NetApp V3020 Storage Virtualization Solution
REQUEST A PRICE QUOTE:
The V3000 series is the midrange NetApp heterogeneous storage virtualization solution for enterprise applications. V3000 systems deliver exceptional capabilities for both business and technical applications, across both SAN and NAS environments.
Description
The V3000 series is the midrange NetApp heterogeneous storage virtualization solution for enterprise applications. V3000 systems deliver exceptional capabilities for both business and technical applications, across both SAN and NAS environments. Three models are available: V3020, V3040, and V3070.
High Scalability
V3000 systems scale to over 500TB of capacity, providing a single architecture and management interface for heterogeneous storage arrays. The V3070 scales to a maximum of 504 LUNs.
Effective Consolidation
The V3000 systems are ideally suited for storage consolidation supporting hundreds of applications because they are not only highly scalable but also very flexible. Data can be stored in either file or block format. Supported protocols include FC, NFS, CIFS, HTTP, and iSCSI for the greatest flexibility.
The Data ONTAP® 7G operating system includes two standard features, FlexVol® and FlexShare™, which improve the effectiveness of consolidation. FlexVol creates volumes that can be readily expanded or contracted while reducing the need for spare capacity. FlexShare enables the consolidation of disparate workloads by ensuring that critical workloads get fast response.
Unique Versatility
V3000 systems can be used for SAN-based and/or NAS-based applications and for primary or secondary storage.
High Availability
A full range of high-availability and disaster recovery options are offered with the V3000 series. However, NetApp goes beyond the data center baseline for availability. Active-active controller configurations enable continuous access to data by automatically failing over to an additional V-Series controller without data loss. Similarly, the NetApp implementation of Snapshot™ copies has no performance impact and requires very little incremental storage, so Snapshot copies can be created frequently. The result is unparalleled application-level availability with recovery in minutes, not hours, after a failure or human error.
Robust SAN
NetApp supports a complete Fibre Channel SAN infrastructure with a full range of certified hosts, adapters, switches, and directors. The V3000 systems are also capable of 4Gb FC SAN
System Configuration
Max. Raw Capacity: 168TB
Max. Cache: 4GB
Max. HDD Count: Array Dependant
Min. HDD Count: Array Dependant
Host Connections: 1Gb FC
2Gb FC
4Gb FC
1Gb iSCSI
1GbE
Dual Controllers: Optional
Expansion Slots: (6) PCI-X
Max. FC Port Count: 8
Max. GigE Port Count: 8
Network Protocol Support: CIFS
HTTP 1.0 Virtual Host
HTTP 1.1 Virtual Host
NDMP
NFS v2
NFS v3
NFS v4
PCNFSD V1
PCNFSD V2
SNMP
NAS/iSCSI Support: NAS & iSCSI
Performance Specifications
Non-Disruptive Options
Component Replacement: Yes
Hot-Pluggable Disks: Yes
Microcode Updates: Yes
