768A 375-3108 2Gb PCI Dual FC Host Adapter
    • 240-4839
    • Low Profile Bracket, RoHS:Y
    X6799A 375-3019 PCI Single FC Host Adapter
    Graphics
    Option # Manufacturing
    Part #    		 Description
    X3678A-F 370-3987 Expert3D 24-Bit Color Frame Buffer
    370-4272 Fan Board
    X3689A 375-3101 XVR-1200 Graphics Accelerator
    X3689A-F 370-4272 Fan Board
    375-3101 XVR-1200 Graphics Accelerator
    I/O
    Option # Manufacturing
    Part #    		 Description
    FX800-FP 340-7924 Filler Panel cover for blank I/O Assembly Position (boat)
    X3692A 375-3140 I/O Combo Card
    375-3180 Myrinet PCI Card
    530-3288 Myrinet 2000 25 Meter Cable
    X4030A 501-4868 cPCI I/O Assembly (4 slot)
    540-4617 cPCI I/O Assembly (4 slot)
    X4050A 501-4404 PCI I/O Assembly (8 slot)
    540-4616 PCI I/O Assembly (8 slot)
    X4051A 540-6247 PCI+ I/O Board FRU Assembly
    • 501-6133
    • PCI+ I/O Board
    X4051A-Z PCI+ I/O Board Option, RoHS:YL
    540-7832 PCI+ I/O Board FRU Assembly, RoHS:YL
    • 501-7455
    • PCI+ I/O Board, RoHS:YL
    X4052A-Z 540-7831 PCI-X I/O Assembly, RoHS:YL
    • 501-6934
    • PCI-X I/O Board, RoHS:YL
    X4141A 540-4764 SunFire Link Assy, w/ optical module
    • 375-0093
    • cPCI Fire Link Optical Module (Paroli)
    • 501-6094
    • Sun Fire Link Asly, w/o optical module
    X4170A 540-4946 Sun Fire Link Switch
    • 300-1518
    • 150W Power Supply
    • 370-4393
    • Fan Tray
    • 501-5637
    • System Controller
    • 501-5939
    • WCIX Module
    • 540-5205
    • Backplane + AC Harness + AC Module
    X4175A 540-5477 Sun Fire Link Optical Module
    • 375-0093
    • cPCI Fire Link Optical Module (Paroli)
    X4180A 537-1022 Sun Fire Link Optical Cable, 5m
    X4181A 537-1023 Sun Fire Link Optical Cable, 12m
    X4182A 537-1024 Sun Fire Link Optical Cable, 20m
    n/a 540-6509 PCI-X I/O Assembly, RoHS:YL
    • 501-6934
    • PCI-X I/O Board, RoHS:YL
    IDPROM
    Socket Manufacturing
    Part #    		 Component Type Host ID
    n/a 501-5132 ID Board (SEEPROM) 8xxxxxxx
    n/a 501-5880 ID Board (SEEPROM) 8xxxxxxx
    Memory
    Option # Manufacturing
    Part #    		 Description
    X7056A 4 GB (4 × 1GB SDRAM DIMMs)
    501-7386 1GB SDRAM DIMM, RoHS:YL
    X7051A 2 GB (4 × 512MB SDRAM DIMMs)
    501-7385 512MB SDRAM DIMM, RoHS:YL
    X7053A 1 GB (4 × 256MB SDRAM DIMMs)
    501-5401 256MB SDRAM DIMM
    X7058A-Z 8 GB (4 × 2GB SDRAM DIMMs), RoHS:YL
    540-6489 2GB SDRAM DIMM Assembly, RoHS:YL
    • 501-6242
    • 2GB SDRAM DIMM, RoHS:YL
    n/a 501-5030 512MB SDRAM DIMM
    n/a 501-6109 1GB SDRAM DIMM
    n/a 540-5086 1GB SDRAM DIMM
    F511-1030 Package of 25 × 512MB SDRAM DIMMs
    • 501-7385
    • 512MB SDRAM DIMM, RoHS:YL
    F511-1031 Package of 25 × 1GB SDRAM DIMMs
    • 501-7386
    • 1GB SDRAM DIMM, RoHS:YL
    Miscellaneous
    Option # Manufacturing
    Part #    		 Description
    X4070A 501-4953 Level 2 Repeater Board
    501-6418 Level 2 Repeater Board
    X6800-USIV-KIT Sun Fire 6800 Power Upgrade Kit
    595-7283 Sun Fire 6800 Power Upgrade Kit Assembly
    • 300-1595
    • Power Supply, A184, AC-48VDC
    X6800-USIV-KIT-Z Sun Fire 6800 Power Upgrade Kit, RoHS:YL
    594-5781 Sun Fire 6800 Power Upgrade Kits Assembly, RoHS:Y
    • 300-2225
    • Power Supply, A184, AC-48VDC, RoHS:YL
    XE6900-FP-SWITCH-Z Sun FIre E6900 Fireplane Switch Upgrade Kit X-Option, RoHS:YL
    540-7086 Level 2 Repeater Board, RoHS:YL
    • 501-7594
    • Level 2 Repeater Board Assembly, V2, RoHS:YL
    • 501-7595
    • L2 Repeater Board, V2, RoHS:YL
    XE6900-USIV+KIT-Z 594-5810 Power Supply Upgrade Kit for 1.8GHz Uniboards, RoHS:YL
    • 300-2223
    • Power Supply, A212, AC-48VDC, RoHS:YL
    n/a 501-7231 Level 2 Repeater Board Assembly, RoHS:YL
    • 501-7335
    • L2 Repeater Board, RoHS:YL
    n/a 540-4523 Sun StorEdge D240 Mediatray
    n/a 594-3419 Power Supply Upgrade Kit for 1.8GHz Uniboards, RoHS:YL
    • 300-1836
    • Power Supply, A212, AC-48VDC, RoHS:YL
    n/a 594-3456 Sun Fire 6800 Power Upgrade Kits Assembly, RoHS:YL
    • 300-1930
    • Power Supply, A184, AC-48VDC, RoHS:YL
    Power
    Option # Manufacturing
    Part #    		 Description
    X4302A 300-1459 Power Supply, A152, AC-48VDC
    X4340A 300-1335 AC Redundant Transfer Unit
    X4341A 300-1396 AC Redundant Transfer Switch
    n/a 300-1595 Power Supply, A184, AC-48VDC
    n/a 300-1836 Power Supply, A212, AC-48VDC, RoHS:YL
    n/a 300-1927 AC Redundant Transfer Unit, RoHS:YL
    n/a 300-1930 Power Supply, A184, AC-48VDC, RoHS:YL
    n/a 300-2223 Power Supply, A212, AC-48VDC, RoHS:YL
    n/a 300-2225 Power Supply, A184, AC-48VDC, RoHS:YL
    n/a 540-3588 AC Input Box
    Rack
    Option # Manufacturing
    Part #    		 Description
    X4349A 595-7069 Earthquake Restraint Hardware for Sun Fire 6800 / E6900 Cabinet
    X4349A-Z 594-3513 Earthquake Restraint Hardware for Sun Fire 6800/E6900, RoHS:Y
    X4359A 595-6351 Rack Mount Kit for Unipacks
    n/a 540-3353 Sun Fire 6800 Cabinet
    • 340-4174
    • Cabinet Frame
    n/a 540-3883 Frame Manager
    n/a 540-3996 Patch Panel
    SCSI
    Option # Manufacturing
    Part #    		 Description
    SG-XPCI2SCSI-LM320 375-3191 PCI/PCI-X Dual Ultra320 SCSI Adapter
    X1032A 501-5656 Single-Ended Ultra/Wide SCSI/FastEthernet (SunSwift PCI)
    X1232A 501-5570 Compact PCI (cPCI) Single Ended UltraSCSI + 10/100 Ethernet
    X2222A 501-5727 Dual FastEthernet / Dual SCSI PCI Adapter
    X4422A 501-6635 Dual GigabitEthernet / Dual SCSI PCI Adapter
    X6540A 375-0005 Dual Single-Ended Ultra/Wide SCSI (PCI)
    X6541A 375-0006 Dual Differential Ultra/Wide SCSI (UDWIS/P)(HVD)
    X6749A 375-0119 Dual Differential Ultra/Wide SCSI, (UDWIS/cPCI)(HVD)
    X6758A 375-3057 PCI Dual Ultra3 SCSI Host Adapter (LVD)
    System Board
    Option # Manufacturing
    Part #    		 Description
    X4006A-CDP 540-5821 CPU/Memory Uniboard w/ 2× US III Cu 900MHZ, 0MB
    X4007A-CDP 540-5825 CPU/Memory Uniboard w/ 4× US III Cu 900MHZ, 0MB
    XCPUBD-2-1050-CDP 540-5795 CPU/Memory Uniboard w/ 2× US III Cu 1050MHz, 0MB
    XCPUBD-222-1200 540-5682 CPU/Memory Uniboard w/ 2× US III Cu 1.2GHz, 4GB
    XCPUBD-4-1050-CDP 540-5799 CPU/Memory Uniboard w/ 4× US III Cu 1050MHz, 0MB
    XS400BRD-482-1050 540-5662 CPU/Memory Uniboard w/ 4× US IV 1.05GHz, 16GB
    XS400BRD-482-1050C Capacity On Demand (COD) Uniboard w/4× unlicensed US IV 1.05GHz, 16GB
    540-6070 CPU/Memory Uniboard w/ 4× US IV 1.05GHz, 16GB
    XS400BRD-482-1200C 540-6071 Capacity On Demand (COD) Uniboard w/ 4× unlicensed US IV 1.2GHz,
    16GB
    XS400BRD-484-1050 540-5663 CPU/Memory Uniboard w/ 4× US IV 1.05GHz, 32GB
    XS400BRD-484-1050C Capacity On Demand (COD) Uniboard w/ 4× unlicensed US IV 1.05GHz, 32GB
    540-6072 CPU/Memory Uniboard w/ 4× US IV 1.05GHz, 32GB
    XS400BRD-484-1200 540-5939 CPU/Memory Uniboard w/ 4× US IV 1.2GHz,
    32GB
    XS400BRD-484-1200C 540-6073 Capacity On Demand (COD) Uniboard w/ 4× unlicensed US IV 1.2GHz,
    32GB
    XUS3BD-222-1200-Z 540-6843 CPU/Memory Uniboard w/ 2× US III Cu 1.2GHz, 4GB, RoHS:YL
    XUS4BD-448-1950-Z CPU/Memory Uniboard w/4× US IV+ 1.95GHz, 32GB, RoHS:YL
    540-7133 CPU/Memory Uniboard w/4× US IV+ 1.95GHz, 32GB, RoHS:YL
    XUS4BD-482-1050-Z 540-6989 CPU/Memory Uniboard w/ 4× US IV 1.05GHz, 16GB, RoHS:YL
    XUS4BD-482-1050C-Z Capacity On Demand (COD) Uniboard w/ 4× unlicensed US IV 1.05GHz, 16GB
    540-6989 CPU/Memory Uniboard w/ 4× US IV 1.05GHz, 16GB, RoHS:YL
    XUS4BD-482-1800-Z CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 16GB, RoHS:YL
    540-6754 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 16GB, RoHS:YL
    540-7071 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 16GB, RoHS:YL
    540-7201 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 16GB, RoHS:YL
    540-7528 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 16GB, RoHS:YL
    540-7535 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 16GB, RoHS:YL
    XUS4BD-484-1050-Z 540-6847 CPU/Memory Uniboard w/ 4× US IV 1.05GHz, 32GB, RoHS:YL
    XUS4BD-484-1050C-Z Capacity On Demand (COD) Uniboard w/ 4× unlicensed US IV 1.05GHz, 32GB
    540-6847 CPU/Memory Uniboard w/ 4× US IV 1.05GHz, 32GB, RoHS:YL
    XUS4BD-484-1800-Z CPU/Memory Uniboard w/4× US IV+ Cu 1.8GHz, 32GB, RoHS:YL
    540-6755 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 32GB, RoHS:YL
    540-7072 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 32GB, RoHS:YL
    540-7202 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 32GB, RoHS:YL
    540-7529 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 32GB, RoHS:YL
    540-7536 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 32GB, RoHS:YL
    SF-XCPUBD-227 540-4830 CPU/Memory Uniboard w/ 2× US III 750MHZ,
    2GB
    SF-XCPUBD-447 540-4829 CPU/Memory Uniboard w/ 4× US III 750MHZ,
    4GB
    SF-XCPUBD-487 540-4832 CPU/Memory Uniboard w/ 4× US III 750MHZ,
    8GB
    X4004A 540-4729 CPU/Memory Uniboard w/ 2× US III 750MHZ,
    0MB
    X4005A 540-4730 CPU/Memory Uniboard w/ 4× US III 750MHZ,
    0MB
    X4006A 540-5051 CPU/Memory Uniboard w/ 2× US III Cu 900MHZ, 0MB
    X4007A 540-5052 CPU/Memory Uniboard w/ 4× US III Cu 900MHZ, 0MB
    XCPUBD-2029 540-5822 CPU/Memory Uniboard w/ 2× US III Cu 900MHZ, 2GB
    XCPUBD-2049 540-5823 CPU/Memory Uniboard w/ 2× US III Cu 900MHZ, 4GB
    XCPUBD-2089 540-5824 CPU/Memory Uniboard w/ 2× US III Cu 900MHZ, 8GB
    XCPUBD-221-1050 540-5796 CPU/Memory Uniboard w/ 2× US III Cu 1050MHz, 2GB
    XCPUBD-222-1050 540-5797 CPU/Memory Uniboard w/ 2× US III Cu 1050MHz, 4GB
    XCPUBD-224-1050 540-5798 CPU/Memory Uniboard w/ 2× US III Cu 1050MHz, 8GB
    XCPUBD-4049 540-5826 CPU/Memory Uniboard w/ 4× US III Cu 900MHZ, 4GB
    XCPUBD-441-1050 540-5800 CPU/Memory Uniboard w/ 4× US III Cu 1050MHz, 4GB
    XCPUBD-441-1200 540-5684 CPU/Memory Uniboard w/ 4× US III Cu 1.2GHz, 4GB
    XCPUBD-442-1050 540-5858 CPU/Memory Uniboard w/ 4× US III Cu 1050MHz, 8GB
    XCPUBD-442-1200 540-5859 CPU/Memory Uniboard w/ 4× US III Cu 1.2GHz, 8GB
    XCPUBD-481-1050 540-5801 CPU/Memory Uniboard w/ 4× US III Cu 1050MHz, 8GB
    XCPUBD-481-1050-C Capacity On Demand (COD) Uniboard w/ 4× unlicensed US III Cu 1050MHz, 8GB
    540-5819 CPU/Memory Uniboard w/ 4× US III Cu 1050MHz, 8GB
    XCPUBD-481-1200 540-5685 CPU/Memory Uniboard w/ 4× US III Cu 1.2GHz, 8GB
    XCPUBD-481-1200-C Capacity On Demand (COD) Uniboard w/ 4× unlicensed US III Cu 1.2GHz, 8GB
    540-5732 CPU/Memory Uniboard w/ 4× US III Cu 1.2GHz, 8GB
    XCPUBD-482-1050 540-5780 CPU/Memory Uniboard w/ 4× US III Cu 1050MHz, 16GB
    XCPUBD-482-1050-C Capacity On Demand (COD) Uniboard w/ 4× unlicensed US III Cu 1050MHz, 16GB
    540-5820 CPU/Memory Uniboard w/ 4× US III Cu 1050MHz, 16GB
    XCPUBD-482-1200 540-5603 CPU/Memory Uniboard w/ 4× US III Cu 1.2GHz, 16GB
    XCPUBD-482-1200-C Capacity On Demand (COD) Uniboard w/ 4× unlicensed US III Cu 1.2GHz, 16GB
    540-5740 CPU/Memory Uniboard w/ 4× US III Cu 1.2GHz, 16GB
    XCPUBD-484-1050 540-5803 CPU/Memory Uniboard w/ 4× US III Cu 1050MHz, 32GB
    XCPUBD-484-1200 540-5604 CPU/Memory Uniboard w/ 4× US III Cu 1.2GHz, 32GB
    XCPUBD-484-1200-C Capacity On Demand (COD) Uniboard w/ 4× unlicensed US III Cu 1.2GHz, 32GB
    540-6010 CPU/Memory Uniboard w/ 4× US III Cu 1.2GHz, 32GB
    XCPUBD-F4089 540-5827 CPU/Memory Uniboard w/ 4× US III Cu 900MHZ, 8GB
    XCPUBD-F4089-C Capacity On Demand (COD) Uniboard w/ 4× unlicensed US III Cu 900MHz, 8GB
    540-5474 CPU/Memory Uniboard w/ 4× US III Cu 900MHz, 8GB
    XCPUBD-F4169 540-5829 CPU/Memory Uniboard w/ 4× US III Cu 900MHz, 16GB
    XCPUBD-F4329 540-5830 CPU/Memory Uniboard w/ 4× US III Cu 900MHz, 32GB
    XS400BRD-482-1200 540-5938 CPU/Memory Uniboard w/ 4× US IV 1.2GHz,
    16GB
    XUS3BD-442-1200-Z 540-6844 CPU/Memory Uniboard w/ 4× US III Cu 1.2GHz, 8GB, RoHS:YL
    XUS3BD-482-1200-Z 540-6845 CPU/Memory Uniboard w/ 4× US III Cu 1.2GHz, 16GB, RoHS:YL
    XUS3BD-484-1200-Z 540-6846 CPU/Memory Uniboard w/ 4× US III Cu 1.2GHz, 32GB, RoHS:YL
    XUS4BD-444-1950-Z CPU/Memory Uniboard w/4× US IV+ 1.95GHz, 16GB, RoHS:YL
    540-7132 CPU/Memory Uniboard w/4× US IV+ 1.95GHz, 16GB, RoHS:YL
    XUS4BD-482-1350-Z 540-6830 CPU/Memory Uniboard w/ 4× US IV 1.35GHz, 16GB, RoHS:YL
    XUS4BD-482-1350C-Z Capacity On Demand (COD) Uniboard w/ 4× unlicensed US IV 1.35GHz, 16GB
    540-6830 CPU/Memory Uniboard w/ 4× US IV 1.35GHz, 16GB, RoHS:YL
    XUS4BD-482-1500-Z 540-6833 CPU/Memory Uniboard w/ 4× US IV+ 1.5GHz, 16GB, RoHS:YL
    XUS4BD-482-1500C-Z Capacity On Demand (COD) Uniboard w/ 4× unlicensed US IV+ 1.5GHz, 16GB
    540-6833 CPU/Memory Uniboard w/ 4× US IV+ 1.5GHz, 16GB, RoHS:YL
    XUS4BD-482-1800C-Z Capacity On Demand (COD) Uniboard w/4× unlicensed US IV+ 1.8GHz, 16GB, RoHS:YL
    540-6754 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 16GB, RoHS:YL
    540-7071 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 16GB, RoHS:YL
    540-7201 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 16GB, RoHS:YL
    540-7528 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 16GB, RoHS:YL
    540-7535 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 16GB, RoHS:YL
    XUS4BD-484-1350-Z 540-6831 CPU/Memory Uniboard w/ 4× US IV 1.35GHz, 32GB, RoHS:YL
    XUS4BD-484-1350C-Z Capacity On Demand (COD) Uniboard w/ 4× unlicensed US IV 1.35GHz, 32GB
    540-6831 CPU/Memory Uniboard w/ 4× US IV 1.35GHz, 32GB, RoHS:YL
    XUS4BD-484-1500-Z 540-6834 CPU/Memory Uniboard w/ 4× US IV+ 1.5GHz, 32GB, RoHS:YL
    XUS4BD-484-1500C-Z Capacity On Demand (COD) Uniboard w/ 4× unlicensed US IV+ 1.5GHz, 32GB
    540-6834 CPU/Memory Uniboard w/ 4× US IV+ 1.5GHz, 32GB, RoHS:YL
    XUS4BD-484-1800C-Z Capacity On Demand (COD) Uniboard w/ 4× unlicensed US IV+ 1.8GHz, 32GB, RoHS:YL
    540-6755 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 32GB, RoHS:YL
    540-7072 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 32GB, RoHS:YL
    540-7202 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 32GB, RoHS:YL
    540-7529 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 32GB, RoHS:YL
    540-7536 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 32GB, RoHS:YL
    XUS4BD-488-1350-Z CPU/Memory Uniboard w/4× US IV 1.35GHz, 64GB, RoHS:YL
    540-7024 CPU/Memory Uniboard w/4× US IV 1.35GHz, 64GB, RoHS:YL
    XUS4BD-488-1350C-Z Capacity On Demand (COD) Uniboard w/ 4× unlicensed US IV 1.35GHz, 64GB, RoHS:YL
    540-7024 CPU/Memory Uniboard w/4× US IV 1.35GHz, 64GB, RoHS:YL
    XUS4BD-488-1500-Z CPU/Memory Uniboard w/4× US IV+ 1.5GHz, 64GB, RoHS:YL
    540-6802 CPU/Memory Uniboard w/4× US IV+ 1.5GHz, 64GB, RoHS:YL
    XUS4BD-488-1500C-Z Capacity On Demand (COD) Uniboard w/ 4× unlicensed US IV+ 1.5GHz, 64GB, RoHS:YL
    540-6802 CPU/Memory Uniboard w/4× US IV+ 1.5GHz, 64GB, RoHS:YL
    XUS4BD-488-1800-Z CPU/Memory Uniboard w/4× US IV+ Cu 1.8GHz, 64GB, RoHS:YL
    540-6756 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 64GB, RoHS:YL
    540-7073 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 64GB, RoHS:YL
    540-7203 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 64GB, RoHS:YL
    540-7530 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 64GB, RoHS:YL
    540-7537 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 64GB, RoHS:YL
    XUS4BD-488-1800C-Z Capacity On Demand (COD) Uniboard w/ 4× unlicensed US IV+ 1.8GHz, 64GB, RoHS:YL
    540-6756 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 64GB, RoHS:YL
    540-7073 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 64GB, RoHS:YL
    540-7203 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 64GB, RoHS:YL
    540-7530 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 64GB, RoHS:YL
    540-7537 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 64GB, RoHS:YL
    XUS4BRD-482-1200 540-6253 CPU/Memory Uniboard w/ 4× US IV 1.2GHz, 16GB
    XUS4BRD-482-1200C Capacity On Demand (COD) Uniboard w/ 4× unlicensed US IV 1.2GHz, 16GB
    540-6280 CPU/Memory Uniboard w/ 4× US IV 1.2GHz, 16GB
    XUS4BRD-482-1350 540-6296 CPU/Memory Uniboard w/ 4× US IV 1.35GHz, 16GB
    XUS4BRD-482-1350C Capacity On Demand (COD) Uniboard w/4x unlicensed US IV 1.35GHz, 16GB
    540-6296 CPU/Memory Uniboard w/ 4× US IV 1.35GHz, 16GB
    XUS4BRD-484-1200 540-6254 CPU/Memory Uniboard w/ 4× US IV 1.2GHz, 32GB
    XUS4BRD-484-1200C Capacity On Demand (COD) Uniboard w/ 4× unlicensed US IV 1.2GHz, 32GB
    540-6281 CPU/Memory Uniboard w/ 4× US IV 1.2GHz, 32GB
    XUS4BRD-484-1350 540-6297 CPU/Memory Uniboard w/ 4× US IV 1.35GHz, 32GB
    XUS4BRD-484-1350C Capacity On Demand (COD) Uniboard w/4x unlicensed US IV 1.35GHz, 32GB
    540-6297 CPU/Memory Uniboard w/ 4× US IV 1.35GHz, 32GB
    n/a 540-5267 CPU/Memory Uniboard w/ 4× US III Cu 1050MHz, 0MB
    n/a 540-5605 CPU/Memory Uniboard w/ 4× US III Cu 1.2GHz, 0MB
    n/a 540-5623 CPU/Memory Uniboard w/ 2× US III Cu 1050MHz, 0MB
    n/a 540-5691 CPU/Memory Uniboard w/ 2× US III Cu 1.2GHz, 0MB
    n/a 540-5940 CPU/Memory Uniboard w/ 4× US IV 1.2GHz,
    0GB
    n/a 540-6078 CPU/Memory Uniboard w/ 2× US III Cu 900MHz, 0MB
    n/a 540-6079 CPU/Memory Uniboard w/ 4× US III Cu 900MHz, 0MB
    n/a 540-6080 CPU/Memory Uniboard w/ 2× US III Cu 1050MHz, 0MB
    n/a 540-6081 CPU/Memory Uniboard w/ 4× US III Cu 1050MHz, 0MB
    n/a 540-6082 CPU/Memory Uniboard w/ 2× US III Cu 1.2GHz, 0MB
    n/a 540-6083 CPU/Memory Uniboard w/ 4× US III Cu 1.2GHz, 0MB
    n/a 540-6233 CPU/Memory UniBoard w/ 4× US IV 1200MHz, 0MB
    n/a 540-6248 CPU/Memory UniBoard w/ 4× US IV 1050MHz, 0MB
    n/a 540-6251 CPU/Memory Uniboard w/ 4× US IV 1.2GHz, 0GB
    n/a 540-6295 CPU/Memory Uniboard w/ 4× US IV 1.35GHz, 0GB
    n/a 540-6439 CPU/Memory Uniboard w/ 4× US IV+ 1.5GHz, 0MB
    n/a 540-6445 CPU/Memory Uniboard w/ 2× US III 750MHZ
    n/a 540-6446 CPU/Memory Uniboard w/ 4× US III 750MHZ, 0MB
    n/a 540-6753 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 0MB, RoHS:YL
    n/a 540-6803 CPU/Memory Uniboard w/ 4× US IV 1.35GHz, 0GB, RoHS:YL
    n/a 540-6832 CPU/Memory Uniboard w/ 4× US IV+ 1.5GHz, 0MB, RoHS:YL
    n/a 540-6848 CPU/Memory Uniboard w/ 2× US III Cu 1.2GHz, 0GB, RoHS:YL
    n/a 540-6849 CPU/Memory Uniboard w/ 4× US III Cu 1.2GHz, 0GB, RoHS:YL
    n/a 540-6853 CPU/Memory Uniboard w/ 4× US IV 1.05GHz, 0GB, RoHS:YL
    n/a 540-7123 CPU/Memory Uniboard w/4× US IV+ 1.95GHz, 0MB, RoHS:YL
    n/a 540-7527 CPU/Memory Uniboard w/4× US IV+ 1.8GHz, 0MB, RoHS:YL
    n/a 559-0067 CPU/Memory Uniboard w/ 4× US III Cu 900MHz,
    0MB (L2 Cache rework)
    n/a 559-0068 CPU/Memory Uniboard w/ 4× US III Cu 1050MHz,
    0MB (L2 Cache rework)
    n/a 559-0069 CPU/Memory Uniboard w/ 4× US III Cu 1.2GHz,
    0MB (L2 Cache rework)
    n/a 559-0072 CPU/Memory Uniboard w/ 2× US III Cu 900MHz,
    0MB (L2 Cache rework)
    n/a 559-0073 CPU/Memory Uniboard w/ 2× US III Cu 1050MHz,
    0MB (L2 Cache rework)
    n/a 559-0074 CPU/Memory Uniboard w/ 2× US III Cu 1.2GHz,
    0MB (L2 Cache rework)
    n/a 540-5664 CPU/Memory Uniboard w/ 4 × US IV 1.05GHz,
    0GB
    System Controller
    Option # Manufacturing
    Part #    		 Description
    X2763A System Controller Board Version 2 Upgrade
    501-6631 System Controller Version 2
    X2763A-Z 501-7312 System Controller Version 2, RoHS:YL
    n/a 501-5407 System Controller Version 1

    Industry Leading Quality, Support and Integrity

    Quality Inspection Checklist
    Before it leaves our facility, every used and refurbished item is thoroughly inspected by our certified technicians and undergoes our exclusive Quality Inspection Checklist to ensure 100% satisfaction guarantee.

    Greentec Systems is a leading provider
    For server, networking and storage equipment. We have an extensive array of inventory of IBM Servers & Storage, Sun Servers & Storage, Cisco Networking (Switches, Routers, Security), and NetApp Storage (disk shelves, disk drives, Filers, NearStore, NetCache). If you don’t see the item or product you require please contact us.

    Have this equipment to sell?
    Depending on the age and condition of the equipment, there is a very good likelihood that we will be able to offer you cash or trade-in credit for other IT hardware. If the equipment is very old we can also assist you with properly decommissioning that gear in the most environmentally friendly way possible.

    Questions?
    For more information please contact 888.333.7388, or fill out the quote from above. We’d love to hear from you.

    Request Quote
    Greentec Systems We geek out helping you with your IT infrastructure.
    Request a quote or product information
    Send
